MDI SNACK III Plus - MDI SNACK
IV Plus
A162828 - A162829
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: +49 5258 971-0
Fax: +49 5258 971-120
Technical Support Hotline: +49 5258 971-197
www.bartscher.com
Version: 1.0
Date of preparation: 2021-02-23
EN
Original instruction manual
1 Safety ............................................................................................................ 2
1.1 Explanation of Signal Words .................................................................... 2
1.2 Safety instructions.................................................................................... 3
1.3 Intended Use ........................................................................................... 6
1.4 Unintended Use ....................................................................................... 6
2 General information ....................................................................................... 7
2.1 Liability and Warranty .............................................................................. 7
2.2 Copyright Protection ................................................................................ 7
2.3 Declaration of Conformity ........................................................................ 7
3 Transport, Packaging and Storage ................................................................ 8
3.1 Delivery Check ......................................................................................... 8
3.2 Packaging ................................................................................................ 8
3.3 Storage .................................................................................................... 8
4 Technical Data ............................................................................................... 9
4.1 Technical Specifications .......................................................................... 9
4.2 List of Components of the Appliance ..................................................... 11
4.3 Functions of the Appliance ..................................................................... 13
5 Installation and operation ............................................................................ 13
5.1 Installation .............................................................................................. 13
5.2 Operation ............................................................................................... 14
6 Cleaning ...................................................................................................... 21
6.1 Safety Instructions for Cleaning ............................................................. 21
6.2 Cleaning ................................................................................................. 22
7 Possible Malfunctions .................................................................................. 23
8 Disposal ....................................................................................................... 24
A162828 1 / 26
Safety
EN
Read this instruction manual before using and keep it available
at all times!
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.
Diese Bedienungsanleitung beschreibt di e Installation, Bedienung und Wartung d es Geräts und gilt als wichtige Infor mationsquelle und Nachschlagewer k. Die Kenntnis aller enthaltenen Sicherh eitshinweise und Handlungsanweisunge n schafft die Voraussetzung f ür das sichere und sachgerechte Ar beiten mit dem Gerät. Darüber hinaus müssen die für den Einsatzbereich des Geräts geltenden örtlichen Unfall verhütungsvorschriften und allgemeine n Sicherheitsbestimmungen eingehalten werden. Diese Bedienungsanleit ung ist Bestandteil des Produkts und muss in unmittelbarer Nähe des Ger äts für das In¬stallations-, Bedienu ngs-, Wartungs- und Reinigungspers onal jederzeit zugänglich auf¬bewahrt werd en. Wenn das Gerät an eine dritt e Person
weitergegeben wird, muss die Bedienungsa nleitung mit ausgehändigt werden.
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
2 / 26 A162828
Safety
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
, die
1.2 Safety instructions
Electrical Current
• Too high a mains voltage or incorrect installation may cause electric shock.
• The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
• To avoid short-circuit, the appliance should be kept dry.
• If there are malfunctions during operation, disconnect the appliance from the
power supply.
• Do not touch the appliance’s plug with wet hands.
• Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
• Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
• Do not transport the appliance, holding it by the power cord.
• Do not allow the power cord to come into contact with heat sources or sharp
edges.
• Do not bend, pinch nor knot the power cord.
A162828 3 / 26
Safety
EN
• Always completely unwind the power cord.
• Never place the appliance or other objects on the power cord.
• Always take hold of the plug to disconnect the appliance from the power supply.
• Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Flammable Materials
• Never subject the appliance to contact with high temperature sources, e.g.:
oven, furnace, open flame, heat generating devices, etc.
• To avoid fire hazard, clean the appliance regularly.
• Do not cover the appliance with, e.g., aluminium foil or cloths.
• Use the appliance only with materials designated to this end and with correct
temperature settings. Materials, groceries and left-overs remaining in the
appliance may catch fire.
• Never use the appliance near flammable or inflammable materials, e.g.: petrol,
spirit, alcohol, etc. High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
• In case of fire, disconnect the appliance from the power supply before
attempting suitable fire-extinguishing actions.
• Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
Safety during deep fat frying
• Never leave the operating appliance without supervision. Possible malfunctions
may lead to overheating and ignition of frying oil / fat in cubes (blocks).
• If due to overheating, the frying oil / fat in cubes (blocks) catches fire, put the lid
on and disconnect the appliance from the power supply.
• Spatters or outbursts of hot oil/fat may cause scalding of hands, arms and face.
Use protective kitchen mitts.
• Do not use wet nor humid products. Dry them before use. Remove excess of ice
from deep frozen products prior to frying them.
• Do not hang frozen food in the basket over the tank filled with hot frying oil / fat
in cubes (blocks). When deep frying in fat, even the smallest drop of water may
cause spatters of hot oil or even small outbursts.
4 / 26 A162828
Safety
EN
Hot Surfaces
• Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
• Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
• You may transport and clean the appliance after it cools down entirely.
• It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.
Health hazard due to burnt food products
• Acrylamides that are present in burnt food products are hazardous to health and
may cause cancer. In order to avoid or reduce acrylamide content, products
should always be fried to the point, when their colour is golden–yellowish, and
not dim and dark nor brown.
• Burnt left-overs and scrubs should be regularly removed from frying oil.
• Products containing starch — cereals and potato products in particular —
should be fried in a maximum temperature of 180 °C.
Improper Use
• Unintended or prohibited use may cause damage to the appliance.
• The appliance may only be used when its technical condition is flawless and
allows for safe operation.
• The appliance may only be used when all connections are executed according
to rules of law in force.
• The appliance may only be used when it is clean.
• Use only original spare parts. Never attempt to repair the appliance on your own.
• Do not introduce any changes in the appliance nor modify it.
Operating Personnel
• The appliance may only be operated by qualified personnel and trained
specialist personnel.
• This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
• Children should be supervised to ensure that they are not playing with or
switching on the appliance.
A162828 5 / 26
Safety
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
– Deep fat frying of adequate food products.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
– Deep fat frying of inadequate food products.
– Deep fat frying of wet or humid food products.
– Do not hang frozen food in the fryer’s basket over the hot frying oil/fat.
6 / 26 A162828
General information
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
– failure to observe instructions,
– unintended use,
– technical alterations introduced by the user,
– usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.
A162828 7 / 26
Transport, Packaging and Storage
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
– in closed rooms;
– in dry and dust-free surrounding;
– away from aggressive agents;
– in a location protected against sunlight;
– in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.
8 / 26 A162828
Technical Data
EN
4 Technical Data
4.1 Technical Specifications
Version / Characteristics A162828 / A162829
• Type: table-top appliance
• Type of power supply: electric
• Appliance connection: ready to plug in
• Heating element:
– stainless steel
– can be piovoted out
• Temperature control:
– electronic
– in 1°C increments
• Oil temperature check:
– current temperature can be displayed at all times
– indicator lamp for the set oil temperature reached
• Fat drain tap
• Digital display
• Cold zone
• Safety thermostat
• Control: knob
• ON/OFF switch
• Indicator lights: heating, ON/OFF, ready/set temperature reached
• Important indication:
– intended for use with frying oil and fat in cubes (blocks)
– for A162829 deep-fat dryer there are 2 separate mains sockets required
A162828 9 / 26
EN
Name:
Deep fat fryer MDI SNACK III Plus
Article number:
A162828
Material:
Stainless steel
Number of basins:
1
Basin volume, in litres:
9
Basin dimensions (W x D x H), in mm:
240 x 300 x 200
Number of baskets:
1
Basket volume, in l:
5,5
Basket dimensions (W x D x H), in mm:
210 x 220 x 120
Temperature range, min.–max., in °C:
50 - 190
Connected load:
3,3 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
300 x 530 x 385
Weight, in kg:
6,4
Name:
Deep fat fryer MDI SNACK IV Plus
Article number:
A162829
Material:
Stainless steel
Number of basins:
2
Basin volume, in litres:
2 x 9
Basin dimensions (W x D x H), in mm:
240 x 300 x 200
Number of baskets:
2
Basket volume, in l:
5,5
Basket dimensions (W x D x H), in mm:
210 x 220 x 120
Temperature range, min.–max., in °C:
50 - 190
Connected load:
2 x 3,3 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
575 x 530 x 385
Weight, in kg:
11,9
The set includes:
– 1 basket
– 1 lid
Technical Data
We reserve the right to implement technical modifications.
10 / 26 A162828
Technical Data
EN
Fig. 1
1. Main appliance
2. Basket with handle
3. Control box
4. Control panel
5. Feet (4 pcs)
6. Fat drain tap
7. Heating element with cover
8. Basin
9. Oil drain opening
10. Lid with handle
The set includes:
– 2 baskets
– 2 lids
4.2 List of Components of the Appliance
A162828
A162828 11 / 26
EN
Fig. 2
1. Main appliance
2. Basket with handle (2x)
3. Control box (2x)
4. Control panel (2x)
5. Feet (4 pcs)
6. Fat drain tap (2x)
7. Heating element with cover (2x)
8. Basin (2x)
9. Oil drain opening (2x)
10. Lid with handle (2x)
A162829
Technical Data
12 / 26 A162828
Installation and operation
EN
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
4.3 Functions of the Appliance
Correct frying in a simple way: Thanks to digital control knob, MDI Bartscher, you
may set the temperature with accuracy down to one degree. Plus, current oil
temperature check is possible at all times.
5 Installation and operation
5.1 Installation
Unpacking / Positioning
• Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
• If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
• Be careful not to damage the rating plate and warning labels fixed on the
appliance.
• Never place the appliance in humid or wet environment.
• Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
• The appliance should be placed on surfaces that are:
– even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
– sufficiently large, and thus enabling usage of the appliance with no
problems;
– easily accessible;
– well ventilated.
• Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
• Leave at least 20 cm clearance from flammable walls and items.
A162828 13 / 26
Installation and operation
EN
WARNING!
Fire hazard!
Operation of the appliance with the oil level below MIN mark may lead to
overheating of frying oil and cause oil to catch fire.
The oil level should be between MIN and MAX marks on the side wall of
the basin.
If overheated during operation, the frying oil or fat in cubes (blocks)
may catch fire.
The appliance should not remain in use for extended periods of time. If
there is a break between subsequent frying processes, set lower
temperature.
Never place the lid on during or immediately after the frying process.
The lid serves only the purpose of covering against dust and to maintain
the oil temperature.
Power supply connection
• Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
• Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
• The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
• In order to connect the twin fryer, 2 separate sockets are necessary.
• Do not use the appliance with an external timer or remote control.
5.2 Operation
Warning Indications
• Insert the bottom cover in the appliance. Th e cover acts as a spacer between t he heating element and left-over fo od tray.
Carefully put the connection box with the h eating element on the back edge of t he appliance. The pin in the connection box lower part must enter the hole in the main appliance. This way the c onnection box is properly mounted.
14 / 26 A162828
Installation and operation
EN
CAUTION!
Risk of burns!
Due to lower flashpoint, old oil that had already been used for frying,
exhibits a tendency for self-ignition and favours frothing.
Do not use old oil for frying.
Regularly change frying oil.
When the oil level is above the MAX mark during operation of the
appliance, hot oil may spill out.
The oil level should be between MIN and MAX marks on the side wall of
the basin.
If the basket is overfilled with products for frying, the frying oil or fat in
cubes (blocks) may boil over.
Observe the maximum allowable level of filling the basket (3 kg) with
products for frying.
If water enters hot frying oil, it may cause spatters of oil and scalding.
Use only dry products for frying.
When draining hot frying oil / fat in cubes (blocks) be aware of the
risk of burns due to spatters of oil.
The frying oil / fat in cubes (blocks) should be cooled down a bit and drain
very carefully.
3. Remove the control box with heating
element and permanently fixed cover from
the appliance by pulling it out of fastening
element and upwards.
Fig. 2
Preparation of the Appliance
1. Take out the equipment (lid, basket(s)) from the appliance.
2. Place the basket handle in the right position, spreading it upwards and pulling by
the fastening grip and snapping in place.
4. Prior to first use, thoroughly clean the appliance and equipment according to
instructions in section 6 'Cleaning'.
A162828 15 / 26
Installation and operation
EN
Fat drain tap is equipped with a safeguard, preventing its
accidental opening. First, the tap must be pressed in —
only then may it be rotated.
6. Prior to filling the basin with frying oil / fat in cubes
(blocks) close the fat drain tap.
Fig. 3
NOTE!
For safety reasons, the appliance operates only when the control box is
properly mounted on the housing, so that the micro-switch below the
control box sets the appliance ready for operation.
5. After cleaning, mount the control box with heating element on the fastening
element of the appliance.
Instructions for Using Frying Oil or Fat in Cubes (Blocks)
• Always use oil suitable for frying (e.g. vegetable oil, sunflower oil, peanut oil,
etc.) or fat in cubes/blocks only.
ATTENTION!
Fat in cubes (blocks) should never be melted in high temperatures; this
may cause the temperature sensor to get damaged.
Fat in cubes/blocks should be melted in the deep-fat fryer, with melting point
position selected.
Observe indications in section 'Indications for Melting Fat in Cubes (Blocks)'.
• Use only oils and fats that are suitable for frying in high temperatures.
• Never mix different types of oil or fat as their boiling points may vary.
16 / 26 A162828
Installation and operation
EN
Indications for Melting Fat in Cubes (Blocks)
in the Deep-Fat Fryer
1. Remove the basket from the basin.
2. Place the fat in cube (block) directly on the cover of the heating element, so that
it is covered.
3. Connect the appliance to a single grounded socket.
The green power indicator light in the ON/OFF switch lights up.
The digital display in the push rotary control knob shows 'OIL', to check the
condition of oil in the basin.
4. Rotate the push rotary control knob, until 'ooo' is shown in the digital display.
This is the melting point position.
5. To start the melting process, briefly press the push rotary control knob.
6. Wait for the fat in cube (block) to melt.
7. When the heating element is covered with liquid fat, the push rotary control knob
may be rotated and set to maximum temperature setting.
8. Place subsequent blocks of fat for melting in the basin, until the right filling level
is reached.
9. Then rotate the controller to set the temperature.
ATTENTION!
Fat in cubes (blocks) that has coagulated in the deep-fat fryer may be
heated up and melted only with the melting point function of the
appliance.
In the Separate Basin
1. To get the fat in cubes (blocks) faster in liquid form, there is a possibility of
melting it in a separate container (e.g., a pot) on a hob.
2. Then, pour the melted fat into the deep-fryer's basin.
A162828 17 / 26
Installation and operation
EN
Fig. 4
1. Push rotary control knob
2. Digital display
3. Indicator light
4. Ready/set temperature reached indicator
light (green)
5. ON/OFF switch with integrated power
indicator light (green)
Filling the Basin with Frying Oil or Fat in Cubes (Blocks)
CAUTION!
Prior to filling with the frying oil or fat in cubes (blocks), the basin must be
clean and dry.
1. Make sure the fat drain tap is closed and locked.
2. Prior to switching on, the basin must be filled with the required amount of liquid
frying oil or fat in cubes (blocks).
3. During operation observe the level of oil in the basin and, if needed, top up with
frying oil or fat in cubes (blocks).
CAUTION!
Never use the appliance if there is no oil for frying or fat in cubes (blocks)
in the basin.
Control Elements / Displayed Messages
18 / 26 A162828
Installation and operation
EN
Switching on
1. Connect the appliance to a single grounded socket.
The green power indicator light in the ON/OFF switch lights up.
The digital display in the push rotary control knob shows 'OIL', to check the
condition of oil in the basin.
2. Operate the push rotary control knob by briefly pressing it.
3. Then rotate the controller to set the temperature.
The temperature may be set within the range of 50°C – 190°C.
The temperature is controlled with 1°C increments.
A red indicator light is lit in the push rotary control knob during the heating phase.
To check the current temperature, press the push rotary control knob. The digital
display will display the current temperature. The red indicator light blinks.
NOTE!
When you check the current temperature, you may change temperature
setting.
4. Press the push rotary control knob again to return to the previous message.
When the set temperature is reached, the ready/set temperature reached green
indicator light will light up.
When the temperature in the basin drops, the appliance heats up again, and the red
information indicator light lights up again.
5. For best results, wait until the appliance reaches the desired temperature and
the suitable indicator light lights up, and then place suitable food products in the
fryer.
NOTE!
Do not use frying oil nor fat in cube (block) for an extended period of time
in too low a temperature, as they cease to be suitable for use.
Frying of Food
1. Place products for frying in the basket.
2. Using the handle slowly lower the basket into the basin with frying oil or fat in
cube (block).
3. Place the basket on the cover of the heating element.
A162828 19 / 26
Installation and operation
EN
4. Fry the food.
5. After frying, carefully remove the basket using the
handle and use the hook to hang the basket on
the fixture for hanging on the control box.
6. Wait for the excess of fat to drip off of the fried
products.
Fig. 5
7. When the frying process and operation of the appliance are completed, rotate
the push rotary control knob to '0' position, and switch the ON/OFF switch to 'O'
position.
Draining off and Removal of Frying Oil / Liquid Fat in Cube (Block)
ATTENTION!
The used frying oil / fat in cube (block) should be disposed of according to
provisions of law on environment protection and local regulations in force.
1. The frying oil / liquid fat in cube (block) should be replaced when it no longer
fulfils legal requirements.
NOTE!
If the fat from cubes (blocks) hardens in the fryer, it may only be melted
with the melting point function; then, the fat should be drained through the
fat drain tap.
2. After cooling, the frying oil or fat in cube (block) should be drained from the
basin via fat drain tap into a suitable container. Make sure that the container is
placed stably.
20 / 26 A162828
Cleaning
EN
– leave the appliance to cool down completely;
– screw off plastic cover over the RESET button on
the rear wall of the control box, rotating it counterclockwise;
– press the button;
– screw the plastic cover anew, rotating it clockwise;
– switch the appliance on as usual.
Fig. 6
Overheating Protection System
If the fryer is accidentally switched on without frying oil / fat in cube (block), or if the
basin is filled with fat to the level below required minimum, the overheating
protection system automatically switches off the appliance. This function serves the
purpose of protecting the appliance against possible damages.
1. Disconnect the appliance from mains power supply.
2. Perform the following steps:
6 Cleaning
6.1 Safety Instructions for Cleaning
• Before cleaning, disconnect the appliance from the power supply.
• Leave the appliance to cool down completely.
• Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
• Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
• For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.
A162828 21 / 26
Cleaning
EN
6.2 Cleaning
1. At the end of a working day clean the appliance thoroughly.
2. Remove the basket from the basin.
3. Raise the heating element and leave it to drip off.
4. Drain the cooled frying oil from the basin.
NOTE!
Observe instructions in section 'Exchange and Removal of Frying Oil /
Liquid Fat in Cubes (Blocks)'.
ATTENTION!
Moisture may enter electric installation or control box and cause electric
shock during switching on.
The main appliance nor the power cord may never be cleaned wet, nor under
running water or any other liquid.
5. Remove the control box with the heating element and its cover from the
appliance. This allows for easy washing of the heating element and the basin.
6. Clean the control box and the heating element with its cover using a damp, soft
cloth and mild cleaning agent. Wipe with a clean cloth.
7. The control panel may be wiped only with lightly damp cloth.
8. Clean the basket (baskets) and the lid (lids) in hot water with mild cleaning
agent. If necessary, heavily soiled elements may be drenched for some time.
9. Wash the basin with warm water and mild cleaning agent. Use soft cloth or
sponge.
10. Drain the water after washing to a suitable container using the fat drain tap.
Then rinse the basin with fresh water and drain it using the fat drain tap again.
11. Wipe the surface of the appliance and power cord only with a slightly damp
cloth.
22 / 26 A162828
Possible Malfunctions
EN
Error
Possible Cause
Solution
The appliance is
connected to the power
supply, switched on, but
the digital displays of
push rotary control knobs
do not show any values
Interrupted power supply
Check the power supply
and the cord for damage or
faults
Safety fuse tripped
Check the fuse, connect
the appliance to another
socket
No power supply
Check the electric power
supply
Appliance is connected
to the power supply,
switched on temperature
set, but the appliance
does not heat up
At least one of the
heating elements is
damaged
Contact the service
company
Appliance stops heating
after some time
Overheating protection
tripped: Too high a
temperature in the basin
(approx. 230°C)
Leave the appliance to cool
down and re-start,
observing indication in
section 'Overheating
Protection System'
7 Possible Malfunctions
Mögliche
The table below contains descriptions of possible causes and solutions to
malfunctions or errors during operation of the appliance. When malfunction cannot
be removed, contact the technical service.
A162828 23 / 26
Disposal
EN
Electric appliances are marked with this symbol. Electrical
appliances must be disposed of and recycled in a correct
and environmentally friendly manner. You must not dispose
of electric appliances with household waste. Disconnect the
appliance from the power supply and remove power cord
from the appliance.
8 Disposal
Electrical Appliance
Electrical appliances should be returned to designated collection points.
Used frying oil
Dispose of the used frying oil according to provisions of natural environment
protection law in force.
24 / 26 A162828
Loading...
