Baumatic AS13SS-A Instruction Manual

Instruction manual

AS13SS-A/B191SS-A
Multifunction oven

ELECTRIC SINGLE

OVENS

USER AND INSTALLATION

INSTRUCTIONS

DD 29/01/07

For future reference please record the following
information which be found on the Rating Plate and the
date of purchase which can be found in the invoice:

Model Number …………………….

Serial Number …………………….

Date of Purchase …………………….

CONTENTS

General Information pages 3-4

Wa

rning and Safety Instructions pages 5-6

In

structions for Use pages 7-15

In

structions for Installation pages 16-21

Maintenance pages 22-23

Technical Data

page 24

European directive on Waste Electrical

Conditions of Guarantee page 26

and Electronic Equipment (WEEE) page 25

GENERAL INFORMATION

Please read this booklet thoroughly before you use this appliance.
It is important that you understand all the control functions before
commencing to cook with your Baumatic appliance.

Please remember the advice and warnings shown on page 5 which
is headed ‘IMPORTANT – Warning and Safety Instructions’.

This appliance is designed for domestic household use and can be
built into a standard kitchen cabinet or housing unit.
NOTE: The adjacent furniture or the housing and all materials used
in the installation must be able to withstand a minimum

temperature rise of 85°C above ambient during periods of use.
Certain types of vinyl or laminate kitchen furniture are particularly
prone to heat damage or discolouration at temperatures below the
above guidelines.
Installing the appliance in contravention of this temperature limit
or the placing of adjacent cabinet materials closer than 4mm to the
appliance, will be at the liability of the owner.

For use in Leisure Accommodation Vehicles, notice must be taken
of the appropriate statement in the Installation Instructions.

The use for any other purpose or in any other environment without
the express agreement of Baumatic Ltd, would invalidate any
warranty or liability claim.

Your new appliance is guaranteed against electrical or mechanical
defects subject to certain exclusions noted in Baumatic Ltd
Conditions of Guarantee.
The foregoing does not affect your statutory rights.

3

The Warranty applies to Great Britain and Northern Ireland only.
In the event that you require any After Sales Service or advice,
please contact the Baumatic Service Department on telephone
number – 0118 933 6911.
Before using this appliance ensure that any protective packaging or
coatings have been removed. To aid the protection of the
environment, please sort the packing materials into different types
and dispose of them in accordance with the local waste disposal
laws.
Any further information on waste disposal can be obtained from
your local Environmental Agency office.
When first used, an odour may be emitted by any residual
protective finish or moisture, which will cease after a short period
of time.

This Appliance has been Constructed and Distributed in
compliance with the essential requirements of the following EEC
DIRECTIVES and EUROPEAN NORMS:

CE Marking – 93/68 Low Voltage – 73/23 EMC – 89/336
Safety Standards – EN 60 335-1, EN 60 335 – 2 – 6.

As Baumatic have a policy of continued product improvement, the
right is reserved to adjust and make any modifications deemed
necessary without notification.

4

IMPORTANT NOTE –
WARNING AND SAFETY INSTRUCTIONS

This appliance complies with all current European safety
legislation, however Baumatic do wish to emphasise that
compliance does not remove the fact that the appliance surfaces
will become hot during use and retain heat after operation.

Baumatic advise that this appliance is not intended for use by young

children or infirm persons unless they have been adequately supervised
by a responsible person to ensure that they can use the appliance
safely. Young children should be supervised to ensure they do not
play with the appliance. If it is necessary for younger family
members to be in the kitchen, please ensure that they are kept under
close supervision at all times. During use, the appliance becomes hot.
Care should be taken to avoid touching heating elements inside the oven.

Do not place heavy objects on or lean on the oven door when open
as this can cause damage to the hinges.

Do not leave heated oil or fat unattended as there is a risk of fire.

Do not place pans or baking trays on the bottom of oven cavities or
line any part of the oven cavity with aluminium foil.

Do not allow electrical fittings or cables to be in contact with hot
areas of the appliance.

Do not use the appliance for space heating or to dry clothes.

Do not install the appliance next to curtains or soft furnishings.

Do not attempt to lift or move cooking appliances by pulling on any
door or handle as this can cause damage.

Always use oven gloves when moving food in or out of the oven cavity.

Warning: this ap

pliance must be earthed.

Do not pour water directly into the inside of a hot oven:
the enamel coating could be damaged.

Before any cleaning operation inside the oven, wait until it has cooled

down.

Do not use a steam cleaner with this appliance.

WARNING: accessible parts will become hot when in use.

To avoid burns and scalds children should be kept away.

5

NOTE: This appliance must be correctly installed by a suitably
qualified person, strictly in accordance with the manufacturer’s
instructions.

For electrical installations, NICEIC registration is recommended.

Baumatic Ltd declines any responsibility for injury or damage
to persons or property as a result of improper use or installation
of this appliance.

Heat, steam and moisture will be created during use, take care
to avoid injury and ensure that the room is adequately
ventilated. If prolonged use occurs, additional ventilation may
be required – please consult your Qualified Installer if you are
in any doubt about the amount required.

Please note that this appliance carries the CE mark for normal
domestic use and is not suitable for the marine environment.

6

INSTRUCTIONS FOR USE

These User Instructions should be retained for future reference and
for use by a person who is perhaps unfamiliar with the appliance.

The following models are covered by these instructions:

AS13

SS-A

B191SS-A

USING THE OVEN

The oven is controlled thermostatically between 40°C and
250°C depending on the temperature required.

The mode of cooking desired is selected by using the multifunction
control knob. The functions that can be selected are as follows:

OVEN LIGHT
The oven light remains on whilst the oven is in use.

CONVECTION MODE
This provides traditional cooking with heat from the
top and bottom elements.

LOWER ELEMENT MODE
This is for slow cooking or for warming up meals.

TOP ELEMENT MODE
This is for gentle cooking, browning or keeping
cooked dishes warm.

7

GRILL MODE
This is for grilling smaller items of food

FAN ASSISTED GRILL MODE
This provides quick browning to seal juices in the

food.

Both the grill and the fan come on. Most of
the cooking is done by grilling and the hot hair
is circulated around the oven. The oven door
should be kept closed. Please preheat the oven
for approximately 5 minutes before using.

PIZZA FUNCTION

This kind of cooking is ideal for pizza and vegetable
dishes. With this function, lower heating element,
circular heating element and fan motor work at the
same time.

FAN OVEN MODE
This provides even heating with the fan and allows
different dishes to be cooked at the same time on
different levels.

DEFROST MODE
The fan runs without heat to reduce the defrost time
for frozen food.

8

WARNING

• Ensure that the oven door is kept closed

when using the

GRILL.

• Do not use aluminium foil to cover the grill pan or heat

• Do not wrap items in aluminium foil and place under the

grill – the high reflectivity of the foil can damage the grill
element.

HELPFUL HINTS

• Before cooking, check that any unused accessories are
removed from the oven.

• Preheat the oven at cooking temperature before use.

• Place cooking trays in the centre of the oven and allow gaps

when using more than one tray for air to circulate.

• Try to open the door as little as possible to view food (the oven
light remains on during cooking).

• Be careful when opening the door to avoid contact with hot
parts and steam.

COOKING GUIDELINES

Please refer to the information on food packaging for guidance on
cooking temperatures and times. Once familiar with the
performance of your appliance, temperatures and times can be
varied to suit personal preferences.

Make sure that frozen foods are thoroughly thawed before
cooking, unless instructed otherwise.

9

USING THE ELECTRONIC PROGRAMMER

F
U
N
C
T

I
O
N

Timer

Minus settin

g

Temperatur

e

Setting the clock

Switch the oven on (230V). 00.00 will appear in blinking mode on
the display. To set the clock, simultaneously press the duration .
and end of cooking keys together. Using the +/- keys select
the time of day required. With the key “+” the time increases, with
the key “-” the time decreases at a speed directly proportional to the
duration of the pressure exerted on the key. When the time is stored,
the point between the hours and the minutes will stop blinking
approximately 7 seconds after the last operation. To update the
time, repeat the operation.

Manual operation

Press duration and end time button together. If an automatic

p

rogram is on the “AUTO” symbol (B) will be erased, the pot
symbol (C) is illuminated. Any programme which has been
previously set is cancelled.

B

C

D

A

Minute minder

Duration and manual mod

e

Automatic programme

Plus setting

Cooking end time

Cooking duration time

10

Semiautomatic operation with cooking duration

Select cooking duration function and set required duration with
the +/- button. “AUTO” (B) and cookpot (C) symbols appear. If
time of day= cooking end time the relay output and the cookpot
symbol (C) are switched off. The audible signal sounds. The
symbol “AUTO” (B) blinks. The cooking will be finished.

Semiautomatic operation with cooking end time

Select cooking end time function and set required end time
using the “+” and “-” keys. The “AUTO” (B) and cookpot (C)
symbols appear. Turn the switch knob and the thermostat knob to
the cooking function and to the desired temperature.
If time of day= cooking end time the oven doesn’t heat any longer
and the cookpot symbol (C) are switched off. The audible signal
sounds and “AUTO” (B) blinks.

Fully automatic operation

1) Set the length of cooking time by pushing the button and the
“+” and “-” keys.

2) Set the end of cooking time by pushing the button and the
“+” and “-” keys.

3) Set temperature and cooking program by using the thermostat
knob and the selector knob.
After this setting the symbol “AUTO” (B) will appear, this means
the oven has been programmed. When the time in the display is the
same of the cooking start time the cookpot symbol (C) will appear
and the oven will start to work.
Cooking Start Time= Cooking End Time – Cooking Duration Time
An example

: cooking lasts 45 minutes and is expected to stop at

14.00.

- Push and “+” key until having set 0.45.

- Push and “+” key until having set 14.00.

After having finished the setting, the clock hour will appear on the
panel and “AUTO” symbol (B) will flash permanently. This means
the cooking program has been memorized.

11

At 13.15 h. (14.00 h. minus 45 minutes ) the oven turns on
automatically. During cooking time the cookpot button (C) and
“AUTO” (B) switch on.
At 14.00 h. the oven turns off automatically, “AUTO” (B)
flashes. The cookpot button (C) switches off and a buzzer goes
on until it is stopped.

Minute counter

Select the minute counter function . The fixed time is set at
5 min.; to change it, press the keys +/-. When the point between
the hours and minutes and the symbol begin to blink, it
means that the countdown has begun. The display shows the
hour and the minutes of the countdown; by pressing the
symbol you can choose whether to display the countdown
or the time.

Audible signal

The audible signal sounds at the end of a minute counter
cycle or of a cooking programme for a period of 7
minutes. To turn it off just press any program input key (the first
three on the left ).
You can also regulate the sound level of the audio signal,
selecting a more pleasing level, by pressing the symbol “-” for
about 2 seconds when you see the time on the display.

Program start and control

Press the cooking duration key or the end-of-cooking time
key to know the remaining time period.

Input error signal

When a data input is mistaken the audio signal sounds and the
symbol “AUTO” (B) flashes.

Cancelling a program

A program can be cancelled pushing at the same time the
button . and .

12

Switch functions

The following functions can be set by turning the switch knob.

The following will be shown on

the display:

Light

190°C

50°C

190°C

250°C

165°C

165°C

165°C

Defrost

The temperature shown on the display can be changed via the keys
+/-. Increase or decrease is in 5°C steps, from a minimum of 40°C
to a maximum of 250°C. The symbol °C will blink until the
required temperature is reached.

13

CLEANING THE APPLIANCE

Always allow the appliance to cool down before cleaning to avoid
a burn injury.
Do not use caustic or abrasive agents, coarse wire wool or hard
tools as these can damage the surface finishes.
Normally, wiping with a soft cloth dampened with hot detergent is
sufficient, but for stubborn marks the following is recommended:

VITREOUS ENAMEL PARTS
Use only a cleaner that is recommended for this type of material –
avoid chloride-based products such as bleach.

DOOR GLASS
Do not use any abrasive medium that could cause damage.
Remember that if the surface of the glass panel becomes scratched,
this could lead to a dangerous failure.
To facilitate cleaning, the door glass can be lifted out after
removing the fixing screws.
When refitting, make sure that the glass is correctly seated in the
door recess and the correct way round.

Care must be taken when cleaning between the door glasses and

14

inside the inner frame as some of the edges maybe sharp due to
the manufacturing process.

REMOVING THE OVEN DOOR

To facilitate cleaning inside the oven, the door can be removed as
follows:

Hinges “A” are provided with two movable bolts “B”.
When bolt “B” is raised, the hinge is released from its housing.
Having done this, the door must be lifted upwards and removed,
sliding it towards the outside; grip the sides of the door near the
hinges when performing these operations.
To refit the door, firstly slide the hinges into their slots and
open the door fully.
Remember to rotate the two movable bolts “B” used to hook
the two hinges before closing the door. (Fig.1).

WARNING

• Take care not to dislodge
the hinge lock system when
removing the door as the
hinge mechanism has a
strong spring system!

• Do not immerse the door in
water at any time.

Fig.1

15

INSTRUCTIONS FOR INSTALLATION

This appliance must be installed by a competent person, in
accordance with the current version of the following UK
Regulations and Safety Standards or their European Norm
replacements:

Building Regulations (issued by the Department of Environment)
Building Standards (issued by the Scottish Development Department)
IEE Wiring Regulations
Electricity at Work Regulations

PRE-COMMISSIONING THE APPLIANCE

When unpacked, check that the following parts are included with
the appliance:

• Baumatic Instruction and Installation Book (all models)

•

2 oven shelves (all models)

•

Removable roof liner (all models except AS13SKX-A)

•

1 grill pan (all models)

• 1 trivet and 1 handle (all models except AS13SKX-A)

• Removable side racks (all models)

• 1 pizza stone (all models except B191)

• 2 low drip tray (AS13SKX-A only)

• Screws and plugs for fixing appliance into housing.

POSITIONING THE APPLIANCE (see Fig. 2 page 18)

These appliances are classified as Class 1.

16

INSTALLATION NOTES

1. Ensure that the aperture for oven installation is the correct size
as per Fig. 2 page 18.

2. Ensure that the rear panel of the furniture housing has been
removed.

3. All ovens with which this instruction book is provided may be
installed without the need for any additional ventilation cut­outs.

4. Ensure that the oven has been securely fixed into the housing.
The fixing of the oven in the cabinet is made by 4 screws “A”
That on the corner of the oven door-frame.

screws

Fixing the oven on the cabinet

17

Fig. 2: Installation distances for 60cm wide single electric ovens
(Shape of top casing may vary)

18

Fig. 4: Ventilation and cut-out requirements for installation of a
Single electric oven into a tall housing unit.

Fig. 3: Ventilation and cut-out requirements for installation of a
single electric oven into a standard kitchen unit.

19

INSTALLATION

AS13SS-A

20

ELECTRICAL CONNECTIONS

The installation must be carried out by a suitably
qualified person, in accordance with the current
version of the following.

o UK Regulations and Safety Standards or their European Norm

Replacements.

o Building Regulations (issued by the Department of the

Environment).

o Building Standards (issued by the Scottish Development

Department).

o IEE Wiring Regulations.
o Electricity At Work Regulations.

Before connecting the appliance, make sure that the supply voltage
marked on the Rating Plate corresponds with your mains supply
voltage.

WARNING: THIS APPLIANCE MUST BE EARTHED.

o This appliance should be wired into a 16 A double pole switched

fused spur outlet, having 3 mm contact separation and placed in
an easily accessible position adjacent to the appliance. The spur
outlet must still be accessible even when your oven is located in
its housing.

o To connect the oven power cord, loosen and remove the cover

on the terminal block, in order to gain access to the contacts
inside. Make the connection, securing the cord in place with the
cable clamp provided and then immediately close the terminal
block cover again.

o If you have to change the oven power cord, the earthing

(yellow/green) conductor must always be 10 mm longer than the
line conductors.

o Care must be taken to ensure that the temperature of the mains

supply cable does not exceed 50°C.

21

REPLACING THE MAINS LEAD

In the event it is necessary to replace the mains supply lead,
proceed as follows:

1. Disconnect the appliance from the supply, undo the fixing
screws and remove the back panel.

2. Undo the clamp screws and terminal screws to release the
existing lead.

3. Assemble the replacement lead that must conform to the
specification listed in the Technical Data, ensuring the correct
colour code connection and that all screws are tightened
correctly.

MAINTENANCE

Before carrying out any maintenance, disconnect the appliance
from the electricity supply.

During the guarantee period, in case of need all service
interventions should be referred back to the Baumatic Ltd
Service department. Please note that intervention or repair by
any unauthorised personnel will invalidate such guarantee.

22

REPLACING THE OVEN LIGHT

(Not covered by the appliance
warranty)

Disconnect the appliance from the
electricity supply, remove the oven
door (as described previously) as
well as the oven shelves.

Remove the protective glass light­cover by twisting anti-clockwise.

Unscrew the old bulb and discard
safely, replace with the type
specified in the Technical Data and
refit the cover.

NOTE – The glass cover may be tight and may therefore
require a tight grip to release.

CARE AND REPLACEMENT OF CATALYTIC LINERS

(Where fitted, the liners are not covered by the appliance
warranty).

To keep the ‘stay clean’ liners operating effectively, the oven
should be heated to at least 200°C whenever heavy soiling has

occurred, in order to avoid permanent soiling.

If the liners are allowed to become black and shiny, they must be
replaced by new items. Remove all internal accessories to facilitate
replacement of the liners.

Replacement liners may be purchased directly from the Baumatic
Spares Department (details as per back cover). Please quote
product-type, model number and the references B600 along with
your appliance’s serial number when placing your order.

23

TECHNICAL DATA

DIMENSIONS

Height: 591mm
Width: 597mm
Depth: 525mm

COOLING FAN

A tangential cooling fan is fitted on the following models:

AS13, AS13.1, B191

ELECTRICAL DETAILS

Rated Voltage: 230V a.c. 50Hz

Supply Connection: 16A (double pole switched fused outlet

with 3mm contact gap)

Max Rated Inputs:

AS13, AS13.1, B191: 3,68 kW

Mains supply lead: 3x 1.5mm type H05 RR-F <HAR>

Oven Light Bulb: 25W/300°C Screw type pigmy

24

2

This appliance is marked according to the European directive
2002/96/EC on Waste electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate
waste handling of this product.

The symbol on the product, or on the documents
accompanying the product, indicates that this appliance may not
be treated as household waste. Instead it shall be handed over to
the applicable collection point for the recycling of electrical and
electronic equipment.

Disposal must be carried out in accordance with local environmental
regulations for waste disposal.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you

purchased the product.

European directive on Waste Electrical

and Electronic Equipment (WEEE)

25

26

BAUMATIC LTD. - CONDITIONS OF GUARANTEE.

Dear Customer,

The conditions of guarantee which apply to your Baumatic appliance are as follows: This product is
guaranteed for 12 months from the date of original purchase.
Baumatic Ltd will repair any defect that arises due to faulty materials or workmanship free of charge
during this period.

In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge
the parts required to repair the appliance, only if they are fitted by a Baumatic engineer, for any defect
that arises due to faulty materials or workmanship within a period of 5 years from the original purchase
date.

An additional and annually renewable insurance scheme for labour is available should you wish to extend
the warranty period.

Should any person other than an authorised representative of Baumatic Ltd interfere with the appliance,
the policy is negated and Baumatic Ltd will be under no further liability.

The guarantee covers the appliance for normal domestic use only, unless otherwise stated.

Any claims made under the terms of the guarantee must be supported by the original invoice/bill of sale
issued at the time of purchase.

This guarantee is transferable only with the written consent of Baumatic Ltd.

If the appliance fails and is considered either not repairable or uneconomical to repair between twelve
months and five years from purchase date, a free of charge replacement will not be offered.

The guarantee for any replacement will only be for the remainder of the guarantee on the original product
purchased.

This guarantee does not cover:

x Sinks and taps
x Failure to comply with the manufacturer’s instructions for use.
x The replacement of cosmetic components or accessories.
x Accidental damage or wilful abuse.
x Subsequent loss or damage owing to the failure of the appliance or electrical supply.
x Incorrect installation.
x Losses caused by Acts of God, civil war, failure to obtain spare parts, strikes or lockouts.
x Filters, fuses, light bulbs, external hoses, damage to bodywork, paintwork, plastic items, covers,

baskets, trays, shelves, burner bases, burner caps, decals, corrosion, rubber seals, refrigeration
system blockage.

In the course of the work carried out it may be necessary to remove the appliance from its operating
position. Whilst all reasonable care will be taken, Baumatic Ltd cannot accept responsibility for damage
sustained to any property whatsoever in this process.

This guarantee is in addition to and does not diminish your statutory or legal rights.

Contacting Baumatic.

SALES
TEL: [phone]
FAX: [phone]

SERVICE
TEL: [phone]
FAX: [phone]

SPARES
TEL: [phone]
FAX: [phone]

TECHNICAL / ADVICE
TEL: [phone]
FAX: [phone]

For mainland UK and Northern Ireland, please contact one of the above numbers for further information or
any other query you may have.

For ROI (Republic of Ireland), please contact one the numbers below:

TEL: [phone] FAX: [phone]

35

Thank you for buying Baumatic.

*

.

*

01 - 6266798

01 - 6266634

Applies to UK, Scotland, Wales & Northern Ireland only. (Republic of Ireland has 1 year labour and 1 year parts warranty only)

*

Cod. 12300013833

®

Baumatic

www.baumatic.com
