BenQ S68 User Manual

Issued by

BenQ Mobile GmbH & Co. OHG

Haidenauplatz 1

D-81667 Munich

Rights of modification reserved.

Manufactured by BenQ Mobile GmbH & Co. OHG

under trademark license of Siemens AG

www.BenQ-Siemens.com/s68

S68

Table of Contents 1

Safety precautions ..................... 2

Phone overview ......................... 5

Display symbols ......................... 7

Getting started ........................... 8

Switching on/off, PIN entry ........ 9

General instructions ................ 10

Security .................................... 11

Calling ...................................... 13

Phonebook ............................... 14

Call records .............................. 16

Voice mailbox .......................... 16

Messages ................................. 17

Internet .................................... 21

Settings .................................... 23

Organiser ................................. 28

Alarm clock ............................... 29

Ringtones ................................. 29

Extras ........................................ 29

My stuff .................................... 31

Mobile Phone Manager ............32

Customer Care .......................... 33

Care and maintenance ............. 34

Product data ............................. 35

Guarantee certificate (UK) ....... 36

Guarantee certificate (IRL) .......37

SAR ........................................... 38

License Agreement ................... 39

Menu tree ................................. 42

Index ......................................... 47

Safety precautions2

Safety precautions

Information for parents

Please read the operating instructions and safety precautions carefully before use. Explain the content and the hazards associated with using the phone to your children.

Remember to comply with legal requirements and local restrictions when using the phone. For example in aeroplanes, petrol stations, hospitals or while driving.

Mobile phones can interfere with the functioning of medical devices such as hearing aids or pacemakers. Keep at least 20 cm/9 inches between phone and pacemaker. Whilst using the mobile phone, hold it to the ear furthest away from the pacemaker. For more information consult your doctor.

Tones, music and handsfree talking are reproduced through the loudspeaker. Do not hold the phone to your ear when it rings or when you have switched on the handsfree function. Otherwise you risk serious permanent damage to your hearing.

Only use original batteries (100 % mercury-free) and charging devices. Otherwise you risk serious damage to health and property. The battery could explode, for instance.

Do not place the phone near to electromagnetic data carriers such as credit cards and floppy disks. Information stored on them could be lost.

Small parts such as the SIM card, dust cap, lens ring and lens cap can be dismantled and swallowed by small children. The phone must therefore be stored out of the reach of small children.

The mains voltage specified on the power supply unit (V) must not be exceeded. Otherwise the charging device may be destroyed.

The power supply must be plugged into an easily accessible AC mains power socket when charging the battery. The only way to turn off the charging device after charging the battery is to unplug it.

You may only open the phone to replace the battery (100 % mercury-free) or SIM card. You must not open the battery under any circumstances. All other changes to this device are strictly prohibited and will invalidate the guarantee.

3Safety precautions

The phone may cause interference in the vicinity of TV sets, radios and PCs.

All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

This crossed-out wheelie bin symbol on the product means the product is covered by the European Directive 2002/96/EC.

The correct disposal and separate collection of your old appliance will help prevent potential negative consequences for the environment and human health. It is a precondition for re-use and recycling of used electrical and electronic equipment.

For more detailed information about disposal of your old appliance, please contact your local council, waste disposal service or the shop where you purchased the product.

Use only original accessories. This will avoid potential risks to health or property and ensure compliance with all relevant regulations.

Permanent hearing loss may occur if you use ear- or headphones at high volume.You can adapt over time to a higher volume, which may sound normal but can be damaging to your hearing. Set your volume to a safe level. If you experience ringing in your ears, reduce the volume or discontinue use of your system.

Improper use will invalidate the guarantee! These safety instructions also apply to original accessories.

As mobile devices offer a range of functions, they can be used in positions other than the head, such as on the body. In this case, at data transfer (GPRS) a separation distance of 2.0 cm is required.

Safety precautions4

Bluetooth

Your phone has a Bluetooth interface. This makes it possible to establish a wireless connection of your phone with a headset of a car kit, or with other Bluetooth-enabled devices.

In order to establish a secure link between the devices and to prevent a third party from having access to your phone, you should observe the following points:

• The initial connection between two devices, what is called "pairing", should take place in familiar surroundings.

• Both devices must be able to identify themselves one time by using a password/PIN. To ensure sufficient security, you should choose a 16-digit number combination for a password that would be difficult to guess (if a PIN has not been assigned).

• An automatic connection acceptance ("connection without confirmation") should only be used in exceptional cases.

• In general, only trustworthy devices should be linked in order to minimize security risks.

• You should restrict the "visibility" of your phone if possible. This will make it much more difficult for unknown devices to establish a connection with your phone. To do this, in the Bluetooth menu, set the option Visib.to others of Always visible to

Not visible.

• The name of your phone is transmitted in a Bluetooth connection. The factory default is the "Bluetooth ID". The first time Bluetooth is activated, or later in the Bluetooth menu, you can change this name (My BT name).

• If Bluetooth is not needed, this function should be deactivated.

Before using Bluetooth accessories, or a mobile phone inside a vehicle, check the vehicle user guide for any limitations on the use of these products.

Phone overview

ACall key

• Dial the number/name displayed/marked, accept calls.

• In standby mode, press to open the Call log lists.

BOn/Off/End key

• Press and hold to switch on (when switched off).

• During a conversation or in an application: press briefly to finish.

• In menus: Press and hold to go back to standby mode.

• In standby mode, press and hold to switch off, press briefly: switch-off menu.

Navi ring

• In standby mode:

H Open the phonebook (page 14). G Open profiles (page 23). E Open the Inbox (page 19). D Create new SMS (page 17).

• In lists, messages and menus:

Scroll up and down.

Scroll left and right.

Centre key

;

• Press the centre key to open the main menu or to start an application or function (page 10).

Softkeys

The current functions of these keys are shown in the bottom line of the display as

§Text§ / symbol.

á ß

10.01.06 14:20

Service provider

Inbox í Menu

Pressing any key activates the display illumination.

5Phone overview

Phone overview6

Earpiece/Loudspeaker

1 2 Double loudspeaker on both sides of

the phone

Dictating machine

Start the dictating machine to record a short memo or call (page 28).

Fast dialling key

‚

Dial number assigned as Fast dialling (Assignment: page 25).

5 6 7

Volume control

Display

Ringtone

• In standby mode, press and hold to switch ringtones and keaytones on/off (e.g. alarm is still active). Vibration is activated automatically.

• On incoming call, press and hold to switch off ringtone for this call.

Key lock

In standby mode, press and hold to switch key lock on/off. Only emergency numbers can be dialled.

Connection socket

For charger, headset and other accessories.

á ß

10.01.06 14:20

Service provider

Inbox í Menu

Display symbols

Display symbols (selection)

Signal strength

Charging

Battery charge level, e.g. 50%

Phonebook

Messages

Internet

Games

Voice mailbox

Call records

Alarm clock

Organiser

Extras

Ringtones

Settings

My stuff

All calls are diverted

Ringtone off

Alarm set

Keypad locked

Activated and available

Bluetooth activated

Events (selection)

SMS memory full

No network access

Æ ç

Phone memory full

Message symbols (selection)

Unread

Read

Sent

MMS with DRM content (page 11)

MMS notification received

r µ

Voice mail received

7Display symbols

Getting started8

Getting started

Your phone's display is supplied with a protective film. Remove this film carefully before using the phone.

Inserting the SIM card

The service provider supplies you with a SIM card on which all data for you r l in e i s st or ed . I f t he S IM ca rd has been delivered in credit-card size, snap the smaller segment out and remove any rough edges.

• Place the SIM card in front of the slot with the contact surface facing downwards. Then press the SIM card slightly to push it in

1 (ensure that the chamfered cor-

ner is in the correct position).

Inserting the battery

• Insert the battery into the phone 2,

press it downwards

• To remove, lift the battery up and out.

• After inserting SIM card and battery close the battery cover.

• To remove, take hold of the cover at the small dents phone and lift the cover up. Do not use the acoustics slots for opening the cover.

4 on either side of the

until it engages.

Please switch off your phone before removing the battery!

9Switching on/off, PIN entry

Charging the battery

The battery is not fully charged when delivered. Plug the charger cable into the bottom of the phone, plug the power supply unit into a power socket and charge for at least two hours.

Display during charging:

Charging time

An empty battery is fully charged after about 2 hours. The mains voltage specified on the power supply unit must not be exceeded. Charging is only possible within a temperature of +5 °C to 45 °C. If the temperature rises/falls 5 °C above/below this range, the charge symbol flashes a warning.

Only use the plug-in power supply unit included in the box!

Operating temperature

The phone may slightly heat up during operation, especially during data transfer. This is normal and not dangerous!

Switching on/off, PIN entry

Switching on/off

Entering PIN

The SIM card can be protected with a 4 to 8-digit PIN.

§OK§

Emergency number (SOS)

Only to be used in real emergencies!

By pressing §SOS§ you can make an emergency call on any network without a SIM card and without entering a PIN (not available in all countries).

Switching your phone on for the first time

Time/date

Set the time/date once.

;

Press and hold key.

Enter the PIN using the number keys. Asterisks are displayed to ensure nobody can read your PIN. Correct with

Press to confirm. Logging on to the network will take a few seconds.

Confirm. Press ; again to start entry.

General instructions10

;

Time zones

I ;

Enter the date (day/month/year) and time (24 hours).

Confirm. The time and date are updated.

Select the desired time zone.

Select the city in the desired time zone.

Confirm.

General instructions

User guide

The following symbols are used to explain operation:

J Enter numbers or letters.

§Options§ Displays a softkey option.

Press the centre key.

;

Press navi ring in the di-

I F =

Main menu

; Press to start application.

rection indicated.

Function dependent on

service provider, may require special registration.

Call up main menu from standby mode.

Select application symbol.

Accessing menus

The steps needed to reach a function are shown in a condensed form in the user guide, e. g. to switch on/off Big

letters on the display:

C ¢ T ¢Display

This comprises the following steps:

; F/I

I I

Centre key

The symbol in the centre of the lower display line shows the current function when pressing centre key.

í ì ñ ð ü ÷ ú

Open the main menu. Select T to open Settings

menu. Confirm with Select Display function

and confirm with Select Big letters function

and change/toggle with

Main menu

OK, confirm

Change

Call

Edit Insert ó Pause Options õ Stop

;

ý ö û ò ô

;

Send

View

Save

Play

Record

;

11Security

Tabs

Tabs allow fast access to information and applications

If an input field is activated on a tab, it is only possible to navigate within the field using the navigation key.

Switch between the individual tabs.

Mark mode

You can mark several entries on the tab in order to perform multiple functions at once.

§Options§

I ;

Additional marking functions:

§Options§ Open menu.

Mark all

Unmark all

Delete marked

Open menu and select

Mark to activate mark

mode.

Select entry/entries.

Mark or remove mark.

Mark all entries.

Unmark all marked entries.

Delete marked entries.

Digital Rights Management (DRM)

The use of downloaded pictures, sounds or applications can be restricted by the suppliers, e.g., copy protection, use for a limited period of time only, number of times it can be used etc.

Security

The phone and SIM card are protected against misuse by security codes.

Keep these security codes in a safe place where you can access them again if required.

PIN codes

Protects your SIM card (personal identification number).

PIN2

This is needed to set the charge detail display and to access additional functions on special SIM cards.

PUK

Key code. Used to unlock SIM

PUK2

cards after the wrong PIN has been entered repeatedly.

Phone

Protects your phone. Must be en-

code

tered at the first security setting.

PIN control

í ¢

The PIN is usually requested each time the phone is switched on. You can deactivate this feature but you risk unauthorised use of the phone. Some service providers do not permit deactivating the control.

ñ J

¢ Security ¢PIN codes

¢ PIN control

Press to change.

Enter PIN. Confirm with

;

Security12

Change PIN codes

í ¢

Change PIN

You can change the PIN (4 to 8 digits) to a number you easily remember.

¢ Security ¢PIN codes

¢ Select function.

ñ Press to change. J

Enter current PIN and confirm with

;

J,; Enter new PIN. Confirm. J,; Repeat new PIN. Confirm.

Change PIN2

Proceed as for Change PIN.

Change phonecode

Define the phone code (4–8 digits) when you start a phone-code protected function for the first time. It is then valid for all phone-code protected functions. To change the code proceed as with Change PIN.

Following the third incorrect attempt, access to the phone code functions is denied. Please contact Service (page 33).

Clearing SIM card barrings

If the PIN is entered incorrectly three times, the SIM card is barred.

Enter the PUK (MASTER PIN) provided by your service provider in accordance with the instructions.

If the PUK has been lost, contact your service provider.

Preventing accidental activation

Even if PIN use is deactivated (page 9) confirmation is required to switch on the phone.

This prevents the phone from being switched on accidentally, e.g. when carried in a pocket or whilst you are on an aircraft.

B Press and hold.

§OK§ Press.

Connection with PCs

You can connect your phone to a PC using Bluetooth or a data cable (accessories). The PC program MPM (Mobile Phone Manager) enables you to store data on PC and, e.g. synchronise the Addressbook with Outlook®, Lotus Notes™. You will find Mobile Phone Manager on the CD-ROM supplied or at:

www.BenQ-Siemens.com/s68

13Calling

Calling

Dialling with number keys

International dialling codes

§Options§ Open, then select Country.

Dialling with Fast dialling key / short cuts

Use the Fast dialling key ‚ or the short cut keys (2 to 9) if numbers are assigned (see page 25). Press and hold number key or number.

Setting the volume

[/ \ Adjust the volume.

Last number redial

Calling from the redial list see Call records, page 16.

Enter number (always with area/international dialling code).

] A short press clears

the last digit, a long press clears the phone number.

Press to dial the displayed phone number.

Press and hold until a "+" is displayed.

to dial the

‚

Press twice. The phone number last called is redialled.

Auto redial last number

§Options§ Open, then Auto dial. The

phone number is dialled ten times at increasing time intervals.

Accepting a call

A Press.

Additional information

Accept the call before bringing the telephone to your ear in order to avoid ear damage caused by the ringtones.

Handsfree

§Options§ Open, then activate/deacti-

Always switch off "handsfree talking" before holding the phone to your ear. Otherwise, you will damage your hearing!

vate Handsfr.

Ending/Rejecting a call

Press briefly.

Establish a second call or conference

You can call another number during a call or link up a multi party call.

§Options§ Open menu. Then select

Hold option. The current

call is put on hold.

Dial the new number and

press

Phonebook14

When connection is established …

Swap … swap between 2 calls.

Confirm with

Conference

… select to start a multi party call. The held call is joined. Repeat procedure until all (up to 4) participants are linked together.

;

Receiving a second call

During a call, you may be advised that there is another call waiting. You will hear a special tone during the call.

§Swap§ /

Accept the waiting call. The current call is put on hold.

§Swap§ Swap between calls.

;

Confirm the notification.

Tone sequences (Send DTMF)

§Options§ Open menu. Then select

Send DTMF option. Enter

tone sequences (numbers) for remote access to an answering machine.

Phonebook

í ¢ L

You can store contacts with different phone and fax numbers as well as additional address details. Tabs are offered for fast access: All contacts,

Groups, Online status, SIM, Filter

F I A

§Options§ Open menu, then Create

All contacts

Display all entries stored in the phone or on the SIM card in alphabetical order.

;

Press in standby mode.

Switch between the tabs.

Select contact.

Call selected contact.

message, to create a mes-

sage for the selected contact.

Confirm <New entry>. The

tabs are displayed. Switch between the tabs:

General sett., Private, Business, Person, Online status

Select input fields on tabs.

+ 34 hidden pages
