BenQ Display Pilot User Manual
Display Pilot
User Manual
LCD Monitor Software
Copyright and disclaimer
Copyright
Copyright 2019 BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any
form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the
prior written permission of BenQ Corporation.
All other logos, products, or company names mentioned in this manual may be the registered trademarks or
copyrights of their respective companies, and are used for informational purposes only.
Disclaimer
BenQ Corporation makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specically disclaims any warranties, merchantability or tness for any particular purpose.
Further, BenQ Corporation reserves the right to revise this publication and to make changes from time to
time in the contents hereof without obligation of BenQ Corporation to notify any person of such revision or
changes.
This document aims to provide the most updated and accurate information to customers, and thus all contents
may be modied from time to time without prior notice. Please visit the website for the latest version of this
document.
It is the sole responsibility of the user if problems (such as data loss and system failure) occurred due to
non-factory installed software, parts, and/or non-original accessories.
(Applicable for icker-free models only) The performance of icker-free may be affected by external factors
such as poor cable quality, unstable power supply, signal interference, or poor grounding, and not limited to the
above mentioned external factors.
Servicing (Windows only)
Should you have any queries about the software after reading the document, contact the customer support
from System > Information > Technical Support.
Typographics
Icon / Symbol Item Meaning
Warning
Tip Useful information for completing a task.
Note Supplementary information.
In this document, the steps needed to reach a menu are shown in condensed form, for example: System >
Information.
Information mainly to prevent the damage to components, data, or personal injury
caused by misuse and improper operation or behavior.
Table of contents
Copyright and disclaimer............................................................................................................................................................2
Copyright ..................................................................................................................................................................................2
Disclaimer................................................................................................................................................................................. 2
Servicing (Windows only) ..................................................................................................................................................... 2
Typographics ............................................................................................................................................................................ 2
Introduction ..................................................................................................................................................................................4
Compatible operating systems ............................................................................................................................................ 4
Installing and launching the Display Pilot software .................................................................................................. ....4
Exiting Display Pilot ..........................................................................................................................4
Overview ....................................................................................................................................................................................... 5
Adjusting the settings............................................................................................................................................................. 6
Conguring Preferences .................................................................................................................... 6
Applying and customizing a color mode ................................................................................................................................. 7
Selecting a color mode from the menu (Color Mode) ...............................................................................................7
Customizing and restoring a color mode .........................................................................................................................7
Switching color modes with keyboard shortcuts ............................................................................................................8
Switching color modes from the context menu (Windows only) ............................................................................... 8
Switching color modes from the system tray (Windows only) ................................................................................... 8
Working with two color modes simultaneously (DualView) .......................................................................................... 9
Switching color modes for DualView with keyboard shortcuts ............................................................................... 9
Changing an input.......................................................................................................................................................................10
Changing an input source from the menu .......................................................................................................................10
Switching input source with keyboard shortcuts ................................................................................................. .........10
Rotating your screen .................................................................................................................................................................10
Manually rotate the screen (Screen Pivot) .................................................................................................................. 10
Automatically rotate the screen (Auto Pivot) ............................................................................................................10
Working with two or more video sources (PIP/PBP) ....................................................................................................10
Managing the layout of multiple windows (Desktop Partition) ..................................................................................11
Creating a window layout ................................................................................................................................................... 12
Customizing each application's color mode (Application Mode) ..............................................................................13
For Windows .........................................................................................................................................................................13
For both Windows and Mac ............................................................................................................................................... 13
Placing your design accurately (Print Assist) ....................................................................................................................14
System information and technical support ........................................................................................................................... 15
Reseting the system ................................................................................................................................................................... 15
Checking for a system update automatically .......................................................................................................................15
09/04/19
Introduction
Display Pilot is a software utility that allows for quick accurate tuning of the display with the ability to easily
save and use monitor congurations that are best suited for you. All adjustments are controlled via software to
eliminate the need to use the monitor on-screen displays (OSD).
• Display Pilot scans the connected display to determine which features are supported. The list of supported features dis-
played in the application will vary based on the monitor model and input selected. Therefore, not all controls and features
described in this document may appear in the application.
• Images in this document are for reference only and may look different according to the operating system of your computer.
The user interface may subject to change without prior notice.
Compatible operating systems
• Windows 7 or above operating systems
• MacOS Mojave 10.14
Installing and launching the Display Pilot software
1. Visit the local website from www.BenQ.com > the purchased model > the Support tab > the Software
tab to download the Display Pilot software.
2. (On Windows) Click the le just downloaded and follow the on-screen instructions to complete the installation. Choose your language preference for installation process. Check Launch Display Pilot in last step
before you nish the installation. Now the software runs in the background and can be accessed through
the Start menu or the system tray at the bottom-right corner of the screen.
(On Mac) Click the le just downloaded from Downloads and install and launch the application properly.
Choose your language preference for installer in the beginning of installation. Once the software is installed, the interface
follows the operating system language setting and cannot be changed from the software.
Exiting Display Pilot
1. Right-click the icon from the system tray at the bottom-right or top-right corner of the screen.
2. (On Windows) Click Exit to close the software.
(On Mac) Click Quit to close the software.
4
Overview
1
2
3
4
6
789
5
1
2
3
4
5
6
7
8
No. Name Descriptions
Color menu Switches to the color settings.
• Color setting synchronization between computer and monitor (ICC Sync) on
page 7
• Selecting a color mode from the menu (Color Mode) on page 7
• Customizing and restoring a color mode on page 7
• Working with two color modes simultaneously (DualView) on page 9
Display menu Switches to different input signals, or pivot, PIP, and PBP settings.
• Changing an input on page 10
• Rotating your screen on page 10
• Working with two or more video sources (PIP/PBP) on page 10
Tools menu Access to extended functions to work with multiple application windows and
more.
• Managing the layout of multiple windows (Desktop Partition) on page 11
• Customizing each application's color mode (Application Mode) on page 13
• Switching color modes with keyboard shortcuts on page 8
• Switching color modes for DualView with keyboard shortcuts on page 9
• Switching input source with keyboard shortcuts on page 10
• Placing your design accurately (Print Assist) on page 14
System menu Shows the display status and provides access to adjust preferences.
• Conguring Preferences on page 6
• System information and technical support on page 15
• Reseting the system on page 15
Current color mode Shows the current color mode of the connected display.
Close button Closes the window while the application is still running in background.
Information button Displays the information on the current function tab.
Minimize button Minimizes the window.
5
