1. Welcome!
1. WELCOME!
1.1 About the product
Overview
Thank you for choosing this Coronis Fusion 6MP!
Coronis Fusion 6MP is an ingenious PACS display system designed to further enhance flexibility and
productivity in diagnostic imaging. Featuring the industry’s first 30-inch color LCD that can be used a s two
seamless heads or one wide-screen display, Coronis Fusion 6MP offers you the freedom to organize your
workspace just the way you want it. It allows you to read CT, MR, cath and echo cardiogram images, or
any other combination, side by side on a single diagnostic screen. Coronis Fusion 6MP features the latest,
breakthrough In-Plane Switching (IPSPro) LCD technology. This technology brings the most advanced
LCD viewing characteristics on the market, setting new standards for brightness and co
a wide viewing angle. Use the instructions in this guide to install your Coronis Fusion 6MP display and
discover all these interesting features yourself!
ntrast, even from
CAUTION: Read all the important safety information before installing and operating your
Coronis Fusion 6MP. Please refer to the de dicated chapter in this user guide.
1.2 What’s in the box
Overview
Your Coronis Fusion 6MP comes with:
• this Coronis Fusion 6MP user guide
• a system CD
• two DVI cables
• two DisplayPort cables
• a USB cable
• a set of AC power cords
• an external power supply
If you ordered a Barco display controller, it’s also in the box together with its accessories. A dedicated
user guide is available on the system CD.
Keep your original packaging. It is designed for this display and is the ideal protection
during transport and storage.
K5902055 CORONIS FUSION 6MP 28/08/2013 3
1. Welcome!
4 K5902055 CORONIS FUSION 6MP 28/08/2013
2. Parts, controls and connectors
2. PARTS, CONTROLS AND
CONNECTORS
2.1 Display front view
Overview
8
1
Image 2-1
Front view
1
USB downstream connectors
3
Right/Down key
5
Stand-by/Cancel key
7
Control wheel
K5902055 CORONIS FUSION 6MP 28/08/2013
32 4 5 6 7
2
Left/Up key
4
Menu/Enter key
6
Power status indicator light
8
Ambient light sensor
5
2. Parts, controls and connectors
2.2 Display rear view
Overview
1 32 4 5 6 7 8 9 10 11 12
Image 2-2
Rear view
1
+24 VDC power input
3
DVI 2 video input
5
Connector compartment cover
7
DisplayPort 1 video input
9
DVI 1 video input
11
USB upstream connector
2
+5 VDC, 0.5 A power output
4
DisplayPort 2 video input
6
Neck cover
8
Display stand cover
10
Ethernet connector (see note below)
12
USB downstream connector
The Ethernet connection is used for maintenance purposes and is not supported for
user application.
6 K5902055 CORONIS FUSION 6MP 28/08/2013
3. Display installation
3. DISPLAY INSTALLATION
Prior to installing your Coronis Fusion 6MP and connecting all necessary cables, make
sure to have a suitable display controller physically installed in your computer. If you
are using a Barco display controller, please consult the user guide deli vered with it to
do this.
3.1 Removing th e covers
The connector compartment cover should be removed to get access to the connectors.
To remove the connector compartment cover
1. Gently lift the clips at one of the handles of the connector compartment cover to release that side of the
cover.
2. Do the same at the other side of the cover.
3. Remove the cover.
The display stand cover should be removed to get access to the cable routing channel.
To remove the display stand cover
1. Gently press and hold the clips at the inside top of the cover.
K5902055 CORONIS FUSION 6MP 28/08/2013
7
3. Display installation
2. Slide the cover upwards while holding the clips pressed.
3.2 Unlocking the height mechanism
In the factory, the height-positioning system in the display stand is locked with a red
hook to prevent damage during transportation. You’ll have to remove this hook before
adjusting your display height position.
To remove the hook:
1. Position the display with its rear side facing you.
2. While holding the display panel pushed down, pull out the red hook in the display stand.
8
K5902055 CORONIS FUSION 6MP 28/08/2013
3. Display installation
3. Keep the clip in the dedicated hole in case the display needs to be shipped later.
To retain the hook for possible future transportation, insert the short, red end of the
hook back into the stand of your display.
3.3 Adjusting the display position
Now that the height-positioning system of your display is unloc
display position.
To adjust the display position
1. Tilt, swivel, raise and lower the display as desire
d.
ked, you can adjust the
K5902055 CORONIS FUSION 6MP 28/08/2013 9
3. Display installation
CAUTION: Do not try to pivot your display when attached to t he stand. Trying to do so
could cause serious damage to your display and its stand.
3.4 Connecting the signal cables
To get access to the connectors, remove the connector compartment cover. See "Removing the covers", page 7 .
Each side of your display can have a different video input connected (one side can have
DVI connected while the other side has D isplayPort connected). Both display sides can
have the same video input connected as well but only one video input is allowed on each
side of your display.
To connect the signal cables to the display:
1. Connect one head of the display controller to the DVI 1 or DisplayPort 1 connector with one of the
supplied DVI or DisplayPort cables.
2. Connect another head of the display controller to the DVI 2 or DisplayPort 2 connector with one of the
supplied DVI or DisplayPort cables.
3. If you want to make use of your display’s USB downstream connectors, connect a PC USB downstream
connector to the display’s USB upstream connector by means of the supplied USB 2.0 cable.
10
K5902055 CORONIS FUSION 6MP 28/08/2013
3. Display installation
3.5 Connecting the power cable
To connect the power cable to the display:
1. Connect the supplied external DC power supply to the +24 VDC power input of your Coronis Fusion
6MP display.
2. Plug the other end of the external DC power supply into a grounded power outlet by means of the proper
power cord delivered in the packaging.
3.6 Routing the cab les
To route the cables
1. Route all connected cables through the cable routing channel in the stand of your display.
Tip: The cable straps at the inside of the connector compartment allow you to fix the cables for better
shielding of the cables.
3.7 Re-attaching the covers
To re-attach the display stand cover
1. Slide the display stand cover downward. You’ll hear a “click” sound of the cover’s clips when the display
stand cover is in position.
K5902055 CORONIS FUSION 6MP 28/08/2013
11
3. Display installation
Pay a ttention that all cables stay in the cable channel while re-attaching the cover.
To re-attach the connector compartment cover
1. Slide the cover’s top in position and then push the cover’s bottom. You’ll hear a “click” sound of the
cover’s clips when the connector compartment cover is in position.
3.8 VESA-mount installation
WARNING: Use an arm that is approved by VESA (according to the VESA 100 mm stan-
dard).
Use an arm that can support the weight of
tions of this display for the applicable weight.
CAUTION: You should mount the panel in landscape position. Portrait position is pos-
sible but not supported.
Overview
The panel, standard attached to a stand, is compatible with the VESA 100 mm standard. Thus, it can be
used with an arm that is approved by VESA. This chapter shows you how to release the panel from the
stand and how to attach it to an arm. If you’re not using an arm, you can skip this chapter.
the display. Refer to the technical specifica-
12
K5902055 CORONIS FUSION 6MP 28/08/2013
1. Gently pull open both lower sides of the cover.
2. Slide the cover upwards while holding the lower sides pulled open.
3. Display installation
3. Lift the plastic frame that covers the fixation of the panel to the stand. Turn it for 45 degrees to uncover
the fixation screws.
4. Unscrew the four fixation screws fixing the panel to the stand.
5. Attach the panel firmly to the arm using 4 screws M4 x 10 mm.
K5902055 CORONIS FUSION 6MP 28/08/2013
13
3. Display installation
WARNING: Never move a display attached to an arm by pulling or pushing the display
itself. Instead, make sure that the arm is equipped with a VESA approved handle and
use this to move the display.
Please refer to the instruction manual of the arm for more information and instructions.
3.9 First time starting up
Overview
You are now ready to start up your Coronis Fusion 6MP for the first time.
1. Switch on your Coronis Fusion 6MP as described in "Stand-by switching", page 16.
2. Turn on the computer connected to your display.
If you have properly installed your display and display controller, the Windows start-up messages will
appear once the boot procedure is finished.
Your Coronis Fusion 6MP display will be running in a basic video mode at a default refresh rate when first time starting up. If you are using a Barco display controller, please
consult the dedicated user guide available on the system CD to install the drivers, software and documentation. When this is done, your display will automatically detect the
connected video input signal(s) and apply the correct video mode and refresh rate.
14 K5902055 CORONIS FUSION 6MP 28/08/2013
4. Daily operation
4. DAILY OPERATION
4.1 Recommendations for d aily operation
Optimize the lifetime of your display
Enabling the Display Power Management System (DPMS) of your display will optimize its diagnostic lifetime by automatically switching off the backlight when the display is not used for a specified period of time.
By default, DPMS is enabled on your display, but it also needs to be activated on your workstation. To do
this, go to “Power Options Properties” in the “Control Panel”.
Barco recommends setting DPMS activation after 20 minutes of non-usage.
Use a screen saver to avoid image retention
Prolonged operation of an LCD with the same content on the same screen area may result in a form of
image retention.
You can avoid or significantly reduce the occurrence of this phenomenon by using a screen saver. You
can activate a screen saver in the “Display properties” window of your workstation.
Barco recommends setting screen saver activation after 5 minutes of non-usage. A
good screen saver displays moving content.
In case you are working with the same image or an application with static image elements for several hours
continuously (so that the screen saver is not activated), change the image content regularly to avoid image
retention of the static elements.
Understand pixel technology
LCD displays use technology based on pixels. As a normal tolerance in the manufacturing of the LCD, a
limited number of these pixels may remain either dark or permanently lit, without affecting the diagnostic
performance of the product. To ensure optimal product quality, Barco applies strict selection criteria for its
LCD panels.
To learn more about LCD technology and missing pixels, consult the dedicated white
papers available at w
ww.barco.com/healthcare.
Enhance user comfort
Every Barco multi-head display system is color matched with the highest specifications in the market.
Barco recommends keeping color-matched displays together. Furthermore, it is important to use all displays of a multi-head configuration at the same rate to preserve color
matching throughout the economic lifetime of the system.
K5902055 CORONIS FUSION 6MP 28/08/2013 15
4. Daily operation
Maximize quality assurance
The ’MediCal QAWeb’ system offers online service for high-grade Quality Assurance, providing maximum
diagnostic confi dence and uptime.
Barco recommends to install MediCal QAWeb Agent and apply the default QAWeb policy
at least. This policy includes calibration on regular intervals. Connecting to MediCal
QAWeb Server offers even more possibilities.
Learn more and sign up for the free MediCal QAWeb Essential level at
w
ww.barco.com/healthcare/qa.
4.2 Key indicator lights
To make the keys light up:
1. Gently sweep your finger over the bottom right hand side of your display.
As a result, the keys will light up and are now available for further actions. However, if no further actions
are taken within the following 5 seconds, the key indicator lights will dim again.
The key auto-dim function can be disabled in the OSD menus. Please refer to "Key indicator lights", page 20 for detailed instructions on how to do this.
4.3 Stand-by switching
The connected power supply also provides a switch that can be used to turn the power
completely off. To use the display, please make sure to switch on this power supply.
This can be done by pushing the on/off switch on the power supply into the “│” position.
16 K5902055 CORONIS FUSION 6MP 28/08/2013
4. Daily operation
Switching on the display while it is in stand-by mode or vice versa can both be done by
using the keys or by using the control wheel.
To switch your display on using the keys:
1. Light up the keys indicator lights as previously described.
2. While the keys are light up, touch the Stand-by/Cancel key for approximately 2 seconds.
As a result, the display will switch on and the power status indicator light is dimmed.
To switch your display on using the control wheel:
1. Press the control wheel for approximately 2 seconds.
As a result, the display will switch on and the power status indicator light is dimmed.
The power LED can be disabled in the OSD menus. Please refer to "Power status indicator light", page 20 for detailed instructions on how to do this.
To switch your display to Stand-by using the keys:
1. Light up the keys indicator lights as previously described.
2. While the keys are light up, touch the Stand-by/Cancel key, a small window pops-up. Press the button
again to confirm.
As a result, the display will switch to stand-by mode and the power status indicator light is orange.
To switch your display to Stand-by using the control wheel:
1. Press the control wheel once, a small window pops-up. Press the control wheel again t
As a result, the display will switch to stand-by mode and the power status indicator light is orange.
In case of a power outage recovery, your display will always start-up in the power mode
it was in before the power interruption (i.e. stand-by or on). This protects your display
against inadvertent image retention problems.
oconfirm.
4.4 Bringing up the OSD menus
About OSD menu
TheOSDmenuallowsyoutoconfigure different settings to make your Coronis Fusion 6MP display fityour
needs within your working environment. Also, you can retrieve general information about your display and
its current configuration settings through the OSD menu.
Bringing up the OSD menus can be done by using the keys or by using the control wheel.
How to bring up the OSD menus using the keys
1. If not already done so, switch on the display as previously described.
2. Light up the keys indicator lights as previously desc
3. While the keys light up, touch the Menu/Enter key.
As a result, the OSD main menu comes up in the bottom right corner of the screen. If no further actions
are taken within the following 90 seconds however , the OSD menu will disappear again.
K5902055 CORONIS FUSION 6MP 28/08/2013
ribed.
17
4. Daily operation
How to bring up the OSD menus using the control wheel
1. If not already done so, switch on the display as previously described.
2. Shortly turn the control wheel.
As a result, the OSD main menu comes up in the bottom right corner of the screen. If no further actions
are taken within the following 90 seconds however , the OSD menu will disappear again.
The OSD menu auto-exit function can be disabled in the OSD menu. Please refer to
"OSD menu automatic close function", page 19 for detailed instructions on how to do
this.
The OSD menu position can be modified in the OSD menu. Please refer to "OSD menu
position", page 19 for detailed instructions on how to do this.
4.5 Navigating through the OSD menus
About OSD menu navigation
Navigating through the OSD menu can be done by using the keys or by using the control wheel.
How to navigate through the OSD menus using the keys
1. Use the Right/Down and Left/Up keys to move through the (sub)menus, change values or make selec-
tions.
2. To go into a submenu or confirm adjustments and selections, use the Menu/Enter key.
3. Use the Stand-by/Cancel key to cancel adjustments or exit a (sub)menu.
4. Exit the OSD menu by touching the Stand-by/Cancel key for approximately 2 seconds.
How to navigate through t he OSD menus using the control wheel
1. Rotate the control wheel to move through the menus, change values or make selections.
2. To go into a submenu or confirm adjustments and selections, shortly click the control wheel.
3. Click the control wheel for approximately 2 seconds to cancel adjustments or exit a (sub)menu.
18
K5902055 CORONIS FUSION 6MP 28/08/2013
5. Advanced operation
5. ADVANCED OPERATION
5.1 OSD menu position
About the OSD menu position
By default, the OSD menu comes up in the bottom center position of the screen. This position can be
modified however. There’s choice from a number of predefined positions.
To change the position of the OSD menu:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > User Interface > Menu menu.
3. Enter the Position submenu.
4. Select one of the available OSD menu positions and confirm.
5.2 OSD menu language
About the OSD menu language
By default, the OSD menu comes up in English. However, there’s a wide range of other languages available for the OSD menu of your Coronis Fusion 6MP.
To change the language of the OSD menu:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > User Interface > Menu menu.
3. Enter the Language submenu.
4. Select one of the available languages and confirm.
5.3 OSD menu automatic close function
About the OSD menu automatic close function
By default, the OSD menu will disappear automatically after approximately 90 seconds of inactivity. However, this function can be disabled so that the OSD menu remains on the screen until manually closed.
To enable/disable the OSD menu automatic close function:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > User Interface > Menu menu.
3. Enter the Automatic Close submenu.
4. Select Enabled/Disabled as desired and confirm.
K5902055 CORONIS FUSION 6MP 28/08/2013
19
5. Advanced operation
5.4 Power status indicator ligh t
About the power status indicator light
By default, when the display is switched on, the power status indicator light is dimmed. This behavior can
be changed so that the power status indicator light will be blue when the display is switched on.
When the display is in stand-by mode, the power status indicator light will always turn
orange, even when the power status indicator light is disabled.
To enable/disable the power status indicator light:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > User Interface > Indicator Lights menu.
3. Enter the Power Status submenu.
4. Select Enabled/Disabled as desired and confirm.
5.5 Key indicator lights
About the key indicator lights
By default, after lighting up, the key indicator lights will dim again if no further actions are taken within the
following 5 seconds. However, this behavior can be changed so that the key indicator lights are always
on or always off.
To co nfigure the key indicator lights
1. Bring up the OSD main menu.
2. Navigate to the Configuration > User Interface > Indicator Lights menu.
3. Enter the Keys submenu.
4. Select Automatic/Always On/Always Off as desired and confirm.
5.6 Power lock function
About the power lock function
By enabling the power lock function, the Coronis Fusion 6MP is
that it can’t be switched to stand-by mode until the power lock function is disabled again.
To enable/disable the power lock function:
forced to remain switched on. This means
1. Bring up the OSD main menu.
2. Navigate to the Configuration > User Interface > Controls menu.
3. Enter the Power Lock submenu.
4. Select Enabled/Disabled as desired and confirm.
20
K5902055 CORONIS FUSION 6MP 28/08/2013
5. Advanced operation
5.7 Keys sound
About keys sound
By default, the keys will make a “beep” sound on every touch. However, this sound can be disabled so
that no sound will be heard when using the keys.
To enable/disable the keys sound:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > User Interface > Controls menu.
3. Enter the Sound submenu.
4. Select Enabled/Disabled as desired and confirm.
5.8 Ethernet over USB
About Eth. over USB
By default, the Ethernet over USB will be disabled. This does not disable the USB hub and still allows
to make use of the display’s USB downstream connectors and any external devices connected to it (keyboard,mouse,...).
Please note that a connection from a PC USB downstream connector to the display’s USB upstream
connector is required to be able to use this functionality.
By enabling the Ethernet over USB, you allow the internal Coronis Fusion 6MP processor to communicate
directly over USB with the connected PC.
Enabling the Ethernet over USB is only recommended when you are using a non-Ba
display controller. If you are using a Barco display controller, this communication will
automatically be done over the connected video cable(s).
To enable/disable the eth. over USB:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Connectivity menu.
3. Enter the Eth. over USB submenu.
4. Select Enabled/Disabled as desired and confirm.
5.9 USB
About USB
By default, USB will be enabled. This will allow the connected PC to communicate directly over USB with
the internal Coronis Fusion 6MP processor.
rco
By disabling USB, communication between the internal Coronis Fusion 6MP processor and the connected
PC will not be possible. This does not disable the USB hub and still allows to make use of the display’s
USB downstream connectors and any external devices connected to it (keyboard, mouse, ...).
Please note that a connection from a PC USB downstream connector to the display’s USB upstream
connector is required to be able to use this functionality.
K5902055 CORONIS FUSION 6MP 28/08/2013
21
5. Advanced operation
Enabling the USB endpoint is only recommended when you are using a non-Barco display controller. If you are using a Barco display controller, this communication will automatically be done over the connected video cable(s).
To enable/disable USB:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Connectivity menu.
3. Enter the USB submenu.
4. Select Enabled/Disabled as desired and confirm.
5.10 DPMS mode
About DPMS mode
Enabling the Display Power Management System (DPMS) mode on your display will optimize its diagnostic lifetime by automatically switching off the backlight when the display is not used for a specified period
of time. By default, DPMS mode is enabled on your display, but it also needs to be activated on your
workstation. To do this, go to the “Power options properties” window of your workstation.
Barco recommends setting DPMS activation after 20 minutes of non-usage.
When DPMS mode is enabled on your display, an additional OSD power saving function
becomes available: hibernate. Please refer to "Hibernate", page 22 for more information
on hibernation and how to enable this function.
To enable/disable DPMS mode on your display:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Power Management menu.
3. Enter the DPMS Mode submenu.
4. Select Enabled/Disabled as desired and confirm.
5.11 Hibernate
About hibernate
Enabling hibernation will not only switch off the backlight but will also force the display to disable other
functionalities so that power consumption is further reduced to a minimum. This happens after a specific
period of time which can be manually adjusted.
Hibernate can only be enabled on your display when the DPMS mode is enabled first.
Therefore, please refer to "DPMS mode", page 22t
22 K5902055 CORONIS FUSION 6MP 28/08/2013
odothis.
5. Advanced operation
To enable/disable hibernation on your display:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Power Management menu.
3. Enter the Hibernate submenu.
4. Select Enabled/Disabled as desired and confirm.
To specify the hibernate timeout:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Power Management menu.
3. Enter the Hibernate Timeout submenu.
4. Set the timeout value as desired and confirm.
5.12 Luminance t arget
About the luminance target
The luminance target of your Coronis Fusion 6MP is adjustable over a predefined range. When you
change the luminance target, the display will adjust its backlight to reach the target.
To set the luminance target:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration menu.
3. Enter the Luminance Target submenu.
4. Set a luminance target value as desired and confirm.
The default value is 450 cd/m². The five year warranty is valid for this setting.
5.13 Color presets
About color presets
The available color preset settings for your display are:
Clearbase Simulation of the clearbase film color temperature.
Bluebase
User When selecting the User color temperature setting,
Native White
Simulation of the bluebase film color temperature.
youwillbeabletomanuallydefine the X and Y
coordinates or the display color temperature in
separate submenus.
The native, unmodified color temperature of the
LCD panel.
To select a color preset:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration > Color Settings menu.
K5902055 CORONIS FUSION 6MP 28/08/2013
23
5. Advanced operation
3. Enter the Color Presets submenu.
4. Select one of the available Color Presets and confirm.
5.14 Color temperature
About color temperature:
It is possible to change the color temperature of your display.
Color temperature can only be changed on your display when color presets is set to
user. Therefore, please refer to "Color presets", page 23 to do this.
To change the color temperature:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration > Color Settings menu.
3. Enter the Color Definition submenu.
4. Select Color Temperature and confirm.
5. Enter the Color Temperature submenu.
6. Set the Temperature value as desired and confirm.
5.15 Color coordinates
About color coordinates:
It is possible to change the color coordinates of your display.
Color coordinates can only be changed on your display when color
user. Therefore, please refer to "Color presets", page 23 to do this.
To change the color coordinates:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration > Color Settings menu.
3. Enter the Color Definition submenu.
4. Select Color Coordinates and confirm.
presetsissetto
5. Enter the X and/or Y submenu.
6. Set the coordinate value for X and/or Y as desired and confirm.
5.16 Viewing modes
About viewing modes
The Coronis Fusion 6MP can be used in two viewing modes:
24
K5902055 CORONIS FUSION 6MP 28/08/2013
5. Advanced operation
Diagnostic
Text In this mode, the luminance is reduced to
As the Coronis Fusion 6MP is intended to be used in a diagnostic environment, the diagnostic mode should always be selected.
This mode provides the full calibrated luminance
and is intended for using the display for diagnostic
purposes.
approximately half of the luminance. This
is intended for using the display with office
applications such as word processing.
Please note that text mode is not persistent, once
powered off, the unit will restart in diagnostic mode.
To select a viewing mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration menu.
3. Enter the Viewing Mode submenu.
4. Select Diagnostic/Text as desired and confirm.
5.17 Display functions
About display functions
Native, uncorrected panels will display all grayscale/color levels with luminance increments that are not
optimal for crucial diagnostic information. Studies have shown however, that in medical images certain
grayscale/color parts contain more diagnostic information then others. To respond to these conclusions,
display functions have been defined. These functions emphasize on these parts containing crucial diagnostic information by correcting the native panel behavior.
Native
Dynamic Gamma 1.8
Dynamic Gamma 2.2
DICOM DICOM (Digital Imaging and Communications
User This display function will be automatically selected
Gamma 1.8
Gamma 2.2
If you select Native, the native panel behavior will
not be corrected.
These are gamma functions that are shifted to take
into account the non-zero luminance of an LCD
panel when driven with a “black” signal. They are
especially useful in CT applications to improve the
perception of low Hounsfield values.
in Medicine) is an international standard that
was developed to improve the quality and
communication of digital images in radiology.
In short, the DICOM display function results in
more visible grayscales in the images. Barco
recommends selecting the DICOM display function
for most medical viewing applications.
when display functions are defined by MediCal
QAWeb.
Select one of these display functions in case the
display is to replace a CRT display with a gamma
of 1.8 or 2.2 respectively.
To select a display function:
1. Bring up the OSD main menu.
K5902055 CORONIS FUSION 6MP 28/08/2013
25
5. Advanced operation
2. Navigate to the Configuration > Calibration menu.
3. Enter the Display Function submenu.
4. Select one of the available display functions and confirm.
5.18 Ambient Light Compensation (ALC)
About ALC
Ambient Light Compensation (ALC) can only be enabled on your display when the DICOM display function is selected. Therefore, please refer to "Display functions", page
25 to correctly set the display function.
When ALC is enabled, the DICOM display function will be recalculated taking a preset ambient light correction value into account. This value is determined by the selected reading room. Therefore, it is also
important to select a realistic reading room when enabling ALC. This can be done by following the instructions in "Reading rooms", page 26.
To enable/disable ALC:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration > Ambient Light menu.
3. Enter the Ambient Light Compensation submenu.
4. Select Enabled/Disabled as desired and confirm.
5.19 Reading roo ms
About reading rooms
Reading rooms can only be selected w hen the DICOM display function is selected.
Therefore, please refer to "Display functions", page 25 to correctly set the display
function.
The American Association of Physicists in Medicine (AAPM) composed a list of pre-defined reading rooms.
Each of these reading rooms are defined by following parameters:
• the maximum light allowed in this type of room
• the preset ambient light correction value for this reading room
These parameters are stored in your display and determine the preset ambient light correction value to
take into account to recalculate the DICOM display function when Ambient Light Compensation (ALC) is
enabled. Please refer to "Ambient Light Compensation (ALC)", page 26 to enable ALC.
The available reading rooms for your Coronis Fusion 6MP are:
CR/DR/ MAMMO Corresponds to light conditions in diagnostic
reading rooms for computed radiology, digital
radiology or mammography. This setting has the
lowest maximum ambient light.
CT/MR/NM Corresponds to light conditions in diagnostic
reading rooms for computed tomography, magnetic
resonance or nuclear medicine scans.
26 K5902055 CORONIS FUSION 6MP 28/08/2013
5. Advanced operation
Staff Office Corresponds to light conditions in office rooms.
Clinical Viewing Room Corresponds to light conditions in diagnostic
reading rooms for clinical viewing.
Emergency Room
Operating Room Corresponds to light conditions in operating rooms.
Corresponds to light conditions in emergency
rooms.
This setting has the highest maximum ambient light.
To select a reading room:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration > Ambient Light menu.
3. Enter the Reading Room submenu.
4. Select one of the available reading rooms and confirm.
5.20 Continuous ALC
About Con tinuous ALC
Continuous ALC can only be selected when the DICOM display function is selected.
Therefore, please refer to "Display functions", page 25 to correctly set the display function.
Enabling continuous ALC will continuously recalculate the DICOM display function taking the averaged
ambient light into account.
To select continuous ALC:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Calibration > Ambient Light menu.
3. Enter the Continuous ALC submenu.
4. Select Enabled/Disabled as desired and confirm.
5.21 Image scaling
About image scaling
Enabling image scaling will multiply each individual pixel to one or more adjacent pixels so that the size
of the displayed image will be a multiple of the original image source video input signal.
Image scaling is only possible when the resolution of your display’s video input signal
is less than or equal to half the maximum resolution of the display.
To enable/disable image scaling:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Source menu.
3. Enter the Scaling submenu.
4. Select Enabled/Disabled as desired and confirm.
K5902055 CORONIS FUSION 6MP 28/08/2013
27
5. Advanced operation
5.22 Image source selec tio n modes
About image source selection modes
Your Coronis Fusion 6MP automatically detects the number of video input signals connected, attaches
them to the correct display side and applies the correct video settings to it (resolution, video encoding
mode, refresh rate,...). However, it may be needed to manually select the video input signal(s) to be
displayed on a certain display side or to adjust certain video settings yourself. The start to this is selecting
one of the following image source selection modes available for your display:
Automatic In this mode, your display automatically detects the
connected video input signals, attaches them to the
correct display side and applies the correct video
settings to it (resolution, video encoding mode,
refresh rate,...). No video settings are available
when this mode is selected.
One Image Source This mode is intended for displaying and manually
configuring only one connected video input signal.
When selecting this mode, the video settings
become available for the selected video input
signal.
Two Image Sources This mode is intended for displaying and manually
configuring two connected video input signals (one
on each display side). When selecting this mode,
the video settings become available for the selected
video input signal on each side of the display.
To select an image source selection mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources menu.
3. Enter the Image Source Selection submenu.
4. Select one of the available image source selec
tion modes and confirm.
5.23 Video input signals
Your Coronis Fusion 6MP display automatica
nals. Manually selecting image source video input signals is possible, but then your
display’s image source selection mode should be set to allow this. Please refer to "Image source selection modes", page 28 to do this.
About input signals
The available input signals for yo
DisplayPort 1 The input corresponding to the DisplayPort 1
DVI 1 The input corresponding to the DVI 1 connector.
DisplayPort 2 The input corresponding to the DisplayPort 2
DVI 2 The input corresponding to the DVI 2 connector.
Automatic Selection
ur display are:
connector.
connector.
The input is automatically selected.
lly detects the connected video input sig-
28 K5902055 CORONIS FUSION 6MP 28/08/2013
5. Advanced operation
To manually select a video input signal:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Input Signal submenu.
4. Select one of the available input signals and confirm.
5.24 Video encoding modes
Your Coronis Fusion 6MP display automatically detects the connected video input signals and applies the correct video encoding settings. Manually selecting a video encoding mode is possible, but then your display’s image source selection mode should be
set to allow this. Please refer to "Image source selection modes", page 28 to do this.
About video encoding modes
Video encoding modes specify how the color and luminance information is encoded in the video signal. In
consumer displays, this is usually done by a limited 8-bit encoding mechanism. Your Coronis Fusion 6MP
however, features 10-bit encoding enabling it to better match the DICOM defi
an extensive range is necessary to comply with the guidelines set forward by the latest medical guidelines.
ned grayscale range. Such
The available video encoding modes for your display are listed below.
Please note that the display controller connected to your display might not al ways support all these v ideo encoding modes.
Standard
HDR1
HDR2
Dual 10 (only with Barco display controller) Dual 10 is a Barco specific 10-bit video encoding
Automatic
This mode uses the standard 8 bit encoding
mechanism.
This mode features 10-bit video encoding following
the High Dynamic Range (HDR) standard, usually
used on color displays.
HDR2 is a Barco specific mode featuring 10-bit
video encoding following the High Dynamic Range
(HDR) standard but allowing full refresh rate (which
is not always possible with HDR1). This mode is
usually used on color displays.
mode which is usually used on grayscale displays
and which allows full refresh rate.
When selecting this option, your Coronis Fusion
6MP will automatically assign the correct video
encoding settings to the connected video input
signals.
To manually select a video encoding mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Video Encoding submenu.
4. Select one of the available video encoding modes and confirm.
K5902055 CORONIS FUSION 6MP 28/08/2013
29
5. Advanced operation
5.25 Grayscale conversion mo des
Your Coronis Fusion 6MP display a utomatically detects the connected video input
signals and applies the correct grayscale conversion settings. Manually selecting a
grayscale conversion mode is possible, but then your display’s image source selection
mode should be set to allow this. Please refer to "Image source selection modes",
page 28 to do this.
About grayscale conversion modes
Grayscale conversion modes specify how color g enerated on the display controller is converted to
grayscale in your display.
The available grayscale conversion modes are:
No Conversion
Use Red Channel This mode is intended for grayscale displays where
gray is sent over the red channel.
Use Green Channel This mode is intended for grayscale displays where
gray is sent over the green channel.
Use Blue Channel This mode is intended for grayscale displays where
gray is sent over the blue channel.
Use All Channels This mode is intended for grayscale displays where
gray is sent over the red, green and blue channel.
This is done by means of a standard conversion
mechanism where 30% red, 59% green and 11%
blue are used to generate gray.
To manually select a grayscale conversion mode:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Grayscale Conversion submenu.
4. Select one of the available color conversion modes and confirm.
5.26 EDID timings
Your Coronis Fusion 6MP display automatically detects the connected video input signals and applies the correct timings. Manually configuring the EDID timings is possible,
but then your display’s image source selection mode should be set to allow this. Please
refer to "Image source selection modes", page 28 to do this.
About EDID timings
Following EDID timings are available for your Coronis Fusion 6MP:
Resolution
Refresh Rate Allows to manually select the refresh rate of the
Color Depth
Allows to manually modify the resolution of the
image source video input signal.
image source video input signal depending on the
maximum refresh rate of the display controller
connected to your display.
Allows to change the color depth to 8 or to 10 bit.
30 K5902055 CORONIS FUSION 6MP 28/08/2013
5. Advanced operation
To manually set EDID timings:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Sources > (Left/Right) Image Source menu.
3. Enter the Timings submenu.
4. Select Resolution, Refresh Rate or Color Depth.
5. Select one of the available settings and confirm.
5.27 Display in fo
About display info
Your display serial number, color type, native resolution, firmware versions, etc. are available in a dedicated submenu of the OSD menu.
To retrieve info about your display:
1. Bring up the OSD main menu.
2. Navigate to the About this Display menu to make the information visible on the screen.
5.28 Display status
About d isplay status
The Status submenu of the OSD menu provides info on the current status of your display (runtimes, temperatures, etc.), the status of the connected image sources (video encoding mode, timings, etc.), the
current calibration status of your display (display function, luminance, ALC, etc.) and the status about
activated connections.
To retrieve the status of your display:
1. Bring up the OSD main menu.
2. Navigate to the Status menu.
3. Enter the Display, Image Sources, Calibration or Connectivity submenu as desired.
K5902055 CORONIS FUSION 6MP 28/08/2013
31
5. Advanced operation
32 K5902055 CORONIS FUSION 6MP 28/08/2013
6. Cleaning your display
6. CLEAN ING YOUR DISPLAY
6.1 Cleaning instructions
To clean the display
Clean the display using a sponge, cleaning cloth or soft tissue, lightly moistened with a recognized cleaning product for medical equipment. Read and follow all label instructions on the cleaning product. In case
of doubt about a certain cleaning product, use plain water.
Do not use following products:
• Alcohol/solvents at higher concentration > 5%
• Strong alkalis lye, strong solvents
•Acid
• Detergents with fluoride
• Detergents with ammonia
• Detergents with abrasives
• Steel wool
• Sponge with abrasives
• Steel blades
• Cloth with steel thread
CAUTION: Take care not to damage or scratch the front glass or LCD. Be careful with
rings or other jewelry and do not apply excessive pressure on the front glass or LCD.
CAUTION: Do not apply or spray liquid directly to the display as excess liquid may cause
damage to internal electronics. Instead, apply the liquid to a cleaning cloth.
K5902055 CORONIS FUSION 6MP 28/08/2013 33
6. Cleaning your display
34 K5902055 CORONIS FUSION 6MP 28/08/2013
7. Repackaging instructions
7. REPACKAGING INSTRUCTIONS
Overview of the packaging
8
7
6
5
4
3
2
1
Image 7-1
Box
1
System CD + User guide
2
5
6
K5902055 CORONIS FUSION 6MP 28/08/2013
Coronis Fusion 6MP display
Top bu ff er
35
7. Repackaging instructions
Bottom buffer
3
Power supply
4
Display controller box
7
Cables (video, USB, power)
8
7.1 Repacking your display
How to repack your display
1. Place the empty box on a stable surface.
2. Slide the system CD and user guide in the dedicated bag attached at the inside of the box.
3. Place the bottom buffer in the box.
4. Put the power supply in the dedicated cavity of the bottom buffer.
5. Put the Coronis Fusion 6MP display in its original bag and place it in the box with its panel facing
downwards.
6. Put the top buffer on top of the display.
7. When applicable, slide the display controller box in the dedicated cavity of the buffers.
8. Put all cables (video, USB, power) in their original bag and slide them in the dedicated cavity of the
buffers.
9. Close and seal the box.
36
K5902055 CORONIS FUSION 6MP 28/08/2013
8. IMPORTANT INFORMATION
8.1 Safety information
General recommendations
Read the safety and operating instructions before operating the device.
Retain safety and operating instructions for future reference.
Adhere to all warnings on the device and in the operating instructions manual.
Follow all instructions for operation and use.
Electrical Shock
8. Important information
• Do not modify this equipment without authorization of the manufacturer.
• No user-serviceable part inside. The equipment should be opened only by qualified service personnel.
Type of protection (electrical):
Display with external power supply: Class I equipment.
Degree of safety (flammable anesthetic mixture):
Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen
or nitrous oxide.
Non-patient care equipment
• Equipment primarily for use in a health care facility that is intended for use where contact with a patient
is unlikely (no applied part).
• The equipment may not be used with life support equipment.
• The user should not touch the equipment, nor its signal input/output ports and the patient at the same
time.
Power connection – Equipment with external 24 VDC power supply
• Power requirements: The equipment must be powered using the delivered medical approved 24 VDC
) SELV power supply.
(
• The medical approved DC (
• The power supply is specified as a part of the ME equipment or combination is specified as a ME
system.
• To avoid the risk of electric shock, this equipment must only be connected to a supply mains with
protective earth.
• The equipment should be installed near an easily accessible outlet.
• The equipment is intended for continuous operation.
) power supply must be powered by the AC mains voltage.
K5902055 CORONIS FUSION 6MP 28/08/2013
37
8. Important information
Transient over-voltage
If the device is not used for a long time, disconnect it from the AC inlet to avoid damage by transient
over-voltage.
To fully disengage the power to the device, please disconnect the power cord from the AC inlet.
Power cords:
• Utilize a UL-listed detachable power cord, 3-wire, type SJ or equivalent, 18 AWG min., rated 250 V
min., provided with a hospital-grade type plug 5-15P configuration for 120V application, or 6-15P for
240V application.
• Do not overload wall outlets and extension cords as this may result in fire or electric shock.
• Mains lead protection (U.S.: Power cord): Power cords should be routed so that they are not likely to
be walked upon or pinched by items placed upon or against them, paying particular attention to cords
at plugs and receptacles.
• The power supply cord should be replaced by the designated operator only at all time.
Water and moisture
Never expose the device to rain or moisture.
Never use the device near water - e.g. near a bathtub, washbasin, swimming pool, kitchen sink, laundry
tuborinawetbasement.
Ventilation
Do not cover or block any ventilation openings in the cover of the set. When installing the device in a
cupboard or another closed location, heed the necessary space between the set and the sides of the
cupboard.
Installation
Place the device on a flat, solid and stable surface that can support the weight of at least 3 devices. If you
use an unstable cart or stand, the device may fall, causing serious injury to a child or adult, and serious
damage to the device.
This apparatus conforms to:
CE0120 (MDD 93/42/EEC; A1:2007/47/EC class IIb product), C
+ A1:2009 (2ND EDITION), IEC 60601-1:2005, ANSI/AAMI ES 60601-1:2005 + C1:2009 + A2:2010,
CAN/CSA C22.2 No. 60601-1 (2008), DEMKO - EN 60601-1:2006, EN 60601-1-2:2007, CCC GB9254-2008 + GB4943.1-2011 + GB17625.1-2012, KCC, VCCI, FCC class B, ICES-001 Level B, FDA
510(k), RoHS.
E - 2004/108/EC, IEC 60950-1:2005
National Scandinavian Deviations for CL. 1.7.2:
Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan"
Norway: "Apparatet må tilkoples jordet stikkontakt"
Sweden: "Apparaten skall anslutas till jordat uttag"
8.2 Environmental information
Disposal information (Waste Electrical and Electronic Equipment)
This symbol on the device indicates that, under European Directive 2002/96/EC governing waste
from electrical and electronic equipment, this device must not be disposed of with other municipal waste.
38
K5902055 CORONIS FUSION 6MP 28/08/2013
8. Important information
Please dispose of your waste device by handing it over to a designated collection point for the recycling of
waste electrical and electronic equipment. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these devices from other types of waste and recycle
them responsibly to promote the sustainable reuse of material resources.
For more information about recycling of this device, please contact your local city office or your municipal
waste disposal service. For details, please visit the Barco website at: h
Barco/weee.
Turkey RoHS compliance
Republic of Turkey: In conformity with the EEE Regulation
Türkiye Cumhuriyeti: EEE Yönetmeliğine Uygundur
中国大陆 RoHS
Chinese Mainland RoHS
根据中国大陆《电子信息产品污染控制管理办法》（也称为中国大陆RoHS）， 以下部分列出了Barco产品
中可能包含的有毒和/或有害物质的名称和含量。中国大陆RoHS 指令包含在中国信息产业部MCV标准：
“电子信息产品中有毒物质的限量要求”中。
ttp://www.barco.com/en/About-
According to the “China Administration on Control of Pollution Caused by Electronic Information Products”
(Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or
hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in
the MCV standard of the Ministry of Information Industry of China,
toxic substances in Electronic Information Products”.
零件项目(名称)
Component name
印制电路配件
Printed Circuit Assemblies
液晶面板
LCD panel
外接电(线)缆
External Cables
內部 线路
Internal wiring
金属外壳
Metal enclosure
塑胶外壳
有毒有害物质或元素
Hazardous substances and elements
铅
Pb
xooo oo
xooo oo
xooo oo
oo o o oo
oo o o oo
oo o o oo
汞
Hg
镉
Cd
in the section “Limit Requirements of
六价铬
Cr6+
多溴联苯
PBB
多溴二苯
醚
PBDE
Plastic enclosure
散热片(器)
Heatsinks
电源供应器
Power Supply Unit
风扇
Fan
K5902055 CORONIS FUSION 6MP 28/08/2013 39
oo o o oo
xooo oo
oo o o oo
8. Important information
零件项目(名称)
Component name
文件说明书
Paper Manuals
光盘说明书
CD manual
O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下.
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for
this part is below the limit requirement in SJ/T11363-2006.
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的
限量要求.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous
materials used for this part is above the limit requirement in SJ/T11363-2006
在中国大陆销售的相应电子信息产品（EIP）都必须遵照中国大陆《电子信息产品污染控制标识要求》标准
贴上环保使用期限（EFUP）标签。Barco 产品所采用的EFUP标签（请参阅实例，徽标内部的编号使用于制
定产品）基于中国大陆的《电子信息产品环保使用期限通则》标准。
All Electronic Information Products (EIP) that are sold within Chinese Mainland must comply with the
“Electronic Information Products Pollution Control Labeling Sta
the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses
(please refer to the photo) is based on the “Standard of Electronic Information Products Environmental
Friendly Use Period” of Chinese Mainland.
有毒有害物质或元素
Hazardous substances and elements
铅
Pb
oo o o oo
oo o o oo
汞
Hg
镉
Cd
ndard” of Chinese Mainland, marked with
六价铬
Cr6+
多溴联苯
PBB
多溴二苯
醚
PBDE
10
8.3 Regulatory compliance information
Indications for use
The Coronis Fusion 6MP (MDCC-6230) display is a display device capable of displaying two 3MP display
images electronically fused together on the one panel. It is intended to be used in displaying and viewing
digital images for review and
of 3280 x 2048 pixels at a pixel pitch of 0.1995mm. This provides the equivalent resolution of 2 x 3MP
displays.
The Coronis Fusion 6MP (MDCC-6230) display is not intended for primary diagnosis of Mammography
images.
Caution (USA): Federal law r
trained on its use.
40
analysis by trained medical practitioners. It provides a screen resolution
estricts this device to sale by or on the order of a physician or a practitioner
K5902055 CORONIS FUSION 6MP 28/08/2013
8. Important information
FCC class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This device generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interfe
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television reception, which can be
determined by turning the device off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the device and receiver.
• Connect the device into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian notice
This ISM device complies with Canadian ICES-001.
rence
Cet appareil ISM est conforme à la norme NMB-001 du Canada.
8.4 EMC notice
General information
No specific requirement on the use of external cables or other accessories except power supply.
With the installation of the device, use only the delivered power supply or a spare part provided by the
legal manufacturer. Using another can result in a decrease of the immunity level of the device.
Electromagnetic emissions
The Coronis Fusion 6MP is intended for use in the electromagnetic environment specified below. The
customer or the user of the Coronis Fusion 6MP should assur
Emissions test
RF emissions
CISPR 11
RF emissions
CISPR 11
Harmonic emissions
IEC 61000-3-2
Voltage fluctuations/ flicker
emissions
IEC 61000-3-3
Compliance
Group 1 The Coronis Fusion 6MP uses
Class B
Class D
Complies
ethatitisusedinsuchanenvironment.
Electromagnetic environment –
Guidance
RF energy only for its internal
function. Therefore, its RF
emissions are very low and are
not likely to cause any interference
in nearby electronic equipment.
The Coronis Fusion 6MP
is suitable for use in all
establishments, including
domestic establishments and
those directly connected to the
public low-voltage power supply
network that supplies buildings
used for domestic purposes.
This Coronis Fusion 6MP complies with appropriate medical EMC standards on emissions to, and interference from surrounding equipment. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
K5902055 CORONIS FUSION 6MP 28/08/2013
41
8. Important information
Interference can be determined by turning the equipment off and on.
If this equipment does cause harmful interference to, or suffer from harmful interference of, surrounding
equipment, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna or equipment.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced technician for help.
Electromagnetic immunity
The Coronis Fusion 6MP is intended for use in the electromagnetic environment specified below. The
customer or the user of the Coronis Fusion 6MP should assure that it is used in such an environment.
Immunity test
Electrostatic discharge
(ESD)
IEC 61000-4-2
Electrical fast
transient/burst
IEC 61000-4-4
Surge
IEC61000-4-5
Voltage dips, short
interruptions and voltage
variations on power
supply input lines
IEC 61000-4-11
IEC 60601
Test levels
± 6kV contact
±8kVair
± 2kV for power supply
lines
± 1kV for input/ output
lines
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
<5%U
U
T
40% U
1
(> 95% dip in
T
) for 0.5 cycle
(60%dipinUT)
T
for 5 cycles
70% U
(30%dipinUT)
T
for 25 cycles
<5%U
U
) for 5s
T
(>95% dip in
T
Compliance level
± 6kV contact
±8kVair
± 2kV for power supply
lines
± 1kV for input/ output
lines
± 1 kV line(s) to line(s)
±2kVline(s)toearth
<5%U
U
) for 0.5 cycle
T
40% U
(> 95% dip in
T
(60% dip in UT)
T
for 5 cycles
70% U
(30% dip in UT)
T
for 25 cycles
<5%U
U
)for5s
T
(>95% dip in
T
Electromagnetic
environment –
guidance
Floors should be wood,
concrete or ceramic tile.
If floors are covered with
synthetic material, the
relative humidity should
be at least 30%
Mains power quality
should be that of a typical
commercial or hospital
environment
Mains power quality
should be that of a typical
commercial or hospital
environment
Mains power quality
should by that of a typical
commercial or hospital
environment. If the user
of the Coronis Fusion
6MP requires continued
operation during power
mains interruptions, it
is recommended that
the Coronis Fusion 6MP
be powered from an
uninterruptible power
supply or a battery.
1. is the a.c. mains voltage prior to application of the test level.
42 K5902055 CORONIS FUSION 6MP 28/08/2013
8. Important information
Immunity test
Power frequency (50/60
Hz) magnetic field
IEC 61000-4-8
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
IEC 60601
Test levels
3A/m
3Vrms
150 kHz to 80 MHz
3V/m
80 MHz to 2.5 GHz
Compliance level
Not applicable
3V
3V/m
Electromagnetic
environment –
guidance
Power frequency
magnetic fields should
be at levels characteristic
of a typical location in
a typical commercial or
hospital environment.
Portable and mobile
RF communications
equipment should be
used no closer to any
part of the Coronis Fusion
6MP, including cables,
than the recommended
separation distance
calculated from the
equation applicable
to the frequency
of the transmitter.
Recommended
separation distance
d=1.2√P
d=1.2√P 80 MHz to 800
MHz
d=2.3√P 800 MHz to 2.5
Ghz
Where P is the maximum
output power rating
of the transmitter in
watts (W) according
to the transmitter
manufacturer and d
is the recommended
separation distance in
meters (m).
Field strengths from
fixed RF transmitters,
as determined by an
electromagnetic site
survey,
2
should be less
than the compliance
level in each frequency
3
range.
Interference may occur in
the vicinity of equipment
marked with symbol:
K5902055 CORONIS FUSION 6MP 28/08/2013 43
8. Important information
Immunity test
IEC 60601
Test levels
Compliance level
Electromagnetic
environment –
guidance
At 80 MHz and 800 MHz, the higher frequency range applies.
These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, obje cts and people.
Recommended separation distance
The Coronis Fusion 6MP is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The customer of the user of the Coronis Fusion 6MP can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Coronis Fusion 6MP as recommended below, according to the
maximum output power of the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter
4
150kHz to 80MHz
d=1.2√P
80MHz to 800MHz
d=1.2√P
800MHz to 2.5GHz
d=2.3√P
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100121223
At 80 MHz and 800 MHz, the separation distance for the higher frequency range a pplies.
These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection form structures, object and people.
2. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur
radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in
the location in which the Coronis Fusion 6MP is used exceeds the applicable RF compliance level above, the Coronis Fusion 6MP
should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as
re-orienting or relocating the Coronis Fusion 6MP.
3. Over the frequency range 150 kHz to 80 MHz, field strengths should be less than3V/m.
4. For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be
estimated using the equation applicable to the frequency of the transmitter. Where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter manufacturer.
44 K5902055 CORONIS FUSION 6MP 28/08/2013
8.5 Exp lanation of symbols
Symbols on the device
On the device or power supply, you may find the following symbols (nonrestrictive list):
Indicates compliance with the Directive 93/42/EEC as Class I device
Indicates compliance with the Directive 93/42/EEC as Class II device
Indicates compliance with Part 15 of the FCC rules (Class A or Class B)
Indicates the device is approved according to the UL regulations
Indicates the device is approved according to the UL regulations for Canada
and US
8. Important information
Indicates the device is approved according to the UL Demko regulations
Indicates the device is approved according to the CCC regulations
Indicates the device is approved according to the VCCI regulations
Indicates the device is approved according to the KC regulations
Indicates the device is approved according to the BSMI regulations
Indicates the USB connectors on the device
Indicates the DisplayPort connectors on the device
Indicates the manufacturing date
Indicates the temperature limitations for the device to safely operate within specs
K5902055 CORONIS FUSION 6MP 28/08/2013 45
8. Important information
Indicates the device serial no.
Consult the operating instructions
Indicates this device must not be thrown in the trash but must be recycled,
according to the European WEEE (Waste Electrical and Electronic Equipment)
directive
Indicates Direct Current (DC)
Indicates Alternating Current (AC)
8.6 Legal disclaimer
Disclaimer notice
Although every attempt has been made to achieve technical accuracy in this document, we assume no
responsibility for errors that may be found. Our goal is to provide you with the most accurate and usable
documentation possible; if you discover errors, please let us know.
Barco software products are the property of Barco. They are distributed under copyright by Barco N.V. or
Barco, Inc., for use only under the specific terms of a software
Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any
form, is authorized.
The specifications of Barco products are subject to change without notice.
license agreement between Barco N.V. or
Trademarks
All trademarks and registered trademarks are property of their respective owners.
Copyright notice
This document is copyrighted. All rights are reserved. Neither this document, nor any part of it, may
be reproduced or copied in any form or by any means - graphical, electronic, or mechanical including
photocopying, taping or information storage and retrieval systems - without written permission of Barco.
© 2013 Barco N.V. All rights reserved.
Patent information (EXAMPLE)
This product is covered under the following intellectual property rights:
US Patent RE43,707
US Patent 7,038,186
US Patent 7,166,829
US Patent 6,950,098
European Patent 1 274 066.
46
K5902055 CORONIS FUSION 6MP 28/08/2013
8.7 Technical specifications
Overview
Product acronym
Screen technology TFT AM Color LCD Dual Domain IPS-Pro
Active screen size (diagonal) 772 mm (30.4")
Active screen size (H x V) 654 x 409 mm (25.8 x 16.1")
Aspect ratio (H:V)
Resolution
Pixel pitch 0.1995 mm
Color imaging
Gray imaging
Color support
Viewing angle (H, V) 178°
MDCC-6230
16:10
native 6MP (3280 x 2048)
configurable to 2 x 3MP+ (1640 X 2048)
configurable to 2 x 3MP (1536 X 2048)
Yes
Yes
30 bit
8. Important information
Uniform Luminance
Tec hn o l o g y (U LT )
Per Pixel Uniformity (PPU)
Ambient Light Compensation
(ALC)
Backlight Output Stabilization
(BLOS)
I-Guard
Maximum luminance
DICOM calibrated luminance
(ULT off)
Contrast ratio (typical) 1000:1 (panel typical)
Responsetime(Tr+Tf)
Scanning frequency (H; V)
Housing color
Video input signals
Video inout terminals NA
USB ports 1 upstream (endpoint), 3 downstream
USB standard
Power requirements (nominal)
Power consumption (nominal)
Power save mode Yes
Power management DVI-DMPM, DP-DMPM
Dot clock 280 MHz
OSD languages English, German, French, Dutch, Spanish, Italian, Portugese, Polish,
Dimensions with stand (W x H
xD)
Dimensions w/o stand (W x H
xD)
Dimensions packaged (W x H
xD)
Net weight with stand 26.5 kg
Yes
No
Yes
Yes (2x )
Yes
720 cd/m²
500 cd/m²
18 ms
30-150 kHz; 15-80 Hz
Black / Silver
DVI-D Dual Link (2x), DisplayPort (2x)
2.0
100-240V
125W
Russian, Swedish, Chinese (simplified), Japanese, Korean, Arabic
Portrait: NA Landscape: 731 x 580~676 x 265 mm
Portrait: NA Landscape: 731 x 485 x 141 mm
869 x 76
4 x 400 mm
K5902055 CORONIS FUSION 6MP 28/08/2013 47
8. Important information
Net weight w/o stand
Net weight packaged with
stand
Net weight packaged w/o stand N/A
Height adjustment range 96 mm
Tilt
Swivel -45° / +45°
Pivot
Mounting standard
Screen protection Protective, non-reflective glass cover
Recommended modalities
Certifications CE0120 (MDD 93/42/EEC; A1:2007/47/EC class IIb product), CE -
Supplied accessories
Optional accessories
QA software MediCal QAWeb
Units per pallet NA
Pallet dimensions (W x H)
Warranty
Operating temperature 0°C to 35°C (15°C to 30°C within specs)
Storage temperature -20°C to 60°C
Operating humidity 8% - 80% (non-condensing)
Storage humidity 5% - 95% (non-condensing)
20 kg
36.5 kg
-5° / +25°
N/A
VESA (100 mm)
CT, MR, US, DR, CR, NM, Film
2004/108/EC, IEC 60950-1:2005 + A1:2009 (2ND EDITION), IEC
60601-1:2005, ANSI/AAMI ES 60601-1:2005 + C1:2009 + A2:2010,
CAN/CSA C22.2 No. 60601-1 (2008), DEMKO - EN 60601-1:2006,
EN 60601-1-2:2007, CCC - GB9254-2008 + GB4943.1-2011 +
GB17625.1-2012, KCC, VCCI, FCC class B, ICES-001 Level B, FDA
510(k), RoHS.
User Guide
Quick Installation Sheet
Video cables (2x DVI Dual Link, 2x DisplayPort)
Main cables (UK, European (CEBEC/KEMA), USA (UL/ CSA; adaptor
plug NEMA 5-15P), Chinese (CCC))
USB 2.0 cable
External power supply
None
NA
5years
Operation altitude
3000 m
8.8 Open source license information
Open source license information
Open source license usage
This product contains software components released under an Open Source license. A copy of the source
code is available on request by contacting your Barco customer support representative.
EACH S EPARATE OPEN SOURCE SOFTWARE COMPONENT AND ANY RELATED DOCUMENTATION ARE PROVIDED "AS IS" WITHOUT EXPRESS OR IMPLIED WARRANTY INCLUDING, BUT NOT
LIMITED TO, THE IM PLIED WARRANTIES OF ME RCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL THE COPYRIGHTHOLDER OR ANY OTHER CONTRIBUTOR
BE LIABLE FOR DIRECT, INCIDENTAL OR CONSEQU ENTIAL DAMAGES, EVEN IF ADVISED OF THE
48
K5902055 CORONIS FUSION 6MP 28/08/2013
8. Important information
POSSIBILITY OF SUCH DAMAGES. MORE INFORMATION/DETAILS IS TO BE FOUND IN EACH SPECIFIC OPEN SOURCE LICENSE.
Copyright on each Open Source Software component belongs to the respective initial copyright holder,
each additional contributor and/or their respective assignee(s), as may be identified in the respective documentation, source code, README file, or otherwise. You shall not remove or obscure or otherwise alter
the respective copyrights.
You acknowledge living up to the conditions of each separate Open Source Software license.
A list of the Open Source Software components used is available in the applicable EULA, through the
(customer section of the) Barco website or through other (online) means.
K5902055 CORONIS FUSION 6MP 28/08/2013
49
K5902055-01
August 2013
0120
Barco n.v.
President Kennedypark 35
8500 Kortrijk
Belgium
www.barco.com
Loading...
