Belkin SE 2-Port User Manual

P73039 F1D102

The OmniView

™

S E 2-Port

User Manual

P73039_F1D102-eng_man.qxd 9/26/00 3:42 PM Page 1

Introduction

Thank you for purchasing the Belkin Components OmniView™SE KVM switch. Controlling multiple PCs from one keyboard, mouse and monitor has never been easier!

The OmniView

™

SE puts you in control. Compatible with AT and PS-2 style computers, it is loaded with features such as Integrated Mouse Conversion Technology, separate DB25 daisychain ports, and an optional 19" (48.3cm) rackmount kit. It has complete keyboard and mouse emulation for error-free boot-ups, plus Microsoft

IntelliMouse®support. The OmniView™SE is also designed to handle the most demanding resolutions up to 1600 x 1200, without any noticeable degradation in image quality. Switching can be done through convenient frontpanel pushbutton, or keyboard “Hot” key commands. And if you wish to control a Macintosh

computer, simply add the Belkin MAC Adapter™for even more system control.

• Allows a user to control two computers from one keyboard, mouse and monitor

• Integrated Mouse Conversion Technology allows connection of AT-style computers

that have serial mouse ports while using a PS/2 mouse only at the console

• Keyboard and mouse emulation for error-free boot-ups

• Microsoft®IntelliMouse®and IntelliMouse®Pro support

• Up to 1600 x 1200 resolution support

• DB25 Daisy-Chain ports - allows control over more computers by adding more

OmniView

™

SE units

• Supports both AT and PS/2 style keyboards (AT requires AT-PS/2 adapter)

• Supports VGA, SVGA and Multisync monitors

• Uses inexpensive and commonly found standard cables

• Pushbutton or keyboard “Hot” key command switching

• AutoScan mode for even more convenience

• Audible feedback when switching

• Recalls CAPS LOCK, NUM LOCK and SCROLL LOCK keys' status for each

computer automatically

• Front-panel status LEDs

• Works with OmniView

™

PS/2 MAC Adapter

™

• No software required

• One year product warranty

Package Contents

OmniView™SE 2-Port F1D102 9VDC, 600mA power supply F1D065-PWR (U.S., Canada)

F1D065-PWR-UK (United Kingdom) This manual P73039 Registration card P72009

Features

P73039_F1D102-eng_man.qxd 9/26/00 3:42 PM Page 1

Technical Specifications

Console Connectors:

Keyboard: 6 pin MiniDIN female Mouse: 6 pin MiniDIN female (for PS/2 mouse)

DB9 male (for spare serial mouse)

Monitor: HDDB15 female

Computer Port Connectors:

Keyboard: 6 pin MiniDIN female Mouse: 6 pin MiniDIN female (for PS/2 mouse)

DB9 male (for serial mouse)

Monitor: HDDB15 male

Dimensions:

Width: 9.5" (237 mm) Height: 2.3" (58 mm) Depth: 6.0" (153 mm)

Weight: 2.5 lbs (1.1 kg) Operating Temp: 32 to 104 deg. F (0~40 deg. C) Storage Temp: -4 to 140 deg. F (-20 ~ 60 deg. C) Humidity: 0~80% RH, non-condensing

P73039_F1D102-eng_man.qxd 9/26/00 3:42 PM Page 2

Product Detail

SLAVE INPUT

DB25 Daisy-chain port

MASTER INPUT SLAVE OUTPUT

DB25 Daisy-chain port

DC power

jack

DIP switches

Optional

serial mouse

connector

CONSOLE connectors

Keyboard connector

PS/2 mouse

connector

VGA monitor

connector

PC PORT

connectors

Serial mouse

output

Keyboard

output

PS/2 mouse

output

VGA signal output

FRONT PANEL

REAR PANEL

Current Active Port

LED Indicators

Current Active Bank

LED Indicators

Bank Select/ Scan Button

Port Select

Button

P73039_F1D102-eng_man.qxd 9/26/00 3:42 PM Page 3

Make sure you have the right cables!

The OmniView™SE requires cables to connect the eight computers you will be controlling. Below are the Belkin part numbers and their descriptions. We recommend purchasing Cable Kits based on the type of mouse port your computer uses. Cable kits have all the cables you need to connect one computer to the OmniView™SE:

PS/2 Cable Kit - A3X982

Includes:

• 2 x F2N036-06

• 1 x F2N025-06-T

AT Cable Kit - A3X939

Includes:

• 1 x F3A510-06

• 1 x F2N025-06-T

• 1 x F2N209-06-T

• 1 x F2N017

(see below for descriptions of each)

Individual Cables and Adapters:

• PS/2 cable for keyboard and mouse ports 6 pin MiniDIN male/male

Part# F2N036-XX

• Standard VGA cable for monitor port HDDB15 male/female with thumbscrews

Part# F2N025-XX-T

• Serial extension cable for serial mouse DB9 male/female with thumbscrews

Part# F2N209-XX-T

• AT keyboard cable for AT-style keyboard port

5 pin DIN male/male

Part# F3A510-XX

• AT to PS/2 keyboard adapter 5 pin DIN female/6 pin MiniDIN male

Part# F2N017

Other Cables and Adapters:

• High-resolution/high-refresh rate VGA cable for monitor port HDDB15 male/female with thumbscrews

Part# A3H981-XX

• PS/2 to AT keyboard adapter - for use with a computer having an AT-style keyboard port 6 pin MiniDIN female/ 5 pin DIN male

Part# F2N018

NOTE: The "XX" in the part number represents the length in feet.

6 pin MiniDIN

6 pin MiniDIN Female 5 pin DIN Male

HDDB15

List of Parts Needed

5 pin DIN

HDDB15

DB9

Daisy-Chain Cable

• DB25 Male/Male, 2’ (61cm) with ferrite Part # F1D108-CBL

Optional 19" (48.3cm) Rackmount Kit

• 19" (48.3cm), 1.5u high Part # F1D103

5 pin DIN Female

6 pin MiniDIN Male

P73039_F1D102-eng_man.qxd 9/26/00 3:42 PM Page 4

1. Set the DIP switches. If you have only one OmniView

™

SE, use the MASTER bank setting. If the OmniView™SE you are using will be daisy-chained off another unit, use a unique slave setting. Please refer to the next section for more information regarding multiple OmniView™SE units.

PLEASE FOLLOW THIS INSTALLATION PROCEDURE EXACTLY. NOT DOING SO MAY RESULT IN KEYBOARD AND/OR MOUSE ERRORS, OR FAULTY OPERATION.

WARNING: Before attempting to connect anything to the OmniView™SE or the computers, make sure everything is powered off. Plugging and unplugging cables may cause irreversible damage to your computers and the OmniView

™

SE.

Belkin Components will not be held responsible for damage caused.

Hardware Installation

DIP SWITCH SETTINGS

1234

ON ON ON ON BANK 0 MASTER ON ON OFF ON BANK 1 Slave ON ON ON OFF BANK 2 Slave ON ON OFF OFF BANK 3 Slave

BANK ADDRESS

3. Connect the monitor to the OmniView

™

SE. Using the attached cable, or the one included with your monitor, connect it to the HDDB15 female port on the back of the OmniView™SE labeled with the monitor symbol at the CONSOLE section.

2. Find a convenient place to put your OmniView

™

SE. Take note of the length of your cables so that your computers, OmniView™SE, keyboard, mouse, and monitor are distanced properly.

Monitor

NOTE: ON is down

Use this setting if you have only one OmniView™SE

DIP switches 1 & 2 set the SCAN_TIME. See the USAGE section regarding this setting.

P73039_F1D102-eng_man.qxd 9/26/00 3:42 PM Page 5
