BC Biomedical PFC-3000 User Manual
BENCHTOP FLOW
ANALYZER
PFC-3000
SERIES
USER MANUAL
NOTICE – DISCLAIMER
USER ASSUMES FULL RESPONSIBILITY FOR UNAUTHORIZED
EQUIPMENT MODIFICATIONS OR APPLICATION OF EQUIPMENT
OUTSIDE OF THE PUBLISHED INTENDED USE AND SPECIFICATIONS.
SUCH MODIFICATIONS OR APPLICATIONS MAY RESULT IN EQUIPMENT
DAMAGE OR PERSONAL INJURY.
NOTICE – DISCLAIMER
BC GROUP INTERNATIONAL, INC. RESERVES THE RIGHT TO MAKE
CHANGES TO ITS PRODUCTS OR SPECIFICATIONS AT ANY TIME,
WITHOUT NOTICE, IN ORDER TO IMPROVE THE DESIGN OR
PERFORMANCE AND TO SUPPLY THE BEST POSSIBLE PRODUCT. THE
INFORMATION IN THIS MANUAL HAS BEEN CAREFULLY CHECKED AND
IS BELIEVED TO BE ACCURATE. HOWEVER, NO RESPONSIBILITY IS
ASSUMED FOR INACCURACIES.
NOTICE – CONTACT INFORMATION
BC BIOMEDICAL
BC GROUP INTERNATIONAL, INC.
3081 ELM POINT INDUSTRIAL DRIVE
ST. CHARLES, MO 63301
USA
1-800-242-8428
1-314-638-3800
www.bcgroupintl.com
sales@bcgroupintl.com
PFC-3000 Series User Manual Copyright © 2013
www.bcgroupintl.com Made in the USA
04/13 Rev 04
USER MANUAL FLOWANALYZER
1 Content
1 Content ................................................................................................................ 2
2 Preface................................................................................................................. 5
3 Intended Use ....................................................................................................... 6
4 Safety Instructions ............................................................................................. 7
4.1 Symbols for Danger, Warnings and Notes .......................................................................... 7
4.2 Personnel ........................................................................................................................... 7
4.3 Responsibilities and Guarantees ........................................................................................ 7
5 Technical Data .................................................................................................... 8
5.1 Measurement Categories ................................................................................................... 8
5.1.1 Analyzer Values ............................................................................................................ 8
5.1.2 Respiratory Parameters ................................................................................................ 9
5.1.3 Principle of Operation for Flow Measurement .............................................................. 10
5.1.4 Special Functions ................................................................ ................................ ........ 11
5.1.5 Communication Interfaces ........................................................................................... 11
5.1.6 Physical Data .............................................................................................................. 11
5.1.7 Calibration by User ...................................................................................................... 11
5.1.8 Operational Data ......................................................................................................... 11
5.1.9 Extras .......................................................................................................................... 11
5.2 Standard Conditions for Flow Measurement ..................................................................... 12
5.3 Power Supply ................................................................................................................... 13
5.4 Battery Mode .................................................................................................................... 13
5.5 Compliance and Approvals ............................................................................................... 13
5.6 Device Labels and Symbols ............................................................................................. 14
5.7 Minimum PC Requirements ................................................................ .............................. 14
6 Preparing for Use ............................................................................................. 15
6.1 Individual Supplied Parts .................................................................................................. 15
6.2 Power Supply ................................................................................................................... 16
6.2.1 Supply Voltage ............................................................................................................ 16
6.3 Mechanical Connections .................................................................................................. 17
6.3.1 Protection Filter ........................................................................................................... 17
6.3.2 FlowAnalyzer
6.3.3 Low Flow ..................................................................................................................... 18
6.3.4 High Flow .................................................................................................................... 19
6.3.5 Differential Pressure .................................................................................................... 20
6.3.6 Low pressure (PFC-3000L) ......................................................................................... 20
6.3.7 Pressure sensor ± 1 bar (PFC-3000V) ........................................................................ 21
6.3.8 High Pressure ................................ ................................................................ ............. 22
6.4 Electrical Interfaces .......................................................................................................... 23
6.4.1 USB ............................................................................................................................ 23
6.4.2 RS 232 ........................................................................................................................ 23
6.4.3 External Trigger ........................................................................................................... 24
6.4.4 Grounding ................................................................................................................... 25
TM
Adapter Set........................................................................................ 17
TM
Page 2 / 84
USER MANUAL FLOWANALYZERTM
7 Operation .......................................................................................................... 26
7.1 Switching the Device On and Off ...................................................................................... 26
7.2 The Start Screen .............................................................................................................. 26
7.3 Adjusting the Contrast ...................................................................................................... 26
7.4 Description of Operating Controls ..................................................................................... 27
7.5 Specifications for the Operating Controls .......................................................................... 27
7.6 Numerical Display ............................................................................................................. 28
7.6.1 Specification for the Numerical Display ........................................................................ 28
7.7 Configuration Display........................................................................................................ 30
7.7.1 Specification for the Configuration Display ................................................................... 30
7.8 Statistics Display .............................................................................................................. 31
7.8.1 Specification of the Statistics Display ........................................................................... 31
7.9 Menu Display .................................................................................................................... 32
7.9.1 Specification of the Menu Display ................................................................................ 32
7.10 Data Storage Capabilities ................................................................................................. 34
7.10.1 Storing Data ................................................................................................................ 34
7.10.2 Retrieving Data ............................................................................................................ 35
7.10.3 Erasing Data ................................................................................................................ 36
7.11 RT-200 Emulation Mode ................................................................................................... 38
7.12 Calibrations ...................................................................................................................... 38
7.12.1 Calibrating the Pressure and Flow Sensors ................................................................. 38
7.12.2 Calibrating the Oxygen Sensor .................................................................................... 39
7.12.3 Calibrating the MultiGasAnalyzerTM MGA-3050 ............................................................ 39
7.13 Gas Type and Standard .................................................................................................... 40
7.14 Setting the Trigger ............................................................................................................ 41
7.14.1 Selection of Ventilation Mode ...................................................................................... 41
7.14.2 Standard Trigger .......................................................................................................... 42
7.14.3 Detailed Trigger Settings ............................................................................................. 43
7.14.4 Usage of an External Trigger ....................................................................................... 44
7.15 Filter ................................................................................................................................. 45
7.16 Setting the Language........................................................................................................ 45
7.17 HW Activation ................................................................................................................... 45
7.18 Accessing System Info ..................................................................................................... 46
7.19 Invisible Menu Options ..................................................................................................... 46
7.20 Factory Defaults ............................................................................................................... 47
8 FlowLabTM Software ......................................................................................... 48
8.1 Installation ........................................................................................................................ 48
8.2 USB Communication ........................................................................................................ 48
8.3 Overview .......................................................................................................................... 48
8.4 Options ............................................................................................................................. 48
8.5 Panels .............................................................................................................................. 49
8.5.1 Configuration ............................................................................................................... 49
8.5.2 Curve Trigger .............................................................................................................. 51
8.5.3 Cursors ........................................................................................................................ 52
8.6 Numerics .......................................................................................................................... 53
8.7 Trending ........................................................................................................................... 54
8.7.1 Configuration ............................................................................................................... 54
8.7.2 Display ........................................................................................................................ 55
8.8 Reporting .......................................................................................................................... 56
8.8.1 Configuration ............................................................................................................... 56
8.9 Gas Calculator .................................................................................................................. 58
8.10 FlowLabTM Settings ........................................................................................................... 59
Page 3 / 84
9 MultiGasAnalyzer
TM
MGA-3050 ................................ ....................................... 60
USER MANUAL FLOWANALYZER
9.1 Description ................................................................................................ ....................... 60
9.2 Intended use .................................................................................................................... 60
9.3 Warnings .......................................................................................................................... 60
9.4 Design and theory ................................ ................................................................ ............ 61
9.5 How to connect ................................................................................................................ 62
9.6 LED Signal ................................................................................................ ....................... 63
9.7 Calibration of Sensor head ............................................................................................... 63
9.8 Preventive maintenance ................................................................................................... 64
9.9 Specifications MultiGasAnalyzerTM MGA-3050 ................................................................. 65
10 Measuring Respiratory Coefficients ............................................................... 66
10.1 General ............................................................................................................................ 66
10.2 Connection to the Ventilator ............................................................................................. 66
10.3 Standard Trigger Values .................................................................................................. 66
10.4 Baseflow .......................................................................................................................... 67
10.5 Finding the Correct Trigger Values ................................................................................... 67
10.5.1 Flow curve after Y-Piece ................................................................ ............................. 67
10.5.2 Flow curve before Y-Piece .......................................................................................... 68
10.5.3 Pressure curve before Y-Piece .................................................................................... 69
10.6 Special situations ............................................................................................................. 69
10.6.1 Inspiration Volume Vti ................................................................................................. 70
10.6.2 Expiration Volume Vte ................................................................................................ . 70
11 Care and Maintenance...................................................................................... 71
11.1 Guidelines for Care and Maintenance ................................................................ .............. 71
11.2 Notes on Replacing Components ..................................................................................... 71
11.3 Preventative Cleaning and Maintenance Routines ........................................................... 71
11.3.1 Replacing the Measuring Screen ................................................................................. 72
11.3.2 Replacing the Oxygen Sensor ..................................................................................... 72
11.3.3 Replacing the Fuses.................................................................................................... 74
11.4 Contacts ........................................................................................................................... 75
11.4.1 Manufacturer's Address ............................................................................................... 75
11.4.2 Technical Support ....................................................................................................... 75
12 Accessories and Spare Parts .......................................................................... 76
12.1 Ordering Address ............................................................................................................. 76
12.2 Available Models .............................................................................................................. 76
12.3 Options ............................................................................................................................ 76
13 Disposal............................................................................................................. 77
14 Appendix A: Abbreviations and Glossary ...................................................... 78
15 Appendix B: Values and Units ......................................................................... 80
15.1 Pressure .......................................................................................................................... 80
15.2 Flow ................................................................................................................................. 80
15.3 Metrology Values ............................................................................................................. 80
15.4 Gas Concentrations.......................................................................................................... 80
15.5 Respiratory Parameters ................................................................................................... 80
15.6 Conversion Factors .......................................................................................................... 81
Manual Revisions & Limited Warranty……………………….…………………………………………82
Notes……………………………………………………………………………………………………….83
TM
Page 4 / 84
USER MANUAL FLOWANALYZERTM
Application
This documentation applies to the products described as:
FlowAnalyzerTM PFC-3000A, FlowAnalyzerTM PFC-3000V, FlowAnalyzerTM PFC-3000L
MultiGasAnalyzerTM MGA-3050
FlowLabTM
You will find the designation FlowAnalyzerTM on the nameplate on the back of the device.
In this user manual, the designation FlowAnalyzerTM includes the FlowAnalyzerTM PFC-3000A,
FlowAnalyzerTM PFC-3000V and the FlowAnalyzerTM PFC-3000L.
Software and Firmware versions
This documentation applies to the following versions:
FlowLabTM Software Version 4.2.1
FlowAnalyzer
TM
Firmware Version 4.2.9
When using older or newer versions small differences to this manual may appear.
Key to symbols used in this manual
Keys, FlowAnalyzerTM labels
and information in the display
Keys, such as Power,
labels, such as USB, and
information in the display, such as Changing the settings,
are shown in bold, italic type.
References to pages and
chapters
The symbol (> XY) is used for references to pages and
chapters (> 5.1.6 Physical Data).
2 Preface
Page 5 / 84
The FlowAnalyzerTM is a compact, mobile and easy-to-use
measuring device.
The FlowAnalyzerTM carries out all the following measurements:
Low flow (-20...20 l/min)
High flow (-300…300 l/min)
Volume
Differential pressure
High pressure
Atmospheric pressure
Oxygen
Temperature
Humidity
Dew point
It can also measure a variety of respiratory parameters:
Inspiration volume, expiration volume
Rate of respiration
I:E
Inspiration time, expiration time
Ppeak
Pmean
Pplateau
PEEP
PF Insp (Peak flow inspiratory)
PF Exp (Peak flow expiratory)
Ti/Ttotal
Cstat
Delta P
The FlowAnalyzerTM has been designed for mobile use. In the
event of power failure the device can be operated from a built-in
battery.
USER MANUAL FLOWANALYZER
3 Intended Use
The FlowAnalyzer
and calibrating ventilators. The FlowAnalyzer
used for patient monitoring.
The FlowAnalyzer
TM
which is being used by a patient.
Page 6 / 84
TM
is a measuring device for testing
TM
should not be
must not be connected to a ventilator
TM
USER MANUAL FLOWANALYZERTM
4.1 Symbols for
Danger, Warnings
and Notes
This User Manual uses the symbols below to draw your specific
attention to the remaining dangers associated with proper use, and
to emphasize important technical requirements.
4.2 Personnel
4.3 Responsibilities
and Guarantees
The manufacturer assumes no responsibility or guarantee, and
exonerates himself accordingly from liability claims, where the
operator or any third party has:
Used the device improperly
Disregarded technical data
Tampered with the device in any way (modifications, changes,
etc.)
Operated the device using accessories that are not listed in the
associated product documentation.
4 Safety Instructions
Information or directions / warnings to prevent any sort
of damage / risk.
The FlowAnalyzerTM may only be operated or worked
on by personnel with suitable technical training and appropriate
experience.
Although this device features a high standard of quality
and safety and has been built and tested according to the current
state of the art, improper usage or misuse can result in injuries
with serious consequences.
Therefore please read this user manual carefully and keep this
documentation within reach of the device.
Page 7 / 84
5.1 Measurement Categories
5.1.1 Analyzer Values1
Low flow
Range
± 20 sl/min
Accuracy
± 1.75% of reading
or ± 0.04 sl/min
High flow
Range
± 300 sl/min
Accuracy
± 1.75% of reading
or ± 0.1 sl/min
Volume
Range
± 100 sl
Accuracy
± 2% of reading or
± 0.02 sl (High flow)
± 0.01 sl (Low flow)
Pressure (in High flow)
Range
0…150 mbar
Accuracy
± 0.75% of reading
or ± 0.1 mbar
Differential pressure
Range
± 150 mbar
Accuracy
± 0.75% of reading
or ± 0.1 mbar
High pressure
Range
0...10 bar
Accuracy
± 1% of reading
or ± 10 mbar
Atmospheric pressure
Range
0...1150 mbar
Accuracy
± 1% of reading
or ± 5 mbar
Oxygen
Range
0...100 % Vol
Accuracy
± 1% Vol
Humidity
Range
0...100 % RH,
Non-condensing
Accuracy
± 3% RH
Temperature
Range
0...50 °C
Accuracy
± 1.75% of reading
or ± 0.5 °C
Dew point
Range
-10...50 °C
Accuracy
± 2% of reading
or ± 1 °C
Additional pressure
sensors
Find details in chapter 6.3.6 Low
pressure (PFC-3000L) and 6.3.7
Pressure sensor ± 1 bar (PFC-3000V).
1
5 Technical Data
USER MANUAL FLOWANALYZER
TM
Standard liter per minute (calculated using STP conditions of 21°C and 1013 mbar)
Page 8 / 84
USER MANUAL FLOWANALYZERTM
5.1.2 Respiratory Parameters
Vti, Vte
Breath volume of
inspiration and
expiration
Range
Accuracy
± 10 sl
(High flow) ± 1.75% or ± 0.0002 sl (>6 sl/min)
(Low flow) ± 1.75% or ± 0.0001 sl (>2.4 sl/min)
Vi, Ve
Minute volume of
inspiration and
expiration
Range
Accuracy
0...300 sl/min
(High flow) ± 2.5% or 0.02 sl/min
(Low flow) ± 2.5% or 0.01 sl/min
Ti, Te
Inspiration and
expiration times
Range
Accuracy
0.05...60 s
± 0.02 s
Ti/Ttotal
Ratio Inspiration time :
Breath cycle time
Range
Accuracy
0...100%
± 5%
Ppeak
Maximum pressure
Range
Accuracy
0...150 mbar
± 0.75% or ± 0.1 mbar
Pmean
Mean pressure
Range
Accuracy
0...150 mbar
± 0.75% or ± 0.1 mbar
I:E
Respiration time ratio
Range
Accuracy
1:300...300:1
± 2.5%
PEEP
Positive End
Expiratory Pressure
Range
Accuracy
0...150 mbar
± 0.75% or ± 0.1 mbar
Rate
Rate of respiration
Range
Accuracy
1...1000 bpm
± 2.5% or ± 1 bpm
PF Insp.
Maximum flow of
inspiration
Range
Accuracy
± 300 sl/min
± 1.75% or ± 0.1 sl/min
PF Exp.
Maximum flow of
expiration
Range
Accuracy
± 300 sl/min
± 1.75% or ± 0.1 sl/min
Cstat
Static Compliance
Range
Accuracy
0...1000 ml/mbar
± 3% or ± 1 ml/mbar
Pplateau
Plateau Pressure
Range
Accuracy
0...150 mbar
± 0.75% or ± 0.1 mbar
Delta P
Amplitude Pressure
(Ppeak – PEEP)
Range
Accuracy
0...150 mbar
± 0.75% or ± 0.1 mbar
Page 9 / 84
5.1.3 Principle of Operation for
Flow Measurement
The Flow is measured over a differential pressure
measurement in the flow channel. A screen is used as the
restrictor.
: dynamic viscosity of gas [Pa s]
: density of gas [kg / m3]
c1, c2: device specific constants (channel geometry)
Dynamic
Viscosity
• The viscosity of a medium is its
resistance to shear or flow
• The viscosity is strongly temperature
dependent
• Small dependency on humidity and
pressure
Density
• The density is a measure of the
medium's mass per unit of volume
• The density is strongly temperature and
pressure dependent
The dependence on the ambient conditions is the reason
why the flow is sometimes transferred to standard
conditions (>5.2 Standard Conditions for Flow
Measurement).
USER MANUAL FLOWANALYZER
TM
Page 10 / 84
USER MANUAL FLOWANALYZERTM
5.1.4 Special Functions
Automatic battery operation in event of power failure.
5.1.5 Communication
Interfaces
USB
RS-232 port for FW download, remote control and connection of
optional MultiGasAnalyzerTM MGA-3050
Trigger input (digital) for external trigger
5.1.6 Physical Data
Weight: < 8.5 Lbs (3.8 kg)
Dimensions (L x W x H): 8.67 x 9.84 x 4.72 Inches
(220 x 250 x 120 mm)
Gas types: Air, O2, N2O, He, N2, CO2 and
Mixed: Air/O2, N2O/O
2,
He/O2
5.1.7 Calibration by
User
Offset calibration of pressure sensors
Calibration of oxygen sensor
5.1.8 Operational Data
Temperature: 15...40 °C (59...104 °F)
Humidity: 10%...90% RH, non-condensing
Air pressure: 700...1060 mbar
Storage and transport -10...60 °C (14...140 °F)
conditions: at 5...95% RH
5.1.9 Extras
- FlowLabTM Software
- MultiGasAnalyzerTM MGA-3050
Page 11 / 84
5.2 Standard Conditions for
Flow Measurement
The FlowAnalyzer calculates the internal flow and volume
measurements with the terms of the selected gas standard.
The FlowAnalyzer supports the following gas standards:
Gas Standard
Temperature
Pressure
Relative
Humidity
Ambient Temperature
and Pressure
ATP
Current gas
temperature
Current ambient
pressure
Current gas
humidity
Ambient Temperature
and Pressure Dry
ATPD
Current gas
temperature
Current ambient
pressure
0%
Ambient Temperature
and Pressure
Saturated
ATPS
Current gas
temperature
Current ambient
pressure
100%
Ambient Pressure at
21°C
AP21
21.0 °C (70 °F)
Current ambient
pressure
Current gas
humidity
Standard Conditions
USA
STP
21.1 °C (70 °F)
1013.25 mbar
(760 mmHg)
0%
Standard Conditions
USA Humid
STPH
21.1 °C (70 °F)
1013.25 mbar
(760 mmHg)
Current gas
humidity
Body Temperature
and Pressure
Saturated
BTPS
37 °C (99 °F)
Current ambient
pressure
100%
Body Temperature
and Pressure Dry
BTPD
37 °C (99 °F)
Current ambient
pressure
0%
Standard Conditions
according to
DIN 1343
0/1013
0 °C (32 °F)
1013.25 mbar
(760 mmHg)
0%
Standard Conditions
according to
ISO 1-1975 (DIN 102)
20/981
20 °C (68 °F)
981 mbar
(736 mmHg)
0%
API Standard
Conditions
15/1013
15 °C (60 °F)
1013.25 mbar
(14.7 psia)
0%
Cummings Standard
25/991
25 °C (77 °F)
991 mbar
(500 ft. high)
0%
20 °C / 1013 mbar
20/1013
20 °C (68 °F)
1013.25 mbar
(760 mmHg)
0%
USER MANUAL FLOWANALYZER
TM
In this user manual the unit sl/min is based on
ambient conditions of 0 °C and 1013 mbar (DIN 1343).
Please refer to Appendix B: Values and Units where you
also can find conversion factors for the units.
Page 12 / 84
USER MANUAL FLOWANALYZERTM
5.3 Power Supply
Input voltage of power pack
100-240 VAC, 50-60 Hz
Supply voltage
15 V DC
Power consumption
25 VA (W)
5.4 Battery Mode
Running time in battery
mode
3 h
Running time in battery
mode with the
MultiGasAnalyzerTM
2 h
Charging the battery
A complete charge takes 8 h.
The usable battery life will be
extended if the battery is used
until the request for recharge and
then charged for 8 h.
5.5 Compliance and
Approvals
IEC 1010-1 (safety)
EN61326-1 (EMC)
CAN/CSA-C22.2 No. 0-M91 (General)
CAN/CSA-C22.2 No. 1010.1-92 (Safety)
CAN/CSA-C22.2 No. 1010.1 B-97 (Safety)
UL. Std No. 61010B-1. 1st Ed. (General)
The instrument is classified in Installation category II.
The instrument is assigned to Pollution degree 2.
The instrument is designed for indoor use only.
as soon as the battery has to be recharged. Do not keep the
battery in discharged mode!
Attention: A total discharge may destroy the battery!
The instrument provides audible and visual alarm
Page 13 / 84
5.6 Device Labels and
Symbols
The following labels and symbols can be found on the
FlowAnalyzerTM :
RS232
RS232 interface (for servicing)
USB
USB interface (for PC communication)
SN: xxxx
Serial number
Warning: observe accompanying
documents.
Date of production Month - Year
Ground
5.7 Minimum PC
Requirements
Intel® Pentium® III 800 MHz
(P4 1200 MHz recommended)
Microsoft® Windows® 98, Me, 2000, XP
Microsoft® Internet Explorer 5.01 or above
128 MB RAM (256 MB recommended)
160 MB hard disc space (full installation)
CD ROM drive
Screen 800 x 600 (1024 x 768 recommended)
USER MANUAL FLOWANALYZER
TM
Page 14 / 84
USER MANUAL FLOWANALYZERTM
6.1 Individual Supplied
Parts
Basic unit:
FlowAnalyzer
TM
Power pack
USB cable
User manual and calibration
certificate
FlowLabTM PC software
Filter
FlowAnalyzer
TM
Adapter Set
6 Preparing for Use
Page 15 / 84
6.2 Power Supply
Power is connected to the back of the FlowAnalyzerTM .
The main power switch is used to switch the instrument on and
off.
A LED marked with Charging lights up when the battery is being
charged. This also works when the device is off.
6.2.1 Supply Voltage
The mains voltage for the power pack supplied is 100...240 V
AC at 50...60 Hz.
USER MANUAL FLOWANALYZER
TM
The FlowAnalyzerTM may only be operated with the
original power pack supplied!
For protection against interference from
electromagnetic fields and static electricity, the device must be
grounded using the pins provided.
Page 16 / 84
Before you switch on the device, check that the
operating voltage of the power pack complies with the local
mains voltage.
Details can be found on the nameplate on the back of the
power pack.
USER MANUAL FLOWANALYZERTM
6.3 Mechanical
Connections
6.3.1 Protection Filter
In order to protect the instrument from contaminations with
particles of the air it is important to use the filter, which is
delivered with each instrument. The filter has to be used on the
High flow as well as on the Low flow channel.
6.3.2 FlowAnalyzer
TM
Adapter Set
The FlowAnalyzer
TM
Adapter Set included assists in connecting
various test objects to the FlowAnalyzer
TM
. A minimal amount of
dead space as well as minimal differences in the Flow stream
assist in assuring highly accurate measurements. When using
the Low flow connection for measuring respiratory parameters,
the positive interface of the differential pressure sensor is
used for the pressure measurement. The T-Piece included with
the connection tube connects the corresponding interfaces.
and result in inaccurate measuring results. The Filter must be
checked on a regular basis.
Particles in the air may clog the measuring system
Page 17 / 84
6.3.3 Low Flow2
The Low flow connection is used to measure small flow rates. In
order to calculate respiratory parameters using this measurement
channel, the trigger must be set to “infant”. Thereby, the positive
interface from the differential pressure sensor will automatically be
used as the pressure sensor. The T-Piece with the connection tube
can be used to connect these two interfaces.
Range:
± 20 sl/min
Accuracy:
± 1.75% of reading or 0.04 sl/min
2
Low flow
USER MANUAL FLOWANALYZER
TM
There are no additional sensors in the low flow
channel to measure temperature, humidity, or O2
concentration which have an impact on flow measurement.
To achieve very accurate measurements it helps if the back
end of the low flow channel is connected to the high flow
channel. On this way the additional values can be measured.
For Flows higher than 20 sl/min the measurement is not
accurate anymore.
Standard liter per minute (calculated using STP conditions of 21°C and 1013 mbar)
Page 18 / 84
USER MANUAL FLOWANALYZERTM
6.3.4 High Flow3
The High flow connection can be used for the following bidirectional measurements:
High flow rates (± 300 sl/min)
Volume
Temperature
Humidity
Oxygen
Pressure in the channel
High flow:
Range:
± 300 sl/min
Accuracy:
± 1.75% of reading or ± 0.1 sl/min
Volume:
Range:
0...10 sl
Accuracy:
± 2% of reading or ± 0.02 sl
Temperature:
Range:
0...50 °C (32...122 °F)
Accuracy:
± 1.75% of reading or ± 0.5 °C
Humidity:
Range:
0...100% not condensing
Accuracy:
± 3% RH
Oxygen:
Range:
0...100 %
Accuracy:
± 1% O2
Pressure
Range:
0...150 mbar
Accuracy:
± 0.75% of reading or ± 0.1 mbar
3
High flow
When working with higher humidity it is important
that there is no condensation inside the instrument. Water can
destroy the sensors!
Pressures higher than 500 mbar will destroy the sensors!
Standard liter per minute (calculated using STP conditions of 21°C and 1013 mbar)
Page 19 / 84
6.3.5 Differential Pressure
The Differential pressure connections can be used to measure
differential pressure.
Range:
± 150 mbar
Accuracy:
± 0.75% of reading or ± 0.1 mbar
6.3.6 Low pressure (PFC-
3000L)
There is an additional low pressure sensor for the PFC-3000L.
The sensor is connected to the specified connector and is
marked with a blue ring.
Range:
0...5 mbar
Accuracy:
± 1% of reading or ± 0.01 mbar
Differential pressure
Low pressure
USER MANUAL FLOWANALYZER
TM
When using one of the pressure options (low P or
± 1bar), the sensor (± 150 mbar) will be connected to the
remaining connector where as the second port of the sensor
is measuring against ambient. The measurement range
remains the same.
Page 20 / 84
USER MANUAL FLOWANALYZERTM
6.3.7 Pressure sensor ± 1
bar (PFC-3000V)
There is an additional pressure sensor ± 1 bar for the PFC-
3000V. The sensor is connected to the specified connector and
is marked with a red ring.
Range:
± 1000 mbar
Accuracy:
± 0.5% of reading or ± 2 mbar
Pressure sensor ±1 bar
1bar), the sensor (± 150 mbar) will be connected to the
remaining connector where as the second port of the sensor
is measuring against ambient. The measurement range
remains the same.
When using one of the pressure options (low P or ±
Page 21 / 84
6.3.8 High Pressure
The High pressure connection can be used to measure
pressures greater than 150 mbar.
If you prefer for this connection a DISS O2 Connection, there is
an appropriate adapter available.
Range:
0...10 bar
Accuracy:
± 1% of reading or ± 10 mbar
High pressure
USER MANUAL FLOWANALYZER
TM
When measuring below 150 mbar it is
recommended to use the Differential Pressure port
± 150 mbar since the accuracy is up to 100 times higher.
Pressures higher than 15 bar will destroy the sensor!
Page 22 / 84
USER MANUAL FLOWANALYZERTM
6.4 Electrical Interfaces
6.4.1 USB
The USB interface is used to connect the FlowAnalyzer
TM
to the PC. The connection is located on the back of the device.
If FlowLabTM software was supplied with the device, the
recorded values can be graphically displayed on the computer.
If your device does not have this software, the USB connection
will be blocked. It can be released at any time with a clearance
code (> 8.2 USB Communication).
6.4.2 RS 232
The RS232 interface is used for servicing (firmware download),
for the connection of the MultgasAnalyzerTM MGA-3050 as well
as for remote control of the unit and is located on the back of the
FlowAnalyzer
TM
.
The connection to the RS 232 port has to be established over
the special RS 232 interface cable.
If the instrument has to be remote controlled e.g. through a
specific software package you can ask your authorized dealer for
a detailed description of the protocol.
FlowAnalyzerTM pin assignment (RJ-45 connector):
RS 232
USB
8
7
6
5
4
3
2
1
Page 23 / 84
Loading...
