Digital Projector

User Manual

MS535P / MX535P

V1.00

Ta bl e o f c o n te n t s

Important safety

instructions .................. 3

Introduction ................. 7

Projector features .................................... 7

Shipping contents ..................................... 8

Projector exterior view .......................10

Positioning your

projector .................... 16

Choosing a location ...............................16

Obtaining a preferred projected image

size .............................................................17

Connection ................ 18

Operation .................. 19

Starting up the projector .....................19

Adjusting the projected image ............20

Using the menus .....................................23

Securing the projector ..........................24

Switching input signal ............................26

Magnifying and searching for details ..27

Selecting the aspect ratio .....................28

Optimizing the image ............................28

Setting the presentation timer ............33

Remote paging operations ...................34

Hiding the image ....................................34

Freezing the image .................................34

Operating in a high altitude

environment ............................................35

Adjusting the sound ..............................35

Personalizing the projector menu

display .......................................................36

Select the lamp saver mode ................36

Shutting down the projector ...............37

Menu operation ......................................38

Maintenance .............. 51

Care of the projector ........................... 51

Lamp information .................................. 52

Troubleshooting ........ 60

Specifications ............. 61

Dimensions ............................................. 62

Ceiling mount installation .................... 62

Timing chart ........................................... 63

Warranty and Copyright

information ................ 67

Table of contents2

Important safety instructions

Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product.

Safety Instructions

1. Please read this manual before you operate your projector.

Save it for future reference.

2. Do not look straight at the

projector lens during operation. The intense light beam

may damage your eyes.

4. Always open the lens shutter

or remove the lens cap when the projector lamp is on.

5. In some countries, the line voltage is NOT stable. This projector is designed to operate safely within a mains voltage between 100 to 240 volts AC, but could fail if power cuts or surges of ±10 volts occur.

In areas where the mains voltage may fluctuate or cut out, it is recommended that you connect your projector through a power stabilizer, surge protector or uninterruptible power supply (UPS).

3. Refer servicing to qualified service personnel.

Important safety instructions3

6. Do not block the projection lens with any objects when the projector is under operation as this could cause the objects to become heated and deformed or even cause a fire.

Safety Instructions (Continued)

7. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45 minutes prior to removing the lamp assembly for replacement.

8. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps beyond the rated life could cause them to break on rare occasions.

10. Do not place this product on an unstable cart, stand, or table. The product may fall, sustaining serious damage.

11. Do not attempt to disassemble this projector. There are dangerous high voltages inside which may cause death if you should come into contact with live parts.

Under no circumstances should you ever undo or remove any other covers. Refer servicing only to suitably qualified professional service personnel.

9. Never replace the lamp assembly or any electronic components unless the projector is unplugged.

12. When the projector is under operation, you may sense some heated air and odor from its ventilation grill. It is a normal phenomenon and not a product defect.

Important safety instructions 4

3000 m

(10000

feet)

0 m

(0 feet)

Safety Instructions (Continued)

13. Do not place this projector in any of the following environments.

- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls and free flow of air around the projector.

- Locations where temperatures may become excessively high, such as the inside of a car with all windows rolled up.

- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical components, shortening the projector's life span and darkening the image.

- Locations near fire alarms

- Locations with an ambient temperature above 40°C / 104°F

- Locations where the altitudes are higher than 3000 m (10000 feet).

14. Do not block the ventilation holes.

- Do not place this projector on a blanket, bedding or any other soft surface.

- Do not cover this projector with a cloth or any other item.

- Do not place inflammables near the projector.

If the ventilation holes are seriously obstructed, overheating inside the projector may result in a fire.

15. Always place the projector on a level, horizontal surface during operation.

- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of more than 15 degrees front to back. Using the projector when it is not fully horizontal may cause a malfunction of, or damage to, the lamp.

Important safety instructions5

Safety Instructions (Continued)

16. Do not stand the projector on end vertically. Doing so may cause the projector to fall over, causing injury or resulting in damage to the projector.

17. Do not step on the projector or place any objects upon it. Besides probable physical damage to the projector, doing so may result in accidents and possible injury.

18. Do not place liquids near or on the projector. Liquids spilled into the projector may cause it to fail. If the projector does become wet, disconnect it from the power supply's wall socket and call BenQ to have the projector serviced.

19. This product is capable of displaying inverted images for ceiling mount installation.

Use only BenQ's Ceiling Mount Kit for mounting the projector and ensure it is securely installed.

Important safety instructions 6

Introduction

Projector features

The projector offers the following features

• SmartEco™ starts your dynamic power saving

SmartEco™ technology saves lamp power consumption depending on the content brightness level when SmartEco mode is selected

• Longest hours lamp life with SmartEco™ technology

SmartEco™ technology increases the lamp life hours when selecting SmartEco mode to lower the power consumption

• ECO BLANK saves lamp power

Pressing the ECO BLANK bottom to immediately hide the image, lowering the lamp power at the same time your image is hiding

• Less than 0.5W in standby condition

Less than 0.5W power consumption under standby mode

• One-key auto-adjustment

Pressing AUTO on the keypad or remote control to show the best picture quality immediately

• Quick Cooling, Auto Power Off, Direct Power On

Quick Cooling function speeds up the cooling process when turning off the projector. Auto Power Off function allows the projector to turn off automatically if no input signal is detected after a set period of time. Direct Power On turns your projector when the power is fed.

•Instant Restart

Selectable Instant Restart function enables you to restart the projector immediately within 90 seconds after turning it off.

• 3D Function supported

Various 3D formats make the 3D function more flexible.

• The apparent brightness of the projected image will vary depending on the ambient lighting conditions, selected input signal contrast/ brightness settings, and is proportional to projection distance.

• The lamp brightness will decline over time and may vary within the lamp manufacturers specifications. This is normal and expected behavior.

Introduction 7

Shipping contents

Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase.

Standard accessories

The supplied accessories will be suitable for your region, and may differ from those illustrated.

*The warranty card is only supplied in some specific regions. Please consult your dealer for detailed information.

Projector Power cord VGA cable

Quick start guide Warranty card* Remote control with

battery

Introduction8

Optional accessories

1. Spare lamp kit

2. Ceiling mount kit

3. Carry bag

4. 3D glasses Introduction 9

Projector exterior view

Front/upper side

Rear/lower side

11 12

14 151617

1. External control panel (See "Projector" on page 11 for details.)

2. Lamp cover

3. Vent (air inhale)

4. Focus ring

5. Zoom ring

6. Front IR remote sensor

7. Projection lens

8. Quick-release lever

9. RGB signal output jack

10. USB mini-B input jack

11. RS-232 control port

12. RGB (PC) signal input jack

13. HDMI input jack

14. Audio input jack

15. Audio output jack

16. Kensington anti-theft lock slot

17. Security bar

18. Vent (heated air exhaust)

19. Rear adjuster foot

20. Front adjuster foot

21. Ceiling mount holes

22. AC power cord inlet

Introduction10

1920

Controls and functions

1 2

4 5 6

1011

Projector

1. Focus ring

Adjusts the focus of the projected image. See "Fine-tuning the image size

and clarity" on page 22 for details.

2. Zoom ring

Adjusts the size of the image. See "Fine-

tuning the image size and clarity" on page 22 for details.

3. OK

Selects an available picture setup mode. See "Selecting a picture mode" on page

29 for details.

Activates the selected On-Screen Display (OSD) menu item. See "Using

the menus" on page 23 for details.

4. POWER indicator light

Lights up or flashes when the projector is under operation. See "Installing the

dust filter (Optional accessory)" on page 58 for detail.

5. TEMP (temperature) warning light

Lights up red if the projector's temperature becomes too high. See

"Installing the dust filter (Optional accessory)" on page 58 for details.

6. LAMP indicator light

Indicates the status of the lamp. Lights up or flashes when the lamp has developed a problem. See "Installing

the dust filter (Optional accessory)" on page 58 for details.

7. POWER

Toggles the projector between standby mode and on. See "Starting up the

projector" on page 19 and "Shutting down the projector" on page 37 for

details.

8. SOURCE

Displays the source selection bar. See

"Switching input signal" on page 26 for

details.

9. BACK

Goes back to previous OSD menu or exits and saves menu settings when it is on top level of OSD menu.

10. MENU

Turns on the On-Screen Display (OSD) menu, exits and saves menu settings.

11. AUTO

Automatically determines the best picture timings for the displayed image. See "Auto-adjusting the image" on page

21 for details.

Introduction 11

12. Keystone/Arrow keys ( / Up, /Down)

Manually corrects distorted images resulting from an angled projection. See "Correcting keystone" on page 22 for details.

13. ECO BLANK

Used to hide the screen picture. See

"Hiding the image" on page 34 for

details.

Ceiling mounting the projector

We want you to have a pleasant experience using your BenQ projector, so we need to bring this safety matter to your attention to prevent possible damage to person and property. If you intend to mount your projector on the ceiling, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit and that you ensure it is securely and safely installed. If you use a non-BenQ brand projector ceiling mount kit, there is a safety risk that the projector may fall from the ceiling due to an improper attachment through the use of the wrong gauge or length screws. You can purchase a BenQ projector ceiling mount kit from the place you purchased your BenQ projector. BenQ recommends that you also purchase a separate Kensington lock compatible security cable and attach it securely to both the Kensington lock slot on the projector and the base of the ceiling mount bracket. This will perform the secondary role of restraining the projector should its attachment to the mounting bracket become loose.

14. Volume /Arrow keys ( / Left, / Right)

Adjusts the sound level. When the On-Screen Display (OSD)

menu is activated, the #12 and #14 keys are used as directional arrows to select the desired menu items and to make adjustments. See "Using the menus" on

page 23 for details.

Introduction12

Remote control

8 9

1. ON

Turns on the projector. See "Starting up

the projector" on page 19 for details.

2. PC 1

Searches for an input signal and displays PC-1 signal.

3. Left/ Right

When the On-Screen Display (OSD) menu is activated, the #3 and #11 keys are used as directional arrows to select the desired menu items and to make adjustments. See "Using the menus" on

page 23 for details.

4. BACK

Goes back to previous OSD menu or exits and saves menu settings when it is on the top level of OSD menu.

5. ECO BLANK

Press the ECO BLANK button to turn off the image for a period of time with 70% lamp power saving. Press again to restore the image. See "Hiding the

image" on page 34 for details.

10 11 12

3 13

14 11 15

16 17

19 20 21 22

6. FREEZE

Freezes the projected image. See

"Freezing the image" on page 34 for

details.

7. Page Up/Down keys (PAGE +/-)

Page up/down arrows when connected through USB to a PC. See

"Remote paging operations" on page 34 for details.

8. CC

CC is not supported by this model.

9. 3D SETTINGS

Activates the 3D On-Screen Display (OSD) menu item.

10. OFF

Turns off the projector. See "Shutting

down the projector" on page 37 for

details.

11. Keystone/Arrow keys ( / Up, /Down)

Manually corrects distorted images resulting from an angled projection. See "Correcting keystone" on page 29 for details.

12. SOURCE

Displays the source selection bar. See

"Switching input signal" on page 26 for

details.

13. OK

Selects an available picture setup mode. See "Selecting a picture mode"

on page 29 for details.

Activates the selected On-Screen Display (OSD) menu item. See "Using

the menus" on page 23 for details.

14. MENU

Turns on the On-Screen Display (OSD) menu, exits and saves menu

settings.

23 for details

See "Using the menus" on page

Introduction 13

15. AUTO

0°

Automatically determines the best picture timings for the displayed image. See "Auto-adjusting the image"

on page 21 for details.

16. Mute

Toggles projector audio between on and off.

17. Digital Zoom keys (ZOOM +/-)

Magnifies or reduces the projected picture size. See "Magnifying and

searching for details" on page 27 for

details.

18. Volume keys (VOL / )

19. SMART ECO

Displays the lamp mode selection bar (Normal/Economic/SmartEco).

20. INFO

Displays the status information of the projector.

21. QUICK INSTALL

Displays the QUICK INSTALL menu including Projector Installation, Test Pattern, and Keystone.

22. ASPECT

Selects the display aspect ratio. See

"About the aspect ratio" on page 28 for

details.

Adjusts the sound level.

Infra-Red (IR) remote control sensor is located on the front of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 8 meters (~ 26 feet).

Make sure that there are no obstacles between the remote control and the IR sensor on the projector that might obstruct the infra-red beam.

• Operating the projector from the front

Introduction14

Replacing the remote control battery

1. To open the battery cover, turn the remote control over to view its back, push on the finger grip on the cover and slide it up in the direction of the arrow as illustrated. The cover will slide off.

2. Remove any existing batteries (if necessary) and install two AAA batteries observing the battery polarities as indicated in the base of the battery compartment. Positive (+) goes to positive and negative (-) goes to negative.

3. Refit the cover by aligning it with the base and sliding it back down into position.

Stop when it clicks into place.

• Avoid excessive heat and humidity.

• There may be battery damage if the battery is incorrectly replaced.

• Replace only with the same or equivalent type recommended by the

battery manufacturer.

• Dispose of the used battery according to the battery manufacturer’s

instructions.

• Never throw a battery into a fire. There may be danger of an explosion.

• If the battery is dead or if you will not be using the remote control for a

long time, remove the battery to prevent damage to the remote control from possible battery leakage.

Introduction 15

Positioning your projector

Choosing a location

Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.

Your projector is designed to be installed in one of four possible installation locations:

1. Front Table

Select this location with the projector placed near the floor in front of the screen. This is the most common way to position the projector for quick setup and portability.

2. Front Ceiling

Select this location with the projector suspended upside-down from the ceiling in front of the screen.

Purchase the BenQ Projector Ceiling Mounting Kit from your dealer to mount your projector on the ceiling.

Set Front Ceiling in the SYSTEM SETUP: Basic > Projector Installation menu after you turn the projector on.

3. Rear Table

Select this location with the projector placed near the floor behind the screen.

Note that a special rear projection screen is required.

Set Rear Table in the SYSTEM SETUP: Basic > Projector Installation menu after you turn the projector on.

4. Rear Ceiling

Select this location with the projector suspended upside-down from the ceiling behind the screen.

Note that a special rear projection screen and the BenQ Projector Ceiling Mounting Kit are required for this installation location.

Set Rear Ceiling in the SYSTEM SETUP: Basic > Projector Installation menu after you turn the projector on.

Positioning your projector16

Obtaining a preferred projected image size

Projection distance

Center of lens

Screen

Vertical offset

Diagonal

The distance from the projector lens to the screen, the zoom setting (if available), and the content format each factors in the projected image size.

Projection dimensions

Refer to "Dimensions" on page 62 for the center of lens dimensions of this projector before calculating the appropriate position.

The screen aspect ratio is 4:3 and the projected picture is 4:3

Screen size Projection distance (mm)

Diagonal

Inch mm (max. zoom) (min. zoom)

30 762 610 457 1153 1273 1392 27 35 889 711 533 1356 1495 1633 32 40 1016 813 610 1558 1717 1875 37 50 1270 1016 762 1963 2161 2359 46 60 1524 1219 914 2368 2605 2843 55

80 2032 1626 1219 3177 3493 3810 73 100 2540 2032 1524 3987 4382 4777 91 120 3048 2438 1829 4796 5270 5745 110 150 3810 3048 2286 6010 6603 7195 137 200 5080 4064 3048 8034 8824 9614 183 220 5588 4470 3353 8843 9712 10581 201 250 6350 5080 3810 10057 11045 12032 229 300 7620 6096 4572 12081 13266 14450 274

(mm)H(mm)

For example, if your projector is MS535P/MX535P and using a 120-inch screen, the average projection distance is 5270 mm and with a vertical offset of 110 mm.

If your measured projection distance is 5.0 m (5000 mm), the closest match in the

"Projection distance (mm)" column is 5270 mm. Looking across this row shows that a 120''

(about 3.0 m) screen is required.

All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics. This will help you determine the exact mounting position so that it best suits your installation location.

Min distance

Average

Max distance

Vertical offset

(mm)

Positioning your projector 17

Connection

When connecting a signal source to the projector, be sure to:

1. Turn all equipment off before making any connections.

2. Use the correct signal cables for each source.

3. Ensure the cables are firmly inserted.

1. VGA cable 2. USB Cable

3. HDMI cable

4. Audio cable (PC/RCA jack)

• In the connections shown above, some cables may not be included with the projector (see "Shipping contents" on page 8). They are commercially available from electronics stores.

Connection18

Operation

Starting up the projector

1. Plug the power cord into the projector and

into a power outlet. Turn on the power outlet switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied.

• Please use the original accessories (e.g. power cable) only with the device to avoid possible dangers such as electric shock and fire.

• If Direct Power On function is activated in the SYSTEM SETUP: Basic > Operation Settings menu, the projector will turn on automatically after the power cord has been connected and power has been applied. See "Direct Power On" on page 47 for details.

• If Signal Power On function is activated in the SYSTEM SETUP: Basic > Operation Settings menu, the projector will turn on automatically when VGA signal is detected. See "Signal Power On" on page 47 for details.

2. Press POWER on the projector or

ON on the remote control to start the

projector. The POWER flashes and stays orange when the projector is on.

The start up procedure takes about 30 seconds. In the later stage of start up, a startup logo is projected.

(If necessary) Rotate the focus ring to adjust the image clearness.

If the projector is still hot from previous activity, it will run the cooling fan for approximately 90 seconds before energizing the lamp.

Operation 19

3. If the projector is activated for the first

time, select your OSD language following the on-screen instructions.

4. If you are prompted for a password, press

the arrow keys to enter a six digit password. See "Utilizing the password

function" on page 24 for details.

5. Switch all of the connected equipment on.

6. The projector will start to search for input

signals. The current input signal being scanned displays in the screen. If the projector doesn't detect a valid signal, the message 'No Signal' will continue displaying until an input signal is found.

You can also press Source on the projector or remote control to select your desired input signal. See "Switching input signal" on page 26 for details.

• If no signal is detected for 3 minutes, the projector automatically enters ECO BLANK mode.

Adjusting the projected image

Adjusting the projection angle

The projector is equipped with 1 front adjuster foot and 2 rear adjuster feet. These adjusters change the image height and projection angle. To adjust the projector:

1. Pull the quick-release lever and lift the front

of the projector. Once the image is positioned where you want it, release the quick-release lever to lock the foot in position. You may also screw the front adjuster foot to change the image height.

2. Screw the rear adjuster feet to fine tune the

horizontal angle.

If the projector is not placed on a flat surface or the screen and the projector are not perpendicular to each other, the projected image becomes trapezoidal. To correct this situation, see "Magnifying and searching for details" on page 27 for details.

• Do not look into the lens while the lamp is on. The strong light from the lamp may cause damage to your eyes.

• Be careful when you press the adjuster button as it is close to the exhaust vent where hot air comes from.

Operation

Auto-adjusting the image

In some cases, you may need to optimize the picture quality. To do this, press AUTO on the projector or remote control. Within 3 seconds, the built-in Intelligent Auto Adjustment function will re-adjust the values of Frequency and Clock to provide the best picture quality.

• This function is only available when PC signal (analog RGB) is selected.

Use build-in test pattern

You can adjust the image shape and focus status by observing the input signal content, or using the test pattern build-in OSD manual from OSD or remote control for better observe the shape changed.

• Using the remote control

Press the Quick Install to display Quick Install menu, and go to the Test Pattern > On. The Test Pattern displays.

•Using the OSD menu

Open the OSD menu and go to the

SYSTEM SETUP: Advanced > Test Pattern > On. The Test Pattern displays.

Operation 21

Fine-tuning the image size and clarity

Press /.

1. Adjust the projected image to the size

that you need using the zoom ring.

2. Then sharpen the image by rotating the

focus ring.

Correcting keystone

Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen.

To correct this, besides adjusting the height of the projector, you will need to manually correct it following one of these steps.

• Using the remot e control

Press / on the projector or remote control to display the Keystone correction page. Press to correct keystoning at the top of the image. Press to correct keystoning at the bottom of the image.

•Using the OSD menu

1. Press MENU and then press / until

the DISPLAY menu is highlighted.

2. Press to highlight Keystone and press

OK. The Keystone correction page displays.

3. Press to correct keystoning at the

top of the image or press to correct keystoning at the bottom of the image.

Operation

Using the menus

Current input

Main menu icon

Main menu

Sub-menu

Highlight

Press MENU to the previous page or to exit.

Status

The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings. Below is the overview of the OSD menu.

The following example describes how to set the OSD language.

1. Press MENU on the projector or remote control to turn the OSD menu on.

3. Press to highlight Language and press OK.

2. Use / to highlight the SYSTEM SETUP: Basic menu.

4. Press / / / to select a preferred language and press OK to leave and save the settings.

* Press MENU to open and close the OSD menu.

* Press BACK to

previous OSD menu or exits and saves menu settings when it is on top level of OSD menu.

go back to

Operation 23

Securing the projector

Using a security cable lock

The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector. See item 16 on page 10 for details.

A Kensington security cable lock is usually a combination of key(s) and the lock. Refer to the lock's documentation for finding out how to use it.

Utilizing the password function

For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the OnScreen Display (OSD) menu.

WARNING: You will be inconvenienced if you activate the power-on lock functionality and subsequently forget the password. Print out this manual (if necessary) and write the password you used in this manual, and keep the manual in a safe place for later recall.

Setting a password

Once a password has been set, the projector cannot be used unless the correct password is entered every time the projector is started.

1. Open the OSD menu and go to the SYSTEM SETUP: Advanced > Security Settings > Change Security menu. Press OK.

2. Enter a new or current password. As pictured to the right, the four arrow keys ( , , ,

) respectively represent 4 digits (1, 2, 3, 4). According to the password you desire to set, press the arrow keys to enter six digits for the password.

3. Confirm the new password by re-entering the new password.

Once the password is set, the OSD menu returns to the Security Settings page with 'Off' shown in the row of Power on

lock.

IMPORTANT: The digits being input will display as asterisks on-screen. Write your selected password down here in this manual in advance or right after the password is entered so that it is available to you should you ever forget it.

Password: __ __ __ __ __ __

Keep this manual in a safe place.

4. Select On by pressing / .

5. To leave the OSD menu, press MENU.

Operation

If you forget the password

If the password function is activated, you will be asked to enter the six-digit password every time you turn on the projector. If you enter the wrong password, the password error message as pictured to the right displays lasting for three seconds, and the message 'INPUT PASSWORD' follows. You can retry by entering another six-digit password, or if you did not record the password in this manual, and you absolutely do not remember it, you can use the password recall procedure. See "Entering the password

recall procedure" on page 25 for details.

If you enter an incorrect password 5 times in succession, the projector will automatically shut down in a short time.

Entering the password recall procedure

1. Press and hold Auto on the projector or remote control for 3 seconds. The projector will display a coded number on the screen.

2. Write down the number and turn off your projector.

3. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector.

Changing the password

1. Open the OSD menu and go to the SYSTEM SETUP: Advanced > Security Settings > Change Password menu.

2. Press OK. The message 'INPUT CURRENT PASSWORD' displays.

3. Enter the old password.

• If the password is correct, another message 'INPUT NEW PASSWORD'

displays.

• If the password is incorrect, the password error message displays. You can

press MENU to cancel the change or try another password.

4. Enter a new password.

Password: __ __ __ __ __ __

Keep this manual in a safe place.

5. Confirm the new password by re-entering the new password.

Operation 25

6. You have successfully assigned a new password to the projector. Remember to enter the new password next time the projector is started.

7. To leave the OSD menu, press MENU.

Disabling the password function

To disable password protection, go back to the SYSTEM SETUP: Advanced > Security Settings > Change Security menu after opening the OSD menu system.

The message 'INPUT PASSWORD' displays. Enter the current password.

• If the password is correct, the OSD menu returns to the Security Settings

page with 'Off' shown in the row of Power on lock. You will not have to enter the password next time you turn on the projector.

• If the password is incorrect, the password error message displays. You can

press MENU to cancel the change or try another password.

Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password.

Switching input signal

The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. When starting up, the projector automatically searches for the available signals.

Be sure the Quick Auto Search function in the Source menu is On (which is the default of this projector) if you want the projector to automatically search for the signals.

You can also manually cycle through the available input signals.

1. Press Source on the projector or remote control. A source selection bar displays.

2. Press / until your desired signal is selected and press OK.

Once detected, the selected source information will display on the screen for seconds. If there is multiple equipment connected to the projector, repeat steps 1-2 to search for another signal.

• The brightness level of the projected

image will change accordingly when you switch between different input signals.

• The input signal type effects the options available for the Picture Mode.

See "Selecting a picture mode" on page 29 for details.

Operation

For best display picture results, you should select and use an input signal which outputs at this resolution. Any other resolutions will be scaled by the projector depending upon the 'aspect ratio' setting, which may cause some image distortion or loss of picture clarity. See "Selecting the aspect

ratio" on page 28 for details.

Changing Color Space

In the unlikely event that you connect the projector to a device via the projector's HDMI input and the projected picture displays wrong colors, please change the color space to YUV.

1. Press MENU and then press / until the Source menu is highlighted.

2. Press to highlight Color Space Conversion and press / to select a suitable color space.

This function is only available when the HDMI input port is in use.

Magnifying and searching for details

If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture.

• Using the remote control

1. Press ZOOM +/- to display the Zoom bar.

2. Press ZOOM + to magnify the center of the picture. Press the key repeatedly until the picture size is suitable for your need.

3. Use the directional arrows ( , , , ) on the projector or remote control to navigate the picture.

4. To restore the picture to its original size, press AUTO. You can also press ZOOM - . When the key is pressed again, the picture is further reduced until it is restored to the original size.

•Using the OSD menu

1. Press MENU and then press / until the DISPLAY menu is highlighted.

2. Press

3. Repeat steps 2-4 in the section of "Using the remote control" above. Or if you

4. Press on the projector repeatedly to magnify the picture to a desired size.

5. To navigate the picture, press OK to switch to the paning mode and press the

6. Use the directional arrows ( , , , ) on the projector or remote control

7. To reduce size of the picture, press OK to switch back to the zoom in/out

to highlight Digital Zoom and press OK. The Zoom bar displays.

are using the projector control panel, continue to the following steps.

directional arrows ( , , , ) to navigate the picture.

to navigate the picture.

functionality, and press AUTO to restore the picture to its original size. You can also press repeatedly until it is restored to the original size.

Operation 27

The picture can only be navigated after the picture is magnified. You can further magnify the picture while searching for details.

Selecting the aspect ratio

The 'aspect ratio' is the ratio of the image width to the image height. With the advent of digital signal processing, digital display devices like this projector

can dynamically stretch and scale the image output to a different aspect than that of the image input signal.

To change the projected image ratio (no matter what aspect the source is):

• Using the remote control

1. Press ASPECT to show the current setting.

2. Press ASPECT repeatedly to select an aspect ratio to suit the format of your

display requirements.

•Using the OSD menu

1. Press MENU and then press / until the DISPLAY menu is highlighted.

2. Press

3. Press / to select an aspect ratio to suit

About the aspect ratio

1. Auto: Scales an image proportionally to fit the projector's native resolution in

2. Real: The image is projected as its original resolution, and resized to fit within

3. 4:3: Scales an image so that it is displayed in the center of the screen with a 4:3

4. 16:9: Scales an image so that it is displayed in the center of the screen with a

5. 16:10: Scales an image so that it is displayed in the center of the screen with a

to highlight Aspect Ratio.

the format of your display requirements.

its horizontal or vertical width. This is suitable for the incoming image which is neither in 4:3 nor 16:9 and you want to make most use of the screen without altering the image's aspect ratio.

the display area. For input signals with lower resolutions, the projected image will display smaller than if resized to full screen. You could adjust the zoom setting or move the projector towards the screen to increase the image size if necessary. You may also need to refocus the projector after making these adjustments.

aspect ratio. This is most suitable for 4:3 images like computer monitors, as it displays them without aspect alteration.

16:9 aspect ratio. This is most suitable for images which are already in a 16:9 aspect, as it displays them without aspect alteration.

16:10 aspect ratio. This is most suitable for images which are already in a 16:10 aspect, as it displays them with out aspect alteration.

Optimizing the image

Operation

Selecting a picture mode

The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type.

To select an operation mode that suits your need, you can follow one of the following steps.

• Press OK on the remote control or

projector repeatedly until your desired mode is selected.

• Go to the PICTURE > Picture Mode menu and press / to select a

desired mode.

The picture modes are listed below.

1. Bright mode: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms.

2. Presentation mode (Default): Is designed for presentations. The brightness is emphasized in this mode.

3. sRGB mode: Maximizes the purity of RGB colors to provide true-to-life images regardless of brightness setting. It is most suitable for viewing photos taken with an sRGB compatible and properly calibrated camera, and for viewing PC graphic and drawing applications such as AutoCAD.

4. Cinema mode: Is appropriate for playing contents from digital cameras or DVs through the PC input for best viewing in a blackened (little light) environment.

5. User 1/User 2 mode: Recalls the settings customized based on the current available picture modes. See "Setting the User 1/User 2 mode" on page 29 for details.

Setting the User 1/User 2 mode

There are two user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User 1/ User 2) as a starting point and customize the settings.

1. Press MENU to open the On-Screen Display (OSD) menu.

2. Go to the PICTURE > Picture Mode menu.

3. Press / to select User 1 to User 2.

4. Press to highlight Reference Mode.

This function is only available when User 1 or User 2 mode is selected up in the Picture Mode sub-menu item.

5. Press / to select a picture mode that is closest to your need.

6. Press to select a sub-menu item to be changed and adjust the value with /

. See "Fine-tuning the image quality in user modes" below for details.

7. When all settings have been done, highlight Save Settings and press OK to store the settings.

8. The confirmation message 'Setting Saved' displays.

Operation 29

Using Wall Color

+50

+30

+70

In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s color to prevent possible color difference between the source and projected pictures.

To use this function, go to the DISPLAY > Wall Color menu and press / to select a color which is the closest to the color of the projection surface. There are several precalibrated colors to choose from: Light Yellow, Pink, Light Green,

Blue, and Blackboard.

Fine-tuning the image quality in user modes

According to the detected signal type and selected picture mode, some of the below functions may not be available. Based on your needs, you can make adjustments tothese functions by highlighting them and pressing / on the projector or remote control.

Adjusting Brightness

The higher the value, the brighter the image. And the lower the setting, the darker the image. Adjust this control so the black areas of the image appear just as black and that detail in the dark areas is visible.

Adjusting Contrast

The higher the value, the greater the contrast. Use this to set the peak white level after you have previously adjusted the Brightness setting to suit your selected input and viewing environment.

+30

Adjusting Color

Lower setting produces less saturated colors. If the setting is too high, colors on the image will be overpowering, which makes the image unrealistic.

Adjusting Tint

The higher the value, the more reddish the picture becomes. The lower the value, the more greenish the picture becomes.

Adjusting Sharpness

The higher the value, the sharper the picture becomes. The lower the value, the softer the picture becomes.

Adjusting Brilliant Color

This feature utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing truer, more vibrant colors in picture. It enables a greater than 50% brightness increase in mid-tone images, which are common in natural scenes, so the projector reproduces images in realistic and true colors. If you prefer images with that quality, select On. If you don’t need it, select Off.

When Off is selected, the Color Temperature function is not available.

Selecting a Color Temperature

The options available for color temperature* settings vary according to the signal type selected.

-30

Operation

1. Cool: Makes images appear bluish white.

2. Normal: Maintains normal colorings for white.

3. Warm: Makes images appear reddish white.

*About color temperatures:

There are many different shades that are considered to be "white" for various purposes. One of the common methods of representing white color is known as the “color temperature”. A white color with a low color temperature appears to be reddish white. A white color with a high color temperature appears to have more blue in it.

Setting a preferred color temperature

To set a preferred color temperature:

1. Highlight Color Temperature and select Warm, Normal or Cool by pressing / on the projector or remote control.

2. Press to highlight Color Temperature Fine Tuning and press OK. The Color Temperature Fine Tuningg page displays.

3. Press / to highlight the item you want to change and adjust the values by pressing / .

• R Gain/G Gain/B Gain: Adjusts the contrast levels of Red, Green, and

Blue.

• R Offset/G Offset/B Offset: Adjusts the brightness levels of Red, Green,

and Blue.

4. Press MENU to exit and save the settings

3D Color Management

In most installation situations, color management will not be necessary, such as in classroom, meeting room, or lounge room situations where lights remain on, or where building external windows allow daylight into the room.

Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered. Color management provides fine color control adjustment to allow for more accurate color reproduction, should you require it.

Proper color management can only be achieved under controlled and reproducible viewing conditions. You will need to use a colorimeter (color light meter), and provide a set of suitable source images to measure color reproduction. These tools are not provided with the projector, however, your projector supplier should be able to provide you with suitable guidance, or even an experienced professional installer.

The Color Management provides six sets (RGBCMY) of colors to be adjusted. When you select each color, you can independently adjust its range and saturation according to your preference.

If you have purchased a test disc which contains various color test patterns and can be used to test the color presentation on monitors, projectors, etc. You can project any image from the disc on the screen and enter the 3D Color Management menu to make adjustments.

To adjust the settings:

1. Go to the PICTURE menu and highlight 3D Color Management.

2. Press OK and the 3D Color Management page displays.

3. Highlight Primary Color and press / to select a color from among Red, Yellow, Green, Cyan, Blue, or Magenta.

Operation 31

4. Press to highlight Hue and press / to select its range. Increase in the

RED

BLUE

GREEN

Yel l ow

Cyan

Magenta

range will include colors consisted of more proportions of its two adjacent colors.

Please refer to the illustration to the right for how the colors relate to each other.

For example, if you select Red and set its range at 0, only pure red in the projected picture will be selected. Increasing its range will include red close to yellow and red close to magenta.

5. Press to highlight Saturation and adjust its values to your preference by pressing / . Every adjustment made will reflect to the image immediately.

For example, if you select Red and set its value at 0, only the saturation of pure red will be affected.

Saturation is the amount of that color in a picture. Lower settings produce less saturated colors; a setting of “0” removes that color from the image entirely. If the saturation is too high, that color will be overpowering and unrealistic.

6. Press to highlight Gain and adjust its values to your preference by pressing

/ . The contrast level of the primary color you select will be affected. Every

adjustment made will reflect to the image immediately.

7. Repeat steps 3 to 6 for other color adjustments.

8. Make sure you have made all of the desired adjustments.

9. Press MENU to exit and save the settings.

Resetting current or all picture modes

1. Go to the PICTURE menu and highlight Reset Picture Settings.

2. Press OK and press / to select Current or All.

• Current: returns current picture mode to the factory preset settings.

• All: returns all settings, except User 1/User 2 in the PICTURE menu to

the factory preset settings.

Operation

Setting the presentation timer

The presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function:

1. Go to the SYSTEM SETUP: Basic > Presentation Timer menu and press OK to display the Presentation Timer page.

2. Highlight Timer Period and decide the timer period by pressing / . The length of time can be set from 1 to 5 minutes in 1-minute increments and 5 to 240 minutes in 5-minute increments.

3. Press to highlight Timer Display and choose if you want the timer to show up on the screen by press

Selection Description

Always Displays the timer on screen throughout the presentation time.

3 min/2 min/1 min

Never Hides the timer throughout the presentation time.

4. Press to highlight Timer Position and set the timer position by pressing

Top-Left Bottom-Left Top-Right Bottom-Right

5. Press to highlight Timer Counting Direction and select your desired counting direction by pressing /

Selection Description

Count Up Increases from 0 to the preset time.

Count Down Decrease from the preset time to 0.

Displays the timer on screen in the last 3/2/1 minute(s).

ing / .

6. Press to highlight Sound reminder and press / to select On.

7. To activate the presentation timer, press and press / to select On and press OK.

8. A confirmation message displays. Highlight Yes and press OK to confirm. The timer starts counting at the time the timer is on.

To cancel the timer, perform the following steps.

1. Go to the SYSTEM SETUP: Basic > Presentation Timer menu and highlight Off.

Press OK. A confirmation message displays.

2. Highlight Yes and press OK to confirm.

Operation 33

Remote paging operations

Connect the projector to your PC or notebook with a USB cable prior to using the paging function.

You can operate your display software program (on a connected PC) which responds to page up/ down commands (like Microsoft PowerPoint) by pressing PAGE +/- on the remote control.

If remote paging function doesn't work, check if the USB connection is correctly made and the mouse driver on your computer is updated to the latest version.

Hiding the image

Press the ECO BLANK button from projector or remote control to turn off the image for a period of time with up to 70% lamp power saving. Press any key on the projector or remote control to restore the image.

• Eco Blank: Save up 70% of your lamp power.

Time to do your part in saving the planet.

When this function is activated with an audio input connected,the audio can still be heard.

The automatic switch to ECO BLANK Mode after the projector is turned on for over three minutes without a display source, eliminating unnecessary energy waste and prolonging the life of the projector lamp

You can set the blank time in the SYSTEM SETUP: Basic > Operation Settings > Blank Timer menu to let the projector return the image automatically after a period of time when there is no action taken on the blank screen. The length of time can be set from 5 to 30 minutes in 5-minute increments.

Do not block the projection lens from projecting as this could cause the blocking object to become heated.

Freezing the image

Press FREEZE on the remote control to freeze the image. The word 'FREEZE' will display in the screen. To release the function, press any key (except the PAGE key) on the projector or remote control.

Even if an image is frozen on the screen, the pictures are running on the connected device. If the connected devices have active audio output, you will still hear the audio even though the image is frozen on screen.

Operation

Operating in a high altitude environment

We recommend you use the High Altitude Mode when your environment is 1500 m –3000 m above sea level, and ambient temperature is between 0°C–35°C.

Do not use the High Altitude Mode if your altitude is between 0 m and 1500 m and ambient temperature is between 0°C and 35°C. The projector will be over cooled, if you turn the mode on under such a condition.

To activate the High Altitude Mode:

1. Press MENU and then press / until the SYSTEM SETUP: Advanced menu is highlighted.

2. Press to highlight High Altitude Mode and press / to select On. A confirmation message displays.

3. Highlight Yes and press OK.

Operation under "High Altitude Mode" may cause a higher decibel operating noise level because of increased fan speed necessary to improve overall system cooling and performance.

If you use this projector under other extreme conditions excluding the above, it may display auto shut-down symptoms, which is designed to protect your projector from over-heating. In cases like this, you should switch to High Altitude mode to solve these symptoms. However, this is not to state that this projector can operate under any and all harsh or extreme conditions.

Adjusting the sound

The sound adjustments made as below will have an effect on the projector speaker(s). Be sure you have made a correct connection to the projector audio input. See

"Connection" on page 18 for how the audio input is connected.

Muting the sound

To temporarily turn off the sound, press on the remote control, or:

1. Press MENU and then press / until the SYSTEM SETUP: Advanced menu is highlighted.

2. Press to highlight Audio Settings and press OK. The Audio Settings page displays.

3. Highlight Mute and press / to select On.

Adjusting the sound level

To adjust the sound level, press VOL / on the remote control, or:

1. Repeat steps 1-2 above.

2. Press to highlight Volume and press

/ to select a desired sound level.

Operation 35

Personalizing the projector menu display

The On-Screen Display (OSD) menus can be set according to your preferences. The following settings do not affect the projection settings, operation, or performance.

• Menu display Time in the SYSTEM SETUP: Basic > Menu Settings menu

sets the length of time the OSD will remain active after your last key press. The time length ranges from 5 to 30 seconds in 5-second increments. Use / to select a suitable time frame.

• Menu Position in the SYSTEM SETUP: Basic > Menu Settings menu sets

the OSD position in five locations. Use / to select a preferred position.

• Language in the SYSTEM SETUP: Basic menu sets your familiar language for

the OSD menus. See "Using the menus" on page 23 for details.

• Reminder message in the SYSTEM SETUP: Basic > Menu Settings menu

sets whether to display reminder messages on screen. Use / to select your desired setting.

• Splash Screen in the SYSTEM SETUP: Basic menu sets a preferred logo

screen to be displayed during projector start-up. Use / to select a screen.

• Fan Speed Mode in the SYSTEM SETUP: Advanced menu is used when the

projector is installed a filter cover. Use / to set to High. See "Installing the

dust filter (Optional accessory)" on page 58 for details.

Select the lamp saver mode

• Using the remote control.

Press SMART ECO to select Normal/ Economic/SmartEco.

• Using the OSD menu.

1. Go to SYSTEM SETUP: Advanced > Lamp Settings > Lamp Mode.

2. Press / to select Normal/Economic/ SmartEco. The lamp brightness vary from the different lamp mode,see the description list in table below.

Lamp Mode Description

Normal Provides full lamp brightness

Economic

SmartEco

If the Economic mode or SmartEco mode is selected, the light output will be reduced and result in darker projected pictures.

Lowers brightness to extend the lamp life and decreases the fan noise

Adjusts the lamp power automatically depending on the content brightness level

Operation

Shutting down the projector

1. Press POWER on the projector or OFF on the remote control and a

confirmation message displays prompting you.

If you don't respond in a few seconds, the message will disappear.

2. Press POWER on the projector or OFF on the remote control a second time. The POWER flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to cool down the projector.

• To protect the lamp, the projector will

not respond to any commands during the cooling process.

• To shorten the cooling time, you can also activate the Quick Cooling

function in the SYSTEM SETUP: Basic > Operation Settings. See

"Quick Cooling" on page 47 for details.

3. Once the cooling process finishes, the POWER is a steady orange and fans stop.

4. Disconnect the power cord from the power putlet if the projector will not be used in an extended period of time.

5. When Instant Restart is On, users can restart projector immediately within 90 secs after turning off projector. (Projector will maintain 30% of power

during the 90 secs)

When Instant Restart is Off, users need to wait lamp to cool down to restart the projector. When quick cooling is on, instant restart item will be grey out

• If the projector is not properly shut down, to protect the lamp, when

you attempt to re-start the projector, the fans will run for a few minutes

to cool down. Press POWER on the projector or ON on the remote control again to start the projector after the fans stop and the POWER turns green.

• Actual lamp life may vary due to different environmental conditions

and usage.

Operation 37

Menu operation

Menu system

Please note that the on-screen display (OSD) menus vary according to the signal type selected.

Main menu Sub-menu Options

Off/Light Yellow/Pink/Light

Green/Blue/Blackboard

Auto/Top-Bottom/Frame sequential/Frame packing/Side By side/Off

3D Settings 1/3D Settings 2/3D Settings 3

3D Settings 1/3D Settings 2/3D Settings 3/Off

1. DISPLAY

Wall Color

Aspect Ratio Auto/Real/4:3/16:9/16:10 Keystone Position Phase H. Size Digital Zoom

3D mode

3D Sync Invert Disable/Invert

Save 3D Settings

Apply 3D Settings

Operation

2. PICTURE

3. Source

Picture Mode

Reference Mode

Brightness Contrast Color Tint Sharpness Brilliant Color On/Off Color

Temperature Color

Temperature Fine Tuning

3D Color Management

Reset Picture Settings

Quick Auto Search On/Off HDMI Range Auto/Full/Limited Color Space Conversion Auto/RGB/YUV

Bright/Presentation/sRGB/Cinema/(3D)/User 1/ User 2

Bright/Presentation/sRGB/Cinema/(3D)

Cool/Normal/Warm

R Gain/G Gain/B Gain/R Offset/G Offset/B Offset

Primary Color R/G/B/C/M/Y Hue Saturation Gain Current/All/

Cancel

Operation 39

Presentation Timer

Language

Timer Period 1~240 minutes

Timer Display

Timer Position

Timer Counting Direction

Sound reminder On/Off On/Off Yes/No

Always/3 min/2 min/1 min/ Never

Top-Left/Bottom-Left/TopRight/Bottom-Right

Count Down/Count Up

4. SYSTEM SETUP: Basic

Projector Installation

Menu display Time

Menu Settings

Operation Settings

Panel Key Lock

Background Color

Splash Screen BenQ/Black/Blue

Menu Position

Reminder message On/Off Direct Power On On/Off

Signal Power On

Auto Power Off

Quick Cooling On/Off Instant Restart On/Off

Blank Timer

Sleep Timer

Reset Filter Timer (optional)

On/OfffYes/No

Front Table/Rear Table/Rear Ceiling/Front Ceiling

5 secs/10 secs/20 secs/30 secs/Always

Center/Top-Left/Top-Right/ Bottom-Right/Bottom-Left

Computer HDMI Disable/3 mins/10 mins/15

mins/20 mins/25 mins/30 mins

Disable/5 mins/10 mins/15 mins/20 mins/25 mins/30 mins

Disable/30 mins/1 hr/2 hrs/3 hrs/4 hrs/8 hrs/12 hrs

Reset/Cancel

BenQ/Black/Blue/Purple

Operation

5. SYSTEM SETUP: Advanced

6. INFORMA TION

High Altitude Mode

Fan Speed Mode

Audio Settings

Lamp Settings

Security Settings

Baud Rate

Test Pattern On/Off

Standby Settings

Reset All Settings

Native Resolution

Current System Status

On/Off Yes/No

High/Normal

Mute On/Off Volume 0~10 Power On/Off Ring

Tone Lamp Mode Normal/Economic/SmartEco

Reset Lamp Timer

Equivalent Lamp Hour Change Password Change Security Power on lock

Monitor Out On/Off Audio Pass Through Off/Audio In/HDMI-1/HDMI-2

Reset/Cancel

Yes/No

On/Off

Reset/Cancel

2400/4800/9600/14400/19200/ 38400/57600/115200

Source Picture Mode Resolution Lamp Mode 3D Format Color System Equivalent Lamp Hour Firmware Version

Note that the menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.

Operation 41

Description of each menu

1. DISPLAY menu

• The default values listed in this manual, especially on pages 42-50, are

for reference only. They may vary between the projectors due to the continuous improvement to the products.

FUNCTION DESCRIPTION

Corrects the projected picture’s color when the projection

Wall Color

Aspect Ratio

Keystone

Position

Phase

H. Size

Digital Zoom

surface is not white. See "Using Wall Color" on page 30 for details.

There are four options to set the image's aspect ratio depending on your input signal source. See "Selecting the aspect ratio" on

page 28 for details.

Corrects any keystoning of the image. See "Correcting keystone"

on page 22 for details.

Displays the position adjustment page. To move the projected image, use the directional arrow keys. The values shown on the lower position of the page change with every key press you made until they reach their maximum or minimum.

This function is only available when a PC signal (analog RGB) is selected.

Adjusts the clock phase to reduce image distortion.

This function is only available when a PC signal (analog RGB) or YPbPr (Component) is selected.

Adjusts the horizontal width of the image.

This function is only available when a PC signal (analog RGB) is selected.

Magnifies or reduces the projected image. See "Magnifying and

searching for details" on page 27 for details.

Operation

FUNCTION DESCRIPTION

1. DISPLAY menu

This projector features a 3D function which enables you to enjoy the 3D contents in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view the 3D images.

3D mode

The default setting is Auto and the projector automatically chooses an appropriate 3D format when detecting 3D contents. If the projector cannot recognize the 3D format, press / to

choose a 3D mode.

3D Sync Invert

When you discover the inversion of the image depth, enable this function to correct the problem.

Save 3D Settings

The projector will memorize the current 3D settings.

Apply 3D Settings

The projector will apply saved 3D settings and keep these settings when you reboot the projector next time.

Operation 43

FUNCTION DESCRIPTION

2. PICTURE menu

Pre-defined picture modes are provided so you can optimize your

Picture Mode

Reference Mode

Brightness

Contrast

Color

Tint

Sharpness

projector image set-up to suit your program type. See "Selecting

a picture mode" on page 29 for details.

Selects a picture mode that best suits your need for the image quality and further fine-tune the image based on the selections listed on the same page below. See "Setting the User 1/User 2

mode" on page 29 for details.

Adjusts the brightness of the image. See "Adjusting Brightness"

on page 30 for details.

Adjusts the degree of difference between dark and light in the image. See"Adjusting Contrast" on page 30 for details.

Adjusts the color saturation level -- the amount of each color in a image. See "Adjusting Color" on page 30 for details.

Adjusts the red and green color tones of the image. See

"Adjusting Tint" on page 30 for details.

Adjusts the image to make it look sharper or softer. See

"Adjusting Sharpness" on page 30 for details.

Operation

FUNCTION DESCRIPTION

2. PICTURE menu

3. Source menu

Brilliant

See "Adjusting Brilliant Color" on page 30 for details.

Color

See "Selecting a Color Temperature" on page 30 for details.

Temperature

Color Temperature

See "Setting a preferred color temperature" on page 31 for details.

Fine Tuning

3D Color

See "3D Color Management" on page 31 for details.

Management

See "Resetting current or all picture modes" on page 32 for

Reset Picture Settings

Quick Auto

details. When Picture Mode is under Bright, choosing "Current" will only

reset the Bright to default value, however, choosing "All" will reset all the Picture Mode settings to default values.

See "Switching input signal" on page 26 for details.

Auto

Adjust HDMI RGB color space range automatically.

Full

HDMI Range

Color Space

Full Range color space. Black level: 0, white level: 255, valid range: 0~255.

Limited

Limited Range color space. Black level: 16, white level: 235, valid range: 1~254.

See "Changing Color Space" on page 27 for details.

Conversion

Operation 45

FUNCTION DESCRIPTION

4. SYSTEM SETUP:

Basic menu

Presentation Timer

Language

Projector Installation

Menu Settings

Reminds the presenter to finish the presentation within a certain time frame. See "Setting the presentation timer" on page 33 for details.

Sets the language for the On-Screen Display (OSD) menus. See

"Using the menus" on page 23 for details.

The projector can be installed on a ceiling or behind a screen, or with one or more mirrors. See "Choosing a location" on page 16 for details.

Menu display Time

Sets the length of time the OSD will remain active after your last key press. The range is from 5 to 30 seconds in 5-second increments.

Menu Position

Sets the On-Screen Display (OSD) menu position.

Reminder message

Sets whether to display the reminder message.

Operation

FUNCTION DESCRIPTION

4. SYSTEM SETUP:

Basic menu

Direct Power On

Selecting On enables the function. See "Starting up the

projector" on page 19 for details.

Signal Power On

Selecting On the projector will turn on automatically when VGA signal is detected. Selecting Off the projector has to be turnned on manually (by keypad or remote). See "Starting up the

projector" on page 19 for details.

Auto Power Off

Allows the projector to turn off automatically if no input signal is detected after a set period of time. See "Setting Auto Power Off"

on page 53 for details.

Quick Cooling Selecting On enables the function and the projector cooling time

Operation Settings

Panel Key Lock

Background Color

Splash Screen

will be shortened to a few seconds.

If you attempt to restart the projector right after the quick cooling process, it may not be turned on successfully and will rerun its cooling fans.

Instant Restart

When instant restart is on, users can restart projector immediately within 90 secs after turning off projector.

Blank Timer

Sets the image blank time when the Blank feature is activated, once elapsed the image will return to the screen. See "Hiding the

image" on page 34 for details.

Sleep Timer

Sets the auto-shutdown timer. The timer can be set to a value between 30 minutes and 12 hours.

Reset Filter Timer

Resets the filter timer if a new filter is replaced. Disables or enables all panel key functions except Power on the

projector.

Allows you to select which background color will display when no signal is input into the projector. Four options are available: BenQ logo, Black, Blue, or Purple.

Allows you to select which logo screen will display during projector start-up. Three options are available: BenQ logo, Black screen, or Blue screen.

Operation 47

FUNCTION DESCRIPTION

5. SYSTEM SETUP: Advanced menu

High Altitude Mode

Fan Speed Mode

Audio Settings

Lamp Settings

Security Settings

Baud Rate

Test Pattern

A mode for operation in high altitude areas. See "Operating in a

high altitude environment" on page 35 for details.

Selecting High when the projector is installed a dust filter. See

"Installing the dust filter (Optional accessory)" on page 58 for

details. Allows you to enter the audio setting menu. See "Adjusting the

sound" on page 35 for details.

Mute

Sets the mute function.

Volume

Adjusts the audio volume level.

Power On/Off Ring Tone

Sets the power on/off ring tone.

Lamp Mode

See "Setting Lamp mode" on page 52 for details.

Reset Lamp Timer

See "Resetting the lamp timer" on page 57 for details.

Equivalent Lamp Hour

See "Getting to know the lamp hour" on page 52 for details on how the total lamp hour is calculated.

Change Password

You will be asked to enter the current password before changing to a new one.

Change Security Power on lock

See "Utilizing the password function" on page 24 for details. Selects a baud rate that is identical with your computer’s so that

you can connect the projector using a suitable RS-232 cable and update or download the projector’s firmware. This function is intended for qualified service personnel.

Selecting On enables the function and the projector displays the grid test pattern. It helps you adjust the image size and focus and check that the projected image is free from distortion. See "Use

build-in test pattern" on page 21 for details.

Operation

FUNCTION DESCRIPTION

5. SYSTEM SETUP: Advanced menu

Monitor Out

Selecting On enables the function. The projector can output a VGA signal when it is in standby mode and the PC and MONITOR OUT jacks are correctly connected to devices. See

"Connecting a monitor" on page 19 for how to make the

connection.

Enabling this function slightly increases the standby power consumption.

Standby Settings

Reset All Settings

The Standby Monitor Out only works when an appropriate D-Sub input is made to the PC jack.

Audio Pass Through

The projector can play sound when it is in standby mode and the corresponding jacks are correctly connected to devices. Press

/ to choose the source that you wish to use. See

"Connection" on page 18 for how to make the connection.

Enabling this function slightly increases the standby power consumption.

Returns all settings to the factory preset values.

The following settings will still remain: User 1, User 2, Projector Installation, Color Space Conversion, High Altitude Mode, Security Settings and Baud Rate.

Operation 49

FUNCTION DESCRIPTION

6. INFORMATION menu

Native

Shows the native resolution of the projector.

Resolution

Source

Shows the current signal source.

Picture Mode Shows the selected mode in the PICTURE menu.

Resolution

Shows the supported resolution of the input signal.

Current System Status

Lamp Mode

Shows the current lamp mode.

3D Format

Shows the current 3D mode.

Color System

Shows input system format RGB or YUV.

Equivalent Lamp Hour

Displays the number of hours the lamp has been used.

Firmware Version

Shows firmware version.

Operation

Maintenance

Care of the projector

Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens and case clean.

Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

Cleaning the lens

Clean the lens whenever you notice dirt or dust on the surface.

• Use a canister of compressed air to remove dust.

• If there is dirt or smears, use lens-cleaning paper or moisten a soft cloth with lens

cleaner and gently wipe the lens surface.

• Never use any type of abrasive pad, alkaline/acid cleaner, scouring powder, or

volatile solvent, such as alcohol, benzene, thinner or insecticide. Using such materials or maintaining prolonged contact with rubber or vinyl materials may result in damage to the projector surface and cabinet material.

Never rub the lens with abrasive materials.

Cleaning the projector case

Before you clean the case, turn the projector off using the proper shutdown procedure as described in "Shutting down the projector" on page 37 and unplug the power cord.

• To remove dirt or dust, wipe the case with a soft, lint-free cloth.

• To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral

pH detergent. Then wipe the case.

Never use wax, alcohol, benzene, thinner or other chemical detergents. These can damage the case.

Storing the projector

If you need to store the projector for an extended time, please follow the instructions below:

• Make sure the temperature and humidity of the storage area are within the

recommended range for the projector. Please refer to "Specifications" on page 61 or consult your dealer about the range.

• Retract the adjuster feet.

• Remove the battery from the remote control.

• Pack the projector in its original packing or equivalent.

Transporting the projector

It is recommended that you ship the projector with its original packing or equivalent.

Maintenance 51

Lamp information

, if

Getting to know the lamp hour

When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows:

1. Lamp Usage Time = (x+y+z) hours, if

Time used in Normal mode = x hours Time used in Eco mode = y hours Time used in SmartEco mode = z hours

2. Equivalent Lamp Hour= hours

X= lamp life spec of Normal mode Y= lamp life spec of Eco mode Z= lamp life spec of SmartEco mode A' is the longest lamp life spec amoung X, Y, Z

See "Setting Lamp mode" below for more information on Economic mode.

The lamp hour in Economic and SmartEco is calculated shorter of that in Normal mode. That is, using the projector in Economic or SmartEco mode helps to extend the lamp hour.

To obtain the lamp hour information:

1. Press MENU and then press / until the SYSTEM SETUP: Advanced menu is highlighted.

2. Press to highlight Lamp Settings and press OK. The Lamp Settings page displays.

3. You will see the Equivalent Lamp Hour information displaying on the menu.

4. To leave the menu, press MENU.

You can also get the lamp hour information on the INFORMATION menu.

Extending lamp life

The projection lamp is a consumable item. To keep the lamp life as long as possible, you can do the following settings via the OSD menu or remote control.

Setting Lamp mode

Using Economic/SmartEco mode will reduces system noise and power consumption. If the Economic/SmartEco mode is selected, the light output will be

reduced and result in darker projected pictures, the projector protected for longer working life.

Setting the projector in Economic/SmartEco mode also extends the lamp operation life. To set Economic/SmartEco mode, go into the SYSTEM SETUP:

Advanced > Lamp Settings > Lamp mode menu and press

Maintenance

The lamp modes are defined as the chart below.

Lamp mode Description

Normal Provides full lamp brightness

Economic

SmartEco

Lowers brightness to extend the lamp life and decreases the fan noise

Adjusts the lamp power automatically depending on the content brightness level

Setting Auto Power Off

This function allows the projector to turn off automatically if no input source is detected after a set period of time to prevent unnecessary waste of lamp life.

To s e t Auto Power Off, go into the SYSTEM SETUP: Basic > Auto Power Off menu and press / . The time period can be set from 5 to 30 minutes in 5-minute increments. If the preset time lengths are not suitable for your presentation, select Disable. The projector will not automatically shut down in a certain time period.

Maintenance 53

Timing of replacing the lamp

When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode.

Do not attempt to replace the lamp yourself. Contact the qualified service personnel for replacement.

The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot. See "Indicators" on page 59 for details.

The following lamp warning displays will remind you to change the lamp.

The warning messages below are for reference only. Please follow the

actual on-screen instructions to prepare and replace the lamp.

Status Message

Install a new lamp for optimal performance. If the projector is normally run with Economic selected ("Setting Lamp mode" on page 52), you may continue to operate the projector until the next lamp warning appears.

A new lamp should be fitted to avoid the inconvenience when the projector runs out of lamp time.

It is strongly recommended that you replace the lamp at this stage. The lamp is a consumable item. The lamp brightness diminishes with use. This is normal lamp behavior. You can replace the lamp whenever you notice that the brightness level has significantly diminished.

The lamp MUST be replaced before the projector will operate normally.

"XXXX" shown in the above messages are numbers that vary depending on different models.

Maintenance

Replacing the lamp (FOR SERVICE PERSONNEL ONLY)

• Hg - Lamp contains mercury. Manage in accordance with local

disposal laws. See www.lamprecycle.org.

• If lamp replacement is performed while the projector is suspended

upside-down from the ceiling, make sure that no one is underneath the lamp socket to avoid any possible injury or damage to the human eyes caused by fractured lamp.

• To reduce the risk of electrical shock, always turn the projector off and

disconnect the power cord before changing the lamp.

• To reduce the risk of severe burns, allow the projector to cool for at

least 45 minutes before replacing the lamp.

• To reduce the risk of injuries to fingers and damage to internal

components, use caution when removing lamp glass that has shattered into sharp pieces.

• To reduce the risk of injuries to fingers and/or compromising image

quality by touching the lens, do not touch the empty lamp compartment when the lamp is removed.

• This lamp contains mercury. Consult your local hazardous waste

regulations to dispose of this lamp in a proper manner.

• To assure optimal performance from the projector, it is recommended

that you purchase a BenQ projector lamp for lamp replacement.

• Ensure good ventilation when handling broken lamps. We recommend

that you use respirators, safety glasses, goggles or face shield and wear protective clothing such as gloves.

1. Turn the power off and disconnect the projector from the power outlet. If the lamp is hot, avoid burns by waiting for approximately 45 minutes until the lamp has cooled.

2. Loosen the screw on the lamp cover.

Maintenance 55

3. Remove the lamp cover by (a) sliding

the cover toward the side of the projector and (b) lifting it off.

• Do not turn the power on with

the lamp cover removed.

• Do not insert your fingers

between the lamp and the projector. The sharp edges inside the projector may cause injuries.

4. Loosen the screws that secure the lamp.

5. Lift the handle so that it stands up. Use the handle to slowly pull the lamp out of the projector.

• Pulling it too quickly may cause

the lamp to break and scatter broken glass in the projector.

• Do not place the lamp in locations

where water might splash on it, children can reach it, or near flammable materials.

• Do not insert your hands into the

projector after the lamp is removed. If you touch the optical components inside, it could cause color unevenness and distortion of the projected images.

(b)

(a)

6. Insert the new lamp into the lamp compartment and make sure it fits in the projector.

7. Tighten the screws that secure the lamp.

• Loose screw may cause a bad

connection, which could result in malfunction.

• Do not over tighten the screws.

8. Ensure the handle is fully laid flat and locked in place.

Maintenance

9. Replace the lamp cover by sliding it

(b)

(a)

into place.

10. Tighten the screw that secures the lamp cover.

• Loose screw may cause a bad

connection, which could result in malfunction.

• Do not over tighten the screw.

11. Restart the projector.

Do not turn the power on with the lamp cover removed.

Resetting the lamp timer

12. After the startup logo, open the OnScreen Display (OSD) menu. Go to the

SYSTEM SETUP: Advanced > Lamp Settings menu. Press OK. The Lamp Settings page displays. Press to highlight Reset lamp timer and press OK. A warning message displays asking if you want to reset the lamp timer. Highlight Reset and press OK. The lamp time will be reset to '0'.

Do not reset if the lamp is not new or replaced as this could cause damage.

Maintenance 57

Installing the dust filter (Optional accessory)

The dust filter is an optional accessory, and it varies by region.

1. Follow the illustration to install the dust filter. Align the dust filter with the arrow positions, then press it close to the projector.

2. Press the hooks until it clicks.

3. Turn on the projector, then press MENU, go to SYSTEM SETUP: Advanced > Fan Speed Mode > High and select Yes.

4. Clean the dust filter periodically. To clean the dust filter, use a small vacuum cleaner designed for computers and other office equipment.

The dust filter should be used in dusty environments only. Filters must be cleaned/replaced periodically i.e after every 500 hrs or 3 months, or sooner depending upon the air environment. Clogged filter can restrict air flow causing the projector to heat excessively leading to pre-mature lamp and/ or projector failure.

5. If the dirt is difficult to remove or the filter is broken, please contact your local dealer or service center to obtain a new filter.

6. Reset filter timer after a new filter is replaced. Go to SYSTEM SETUP: Basic > Operation Settings > Reset Filter Timer and select Reset.

Maintenance

Indicators

Light Status & Description

POWER TEMP LAMP

System Message

Orange Off Off Stand-by mode

Green

Flashing

Green Off Off Normal operation

Orange

Flashing

Red

Flashing

Green Off Red CW start fail

Green Off Off Burn-in ON Green Green Green Burn-in OFF

Off Off Red Lamp1 error in normal operation

Off Off

Red Red Off

Red

Green Red Off Temperature 1 error (over limited temperature)

Green

Green Green Off Thermal Sensor 1 short error Green

Flashing

Off Off Powering up

Off Off Normal power-down cooling

Red

Flashing

Red

Flashing

Red

Flashing

Green

Flashing

Red

Flashing

Orange

Flashing

Download

Burn-In Messages

Lamp Error Messages

Lamp is not lit up

Thermal Error Messages

Fan 1 error (the actual fan speed is outside the desired speed)

Fan 2 error (the actual fan speed is outside the

Off

desired speed)

Off Thermal Sensor 1 open error

Off Thermal IC #1 I2C Connection error

Maintenance 59

Troubleshooting

The projector does not turn on.

Cause Remedy

There is no power from the power cable.

Attempting to turn the projector on again during the cooling process.

No picture

Cause Remedy

The source is not turned on or connected correctly.

The projector is not correctly connected to the input signal device.

The input signal has not been correctly selected.

Blurred image

Cause Remedy

The projection lens is not correctly focused.

The projector and the screen are not aligned properly.

Plug the power cord into the AC inlet on the projector, and plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on.

Wait until the cooling down process has completed.

Turn the source on and check that the signal cable is connected correctly.

Check the connection.

Select the correct input signal with the SOURCE key on the projector or remote control.

Adjust the focus of the lens using the focus ring.

Adjust the projection angle and direction as well as the height of the unit if necessary.

Remote control does not work

Cause Remedy

The battery is out of power. Replace the battery with new one. There is an obstacle between the

remote control and the projector. You are too far away from the

projector.

The password is incorrect

Cause Remedy

You do not remember the password.

Troubleshooting

Remove the obstacle.

Stand within 8 meters (26 feet) of the projector.

Please see "Entering the password recall

procedure" on page 25 for details.

Specifications

All specifications are subject to change without notice.

Optical

Resolution

MS535P: 800 x 600 SVGA MX535P: 1024 x 768 XGA

Display system

1-CHIP DMD

Lens F/Number

F = 2.42 to 2.62 f = 22 to 25.79 mm

Offset

MS535P: 106.7±5% MX535P: 106±5%

Zoom ratio

1.2X

Lamp

210 W lamp

Electrical

Power supply

AC100–240V, 2.60 A, 50-60 Hz (Automatic)

Power consumption

260 W (Max); < 0.5 W (Standby)

Mechanical

Weigh t

2.6 kg (5.7 lbs)

Output terminals

RGB output

D-Sub 15-pin (female) x 1

Speaker

(Stereo) 2 watt x 1

Audio signal output

PC audio jack x 1

Control

RS-232 serial control

9 pin x 1 IR receiver x 1 USB mini-B x 1

Input terminals

Computer input

RGB input

D-Sub 15-pin (female) x 2

Digital signal input

HDMI x 2

Audio signal input

Audio in

PC audio jack x 1

Environmental Requirements

Te m p e r a t u r e

Operating: 0°C-40°C at sea level Storage: -20°C-60°C at sea level

Relative humidity

Operating: 10%-90% (without condensation) Storage: 10%-90% (without condensation)

Altitude

Operating: 0-1499 m at 0°C-35°C; 15003000 m at 0°C-30°C (with High Altitude Mode on) Storage: 0-12200 m at 30°C

Tr a n s po r t i n g

Original packing or equivalent is recommended.

Repairing

Please visit below website and choose your country to find your service contact window.

http://www.benq.com/welcome

Lamp life results will vary depending on environmental conditions and usage.

Specifications 61

Dimensions

241.3

332.4

127.7

149.5 84

242

228

537.9

577.7

626.9

89.1

166.2

332.4

60.6

Ceiling mount screw: M4 (Max L = 25 mm; Min L=20 mm) Unit: mm

332.4 mm (W) x 99 mm (H) x 241.3 mm (D)

Ceiling mount installation

Specifications

Timing chart

1. VGA Analog

Supported timing for PC input

Resolution Timing

VGA_60 59.94 31.469 25.175

640 x 480

720 x 400

800 x 600

1024 x 768

1152 x 864

1024 x 576

1024 x 600

1280 x 720

1280 x 768

1280 x 800

1280 x 1024

1280 x 960

1360 x 768

1440 x 900

VGA_72 72.809 37.861 31.500 VGA_75 75 37.5 31.500 VGA_85 85.008 43.269 36.000

720 x

400_70 SVGA_60 60.317 37.879 40.000 SVGA_72 72.188 48.077 50.000 SVGA_75 75 46.875 49.500 SVGA_85 85.061 53.674 56.250

SVGA_120

(Reduce Blanking) XGA_60 60.004 48.363 65.000 XGA_70 70.069 56.476 75.000 XGA_75 75.029 60.023 78.750 XGA_85 84.997 68.667 94.500

XGA_120

(Reduce Blanking)

1152 x

864_75

BenQ

Notebook

Timing

BenQ

Notebook

Timing 1280 x

720_60

1280 x

720_120

1280 x

768_60 WXGA_60 59.81 49.702 83.500 WXGA_75 74.934 62.795 106.500 WXGA_85 84.88 71.554 122.500

WXGA_120

(Reduce

Blanking) SXGA_60 60.02 63.981 108.000 SXGA_75 75.025 79.976 135.000 SXGA_85 85.024 91.146 157.500

1280 x

960_60

1280 x

960_85

1360 x

768_60

WXGA+_6

Horizontal Frequency

(KHz)

70.087 31.469 28.3221

119.854 77.425 83.000

119.989 97.551 115.5

75 67.5 108

60 35.82 46.966

64.995 41.467 51.419

60 45 74.250

120 90.000 148.500

59.87 47.776 79.5

119.909 101.563 146.25

60 60 108.000

85.002 85.938 148.500

60.015 47.712 85.5

59.887 55.935 106.500

Ve rt ic a l

Frequenc

y (Hz)

Pixel

Frequency

(MHz)

3D Field Sequent

ial

◎◎◎

◎

◎◎◎

◎

◎◎◎

◎

◎◎◎

◎

top

side

bott

side

◎◎

Specifications 63

1400 x 1050 SXGA+_60 59.978 65.317 121.750 1600 x 1200 UXGA 60 75 162.000

1680 x 1050

640 x 480

@67Hz

832 x 624

@75Hz

1024 x 768

@75Hz

1152 x 870

@75Hz

1680 x

1050_60

MAC13 66.667 35 30.240

MAC16 74.546 49.722 57.280

MAC19 75.02 60.241 80.000

MAC21 75.06 68.68 100.000

59.954 65.29 146.25

• The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen.

2. HDMI Digital

Supported timing for PC input

Resolution Timing

VGA_60 59.94 31.469 25.175

640 x 480

720 x 400

800 x 600

1024 x 768

1152 x 864

1024 x 576

1024 x 600

1280 x 720

1280 x 768

VGA_72 72.809 37.861 31.500 VGA_75 75 37.5 31.500 VGA_85 85.008 43.269 36.000

720 x

400_70 SVGA_60 60.317 37.879 40.000 SVGA_72 72.188 48.077 50.000 SVGA_75 75 46.875 49.500 SVGA_85 85.061 53.674 56.250

SVGA_120

(Reduce Blanking) XGA_60 60.004 48.363 65.000 XGA_70 70.069 56.476 75.000 XGA_75 75.029 60.023 78.750 XGA_85 84.997 68.667 94.500

XGA_120

(Reduce Blanking)

1152 x

864_75

BenQ

Notebook

Timing

BenQ

Notebook

Timing 1280 x

720_60

1280 x

768_60

Horizontal Frequency

(KHz)

70.087 31.469 28.3221

119.854 77.425 83.000

119.989 97.551 115.5

75 67.5 108

60 35.82 46.966

64.995 41.467 51.419

60 45 74.250

59.87 47.776 79.5

Ve rt ic a l

Frequenc

y (Hz)

Pixel

Frequency

(MHz)

3D Field Sequent

ial

◎◎◎

◎

◎◎◎

◎

◎◎◎

◎◎ ◎◎

◎◎

top

side

bott

side

Specifications

WXGA_60 59.81 49.702 83.500 WXGA_75 74.934 62.795 106.500

1280 x 800

1280 x 1024

1280 x 960

1360 x 768

1440 x 900

1400 x 1050 SXGA+_60 59.978 65.317 121.750 1600 x 1200 UXGA 60 75 162.000

1680 x 1050

640 x 480

@67Hz

832 x 624

@75Hz

1024 x 768

@75Hz

1152 x 870

@75Hz

1920 x 1080

1920 x 1200

WXGA_85 84.88 71.554 122.500

WXGA_120

(Reduce Blanking)

SXGA_60 60.02 63.981 108.000 SXGA_75 75.025 79.976 135.000 SXGA_85 85.024 91.146 157.500

1280 x

960_60

1280 x

960_85

1360 x

768_60

WXGA+_6

1680 x

1050_60

MAC13 66.667 35 30.240

MAC16 74.546 49.722 57.280

MAC19 75.02 60.241 80.000

MAC21 75.06 68.68 100.000

1920 x

1080_60

1920 x

1200_60

(Reduce Blanking)

119.909 101.563 146.25

60 60 108.000

85.002 85.938 148.500

60.015 47.712 85.5

59.887 55.935 106.500

59.954 65.29 146.25

67.5 60 148.5

59.95 74.038 154.000

◎◎◎

◎

The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen.

◎◎

◎◎ ◎◎

◎◎

Specifications 65

3D Field Sequential

3D Frame Packing

3D Top-Bottom

3D Side by Side

Timing Resolution

480i

480p 720 x 480 31.47 59.94 27

576i

576p 720 x 576 31.25 50 27 720/50p 1280 x 720 37.5 50 74.25 720/60p 1280 x 720 45.00 60 74.25

1080/50i 1920 x 1080 28.13 50 74.25 1080/60i 1920 x 1080 33.75 60 74.25 1080/24P 1920 x 1080 27 24 74.25 1080/25P 1920 x 1080 28.13 25 74.25 1080/30P 1920 x 1080 33.75 30 74.25 1080/50P 1920 x 1080 56.25 50 148.5 1080/60P 1920 x 1080 67.5 60 148.5

720 (1440)

x 480

720 (1440)

x 576

Horizontal

Frequency

(KHz)

15.73 59.94 27

15.63 50 27

Ve rt ic al

Frequenc

y (Hz)

Pixel

Frequency

(MHz)

◎

◎◎◎ ◎◎◎

◎

◎◎◎

◎ ◎

◎◎ ◎◎

Specifications

Warranty and Copyright information

Patents

Please go to http://patmarking.benq.com/ for the details of BenQ projector patent coverage.

Limited warranty

BenQ warrants this product against any defects in material and workmanship, under normal usage and storage.

Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.

Important: The above warranty shall be void if the customer fails to operate the product in accordance with BenQ's written instructions, especially the ambient humidity must be in-between 10% and 90%, temperature in-between 0°C and 35°C, altitude lower than 4920 feet, and avoiding to operate the projector in a dusty environment. This warranty gives you specific legal rights, and you may have other rights which vary from country to country.

For other information, please visit www.BenQ.com.

Copyright 2018 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

Disclaimer

BenQ Corporation makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.

*DLP, Digital Micromirror Device and DMD are trademarks of Texas Instruments. Others are copyrights of their respective companies or organizations.

Warranty and Copyright information

Benq MS535P, MX535P User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Ta bl e o f c o n te n t s

Important safety instructions

Introduction

Projector features

Shipping contents

Standard accessories

Optional accessories

Projector exterior view

Controls and functions

Projector

Remote control

Positioning your projector

Choosing a location

Obtaining a preferred projected image size

Projection dimensions

Connection

Operation

Starting up the projector

Adjusting the projected image

Adjusting the projection angle

Auto-adjusting the image

Use build-in test pattern

Fine-tuning the image size and clarity

Correcting keystone

Using the menus

Securing the projector

Using a security cable lock

Utilizing the password function

Setting a password

If you forget the password

Entering the password recall procedure

Changing the password

Disabling the password function

Switching input signal

Changing Color Space

Magnifying and searching for details

Selecting the aspect ratio

Optimizing the image

Selecting a picture mode

Using Wall Color

Fine-tuning the image quality in user modes

Setting the presentation timer

Remote paging operations

Hiding the image

Freezing the image

Operating in a high altitude environment

Adjusting the sound

Personalizing the projector menu display

Select the lamp saver mode

Shutting down the projector

Menu operation

Menu system

Description of each menu

Maintenance

Care of the projector

Cleaning the lens

Cleaning the projector case

Storing the projector

Transporting the projector

Lamp information

Getting to know the lamp hour

Extending lamp life

Timing of replacing the lamp

Replacing the lamp (FOR SERVICE PERSONNEL ONLY)

Installing the dust filter (Optional accessory)

Indicators

Troubleshooting

Specifications

Dimensions

Ceiling mount installation

Timing chart

1. VGA Analog

2. HDMI Digital

Warranty and Copyright information
