Barco MatrixPRO 8x8, MatrixPRO HD-SD-SDI, MatrixPro 16x16 User Manual

NSсNS=~еЗ=UсU=eaLpaJpaf=oзмнЙк
rлЙкЫл=dмбЗЙ
Manual # 26-0401000-00
Revision A
June 29, 2005
NSсNS=~еЗ=UсU=eaLpaJpaf=oзмнЙк==rлЙкЫл=dмбЗЙ
`зйукбЦЬн
shall not otherwise be recorded, transmitted or stored in a retrieval system without the prior written consent of Barco.
kзнбЕЙ
Barco provides this manual “as is” without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/ or the program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this publication; these changes are incorporated in new editions of this publication.
cЙЗЙк~д=`зггмебЕ~нбзел=`зггбллбзе=Ec``F=pн~нЙгЙен
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area may cause harmful interference, in which case the user will be responsible for correcting any interference.
dм~к~енЙЙ=~еЗ=`згйЙел~нбзе
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco must be informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of compliant, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties guaranteed in writing or due to the intent or gross negligence or part of Barco.
ii MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in p articular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not
agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are system failures which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as normal maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied with by the customer.
qê~ÇÉã~êâë
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders. All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for the products or their manufactures.
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide iii
léÉê~íçêë=p~ÑÉíó=pìãã~êó
The general safety information in this summary is for operating personnel.
aз=kзн=oЙгзоЙ=`зоЙкл=зк=m~еЙдл
There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous voltages. To avoid personal injury, do not remove the top cover. Do not operate the unit without the cover installed.
mзпЙк=pзмкЕЙ
This product is intended to operate from a power source that will not apply more than 230 volts rms between the supply conductors or between both supply conductor and ground. A protective ground connection by way of grounding conductor in the power cord is essential for safe operation.
dкзмеЗбеЦ=нЬЙ=mкзЗмЕн
This product is grounded through the grounding conductor of the power cord. To avoid electrical shock, plug the power cord into a properly wired receptacle before connecting to the product input or output terminals. A protective-ground connection by way of the grounding conductor in the power cord is essential for safe operation.
rлЙ=нЬЙ=mкзйЙк=mзпЙк=`зкЗ
Use only the power cord and connector specified for your product. Use only a power cord that is in good condition. Refer cord and connector changes to qualified service personnel.
rлЙ=нЬЙ=mкзйЙк=cмлЙ
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating characteristics. Refer fuse replacement to quali fied service personnel.
aз=kзн=lйЙк~нЙ=бе=bсйдзлбоЙ=^нгзлйЬЙкЙл
To avoid explosion, do not operate this product in an explosive atmosphere.
iv MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
qЙкгл=fе=qЬбл=j~ем~д=~еЗ=bимбйгЙен=j~квбеЦ=
t^okfkd
Highlights an operating procedure, practice, condition, statement, etc., which, if not strictly observed, could result in injury to or death of personnel.
Note
Highlights an essential operating procedure, condition or statement.
`^rqflk
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
^sboqfppbjbkq>
Le point d´exclamation dans un triangle equilatéral signale à alerter l´utilisateur qu´il y a des instructions d´operation et d´entretien tres importantes dans la litérature qui accompagne l´appareil.
slopf`eq
Ein Ausrufungszeichen innerhalb eines gleichwinkeligen Dreiecks dient dazu, den Benutzer auf wichtige Bedienungs-und Wartungsanweisungen in der Dem Great beiliegenden Literatur aufmerksam zu machen.
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide v
`Ь~еЦЙ=eблнзку
The table below lists the changes to the 16x16 and 8x8 HD/SD-SDI Router User’s Guide.
Table 0-1. Change History
Rev Date ECO # Description Approved By
01 6/9/04 Initial Release L. Gilstrom 05 3/28/05 Updates P. Norton A 6/29/05 1458 Release J. Pacak
vi MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
q~ДдЙ=зС=`зенЙенл
`Ü~éíÉê=N fенкзЗмЕнбзе =K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K= N
In This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
How to Use This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Navigating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Table of Contents and Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About the MatrixPRO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
`Ü~éíÉê=O e~êÇï~êÉ=fåëí~ää~íáçå=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K= T
In This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Unpacking and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Rear Panel Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rack-Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Power Cord/Line Voltage Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Video Input/Output Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
`Ü~éíÉê=P léÉê~íáçåK=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=NP
In This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MatrixPRO Power-Up Initialization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
MatrixPRO Front Panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Menu Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Main Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
System Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Factory Reset Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Tech Support Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Status Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Reclocking Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Vertical Interval Switching Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Save Presets Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Recall Presets Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Control of Digital Video Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Establishing Groups of Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Manual Grouping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide vii
Table of Contents
`Ü~éíÉê=Q drf=fåëí~ää~íáçå=~åÇ=léÉê~íáçå K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=PN
In This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Control GUI Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Equipment Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Remote Ethernet Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
GUI Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Video Switching Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Preset Save And Recall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Menu Bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Labeling Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Grouping Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Sequencing Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Setup Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
The "About" Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
`Ü~éíÉê=R ^ййдбЕ~нбзе=pйЙЕбСбЕ=`зееЙЕнбзел=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=QT
In This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Connectivity Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Further Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
`Ü~éíÉê=S réÖê~ÇáåÖ=pçÑíï~êÉK=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=QV
In This Chapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Hardware Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Connecting to Barco Folsom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Downloading Necessary Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Installing MatrixPRO Software Files and Flash File Loader . . . . . . . . . . . . . . 51
Preparing to Upgrade the MatrixPRO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Starting the MatrixPRO Flash File Loader Utility . . . . . . . . . . . . . . . . . . . . . . 52
Uploading Files to MatrixPRO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
^ййЙеЗбс=^= pйЙЕбСбЕ~нбзелK=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=RR
In This Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
SDI Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
HD/SDI Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Common Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
^ййЙеЗбс=_= oЙгзнЙ=`зенкзд=mкзнзЕздK=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=RV
In This Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Default Serial Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
RS-232/485 Remote Control Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
RS-232 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
RS-485 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
MatrixPRO Remote Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
viii MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
Table of Contents
MatrixPRO Serial Command List/Description . . . . . . . . . . . . . . . . . . . 66
HELP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
CLEAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
CSUMSTAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
FPLOCK en. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
GADD grp out in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
GCLEAR grp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
GDEL grp out in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
IPCONFIG I3 I2 I1 I0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
ISTAT num . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
LOADRMP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
OBLNK out blnk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
OSTAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
PRST num. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
PSTAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
RCLKEN num en. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
RESETMP op . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
RNOV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
RPRST num . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
RTEMP out in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
SBAUD mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
SMODE mode [485id] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
SWITCH mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
TAKE en . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
UNOV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
^ййЙеЗбс=`= `зен~Ен=fеСзкг~нбзе=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=TP
In This Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Barco Folsom Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Return Material Authorization (RMA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Barco Events Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
fåÇÉñ =K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=K=TR
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide ix
Table of Contents
x MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
NK==fенкзЗмЕнбзе
få=qÜáë=`Ü~éíÉê
This chapter is designed to introduce you to the MatrixPRO™ 16x16 and 8x8 HD/SD-SDI Router User’s Guide.
Areas to be covered are:
Chapter Structure
How to Use This Guide
Conventions
About the MatrixPRO
Features
T echnical Description
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 1
NK==fенкзЗмЕнбзе

Chapter Structure

`Ь~йнЙк=pнкмЕнмкЙ
The following chapters provide instructions for all aspects of MatrixPRO 16x16 and 8x8 HD/SD-SDI Router operations:
Chapter 1, “Introduction” provides a system overview, a list of features, and
discusses easy ways to use this guide.
Chapter 2, “Hardware Installation” provides comprehensive system installation
instructions.
Chapter 3, “Operation” provides basic system operating instructions.
Chapter 4, “GUI Installation and Operation” describes the system’s interactive
Graphical User Interface application.
Chapter 5, “Application Specific Connections” provides a sample diagram of
system connectivity.
Chapter 6, “Upgrading Soft wa re” outlines procedures for upgrading system
software components.
Appendix A, “Specifications” lists the MatrixPRO 16x16 and 8x8 HD/SD-SDI
Router’s specifications.
Appendix B, “Remote Control Protocol” provides detailed information regarding
external remote control protocol.
Appendix C, “Contact Information” lists important Barco contact, RMA, warranty
and technical support details.
2 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
eçï=íç=rëÉ=qÜáë=dìáÇÉ
Following are important tips for streamlining your use of this User’s Guide in its electronic “PDF” form.
k~îáÖ~íáåÖ
Use Acrobat Reader’s “bookmarks” to navigate to the desired location. All chapter files have the same bookmark structure for instant navigation to any section. Please note:
Extensive hyperlinks are provided within the chapters.
Use Acrobat’s “Go to Previous View” and “Return to Next View” buttons to trace
your complete navigational path.
Use the “Previous Page” and “Next Page” buttons to go to the previous or next
page within a file.
Use Acrobat’s extensive search capabilities, such as the “Find” tool and “Search
Index” tool to perform comprehensive searches as required.
NK==fенкзЗмЕнбзе

How to Use This Guide

q~ДдЙ=зС=`зенЙенл=~еЗ=fеЗЙс
Use the Table of Contents bookmarks to navigate a desired topic. Click any item to instantly jump to that section of the guide. You can also use the Index to jump to specific topics within a chapter. Each page number in the Index is a hyperlink.
`зеоЙенбзел=
The following conventions are used throughout this guide:
The symbol denotes an operations procedure.
The symbol S denotes an example.
Entries written in bold-face capital letters denote physical buttons or chassis
connectors.
S Press SEL to ...
When two buttons together are required for an operation or function, the plus (+)
sign is used between the buttons. This procedure requires that you hold down the first button, then press the second.
S Press SHIFT + 1/9 to ...
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 3
NK==fенкзЗмЕнбзе

About the MatrixPRO

^Äçìí=íÜÉ=j~íêáñmol
The MatrixPRO 16x16 digital router is available in HD-SDI or SD-SDI versions:
The HD-SDI router can route HD-SDI, adhering to SMPTE 292 or SD-SDI signals
adhering to SMPTE 259.
The SD-SDI router adheres only to SMPTE 259.
Both versions of the MatrixPRO 16x16 digital router provide 16 inputs and 16 outputs, and allow any input to be routed to any output (or group of outputs). The 8x router provides eight inputs and eight outputs.
MatrixPRO is an ideal switcher to provide professional-quality serial digital video signal routing. The operator can save up to eight "presets" from the front panel, and eight with the MatrixPRO Control GUI. Typical applications include live staging events, corporate boardroom presentations, and educational and training events. Remote control operation is available over RS-232, RS-485 and Ethernet.
To ensure trouble-free operation, please follow all procedures in the Installation and Operation sections of this manual. Refer to Chapter 2, “Hardware Installation Chapter 3, “Operation” for details.
Should you have any questions regarding the operation of this unit, please consult the factory. Refer to Appendix C, “Contact Information” section for information.
” and
cЙ~нмкЙл
The MatrixPRO 16x16 digital router includes the following features:
HD-SDI architecture allows routing of digital serial video streams, adhering to
SMPTE 292.
SD-SDI architecture routes video adhering to SMPTE 259.
Enable/disable reclockers are provid e d on the ou tp u ts.
IP (Ethernet) control is standard, (a static IP address is required.)
Front Panel Lockout Mode is provided.
Memory Presets save individual I/O configurations for recall via the front panel or
RS-232/485.
I/O Grouping allows specific inputs and outputs to be grouped together making
installation and control easier.
The system’s vertical interval switching capability provides glitch-free switches
when used with synchronous video sources. The source for vertical switching will be channel 1 input.
A MatrixPRO Control Software GUI is provided for setup and control via serial
commands or Ethernet control.
The optional MatrixPRO Remote Control Panel is available for remote operation
via RS-485.
4 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
qЙЕЬебЕ~д=aЙлЕкбйнбзе
The MatrixPRO Serial Digital switcher is available in three versions.
The 16x16 HD-SDI is a serial digital matrix switcher adhering to SMPTE 292M
and SMPTE 259M with 16 inputs and 16 outputs.
The 8x8 HD-SDI is a serial digital matrix switcher adhering to SMPTE 292M and
and SMPTE 259M with 8 inputs and 8 outputs.
The 16x16 SD-SDI is a serial digital matrix switcher adhering to SMPTE 259M
with 16 inputs and 16 outputs.
The output gain is unity into 75 ohm loads. All video signals are carried on BNCs for the highest signal quality.
A matrix switcher can route any input to any output (or multiple) outputs. The matrix switcher has built in capabilities to group outputs and route a si ngle input to that group.
The router has the ability to switch inputs to outputs during the vertical interval. In practice, this feature will be used to switch synchronous sources. Channel 1 is the source for vertical interval switching. The feature can be enabled or disabled.
If there is a signal present on channel 1, status will be reported as valid.
If there is no signal present, status will be reported as invalid.
The reclocking circuits clean up marginal input signals. There are times when the signal quality is much worse than marginal, but still produces a usable picture. In this case, the reclocking circuits should be disabled because they will be ineffective at improving image quality.
The MatrixPRO 16x and 8x series can be controlled by the front panel, RS-232, RS-485, or Ethernet. The MP Control GUI allows control of the MatrixPRO router from a PC via serial and Ethernet interfaces. Barco Folsom also offers the compact 1RU MatrixPRO Remote Control Panel which provides 16 input and 16 output buttons for simple remote operation of the MatrixPRO router.
The MatrixPRO product line has been specifically designed to work as the front-end switchers for the Encore Presentation System. The Encore Controller communicates with MatrixPRO analog and digital routers over an EtherNet local area network. All Controller commands are processed and issued to the array of routers without the need to specifically program each switcher. Control of each router is essentially "transparent" to the user.
NK==fенкзЗмЕнбзе

Technical Description

MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 5
NK==fенкзЗмЕнбзе
Technical Description
6 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
OK==e~êÇï~êÉ=fåëí~ää~íáçå
få=qÜáë=`Ü~éíÉê
This chapter provides detailed instructions for installing the MatrixPRO 16x16 and 8x8 HD/ SD-SDI Router hardware.
The following topics are discussed:
Safety Precautions
Unpacking and Inspection
Site Preparation
Rear Panel Connectors
Rack-Mount Installation
Power Cord/Line Voltage Selection
Video Input/Output Connections
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 7
2. Hardware Installation

Safety Precautions

p~СЙну=mкЙЕ~мнбзел=
For all MatrixPRO 16x16 and 8x8 HD/SD-SDI Router installation procedures, observe the following important safety and handling rules to avoid damage to yourself and the equipment:
To protect users from electric shock, ensure that the power supplies for each unit
connect to earth via the ground wire provided in the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily
accessible.
rей~ЕвбеЦ=~еЗ=fелйЙЕнбзе=
Before opening the boxes, inspect them for damage. If you find any damage, notify the shipping carrier immediately for all claims adjustments. As you open each box, compare its contents against the packing slips. If you find any shortages, contact your Barco sales representative.
Once you have removed all the components from their packaging and checked that all the listed components are present, visually inspect each unit to ensure there was no damage during shipping. If there is damage, notify the shipping carrier immediately for all claims adjustments.
páíÉ=mêÉé~ê~íáçå=
The environment in which you install your MatrixPRO 16x16 and 8x8 HD/SD-SDI Routers should be clean, properly lit, free from static, and have adequate power, ventilation, and space for all components.
8 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
2. Hardware Installation
oЙ~к=m~еЙд=`зееЙЕнзкл
The figures below illustrate the MatrixPRO 16x16 and 8x8 rear panels:

Rear Panel Connectors

1
15131197531
3579111 13 15
4 6 8 1012141622 4 6 8 10 12 14 16
OUTPUTINPUT
2
Figure 2-1. MatrixPRO 16x16 HD-SDI and SD-SDI Rear Panel
INPUT OUTPUT
2
ETHERNET
RS-232/485
100-240 V 50-60 Hz
3.0A
43
1
ETHERNET
8765432112345678
RS-232/485
50-60Hz100-240V
3.0A
43
Figure 2-2. MatrixPRO 8x8 HD-SDI Rear Panel
1) XLR Ethernet Connector 3) DB-25 Serial Communications Connector
2) BNC Video Input and Output Connectors 4) AC Power Connector
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 9
2. Hardware Installation

Rack-Mount Installation

o~ÅâJjçìåí=fåëí~ää~íáçå
MatrixPRO 16x and 8x Digital Router units are designed to be rack mounted. Please note the following important points:
When rack mounting the unit, remember that maximum ambient operating
temperature for the unit is 40 degrees C.
Leave at least one inch of space front and rear to make sure that the airflow
through the fan and vent holes is not restricted.
When installing equipment into a rack, distribute the units evenly to prevent
hazardous conditions that may be created by uneven weight distribution.
Connect the unit only to a properl y rate d sup pl y c ircuit.
Reliable Grounding (Earthing) of Rack-Mounted Equipment should be maintained.
10 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
2. Hardware Installation
mзпЙк=`зкЗLiбеЙ=sздн~ЦЙ=pЙдЙЕнбзе
The MatrixPRO 16x Matrix Switcher performs line voltage selection automatically. No user controls are required for line voltage selection. The AC power cords must be accessible so that the cords can be removed during field servicing.

Power Cord/Line Voltage Selection

Warning
Figure 2-3. Tandem Prong-type Plug
Avertissement
Warnung
When the MatrixPRO 16x16 HD/SDI SDI is used in the 230­volt mode, a UL listed line cord rated for 250 volt s at 15 amp s must be used. This cord will be fitted with a tandem prong­type plug.
La choix de la ligne de voltage se réalise automatiquement par le MatrixPRO 16x16 HD/SDI SDI Transformateur Graphique. On n'a pas besoin du controller usager pour la choix de la ligne de voltage.
Das MatrixPRO 16x16 HD/SDI SDI -Gerät mu beim Anschlu an 240V ~ mit einer vom VDE auf 250V/10A geprüften Netzleitung mit einem Schukostecker ausgestattet sein.
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 11
2. Hardware Installation

Video Input/Output Connections

sбЗЙз=fеймнLlмнймн=`зееЙЕнбзел
The figure below illustrates the input and output connectors on the 16x16 panel:
15131197531
3579111 13 15
4 6 8 1012141622 4 6 8 10 12 14 16
OUTPUTINPUT
RS-232/485
1 2
Figure 2-1. MatrixPRO 16x16 Input/Output Connectors
1) 16x Video Input Connectors 2) 16x Video Output Connectors
The figure below illustrates the input and output connectors on the 8x8 panel:
INPUT OUTPUT
8765432112345678
RS-232/485
100-240 V 50-60 Hz
3.0A
3.0A
ETHERNET
ETHERNET
50-60Hz100-240V
3 4
Figure 2-2. MatrixPRO 8x8 Input/Output Connectors
3) 8x Video Input Connectors 4) 8x Video Output Connectors
1) 16x Video Input Connectors
The video input section on the MatrixPRO rear panel provides 16 digital video inputs. Each HD-SDI input accepts serial digital video signals up to 1.485Gb/s. The SD-SDI version accepts serial digital video signals up to 540Mb/s. Connection points for each type of video signal are illustrated above.
2) 16x Video Output Connectors
Sixteen independently buffered outputs are provided.
3) 8x Video Input Connectors
Eight independently buffered inputs are provided.
4) 8x Video Output Connectors
Eight independently buffered outputs are provided.
12 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
PK==léÉê~íáçå
få=qÜáë=`Ü~éíÉê
This chapter provides detailed operating instructions for the MatrixPRO 16x16 and 8x8 HD/ SD-SDI Routers.
The following topics are discussed:
Control Overview
MatrixPRO Power-Up Initialization
MatrixPRO Front Panels
Menu Structure
Control of Digital Video Switching
Establishing Groups of Inputs and Outputs
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 13
3. Operation

Control Overview

`зенкзд=lоЙкобЙп
This portion of the manual outlines how to control all MatrixPRO functions. There are many means to control the unit available to the user.
First, the front panel is available for status and control. Two keys and a display on
the MatrixPRO front panel are used for navigating through the menu system. This enables you to configure the system, to save and recall presets, and to report system status. Channel routing is accomplished by a set of front panel switches.
A second means of control is through the use of the MatrixPRO Control software.
The GUI can interface to the MatrixPRO through RS-232 or Ethernet.
Barco Folsom makes a Remote Control Switch Panel for controlling the
MatrixPRO remotely.
The unit can be controlled remotely by various third-party controllers.
j~íêáñmol=mçïÉêJré=fåáíá~äáò~íáçå
After plugging in the MatrixPRO to the wall socket, locate the power switch on the back of the chassis, and turn the power ON. The LEDs on the buttons will light, the display will show the Main Menu screen, and the last saved or recalled setup will be recalled.
14 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
3. Operation
j~íêáñmol=cêçåí=m~åÉäë
On the MatrixPRO 16x and 8x routers, the front panel allows local control and monitoring of the matrix switcher. The figures below illustrate the MatrixPRO 16x16 and 8x8 front panels:

MatrixPRO Front Panels

2
ADJUST
ESC
5
Figure 3-1. MatrixPRO 16x16 Front Panel
2
SEL
ADJUST
ESC
31
INPUT
9
9
OUTPUT
6
31
INPUT
7654321
1 234567
OUTPUT
4
8167156145134123112101
SHIFTSEL
8167156145134123112101
TAKE
SHIFT
7
4
8
8
TAKE
5
6
Figure 3-2. MatrixPRO 8x8 Front Panel
1) Menu Display 5) Menu Navigation Buttons
2) Menu Selector Knob 6) Output Crosspoint Selection Buttons
3) Input Crosspoint Selection Buttons 7) SHIFT Buttons (for MatrixPRO 16x16 only)
4) TAKE Button
1) Menu Display
The Menu Display shows all MatrixPRO menus, using a four-line display. Brightness is adjustable.
2) Menu Selector Knob
Use the Selector Knob to scroll through system menus. The cursor (>) always indicates the current line.
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 15
3. Operation
MatrixPRO Front Panels
Please continue with the “Menu Structure the MatrixPRO Digital product line.
3) Input Crosspoint Selection Buttons
At the right-side of the front panel, the 8x and 16x routers each have a set of eight input selection switches on the top row. On the 16x only, unshifted input buttons access inputs 1-8; shifted buttons access inputs 9-16.
Routing operation resembles the industry standard procedure — select a destination (output), select a source (input) and press TAKE.
4) TAKE Button
Once input and output selections are made, press TAKE to complete a route.
5) Menu Navigation Buttons
Two but tons are provided for menu navigation. Within the menu structure:
~ Press SEL to enter a menu, change a parameter and accept a
parameter.
~ Press ESC to exit a menu without making changes, and to navigate up
the menu tree.
Refer to the “Main Menu” section for additional menu navigation instructions.
6) Output Crosspoint Selection Buttons
At the right-side of the front panel, The 8x and 16x routers each have a set of eight output selection switches on the bottom row. On the 16x only, unshifted output buttons access outputs 1-8; shifted buttons access outputs 9-16.
Routing operation resembles the industry standard procedure — select a destination (output), select a source (input) and press TAKE.
7) SHIFT Buttons
On the 16x router only, the two SHIFT keys allows access to inputs 9 through 16, and outputs 9 through 16. When the SHIFT key is pressed for the adjacent row, the button lights to indicate that inputs (or outputs) 9 through 16 can be accessed.
” section, which describes all menu displays in
16 MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide
3. Operation
jЙем=pнкмЕнмкЙ
This section illustrates and explains all the menus in the MatrixPRO’s menu structure, in the order in which they appear. The following topics are discussed:
Menu Tree
Main Menu
Setup Menu
Status Menu
Reclocking Menu
Vertical Interval Switching Menu
Save Presets Menu
Recall Presets Menu

Menu Structure

Note
The MatrixPRO menu display is four lines high, and the selector knob is used to scroll through the lines. In the following sections, entire menus will be shown for clarity, rather than four-line sections.
MatrixPRO • 16x16 and 8x8 HD/SD-SDI Router • User’s Guide 17
