Beko CS 238021 X, CSA240K21XP Operating Instructions
CS238021X
REFRIGERATOR-FREEZER type I
CHŁODZIARKO-ZAMRAŻARKA typu I
CHLADNIČKA-MRAZNIČKA typu I
CHLADNIČKA-MRAZÁK typu I
FRIZIDERA-FREZER tip I
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses a completely environmentally
friendly refrigerant the R600a (flammable only under certain conditions) you must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, others than the ones recommended by
the manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other than those that might have been
recommended by the manufacturer.
UPOZORNĚNÍ!
Aby byl zajištěn normální provoz vaší chladničky, která používá pro životní prostředí zcela neškodné chladicí
médium R600a (vznětlivé pouze za určitých podmínek), musíte dodržet následující pravidla:
Nebraňte ve volné cirkulaci vzduchu kolem přístroje.
Nepoužívejte mechanická zařízení pro zrychlení odmražení kromě těch, která jsou doporučená výrobcem.
Nelikvidujte chladicí okruh.
Nepoužívejte elektrické spotřebiče uvnitř prostoru pro potraviny kromě těch, která by mohl doporučit výrobce.
VAROVANIE!
Aby sa zabezpečila normálna prevádzka vašej chladničky, ktorá používa úplne ekologicky nezávadné chladivo
R600a (horľavé len pri určitých podmienkach), musíte dodržiavať nasledujúce pravidlá:
Nebráňte voľnej cirkulácii vzduchu okolo spotrebiča.
Nepoužívajte mechanické prístroje na urýchľovanie rozmrazovacieho procesu, iné ako odporúča výrobca.
Neporušujte chladiaci okruh.
Nepoužívajte elektrické spotrebiče vo vnútri pípacieho priestoru potravín, iné ako tie, ktoré odporúčal výrobca.
UWAGA!
Aby zapewnić normalną pracę tej, wykorzystującej całkowicie przyjazny środowisku (łatwopalny tylko w pewnych
warunkach) środek chłodniczy R600a, chłodziarko-zamrażarki, należy przestrzegać następujących zasad:
Nie należy blokować swobodnego przepływu powietrza wokół chłodziarko-zamrażarki.
W celu przyśpieszenia rozmrażania nie należy używać żadnych innych urządzeń mechanicznych niż zalecane
przez producenta.
Nie wolno uszkodzić obwodu chłodniczego.
Wewnątrz komory przechowywania żywności nie należy używać żadnych innych urządzeń elektrycznych niż
ewentualnie zalecanych przez producenta.
UPOZORENJE!
Da biste obezbedili normalan rad Va.eg fri.idera, koji koristi ekolo.ki rashlađivač R600a (a koji je zapaljiv samo
pod određenim okolnostima) morate po.tovati sledeća pravila:
Nemojte ometati slobodan protok vazduha oko uređaja.
Nemojte koristiti druga mehanička sredstva osim onih koje predviđa proizvođač, da biste ubrzali odmrzavanje.
Nemojte uni.titi jedinicu za hlađenje.
Nemojte koristiti električne uređaje u odeljku za čuvanje hrane, osim onih koje preporučuje proizvođač.
Safety first /1
Electrical requirements /2
Transportation instructions /2
Installation instructions /2
Getting to know your appliance /3
Suggested arrangement of food in the appliance /3
Temperature control and adjustment /3
Before operating /4
Storing frozen food /4
Freezing fresh food /4
Making ice cubes /4
Defrosting /5
Changing the illumination lamp /5
Cleaning and care /5
Repositioning the door /6
Do’s and don’ts /6
Energy Consumption /7
Information concerning the noise /8
Troubleshooting /8
Thechnical data /9
Bezpieczeństwo przede wszystkim /10
Podłączenie do zasilania /11
Instrukcja transportu i ustawienia /11
Montaż /11
Zapoznaj się z Twoim urządzeniem /12
Porady dotyczące przechowywania żywności /12
Regulacja temperatury /12
Uruchamianie /13
Porady dotyczące przechowywania
zamrożonej żywności /13
Zużycie energii /13
Mrożenie świeżej żywności /14
Jak robić kostki lodu /14
Odmrażanie /14
Wymiany lampy oświetlenia /14
Czyszczenie urządzenia /15
Zmiana kierunku otwierania drzwi /15
Środki ostrożności w trakcie użytkowania /15
Informacja dotycząca odgłosów /16
Usuwanie usterek /16
Rozmieszczenie żywności /17
Przykłady zastosowań /17
Zalecane ustawienia /17
Odzysk opakowania /18
Odzysk starego urządzenia chłodniczego /18
Charakterystyka techniczna /19
Tabliczka znamionowa /19
Bezpečnosť nadovšetko /20
Elektrické požiadavky /21
Prepravné pokyny /21
Inštalačné pokyny /21
Poznávanie spotrebiča /22
Navrhnuté rozmiestnenie potravín v spotrebiči /22
Riadenie a nastavenie teploty /23
Pred uvedením do prevádzky /23
Skladovanie zmrazených potravín /23
Mrazenie čerstvých potravín /23
Tvorba kociek ľadu /23
Rozmrazovanie /23
Zmena osvetlenia lampy /24
Čistenie a údržba /24
Premiestňovanie dverí /25
Čo sa má a čo sa nesmie robiť /25
Spotreba energie /26
Informácie týkajúce sa zvukov /26
Riešenie problémov /26
Technické údaje /27
Bezpečnost především /28
Elektrické požadavky /29
Pokyny pro transport /29
Pokyny pro instalaci /29
Seznámení s vaším spotřebičem /30
Doporučené rozložení potravin ve spotřebiči /30
Kontrola a nastavení teploty /31
Před spuštěním /31
Ukládání zmrzlých potravin /31
Mražení čerstvých potravin /31
Tvorba kostek ledu /31
Odmrazování /32
Změna osvětlení lampy /32
Čištění a péče /32
Změna pozice dvířek /33
Co dělat a co nedělat /33
Spotřeba energie /34
Informace týkající se hlučnosti /34
Odstraňování potíží /34
Technická data /35
Bezbednost na prvom mestu /36
Neophodne električne instalacije /37
Uputstvo za transport /37
Uputstvo za instaliranje /37
Elementi uređaja /38
Regulacija temperature /38
Pre stavljanja aparata u upotrebu /38
Skladištenje zamrznute hrane /38
Zamrzavanje sveže hrane /39
Pravljenje leda /38
Odmrzavanje /39
Promena osvetljenja lampu /39
Čišćenje i održavanje /39
Potrošnja energije /40
Informacije u vezi sa bukom i vibracijama /40
Smer otvaranja vrata /41
Problemi /41
Tehnički podaci o uređaju /41
SK Index
CZ Obsah
PL Spis treści
GB Index
SR Sadržaj
1
2
3
4 9 5
6
7
8
10
GB Instruction for use
1
This appliance is not intended for use by person with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Congratulations on your choice of a Quality
Appliance, designed to give you many years of service.
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been
removed.
• Leave to stand for at least 12 hours before switching
on, to allow compressor oil to settle, if transported
horizontally.
• If you are discarding an old appliance with a lock or
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the
insulation which are flammable. We suggest you
contact your local authority for information on disposal
and available facilities.
• We do not recommend use of this appliance in an
unheated, cold room. (e.g. garage, conservatory,
annex, shed, out-house etc.)
To obtain the best possible performance and trouble
free operation from your appliance it is very important to
read these instructions carefully. Failure to observe
these instructions may invalidate your right to free
service during the guarantee period.
Please keep these instructions in a safe place for easy
reference.
GB Instruction for use
Electrical requirements
Before inserting the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating plate inside the appliance
corresponds to your electricity supply.
We recommend that this appliance is
connected to the mains supply via a suitably
switched and fused socket in a readily
accessible position.
Warning! This appliance must be earthed.
Repairs to electrical equipment should only be
performed by a qualified technician. Incorrect
repairs carried out by an unqualified person
are carry risks that may have critical
consequences for the user of the appliance.
ATTENTION!
This appliance operates with R600a which is
an environmental friendly but flammable gas.
During the transportation and fixing of the
product, care must be taken not to damage
the cooling system. If the cooling system is
damaged and there is a gas leakage from the
system, keep the product away from open
flame sources and ventilate the room for a
while.
WARNING - Do not use mechanical devices
or other means to accelerate the defrosting
process, others than those recommended by
the manufacturer.
WARNING - Do not damage the refrigerant
circuit.
WARNING - Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
WARNING - If the supply cord is damaged, it
must be replaced by the manufacturer, its
service agent or similarly qualified persons in
order to avoid a hazard.
Transportation instructions
1. The appliance should be transported only in
an upright position. The packing as supplied
must be intact during transportation.
2. If during the transport the appliance, has
been positioned horizontally, it must not be
operated for at least 12 hours, to allow the
system to settle.
3. Failure to comply with the above
instructions could result in damage to the
appliance, for which the manufacturer will not
be held liable.
4. The appliance must be protected against
rain, moisture and other atmospheric
influences.
Important!
• Care must be taken while cleaning/carrying
the appliance not to touch the bottom of the
condenser metal wires at the back of the
appliance, as this could cause injury to fingers
and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use.
You could injure yourself or damage the
appliance.
• Make sure that the mains cable is not caught
under the appliance during and after moving,
as this could damage the cable.
• Do not allow children to play with the
appliance or tamper with the controls.
Installation instructions
1. Do not keep your appliance in a room
where the temperature is likely to fall below 10
degrees C (50 degrees F) at night and/or
especially in winter, as it is designed to
operate in ambient temperatures between +10
and +38 degrees C (50 and 100 degrees F).
At lower temperatures the appliance may not
operate, resulting in a reduction in the storage
life of the food.
2. Do not place the appliance near cookers or
radiators or in direct sunlight, as this will
cause extra strain on the appliance's
functions. If installed next to a source of heat
or freezer, maintain the following minimum
side clearances:
From Cookers 30 mm
From Radiators 300 mm
From Freezers 25 mm
3. Make sure that sufficient room is provided
around the appliance to ensure free air
circulation (Item 2).
• Put the back airing lid to the back of your
refrigerator to set the distance between the
refrigerator and the wall (Item 3).
2
GB Instruction for use
4. The appliance should be positioned on a
smooth surface. The two front feet can be
adjusted as required.To ensure that your
appliance is standing upright adjust the two
front feet by turning clockwise or anticlockwise, until firm contact is secured with
the floor. Correct adjustment of feet prevents
excessive vibration and noise (Item 4).
5. Refer to "Cleaning and Care" section to
prepare your appliance for use.
Getting to know your appliance
(Item 1)
1 - Thermostat and lamp housing
2 - Adjustable Cabinet shelves
3 - Wine bottles support
4 - Water collector
5 - Crisper cover
6 - Crispers
7 - Ice tray support & ice tray
8 - Compartment for quickly freezing
9 - Compartments for frozen froods keeping
10 - Adjustable foot
11 - Dairy Compartment
12 - Shelf for jars
13 - Keeping cup
14 - Shelf for bottles
Suggested arrangement of food in
the appliance
Guidelines for obtaining optimum storage and
hygiene:
1. The fridge compartment is for the short-term
storage of fresh food and drinks.
2. The freezer compartment is rated
and suitable for the freezing and storage of
pre-frozen food.
The recommendation for storage as
stated on the food packaging should be
observed at all times.
3. Dairy products should be stored in the
special compartment provided in the door liner.
4. Cooked dishes should be stored in airtight
containers.
5. Fresh wrapped produce can be kept on the
shelf. Fresh fruit and vegetables should be
cleaned and stored in the crispers.
6. Bottles can be kept in the door section.
7. To store raw meat, wrap in polythene bags
and place on the lowest shelf. Do not allow to
come into contact with cooked food, to avoid
contamination. For safety, only store raw meat
for two to three days.
8. For maximum efficiency, the removable
shelves should not be covered with paper or
other materials to allow free circulation of cool
air.
9. Do not keep vegetable oil on door shelves.
Keep the food packed, wrapped or covered.
Allow hot food and beverages to cool before
refrigerating. Leftover canned food should not
be stored in the can.
10. Fizzy drinks should not be frozen and
products such as flavoured water ices should
not be consumed too cold.
11. Some fruit and vegetables suffer damage if
kept at temperatures near 0°C. Therefore wrap
pineapples, melons, cucumbers, tomatoes and
similar produce in polythene bags.
12. High-proof alcohol must be stored upright in
tightly closed containers. Never store products
that contain an inflammable propellant gas (e.g.
cream dispensers, spray cans, etc.) or explosive
substances. These are an explosion hazard.
13. To take out the baskets from the freezer
compartment please proceed as in Item 9.
3
GB Instruction for use
Temperature control and adjustment
Operating temperatures are controlled by the
thermostat knob (Item 5) and may be set at
any position between MIN and MAX (the
coldest position).
The average temperature inside the fridge
should be around +5°C (+41°F).
Therefore adjust the thermostat to obtain the
desired temperature. Some sections of the
fridge may be cooler or warmer (such as
salad crisper and top part of the cabinet)
which is quite normal. We recommend that
you check the temperature periodically with a
thermometer to ensure that the cabinet is kept
to this temperature. Frequent door openings
cause internal temperatures to rise, so it is
advisable to close the door as soon as
possible after use.
Before operating
Final Check
Before you start using the appliance check
that:
1. The feet have been adjusted for perfect
levelling.
2. The interior is dry and air can circulate
freely at the rear.
3. The interior is clean as recommended
under "Cleaning and care.”
4. The plug has been inserted into the wall
socket and the electricity is switched on.
When the door is open the interior light will
come on.
And note that:
5. You will hear a noise as the compressor
starts up. The liquid and gases sealed within
the refrigeration system may also make some
(noise), whether the compressor is running or
not. This is quite normal.
6. Slight undulation of the top of the cabinet is
quite normal due to the manufacturing
process used; it is not a defect.
7. We recommend setting the thermostat knob
midway and monitor the temperature to
ensure the appliance maintains desired
storage temperatures (See section
Temperature Control and Adjustment).
8. Do not load the appliance immediately it is
switched on. Wait until the correct storage
temperature has been reached. We
recommend checking the temperature with an
accurate thermometer (see; Temperature
Control and Adjustment).
Storing frozen food
Your freezer is suitable for the long-term
storage of commercially frozen foods and also
can be used to freeze and store fresh food.
If there is a power failure, do not open the
door. Frozen food should not be affected if the
failure lasts for less than 18 hrs. If the failure
is longer, then the food should be checked
and either eaten immediately or cooked and
then re-frozen.
Freezing fresh food
Please observe the following instructions to
obtain the best results.
Do not freeze too large a quantity at any one
time. The quality of the food is best preserved
when it is frozen right through to the core as
quickly as possible.
Do not exceed the freezing capacity of your
appliance in 24 h.
Placing warm food into the freezer
compartment causes the refrigeration
machine to operate continously until the food
is frozen solid. This can temporarily lead to
excessive cooling of the refrigeration
compartment.
When freezing fresh food, keep the
thermostat knob at medium position. Small
quantities of food up to 1/2 kg. (1 lb) can be
frozen without adjusting the temperature
control knob.
Take special care not to mix already frozen
food and fresh food.
Making ice cubes
Fill the ice - cube tray 3/4 full with water and
place it in the freezer. Loosen frozen trays
with a spoon handle or a similar implement;
never use sharp-edged objects such as
knives or forks.
4
GB Instruction for use
Defrosting
A) Fridge compartment
The fridge compartment defrosts
automatically. The defrost water runs to the
drain tube via a collection container at the
back of the appliance (Item 6).
During defrosting, water droplets may form at
the back of the fridge compartment where a
concealed evaporator is located. Some
droplets may remain on the liner and refreeze
when defrosting is completed. Do not use
pointed or sharp-edged objects such as
knives or forks to remove the droplets which
have refrozen.
If, at any time, the defrost water does not
drain from the collection channel, check that
no food particles have blocked the drain tube.
The drain tube can be cleared with a pipecleaner or similar implement.
Check that the tube is permanently placed with
its end in the collecting tray on the compressor
to prevent the water spilling on the electric
installation or on the floor (Item 7).
B) Freezer compartment
Defrosting is very straightforward and without
mess, thanks to a special defrost collection
basin.
Defrost twice a year or when a frost layer of
around 7 (1/4") mm has formed. To start the
defrosting procedure, switch off the appliance
at the socket outlet and pull out the mains
plug.
All food should be wrapped in several layers
of newspaper and stored in a cool place (e.g.
fridge or larder).
Containers of warm water may be placed
carefully in the freezer to speed up the
defrosting.
Do not use pointed or sharp-edged
objects, such as knives or forks to remove
the frost.
Never use hairdryers, electrical heaters or
other such electrical appliances for defrosting.
Sponge out the defrost water collected in the
bottom of the freezer compartment. After
defrosting, dry the interior thoroughly (Item 8).
Insert the plug into the wall socket and switch
on the electricity supply.
Changing the illumination lamp
To change the lamp used for illumination of
your refrigerator, please call your Authorized
Service.
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outlet and pull out the
mains plug before cleaning.
2. Never use any sharp instruments or
abrasive substances, soap, household
cleaner, detergent or wax polish for cleaning.
3. Use luke warm water to clean the cabinet
of the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution
of one teaspoon of bicarbonate of soda to one
pint of water to clean the interior and wipe it
dry.
5. Make sure that no water enters the
temperature control box.
6. If the appliance is not going to be used for
a long period of time, switch it off, remove all
food, clean it and leave the door ajar.
7. We recommend that you polish the metal
parts of the product (i.e. door exterior, cabinet
sides) with a silicone wax (car polish) to
protect the high quality paint finish.
8. Any dust that gathers on the condenser,
which is located at the back of the appliance,
should be removed once a year with a
vacuum cleaner.
9. Check door seals regularly to ensure they
areclean and free from food particles.
10. Never:
• Clean the appliance with unsuitable material;
eg petroleum based products.
• Subject it to high temperatures in any way,
• Scour, rub etc., with abrasive material.
11. Removal of dairy cover and door tray :
• To remove the dairy cover, first lift the cover
up by about an inch and pull it off from the
side where there is an opening on the cover.
• To remove a door tray, remove all the
contents and then simply push the door tray
upwards from the base.
5
GB Instruction for use
12. Make sure that the special plastic
container at the back of the appliance which
collects defrost water is clean at all times. If
you want to remove the tray to clean it, follow
the instructions below:
• Switch off at the socket outlet and pull out
the mains plug
• Gently uncrimp the stud on the compressor,
using a pair of pliers, so that the tray can be
removed
• Lift it up.
• Clean and wipe it dry
• Reassemble, reversing the sequence and
operations
13. To remove a drawer, pull it as far as
possible, tilt it upwards and then pull it out
completely.
Repositioning the door
Proceed in numerical order (Item 10).
Do’s and don’ts
Do- Clean and defrost your appliance regularly
(See "Defrosting")
Do- Keep raw meat and poultry below cooked
food and dairy products.
Do- Take off any unusable leaves on
vegetables and wipe off any soil.
Do- Leave lettuce, cabbage, parsley and
cauliflower on the stem.
Do- Wrap cheese firstly in greaseproof paper
and then in a polythene bag, excluding as
much air as possible. For best results, take
out of the fridge compartment an hour
before eating.
Do- Wrap raw meat and poultry loosely in
polythene or aluminium foil. This prevents
drying.
Do- Wrap fish and offal in polythene bags.
Do- Wrap food with a strong odour or which
may dry out, in polythene bags, or
aluminium foil or place in airtight container.
Do- Wrap bread well to keep it fresh.
Do- Chill white wines, beer, lager and mineral
water before serving.
Do- Check contents of the freezer every so
often.
Do- Keep food for as short a time as possible
and adhere to "Best Before" and "Use by"
etc. dates.
Do- Store commercially frozen food in
accordance with the instructions given on
the packets.
Do- Always choose high quality fresh food and
be sure it is thoroughly clean before you
freeze it.
Do- Prepare fresh food for freezing in small
portions to ensure rapid freezing.
Do- Wrap all food in aluminium foil or freezer
quality polythene bags and make sure any
air is excluded.
Do- Wrap frozen food immediately after
purchasing and put it in to the freezer as
soon as possible.
Do- Defrost food in the fridge compartment.
6
Don’t- Store bananas in your fridge
compartment.
Don’t- Store melon in your fridge. It can be
chilled for short periods as long as it is
wrapped to prevent it flavouring other
food.
Don’t- Cover the shelves with any protective
materials which may obstruct air
circulation.
Don’t- Store poisonous or any dangerous
substances in your appliance. It has
been designed for the storage of edible
foodstuffs only.
Don’t- Consume food which has been
refrigerated for an excessive length of
time.
Don’t- Store cooked and fresh food together
in the same container. They should be
packaged and stored separately.
Don’t- Let defrosting food or food juices drip
onto food.
Don’t- Leave the door open for long periods,
as this will make the appliance more
costly to run and cause excessive ice
formation.
Don’t- Use sharp edged objects such as
knives or forks to remove the ice.
Don’t- Put hot food into the appliance. Let it
cool down first.
Don’t- Put liquid-filled bottles or sealed cans
containing carbonated liquids into the
freezer, as they may burst.
Don’t- Exceed the maximum freezing loads
when freezing fresh food.
Don’t- Give children ice-cream and water ices
direct from the freezer. The low
temperature may cause 'freezer burns'
on lips.
Don’t- Freeze fizzy drinks.
Don’t- Try to keep frozen food which has
thawed; it should be eaten within 24
hours or cooked and refrozen.
Don’t- Remove items from the freezer with
wet hands.
GB Instruction for use
7
Energy Consumption
Maximum frozen food storage volume is
achieved without using the middle drawer and
the upper shelf cover provided in the freezer
compartment. Energy consumption of your
appliance is declared while the freezer
compartment is fully loaded without the use of
the middle drawer and upper shelf cover.
Practical advice concerning the reduction of
the electricity consumption
1. Make sure that the appliance is located in
well-ventilated areas, far from any source of
heat (cooker, radiator etc.). At the same time,
the location of the appliance must be done in
such a way that it prevents it to be under the
direct incidence of the sunbeams.
2. Make sure that the food purchased in
refrigerated/frozen condition is placed into the
appliance as soon as possible, especially during
summertime. It is recommended to use thermal
insulated bags to transport the food home.
3. We recommend the thawing of the packets
taken out from the freezer compartment be
done in the refrigerator compartment. For this
purpose, the packet which is going to be thawed
will be placed in a vessel so that the water
resulting from the thawing does not leak in the
refrigerator compartment. We recommend you
to start the thawing at least 24 hours before the
use of the frozen food.
4. We recommend reducing the number of door
openings to the minimum.
5. Do not keep the door of the appliance open
more than necessary and make sure that after
each opening the door is well closed.
Troubleshooting
If the appliance does not operate when
switched on, check;
• That the plug is inserted properly in the
socket and that the power supply is on. (To
check the power supply to the socket, plug
in another appliance)
• Whether the fuse has blown/circuit breaker
has tripped/main distribution switch has
been turned off.
• That the temperature control has been set
correctly.
• That the new plug is wired correctly, if you
have changed the fitted, moulded plug.
If the appliance is still not operating at all after
above checks, contact the dealer from whom
you purchased the unit.
Please ensure that above checks have been
done, as a charge will be made if no fault is
found.
GB Instruction for use
8
Information concerning the noise
and the vibrations which might
appear during the operation of the
appliance
1. The operation noise can increase during the
operation.
- In order to keep the temperatures at the
adjusted temperatures, the compressor of the
appliance starts periodically. The noise
produced by the compressor becomes stronger
when it starts and a click can be heard when it
stops.
- The performance and operation features of the
appliance can change according to the
modifications of the temperature of the ambient
environment. They must be considered as
normal.
2. Noises like liquids flowing or as being
sprayed
- These noises are caused by the flow of the
refrigerant in the circuit of the appliance and
comply with the operation principle of the
appliance.
3. Other vibrations and noises.
- The level of noise and vibrations can be
caused by the type and the aspect of the floor
on which the appliance is placed. Make sure
that the floor does not have significant level
distortions or if it can yield to the weight of the
appliance (it is flexible).
- Another source of noise and vibrations is
represented by the objects placed on the
appliance. These objects must be removed from
the appliance
- The bottles and the vessels placed in the
refrigerator touching each other. In such cases
move the bottles and the vessels so that there is
a small distance between them.
Brand
Appliance type
REFRIGERATOR-FREEZER type I
CS238021X
Total gross volume (l.)
359
Total usable volume (l.)
334
Freezer - usable volume (l.)
90
Refrigerator - useful volume
244
Freezing capacity (kg/24 h)
5
Energy class (1)
A+
Power consumption (kWh/year) (2)
281
Autonomy (h)
18
Noise [dB(A) re 1 pW]
39
Weight (kg)
64
Dimensions (cm)
201x59,5x60
Ecological refrigerating agent R600a
(1) Energy class: A+++ . . . D (A+++ = economical . . . D = less economical)
(2) The real power consumption depends on using conditions and appliance location.
PRODUCT NUMBER
7508320041
MODEL
CS238021X
REFRIGERATOR-FREEZER type I
Class SN-ST
TOTAL GROSS/USABLE VOLUME
359/334 l
FRIGE USABLE VOLUME
244 l
FREEZER USABLE VOLUME
90 l
FREEZING CAPACITY
5 Kg/24 hr
REFRIGERANT R 600a
0,056 kg
BLOWING AGENT C5 H10
COMPRESSOR
220-240V ~ 50 Hz
120 W/0,60 A
9
The symbol on the product or on packaging indicates that this product may not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city office, you household
waste disposal service or the shop where you purchased the product.
GB Instruction for use
Technical data
PL Instrukcja obsługi
10
Używanie urządzenia przez osoby z fizycznymi sensorycznymi lub mentalnymi
ograniczeniami powinno odbywać się tylko pod kontrolą osób odpowiedzialnych za
ich bezpieczeństwo.
Należy dopilnować, aby dzieci nie używały urządzenia do zabawy.
Gratulujemy dokonania mądrego wyboru!
BEKO to jedna z wiodących marek sprzętu AGD w
Europie. Produkty naszej marki to dla konsumentów w
ponad 100 krajach synonim funkcjonalności,
niezawodności i przystępnej ceny. Obecnie już ponad 250
milionów użytkowników urządzeń potwierdza,
że był to mądry wybór.
Bezpieczeństwo przede wszystkim
Opisana tu chłodziarko-zamrażarka jest najnowszym
modelem urządzeń chłodniczych wchodzących
w skład serii produktów .
Została ona zaprojektowana i wyprodukowana zgodnie z
międzynarodowymi normami. Przed przystąpieniem do
użytkowania prosimy zapoznać się uważnie z instrukcją
obsługi. Zastosowanie się do poniższych zaleceń
zagwarantuje uzyskanie optymalnego zużycia energii
elektrycznej i zapewnieni bezpieczeństwo eksploatacji oraz
uchroni przed powstaniem przypadkowych uszkodzeń.
Ostrzeżenie!
Urządzenie to może być użytkowane wyłącznie zgodnie z
przeznaczeniem, dla którego zostało wyprodukowane.
Urządzenie należy instalować w miejscu o odpowiednich
wymiarach oraz nie narażonym na działanie deszczu,
wilgoci itd.
Ważne!
Producent nie będzie ponosić odpowiedzialności za szkody
wynikłe z niestosowania się do zaleceń zawartych w
instrukcji obsługi. Instrukcję obsługi należy przechowywać w
bezpiecznym miejscu tak, aby można było z niej korzystać w
razie konieczności. Może być ona przydatna również dla
innego użytkownika.
Loading...
