TPC2133 Triple Play™ Universal Flat Panel A/V System
Features
• Versatile design allows user to display a TV in 3 different ways:
① On the swivel mounting pole
② On the included wall mount
③ Simply placed on the stand
• Accommodates most at panel TVs up to 60" (or up to 125 lbs.)
and holds at least 4 audio/video components
• Features Dark Espresso nished solid wood legs and an
elegantly curved front with Brushed Nickel accents
• Perfect for a large soundbar or center channel speaker
• Sturdy scratch resistant, powder-coated Black metal frame
and elegant Black tempered safety glass shelves
• Open architecture design provides ventilation for components
• CMS® Cable Management System hides and routes
unsightly wires
• Universal TV mounting system ts TVs up to 700 x 500 mm
• Assembles in minutes with no tools required
Triple Play
™
No Tools Assembly
Specications
TV Size Up to 60"
# of Components At least 4
Color
Cable Management System
UPC 748249021331
Container Quantity 425
Carton Weight 102.5 lbs. (46.5 kg)
Carton Dimensions 55.9" x 24.8" x 6.8"
Dark Espresso / Brushed Nickel
Yes
Dimensions
Width Height Depth
Overall 52" 59" 22"
Table Only 52" 22.25" 20"
Top Shelf 52" n/a 20"
Middle Shelf 43.5" 8.25" 18.25"
Bottom Shelf 40.75" 8.5" 18.25"
All measurements are nominal usable space
WeightCapacities
lbs. kg
Top Shelf/Wall Mount/Pole 125 56.7
Middle Shelf 50 22.7
Mounted on wall with
included wall mount
Bell’OInternationalCorp.bello.com | © 2014 All designs are patented or patent pending. Availability and specications are subject to change without notice.
Mounted on
swivel pole
Placed on
the stand
Bottom Shelf 75 34
