AS2MICRO Portable simultaneous li-ion battery charger
User Manual
WE STRONGLY RECOMMEND THAT YOU READ THIS INSTRUCTION BEFORE USI NG YOUR BEBOB AS2MICRO CHARGER! PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE
Features
• 2 Channel AMount sim ultaneous Li-Ion Charger.
• AC Adapter. 16,8V – 5.0A DC Dtap (male) Output
• Powerbase Mode.
Charging
• Plug the blue Dtap Plug of the S1mic ro in the blue Tw ist Dtap So c k et of the Powerbase-Amicro.
• The S1mic ro led indicator show gr een when t he charger is plugged in with no battery connected
• The Chan nel Status indicat or turns red when a battery is placed on the c or respo nding channel
and the charging process has begun
• The Chan nel Status indicat or turns back gre en when the battery is fully charge d
AC Adapter S1MICRO
• You can use your S1micro AC Adapter (Part of the Kit) as a 1 Channel Travel Quick
Charger
• Plug the Blue Dtap in theTwist Dtap Socket on any bebob battery (but Bmount)
• The AC adapter delivers up to 5,0A under 16,5V
bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: +49 89 27818282
www.bebob.de
Juni 2019
Page 2
Model
AS2micro
Mount
Amicro
Channel
2 simultaneous
Charging current
16,8V 2.5A per Channel 5,0A global
AC In
90-264V/47-63Hz 100W
Weight AC Adaptor
0,365 Kg
Dimensions (WXHXD)
40 x 138x 60mm
Weight Powerbase
0,160 Kg
Dimensions (WXHXD)
96 x 66x 45mm
Batteries
bebob
Charging time
depends on the battery capacity
Operating Temp. Range
- 10°C ~ + 35°C
Powerbase
• Plug off the S1micro from the Powerbase-Amicro
• Place one or two full batteries on the Powerbase
• Battery Power will be available over the black twist Dtap Socket
• Maximum Load depends on the batteries and limited to 10A
Safety instructions
• Only for professional use! Keep Charger out of reach of children and personnel that has
not been instructed in the use!
• Use only with recommended batteries.
• Keep the charger dry and do not imm erse in water.
• Do not cover the charger under use
• Do not keep in contact wi th any part of t he body while the c harger is in working status.
• Do not use or store t he charger in uns t able, du s t y or damp environments.
• Remove the battery from the charger after the charging process is complete.
• Do not attempt to open or repair the c harger. Contact your dealer for help if it becomes
defective.
• Handle with care! Do not throw! Do not drop!
Warranty
• The AS2micro is covered by a 2 years unconditional warranty on all parts.
• For warranty issues or if you have any additional questions, please contact the appropriate
Specifications
bebob distributor listed at www.bebob.de.
bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: +49 89 27818282
www.bebob.de
Juni 2019
