LC7100 Smart PC
Copyright 2012
All Rights Reserved
Manual Version 1.0
Part Number:
The information contained in this document is subject to change without
notice.
We make no warranty of any kind with regard to this material, including,
but not limited to, the implied warranties of merchantability and fitness
for a particular purpose. We shall not be liable for errors contained herein
or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be
photocopied, reproduced or translated to another language without the
prior written consent of the manufacturer.
TRADEMARK
Intel®, Pentium® and MMX are registered trademarks of Intel®
Corporation. Microsoft® and Windows® are registered trademarks of
Microsoft Corporation.
Other trademarks mentioned herein are the property of their respective
owners.
ii
Safety
IMPORTANT SAFETY INSTRUCTIONS
1. To disconnect the machine from the electrical Power Supply, turn off
the power switch and remove the power cord plug from the wall socket.
The wall socket must be easily accessible and in close proximity to the
machine.
2. Read these instructions carefully. Save these instructions for future
reference.
3. Follow all warnings and instructions marked on the product.
4. Do not use this product near water.
5. Do not place this product on an unstable cart, stand, or table. The
product may fall, causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided
for ventilation; to ensure reliable operation of the product and to
protect it from overheating. These openings must not be blocked or
covered. The openings should never be blocked by placing the product
on a bed, sofa, rug, or other similar surface. This product should never
be placed near or over a radiator or heat register, or in a built-in
installation unless proper ventilation is provided.
7. This product should be operated from the type of power indicated on
the marking label. If you are not sure of the type of power available,
consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
9. Never push objects of any kind into this product through cabinet slots
as they may touch dangerous voltage points or short out parts that
could result in a fire or electric shock. Never spill liquid of any kind on
the product.
CE MARK
This device complies with the requirements of the EEC directive
2004/108/EC with regard to “Electromagnetic compatibility” and
2006/95/EC “Low Voltage Directive”
FCC
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference
that may cause undesired operation
iii
CAUTION ON LITHIUM BATTERIES
There is a danger of explosion if the battery is replaced incorrectly. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.
Battery Caution
Risk of explosion if battery is replaced by an incorrectly type.
Dispose of used battery according to the local disposal instructions.
Safety Caution
Note: To comply with IEC60950-1 Clause 2.5 (limited power sources, L.P.S)
related legislation, peripherals shall be 4.7.3.2 "Materials for fire enclosure"
compliant.
4.7.3.2 Materials for fire enclosures
For MOVABLE EQUIPMENT having a total mass not exceeding
18kg.the material of a FIRE ENCLOSURE, in the thinnest significant
wall thickness used, shall be of V-1 CLASS MATERIAL or shall pass
the test of Clause A.2.
For MOVABLE EQUIPMENT having a total mass exceeding 18kg
and for all STATIONARY EQUIPMENT, the material of a FIRE
ENCLOSURE, in the thinnest significant wall thickness used, shall
be of 5VB CLASS MATERIAL or shall pass the test of Clause A.1
LEGISLATION AND WEEE SYMBOL
2002/96/EC Waste Electrical and Electronic Equipment Directive on the
treatment, collection, recycling and disposal of electric and electronic
devices and their components.
iv
The crossed dustbin symbol on the device means that it should not be
disposed of with other household wastes at the end of its working life.
Instead, the device should be taken to the waste collection centers for
activation of the treatment, collection, recycling and disposal procedure.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased
this product, or their local government office, for details of where and
how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
This product should not be mixed with other commercial wastes for
disposal.
v
Revision History
Changes to the original user manual are listed below:
Revision Date Description
V1.0 Jul, 2012 Release ( LC710x)
vi
Table of Contents
1 Item Checklist ................................................ 1
1-1 Standard Items ............................................................ 1
2 System View .................................................. 2
2-1 Front View .................................................................... 2
2-2 Rear View ...................................................................... 3
2-3 Bottom View ................................................................ 4
2-4 I/O View......................................................................... 5
3 Peripheral Installation ................................ 7
3-1 Cash Drawer ................................................................. 7
3-2 Serial Ports (COM 1 to COM 4) ................................... 9
4 System Assembly & Disassembly ............. 11
4-1 Replace the HDD ........................................................ 11
4-2 Replace the Motherboard ........................................ 12
5 Specification ................................................ 13
6 Jumper Settings .......................................... 15
6-1 C56 Motherboard ...................................................... 15
7 BIOS Settings ............................................... 21
7-1 VGA with 12V Setting............................................... 23
Appendix .......................................................... 25
vii
1 Item Checklist
Take the system unit out of the carton. Remove the unit from the carton by holding it
by the foam inserts. The following contents should be found in the carton:
1-1 Standard Items
a.
b.
c.
d.
e.
a. System
b. Driver CD
c. Power Adapter (65W)
d. Power Cable
e. COM-RJ45 Cable (x2)
1
2 System View
2-1 Front View
③
②
Number Description
1 FRONT PLATE
2
3 CHASSIS
CHASSIS COVER （Optional）
①
2
2-2 Rear View
④
Number Description
4 I/O PLATE
3
⑤
2-3 Bottom View
Number Description
5 Wall Mount Kit Installing Place
6 Stand Pad
⑥
4
2-4 I/O View
2
Rear View
9
1
Number Description
3
4
5 6 7
8
1 Cash Drawer
2 USB x 4
3 LAN
4 COM1~4 (from left to right)
5 VGA
6 Power Jack for System
7 Power Button
8 Power LED
9 Kensington Lock
Note: The maximum current that can be drawn from each COM port is 500 mA.
5
11 12 13
Front View
10
Number Description
10 Model Label
11 USB
12 Power LED
13 Power Button
6
3 Peripheral Installation
The peripheral and modules units provided are tested and can be supplied at your
request.
3-1 Cash Drawer
You can install a cash drawer through the cash drawer port. Please verify the pin
assignment before installation.
Check topic 6 “Jumper settings” to find out how to set the motherboard to
work with 12 or 24V cash drawers.
Cash Drawer Pin Assignment
Pin Signal
1 GND
2 DOUT bit0
3 DIN bit0
4 12V / 19V
5 DOUT bit1
6 GND
Cash Drawer Controller Register
The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
Register Location:
Attribute:
Size:
BIT BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
48Ch
Read / Write
8bit
Attribute Reserved Read
3-2
7
Reserved Write Reserved
3-3
7 6 5 4 3 2 1 0
X X X X X
Reserved
Cash Drawer “DOUT bit0” pin output control
Cash Drawer “DOUT bit1” pin output control
Reserved
Cash Drawer “DIN bit0” pin input status
Reserved
Bit 7: Reserved
Bit 6: Cash Drawer “DIN bit0” pin input status.
= 1: the Cash Drawer closed or no Cash Drawer
= 0: the Cash Drawer opened
Bit 5: Reserved
Bit 4: Reserved
Bit 3: Cash Drawer “DOUT bit1” pin output control.
= 1: Opening the Cash Drawer
= 0: Allow close the Cash Drawer
Bit 2: Cash Drawer “DOUT bit0” pin output control.
= 1: Opening the Cash Drawer
= 0: Allow close the Cash Drawer
Bit 1: Reserved
Bit 0: Reserved
Note: Please follow the Cash Drawer control signal design to control the Cash Drawer.
Cash Drawer Control Command Example
Use Debug.EXE program under DOS or Windows98
Command Cash Drawer
O 48C 04 Opening
8
O 48C 00 Allow to close
Set the I/O address 48Ch bit2 =1 for opening Cash Drawer by “DOUT bit0”
pin control.
Set the I/O address 48Ch bit2 = 0 for allow close Cash Drawer.
Command Cash Drawer
I 48C Check status
The I/O address 48Ch bit6 =1 mean the Cash Drawer is opened or not exist.
The I/O address 48Ch bit6 =0 mean the Cash Drawer is closed.
3-4 Serial Ports (COM 1 to COM 4)
Pin Assignment for COM Ports (RJ45, RS-232)
Pin No. Signal Name
1 NULL
2 DCD
3 DSR
4 RX
5 RTS
6 TX
7 CTS
8 DTR
9 GND
10 NULL, or +5/+12 VDC
Pin Assignment for COM Cable (RS-232, RJ45 – DB9 male)
RJ45-10 Pin No.
1 NULL 1 DCD
2 DCD 2 RX
3 DSR 3 TX
Signal Name DB9-M Pin No.
Signal Name
4 RX 4 DTR
5 RTS 5 GND
9
6 TX 6 DSR
7 CTS 7 RTS
8 DTR 8 CTS
9 GND 9 NULL, or +5/+12 VDC
10 NULL, or +5/+12 VDC
DB9: male connector RJ45-10 connector
10
4 System Assembly & Disassembly
4-1 Replace the HDD
1. Put the system upside down.
Unfasten the under cover screw (x5)
2. Unfasten the I/O cover screw (x2).
Slide out the I/O Cover.
3. Unfasten the HDD screw (x3).
Separate the HDD from the metal bracket
11
4-2 Replace the Motherboard
1. Put the system upside down.
Unfasten the under cover screw (x5)
2. Unfasten the I/O cover screw (x2).
Slide out the I/O Cover.
3. Unfasten the HDD screw (x1) and remove the DDR
and LED cable.
4. Unfasten the screws (x5) on the Motherboard.
5. Unfasten the hex screws (x2) to release the I/O
12
metal panel from the Motherboard.
Operating Temperature
5 Specification
Model LC7100
Motherboard
CPU Intel CedarView D2550 processor 1.86GHz 1MB Cache
Chipset NM10
System Memory 1 x DDR3 SO-DIMM socket up to 4G, FSB 1066MHz
Graphic Memory Intel GMA 3650 (Gfx frequency up to 640MHz), DX9
BIOS I/O power
BIOS Phoenix UEFI code
Cash drawer +12V/+24V by jumper selection
VGA Max Resolution 1920x1200 : 60 Hz (HD videos capable)
I/O ports
USB
Serial/COM
VGA 1 (w/ +12V power, by BIOS setting)
LAN (10 / 100/1000)
Cash Drawer Port
DC Jack 1 x 2pin CN
Power Button 1
Printer 1(Parallel port printer 25 pins )option
Storage
HDD 2.5" x 1, SATA generation 2.0
Flash memoiry SSD Solid State Disk (option)
Power
Power Adapter
(COM1 w/o power; COM2/COM3/COM4 powered COM with power enable
/disable by BIOS setting; COM2 is 0V/5V; COM3 is 0V/5V; COM4 is 0V/12V;
4 x USB Type A (2 with special cables)
RJ45 x 4 (COM1/COM2/COM3/COM4):
default BIOS setting 0V)
1 x RJ-45
1 x RJ-11 (12V or 19V)
DC 18.5V / 65W
Certificate
EMC & Safety FCC Class A, CE, LVD
Environment
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
13
0°C ~ 35°C (32°F ~ +95°F)
Operating Humidity 20% - 85% RH non-condensing
Storage Humidity 20% - 85% RH non-condensing
Dimension (W x D x H) 195 x 165 x 45mm
Operating System
Windows XP, POS Ready 2009, XP Embedded, XP professional for Embedded,
OS Support
*Product specification is subject to change without prior notice
Embedded, Linux, Windows 7 (32bit), POSReady 7
14
6 Jumper Settings
6-1 C56 Motherboard Layout
15
6-2 Connectors & Functions
Connector Function
CN1 LVDS Inverter Connector
CN2 System FAN Connector
CN3 LVDS Connector
CN4 Power LED Connector
CN5 SATA LED Connector
CN6 Speaker & MIC Connector
CN8 SATA Power Connector
CN9 COM5(Touch) Connector
CN10 Printer Port Connector
CN11/12 USB Port(Internal)
CN13 LAN LED Connector
CN14 PS2 Keyboard Connector
CN15 Card Reader Connector(COM6)
CN16 +19V DC IN Connector
CN17 Power button(Internal)
CN18 Front I/O Connector(USB/power LED/ Power button)
PWR 1/2 +19V DC JACK
RJ11_1 Cash Drawer Connector
RJ45_1 LAN Connector
RJ45_2 COM1/ COM2/ COM3/ COM4
DDR3_A1 DDR3 SO-DIMM
SATA1/2/4 SATA Connector
SKT1 BIOS Connector
USB1 USB6 USB7
USB2 USB4 USB5
VGA1 VGA Connector
SW1 Power Button
JP1 Inverter Select
JP2 CMOS Operation Mode
JP3 LCD ID Setting
JP4 H/W Reset
JP5 COM2 Power Setting
JP6 COM3/COM4 Power Setting
16
JP7 Auto Button Setting
2 3 4 1 2 3 4 1 2 3 4 5 6 1 2 3 4 5 6
JP8 Touch Connector
JP9 CASH DRAWER Power Setting
6-3 Jumper Settings
Cash Drawer Power Setting
Function JP9
▲19V
12V
Inverter Selection
1
Function JP1
▲CCFL
LED
COM2/COM3/COM4 Power Setting
COM2, COM3 and COM4 can be set to provide power to your serial device.
The voltage can be set to +5V or +12V by setting jumper JP5 and JP6 on the
motherboard. When enabled, the power is available on pin 10 of the RJ45 serial
connector. If you use the serial RJ45 to DB9 adapter cable, the power is on pin 9 of
the DB9 connector. By default, the power option is disabled in the BIOS.
17
2 3 4 1 2 3 4 1 2 3 4
Enable COM2/ COM3/COM4 power in BIOS
1. Power on the system, and press the <DEL>
key when the system is booting up to
enter the BIOS Setup utility.
2. Select the Advanced tab.
3. Select VGA/COM Power and LCD
Brightness Configuration Ports and press
<Enter> to go to display the available
options.
4. To enable the power, select COM2 , COM3
or COM4 Power setting and press <Enter>.
Save the change by pressing F10.
COM2 Power Setting
Function JP5
No Power
5V
1
COM2
18
12V
COM3/COM4 Jumper Setting
2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
4 5 6 7 8
2 3 4 5 6 7 8
2 3 4 5 6 7 8
2 3 4 5 6 7 8
2 3 4 5 6 7 8
Function JP6
▲5V
1
COM3
12V
5V
COM4
▲12V
LCD ID Setting
LVDS
Panel# Resolution
Bits Channel
1 800X600 18 Single
2 800X600 18 Single
3 800X600 24 Single
4 1024X600 18 Single
5 1024X768 18 Single
Output
Interface
JP3
3
9
10
1
9
10
1
9
10
1
9
10
1
9
10
19
6 1024X768 24 Single
2 3 4 5 6 7 8
2 3 4 5 6 7 8
2 3 4 5 6 7 8
2 3 4 5 6 7 8
2 3 4 5 6 7 8
2
4 5 6 7 8 9
2 3 4 5 6 7 8
7 1280X1024 24 Dual 1st: LCD Panel
8 1366X768 18 Single
9 1366X768 24 Single
10 1440X900 24 Dual
11 1920X1080 24 Dual
1
9
10
1
9
10
1
9
10
1
9
10
1
9
10
1
9
10
CRT
1
Jumper open
1
Jumper short
3
1
10
20
7 BIOS Settings
BIOS Main Menu
When the BIOS Main Menu is displayed, the following items can be selected. Use
the arrow keys to select items and the Enter key to accept and enter the sub-menu.
Note: The BIOS setup menus shown in this section are for reference only and may not
exactly match the items of your BIOS version.
Standard CMOS Features
Use this menu for basic system configuration.
Advanced BIOS Features
Use this menu to set the Advanced Features available on the system.
Advanced Chipset Features
Use this menu to change the values in the chipset registers and optimize the system’s
performance.
Integrated Peripherals
Use this menu to specify your settings for integrated peripherals.
Power Management setup
Use this menu to specify your settings for power management.
21
PnP/PCI Configurations
This entry appears if your system supports Plug and Play and PCI Configuration.
PC health status
Displays CPU, System Temperature, Fan Speed, and System Voltages Value.
Load Optimized Defaults
Use this menu to load the BIOS default values, i.e., factory settings for optimal
performance system operations. While Award has designed the custom BIOS to
maximize performance, the factory has the option to change these defaults to meet
their needs.
Set Supervisor Password
Enables you to change, set, or disable the supervisor or user password.
Set Password
Change, set, or disable the password. It allows you to limit access to the system and to
the setup, or just to the setup.
Save & exit setup
Save CMOS value changes to CMOS and exits setup.
Exit without saving
Ignores all CMOS value changes and exits setup.
22
7-1 VGA with 12V Setting
1. Turn on power than click “Del” for BIOS SETUP
2. Select Power Configuration COM/VGA Ports
3. Select VGA Power Setting
23
4. Change No Power to +12V
5. Press F10 to save
24
Appendix
Drivers Installation:
The shipping package includes a Driver CD. You can find every individual driver and
utility that enables you to install the drivers in the Driver CD.
Please insert the Driver CD into the drive and double click on the “index.htm” to pick
up the models. You can refer to the drivers installation guide for each driver in the
“Driver/Manual List”.
25
Loading...
