Belshaw Adamatic FT42 User Manual

Feed Table

FT42

Operator’s Manual

Belshaw Bros., Inc.

814 44th Street NW, Suite 103

Auburn, WA 98001 USA

Phone: +-1-206-322-5474 • Fax: +-1-206-322-5425

E-mail: [e-mail] • http://www.belshaw.com

If you accept the machine from the shipping
company, you are, in effect, saying that the
machine is in good condition, and you must
pay for the machine. Belshaw cannot pay for

shipping damage, because the freight company
has accepted the machine from Belshaw in good
condition, and is responsible for its safe delivery.
For your protection, inspect the machine to see
that no parts are bent, scratched, or otherwise
damaged. If any damage has occurred in
shipping, file a freight claim with the shipping
company immediately.

To unpack the FT42-E Feed Table and transport
it to the workstation:

1. Remove the Feed Table from the shipping
crate.

2. Coil the power cord so you do not trip over
it.

3. With the help of another person, carry the
Feed Table to the workstation.

IMPORANT

Keep this manual for future reference.

EQUIPMENT RECORD

Please provide the information below when you correspond with us about your machine.

Purchased by _____________________________________________________________________

Installed by ______________________________________________________________________

Date of Installation ________________________________________________________________

Model number ___________________________________________________________________

Serial number

02/20/08

MN-1667EN

Belshaw Bros., Inc.

814 44th Street NW, Suite 103

Auburn, WA 98001 USA

Phone: +-1-206-322-5474 • Fax: +-1-206-322-5425

E-mail: [e-mail] • http://www.belshaw.com

Contents

1 Operation 1

2 Cleaning 2

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 OM MN-1667EN iii

Preface

SPECIFICATIONS

Dimensions Shipping

Weight

L = 52”/132 cm

W = 19”/48 cm

H = 11 3/4”/
30 cm

The Feed Table, Model FT42-E, is designed to
supply proofed yeast-raised donuts to the Donut
Robot. It is not designed to perform any other
function.

The FT42-E Feed Table is meant to be used on a
flat, stationary table or countertop, positioned
end-to-end with the Donut Robot. The operator
must work safely at all times and read this
manual and follow its instructions and warnings.

The FT42-E Feed Table produces less than 70
dB(A) of equivalent A-weighted sound pressure
at work stations. This has been determined while
running the machine, using a Bruel & Kjaer
sound level meter, type 2236.

73 lb/33.1 kg 115 V

Electrical
Data

1 Phase

50 Hz

Construction Standard Equipment

Stainless steel,
nickel-plated
mild steel, and
aluminum alloys.

• To avoid damaging the machine, never

• Be careful never to get shortening, water,

• To prevent unintentional startup and

Complete conveyor assembly,
including drive system and
controls. Does not include
proofing cloths or proofing boards.

use force to assemble, disassemble,
operate, clean, or maintain it.

or other materials on the floor. If
anything does get spilled on the floor,
mop it up immediately. Materials on the
floor can cause people to slip or fall,
resulting in serious injury or loss of life.

possible fire, unplug the machine if there
is a local power outage. When the power
is restored, it is safe to plug the machine
in again.

A thorough understanding of how to install,
maintain, and safely operate the FT42-E Feed
Table will prevent production delays and
injuries. Heed the following warnings and all
other warnings that appear in this manual:

• To avoid electrocution or other injury,

unplug the machine before attempting
any adjustment, repair, disassembly, or
cleaning.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

iv MN-1667EN Feed table FT42 OM

• To avoid electrocution, make sure that

all electrical cords are not frayed or
cracked and that they do not pass
through any water or shortening.

• Make sure that all electrical cords are

routed so that no one will trip over them.

1 Operation

Operation

CAUTION

To avoid damaging the machine, never use

force to assemble or operate the Feed

Table.

1. Test to make sure that the automatic timing
for the Feed Table is working. To do this:

a. Turn on the Donut Robot’s conveyor

drive.

b. Turn on the Feed Table’s conveyor

drive.

The Feed Table should receive a signal

from the Donut Robot, move forward the
distance needed to supply one pocket of
donuts, and then stop until it receives the
next signal.

5. Release the prime switch and turn on the
main power. Remove the proofing board.

When the Feed Table is on, the Feed Table

automatically advances donuts when the
Donut Robot is ready to accept them. After
the donuts go into the fryer, the proofing
cloths are carried underneath the Feed Table
and fall onto the work surface.

6. Continue putting proofing cloths on the Feed
Table.

2. Proof your donuts on the proofing cloths
from the Feed Table.

3. Put a proofing board, with a proofing cloth
on it, on the Feed Table.

4. Press the prime switch on the power head
assembly. The hooks on the Feed Table will
grab the proofing cloth off of the proofing
board. Allow the cloth to advance to the
front of the Feed Table.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 OM MN-1667EN 1

2 Cleaning

Cleaning

After each use, clean the Feed Table with a soft,
damp cloth.

WARNING

To avoid electrocuting yourself or

damaging the machine, never allow any

liquid to enter the power head.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

2 MN-1667EN Feed table FT42 OM

Feed Table

FT42

Technical Supplement

Belshaw Bros., Inc.

814 44th Street NW, Suite 103

Auburn, WA 98001 USA

Phone: +-1-206-322-5474 • Fax: +-1-206-322-5425

E-mail: [e-mail] • http://www.belshaw.com

If you accept the machine from the shipping
company, you are, in effect, saying that the
machine is in good condition, and you must
pay for the machine. Belshaw cannot pay for

shipping damage, because the freight company
has accepted the machine from Belshaw in good
condition, and is responsible for its safe delivery.
For your protection, inspect the machine to see
that no parts are bent, scratched, or otherwise
damaged. If any damage has occurred in
shipping, file a freight claim with the shipping
company immediately.

To unpack the FT42-E Feed Table and transport
it to the workstation:

1. Remove the Feed Table from the shipping
crate.

2. Coil the power cord so you do not trip over
it.

3. With the help of another person, carry the
Feed Table to the workstation.

IMPORANT

Keep this manual for future reference.

EQUIPMENT RECORD

Please provide the information below when you correspond with us about your machine.

Purchased by _____________________________________________________________________

Installed by ______________________________________________________________________

Date of Installation ________________________________________________________________

Model number ___________________________________________________________________

Serial number

02/20/08

MN-1668EN

Belshaw Bros., Inc.

814 44th Street NW, Suite 103

Auburn, WA 98001 USA

Phone: +-1-206-322-5474 • Fax: +-1-206-322-5425

E-mail: [e-mail] • http://www.belshaw.com

Contents

1 Installation 1

2 Maintenance 2

3 Troubleshooting 3

4 Electrical Components 7

Testing the Continuity of a Toggle Switch 7
Testing the Continuity of a Microswitch 8

5 Appendix 9

Parts List Drawing Insert Page Insert

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 TS MN-1668EN iii

Preface

SPECIFICATIONS

Dimensions Shipping

Weight

L = 52”/132 cm

W = 19”/48 cm

H = 11 3/4”/
30 cm

The Feed Table, Model FT42-E, is designed to
supply proofed yeast-raised donuts to the Donut
Robot. It is not designed to perform any other
function.

The FT42-E Feed Table is meant to be used on a
flat, stationary table or countertop, positioned
end-to-end with the Donut Robot. The operator
must work safely at all times and read this
manual and follow its instructions and warnings.

The FT42-E Feed Table produces less than 70
dB(A) of equivalent A-weighted sound pressure
at work stations. This has been determined while
running the machine, using a Bruel & Kjaer
sound level meter, type 2236.

73 lb/33.1 kg 115 V

Electrical
Data

1 Phase

50 Hz

Construction Standard Equipment

Stainless steel,
nickel-plated
mild steel, and
aluminum alloys.

• To avoid damaging the machine, never

• Be careful never to get shortening, water,

• To prevent unintentional startup and

Complete conveyor assembly,
including drive system and
controls. Does not include
proofing cloths or proofing boards.

use force to assemble, disassemble,
operate, clean, or maintain it.

or other materials on the floor. If
anything does get spilled on the floor,
mop it up immediately. Materials on the
floor can cause people to slip or fall,
resulting in serious injury or loss of life.

possible fire, unplug the machine if there
is a local power outage. When the power
is restored, it is safe to plug the machine
in again.

A thorough understanding of how to install,
maintain, and safely operate the FT42-E Feed
Table will prevent production delays and
injuries. Heed the following warnings and all
other warnings that appear in this manual:

• To avoid electrocution or other injury,

unplug the machine before attempting
any adjustment, repair, disassembly, or
cleaning.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

iv MN-1668EN Feed table FT42 TS

• To avoid electrocution, make sure that

all electrical cords are not frayed or
cracked and that they do not pass
through any water or shortening.

• Make sure that all electrical cords are

routed so that no one will trip over them.

1 Installation

1. Unplug the cutter head power cord of your
Donut Robot.

2. Release the plunger from the cutter head.

3. Unscrew and lift off the hopper assembly.

4. Lift off the cutter head and swing column.

5. Lift the outfeed end of the Feed Table and
set the brace under the trip shelf over the
edge of the kettle.

WARNING

To avoid injury, make sure that the Feed

Table is turned off before proceeding.

6. Plug the Feed Table power cord into the
outlet on the end of the heater head.

7. Set the Donut Robot to cut one cut per
pocket.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 TS MN-1668EN 1

2 Maintenance

If you ever need to adjust the tension of the
conveyor chains, follow these steps:

1. Loosen the hex head bolts that hold the
roller shaft at the outfeed end of the
conveyor.

2. Pull the shaft until the chains reach the
correct tension. The tension is correct when
you can lift the chains about 1”/2.5 cm
above the surface of the Feed Table. Each
chain should have the same tension.

3. Tighten the hex head bolts that hold the
roller shaft.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

2 MN-1668EN Feed table FT42 TS

3 Troubleshooting

If you have a problem with your FT-42 Feed
Table that you cannot solve, call your dealer or
another qualified technician.

If your dealer cannot help you, please call
Belshaw. To do so, first dial the appropriate
international access code, then 1-206-322-5474
(United States). When you call, please specify
the following:

• The model name of the machine.

• The serial number of the machine.

• The voltage, phase, and cycle of the

machine.

CAUTION

If you perform repairs yourself or have

them performed by anyone other than a

service technician authorized by Belshaw

Bros., you do so at your own risk.

To avoid down time, call us to see whether we
have a machine we can loan to you while your
machine is being serviced.

Ship machines in need of servicing to:

Belshaw Bros., Inc.
814 44th Street NW, Suite 103
Auburn, WA 98001 USA

Following is a troubleshooting chart to help you
identify and solve some basic problems.

WARNING

To avoid being burned, electrocuted, or

otherwise injured, unplug the machine and

allow it to cool before disassembling,

repairing, or wiring.

If your dealer or another local, qualified
technician cannot provide service for your
machine, Belshaw can provide factory service.
First call us for a return goods authorization.
Then send your machine to us, freight prepaid,
with your instructions for service, your phone
number, and the name of the person for us to
contact when we have made a cost estimate. In
most cases, the machine can be shipped back,
freight collect, within five days.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 TS MN-1668EN 3

THE CONVEYOR CHAINS DO NOT ADVANCE WHEN THE MAIN POWER IS
ON OR WHEN THE PRIME SWITCH IS PRESSED, AND THE PILOT LIGHT
DOES NOT COME ON.

Possible Causes What To Do

The power cord is not connected. Plug in the power cord.

The circuit breaker for the gear box outlet on the
Donut Robot’s heater head is tripped.

The black or white wire in the power cord is
broken or poorly connected.

The fuse on the Feed Table is blown. Replace the fuse.

The fuse for the Donut Robot’s conveyor is
blown.

Push the white reset button near the outlet.

To avoid electric shock or other injury, before
doing any of the following, unplug the machine.

Repair the cord and/or make the proper connection.

Replace the fuse.

WARNING

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

4 MN-1668EN Feed table FT42 TS

THE CONVEYOR CHAINS DO NOT ADVANCE WHEN THE MAIN POWER IS
ON, BUT THEY DO ADVANCE WHEN THE PRIME SWITCH IS PRESSED.

Possible Causes What To Do

The red wire in the power cord is broken or
poorly connected.

The microswitch in the power head is defective. Replace the microswitch.

The microswitch in the Donut Robot’s signal
circuit is defective.

To avoid electric shock or other injury, before
doing any of the following, unplug the machine.

Repair the cord and/or make the proper connection.

Replace the microswitch.

WARNING

THE CONVEYOR CHAINS DO NOT ADVANCE AT ALL, DO NOT ADVANCE
FAR ENOUGH, OR DO NOT ADVANCE THE SAME DISTANCE DURING
EACH CYCLE, BUT THE PILOT LIGHT DOES COME ON.

Possible Cause What To Do

WARNING

The cam in the power head is loose. Tighten the cam set screw.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 TS MN-1668EN 5

To avoid electric shock or other injury, before
doing the following, unplug the machine.

THE CONVEYOR CHAINS ADVANCE CONTINUOUSLY WHEN THE MAIN
POWER IS ON.

Possible Causes What To Do

The brake is defective. Repair or replace the brake.

The cam in the power head is loose. Tighten the cam set screw.

The microswitch in the power head is defective. Replace the microswitch.

The microswitch in the Donut Robot’s signal
circuit is defective.

To avoid electric shock or other injury, before
doing any of the following, unplug the machine.

Replace the microswitch.

WARNING

TWO ROWS OF DONUTS ARE ADVANCED DURING EACH CYCLE.

Possible Causes What To Do

To avoid electric shock or other injury, before
doing either of the following, unplug the machine.

WARNING

The brake is defective. Repair or replace the brake.

The cam in the power head is loose. Tighten the cam set screw.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

6 MN-1668EN Feed table FT42 TS

4 Electrical Components

This section explains how to test the continuity
of electrical components in the FT42-E Feed
Table.

Testing the Continuity of a
Toggle Switch

WARNING

To avoid the possibility of electric shock,

disconnect the machine from the power

source before testing.

+

switch terminals

toggle switch

1. Disconnect the machine from the power
source.

2. Disconnect the terminal wires from the
switch.

3. Obtain a continuity tester or a volt-ohm
meter. If neither of these instruments is
available, make a continuity tester using a
battery and a bulb. (See Figure 4-1.)

4. Connect the wires of the continuity tester to
the switch terminals, as shown in Figure 4-1,
and test the switch in the ON and OFF
positions. The switch should show
continuity only when in the ON position.

battery

_

Figure 4-1. Toggle Switch Continuity Test.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 TS MN-1668EN 7

Testing the Continuity of a
Microswitch

WARNING

To avoid the possibility of electric shock,

disconnect the machine from the power

source before testing.

1. Disconnect the machine from the power
supply.

2. Disconnect the terminal wires from the
switch.

3. Obtain a continuity tester or a volt-ohm
meter. If neither of these instruments is
available, make a continuity tester using a
battery and a bulb. (See Figure 4-2.)

4. Connect one wire of the continuity tester to
the microswitch’s common (COM) terminal
and the other wire to the normally open
(NO) terminal, as shown in Figure 4-2. The
switch should show continuity only when
the microswitch actuator arm is depressed.

5. To test the normally closed (NC) terminal,
move the wire from the normally open (NO)
terminal to the normally closed terminal.
Now the switch should show continuity only
when the actuator arm is not depressed.

switch
terminals

NC NO

COM

+

battery

−

microswitch

Figure 4-2. Microswitch Continuity Test.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

8 MN-1668EN Feed table FT42 TS

5 Appendix

See Parts List Drawing Insert Page.

Belshaw Bros., Inc. • www.belshaw.com • Phone [phone] • Fax [phone]

Feed Table FT42 TS MN-1668EN 9
