Behringer CE500D User Manual

Product Information Document
Install
CE500D
High-Performance, Active 100-Watt Commercial Installed Sound Speaker
Multi-purpose, 100-Watt,
active speaker for commercial sound applications
Perfect for restaurants, shops,
exhibitions, multimedia, home recording and A/V production
Exceptional sound quality, wide
dynamic range and ultra-linear frequency range
Revolutionary Class-D amplier
technology: enormous power and incredible sonic performance
Powerful 5 ½" woofer with extremely
light-weight cellulose cone and high-resolution ½" tweeter
Ultra-low noise mic/line input with
volume control and peak LED
Additional line output connector
allows linking of additional speaker systems
The CE500D active loudspeaker
system is ideal for business
environments, letting you enjoy full,
clear sound over a wide listening area.
Specically designed to complement
indoor commercial facilities, such as
restaurants, shops, exhibition halls and
more, the 100-Watt CE500D comes
equipped with special mounting
brackets so they can be placed on
walls, or suspended from above to
meet your coverage requirements.
Integrated limiter for
ultimate system control and speaker protection
Ultra-exible and heavy-duty
wall-mount bracket included
Internal switch-mode power supply
(100 - 240 V~) for noise-free audio and low power consumption
3-Year Warranty Program*
Designed and engineered
in Germany
*Warrant y details can be fo und at musictri. be.
Class-D – Massive Power, Perfect Sound
Thanks to our revolutionary Class-D amplier technology, the CE500D provides enormous power and incredible sonic performance in an easy-to-use and lightweight package. Class-D amplication makes all the dierence, oering the ultimate in energy eciency and eliminating the need for heavy power supplies and massive heat sinks. This amazing technology makes it possible to design and build extremely powerful products that are signicantly lighter in weight than their traditional counterparts, while using less energy and protecting the environment.
Product Information Document
Install
CE500D
High-Performance, Active 100-Watt Commercial Installed Sound Speaker
Custom-Engineered Transducers
Powerful ampliers coupled with state-of-the-art technology sure sounds impressive – but what about the part of the system you actually hear? We never cut corners on our transducers (woofers and tweeters), and we never just pull what we have o the shelf. Our LF (Low Frequency) and HF (High Frequency) transducers are designed specically for each application – it’s what sets us apart from the competition. When you buy a CE500D, you can rest assured the transducers inside have been engineered to perform awlessly with every other element for truly professional results. As a result, the CE500D provides ruler-at frequency response from 60 Hz – 20 kHz, with tight and accurate low end, articulately-detailed mids and crystal-clear highs.
Serious Connections
Connecting the CE500D is ultra-easy thanks to the convenient rear panel, which provides a standard XLR Mic Input and ⁄" jacks for connecting a mixer, computer, or even an mp3 deck. To raise and lower the mic volume, just turn the Level control (⁄" input levels are controlled by the source device). To run two CE500Ds in stereo mode, simply connect your stereo playback device's output jack to an stereo splitting adapter and connect one loudspeaker to the right and the other to the left output from the adapter. You can even chain together as many CE500Ds as you’d like via the handy Link XLR Output – all you need is a standard mic cable.
Instant PA System
You don’t even need a mixer to use the CE500D – just provide operating power, connect a microphone and start talking. Sometimes that’s all you need; the CE500D is like having your very own personal 100-Watt megaphone!
2 of 9
Product Information Document
Install
CE500D
High-Performance, Active 100-Watt Commercial Installed Sound Speaker
Sound Value
Whether you need speakers for the conference room, the waiting room or the dining area, the 100-Watt CE500D will elevate your company status – and get your message across in style. Visit your local BEHRINGER dealer, or get yours online today!
You Are Covered
We always strive to provide the best possible Customer Experience. Our products are made in our own MUSIC Tribe factory using state-of-the-art automation, enhanced production workows and quality assurance labs with the most sophisticated test equipment available in the world. As a result, we have one of the lowest product failure rates in the industry, and we condently back it up with a generous Warranty program.
3 of 9
