Vacuum Cleaner
User Manual
BKS 2125
Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully before using the product and keep it
as a reference for future use. If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models. Differences between models
will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful hints
C
A
about usage.
Warning for hazardous situations with
regard to life and property.
B
Warning for electric shock.
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations.
Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.
TABLE OF CONTENTS
1 Important instructions for safety and
environment 3
2 Technical aspects of your machine 4
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3 How to use 5-8
3.1 Dust indicator. . . . . . . . . . . . . . . . . . . . . . 5-6
3.2 How to use the extention pipe . . . . . . . . . . . .7
3.3 How to use the accessories . . . . . . . . . . . . .7
3.3.1 Crevice tool . . . . . . . . . . . . . . . . . . . . .7
3.3.2 Upholstery brush . . . . . . . . . . . . . . . . . . .7
3.4 How to use the parquet, carpet brush . . . . . .7
3.5 Turning off and parking. . . . . . . . . . . . . . . 7-8
3.6 Cloth dust bag . . . . . . . . . . . . . . . . . . . . . . . 8
4 How to clean 9-10
4.1 You can clean cloth dust bags as fallows . . . .9
4.2 How to clean the motor filter . . . . . . . . . . . . .9
4.3 Taking off the exhaust cover and exhaust
filters. . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Vacuum Cleaner / User's Manual
2 / 10 EN
1 Important instructions for safety and environment
Basic safety Precautions should always be followed
when using electrical appliances including the
following :
1. If the voltage written under the label of your
vacuum cleaner is appropriate with the mains
voltage in your house; you can use your vacuum
cleaner. Otherwise motor may burn.
2. Do not leave your vacuuzm cleaner plugged.
Unplug it when you do not use or when service
is necessary.
3. Do not use your vacuum cleaner on wet surfaces and outside the house.
4. This appliance is not intended for use by
persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that
they do not play with the appliance.
5. If the power cord or plug is damaged, any drop
or fall occured, left outside, get wet or your
device is not working; consult to authorized
services.
6. Do not carry your device by pulling from its
cable. Protect the cable from sharp edges, hot
surfaces and be careful to not to closely pressed
between a door and a door frame.
7. Do not unplug it by pulling from its cord. Unplug
it by holding from the plug.
8. Do not touch the plug or the device with wet
hands.
9. Do not drop any objects in to any open parts
of your device. Make sure that the air passage
holes and channels are open.
10. Keep your hands and hair away from the working parts of the machine.
11. Do not use your vacuum cleaner to clean flammable objects such as cigarettes, matches, hot
ashes.
12. Do not use your vacuum cleaner without a
paper filter or other filters are attached.
13. Turn on all of the control buttons on your
vacuum cleaner before unpluging.
14. Do not vacuum burnable or flammable liquids.
Do not use your device where these kinds of
liquids exist.
15. Unplug it when attaching or changing the accessories delivered with your vacuum cleaner.
16. Do not operate your vacuum cleaner while
keeping it vertical.
17. Small pieces of dust may cause clog of dust
bag. This will terminate the air passage from
the dust bag. In this case the dust bag must be
changed altough the dust bag is not completely
filled.
3 / 10 EN
Vacuum Cleaner / User's Manual
2 Technical aspects of your machine
2.1 Overview
2
3
4
1
5
6
7
10
9
8
17
18
19
20 21
15
11
12
1- Plug and the power cord
2- Brush parking area
3- Cable twisting button
4- On-Off button with power variator
5- Carrying handle
6- Blue indicator light
7- Vacuum control button
8- Dust indicator
9- Front cover
10- Hose inlet
11- Exhaust filter area
12- Wheel
13- Body protection rubber
14- Front cover opening pin
15- 360 degrees turnable hose adaptor
16- Elastic hose
17- Handle
13
14
16
26
22
23
25
24
27
18- Air control slide
19- Telescobic extention pipe
20- Upholstery brush
21- Crevice tool
22- Accessories carrying piece
23- Telescobic control pin
24- Dust brush
25- Brush park projection
26- Brush control pin
27- Parquet carpet brush
Max. Power : 2500 W
Net weight : 6.6 kg
Voltage and frequency : 220-240V AC 50 Hz
Dust volume : 4 lt
Usage radius : 9 m
Filtration layer : 7 levels
Values stated on your product labels or in the documentation accompanying it are obtained in laboratory in accordance with the
relevant standards. These values may change depending on operational and environmental conditions of the product.
Vacuum Cleaner / User's Manual
4 / 10 EN
3 How to use
Pull the plug and the cable located at the back,
outside; plug it. Stop pulling when you see the
yellow sign on the cable, red sign comes after
yellow sign, never pull when you see the red sign.
Otherwise you may give harm to the cable twister
of your product.
Push the on-off button with power variator in order
to operate your vacuum cleaner. When the on-off
button with power variator is pushed, the blue
indicator light around the vacuum control button
will be on.
Push the cable twister button on the device in
order to twist the cable after the operation of the
vacuum cleaner is finished. Do not step on the
cable twister button. The mechanism may receive
harm in case of stepping onto it strongly.
You can control the vacuum power of your product
with the vacuum power control button located on
the body of your device while operating.
Note: If your carpet brush sticks to your carpet because of the high vacuum power of your product,
you may decrase the vacuum power by this button.
You may reduce the vacuum power a little bit
without using the vacuum power control on your
product, by pulling the slide back when you want,
using the air control slide on the handle.
Do not clean by rubbing the edge of the handle to
carpets and coaches, otherwise the edge will melt
and can not be used anymore. Use the brushes
and accessories delivered with your product for
cleaning.
3.1 Dust indicator
It shows the fullness proportion of your dust bag.
If the indicator shows the red position more than
%50, then it means that the changing time of
the dust bag has arrived. The dust bag must be
changed altough dust is not collected fully in the
dust bag, if slight pieces of dust is filled the pores
of the dust bag. If the indicator shows fully red,
change the bag immedeately, otherwise the motor
protector termostate will operate to terminate your
product and your product will not work for 30 minutes. In this case change the dust bag, wait your
product to get cold and then operate.
Dust indicator
5 / 10 EN
Vacuum Cleaner / User's Manual
3 How to use
If you preferred to use a cloth filter, empty the
cloth bag and wash in warm water when the dust
indicator shows red. You may use soap when
you wash the cloth bag. The cloth bag should be
inserted into its place after it is dried for 24 hours.
While you are inserting the cloth bag into its place
make sure that no space is left on the backside
and fully closed, otherwise dusts may escape into
your motor and cause harm.
Picture 1
You can carry your product by holding from its handle. If you want to carry it vertically hold it from the
cavity area for carrying located below the product.
The sides and the wheels of your product is
covered with protective rubber against crashes. By
this way, straching your product and harming your
furnitures are prevented.
Picture 2
The hose adaptor of your product has a property
of turning 360 degrees. By this property it provides
an ergonomic usage during cleaning.
You can attach the hose adaptor by pushing the
hose adaptor in the direction of the arrow without
pushing the nails as shown in picture 1. Make sure
that the nails on the hose adaptor are fitted into
their places as shown in picture 2.
Push the bails on the hose adaptor and pull it
backwards in order to take the hose adaptor out of
the vacuum cleaner.
Vacuum Cleaner / User's Manual
6 / 10 EN
3 How to use
3.2 How to use the extention pipe
The extention pipe of your product has telescobic
property. In order to extent the pipe, push the pin
shown in the picture and pull it from the edge by
your hand. You may arrange its lenght as you wish.
Pin
3.3 How to use the accessories
There is an accessories carrying adaptor on the
extention pipe. You can use 2 of the accessorieses
you wish by attaching on it. If you don’t want to use
this adaptor, you can take its screw with a screw
driver and take the piece out of the telescobic
extention pipe.
3.3.1 Crevice tool
It can be used in crevice places such
as interiors of furnitures and coaches.
3.3.2 Upholstery brush
It can be used to clean floor
coverings, steps, inside of your
car, coaches, furniture, etc.
3.4 How to use the parquet, carpet brush
There is a control mechanism on the left side
of the parquet carpet brush. By the help of this
control mechanism the brush is brought into the
desired conditions suitable for the surface to be
cleaned.
a. In order to clean the rugs and the carpets, use
your brush in normal condition. (Hair brushes are
hidden.)
b. In order to clean hard floor coverings such as
parquet, vinyl floor covering, linoleum and flat
surfaces such as walls without scrating, change
the position of the control mechanism and clean on
the hair brushes.
Warning: The carpet brush may stick to your
carpet closely since the vacuum power of your
vacuum cleaner is very high. For this reason it may
cause exhausting arm and back aches. In order not
to face such a problem, reduce the vacuum power
of the product.
3.5 Turning off and parking
The operation of the vacuum cleaner is stopped by
pushing on the on-off button with power variator
located on the body.
Do not unplug it immedeately in order to stop the
operation of your product, first push the on-off
button with power variator to stop the operation of
the product.
7 / 10 EN
3.3.3 Dust brush
Dust brush is used for taking
the dusts of fragile objects and
curtains.
Vacuum Cleaner / User's Manual
3 How to use
You can park your vacuum
cleaner in two different ways:
vertical and horizantal. You can
attach the brushes parking place
in to the parking socket at the
back of the product in order to
park vertically.
Also you can attach the parking place at the back
of your brush into the parking socket located at the
back of your product and park horizontally.
Change your dust bag when the dust indicator
glows red or if the vacuum power of your vacuum
cleaner is not at the desired level. In order to
change the dust bag, first open the front cover by
lifting the pin located in the front. After opening,
take it out by sliding it up over the cradle where full
dust bag is located. The cover will not be closed
before a new dust bag is inserted. Please do not
force to close the cover otherwise plastic sections
may harm.
3.6 Cloth dust bag
If you use cloth dust bags instead of paper, you
may empty it and reuse for many times. If the dust
bag in your device is cloth then take the bag out as
explained in “changing the paper filter”.
Cloth filter clips
Warning: The dust bags purchased from unauthorised places other than services and dealers are
not original. The dust bags which are not original
are at very low quality. For this reason they are torn
in a short time and your product becomes useless.
For the breakdowns stemmed from using fake dust
bags are considered out of warranty.
Vacuum Cleaner / User's Manual
8 / 10 EN
4 How to clean
4.1 You can clean cloth dust bags as follows:
• Hold the dust bag over a dust bin upside down.
Take the clips off by pushing to the side.
• Wash the cloth bag in warm water by hand. After
washing, leave it to dry and never use before it is
completely dried.
• Close the bag by pushing the clips on the lower
edge of the bag.
If you are using a cloth bag we recommend you to
change the motor filter once a year.
4.2 How to clean the motor filter
When the motor protection filter is extremely
dusted, take it out and clean.
Also take the motor protection filter out and shake
every time when the dust bag is changed. Buy
a new motor protection filter from the service
and change once in every 5 paper filter change.
Otherwise filter looses its effection since it finishes
its usage life. On the other hand it may cause
the motor to work louder and live shorter. Motor
protection filter does not have a property such as
being washed, it looses its effects when washed
and causes the motor to be harmed.
4.3 Taking off the exhaust cover and exhaust
filters
On every fifth change of dust bag, with the change
of motor protection filter; open the exhaust cover at
the back where the air gets out of your product, by
pushing on the pin as shown in the picture in order
to take the hepa filter and sponge filter located
inside.
Filter casette
9 / 10 EN
Motor protection
filter
Hepa filter
Sponge filter
Wash the hepa filter and the sponge filter in warm
water and leave them to dry for 24 hours.
Attention! Do not use devices such as hair dryers
or stoves which give hot air out in order to dry.
Vacuum Cleaner / User's Manual
4 How to clean
Do not insert the hepa filter and sponge into their
places before they are completely dried, otherwise
humidity odour may be delivered, water splash may
occur at the backside and filters may be harmed.
Vacuum Cleaner / User's Manual
10 / 10 EN
www.beko.com
Loading...
