Bartscher Soap dispenser, wall-mounting,SS,1L Operating instructions

850.007

Bedienungsanleitung

Seifenspender

Instruction manual

Soap dispenser

Mode d’emploi

Distributeur de savon

Manuale di utilizzo

Dispenser di sapone

Mantenga las instrucciones

Dispensador de jabón

Manual de instruções

Dispensor de sabonete

Gebruiksaanwijzing

Zeepdispenser

Brugsanvisning skal

Sæbedispenser

Инструкция по эксплуатации

Дозатор для жидкого мыла

D

GB/UK

F/B/CH

I/CH

E

P

NL/B

DK

RUS

/A/CH

TR

PL

CZ

HR

H

GR

Kullanma kılavuzu

Sabun dispanseri

Instrukcja obsługi

Dozownik do mydła

Návod k obsłużę

Dávkovač mýdla

Upute za upotrebu

Dozator sapuna

Használati útmutató

Szappanadagoló

Οι οδηγίες χρήσης που ακολουθούν

Συσκευή υγρού σαπουνιού

V1/0611

GB/UK

Technical data:

-------------------------------------------------- --------------------------------------

Name: ●
Code-No: ●

Material: ● chrome nickel steel, brushed
Capacity: ● 1 liter
Dimensions: ● width 123 x D 110 x height 204 mm
Weight: ● 0.5 kg
Equipment: ● fastening materials

Soap dispenser for wall mounting

850.007

----------------------------------------------------------------------------------------

Delivery without filling!

List of components

②

①

Housing / container

①

Opening for filling

②

Fill level indicator

③

Pump

④

③

④

Features:

• Ideal for use in public bathrooms, such as restaurants, hotels, airports, etc.;

• Manual, cartridge-free pumping system for liquid soap;

• Fill level indicator;

• Low maintenance.

Installation

• Unpack the soap towel dispenser and remove the packaging.

• Attach the soap dispenser near sinks, in an easily accessible place.

- 3 -

• Remove the wall bracket from the soap dispenser and mark on
the wall holes to be drilled based on the holes in the wall
bracket at the desired height.

• Drill 3 holes in the wall and insert the wall plugs connected to
the dispenser.

• Screw the wall bracket to the wall with the attached screws and
then hang the soap dispenser on the bracket.

• Make sure that the soap dispenser snaps into the wall bracket.

• In conclusion, tighten the screw inside

the container.

Filling with soap / taking soap

Opening for filling

• Press the pump at the front of the unit to dispense
soap as needed.

Cleaning

• Clean the soap dispenser with a soft, damp cloth.

• Never use harsh or abrasive cleaners that could scratch

the surface.

• After washing use a soft, dry cloth to dry and polish the
surface.

• Open the opening for filling the soap dispenser
and fill the container with liquid soap.

• The minimum capacity is approximately 300 ml.

Wall bracket

Screw

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten Tel.: [phone]
Germany Fax: [phone]

- 4 -
