Beko HII64400AT User Manual

Built-In Hob HII 64400 AT

Please read this manual first.

Dear Customer, We would like you to obtain best performance with your product that has been

manufactured in modern facilities and passed through strict quality control procedures. Therefore, we advise you to read through this User Manual carefully before using your product and keep it for future reference. If you hand over the product to someone else, deliver the User Manual as well.

The User Manual will help you use the product in a fast and safe way.

• Read the User Manual before installing and operating the product.

• You must strictly observe the safety instructions.

• Keep this User Manual within easy reach for future reference.

• Also read other documents supplied with the product.

Remember that this User Manual may also be applicable for several other models.

Differences between models are explicitly identified in the manual.

Explanation of symbols

Throughout this User Manual the following symbols are used:

Important information or useful hints about usage.

Warning for hazardous situations with regard to life and property.

Warning for electric shock.

Warning for risk of fire.

Warning for hot surfaces.

Table of Contents

1 General information 4

Overview ............................................... 4

Technical specifications ....................... 4

2 Important safety instructions 6

General safety ....................................... 6

Intended use ...................................... 7

Safety for children .............................. 7

Safety when working with electricity . 7

3 Installation 8

Before installation ................................. 8

Installation and connection................... 9

Disposal .............................................. 12

Disposing of packaging material ..... 12

Future Transportation ...................... 12

Disposing of the old product ........... 12

4 Preparation 14

Tips for saving energy ......................... 14

Initial use ............................................. 14

First cleaning of the appliance ........ 14

5 How to use the hob 15

General information about cooking .... 15

Using the hobs .................................... 17

Control panel ...................................... 17

6 Maintenance and care 24

General information ............................ 24

Cleaning the hob ................................. 24

7 Troubleshooting 26

8 Guarantee and Service Error!

Bookmark not defined.

3 | EN

1 General information

1 Induction cooking plate

2 Assembly clamp

3 Vitroceramic surface

4 Base cover

Voltage / frequency

220-240 V~/380

415 V 2N ~ 50

Total power consumption

max. 7200 W

Fuse min. 16 A x 2 / 32 A

Cable type / section

H05VV

-FG 5 x 1,5 mm

Cable length

max. 2 m

External dimensions (height / width / depth)

55 mm/580 mm/510 mm

Installation dimensions (width / depth)

560 mm/490 mm

Burners

Rear left

Induction cooking plate

Dimension

180 mm

Power

2000/2300

Front left

Induction cooking plate

Dimension

180 mm

Power

2000/2300

Front right

Induction cooking plate

Dimension

145mm

Power

1600/1800

Rear right

Induction cooking plate

Overview

Technical specifications

or equivalent

4 | EN

Dimension

210 mm

Power

2000/2300 W

IMPORTANT

Technical specifications may be

IMPORTANT

Values stated on the product labels

changed without prior notice to improve the quality of the product.

Figures in this manual are schematic and may not exactly match your product.

or in the documentation accompanying it are obtained in laboratory conditions in accordance with relevant standards. Depending on operational and environmental conditions of the product, these values may vary.

The appliance is not intended to be operated by means if an external timer or separate remote control.

5 | EN

2 Important safety instructions

This section contains safety instructions that will help you avoid risk of injury and damage. All warranties will become void if you do not follow these instructions.

General safety

• This product is not intended to be

used by persons with physical, sensory or mental disorders or unlearned or inexperienced people (including children) unless they are attended by a person who will be responsible for their safety or who will instruct them accordingly for use of the product. Children must be supervised to prevent them from tampering with the product.

• Connect the product to an earthed

outlet/line protected by a fuse of suitable capacity as stated in the "Technical specifications" table. Have the earthing installation made by a qualified electrician while using the product with or without a transformer. Our company shall not be liable for any problems arising due to the product not being earthed in accordance with the local regulations.

• If the supply cord is damaged, it

must be replaced by the manufacturer, its service agent or similary qualified persons in order to avoid a hazard.

• Do not operate the product if it is

defective or has any visible damage.

• Do not carry out any repairs or

modifications on the product. However, you may remedy some troubles that do not require any repairs or modifications. See Troubleshooting, page 26.

• Never wash down the product with

water! There is the risk of electric shock!

• Never use the product when your

judgment or coordination is impaired by the use of alcohol and/or drugs.

• Product must be disconnected

from the mains during installation, maintenance, cleaning and repair procedures.

• Be careful when using alcoholic

drinks in your dishes. Alcohol evaporates at high temperatures and may cause fire since it can ignite when it comes into contact with hot surfaces.

• Do not heat closed tins and glass

jars in the oven. The pressure that would build-up in the tin/jar may cause it to burst.

• Do not place any flammable

materials close to the product as the sides may become hot during use.

• Keep all ventilation slots clear of

obstructions.

• Make sure that the product

function knobs are switched off after every use.

6 | EN

• Vapour pressure that build up due

IMPORTANT

As induction hobs create a

DANGER

to the moisture on the hob surface or at the bottom of the pot can cause the pot to move. Therefore, make sure that the oven surface and bottom of the pots are always dry.

• Hotplates of your oven are

equipped with "Induction" technology. Your induction hob that provides both time and money savings must be used with pots suitable for induction cooking; otherwise hotplates will not operate. See.General information about cooking, page 15, selecting the pots.

magnetic field, they may cause harmful impacts for people who use devices such as insulin pump or pacemaker.

Safety for children

• Electrical and/or gas products are

dangerous to children. Keep children away from the product when it is operating and do not allow them to play with the product.

• Accessible parts of the appliance

will become hot whilst the appliance is in use. Children should be kept away until the product has cooled down.

• Do not place any items above the

appliance that children may reach for.

• The packaging materials will be

dangerous for children. Keep the packaging materials away from children. Please dispose of all parts of the packaging according to environmental standards.

SAVE THESE INSTRUCTIONS

Fire Hazard!

This handrail is not towel dryer. Do not hang up towel, gloves, or similar textile products when the gril function is at open door.

Intended use

This product is designed for domestic use. Commercial use will void the guarantee.

"CAUTION: This appliance is for cooking purposes only. It must not be used for other purposes, for example room heating."

The manufacturer shall not be liable for any damage caused by improper use or handling errors.

Safety when working with electricity

Defective electric equipment is one of the major causes of house fires.

• Any work on electrical equipment

and systems should only be carried out by authorized and qualified persons.

• In case of any damage, switch off

the product and disconnect it from the mains. To do this, turn off the fuse at home.

• Make sure that fuse rating is

compatible with the product.

7 | EN

3 Installation

IMPORTANT

DANGER

Product must be installed by a qualified person in accordance with the regulations in force. The manufacturer shall not be held responsible for damages arising from procedures carried out by unauthorized persons which may also void the warranty.

Preparation of location and electrical and gas installation for the product is under customer’s responsibility.

The product must be installed in accordance with all local gas and/or electrical regulations.

Prior to installation, visually check if the product has any defects on it. If so, do not have it installed.

Damaged products cause risks for your safety.

Before installation

The hob is designed for installation in a commercial worktop. A safety distance must be left between the appliance and the kitchen walls and furniture. See figure (values in mm).

• It can also be used in a free

standing position. Allow a minimum distance of 750 mm above the hob surface.

• (*) If a cooker hood is to be

installed above the cooker, refer to cooker hood manufacturer' instructions regarding installation height (min 650 mm)

• Remove packaging materials and

transport locks.

• Surfaces, synthetic laminates and

adhesives used must be heat resistant (100 °C minimum).

• The worktop must be aligned and

fixed horizontally.

• Cut aperture for the hob in

worktop as per installation dimensions.

8 | EN

* min.

Installation and connection

NOTICE

DANGER

come into contact with hot parts

A damaged power cable must be

installation in accordance with the local regulations.

• The product must be installed in

accordance with all local gas and electrical regulations.

Do not install the hob on places with sharp edges or corners. There is the risk of breaking for glass ceramic surface!

Electrical connection

Connect the product to a grounded outlet/line protected by a fuse of suitable capacity as stated in the "Technical specifications" table. Have the grounding installation made by a qualified electrician while using the product with or without a transformer. Our company shall not be liable for any damages that will arise due to using the product without a grounding

The product must be connected to the mains supply only by an authorised and qualified person. The product's warranty period starts only after correct installation.

Manufacturer shall not be held responsible for damages arising from procedures carried out by unauthorised persons.

The power cable must not be clamped, bent or trapped or

of the product.

replaced by a qualified electrician. Otherwise, there is risk of electric shock, short circuit or fire!

9 | EN
