i
PROGRAMMING GUIDE
S302D
2D Imaging
Barcode Scanner
Programming Guide
Advanced imaging barcode scanner
i
PROGRAMMING GUIDE
Important Notice
No warranty of any kind is made in regard to this material, including, but not limited to,
implied warranties of merchantability or fitness for any particular purpose. We are not
liable for any errors contained herein nor for incidental or consequential damages in
connection with furnishing, performance or use of this material. We shall be under no
liability in respect of any defect arising from fair wear and tear, willful damage,
negligence, abnormal working conditions, failure to follow the instructions and warnings,
or misuse or alteration or repair of the products without written approval. No part of this
document may be reproduced, transmitted, stored in a retrieval system, transcribed, or
translated into any human or computer or other language in any form or by any means
electronic, mechanical, magnetic, optical, chemical, biological, manual or otherwise,
except for brief passages which may be quoted for purposes of scholastic or literary
review, without express written consent and authorization. We reserve the right to make
changes in product design without reservation and without notification. The material in
this guide is for information only and is subject to change without notice. All trademarks
mentioned herein, registered or otherwise, are the properties of their various, ill,
assorted owners.
General Handling Precautions
Do not dispose the scanner in fire.
Do not put the scanner directly in the sun or by any heat source.
Do not use or store the scanner in a very humid place.
Do not drop the scanner or allow it to collide violently with other objects.
Do not take the scanner apart without authorization
Guidance for Printing
This manual is in A5 size. Please double check your printer setting before printing it out.
When the barcodes are to be printed out for programming, the use of a high-resolution
laser printer is strongly suggested for the best scan result.
Copyright © 2016. All rights reserved.
Advanced imaging barcode scanner
ii
PROGRAMMING GUIDE
Table of Contents
Important Notice ..................................................................................................... i
General Handling Precautions ............................................................................................ i
Guidance for Printing .......................................................................................................... i
Settings and Programming ...................................................................................... 1
Programming Options ........................................................................................................ 1
Default Factory Device Settings ......................................................................................... 1
Interface Mode ....................................................................................................... 2
Interface Switch ................................................................................................................. 2
Baud Rate .......................................................................................................................... 3
Word Format: Parity, Data bits, Stop bits ........................................................................... 4
User Preferences ..................................................................................................... 6
System Settings .................................................................................................................. 6
Spanish Keyboard .............................................................................................................. 7
English Keyboard ............................................................................................................... 7
Beeper-Good Read ............................................................................................................. 8
Beeper Volume-Good Read ............................................................................................... 8
Beep During Good Decode ................................................................................................ 9
LED Illumination................................................................................................................. 9
LED-Good Read ................................................................................................................ 10
Number Of Beep-Good Read ........................................................................................... 10
Good Read Delay ............................................................................................................. 12
Same Code Delay ............................................................................................................. 13
Scan Mode ....................................................................................................................... 14
Manual Mode Timeout.................................................................................................... 14
Presentation Timeout ...................................................................................................... 14
Centering Windows ......................................................................................................... 15
Ship Image ....................................................................................................................... 16
No Read ........................................................................................................................... 16
Image Reverse ................................................................................................................. 16
Data Redundant ............................................................................................................... 17
Data Editing .......................................................................................................... 18
Prefix / Suffix ................................................................................................................... 18
Prefix Set Up Flow ............................................................................................................ 18
Suffix Set Up Flow ............................................................................................................ 19
Data Format ..................................................................................................................... 20
Advanced imaging barcode scanner
iii
PROGRAMMING GUIDE
Cap Locks ......................................................................................................................... 21
Symbologies.......................................................................................................... 22
Introduction ..................................................................................................................... 22
Message Length ............................................................................................................... 22
Codabar ................................................................................................................ 23
Codabar Enable/Disable .................................................................................................. 23
Codabar Stop/Start Characters ........................................................................................ 23
Codabar Check Characters ............................................................................................... 24
Codabar Message Length ................................................................................................ 24
Code 39 ................................................................................................................. 25
Code 39 Enable/Disable ................................................................................................... 25
Code 39 Full ASCII Conversion ......................................................................................... 25
Code 39 Append .............................................................................................................. 26
Code 39 Check Characters ............................................................................................... 26
Code 39 Start/Stop Characters ........................................................................................ 27
Code 32 Pharmaceutical .................................................................................................. 27
Code 39 Message Length ................................................................................................. 28
Trioptic ............................................................................................................................. 28
Interleaved 2 of 5 .................................................................................................. 29
Interleaved 2 of 5 Enable/Disable .................................................................................... 29
Interleaved 2 of 5 Check Characters ................................................................................ 30
Interleaved 2 of 5 Message Length .................................................................................. 30
NEC 25 .................................................................................................................. 31
NEC 25 Enable/Disable .................................................................................................... 31
NEC 25 Check Characters ................................................................................................. 32
Straight 2 of 5 Industrial ........................................................................................ 33
Straight 2 of 5 Industrial Enable/Disable ......................................................................... 33
Straight 2 of 5 Message Length ........................................................................................ 33
Matrix 2 of 5 ......................................................................................................... 34
Matrix 2 of 5 Enable/Disable ........................................................................................... 34
Matrix 2 of 5 Message Length ......................................................................................... 34
Code 11 ................................................................................................................. 35
Code 11 Enable/Disable ................................................................................................... 35
Code 11 Check Characters ............................................................................................... 35
Code 11 Message Length ................................................................................................. 36
Code 128 ............................................................................................................... 37
Advanced imaging barcode scanner
iv
PROGRAMMING GUIDE
Code 128 Enable/Disable ................................................................................................. 37
Code 128 Message Length ............................................................................................... 37
Code 93 ................................................................................................................. 38
Code 93 Enable/Disable ................................................................................................... 38
Code 93 Message Length ................................................................................................. 38
MSI ....................................................................................................................... 39
MSI Enable/Disable.......................................................................................................... 39
MSI Check Characters ...................................................................................................... 39
MSI Message Length ........................................................................................................ 40
Telepen ................................................................................................................. 41
Telepen Enable/Disable ................................................................................................... 41
Telepen Output ................................................................................................................ 41
Telepen Message Length ................................................................................................. 42
UPC/EAN/JAN ....................................................................................................... 43
UPC-A Enable/Disable...................................................................................................... 43
UPC-A Check Characters .................................................................................................. 43
UPC-A Number System .................................................................................................... 44
UPC-A 2 Digit ................................................................................................................... 44
UPC-A 5 Digit ................................................................................................................... 45
UPC-A Addenda Required ................................................................................................ 45
UPC-A Addenda Separator ............................................................................................... 46
UPC-E0 ............................................................................................................................. 46
UPC-E1 ............................................................................................................................. 47
UPC-E0 Expand ................................................................................................................ 47
UPC-E0 Check Digit .......................................................................................................... 48
UPC-E0 Number System .................................................................................................. 48
UPC-E0 Addenda 2 Digit .................................................................................................. 49
UPC-E0 Addenda 5 Digit .................................................................................................. 49
UPC-E0 Addenda Required .............................................................................................. 50
UPC-E0 Addenda Separator ............................................................................................. 50
EAN/JAN-13 ..................................................................................................................... 51
EAN/JAN-13 Check Digit .................................................................................................. 51
EAN/JAN-13 2 Check Digit Addenda ................................................................................ 52
EAN/JAN-13 5 Check Digit Addenda ................................................................................ 52
EAN/JAN-13 Addenda Required ....................................................................................... 53
EAN/JAN-13 Addenda Separator...................................................................................... 53
IBSN Translate .................................................................................................................. 54
EAN-8 ............................................................................................................................... 54
Advanced imaging barcode scanner
v
PROGRAMMING GUIDE
EAN-8 Check Digit ............................................................................................................ 55
EAN-8 Check Digit Addenda ............................................................................................. 55
EAN-8 2 Check Digit Addenda .......................................................................................... 56
EAN-8 5 Check Digit Addenda .......................................................................................... 56
EAN-8 Addenda Required ................................................................................................ 57
EAN-8 Addenda Separator ............................................................................................... 57
UPC-A/EAN-13 Extend Coupon Code ............................................................................... 58
EAN.UCC Emulation ......................................................................................................... 58
Postal Code ........................................................................................................... 59
China Postal Code ............................................................................................................ 59
China Postal Code Message Length ................................................................................. 60
Han Xin Code ................................................................................................................... 60
Han Xin Code Message Length ........................................................................................ 61
Korean Postal Code .......................................................................................................... 61
Korean Postal Code Message Length ............................................................................... 62
PostNet ............................................................................................................................ 62
PostNet Check Digit ......................................................................................................... 63
Planet Code ..................................................................................................................... 63
Planet Code Check Digit ................................................................................................... 64
British Post ....................................................................................................................... 64
Japanese Post .................................................................................................................. 65
Canadian Post .................................................................................................................. 65
Kix Post ............................................................................................................................ 66
Australian Post ................................................................................................................. 66
RSS (Reduced Space Symbology) ........................................................................... 67
RSS-14 .............................................................................................................................. 67
RSS-Limited Code ............................................................................................................. 68
RSS-Expanded Code ......................................................................................................... 69
RSS-Expanded Code Message Length .............................................................................. 69
2D Symbologies .................................................................................................... 70
PDF417 ............................................................................................................................ 70
PDF417 Message Length .................................................................................................. 70
Micro PDF417 .................................................................................................................. 71
Micro PDF417 Message Length ....................................................................................... 71
TLC39 ............................................................................................................................... 72
Codablock F ..................................................................................................................... 73
Codablock F Message Length ........................................................................................... 73
Aztec ................................................................................................................................ 74
Advanced imaging barcode scanner
vi
PROGRAMMING GUIDE
Aztec Message Length ..................................................................................................... 74
Maxicode ......................................................................................................................... 75
Maxicode Message Length .............................................................................................. 75
Data Matrix ...................................................................................................................... 76
Data Matrix Message Length ........................................................................................... 76
QR Code ........................................................................................................................... 77
QR Code Message Length ................................................................................................ 77
QR Code Advanced Data Setting ...................................................................................... 78
Maintenance ......................................................................................................... 79
Troubleshoot .................................................................................................................... 79
Appendix A ........................................................................................................... 80
Standard Default Parameters ........................................................................................... 80
Appendix B ........................................................................................................... 84
Code ID Table ................................................................................................................... 84
Appendix C ........................................................................................................... 85
Sample Barcodes ............................................................................................................. 85
Appendix D ........................................................................................................... 88
Numeric Barcodes ........................................................................................................... 88
Save ................................................................................................................................. 91
Discard ............................................................................................................................. 91
Appendix E ............................................................................................................ 92
Full ASCII Table ................................................................................................................. 92
Advanced imaging barcode scanner
1
PROGRAMMING GUIDE
User Preferences
Parameter
Default
Baud Rate
115200 BPS
Word Format
None, 8, 1
Illumination
On
LED-Good Read
On
Number of Beep-Good Read
1
Good Read Delay
200
Same Code Delay
500ms
Scan Mode
Manual Trigger
Manual Mode
30000ms
Presentation
500ms
Centering Windows
Off
Ship Image
JPG/BMP
No Read
Off
Image Reverse
Off
Data Redundant
Off
Settings and Programming
Scan selected barcodes in this manual to affect setup and programming of your handheld
imaging barcode scanner. Decoding options and interface protocols can be tailored to a
specific application. Setup parameters are stored in non-volatile memory in the scanner
and are retained even when power is off. Setup parameters change only when you reset
them.
You may need to hide adjacent code patches with your hand when scanning.
Programming Options
This section contains the following two divisions:
1. Default factory device settings.
2. Supported symbologies.
Default Factory Device Settings
Advanced imaging barcode scanner
2
PROGRAMMING GUIDE
USB HID
(Default)
USB Virtual COM
Interface Mode
Interface Switch
The S302D imaging barcode scanner supports USB virtual COM, USB-HID and RS232. The
USB cable supports both USB virtual COM and USB-HID modes. Please install the virtual
COM port driver before using USB Virtual COM.
To use USB Virtual COM for the first time, scan the USB Virtual COM
barcode below and then install the Virtual COM driver.
To switch from USB Virtual Com to USB-HID mode after the virtual COM
driver is installed, scan the USB HID barcode below.
To switch from USB Virtual Com to USB-HID mode if the virtual COM driver
is not installed:
1. Unplug USB cable from computer.
2. Press and hold the trigger while plugging USB cable to computer.
3. Scan the USB HID barcode below.
To switch to RS232, change to RS232 interface cable, then scan barcodes on
next few pages to set up communication protocols.
Advanced imaging barcode scanner
3
PROGRAMMING GUIDE
1200BPS
2400BPS
4800BPS
9600BPS
19200BPS
38400BPS
Baud Rate
Baud rate is the number of bits of data transmitted per second. Set the imager's baud
rate to match the baud rate setting of the host device. Otherwise, data may not reach
the host device or may reach it in distorted form.
Advanced imaging barcode scanner
4
PROGRAMMING GUIDE
57600BPS
115200BPS
(Default)
None,7,1
None,7,2
None,8,1
(Default)
Word Format: Parity, Data bits, Stop bits
A parity check bit is the most significant bit of each ASCII coded character. Select the
parity type according to host device requirements. Parity: checks character bit patterns
for validity; Data bits: sets the word length; Stop bits: sets the stop bits.
Advanced imaging barcode scanner
5
PROGRAMMING GUIDE
Even 7,1
Even 7,2
Even 8,1
Odd 7, 1
Odd 7, 2
Odd 8, 1
Advanced imaging barcode scanner
6
PROGRAMMING GUIDE
User Preferences
System Settings
Scan this barcode to return all parameters to the default values.
Set All Defaults
Scan this barcode to enable AUX Scanner.
Aux Scanner Enable
Scan this barcode to show scanner version.
Show Version
Advanced imaging barcode scanner
7
PROGRAMMING GUIDE
Enable Spanish keyboard
Code 128 Code Page: Binary
Code 39 Code Page: Binary
Enable English keyboard
Spanish Keyboard
To enable Spanish keyboard layout in USB HID interface, please scan all 3 barcodes below
to complete the setting.
English Keyboard
To return to English keyboard from Spanish keyboard scan the following barcode.
Advanced imaging barcode scanner
8
PROGRAMMING GUIDE
On
Off
Off
Low Volume
Medium Volume
High Volume
Beeper-Good Read
To enable or disable beeper, scan the following barcodes.
Beeper Volume-Good Read
To select a beeper volume, scan the Low Volume, Medium Volume, or High Volume
barcode.
Advanced imaging barcode scanner
9
PROGRAMMING GUIDE
Normal
Short
On
(Default)
Off
Beep During Good Decode
Scan a barcode below to select the duration of the beep signal after a good decode.
LED Illumination
To enable or disable LED illumination, scan the following barcodes.
Advanced imaging barcode scanner
10
PROGRAMMING GUIDE
On
(Default)
Off
1
(Default)
2
3
LED-Good Read
To enable or disable LED indicator after a good read, scan the following barcodes.
Number Of Beep-Good Read
Scan a barcode below to select the number of the beep signal to sound after a good
decode.
Advanced imaging barcode scanner
11
PROGRAMMING GUIDE
4
5
6
7
8
Advanced imaging barcode scanner
12
PROGRAMMING GUIDE
No Delay
200ms
(Default)
500ms
2000ms
*Specified
Good Read Delay
Scan a barcode below to set the minimum amount of time before the imager can read
another barcode after a good read.
*To set your own length for the good read delay, scan the “Specified” barcode, then set
the delay by scanning digits from the Appendix, then scan “Save”.
Advanced imaging barcode scanner
13
PROGRAMMING GUIDE
No Delay
500ms
(Default)
2000ms
Same Code Delay
Scan a barcode below to set the minimum amount of time before the imager can read
the same barcode a second time.
Advanced imaging barcode scanner
14
PROGRAMMING GUIDE
Manual Trigger Mode
(Default)
Auto Scan Mode
Scan Mode
Scan a barcode below to set the imager to trigger manually or automatic scanning until a
barcode has been read.
Manual Mode Timeout
To a set timeout for the imager’s trigger when using Manual Trigger, scan the following
“Timeout” barcode, then set the delay by scanning digits from the Appendix, then scan
“Save” (Default: 30,000).
Timeout (0-300,000ms)
Presentation Timeout
This option is used in Presentation mode to prevent multiple reads of a symbol left in the
device’s field of view. To set the minimum amount of time before the imager can read
the same barcode a second time, scan the following “Timeout” barcode then set the
delay by scanning digits from the Appendix, then scan “Save” (Default: 500).
Advanced imaging barcode scanner
Reread Timeout (0-300,000ms)
15
PROGRAMMING GUIDE
On
Off
(Default)
Left of centering window 40%
Right of centering window 60%
Top of centering window 40%
Bottom of centering window 60%
Centering Windows
To change the field of view of your imager, scan “On” to enable the feature, and then
scan one of the following barcodes to change the top, bottom, left, or right of the
centering window.
Advanced imaging barcode scanner
16
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
Ship Image
To ship the image stored in the imager memory, scan the follow barcode.
JPG/BMP
No Read
Enable this function to transmit a No Read message when a code can not be read.
Image Reverse
Enable this function to allow the imager to read barcodes that are inverted.
Advanced imaging barcode scanner
17
PROGRAMMING GUIDE
Data Redundant Check = Off
(Default)
Data Redundant Check = 1
Data Redundant Check = 2
Data Redundant Check = 3
Data Redundant
This function sets the imager to read the barcode multiple times before accepting data.
Advanced imaging barcode scanner
18
PROGRAMMING GUIDE
Prefix
Suffix
Data Editing
Prefix / Suffix
Prefix and Suffix are additional characters that can be sent before and after the scanned
data.
To set up Prefix/Suffix:
Prefix Set Up Flow
Ex. If we wish to add “3” as prefix for all barcode type, then follow procedure as below,
Scanning [prefix] to enter setup. Then we select barcode by scanning code ID (ID table in
the back) of all barcode which is [9] [9], then we scan [3] [3] as 3 of ASCII HEX. At the end,
we scan [Save] to completed setup. So for full process, you scan [prefix] -> [9] [9] -> [3] [3]
-> [Save].
Note: When adding a backslash (“\”or 5 C in Hex ID), please scan 5 C twice (5C5C): once
to create the leading backslash and once to create the backlash itself.
Advanced imaging barcode scanner
19
PROGRAMMING GUIDE
Suffix Set Up Flow
Ex. If we wish to add “36” as suffix for all barcode type, then follow procedure as below,
Scanning [suffix] to enter setup. Then we select barcode by scanning code ID of all
barcode which is [9] [9], then we scan [3] [3] as 3 of ASCII HEX and [3] [6] as 6. Before we
save, we scan command to setup terminator. If we wish to have Insert (01 from ASCII) &
Enter (0A from ASCII) as terminator, we scan [0] [1] [0] [A]. To complete setup, we scan
[Save]. So for full process, you scan [Suffix] -> [9] [9] -> [3] [3] -> [3] [6] -> [0] [1] -> [0] [A]
-> [Save].
Note: For Suffix setup, terminator set up is required within suffix set up. If terminator is
not set before save, terminator will automatically set to null.
Advanced imaging barcode scanner
20
PROGRAMMING GUIDE
Data followed by <Enter>
(Default)
No message after data
Data followed by <Enter>
+ new line
Data followed by new line
Data followed by TAB
Data Format
To change the output format, scan the following barcodes.
Advanced imaging barcode scanner
21
PROGRAMMING GUIDE
Cap Locks On
Cap Locks Off
Cap Locks
To change the capital lock preferences, scan the following barcodes.
Advanced imaging barcode scanner
22
PROGRAMMING GUIDE
Symbologies
Introduction
This chapter describes symbology features and provides the programming barcodes for
selecting these features.
The device is shipped with the settings shown in the Symbology Default Table. If the
default values suit requirements, programming is not necessary.
There are two ways to change a parameter value:
Scan the appropriate barcodes in this guide. These new values replace the
standard default values in memory.
For serial hosts, send a “parameter send” command from the host system.
For complete descriptions and examples of each serial programming
command, refer to the corresponding programming barcode in this manual.
Note: Most computer monitors allow scanning the barcodes directly on the screen.
When scanning from the screen, be sure to set the document magnification to a level
where the barcode can be seen clearly and bars and/or spaces are not merging.
Message Length
The length of a code refers to the number of characters (i.e., human readable characters),
including check digit(s) the code contains.
To set the length of a barcode symbology:
1. Scan the “Minimum” or “Maximum” barcode to enter program mode.
2. Scan the digit(s) from the ASCII table in Appendix.
3. Scan “Save” to save the change.
Note: When setting lengths for different barcode types by scanning single digit numbers,
single digit numbers must always be preceded by a leading zero.
Advanced imaging barcode scanner
23
PROGRAMMING GUIDE
Default
On
(Default)
Off
Don’t Transmit
(Default)
Transmit
Codabar
Codabar Enable/Disable
To set Codabar to its default settings, scan Default; to enable or disable Codabar, scan On
or Off.
Codabar Stop/Start Characters
Stop/Start Characters set the leading and trailing ends of the barcode.
Advanced imaging barcode scanner
24
PROGRAMMING GUIDE
No Check Character
(Default)
Validate But Don’t Transmit
Validate And Transmit
Maximum
(Default: 60)
Minimum
(Default: 4)
Codabar Check Characters
Scan a barcode below to set the Codabar check character preferences.
Codabar Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
25
PROGRAMMING GUIDE
Default
On
(Default)
Off
Off
(Default)
On
Code 39
Code 39 Enable/Disable
To set Code 39 to its default settings, scan Default; to enable or disable Code 39, scan On
or Off.
Code 39 Full ASCII Conversion
Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII
character set. Scan the appropriate barcode below to enable or disable it.
Advanced imaging barcode scanner
26
PROGRAMMING GUIDE
On
Off
(Default)
No Check Character
(Default)
Validate But Don’t Transmit
Validate And Transmit
Code 39 Append
To set the imager to append Code 39 data before transmitting to the host, scan the
appropriate barcode below.
Code 39 Check Characters
Scan a barcode below to set the Code 39 check character preferences.
Advanced imaging barcode scanner
27
PROGRAMMING GUIDE
Transmit
Don’t Transmit
(Default)
On
Off
(Default)
Code 39 Start/Stop Characters
Start/Stop Characters set the leading and trailing ends of the barcode.
Code 32 Pharmaceutical
To enable/ disable Code 39 Pharmaceutical, scan the appropriate barcode below.
Advanced imaging barcode scanner
28
PROGRAMMING GUIDE
Minimum
(Default: 0)
Maximum
(Default: 48)
On
Off
(Default)
Code 39 Message Length
Please see Message Length on setting the message length.
Trioptic
To enable/ disable Trioptic code, scan the appropriate barcode below.
Advanced imaging barcode scanner
29
PROGRAMMING GUIDE
Default
On
(Default)
Off
Interleaved 2 of 5
Interleaved 2 of 5 Enable/Disable
To set Interleaved 2 of 5 to its default settings, scan Default; to enable or disable
Interleaved 2 of 5, scan On or Off.
Advanced imaging barcode scanner
30
PROGRAMMING GUIDE
No Check Character
(Default)
Validate But Don’t Transmit
Validate And Transmit
Maximum
(Default: 80)
Minimum
(Default: 4)
Interleaved 2 of 5 Check Characters
Scan a barcode below to set the Interleaved 2 of 5 check character preferences.
Interleaved 2 of 5 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
31
PROGRAMMING GUIDE
Default
On
(Default)
Off
NEC 25
NEC 25 Enable/Disable
To set NEC 25 to its default settings, scan Default; to enable or disable NEC 25, scan On
or Off.
Advanced imaging barcode scanner
32
PROGRAMMING GUIDE
No Check Character
(Default)
Validate But Don’t Transmit
Validate And Transmit
NEC 25 Check Characters
Scan a barcode below to set the NEC 25 check character preferences.
Advanced imaging barcode scanner
33
PROGRAMMING GUIDE
Default
On
Off
(Default)
Maximum
(Default: 48)
Minimum
(Default: 4)
Straight 2 of 5 Industrial
Straight 2 of 5 Industrial Enable/Disable
To set Straight 2 of 5 Industrial to its default settings, scan Default; to enable or disable
Straight 2 of 5 Industrial, scan On or Off.
Straight 2 of 5 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
34
PROGRAMMING GUIDE
Default
On
Off
(Default)
Maximum
(Default: 80)
Minimum
(Default: 4)
Matrix 2 of 5
Matrix 2 of 5 Enable/Disable
To set Matrix 2 of 5 to its default settings, scan Default; to enable or disable Matrix 2 of 5,
scan On or Off.
Matrix 2 of 5 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
35
PROGRAMMING GUIDE
Default
On
Off
(Default)
2 Check Digit
(Default)
1 Check Digit
Code 11
Code 11 Enable/Disable
To set Code 11 to its default settings, scan Default; to enable or disable Code 11, scan On
or Off.
Code 11 Check Characters
Scan a barcode below to set the Code 11 check character preferences.
Advanced imaging barcode scanner
36
PROGRAMMING GUIDE
Minimum
(Default: 4)
Maximum
(Default: 80)
Code 11 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
37
PROGRAMMING GUIDE
Default
On
(Default)
Off
Maximum
(Default: 80)
Minimum
(Default: 0)
Code 128
Code 128 Enable/Disable
To set Code 128 to its default settings, scan Default; to enable or disable Code 128, scan
On or Off.
Code 128 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
38
PROGRAMMING GUIDE
Default
On
(Default)
Off
Maximum
(Default: 80)
Minimum
(Default: 0)
Code 93
Code 93 Enable/Disable
To set Code 93 to its default settings, scan Default; to enable or disable Code 93, scan On
or Off.
Code 93 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
39
PROGRAMMING GUIDE
Default
On
Off
(Default)
Validate Type 10, Transmit
Validate Type 10, Don’t Transmit
(Default)
MSI
MSI Enable/Disable
To set MSI to its default settings, scan Default; to enable or disable MSI, scan On or Off.
MSI Check Characters
Scan a barcode below to set the MSI check character preferences.
Advanced imaging barcode scanner
40
PROGRAMMING GUIDE
Minimum
(Default: 4)
Maximum
(Default: 48)
MSI Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
41
PROGRAMMING GUIDE
Default
On
Off
(Default)
Original Output
AIM Output
(Default)
Telepen
Telepen Enable/Disable
To set Telepen to its default settings, scan Default; to enable or disable Telepen, scan On
or Off.
Telepen Output
Scan a barcode below to set the Telepen Output preferences.
Advanced imaging barcode scanner
42
PROGRAMMING GUIDE
Minimum
(Default: 1)
Maximum
(Default: 60)
Telepen Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
43
PROGRAMMING GUIDE
Default
On
(Default)
Off
Off
On
(Default)
UPC/EAN/JAN
UPC-A Enable/Disable
To set UPC-A to its default settings, scan Default; to enable or disable UPC-A, scan On or
Off.
UPC-A Check Characters
Scan a barcode below to set the UPC-A check character preferences.
Advanced imaging barcode scanner
44
PROGRAMMING GUIDE
On
(Default)
Off
On
Off
(Default)
UPC-A Number System
Scan a barcode below to set the UPC-A Number System preferences.
UPC-A 2 Digit
Scan a barcode below to set the UPC-A 2 Digit preferences.
Advanced imaging barcode scanner
45
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
UPC-A 5 Digit
Scan a barcode below to set the UPC-A 5 Digit preferences.
UPC-A Addenda Required
Scan a barcode below to set the UPC-A Addenda Required preferences.
Advanced imaging barcode scanner
46
PROGRAMMING GUIDE
On
(Default)
Off
Default
On
(Default)
Off
UPC-A Addenda Separator
Scan a barcode below to set the UPC-A Addenda Separator preferences.
UPC-E0
To set UPC-E0 to its default settings, scan Default; to enable or disable UPC-E0, scan On
or Off.
Advanced imaging barcode scanner
47
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
UPC-E1
Scan a barcode below to set the UPC-E1 preferences.
UPC-E0 Expand
Scan a barcode below to set the UPC-E0 Expand preferences.
Advanced imaging barcode scanner
48
PROGRAMMING GUIDE
On
(Default)
Off
On
(Default)
Off
UPC-E0 Check Digit
Scan a barcode below to set the UPC-E0 Check Digit preferences.
UPC-E0 Number System
Scan a barcode below to set the UPC-E0 Number System preferences.
Advanced imaging barcode scanner
49
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
UPC-E0 Addenda 2 Digit
Scan a barcode below to set the UPC-E0 Addenda 2 Digit preferences.
UPC-E0 Addenda 5 Digit
Scan a barcode below to set the UPC-E0 Addenda 5 Digit preferences.
Advanced imaging barcode scanner
50
PROGRAMMING GUIDE
Not Required
(Default)
Required
On
(Default)
Off
UPC-E0 Addenda Required
Scan a barcode below to set the UPC-A Addenda Required preferences.
UPC-E0 Addenda Separator
Scan a barcode below to set the UPC-A Addenda Separator preferences.
Advanced imaging barcode scanner
51
PROGRAMMING GUIDE
Default
On
(Default)
Off
Off
On
(Default)
EAN/JAN-13
To set EAN/JAN-13 to its default settings, scan Default; to enable or disable EAN/JAN-13,
scan On or Off.
EAN/JAN-13 Check Digit
Scan a barcode below to set the EAN/JAN-13 Check Digit preferences.
Advanced imaging barcode scanner
52
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
EAN/JAN-13 2 Check Digit Addenda
Scan a barcode below to set the EAN/JAN-13 2 Check Digit Addenda preferences.
EAN/JAN-13 5 Check Digit Addenda
Scan a barcode below to set the EAN/JAN-13 5 Check Digit Addenda preferences.
Advanced imaging barcode scanner
53
PROGRAMMING GUIDE
Not Required
(Default)
Required
On
(Default)
Off
EAN/JAN-13 Addenda Required
Scan a barcode below to set the UPC-A Addenda Required preferences.
EAN/JAN-13 Addenda Separator
Scan a barcode below to set the UPC-A Addenda Separator preferences.
Advanced imaging barcode scanner
54
PROGRAMMING GUIDE
On
Off
(Default)
Default
On
(Default)
Off
IBSN Translate
Scan a barcode below to set the IBSN Translate preferences.
EAN-8
To set EAN -8 to its default settings, scan Default; to enable or disable EAN-8, scan On or
Off.
Advanced imaging barcode scanner
55
PROGRAMMING GUIDE
On
(Default)
Off
On
Off
(Default)
EAN-8 Check Digit
Scan a barcode below to set the EAN-8 Check Digit preferences.
EAN-8 Check Digit Addenda
Scan a barcode below to set the EAN-8 Check Digit Addenda preferences.
Advanced imaging barcode scanner
56
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
EAN-8 2 Check Digit Addenda
Scan a barcode below to set the EAN-8 2Check Digit Addenda preferences.
EAN-8 5 Check Digit Addenda
Scan a barcode below to set the EAN-8 5 Check Digit Addenda preferences.
Advanced imaging barcode scanner
57
PROGRAMMING GUIDE
Not Required
(Default)
Required
On
(Default)
Off
EAN-8 Addenda Required
Scan a barcode below to set the EAN-8 Addenda Required preferences.
EAN-8 Addenda Separator
Scan a barcode below to set the EAN-8 Addenda Separator preferences.
Advanced imaging barcode scanner
58
PROGRAMMING GUIDE
On
Off
(Default)
Off
(Default)
EAN.UCC-128 Emulation
RSS. Emulation
UPC-A/EAN-13 Extend Coupon Code
Scan a barcode below to set the UPC-A/EAN-13 Extend Coupon Code preferences.
EAN.UCC Emulation
Scan a barcode below to set the EAN.UCC Emulation preferences.
Advanced imaging barcode scanner
59
PROGRAMMING GUIDE
Default
On
Off
(Default)
Postal Code
Note: For best performance when reading a postal code, please enable only one postal
symbology and disable the rest.
To enable or disable a postal code, please scan the following barcode first to enter
programming mode, then scan the On or Off barcode for your postal code.
Postal Code
China Postal Code
To set China Postal Code to its default settings, scan Default; to enable or disable China
Postal Code, scan On or Off.
Advanced imaging barcode scanner
60
PROGRAMMING GUIDE
Minimum
(Default: 4)
Maximum
(Default: 80)
Default
On
Off
(Default)
China Postal Code Message Length
Please see Message Length on setting the message length.
Han Xin Code
To set Han Xin Code to its default settings, scan Default; to enable or disable Han Xin
Code, scan On or Off.
Advanced imaging barcode scanner
61
PROGRAMMING GUIDE
Minimum
(Default: 1)
Maximum
(Default: 7873)
Default
On
Off
(Default)
Han Xin Code Message Length
Please see Message Length on setting the message length.
Korean Postal Code
To set Korean Postal Code to its default settings, scan Default; to enable or disable
Korean Postal Code, scan On or Off.
Advanced imaging barcode scanner
62
PROGRAMMING GUIDE
Minimum
(Default: 4)
Maximum
(Default: 48)
On
Off
(Default)
Korean Postal Code Message Length
Please see Message Length on setting the message length.
PostNet
Scan a barcode below to enable or disable PostNet.
Advanced imaging barcode scanner
63
PROGRAMMING GUIDE
Not Transmit
(Default)
Transmit
On
Off
(Default)
PostNet Check Digit
Scan a barcode below to set the PostNet Check Digit preferences.
Planet Code
Scan a barcode below to enable or disable Planet Code.
Advanced imaging barcode scanner
64
PROGRAMMING GUIDE
Don’t Transmit
(Default)
Transmit
On
Off
(Default)
Planet Code Check Digit
Scan a barcode below to set the Planet Code Check Digit preferences.
British Post
Scan a barcode below to enable or disable British Post code.
Advanced imaging barcode scanner
65
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
Japanese Post
Scan a barcode below to enable or disable Japanese Post code.
Canadian Post
Scan a barcode below to enable or disable Canadian Post code.
Advanced imaging barcode scanner
66
PROGRAMMING GUIDE
On
Off
(Default)
On
Off
(Default)
Kix Post
Scan a barcode below to enable or disable Kix Post code.
Australian Post
Scan a barcode below to enable or disable Australian Post code.
Advanced imaging barcode scanner
67
PROGRAMMING GUIDE
Default
On
(Default)
Off
RSS (Reduced Space Symbology)
The variants of RSS are RSS 14, RSS Expanded, and RSS Limited. The limited and
expanded versions have stacked variants. Scan the appropriate barcode below to enable
or disable each variant of RSS.
RSS-14
To set RSS-14 to its default settings, scan Default; to enable or disable RSS-14, scan On or
Off.
Advanced imaging barcode scanner
68
PROGRAMMING GUIDE
Default
On
(Default)
Off
RSS-Limited Code
To set RSS-Limited Code to its default settings, scan Default; to enable or disable RSSLimited, scan On or Off.
Advanced imaging barcode scanner
69
PROGRAMMING GUIDE
Default
On
(Default)
Off
Maximum
Minimum
RSS-Expanded Code
To set RSS-Expanded Code to its default settings, scan Default; to enable or disable RSSExpanded, scan On or Off.
RSS-Expanded Code Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
70
PROGRAMMING GUIDE
Default
On
(Default)
Off
Maximum
(Default: 2750)
Minimum
(Default: 1)
2D Symbologies
PDF417
To set PDF417 to its default settings, scan Default; to enable or disable PDF417, scan On
or Off.
PDF417 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
71
PROGRAMMING GUIDE
Default
On
Off
(Default)
Maximum
(Default: 366)
Minimum
(Default: 1)
Micro PDF417
To set Micro PDF417 to its default settings, scan Default; to enable or disable Micro
PDF417, scan On or Off.
Micro PDF417 Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
72
PROGRAMMING GUIDE
On
Off
(Default)
TLC39
Scan a barcode below to enable or disable TLC39.
Advanced imaging barcode scanner
73
PROGRAMMING GUIDE
Default
On
Off
(Default)
Maximum
(Default: 2048)
Minimum
(Default: 1)
Codablock F
To set Codablock F to its default settings, scan Default; to enable or disable Codablock F,
scan On or Off.
Codablock F Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
74
PROGRAMMING GUIDE
Default
On
(Default)
Off
Maximum
(Default: 3832)
Minimum
(Default: 1)
Aztec
To set Aztec to its default settings, scan Default; to enable or disable Aztec, scan On or
Off.
Aztec Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
75
PROGRAMMING GUIDE
Default
On
Off
Maximum
(Default: 150)
Minimum
(Default: 1)
Maxicode
To set Maxicode to its default settings, scan Default; to enable or disable Maxicode, scan
On or Off.
Maxicode Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
76
PROGRAMMING GUIDE
Default
On
(Default)
Off
Maximum
(Default: 3116)
Minimum
(Default: 1)
Data Matrix
To set Data Matrix to its default settings, scan Default; to enable or disable Data Matrix,
scan On or Off.
Data Matrix Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
77
PROGRAMMING GUIDE
Default
On
(Default)
Off
Maximum
(Default: 7089)
Minimum
(Default: 1)
QR Code
To set QR Code to its default settings, scan Default; to enable or disable QR Code, scan
On or Off.
QR Code Message Length
Please see Message Length on setting the message length.
Advanced imaging barcode scanner
78
PROGRAMMING GUIDE
Send $
QR Code Advanced Data Setting
To change the GS1 Send Keystroke for FNC1 from default [F8] to "$", scan barcode below.
Advanced imaging barcode scanner
79
PROGRAMMING GUIDE
USB mode to RS232 mode
USB mode to USB Virtual COM
RS232 to USB mode
Default Multi-interfaces
Mode already cover both
USB & RS-232 interfaces
No power, (hold the trigger, re-plug
USB cable, power on to scan mode
switch barcode commands and
working properly)
Default Multi-interfaces
Mode already cover both
USB & RS-232 interfaces
Maintenance
Cleaning the scan window is the only maintenance required. A dirty window may affect
scanning accuracy.
Never use any abrasive material or solvents on the window. Do not spray water or other
cleaning liquids directly onto the window.
Remove dirt by wiping gently with a damp cloth or tissue moistened with water and/or
ammonia.
Troubleshoot
Follow the table below for ways to switch interface when the cable is missing.
Advanced imaging barcode scanner
80
PROGRAMMING GUIDE
Symbology
Default
Codabar
Enable
Code 39
Enable
Code 39 Full ASCII
Disable
Code 39 Append
Disable
Code 39 Check Char
No check char
Code 39 start/stop char
Don’t transmit
Code 32 Pharmaceutical
Disable
Code 39 Message Length
0~48
Interleaved 2 of 5
Enable
Interleaved 2 of 5 Check Char
No check char
Interleaved 2 of 5 Message
Length
4~80
NEC 25
Enable
NEC 25 Check Char
No check char
Straight 2 of 5 Industrial
Disable
Straight 2 of 5 Industrial
Message
4~48
Straight 2 of 5 Industrial IATA
Disable
Straight 2 of 5 Industrial IATA
Message Length
4~48
Matrix 2 of 5
Disable
Matrix 2 of 5 Message Length
4~80
Code 11
Disable
Code 11 Message Length
4~80
Code 11 Check Char
2 check digits
Code 128
Enable
Appendix A
Standard Default Parameters
Advanced imaging barcode scanner
81
PROGRAMMING GUIDE
Code 128 Message Length
0~80
Code 93
Enable
Code 93 Message Length
0~80
MSI
Disable
MSI Message Length
4~48
MSI Check Char
Validate Type 10,
Don’t Transmit
Telepen
Disable
Telepen Output
AIM output
Telepen Message Length
1~60
UPC-A
Enable
UPC-A Check char
Enable
UPC-A Number System
Enable
UPC-A 2 digit
Disable
UPC-A 5 digit
Disable
UPC-A Addenda Required
Disable
UPC-A Addenda Separator
Enable
UPC-E0
Enable
UPC-E1
Disable
UPC-E0 Expand
Disable
UPC-E0 Check digit
Enable
UPC-E0 Number System
Enable
UPC-E0 Addenda 2 digit
Disable
UPC-E0 Addenda 5 digit
Disable
UPC-E0 Addenda Required
Not required
UPC-E0 Addenda Separator
Enable
EAN/JAN-13
Enable
EAN/JAN-13 Check Digit
Enable
Advanced imaging barcode scanner
82
PROGRAMMING GUIDE
EAN/JAN-13 2 Check Digit
Addenda
Disable
EAN/JAN-13 5 Check Digit
Addenda
Disable
EAN/JAN-13 Addenda
Required
Not required
EAN/JAN-13 Addenda
Separator
Enable
IBSN Translate
Disable
EAN-8
Enable
EAN-8 Check Digit
Enable
EAN-8 2 Check Digit Addenda
Disable
EAN-8 5 Check Digit Addenda
Disable
EAN-8 Addenda Required
Not required
EAN-8 Addenda Separator
Enable
UPC-A/EAN-13 Extend
Coupon Code
Disable
EAN.UCC Emulation
Disable
China Postal Code
Disable
China Postal Code Message
Length
4~80
RSS-14
Enable
RSS-Limited Code
Enable
RSS-Expanded Code
Enable
RSS-Expanded Code Message
Length
4~74
Trioptic Code
Disable
PDF417
Enable
PDF417 Message Length
1~2750
Micro PDF417
Disable
Micro PDF417 Message
Length
1~366
TLC39
Disable
Advanced imaging barcode scanner
83
PROGRAMMING GUIDE
Codablock F
Disable
Codablock F Message Length
1~2048
Aztec
Enable
Aztec Message Length
1~3832
Maxicode
Enable
Maxicode Message Length
1~150
Data Matrix
Enable
Data Matrix Message Length
1~3116
QR
Enable
QR Message Length
1~7089
Han Xin Code
Disable
Han Xin CodeMessage Length
1~7873
Korean Postal Code
Disable
Korean Postal Code Message
Length
4~48
PostNet
Disable
PostNet Check Digit
Don’t transmit
Planet Code
Disable
Planet Code Check Digit
Don’t transmit
British Post
Disable
Japanese Post
Disable
Canadian Post
Disable
Kix Post
Disable
Austrailian Post
Disable
Advanced imaging barcode scanner
84
PROGRAMMING GUIDE
Symbology
Code ID
Code ID in HEX
Code 128 j 6A
GS1-128(UCC/EAN-128)
j
6A
AIM-128 f 66
EAN-8 d 64
EAN-13 d 64
ISSN n 6E
ISBN B 42
UPC-E c 63
UPC-A c 63
Interleaved 2 of 5
e
65
ITF-6 e 65
ITF-14 e 65
Matrix 2 of 5
v
76
Industrial 2 of 5
D
44
Standard 2 of 5
s
73
Code 39 b 62
Codabar a 61
Code 93 i 69
Code 11 H 48
GS1 Databar
R
52
PDF417 r 72
QR Code Q 51
Data Matrix
u
75
All 99
Appendix B
Code ID Table
Advanced imaging barcode scanner
85
PROGRAMMING GUIDE
Canada Post 4-State
01,K1A0B1,7010,
Japan Post 4-State
80342716666
US POSTNET
8034271888
Australian Post
8034271999
Dutch Post - Royal TPG Post KIX 4-State
1231FZ13XHS
USPS PLANET Barcode
4012345235636
British Royal Mail 4-State BPO
1234567895
Appendix C
Sample Barcodes
Advanced imaging barcode scanner
86
PROGRAMMING GUIDE
Infomail Mail 4-State
Sweden Post 4-State
China Post
Advanced imaging barcode scanner
87
PROGRAMMING GUIDE
USPS 4-state (Intelligent Mail)
Barcode ID.........82
Service Type ID....152
Mailer ID..........568794
Serial Number......748970563
ZIP Code...........12789600178
Barcode ID.........00
Service Type ID....311
Mailer ID..........000479
Serial Number......612518080
ZIP Code...........20724170703
Barcode ID.........20
Service Type ID....301
Mailer ID..........901212001
Serial Number......311323
ZIP Code...........20724170703
Advanced imaging barcode scanner
88
PROGRAMMING GUIDE
0
1
2
3
4
Appendix D
Numeric Barcodes
For parameters requiring specific numeric values, scan the appropriately numbered
barcode(s).
Advanced imaging barcode scanner
89
PROGRAMMING GUIDE
5
6
7
8
9
A
Advanced imaging barcode scanner
90
PROGRAMMING GUIDE
B
C
D
E
F
Advanced imaging barcode scanner
91
PROGRAMMING GUIDE
Save
To save the setting, scan the barcode below.
Save
Discard
To correct an error or change a selection, scan the barcode below.
Discard
Advanced imaging barcode scanner
92
PROGRAMMING GUIDE
ASCII
Hexacode
ASCII
Hexacode
Full ASCII ---NUL
00
Full ASCII ---SI
Function key-----“Shift”
0F
Full ASCII ---SOH
Function key-----“Ins”
01
Full ASCII ---DLE
Function key-----“5(num)”
10
Full ASCII ---STX
Function key-----“Del”
02
Full ASCII ---DC1
Function key-----“F1”
11
Full ASCII ---ETX
Function key-----“Home”
03
Full ASCII ---DC2
Function key-----“F2”
12
Full ASCII ---EOT
Function key-----“End”
04
Full ASCII ---DC3
Function key-----“F3”
13
Full ASCII ---ENQ
Function key-----“Up arrow”
05
Full ASCII ---DC4
Function key-----“F4”
14
Full ASCII ---ACK
Function key-----“Down arrow”
06
Full ASCII ---NAK
Function key-----“F5”
15
Full ASCII ---BEL
Function key-----“Left arrow”
07
Full ASCII ---SYN
Function key-----“F6”
16
Full ASCII ---BS
Function key-----“Backspace”
08
Full ASCII ---ETB
Function key-----“F7”
17
Full ASCII ---HT
Function key-----“TAB”
09
Full ASCII ---CAN
Function key-----“F8”
18
Full ASCII ---LF
Function key-----“Enter (alpha
numeric)”
0A
Full ASCII ---EN
Function key-----“F9”
19
Full ASCII ---VT
Function key-----“right arrow”
0B
Full ASCII ---SUB
Function key-----“F10”
1A
Full ASCII ---FF
Function key-----“PgUp”
0C
Full ASCII ---ESC
Function key-----“F11”
1B
Full ASCII ---CR
Function key-----“Enetr(num.)”
0D
Full ASCII ---FS
Function key-----“F12”
1C
Full ASCII ---SO
Function key-----“PgDn”
0E
Full ASCII ---GS
Function key-----“ESC”
1D
Appendix E
Full ASCII Table
Advanced imaging barcode scanner
93
PROGRAMMING GUIDE
Full ASCII ---RS
Function key-----“CTL(L)”
1E
Full ASCII ----
2D
Full ASCII ---US
Function key-----“ALT(L)”
1F
Full ASCII ---.
2E
Full ASCII ---SP
20
Full ASCII ---/
2F
Full ASCII ---!
21
Full ASCII ---0
30
Full ASCII ---“
22
Full ASCII ---1
31
Full ASCII ---#
23
Full ASCII ---2
32
Full ASCII ---$
24
Full ASCII ---3
33
Full ASCII ---%
25
Full ASCII ---4
34
Full ASCII ---&
26
Full ASCII ---5
35
Full ASCII ---‘
27
Full ASCII ---6
36
Full ASCII --- (
28
Full ASCII ---7
37
Full ASCII ---)
29
Full ASCII ---8
38
Full ASCII ---*
2A
Full ASCII ---9
39
Full ASCII ---+
2B
Full ASCII ---:
3A
Full ASCII ---,
2C
Full ASCII ---;
3B
Full ASCII ---<
3C
Full ASCII ---K
4B
Full ASCII ---=
3D
Full ASCII ---L
4C
Full ASCII --->
3E
Full ASCII ---M
4D
Full ASCII ---?
3F
Full ASCII ---N
4E
Advanced imaging barcode scanner
Loading...
