Benq S680C Users Manual

Copyright

© 2004. BENQ Corporation. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a
retrieval system or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of
BENQ Corporation.
* This publication includes images from CorelDRAW® 9 which are

protected by the copyright laws of the U.S., Canada and elsewhere. Used
under license.

Disclaimer

BENQ Corporation makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability or fitness for any particular
purpose. Further, BENQ Corporation reserves the right to revise this
publication and to make changes from time to time in the contents hereof
without obligation of BENQ Corporation to notify any person of such
revision or changes.

Safety Information

For your safety, please read the guidelines below carefully
before you use your phone:

Exposure to Radio Frequency Signals

Max. SAR measurement

EU: GSM900: 0.795 mW/g; DCS1800: 0.504 mW/g.
USA: PCS1900: 0.557 mW/g.

Your wireless handheld portable telephone is a low power transmitter and
receiver. When it is ON, it receives and also sends out radio frequency
(RF) signals.
European and international agencies have set standards and
recommendations for the protection of public exposure to RF
electromagnetic energy.

• International Commission on Non-Ionizing Radiation Protection

(ICNIRP) 1996

• Verband Deutscher Elektringenieure (VDE) DIN- 0848

• Directives of the European Community, Directorate General V in

Matters of Radio Frequency Electromagnetic Energy

• National Radiological Protection Board of the United Kingdom, GS 11,

1988

• American National Standards Institute (ANSI) IEEE. C95.1- 1992

• National Council on Radiation Protection and Measurements (NCRP).

Report 86

• Department of Health and Welfare Canada. Safety Code 6
These standards are based on extensive scientific review. For example,
over 120 scientists, engineers and physicians from universities,
government health agencies and industry reviewed the available body of
research to develop the updated ANSI Standard.
The design of your phone complies with these standards when used
normally.

Safety Information i

Specific Operating Restrictions

No metallic component allowed in body-worn accessories.

Antenna Care

Use only the supplied or approved replacement antenna. Unauthorized
antennas, modifications or attachments may damage the phone and
violate FCC regulations.

Phone Operation

Normal Position: Hold the phone as you would any other telephone with
the antenna pointed up and over your shoulder.
For your phone to operate most efficiently, do not touch the antenna
unnecessarily when the phone is in use. Contact with the antenna affects
call quality and may cause the phone to operate at higher power level than
otherwise needed.

Batteries

All batteries can cause property damage, injury or burns if a conductive
material such as jewelry, keys or beaded chains touches exposed terminals.
The material may complete electrical circuit and become quite hot. To
protect against such unwanted current drain, exercise care in handling any
charged battery, particularly when placing it inside your pocket, purse or
other container with metal objects. When battery is detached from the
phone, your batteries are packed with a protective battery cover; please
use this cover for storing your batteries when not in use.

Driving

Check the laws and regulations on the use of wireless telephones in the
areas where you drive. Always obey them. Also, if using your phone while
driving, please:

• Give full attention to driving--driving safety is your first responsibility.

• Use hands-free operation, if available.

ii Safety Information

• Pull off the road and park before making or answering a call if driving

conditions so require.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a
minimum separation of six (6") inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers:

• Should ALWAYS keep the phone more than six inches from their

pacemaker when the phone is turned ON.

• Should not carry the phone in a breast pocket.

• Should use the ear opposite the pacemaker to minimize the potential for

interference.
If you have any reason to suspect that the interference is taking place, turn
your phone OFF immediately.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the
event of such interference you may want to consult your hearing aid
manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.

Safety Information iii

Turn your phone OFF in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or health care facilities may
be using equipment that could be sensitive to external RF energy.

Ve h i c l es

RF signals may affect improperly installed or inadequately shielded
electronic systems in motor vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also consult the
manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notice so requires.

Aircraft

FCC regulations prohibit using your phone while in the air. Switch OFF
your phone before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when
in a “blasting area” or in area posted “TURN OFF TWO-WAY RADIO.”
Obey all signs and instructions.

Potentially Explosive Atmospheres

Turn your phone OFF and do not remove the battery when in any area
with a potentially explosive atmosphere and obey all signs and
instructions. Sparks, from your battery, in such areas could cause an
explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always
clearly marked. They include fueling areas such as gasoline stations; below
deck on boats; fuel or chemical transfer or storage facilities; vehicles using
liquefied petroleum gas (such as propane or butane); areas where the air
contains chemicals or particles, such as grain, dust, or metal powders; and
any other area where you would normally be advised to turn off your
vehicle engine.

iv Safety Information

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including both
installed or portable wireless equipment, in the area over the air bag or in
the air bag deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious injury could result.

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:

1. this device may not cause harmful interference, and

2. this device must accept any interference received, including

interference that may cause undesired operation.

European Union Directives Conformance Statement

This device complies with the OJ-Directive as below:

Electromagnetic Compatibility Directive (89/336/EEC), Low Voltage
Directive (73/23/EEC)
And R&TTE Directive (99/05/EEC).

And also complies with the standard:

3GPP TS 51.010-1
EN 301 511
EN 30360/ EN30361
ETSI EN 301 489-1/-7
EN 60950

Safety Information v

IMPORTANT NOTE:
FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 1.5 cm between the radiator &
your body.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.

vi Safety Information

Table of Contents

Safety Information ...........................................................i

1. Preparing Your Phone For Use................................... 1

Inserting a SIM Card............................................................ 1

Installing a Battery and Charging the Phone ...................... 2

Turning the Phone On ......................................................... 5

2. Getting to Know Your Phone ..................................... 7

Your Phone at a Glance........................................................ 7

Active Flip Feature.............................................................. 10

Status Indicator Light......................................................... 10

Standby Screen.................................................................... 11

External Display .....................................................................11

Icons in the External Display's Status Bar.............................12

Main Screen ............................................................................14

Icons in the Main Display's Status Bar.................................. 16

Using the Keys in the Standby Mode ....................................18

Menu Navigation................................................................ 23

Main menu map.....................................................................30

3. Using Your Phone ..................................................... 33

Making a Phone Call ..........................................................33

Ending a Phone Call........................................................... 33

Answering a Phone Call .....................................................34

Rejecting an Incoming Call................................................ 35

Turning Off the Ring Tone

for an Incoming Call .......................................................... 35

viiTable of Contents

Making an International Call............................................. 35

Making an Emergency Call ................................................ 36

Dialing an Extension Number ........................................... 36

Speed Dialing ...................................................................... 36

Voice Dialing ...................................................................... 36

Listening to Voicemails...................................................... 37

Phone Book......................................................................... 38

Adding Contacts to the Phone Book.....................................38

Finding Contacts in the Phone Book ....................................43

Last Missed, Dialed, and Received Calls............................ 45

Operations During a Call................................................... 47

Call Menu ........................................................................... 49

Using the Silent Profile....................................................... 51

Camera Function................................................................ 52

Shortcuts Menu ..................................................................57

Setting Function Shortcuts ....................................................57

Setting Phone Number Shortcuts..........................................59

Using Function and Phone Number Shortcuts .................... 60

Messages Menu................................................................... 61

Create ......................................................................................63

Short Message..............................................................................63

MMS ............................................................................................66

SIM Folder ..............................................................................71

Inbox .......................................................................................72

Template .................................................................................77

SMS Template .............................................................................77

MMS Template ...........................................................................77

viii Table of Contents

Outbox ....................................................................................77

Drafts.......................................................................................78

Voicemail ................................................................................79

Message Settings .....................................................................79

Cleanup Messages...................................................................84

Memory Status .......................................................................84

Voice Memo........................................................................ 85

Input Modes ....................................................................... 86

Changing the Text Input Mode.............................................86

Letter Input Mode (ABC) ......................................................87

Numeric Input Mode (123)................................................... 87

Predictive Input Mode (iTap) ...............................................87

Symbol Input Mode ...............................................................89

Direct Connection to URLs ...............................................90

4. Menus.........................................................................92

Phone Book......................................................................... 92

Find .........................................................................................92

Add..........................................................................................92

Edit ..........................................................................................92

Copy ........................................................................................93

Delete ......................................................................................93

Caller Groups..........................................................................93

Privacy Manager.....................................................................94

Business Card .........................................................................96

Activate ...................................................................................97

My Number ............................................................................97

SIM Status...............................................................................97

ixTable of Contents

Call Records ........................................................................ 98

Missed Calls ............................................................................98

Received Calls .........................................................................98

Dialed Calls.............................................................................98

Delete All.................................................................................98

Call Duration..........................................................................99

Call Cost................................................................................100

Messages............................................................................ 101

Organizer .......................................................................... 102

Calendar................................................................................102

To Do List .............................................................................104

Note.......................................................................................105

Tools.................................................................................. 105

Camera..................................................................................105

Alarm Clock..........................................................................106

Shortcuts ...............................................................................107

Voice Memo .........................................................................107

Calculator..............................................................................108

Currency Converter .............................................................108

Stopwatch .............................................................................110

Countdown Timer ...............................................................110

Memory Status .....................................................................111

Service Number ....................................................................111

SIM Toolkit Menu................................................................111

Games................................................................................ 112

Champion Soccer .................................................................112

Dragon Fight.........................................................................117

x Table of Contents

Internet.............................................................................. 118

WAP Service .........................................................................118

Start Browser............................................................................. 119

WAP Message............................................................................125

Enter Address ............................................................................125

Resume ......................................................................................125

Clear Cache ...............................................................................125

WAP Settings............................................................................. 125

JAVA .....................................................................................129

Multimedia ....................................................................... 133

Picture...................................................................................133

Animation............................................................................. 134

Melody ..................................................................................134

My Melodies..............................................................................134

Composer ..................................................................................136

Help ...........................................................................................139

Album ...................................................................................139

Settings .............................................................................. 144

Date & Time .........................................................................144

Time...........................................................................................144

Format .......................................................................................144

Secondary Time........................................................................145

Power On/Off .......................................................................145

Profiles ..................................................................................146

Display ..................................................................................150

Theme........................................................................................150

Wallpaper ..................................................................................150

Welcome Message.....................................................................151

Contrast.....................................................................................152

Brightness ..................................................................................152

xiTable of Contents

Backlight Setting .......................................................................152

OLED Duration.........................................................................152

OLED Animation Setting .........................................................153

Audio.....................................................................................153

Power Saving Mode..............................................................153

Call Settings ..........................................................................154

Call Divert .................................................................................154

Call Barring ...............................................................................155

Call Waiting...............................................................................156

Auto Redial................................................................................156

Show Number ...........................................................................156

Fixed Dial Number ...................................................................157

Active Line.................................................................................157

Connect Alert ............................................................................157

Minute Beep ..............................................................................158

Network ................................................................................158

Mode Selection..........................................................................158

Available List .............................................................................158

Band Setting ..............................................................................159

Connection Mode .....................................................................159

Security .................................................................................159

PIN Code...................................................................................159

Phone Lock................................................................................160

SIM Lock ...................................................................................161

Screen Lock ...............................................................................161

Language ...............................................................................162

Input Mode...........................................................................162

Flip Activate..........................................................................162

User Group ...........................................................................163

Restore ..................................................................................163

xii Table of Contents

5. Care and Maintenance ............................................ 164

6. Troubleshooting...................................................... 165

xiiiTable of Contents

xiv Table of Contents

Preparing Your Phone For Use

Inserting a SIM Card

1. Turn the phone over, and release the battery latch. Lift the battery off

the phone.

Battery latch

Do not remove the battery when the phone is on. Doing so could
cause you to lose personal settings or data stored either on your SIM
card or in the phone's memory.

2. Slide the SIM card in under the metal plate in the SIM card slot, with

the SIM card's metal contacts facing down and the cut corner at the
top right.

Metal plate

SIM card

A SIM card can be easily damaged if its metal contacts become
scratched. Therefore, take special care when holding or inserting it.

Preparing Your Phone For Use 1

If you wish to remove the SIM card, you

/

must first press down the stay, then push
the SIM card out of the slot.

SIM card

Stay

Installing a Battery and Charging the Phone

1. With the battery's metal contacts facing down, align the protruding

tabs on the end with the holes in the battery bay of the phone. Then
push the battery toward the end of the bay to insert the battery's tabs
into the holes. Press down to click the battery in place.

2 Preparing Your Phone For Use

2. Insert the charger connector into the charger socket on the bottom of

the phone. Make sure that the connector is inserted in the correct
orientation (with the arrow pointing up).

Charger socket

Charger connector

3. Insert the charger into a power outlet.

4. Once the phone is fully charged, remove the charger from both the

power outlet and the phone.

Preparing Your Phone For Use 3

• Charging requires approximately 4 hours.

/

• When charging the phone while it is turned off, the external and

main displays will be activated, and the status indicator light will
flash blue (during the charging process, the external display will
show the time and cycle through 3 animations, then turn off
temporarily. This is normal.

• During charging, in the external display's battery indicator ,

the lines showing the battery power level will scroll until the battery
is fully charged.

• When charging while the phone is turned off, the main display

shows the animation. If the charging is performed while the

phone is on, the main display shows the icon. The lines
showing the battery power level will scroll until the battery is fully
charged.

• After the battery is fully charged, the status indicator light will flash

purple.

• When the battery is out of power, the phone will play an alert sound

to remind you to recharge it and then will automatically turn off.

Do not remove the battery while the phone is charging.

4 Preparing Your Phone For Use

Tur ni ng t he P hon e O n

1. Open the phone's flip.

2. Press and hold to turn the phone on. The

phone will display the welcome animation.

• You can select and set a welcome animation, image, or message

/

that will display when you turn on your phone, as well as the music
that will be played. Go to the menu: Settings → Display →
Welcome Message. For details, please refer to page 151.

• If the welcoming music goes on too long, once the standby screen

comes up, you can press to stop playback.

3. Enter your PIN1 number. If you enter the PIN1 number incorrectly,

press (Clear) to delete the incorrect numerals. Press and

hold to delete all numerals that have been entered. After

completing entry of your PIN1 number, press to confirm.

8 The PIN (Personal Identification Number) is a password provided by

a network operator with a SIM card. You need this password in order
to use the SIM card.

If you enter the PIN incorrectly 3 times in a row, the SIM card will lock
down and no longer be usable. If this happens, you must enter the
PUK (Personal Unblocking Key) for that SIM card in order to unlock
it. Please contact your network operator to obtain a PUK.

To cancel PIN password authentication, go to the menu Settings →

/

Security → PIN Code → PIN1 Code. Please see page 159.

Preparing Your Phone For Use 5

4. When the PIN code entered has been accepted, the phone will

automatically search for the designated network. This search process
may take a few seconds.

5. The phone will then ask you whether you wish to

activate the phone book stored in the phone's

memory or on your SIM card. Press to
highlight the desired phone book and then press

to open the phone book you have selected.

6. After you open the phone book on the SIM card, any data you

browse, store, or delete will be from the SIM card's phone book. If
you open the phone book in the phone's memory, any data that you
view, store, or delete will be from the phone's phone book.

If at some later point, you wish to switch phone books, go to the

/

following menu Phone Book → Activate.

7. The standby screen will be displayed, as well as network signal

strength and the name of the network operator. You can now use the
phone.

8 If the phone cannot detect the network, the on-screen signal strength

meter will show no bars.

8 If the phone links to a network that you are not authorized to use, the

signal strength meter will show a level of zero. You will only be able to
make emergency calls.

6 Preparing Your Phone For Use

Getting to Know Your Phone

Your Phone at a Glance

The figure below shows the main parts of your phone:

Front v iew 1

Antenna

Status indicator light

External display

External speaker

Getting to Know Your Phone 7

Front view 2

Earpiece

Main display

OK key

Left soft key

Dial/Answer key

Messages menu key

Microphone

8 Getting to Know Your Phone

Scroll key

Right soft key

Power on/off key

Alphanumeric keys

Side and back views

Hands-free headset/Data cable jack

Lanyard hole

Volume ke y

Mirror used to take
self photos

Camera lens

To avoid potential RF interference, and please keep the minimum
distance with 15mm.

Getting to Know Your Phone 9

Active Flip Feature

Opening the flip allows you to answer an incoming call. Closing the flip
ends a call, cancels dialing, or rejects an incoming call.

You can turn the active flip feature on or off. To do so, go to the menu:

/

Settings → Flip Activate.

Status Indicator Light

The status indicator light has the following functions:

• Flashes blue when the phone detects a network or is charging.

• Flashes purple when the battery is fully charged.

• Flashes blue rapidly when there is an incoming call.

8 To turn off the status indicator light, you must start up the power

saving mode. Go to this menu: Settings → Power Saving Mode.

10 Getting to Know Your Phone
