BEL FS50GTCL Whi/444443998
BEL FS50GTCL Blk/444443999
BEL FS50GTCL Sta/444444000
OPERATING AND INSTALLATION
INSTRUCTIONS OF
FREESTANDING
GAS TWIN CAVITY
Dear Customer,
Thank you for purchasing this Cooking Appliance. The safety
precautions and recommendations in these instructions are for your own safety and the safety of others. These instructions will also allow you to make full use of all the features offered by your appliance.
Please keep this booklet in a safe place. It may be useful in future, either to yourself or to others in the event that doubts should arise relating to its operation.
This appliance must be used only for its intended purpose, that is for the domestic cooking of foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous.
The manufacturer declines all responsibility in the event of damage caused by improper or incorrect use of the appliance.
CONTENTS:
1.COOKER LAYOUT
2.WARNINGS
3.INSTALLATING YOUR COOKER
4.USING THE PRODUCT
5.CLEANING AND MAINTENANCE
6.SERVICE AND TRANSPORT
2
PART 1: COOKER LAYOUT |
|
|
LAYOUT: |
7 |
|
|
||
|
2. Rack |
|
|
1. Rack |
|
1 |
8 |
|
2 |
||
5. Rack |
||
|
4. Rack |
|
|
3. Rackf |
|
|
2. Rack |
|
|
1. Rack |
|
5 |
|
3
9
6
13
10
4
11 12
List of Components: |
|
1- Cooktop |
8- Oven Lamp |
2- Control Panel |
9- Semi-Rapid Burner |
3- Oven Door Handle |
10Rapid Burner |
4- Supply Leg |
11Auxillary Burner |
5- Oven Door |
12Hob enamel pan supports |
6- Wire Grid |
13- Semi-Rapid Burner |
7- Grill |
|
3
PART 2: WARNINGS
PLEASE READ THE ENTIRE INSTRUCTION MANUAL CAREFULLY BEFORE USING YOUR
APPLIANCE. MAKE SURE TO KEEP THE MANUAL SOMEWHERE SAFE IN CASE YOU NEED IT
FOR FUTURE REFERENCE.
THIS INSTRUCTION MANUAL HAS BEEN WRITTEN WITH OUR OTHER COOKER MODELS IN
MIND, AS WELL AS YOUR MODEL, THEREFORE SOME OF THE FEATURES THAT YOU SEE
EXPLAINED IN THIS MANUAL WILL NOT BE APPLICABLE TO YOUR COOKER.
PLEASE PAY PARTICULAR ATTENTION TO THE INSTRUCTIONS THAT HAVE ACCOMPANYING
PICTURES WHEN READING THIS MANUAL.
General Safety Warnings
-This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
-WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
-WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.
4
-WARNING: Danger of fire: do not store items on the cooking surfaces.
-WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock.
-For hobs incorporating a lid, any spillage should be removed from the lid before opening. And also the hob surface should be allowed to cool before closing the lid.
-The appliance is not intended to be operated by means of an external timer or separate remotecontrol system.
-WARNING: In order to prevent tipping of the appliance, the stabilizing brackets must be installed. (For detail information please read the anti-tilting kit set guide.)
-During use, the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.
-During use, handles held for short periods in normal use can get hot.
-Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass and other surface since they can scratch the surface, which may result in shattering of the glass or damage to the surface.
5
-Do not use steam cleaners for cleaning the appliance.
-WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.
-CAUTION: Accessible parts may be hot when the cooking or grilling is in use. Young children should
be kept away.
-Your appliance is produced in accordance with all applicable local and international standards and regulations.
-Maintenance and repair work must be made only by authorized service technicians. Installation and repair work that is carried out by unauthorized technicians may endanger you. It is dangerous to alter or modify the specifications of the appliance in any way.
-Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure or electricity voltage and frequency) and the requirements of the appliance are compatible. The requirements for this appliance are stated on the label.
-CAUTION: This appliance is designed only for cooking food and is intended for indoor domestic household use only and should not be used for any other purpose or in any other application, such as for non-domestic use or in a commercial environment or room heating.
-Do not try to lift or move the appliance by pulling the door handle.
-This appliance is not connected to a combustion products evacuation device. It shall be installed and connected in accordance with current installation regulations. Particular attention shall be given to the relevant requirements regarding ventilation.
-If after 15 seconds the burner has not lit, stop operating the device and open the compartment door and/or wait at least 1 minute before attempting a further ignition of the burner.
-These instructions are only valid if the country symbol appears on the appliance. If the symbol does not appear on the appliance, it is necessary to refer to the technical instructions which will provide the necessary instructions concerning modification of the appliance to the conditions of use of the country.
-All possible security measures have been taken to ensure your safety. Since the glass may break, you should be careful while cleaning to avoid scratching. Avoid hitting or knocking on the glass with accessories.
6
-Ensure that the supply cord is not wedged during the installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to prevent a hazard.
-While the oven door is open, do not let children climb on the door or sit on it.
Installation Warnings
-Do not operate the appliance before it is fully installed.
-The appliance must be installed by an authorized technician and put into use. The producer is not responsible for any damage that might be caused by defective placement and installation by unauthorized people.
-When you unpack the appliance, make sure that it is not damaged during transportation. In case of any defect; do not use the appliance and contact a qualified service agent immediately. As the materials used for packaging (nylon, staplers, styrofoam...etc) may cause harmful effects to children, they should be collected and removed immediately.
-Protect your appliance against atmospheric effects. Do not expose it to effects such as sun, rain, snow etc.
-The surrounding materials of the appliance (cabinet) must be able to withstand a temperature of min 100°C.
During usage
-When you first run your oven a certain smell will emanate from the insulation materials and the heater elements. For this reason, before using your oven, run it empty at maximum temperature for 45 minutes. At the same time you need to properly ventilate the environment in which the product is installed.
-During usage, the outer and inner surfaces of the oven get hot. While opening the oven door, step back to avoid the hot steam coming out of the oven. There may be a risk of burns.
-Do not put flammable or combustible materials, in or near the appliance when it is operating.
-Always use oven gloves to remove and replace food in the oven.
-Do not leave the cooker while cooking with solid or liquid oils. They may catch fire on condition of extreme heating. Never pour water on to flames that are caused by oil. Cover the saucepan or frypan with its cover in order to choke the flame that has occured in this case and turn the cooker off.
-Always position pans over the centre of the cooking zone, and turn the handles to a safe position so they cannot be knocked or grabbed.
-If you are not using the appliance for a long time, unplug it. Keep the main control switch off. Also when you are not using the appliance, keep the gas valve off.
-Make sure the appliance control knobs are always in the "0" (stop) position when it is not used.
-The trays incline when pulled out. Be careful not to let hot liquid spill over.
7
-CAUTION: The use of a gas cooking appliance results in the production of heat, moisture and products of combustion in the room in which it is installed. Ensure that the kitchen is well ventilated especially when the appliance is in use, keep natural ventilation holes open or install a mechanical ventilation device (mechanical extractor hood).
-Prolonged intensive use of the appliance may call for additional ventilation, for example opening of a window, or more effective ventilation, for example increasing the level of mechanical ventilation where present.
-While using the grill burner, keep the oven door open and always use the grill deflector shield supplied with the product. Never use the grill burner with the oven door closed.
-When the door or drawer of the oven is open, do not leave anything on it. You may unbalance your appliance or break the cover.
-Do not put heavy things or flammable or ignitable goods (nylon, plastic bag, paper,
cloth...etc) into the drawer. This includes cookware with plastic accessories (e.g. handles).
- Do not hang towels, dishcloths or clothes from the appliance or its handles.
During cleaning and maintenance
-Always turn the appliance off before operating such as cleaning or maintenance. You can do it after unplugging the appliance or turning the main switch off.
-Do not remove the control knobs to clean the control panel.
TO MAINTAIN THE EFFICIENCY AND SAFETY OF YOUR APPLIANCE, WE RECOMMEND YOU ALWAYS USE ORIGINAL SPARE PARTS AND TO CALL ONLY OUR AUTHORIZED
SERVICE AGENTS IN CASE OF NEED.
