BECKHOFF CP32xx User Manual

Installation and Operating instructions for

CP32xx

Multi-touch Panel PC

Version: 1.3
Date: 2015-02-17

Table of contents

Table of contents

1 Foreword 3

1.1 Notes on the Documentation 3

1.1.1 Liability Conditions 3

1.1.2 Trademarks 3

1.1.3 Patent Pending 3

1.1.4 Copyright 3

1.1.5 State at Delivery 3

1.1.6 Delivery conditions 3

1.2 Description of safety symbols 4

1.3 Basic safety measures 5

1.4 Operator’s obligation to exercise diligence 6

1.4.1 National regulations 6

1.4.2 Procedure in the event of a fault 6

1.4.3 Operator requirements 6

2 Product Description 7

2.1 Product overview 7

2.2 Appropriate Use 8

2.3 Access to the connectors 8

2.4 Access to the hard disk and battery 9

2.4.1 Removing the Cover 9

2.5 Connections 11

2.5.1 Power Supply (X101) 11

2.5.2 Network Interfaces (X102, X103) 12

2.5.3 Additional interfaces (optional) 12

2.5.4 Protective Earthing 12

2.6 Connection Cables 13

2.6.1 Connection Cables for the Power Supply, optional 13

2.6.2 Ethernet connection cables, optional 13

3 Installation 14

3.1 Transport and Unpacking 14

3.1.1 Transport 14

3.1.2 Unpacking 14

4 Mounting 15

4.1 Mounting arm adapter 15

4.2 Mounting the mounting arm tube 16

4.3 Power Supply of the Industrial PC 17

CP32xx 1

Table of contents

4.3.1 Beckhoff power supply technology 17

4.4 Connecting Power Supply 19

4.4.1 Cable Cross Sections 19

4.4.2 Check voltage rating and connect 19

4.4.3 Configuration for shutting down the PC 19

4.4.4 PC_ON and Power Status functions 19

4.4.5 Wiring diagram 20

4.5 Connecting the Panel PC 21

4.5.1 Connecting cables 21

4.5.2 Earthing measures 21

5 Operating Instructions 22

5.1 Switching the Panel PC on and off 22

5.1.1 Switching on 22

5.1.2 Shutting down and switching off 22

5.1.3 First switching on and driver installation 22

5.2 Operation 22

5.3 Servicing and maintenance 23

5.3.1 Cleaning 23

5.3.2 Maintenance 23

5.3.3 Replacing the battery 23

5.4 Emergency procedures 23

5.5 Shutting down 23

5.5.1 Disposal 23

6 UPS Software Components (optional) 24

6.1 Installation on the PC 24

6.2 Help files 24

7 Troubleshooting 25

8 Assembly dimensions 26

9 Technical Data 27

10 Appendix 28

10.1 Beckhoff Support and Service 28

10.1.1 Beckhoff branches and partner companies 28

10.1.2 Beckhoff company headquarters 28

10.2 Approvals for USA and Canada 29

10.3 FCC Approvals for the United States of America 29

10.4 FCC Approval for Canada 29

2 CP32xx

Foreword

1 Foreword

1.1 Notes on the Documentation

This description is only intended for the use of trained specialists in control and automation engineering
who are familiar with the applicable national standards. It is essential that the following notes and
explanations are followed when installing and commissioning these components.

The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.

1.1.1 Liability Conditions

The documentation has been prepared with care. The products described are, however, constantly under
development. For that reason the documentation is not in every case checked for consistency with
performance data, standards or other characteristics. In the event that it contains technical or editorial
errors, we retain the right to make alterations at any time and without warning. No claims for the
modification of products that have already been supplied may be made on the basis of the data, diagrams
and descriptions in this documentation.

1.1.2 Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, Safety over EtherCAT®, TwinSAFE® and XFC® are registered
trademarks of and licensed by Beckhoff Automation GmbH.
Other designations used in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owners.

1.1.3 Patent Pending

The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents: EP1590927, EP1789857, DE102004044764, DE102007017835 with corresponding applications
or registrations in various other countries.
The TwinCAT Technology is covered, including but not limited to the following patent applications and
patents: EP0851348, US6167425 with corresponding applications or registrations in various other
countries.

1.1.4 Copyright

©

Beckhoff Automation GmbH & Co. KG.
The reproduction, distribution and utilization of this document as well as the communication of its contents
to others without express authorization are prohibited. Offenders will be held liable for the payment of
damages. All rights reserved in the event of the grant of a patent, utility model or design.

1.1.5 State at Delivery

All the components are supplied in particular hardware and software configurations appropriate for the
application. Modifications to hardware or software configurations other than those described in the
documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.

1.1.6 Delivery conditions

In addition, the general delivery conditions of the company Beckhoff Automation GmbH & Co. KG apply.

CP32xx 3

Foreword

1.2 Description of safety symbols

The following safety symbols are used in this operating manual. They are intended to alert the reader to
the associated safety instructions.

Acute risk of injury!

If you do not adhere the safety advise adjoining this symbol, there is immediate

DANGER

WARNING

CAUTION

danger to life and health of individuals!

Risk of injury!

If you do not adhere the safety advise adjoining this symbol, there is danger to life and
health of individuals!

Hazard to individuals!

If you do not adhere the safety advise adjoining this symbol, there is obvious hazard to
individuals!

Hazard to devices and environment

Attention

Note

If you do not adhere the notice adjoining this symbol, there is obvious hazard to
materials and environment.

Note or pointer

This symbol indicates information that contributes to better understanding.

4 CP32xx

Foreword

1.3 Basic safety measures

Before the Panel PC is switched off, software that is running must be properly closed.
Otherwise it is possible that data on the storage medium is lost. Please read the section Switching the

Panel PC on and off.

Switch off all parts of the equipment, then uncouple the Panel PC

Before opening the housing, and whenever the Panel PC is not being used for control

Warning

Disconnect the device by unplugging the connectors on the rear side of the Panel PC.
Items of equipment that have been switched off must be secured against being switched on again.

Warning

purposes (such as during functional checks after a repair), all parts of the equipment
must first be switched off, after which the Panel PC is to be disconnected from the
equipment.

Do not exchange any parts when under power

When components are being fitted or removed, the supply voltage must be switched
off.

Fitting work on the Panel PC can result in damage:

• if metal objects such as screws or tools fall onto operating circuit boards

• if connecting cables internal to the Panel PC are removed or inserted during

operation.

CP32xx 5

Foreword

1.4 Operator’s obligation to exercise diligence

The operator must ensure that

• the product is only used as intended (see chapter Product Description)

• the product is in a sound condition and in working order during operation

• the product is operated, maintained and repaired only by suitably qualified and authorized

personnel

• the personnel is instructed regularly about relevant occupational safety and environmental
protection aspects, and is familiar with the operating manual and in particular the safety notes
contained herein

• the operation manual is in good condition and complete, and always available for reference at the
location of the product.

Do not open the housing of the Panel PC!

For technical support contact Beckhoff Service.

Note

1.4.1 National regulations

Depending on the type of machine and plant in which the Industrial PC is used, national regulations
governing the controllers of such machines will apply, and must be observed by the operator. These
regulations cover, amongst other things, the intervals between inspections of the controller. The operator
must initiate such inspections in good time.

1.4.2 Procedure in the event of a fault

In the event of faults at the Industrial PC, the list in the section Troubleshooting can be used to determine
the measures to be taken.

1.4.3 Operator requirements

Anyone who uses the Industrial PC must have read these operating instructions and must be familiar with
all the functions of the software installed on the Industrial PC to which he has access.

6 CP32xx

Product Description

2 Product Description

2.1 Product overview

The high-performance multi-touch Panel PC

With the CP32xx series, a high-end Panel PC with multi-touch can be used directly in the field. The
devices in a slender aluminium housing feature complete IP65 protection and are designed for mounting
arm installation. The Panel PCs offer maximum computing power with processors of the latest generation,
such as Intel® Celeron® or Core™ i3, i5, or i7.

A choice of seven different multi-touch TFT displays in sizes between 12-inch and 24-inch and 4:3,
widescreen, landscape or portrait formats are available. The operating temperature range is 0 to 45 °C.

The multi-touch Panel PCs offer the following benefits:

• Industrial PC with Control Panel for mounting arm installation

• Multi-finger touch screen

• Rotatable and tiltable mounting arm adapter for Rittal and Rolec mounting arm systems with

48 mm tube

• Passive cooling through heat sink; internal fan for equal heat distribution to all the walls of the
housing

• Wiring area for up to 6 IP65 connectors

• 1 slot for one 2½-inch hard disk or SSD and 1 slot for one CFast card

• Lithium battery of the system clock, changeable from outside

• Protection class IP65.

CP32xx 7

Product Description

2.2 Appropriate Use

The CP32xx Panel PC is designed for industrial application in machine and plant engineering. In addition
to the integrated PC, a TFT display with touch screen is accommodated in a slender aluminium housing.
The Panel PC is designed for mounting arm installation.

Risk of explosion!

The Control Panel must not be used where there is a risk of explosion.

Danger

2.3 Access to the connectors

The connectors of the Panel PC are located at the rear side of the device behind a cover (1). To get
access to the connectors, the cover has to be removed:

1

2

First loosen the fixing screw (2) with a star screwdriver Torx size 20. The cover now can be drawn off in
direction of the arrow (see next picture).
