Bernette Chicago 7, Chicago 5 Quick Start Manual
1
Machine SetupMachine Overview
2 3 4 5
Details of the sewing machine
1 Thread guide
2 Presser foot pressure
3 Bobbin winder pre-tension
4 Thread tension dial
5 Spool pin
6 Hole for second spool pin
7 Bobbin winder spindle
8 Bobbin winder stopper
9 LCD display
10 Speed dial
11 Operation buttons
12 Thread cutter
13 One-step buttonhole lever
14 Needle threader
15 Stitch plate cover
16 Sewing table and accessory box
17 Selection buttons
18 Function buttons
19 Top cover
20 Handwheel
21 Embroidery module connector
22 Power switch
23 Power cord
24 Foot control connector
25 Handle
26 Presser foot lever
27 Feed dog lever
28 Embroidery module (Chicago 7)
1
3
4
2
9
11
12
10
13
15
16
14
5
6
7
8
17
18
20
19
28
22
23
24
21
25
27
26
Display Explanation & Operating Functions
Buttons Explanation
1 Start/Stop button
2 Reverse / Exit button
3 Auto-lock / Trace button
4 Needle up/down button
5 Speed dial
6 OK button
7 Arrow buttons
8 Direct pattern selection and Number buttons
9 Mirror image button
10 Elongation / Resize button
11 Double needle / Rotate button
12 Stitch length adjustment / Stitch forward/back button
13 Stitch width adjustment / Colour forward/back button
14 Memory / Setup button
15 Clear / Return button
16 Pattern group selection / Colour setup button
The icon on the button is for sewing mode, and the icon
on the side of the button is for embroidery mode.
Note
1
3
4
2
5
6
7
8
9
11 13
14
16
10 12
15
Threading the Upper Thread
It is important to carry out the threading correctly as by not
doing so several sewing problems can occur.
Note
6
5
7
A
1
2
A
B
C
B
Inserting the Bobbin
Machine Setup
my
bernette
my
city
Quick Start Guide
Machine Overview 2
Details of the sewing machine
Display Explanation & Operating Functions 3
Buttons Explanation
Machine Setup 4-5
Threading the Upper Thread
Inserting the Bobbin
Start to sew 6-7
How to select a stitch
Enter a sequence of stitch motifs in Memory Enter Mode
Start to embroider (Chicago 7) 8-10
Attaching the embroidery foot
Connecting the embroidery module
– Hooping the fabric
Starting to embroider
