Benq 9H.F51TK.NA2 Product Data Sheet

The Robust and Sleek All-in-One Solution

BenQ 43” 55” Smart Signage

ST4301K/ ST5501K

X-Sign

USB Plug

& Play

DMS Tools

Specications

Panel

Audio

Connectivity

Powe r

Mechanical

Environment

OSD

Software

Accessory

ST4301K ST5501K

Screen Size (inch) 43” 55”

Backlight/Lightsource D-LED D-LED

Active Area (horizontal × vertical)(mm) 941.2(H)mm x 680.4(V)mm 1209.6(H)mm × 680.4(V)mm

Resolution (pixels) UHD 3840 x 2160 UHD 3840 x 2160

Brightness (typical) 350 nits 350 nits

Contrast Ratio (typical) 1100:1 1200:1

Viewing Angle (horizontal/vertical) 178° / 178° 178° / 178°

Aspect Ratio 16:9 16:9

Light Life (typical) 30,000hrs 30,000hrs

Display Orientation Landscape / Portrait Landscape / Portrait

Internal Speaker (Amp) 5W x 2 5W x 2

Audio Line In/Out (3.5mm) No / x1 No / x1

VGA In/Out x1 / No x1 / No

DVI In/Out x1 / No x1 / No

HDMI In/Out x2 / No x2 / No

Display Port In/Out x1 / No x1 / No

USB port (Type A) x3 (2.0) x3 (2.0)

RJ45 Port In/Out x1 / No x1 / No

AC/DC In AC AC

AC Power Switch Yes Yes

Voltage 100V ~ 240V, 50Hz / 60Hz 100V ~ 240V, 50Hz / 60Hz

Power Consumption (typical/standby )

Dimension (WxHxD) (mm) 969.9 x 558.3 x 84.8(mm)

Bezel Width (top/bottom/left/right) (mm) 13.0/13.0/13.0/13.0 mm 13.9/13.9/13.9/13.9 mm

Weight (w/o Packing/ w/ Packing) (kg) 10.4kg / 14.0kg

Wall Mounting (VESA) (mm) 200x400 (4-M6) 400x400 (4-M6)

Operation Temperature 0°C ~ 40°C 0°C ~ 40°C

Storage Temperature -10°C ~ 60°C -10°C ~ 60°C

On-Screen Display Languages

Device Management Solution (DMS) Yes Yes

X-Sign (please check X-Sign website for detailed
compatibility info.)

Remote Control Yes Yes

Power Cord (by region) Yes Yes

VGA Cable Yes Yes

HDMI Cable Yes Yes

Quick Start Guide Yes Ye s

User’s Manual Electronic File Yes Ye s

RS232 Cable Yes Yes

65W≦0.5W 93W≦0.5W

1243.2 x 714.0 x 69.6(mm)

15.0kg / 20.8kg

English / French / German / Dutch / Polish /
Russian / Czech / Danish / Swedish / Italian
/ Romanian / Finnish / Norwegian / Greek /
Hungarian / Spanish / Portuguese / Traditional
Chinese / Simplified Chinese / Arabic / Japanese
/ Thai / Persian / Vietnamese / Korean (25L)

Yes Yes

English / French / German / Dutch / Polish /
Russian / Czech / Danish / Swedish / Italian
/ Romanian / Finnish / Norwegian / Greek /
Hungarian / Spanish / Portuguese / Traditional
Chinese / Simplified Chinese / Arabic /
Japanese / Thai / Persian / Vietnamese / Korean
(25L)

Input/output terminals

1 2 3

RJ451

USB(1.5A)

2

USB

3

USB

4

4 5 6 7 8 9 10

5 Display Port

HDMI

6

HDMI

7

8 DVI

VGA

9

PS AUDIO IN

10

11 12 13

LINE OUT

11

RS232

12

Micro SD

13

The All-in-One Solution for

Retail Spaces of All Kinds

BenQ Smart Signage series is the ideal digital display solution for small businesses and corporations. It brings

together a wide variety of features that further elevate the attractiveness of retail and corporate environments.

The stunning 4K resolution helps to enhance customer engagement, while the iron frame that covers all sides

of the signage provides a robust and sleek design that blends well into modern retail and corporate spaces.
Additionally, the powerful X-Sign software facilitates effortless content creation and management, and DMS

The wide range of sizes and sleek design ensure that businesses and corporations can enjoy a consistent look

that helps them establish strong brand or corporate images. Combining all the aforementioned features and

benets, Smart Signage series is an all-in-one solution for modern businesses and corporations.

application guarantees hassle-free display control.

All-in-One, Clutter Free Solution

Android Built-In

Built-in Android means that BenQ Smart Signage series is ready to work as soon as
operators plug it in. There’s no need to hook it up to a PC or other device to serve
content, and embedded speakers provide for the audio needs. With no cables to hide,

the all-in-one Smart Signage ts neatly on shelves and reduces clutter.

USB Plug & Play

The plug-and-play simplicity enables you to access and play multimedia les directly from
a USB ash drive. Requiring no PC connection or complicated cable setup, BenQ Smart

Signage ensures a holistic shopping experience with the most hassle-free installation.

Wireless Solution for Seamless Collaboration

InstaShare is the software designed for seamless wireless presentation and

collaboration during lectures. It allows the smooth streaming of visual, audio les
and Full HD quality videos. Users can also mirror content from mobile devices,

and invite up to 16 participants for seamless collaboration.

Display Performance Excellence

Flexible and Sleek Design for All Retail and Corporate Environments

BenQ Smart Signage series comes with a wide range of sizes, and an iron frame
that covers all sides of the signage, ensuring a sleek and robust design that can
provide a consistent look for retail and corporate spaces.

Flawless Display in Portrait and Landscape View

Unlike anything else available on the market, BenQ Smar t Signage displays

are built to ensure awless portrait and landscape view. This choice between
vertical and horizontal installation greatly increases exibility when operators are

designing and arranging their stores.

Reliable Operation

An amazing life of 30,000 hours translates to years of reliable display service and
industrial-class performance far more economical than consumer models. Built

with better cooling techniques reaching longer runtimes for at least 18 hours a

day that is safer.

4K2K UHD Unparalleled Clarity

An ultra-high denition resolution of 4K2K (3840 x 2160) offers not only the
most exquisite image details for an optimal viewing experience but also four

times more information and workspace than a 1080p full HD display, enhancing

your efciency and productivity.

Powerful Performance & Drive

The combination of 32GB system storage and 2GB RAM memory ensures
delivery of smooth, seamless display performance at all times, even while the
smart signage is multitasking between applications.

Easy to Install

Lightweight Design

Our smart signage displays can be easily mounted or rearranged to suit diverse
uses, which saves you plenty of costs and manpower on signage installation, and

eventually facilitates different display congurations in stores, ofces, and other

commercial establishments.

Slim & Stylish Design

A narrow bezel and slim design boasts a stylish outlook betting any in-store
environment, whether it’s a trendy café or a sophisticated boutique store.

Integrated X-Sign 2.0 Software with

Smart Signage Content Templates

X-Sign Designer

BenQ’s X-Sign 2.0 takes the hassle out of designing signage content. Included
with the Smart Signage displays, BenQ’s exclusive X-Sign software provides

content templates, making it easy for operators to quickly design and roll out new

promotional material. The templates also let operators add images, videos, and
scrolling text to their marketing materials. The long-size templates let operators
create marketing content easily while the ability to enrich materials with media
content will boost the store’s bottom line.

Instant Price Updates

Updating prices and other uctuating content is easy.
Operators just need to modify a centralized .csv le in the cloud.

Broadcast YouTube Live Streaming
across Multiple Displays

With X-Sign, operators can insert live YouTube broadcasts of
product launches on Smart Signage in real time, which makes
promoting new products instant and easy.

Centralized Remote Display Management

X-Sign’s intuitive interface makes it easy for operators to monitor and manage
all remote displays from a central, off-site location. With X-Sign, operators can
keep tabs on display performance in real-time and receive instant alerts about
any issues. Loaded with functionality, X-Sign also allows operators to see what
content is playing on each display, manage updates, restar t displays, and manage
screen on/off and volume settings.

QR Code Interaction and Analysis

X-Sign allows operators to embed QR Codes that, when scanned,
can offer customers the latest promotional information. X-Sign also
offers QR Code analysis to let operators see when and where
customers are interacting with content. This analysis can help

operators quickly adjust their offers to match customer interest.

Real Time Messages

X-Sign lets operators push real-time messages to the display
network to create instant excitement.

Hassle-Free Display Management

Device Info and Management

Remotely control your displays with DMS Cloud

via Internet. It’s an effective way to lower TCO

and energy consumption for your operation.

Install Android™ apps for a selection of displays through

our cloud server. DMS Cloud is designed to save you the

hassles of repetitive manual installation work.

Apps Management

More Features

DMS Local

DMS Local is a Device Info and Management software based on windows OS. For

users who would like to control your displays remotely via LAN, you can download

DMS Local software for your operation.

OTA

(Over-the-Air) Update

Upgrade the latest BenQ rmware for your

displays through our OTA Update suppor t

and keep them running smoothly at all times.

MDA (Multiple Display Administrator)

For users who would like to control your displays remotely via RS232, you can

download MDA software for your operation.

Dimension

ST4301K

ST5501K

13.9

13.913.9

13.0

558.3

13.0

969.9

1243.2

1215.4

14.8

155.6

13.0

13.9

13.0

69.6

31.8

10.8

84.8

45.8

9.8

179.2200.0

179.2

421.6

285.0

400.0

WALL MOUNT SCREW

400

WALL MOUNT SCREW
THREAD DEPTH: 4 - M6*28L

285.0

4 - M6*28L

421.6

157400157

714

10

199.1

2019

Android is a trademark of Google Inc. The Android robot is reproduced or modified
from work created and shared by Google and used according to terms described in the
Creative Commons 3.0 Attribution License.

7

Doc: DSP_IL430/IL490/IL550_DS_EN_201712

DSP_ST4301K_5501K_DS_EN_201905
