Barco G60-W10, G60-W7, G60-W8 User Manual

Page 1
G60
ENABLING BRIGHT OUTCOMES
User Guide
Page 2
Barco NV
Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com
Registered office: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
Page 3
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not otherwise be recorded, transmitted or stored in a retrieval system without the prior written consent of Barco.
Changes
Barco provides this manual 'as is' without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.
This publication could contain technical inaccuracies or typographical errors. Changes are periodically made to the information in this publication; these changes are incorporated in new editions of this publication.
The latest edition of Barco manuals can be downloaded from the Barco web site www.barco.com or from the secured Barco web site https://www.barco.com/en/signin.
Trademarks
Brand and product names mentioned in this manual may be trademarks, registered trademarks or copyrights of their respective holders. All brand and product names mentioned in this manual serve as comments or examples and are not to be understood as advertising for the products or their manufacturers.
Guarantee and Compensation
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred during transport, as well as for material and manufacturing faults Barco must be informed immediately in writing of any complaints.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for direct or indirect damage, and also damage attributed to the operation of software as well as to other services provided by Barco, being a component of the system or independent service, will be deemed invalid provided the damage is not proven to be attributed to the absence of properties guaranteed in writing or due to the intent or gross negligence or part of Barco.
If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. Not included in the guarantee coverage are system failures which are attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as normal maintenance are not subject to the guarantee provided by Barco either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied with by the customer.
Federal Communications Commission (FCC Statement)
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area may cause harmful interference, in which case the user will be responsible for correcting any interference at his own expense
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment
Page 4
FCC responsible: Barco Inc.
3059 Premiere Parkway Suite 400 30097 Duluth GA, United States Tel: +1 678 475 8000
Patent protection
Please refer to www.barco.com/about-barco/legal/patents
EMC notices
EN55032/CISPR32 Class A MME (MultiMedia Equipment)
Warning : This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment
may cause radio interference.
GB/T 9254 Class A ITE (Information Technology Equipment)
Warning : This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
BSMI Taiwan Class A statement:
警告使用者 : 此為甲類資訊技術設備,於居住環境中使用 ,可能會造成射頻擾動,在此情況下,使用者會被要 求採取某些適當的對策。
Page 5
Table of contents
1 Safety.........................................................................................................................................................................................................................7
1.1 General considerations ....................................................................................................................................................................8
1.2 Important safety instructions ......................................................................................................................................................10
1.3 Product safety labels.......................................................................................................................................................................13
2 Product overview ...........................................................................................................................................................................................15
2.1 Main unit.................................................................................................................................................................................................16
2.2 Input/Output (I/O) Panel ................................................................................................................................................................17
2.3 Control panel .......................................................................................................................................................................................18
2.4 Remote Control Unit (RCU) ........................................................................................................................................................19
3 Powering On/Off the projector..............................................................................................................................................................21
3.1 Powering On the projector...........................................................................................................................................................22
3.2 Powering Off the Projector...........................................................................................................................................................22
4 User controls.....................................................................................................................................................................................................25
4.1 On-Screen Display Menus...........................................................................................................................................................26
4.2 Picture Menu .......................................................................................................................................................................................27
4.3 Screen Menu .......................................................................................................................................................................................30
4.4 Settings Menu.....................................................................................................................................................................................34
4.5 Light Source Menu ...........................................................................................................................................................................35
4.6 Options Menu......................................................................................................................................................................................36
4.7 3D Menu.................................................................................................................................................................................................38
4.8 Communications Menu..................................................................................................................................................................39
5 Troubleshooting..............................................................................................................................................................................................41
5.1 LED indication chart ........................................................................................................................................................................42
5.2 Projector Problems .......................................................................................................................................................................... 43
A Specifications...................................................................................................................................................................................................45
A.1 Product specification of the G60-W7 .....................................................................................................................................46
A.2 Product specification of the G60-W8 .....................................................................................................................................47
A.3 Product specification of the G60-W10 ..................................................................................................................................48
A.4 Compatibility modes........................................................................................................................................................................49
A.5 Dimensions of the G60 ..................................................................................................................................................................52
A.6 Ceiling mount ......................................................................................................................................................................................54
B Environmental information .....................................................................................................................................................................55
B.1 China RoHS compliance...............................................................................................................................................................56
B.2 Taiwan RoHS compliance ............................................................................................................................................................ 57
B.3 Turkey RoHS compliance ............................................................................................................................................................58
B.4 Disposal information........................................................................................................................................................................58
R5910888 /00 G60
5
Page 6
B.5 Production address..........................................................................................................................................................................59
B.6 Contact information .........................................................................................................................................................................59
B.7 Download Product Manual ..........................................................................................................................................................59
Glossary....................................................................................................................................................................................................................1
Index............................................................................................................................................................................................................................1
R5910888 /00 G606
Page 7

Safety 1

About this document
Read this document attentively. It contains important information to prevent personal injury while installing and using the G60 projector. Furthermore, it includes several cautions to prevent damage to the G60 projector. Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing the G60 projector.
Clarification of the term G60used in this document
When referring in this document to the term G60means that the content is applicable for following Barco products:
G60-W7, G60-W8, G60-W10
Model certification name
G60
Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. Observing the specification mentioned in this chapter is critical for projector performance. Neglecting this can result in loss of warranty.
Overview
General considerations
Important safety instructions
Product safety labels
R5910888 /00 G60
7
Page 8
Safety

1.1 General considerations

General safety instructions
Before operating this equipment please read this manual thoroughly and retain it for future reference.
Installation and preliminary adjustments should be performed by qualified Barco personnel or by
authorized Barco service dealers.
All warnings on the projector and in the documentation manuals should be adhered to.
All instructions for operating and use of this equipment must be followed precisely.
All local installation codes should be adhered to.
Notice on safety
This equipment is built in accordance with the requirements of the international safety standards IEC60950-1, EN60950-1, UL60950-1 and CAN/CSA C22.2 No.60950-1, which are the safety standards of information technology equipment including electrical business equipment. These safety standards impose important requirements on the use of safety critical components, materials and insulation, in order to protect the user or operator against risk of electric shock and energy hazard and having access to live parts. Safety standards also impose limits to the internal and external temperature rises, radiation levels, mechanical stability and strength, enclosure construction and protection against the risk of fire. Simulated single fault condition testing ensures the safety of the equipment to the user even when the equipment's normal operation fails.
Laser safety precautions for G60-W7 series
This product is classified as Class 1 Laser Product-Risk Group 2 of IEC 60825-1 : 2014 and Class 3R Laser product of IEC 60825-1:2007, complying with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.50, dated June 24, 2007.
To ensure safety operation, read all laser safety precautions before installing and operating the projector.
Class 3R Laser product. Do NOT deliberately look into or stare into the beam, which can cause injury to
the retina in the back of the eye.
When turning on the projector, make sure no one within projection range is looking at the lens.
Keep any reflective objects out of the light path of the projector. Glass and shinny surfaces can eflect the
laser beam from the lens as the light path is extensive, and the reflective beam can cause unpredictable incident such as fire hazards or eye injuries.
Any operation or adjustment not specifically instructed by the user’s guide creates the risk of hazardous
laser radiation exposure.
Do not open or disassemble the projector as this may cause damage by the exposure of laser radiation.
Failure to follow the control, adjustment or operation procedures may cause damage by the exposure of
laser radiation.
Laser safety precautions for G60-W8 series
This product is classified as CLASS 1 LASER PRODUCT - RISK GROUP 2 of IEC 60825-1 : 2014 and also complies with 21 CFR 1040.10 and 1040.11 as a Risk Group 2, LIP ( Laser Illuminated Projector) as defined in IEC 62471:2006 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
According to IEC 60825-1:2014 and IEC 62471:2006, this projector may become CLASS 1 LASER PRODUCT - RISK GROUP 3 product when installed with G LENS (2.90 - 5.50 : 1) lens (throw ratio 2.90-5.50).
To ensure safety operation, read all laser safety precautions before installing and operating the projector.
This projector uses extremely high brightness laser. Never attempt to look directly into the lens or at the
laser beam. The bright light may result in permanent eye damage.
Possibly hazardous optical radiation emitted from this product.
This projector has a built-in Class 4 laser module. Never attempt to disassemble or modify the laser
module.
Any operation or adjustment not specifically instructed in the User manual creates the risk of hazardous
laser radiation exposure.
Do not stare into beam when the projector is on. When turning on the projector, make sure no one within
projection range is looking into the lens.
Follow the control, adjustment, or operation procedures to avoid damage or injury from exposure of laser
radiation.
R5910888 /00 G608
Page 9
Safety
The instructions for the assembly, operation, and maintenance include clear warnings concerning
precautions to avoid possible exposure to hazardous laser radiation.
Laser safety precautions for G60-W10 series
This product is classified as Class 1 Laser Product-Risk Group 2 (RG2 ) of IEC 60825-1: 2014 and Class 3R Laser product of IEC 60825-1:2007, complying with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.50, dated June 24, 2007.
When installed with G LENS (2.90 - 5.50 : 1) lens (throw ratio 2.90-5.50), this projector may become Class 1 Laser Product-Risk Group 3 (RG3) according to IEC 60825-1:2014, IEC 62471:2006, IEC 62471-5: 2015, and also complying with Immediately in Effect Guidance Document: Classification and Requirements for Laser Illuminated Projectors (LIPs) Guidance for Industry and Food and Drug Administration Staff Document issued on February 18, 2015.
To ensure safety operation, read all laser safety precautions before installing and operating the projector.
This projector uses extremely high brightness laser. Do not stare into the direct laser beam, as the
extremely high brightness may cause permanent eye damage. (Risk Group 2 of IEC 62471-5:2015).
No direct exposure to the beam shall be permitted. (Risk Group 2/Risk Group 3 of IEC 62471-5:2015).
This product is not for household use.
Possibly hazardous optical radiation emitted from this product.
This projector has a built-in Class 4 laser module. Never attempt to disassemble or modify the laser
module.
Any operation or adjustment not specifically instructed in the User manual creates the risk of hazardous
laser radiation exposure.
Do not stare into beam when the projector is on. When turning on the projector, make sure no one within
projection range is looking into the lens.
Follow the control, adjustment, or operation procedures to avoid damage or injury from exposure of laser
radiation.
The instructions for the assembly, operation, and maintenance include clear warnings concerning
precautions to avoid possible exposure to hazardous laser radiation.
Light Intensity Hazard Distance for G60-W8 series
This projector may become CLASS 1 LASER PRODUCT - RISK GROUP 3 when installed with G LENS (2.90
- 5.50 : 1) lens (throw ratio 2.90-5.50). Permanent eye injury is possible when exposed to the high intensity laser beam within the hazard distance.
Projection Lens
G LENS (2.90 - 5.50 : 1) 2.90-5.50 IEC 60825-1:2014 IEC 62471:2006
Follow the precautions to avoid light intensity hazard.
NEVER look into the lens! High intensity laser beam.
Permanent eye injury is possible when exposed to the high intensity laser light within the hazard distance.
Do not place any reflective objects in the light path of the projector.
Throw Ratio
Classification and Requirements for Laser Illuminated
Projectors (LIPs)
CLASS 1 RISK GROUP 3
HD: 2.15 meters
Light Intensity Hazard Distance for G60-W10 series
This projector may become Class 1 Laser Product-Risk Group 3 (RG3) when installed with G LENS (2.90 -
5.50 : 1) lens (throw ratio 2.90-5.50). Permanent eye injury is possible when exposed to the high intensity laser beam within the hazard distance (HD).
Projection Lens
Throw Ratio
Classification and Requirements for Laser Illuminated
Projectors (LIPs)
G LENS (2.90 - 5.50 : 1) 2.90-5.50 IEC 60825-1:2014 IEC 62471:2006 IEC 62471-5:
2015
R5910888 /00 G60 9
Page 10
Safety
Projection Lens
Follow the precautions to avoid light intensity hazard.
NEVER look into the lens! High intensity laser beam.
Permanent eye injury is possible when exposed to the high intensity laser light within the hazard distance.
Operators shall control access to the beam within the hazard distance or install the product at a height that
will prevent eye exposure within the hazard distance.
Do not place any reflective objects in the light path of the projector.
Throw Ratio
Classification and Requirements for Laser Illuminated
Projectors (LIPs)
CLASS 1 RISK GROUP 3
HD: 8.0 meters
RISK GROUP 3
HD: 3.0 meters
User definition
Throughout this manual, the term SERVICE PERSONNEL refers to Barco authorized persons having appropriate technical training and experience necessary to be knowledgeable of potential hazards to which they are exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons. Only Barco authorized SERVICE PERSONNEL, knowledgeable of such risks, are allowed to perform service functions inside the product enclosure. The term USER and OPERATOR refers to any person other than SERVICE PERSONNEL. When installing an interchangeable lens with a throw ratio that make the projector become RG3, refer to chapter Risk Group 3 Safety, page 9. Such combination of projector and lens are intended for professional use only, and are not intended for consumer use.
FOR PROFESSIONAL USE ONLY means installation can only be carried out by Barco AUTHORIZED PERSONNEL familiar with potential hazards associated with high intensity light beams.

1.2 Important safety instructions

To prevent the risk of electrical shock
This product should be operated from a mono phase AC power source.
This apparatus must be grounded (earthed) via the supplied 3 conductor AC power cable. If none of the
supplied power cables are the correct one, consult your dealer. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the purpose of the grounding­type plug.
Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the
cord. To disconnect the cord, pull it out by the plug. Never pull the cord itself.
Use only the power cord supplied with your device. While appearing to be similar, other power cords have
not been safety tested at the factory and may not be used to power the device. For a replacement power cord, contact your dealer.
Do not operate the projector with a damaged cord. Replace the cord.
Do not operate the projector if the projector has been dropped or damaged until it has been examined and
approved for operation by a qualified service technician. Position the cord so that it will not be tripped over, pulled, or contact hot surfaces.
If an extension cord is necessary, a cord with a current rating at least equal to that of the projector should
be used. A cord rated for less amperage than the projector may overheat.
Never push objects of any kind into this product through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a risk of fire or electrical shock.
Do not expose this projector to rain or moisture.
Do not immerse or expose this projector in water or other liquids.
Do not spill liquid of any kind on this projector.
Should any liquid or solid object fall into the cabinet, unplug the set and have it checked by qualified
service personnel before resuming operations.
Do not disassemble this projector, always take it to an authorized trained service person when service or
repair work is required.
Do not use an accessory attachment which is not recommended by the manufacturer.
R5910888 /00 G6010
Page 11
Safety
Lightning - For added protection for this video product during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the device due to lightning and AC power-line surges.
To prevent personal injury
To prevent injury and physical damage, always read this manual and all labels on the system before
connecting to the wall outlet or adjusting the projector.
To prevent injury, take note of the weight of the projector.
To prevent injury, ensure that the lens and all covers are correctly installed. See installation procedures.
Warning: high intensity light beam. NEVER look into the lens ! High luminance could result in damage to
the eye.
Warning: extremely high brightness laser: This projector uses extremely high brightness laser. Never
attempt to look directly into the lens or at the laser.
Before attempting to remove any of the projector’s covers, you must turn off the projector and disconnect
from the wall outlet.
When required to switch off the projector, to access parts inside, always disconnect the power cord from
the power net.
The power input at the projector side is considered as the disconnect device. When required to switch off
the projector, to access parts inside, always disconnect the power cord at the projector side. In case the power input at the projector side is not accessible (e.g. ceiling mount), the socket outlet supplying the projector shall be installed nearby the projector and be easily accessible, or a readily accessible general disconnect device shall be incorporated in the fixed wiring.
Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious
damage to it and possible injury to the user.
It is hazardous to operate without lens or shield. Lenses, shields or ultra violet screens shall be changed if
they have become visibly damaged to such an extent that their effectiveness is impaired. For example by cracks or deep scratches.
Exposure to UV radiation: Some medications are known to make individuals extra sensitive to UV
radiation. The American Conference of Governmental Industrial Hygienists (ACGIH) recommends occupational UV exposure for an-8 hour day to be less than 0,1 micro-watts per square centimeters of effective UV radiation. An evaluation of the workplace is advised to assure employees are not exposed to cumulative radiation levels exceeding these government guidelines. The exposer of this UV radiation is allowed for only 1 hour per day for maintenance and service persons.
To prevent fire hazard
Do not place flammable or combustible materials near the projector!
Barco large screen projection products are designed and manufactured to meet the most stringent safety
regulations. This projector radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe. Exposing flammable or combustible materials into close proximity of this projector could result in the spontaneous ignition of that material, resulting in a fire. For this reason, it is absolutely necessary to leave an exclusion zonearound all external surfaces of the projector whereby no flammable or combustible materials are present. The exclusion zone must be not less than 100 cm (39.4) for all DLP projectors. The exclusion zone on the lens side must be at least 5 m. Do not cover the projector or the lens with any material while the projector is in operation. Keep flammable and combustible materials away from the projector at all times. Mount the projector in a well-ventilated area away from sources of ignition and out of direct sun light. Never expose the projector to rain or moisture. In the event of fire, use sand, CO2 or dry powder fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non- Barco replacement parts as they may degrade the safety of this projector.
Slots and openings in this equipment are provided for ventilation. To ensure reliable operation of the
projector and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the projector too close to walls, or other similar surface. This projector should never be placed near or over a radiator or heat register. This projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided.
Projection rooms must be well ventilated or cooled in order to avoid build up of heat.
Let the projector cool down completely before storing. Remove cord from the projector when storing.
R5910888 /00 G60 11
Page 12
100 cm (39.4”)
100 cm (39.4”)
100 cm (39.4”)
100 cm (39.4”)
30 mm
(1.2”)
10.1 mm (0.4”)
1 2
Safety
To prevent projector damage
Always remove lens cap before switching on the projector. If the lens cap is not removed, it may melt due
to the high energy light emitted through the lens. Melting the lens cap may permanently damage the surface of the projection lens.
The air filters of the projector must be cleaned or replaced on a regular basis. Cleaning the booth area
would be monthly minimum. Neglecting this could result in disrupting the air flow inside the projector, causing overheating. Overheating may lead to the projector shutting down during operation.
The projector must always be installed in a manner which ensures free flow of air into its air inlets and
unimpeded evacuation of the hot air from its cooling system.
If more than one projector is installed in a common projection booth, the exhaust air flow requirements are
valid for EACH individual projector system. Note that inadequate air extraction or cooling will result in decreased life expectancy of the projector as a whole as well as causing premature failure of the lasers.
In order to ensure that correct airflow is maintained, and that the projector complies with Electromagnetic
Compatibility (EMC) requirements, it should always be operated with all of its covers in place.
Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product
and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heat register. The device should not be placed in a built-in installation or enclosure unless proper ventilation is provided.
Ensure that nothing can be spilled on, or dropped inside the projector. If this does happen, switch off and
unplug the mains supply immediately. Do not operate the projector again until it has been checked by qualified service personnel.
Do not block the projector cooling fans or free air movement around the projector.
Do not use this equipment near water.
Special care for Laser Beams: Special care should be used when DLP projectors are used in the same
room as high power laser equipment. Direct or indirect hitting of a laser beam on to the lens can severely damage the Digital Mirror Devicesin which case there is a loss of warranty.
Never place the projector in direct sun light. Sun light on the lens can severely damage the Digital Mirror
Devicesin which case there is a loss of warranty.
Save the original shipping carton and packing material. They will come in handy if you ever have to ship
your equipment. For maximum protection, repack your set as it was originally packed at the factory.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning. Never use strong solvents, such as thinner or benzine, or abrasive cleaners, since these will damage the cabinet. Stubborn stains may be removed with a cloth lightly dampened with mild detergent solution.
To ensure the highest optical performance and resolution, the projection lenses are specially treated with
an anti-reflective coating, therefore, avoid touching the lens. To remove dust on the lens, use a soft dry cloth. Do not use a damp cloth, detergent solution, or thinner.
Rated operating ambient temperature: ta= 5 °C (41 °F) to 40 °C (104 °F).
Rated operating humidity: 10% RH to 85% RH (non-condensing). yy This projector can be set to any angle
within 360° range.
Allowing proper space around the projector is critical for proper air circulation and cooling of the unit. The
dimensions shown here indicate the minimum space required.
Image 1-1
1 Bottom intake vents. 2 Ceiling mount plate.
R5910888 /00 G6012
Page 13
RG 2
COMPLIES WITH 21 CFR 1040.10AND
1040.11 E
XCEPT FOR DEVIATIONS PURSUANT TO LASER NOTICE No. 50, DATED JUNE 24, 2007. IEC/EN 60825-1:2007
IEC/EN 60825-1 : 2007 LASER RADIATION -AVOID DIRECT EYE EXPOSURE - CLASS 3R LASER PRODUCT Wave length : 449-461 nm / Max. Pulse energy : 0.52mJ / Pulse duration : 1.06 ms IEC/EN 60825-1 : 2014 CLASS 1 LASER PRODUCT/ RISK GROUP 2 WARNING : Possibly hazardous optical radiation emitted from this product. Do not stare into the beam, May be harmful to the eyes.
IEC/EN 60825-1 : 2007
IEC/EN 60825-1 : 2014
IEC/EN 60825-1 : 2007 RAYONNEMENTLASER - ÉVITEZ TOUTE EXPOSITION DIRECTE DES YEUX ­PRODUITLASER DE CLASSE 3R Longueur d'ondes : 449 - 461 nm / Max.impulsion d'énergie : 0.52 mJ / Durée impulsions 1.06 ms IEC/EN 60825-1 : 2014 PRODUITLASER DE CLASSE 1 / GROUPE A RISQUE 2 AVERTISSEMENT: Risquse possibles de rayonnements optiques émis par ce produit. Ne pas regarder dans le faisceau. Peut être dangereux pour les yeux.
IEC/EN 60825-1 : 2007
IEC/EN 60825-1 : 2014
Safety
For ceiling mounted installations, make sure to leave 30 mm (1.2”) between the ceiling mount and the
bottom intake vents of the projector.
To prevent battery explosion
Danger of explosion if battery is incorrectly installed.
Replace only with the same or equivalent type recommended by the manufacturer.
For disposal of used batteries, always consult federal, state, local and provincial hazardous waste disposal
rules and regulations to ensure proper disposal.
On servicing
Do not attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltage potentials and risk of electric shock.
Refer all servicing to qualified service personnel.
Attempts to alter the factory-set internal controls or to change other control settings not specially discussed
in this manual can lead to permanent damage to the projector and cancellation of the warranty.
Remove all power from the projector and refer servicing to qualified service technicians under the following
conditions:
- When the power cord or plug is damaged or frayed.
- If liquid has been spilled into the equipment.
- If the product has been exposed to rain or water.
- If the product does not operate normally when the operating instructions are followed. Adjust only those
controls that are covered by the operating instructions since improper adjustment of the other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation.
- If the product has been dropped or the cabinet has been damaged.
- If the product exhibits a distinct change in performance, indicating a need for service.
Replacement parts: When replacement parts are required, be sure the service technician has used original
Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards. Unauthorized substitutions may void warranty.
Safety check: Upon completion of any service or repairs to this projector, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
Safety Data Sheets for Hazardous Chemicals
For safe handling information on chemical products, consult the Safety Data Sheet (SDS). SDSs are available upon request via safetydatasheets@barco.com.

1.3 Product safety labels

Light beam related safety labels for G60-W7 series
Label image Label description
Risk Group 2 of IEC60825-1:2014 and Class 3R Laser product of IEC 60825-1:2007. Do not look into the laser light. The extremely high brightness may cause permanent eye damage.
This product is classified as Class 1 Laser Product-Risk Group 2 of IEC 60825-1 : 2014 and Class 3R Laser product of IEC 60825­1:2007, complying with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.50, dated June 24, 2007.
R5910888 /00 G60 13
Page 14
R G 2R G 2
Thi s produ ct comp lies wi th perf orman ce stan dards f or lase r pro ducts u nder 21 C FR Part 1 040 exc ept wit h respe ct to tho se cha racte risti cs auth orize d by Varia nce Num ber XXX X-X-X XXX effe ctive [ inser t the da te of the v arian ce appr oval]
BAR CO INC 305 9 Premi ere Par kway Su ite 400 , Dulut h, GA 3009 7, USA
U.S .A. Onl y
Warni ng! Do no t look in to the be am. No di rect ey e expos ure to th e beam is per mitte d. Not fo r house hold us e. RG3 Ha zard Di stanc e: Refe r to the ma nual.
Avert issem ent! Ne r egard ez pas à l' intér ieur du f aisce au. L'e xposi tion dire cte des y eux au fa iscea u est int erdit e. RG3 Di stanc e à risqu e: Cons ultez l e manue l.
! .
. R G 3 :
IEC6 0825- 1:201 4 Class 1 L aser Pr oduct R isk Gro up 3
Thi s produ ct comp lies wi th perf orman ce stan dards f or lase r pro ducts u nder 21 C FR Part 1 040 exc ept wit h respe ct to tho se cha racte risti cs auth orize d by Varia nce Num ber XXX X-X-X XXX effe ctive [ inser t the da te of the v arian ce appr oval]
BAR CO INC 305 9 Premi ere Par kway Su ite 400 , Dulut h, GA 3009 7, USA
U.S .A. Onl y
Safety
Light beam related safety labels for G60-W8 series
Label image Label description
Risk Group 2, IEC60825-1:2014. Do not look into the laser light. The extremely high brightness may cause permanent eye damage.
FDA laser variance (US projectors only)
This product is classified as Class 1 Laser Product-Risk Group 2 of IEC 60825-1:2014 and also complies with 21 CFR 1040.10 and
1040.11 as a Risk Group 2, LIP ( Laser Illuminated Projector) as defined in IEC 62471:2006 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
This projector may become Class 1 Laser Product-Risk Group 3 of IEC 60825-1:2014 when installed with G lens - Ultra Long Zoom (throw ratio 2.90 - 5.50 : 1).
Light beam related safety labels for G60-W10 series
Label image Label description
FDA laser variance (US projectors only)
This product is classified as Class 1 Laser Product-Risk Group 2 of IEC/EN 60825-1:2014 and Class 3R Laser product of IEC/EN 60825-1:2007, complying with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.50, dated June 24, 2007.
This projector may become Risk Group 3 product when an interchangeable lens with throw ratio greater than 2.9 (G lens - Ultra Long Zoom) is installed. Refer to the manual for the lens list and hazard distance before operation. Such combinations of projector and lens are intended for professional use only, and are not intended for consumer use.
Not for household use. No direct exposure to beam shall be permitted, which can cause
injury to the retina in the back of the eye.
R5910888 /00 G6014
Page 15

Product overview 2

Overview
Main unit
Input/Output (I/O) Panel
Control panel
Remote Control Unit (RCU)
R5910888 /00 G60
15
Page 16
1
2
76 6 68 9
3 54
Product overview

2.1 Main unit

Component location
Image 2-1
1 Remote receiver (Front) 2 Projection lens
Image 2-2
3 LED Status Indicator 4 Input/Output (I/O) Panel 5 Remote receiver (Top) 6 Adjustable feet
R5910888 /00 G6016
7 Control panel 8 Power socket (AC100-
240V, 50-60Hz)
9 Power switch
Page 17
Airflow
VGA-OUT
VGA-I N
DVI-D
HDMI-1
HDMI-2
3D SYNC OUT
3D SYNC I N
LAN
HDBas eT
RE MOTE IN
USB T ype-A
mini USB
3G-S DI
RS -232
1 2 4 5 6
7 8 9 10 11 12 13
3
Image 2-3

2.2 Input/Output (I/O) Panel

Product overview
Input and output ports location
Image 2-4
1 3D SYNC IN 2 HDBaseT connector 3 HDMI connector 4 DVI-D input connector 5 VGA-IN connector 6 3D-SGI connector 7 3D SYNC OUT
8 Networking connector RJ45 9 USB Type-A (Power out 5V, 0.5A) 10 Mini USB (Service) 11 Wired remote connector 12 RS232 connector 13 VGA-OUT connector
R5910888 /00 G60 17
Page 18
Z
IN PU TEX IT
ME NU
LE NS
FO CU S
OO M
EN TE R
1 2 3 6
7 8 9
11
10
5
12
4
Product overview

2.3 Control panel

Button location
Image 2-5
1 POWER 2 LENS 3 MENU 4 EXIT 5 ENTER 6 INPUT
7 ZOOM 8 FOCUS 9 LEFT 10 UP 11 DOWN 12 RIGHT
Button function
Button Function
POWER Turn the projector on or off.
LENS Adjust lens position.
MENU Show the main menu on screen.
EXIT Return to previous menu or exit menu if at top level.
ENTER Confirm the settings.
INPUT Select an input source.
ZOOM Adjust the image size.
FOCUS Adjust the image focus.
LEFT Navigate left through the menu.
UP Navigate up through the menu.
DOWN Navigate down through the menu.
RIGHT Navigate right through the menu.
R5910888 /00 G6018
Page 19

2.4 Remote Control Unit (RCU)

ON OFF
21 3
54 6
87 9
Gamma Bright Cont. PIP
0
Info
Mode
Auto Input
Menu Exit
Hot Key
Shutter
(AV Mute)
Pattern
Focus
Lens H
Lens V
Keystone H
Keystone V
Zoom
Enter
1
4
3
6
10
12
14
2
8
9
16
17
19
20
22
23
5
7
11
13
15
18
21
24
Button identification
Button location No. Button Function
1 ON Turn on the projector.
2 OFF Turn off the projector.
3 Number Input numbers (0-9).
4 Info Displays information on the source
image.
5 Mode Select a preset picture mode.
6 Auto Automatically synchronize the projector
to an input source.
7 Input Select an input source manually.
8 Enter Confirm an selection.
9 Arrow keys Use arrow keys to navigate through the
menu or select the appropriate settings.
Product overview
10 Menu Show the main menu on the screen.
11 Exit Back to previous Menu.
12 Gamma Set the gamma of the image.
13 PIP Set up the picture in picture (PIP) mode.
14 Brightness Set the brightness of the image.
15 Contrast Set the contrast of the image.
16 Lens H Adjust the image position horizontally.
17 Lens V Adjust the image position vertically.
18 Focus Adjust the image focus.
19 Keystone H Adjust a horizontally keystone image.
20 Keystone V Adjust a vertically keystone image.
21 Zoom Adjust the image size.
22 Shutter Momentarily turn off/on the screen (AV
Mute).
23 Hot Key Select a specific function set as the hot
key.
24 Pattern Display test patterns.
R5910888 /00 G60 19
Page 20
Product overview
R5910888 /00 G6020
Page 21

Powering On/Off the projector

This chapter assumes that the power cord and (all) signal cables are securely connected. For detailed instructions see installation manual.
Overview
Powering On the projector
Powering Off the Projector
3
R5910888 /00 G60
21
Page 22
1
IN PU TEX IT
ME NU
LE NS
FO CU S EN TE R
ON OFF
21 3
54 6
2 3
4
Powering On/Off the projector

3.1 Powering On the projector

How to power On the projector
1. Power on the AC switch (1) and wait until the power button on the control panel is solid red.
Image 3-1
2. Turn on the projector by pressing the POWER button (2) on the control panel or the ON key (3) on the remote
control.
Image 3-2
The status LED (4) will flash orange. The startup screen will display and the status LED will turn to solid green.
Image 3-3
3. Turn on your source. The projector detects the source you selected and displays the image.
Note: If you connect multiple sources at the same time, press Inputkey on the control panel or on the remote control to switch inputs.
WARNING: Do not look directly into the lens when the projector is turned on. The strong light might cause permanent eye damage.

3.2 Powering Off the Projector

How to power Off the projector
1. Press the POWER button (2) on the control panel or the OFF key (5) on the remote control, a message
displays on the screen.
R5910888 /00 G6022
Page 23
IN PU TEX IT
ME NU
LE NS
FO CU S EN TE R
ON OFF
21 3
54 6
2 5
Powering On/Off the projector
Image 3-4
2. Press the POWER button or OFF key again to confirm, otherwise the message disappears after 5 seconds
and the projector remains on.
CAUTION: Dont turn on the projector immediately after entering Standby mode.
R5910888 /00 G60 23
Page 24
Powering On/Off the projector
R5910888 /00 G6024
Page 25

User controls 4

Overview
On-Screen Display Menus
Picture Menu
Screen Menu
Settings Menu
Light Source Menu
Options Menu
3D Menu
Communications Menu
R5910888 /00 G60
25
Page 26
1 2 3
User controls

4.1 On-Screen Display Menus

About OSD
The projector has On-Screen Display (OSD) menus that allow you to make image adjustments and change a variety of settings.
Follow the steps below to use the OSD menu to configure the projector settings.
How to operate
1. To open the OSD menu, press Menu key on the control panel or remote control.
2. Use arrow keys to navigate through the menus and select appropriate settings.
3. Press Enter to enter the submenu or confirm a setting.
4. Press Exit to return to the previous menu or exit OSD menu if at top level.
Image 4-1
1 Main menu 2 Sub-menus 3 Settings
R5910888 /00 G6026
Page 27

4.2 Picture Menu

Overview
User controls
Image 4-2
Display Mode
Set the display mode to optimize the image performances for different display content.
Bright : Best for high brightness applications.
Presentation : Best for presentations when connected to a PC.
Movie : Best for playing videos.
sRGB : Best for high definition televisions.
Blending : Best for multiple projector applications.
DICOM SIM : Best for projecting monochrome medical images, such as X-ray diagram.
User : The mode for the image settings saved by the user.
Wall Color
Set the wall color of the projector to achieve best color perfomance for a specific wall. The available options are White and Gray 130.
Brightness
Adjust the luminous brightness of the projected image.
Contrast
Adjust the contrast of the projected image.
Sharpness
Adjust the clarity of detail in the projected image.
Color
Transform a video image from black and white to fully saturated color.
R5910888 /00 G60 27
Page 28
User controls
Tint
Adjust the color balance of red and green in video images.
Gamma
Select appropriate gamma value to optimize the image conformance to different applications.
Video : Best for video or TV sources.
Film : Best for home theater applications.
Bright : Best for emphasizing brightness.
CRT : Best for CRT monitors.
DICOM : Best for medical images, such as X-ray diagram.
White Peaking
Adjust the brightness of whites in the projected image, with 0 being the minimal level and 100 being the maximum.
Color Temperature
Adjust the color temperature of the projected image. The available options are Warm, Normal, and Cool.
Color Wheel Speed
The speed of the phosphor color wheel determines the image performance and the service life of the projector.
2x : Extends the projector’s service life and reduces the npise level during operation.
3x : Increases the speed to eliminate the color artifacts for best image quality.
HSG Adjustment
HSG adjustment uses hue, saturation, and gain (HSG) to adjust the images primary colors-red, green, blue, cyan, magenta, and yellow. It helps calibrate the projected image to achieve better color conformance to the surroundings, in consideration of factors such as screen size, ambient lighting, and multiple projector applications.
Image 4-3
Primary colors : Select the primary color for further adjustment.
Hue : Adjust the hue of the selected color. The value reflect the number of degrees of rotation around the
chromaticity diagram from the original color. Increasing value indicates clockwise rotation, and decreasing value, counterclockwise rotation.
R5910888 /00 G6028
Page 29
User controls
Image 4-4
Saturation : Adjust the saturation of the selected color. The value indicates the color shifts from or towards
the white in the center of the chromaticity diagram.
Gain : Adjust the gain of the selected color. Increase the value to brighten the image (add white to a color)
or decrease the value to darken the image (add black to a color).
Reset to Default : Reset the color settings to factory default values.
Contrast Enhancement
Optimize the contrast ratio for different input sources.
Off : Disable the contrast enhancement.
Dynamic Black : Automatically adjust the contrast ratio for video sources.
Extreme Black : Automatically increase the contrast ratio for blank (black) images.
Color Space
Select a color space that has been specifically tuned for the input signal. Use only for analog signals and certain digital sources. The available options are Auto, RGB (0-255), RGB (16-235), and YUV.
Save to User
Save the user settings.
R5910888 /00 G60 29
Page 30
User controls

4.3 Screen Menu

Overview
Image 4-5
Aspect Ratio
Set the aspect ratio of the projected image. The available options are Auto, 4:3, 16:9, 16:10. Select Auto to display the detected image size.
Pixel Phase
Adjust the phase of the pixel-sampling clock relative to the input signal. It help to improve the quality of the image shows shimmer or noise after being optimized with pixel tracking. This function applies to analog RGB signals only.
Pixel Track
Flickering or vertical stripes across the image indicates poor pixel tracking. Adjust the pixel track to optimize the image quality across the screen. This function applies to analog RGB signals only.
Horz Position
Adjust the horizontal position of the display area within the lens offset range.
Vert Position
Adjust the vertical position of the display area within the lens offset range.
Digital Horz Zoom
Change the horizontal size of the projected area. After re-sizing the image with this function, use Digital Horz Shift and Digital Vert Shift to move the image.
Digital Vert Zoom
Change the vertical size of the projected area. After re-sizing the image with this function, use Digital Horz Shift and Digital Vert Shift to move the image.
R5910888 /00 G6030
Page 31
User controls
Digital Horz Shift
Adjust the horizontal position of the display area if it is resized through Digital Horz Zoom setting.
Digital Vert Shift
Adjust the vertical position of the display area if it is resized through Digital Vert Zoom setting.
Ceiling Mount
Flips the image upside down to project from a ceiling mount.
Rear Projection
Reverse the image to project behind a translucent screen.
Geometric Correction
Configure the geometric settings to reshape the image for different projection surface.
Image 4-6
H. Keystone : Adjust the left and right side of the projected image to make it an even rectangle. It is used
for the images with unequal left and right sides.
Image 4-7
V. Keystone : Adjust the top and bottom side of the projected image to make it an even rectangle. It is
used for the images with unequal top and bottom sides.
Image 4-8
4 - corner : Position the 4 corners of the image to have it fit a specific projection surface.
R5910888 /00 G60 31
Page 32
B C
D
E
A
H
FG
PPP
PPP
User controls
Image 4-9
Grid Color : Set the grid color for 4-corner adjustment. The available options are purple or green.
Reset : Reset geometric settings to factory default values.
PC Mode : Enable PC mode to use PC software for more complicated geometric configuration.
PIP/PBP
PIP/PBP (picture in picture/picture by picture) mode allows displaying two images from two independent sources. For more information on the PIP/PBP compatibility, See Compatibility modes, page 49.
Image 4-10
PIP/PBP Enable : Select the appropriate PIP/PBP mode.
- Off : Disable PIP/PBP mode.
- PBP : Display two input sources simultaneously on the left and right sides of the screen.
- PIP : Display one input source on the main screen and the other input source in an inset window.
Main Source : Select an input source for the main image.
Sub Source : Select an input source for the second image.
Layout : Adjust the layout of two images. In the layout chart below, the “P” indicates the main image:
PIP Size
PIP Layout
Small Medium
Large
PIP, Bottom Right
PIP, Bottom Left
R5910888 /00 G6032
Page 33
PPP
PPP
P
P
User controls
PIP Layout
Small Medium
PIP, Top Left
PIP, Top Right
PBP Layout
PBP, Main Left
Size : Change the display size of the sub source in PIP mode.
Swap : Swap the main source and sub source.
Source Key
Configure the source settings.
Change Sources : Change the input source.
List All Sources : List all input sources.
Auto Source : Automatically detect and select input source.
PIP Size
Large
PBP, Main Right
Auto Image
Select the the timing detection mode to support input signal with marginal quality. After the selection, the projector will reacquire and lock the signal.
Normal : Best for 4:3 input source.
Wide : Best for 16:9 input source and most 4:3 input source.
Source Info
Display the information of the current input source.
R5910888 /00 G60 33
Page 34
User controls

4.4 Settings Menu

Overview
Image 4-11
Language
Select the language of the OSD menu. The available languages are English, Simplified Chinese, French, German, Italian, Japanese, Korean, Russian, Spanish, Portuguese, Indonesian, Dutch.
Menu Location
Adjust the location of the OSD menu. The available languages are Left Top, Right Top, Center, Left Bottom and Right Bottom.
Standby Power Mode
Select the power mode for the projector in standby status.
Standby Mode : Minimum power consumption (0,5 Watt) which does not allow controlling the projector
over the network.
Network Standby Mode : Low power consumption (< 2W) which allows the LAN module to enter sleep
mode and supports to be woken by Wake on LAN (WoL). When the LAN module is woken by WoL, the projector is ready to receive commands over the network.
Communication Mode : More power consumption that allows controlling the projector over the network.
Test Pattern
Select a test pattern. The available options are None, Grid, White, Black, Checkerboard, and Color Bars.
Direct Power On
Turn on this function to have the projector automatically turning on when connected to AC power.
Source in Power On
Turn on this function to have the projector automatically turning on when connected to HDMI input sources. It only applies to the standby projector set to Communication Mode.
R5910888 /00 G6034
Page 35
User controls
Hot-Key Settings
Assign a specific function to the Hot Keybutton on the remote control. It allows you to use the function easily without going through the OSD menus. The available functions for Hot Keybutton are Blank Screen, Aspect Ratio, Freeze Screen, and Projector Info.
Reset to Default
Reset all settings to the factory default values.
Service
The service menu is only available to Barco qualified service technitians.

4.5 Light Source Menu

Overview
Image 4-12
Light Source Mode
Set up the light source mode depending on the installations.
Constant Power : Enable the Constant Power to meet different installation requirements.
Constant Intensity : Select to maintain the current constant brightness and color settings. It is used after
the Constant Power is enabled.
ECO : Set the projector to 50% constant brightness and color settings.
Constant Power
Select a value for the laser diode power. The value ranges from 0 to 99, which covers the power level from 30% to 100%. The power level can be managed to obtain the brightest image or longest service life.
Light Source Info
Display the total used hours of the laser diode and information on light sensor calibration
R5910888 /00 G60 35
Page 36
User controls

4.6 Options Menu

Overview
Image 4-13
Background Color
Select the background color when no signal is detected. The available options are Logo, Blue, Black, and White.
Auto Shutdown
Set a time value for the projector to automatically turn off if no signal is detected within the specified time period.
Sleep Timer
Set a time value for the projector to automatically turn off after operating for the specified amount of time.
Lens Function
Configure the lens settings.
R5910888 /00 G6036
Page 37
User controls
Image 4-14
Focus : Use up and down arrow keys to adjust the focus of the projected image.
Zoom : Use up or down arrow keys to zoom in ir zoom out of the projected image.
Lens Shift : Use arrow keys to adjust the lens position to shift the projected area.
Lens Memory : Save or apply the current lens position. The projector can save up to five records.
Lens Lock : Lock the lens to prevent the lens motors from moving.
Lens Calibration : Calibrate the lens to return it to the center position.
High Altitude
When the projector is operated at the altitude over 5,000ft (1,500m), enable this funtion to have the projector fans operating at high speed to ensure proper air circulation.
PIN
Set a PIN number to protect the projector.
PIN Protect : Enable PIN Protect to protect the project. A PIN number is required once this function is
enabled. (Default: 12345)
Change PIN : Change the PIN number.
Remote Settings
Set up the remote receiver to control the communication between the projector and the remote control.
Top : Enable or disable the top remote receiver.
Front : Enable or disable the front remote receiver.
HDBaseT : Select On to set the HDBaseT terminal as the remote receiver.
Projector Address : Set a specific number for the projector as its address. The projector will only
responds to the remote control set with the same address.
Show Messages
Turning on or off the on screen messages showing the projector status information, such as input source, IP address, and gamma.
LED Settings
Configure the status LED indicators to help identify the projector status. The definitions of the status LED are discussed in the chapter LED indication chart, page 42.
Keypad LED : Turn on or off the keypad backlight.
Status LED : Turn on or off the status LED indicators, or select Warning/Errors Only to enable the
indicators for warning and error only.
Information
Display the projector information, such as model name, firmware version, and main input.
R5910888 /00 G60 37
Page 38
User controls

4.7 3D Menu

Overview
Image 4-15
3D
Enable the 3D function.
Auto : The projector automatically enables 3D function when receiving the 3D input in 1.4a format.
On : Turn on the 3D function manually.
3D Invert
3D video files and images combine two slightly different images (frames) of the same scene representing the different views that the left and right eyes see. When these frames are displayed fast enough and viewed with 3D glasses synchronized with the left and right frames, the viewers brain then assemble the separate images into a single 3D image. When the 3D image does not appear correctly, invert the sequence of the left and right frames.
3D Format
Select a proper 3D format for the 3D input signal. The available options are Frame Packing, Side-by-Side (Half), Top and Bottom, and Frame Sequential.
3D Sync Out
Set up the transmission of the 3D sync output signal.
To Emitter : Send the 3D sync output signal to the emitter connected to the projector’s 3D sync out port.
To Next Projector : For multiple projector applications, send the 3D sync output signal to next projector.
Frame Delay
Set a frame delay value for the projector to correct the time difference between the 3D signal being given and the result being executed. This function works only when L/R Reference is set to Field GPIO.
When performing 3D blending on multiple projectors, set the frame delay for each projector to correct the none synchronous images.
R5910888 /00 G6038
Page 39
User controls
L/R Reference
Select the reference for left and right (L/R) frames.
1ST Frame : When the projector generates 3D sync signal internally, select this option to set the first frame
of the input source as the projectors left reference. If the 3D image does not appear correctly, use 3D Invert function to swap the left and right frames.
Field GPIO : When the projector receives external 3D sync signal through a 3D sync in cable, select this
option to have the projectors L/R reference synchronizing with the 3D sync signal from the 3D sync in cable.
DLP Link
Enable or disable the DLP Link function according to how the 3D sync signal is processed.
On : Turn on DLP Link when the 3D sync signal is generated by the DLP Link technology built-in the
projector. DLP Link works only with the glasses that are compatible with DLP 3D technology and the 3D function is enabled.
Off : Turn off DLP Link when the 3D sync out signal is sent to an emitter or another projector through the
3D sync out port.

4.8 Communications Menu

Overview
Image 4-16
LAN
Configure the LAN settings for network communications.
DHCP : Turn on DHCP to automatically acquire IP address, subnet mask, gateway, and DNS. If it is turned
off, manually enter the values for the network.
IP Address : Set the projector’s IP address.
Subnet Mask : Set the projector’s subnet mask.
Default Gateway : Set the projector’s gateway.
MAC Address : Display the MAC address.
Apply : Apply the network settings.
R5910888 /00 G60 39
Page 40
User controls
Network
View and configure the projectors network settings.
Projector Name : Display the projector name.
Show Network Messages : Select On to display network information as on screen messages.
Network Factory Reset : Reset the network settings to factory default settings.
Serial Port Baud Rate
Select a serial port and baud rate. The available options include 1200, 2400, 4800, 9600, 14400, 19200, 38400, 57600, and 115200.
Serial Port Echo
When set to On, the projector will return the serial command it receives. The user can view the command that has been sent to the projector.
Serial Port Path
Select the serial port path for the serial commands. The available options are RS232 or HDBaseT.
R5910888 /00 G6040
Page 41

Troubleshooting 5

If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local re-seller or service center.
Overview
LED indication chart
Projector Problems
R5910888 /00 G60
41
Page 42
1 2 3
Troubleshooting

5.1 LED indication chart

Overview
Image 5-1
1 Light LED 2 Status LED 3 AV Mute LED
Explanation
Message
Green
Standby State
Power on (Warm up)
Power on & Laser diode on
AV mute is off (Image is displayed)
AV mute is on (Image is black)
Projector communication
Firmware upgrade Flash-
Laser diode time has expired
Steady Steady Steady
Steady Steady Steady
Steady Steady Steady
Steady Flash-
Light LED
Orange
Steady
Red Green
ing
ing
Status LED AV Mute LED
Orange
Flash-
ing
Flash-
ing
Red Green
Steady
Orange
Unit loses over 60% initial luminance
Error (Over temperature)
Error (Fan failure)
Power key of the keypad is in steady red light when the projector enters standby mode.
R5910888 /00 G6042
Steady
Flash-
ing
Page 43
Troubleshooting

5.2 Projector Problems

No image appears on-screen
Check if all the cables and the AC power are correctly connected. For more details, refer to the installation
manual.
Check if the pins of the connectors are not crooked or broken.
Check if the “Shutter (AV Mute)” function is disabled.
Partial, scrolling or incorrectly displayed image
Press “Auto” on the remote control to detect input signal automatically.
If you are using a PC, set the PC’s resolution lower or equal to WUXGA (1920 × 1200).
If you are using a Notebook:
- Set the resolution lower or equal to WUXGA (1920 × 1200).
- Press the appropriate keys listed below for your notebook manufacturer to send signal out from
notebook to projector. Example: [Fn]+[F4]
Acer [Fn]+[F5]
Asus [Fn]+[F8]
Dell [Fn]+[F8]
Gateway [Fn]+[F4]
BM/Lenovo [Fn]+[F7]
HP/Compaq [Fn]+[F4]
NEC [Fn]+[F3]
Toshiba Fn]+[F5]
Mac Apple System Preference > Display > Arrangement > Mirror display
If you experience difficulty changing resolutions or your monitor freezes, restart all equipments including
the projector.
Image is flickering and shimmering
Adjust the pixel phase and pixel track of the projector. See “Pixel Phase“ and “Pixel Track“ in chapter
Screen Menu, page 30.
Image is fuzzy and blurry
Press the “Focus ▲” or “Focus ▼” button on the remote control or control panel to adjust the image focus
until it is sharp and clear. To adjust focus from OSD menu, select Options > Lens function > Focus“.
Make sure the projection screen is in proper distance with the projector. For projection distances of each
lens, see chapter installation manual.
Stretched when displaying 16:10 DVD videos
Set appropriate aspect ratio for the projector by selecting “Screen > Aspect Ratio“ from the OSD menu.
Set the aspect ratio to 16:10 on the DVD player.
Image is too small or too large
Adjust the image size by pressing the “Zoom ▲” or “Zoom ▼” button on the remote control or control panel,
or selecting Options > Lens function > Zoomfrom the OSD menu.
Adjust the distance between the projector and the screen.
Adjust the aspect ratio by selecting “Screen > Aspect Ratio“ from the OSD menu.
R5910888 /00 G60 43
Page 44
Troubleshooting
Image is not an even rectangle
Perform keystone correction by pressing the “Keystone H“ and “Keystone V“ button on the remote control,
or using Screen > Geometric Correction > V. Keystone or H. Keystonefrom the OSD menu.
Image is reversed
To reverse the image, enable rear projection by selecting “Screen > Rear Projection > On” from the OSD
menu.
The projector stops responding to all controls
If possible, turn off the projector, then unplug the power cord and wait at least 60 seconds before
reconnecting power.
If the remote control does not work
Check if the operating angle of the remote control is pointed within ±30° (front and back) to the remote
receivers on the projector. Make sure there are any obstructions between the remote control and the projector.
Check the remote batteries. Make sure batteries are inserted correctly. Replace the batteries if they are
used up.
Ensure you have set the correct IR code to the remote control. See “Remote Settings“ in the chapter
Options Menu, page 36.
R5910888 /00 G6044
Page 45
Specifications A
Overview
Product specification of the G60-W7
Product specification of the G60-W8
Product specification of the G60-W10
Compatibility modes
Dimensions of the G60
Ceiling mount
R5910888 /00 G60
45
Page 46
Specifications

A.1 Product specification of the G60-W7

Specifictions
Projector type Single chip DLP laser phosphor projector
Resolution 1,920 x 1,200 (WUXGA)
Brightness 7,000 center lumens
Contrast ratio 1,200:1 sequential; 6,000:1 dynamic; Extreme black: 100,000:1
Brightness uniformity 85%
Aspect ratio 16:10
Lens type G-lenses - 0.36:1 / 0.75-0.95:1 / 0.95-1.22:1 / 1.22-1.52:1 / 1.52-2.92:1 /
2.90-5.50:1
Optical lens shift Up to 100% vertical lens shift, up to 30% horizontal lens shift. Motorized
zoom, focus, vertical and horizontal shift
Color correction Yes
CLO (constant light output) Yes
Light source Laser phosphor
Light source lifetime Up to 20,000hrs
Sealed DLPcore Yes
Orientation 360° rotation, no restrictions
3D Active stereoscopic 3D
Image processing Embedded warp & blend possible via Ptoolset
Keystone correction Yes
Inputs 2x HDMI 1.4 / DVI-D / HDBaseT / 3G-SDI / VGA (D-Sub 15 pin) / RJ 45
Ethernet / RS232 in
Input resolutions Up to 1,920 x 1,200 @ 60Hz
Software tools Projector Toolset
Control IR, RS232, RJ45, 3.5mm phone jack for wired remote
Network connection 10/100 Ethernet, RJ45
Power requirements 100-240V / 50-60Hz
Power consumption 520W nominal, 600W maximum
BTU per hour 1,780 BTU/h nominal; 2,050 BTU/h maximum
Standby power < 0.5W
Noise level (typical at 25°C/ 77°F)
Operating temperature 5 - 40 °C (sea level)
Storage temperature -10 to 60 °C
Operating humidity 10 - 85% RH, non-condensing
Storage humidity 5 - 90% RH, non-condensing
Dimensions (WxLxH) without feet: 484 x 529 x 195 mm / 19.06 x 20.83 x 7.68 in
R5910888 /00 G6046
36dB(A) - 40dB(A) depending on the used mode
Page 47
Specifications
Weight without lens: 16.9 kg / 37.3 lbs
Standard accessories Power cord, wireless remote control
Certifications CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI
Warranty Limited 3 years parts and labor

A.2 Product specification of the G60-W8

Specifictions
Projector type Single chip DLP laser phosphor projector
Resolution 1,920 x 1,200 (WUXGA)
Brightness 8,000 center lumens
Contrast ratio 1,200:1 sequential; 6,000:1 dynamic; Extreme black: 100,000:1
Brightness uniformity 85%
Aspect ratio 16:10
Lens type G-lenses - 0.36:1 / 0.75-0.95:1 / 0.95-1.22:1 / 1.22-1.52:1 / 1.52-2.92:1 /
2.90-5.50:1
Optical lens shift Up to 100% vertical lens shift, up to 30% horizontal lens shift. Motorized
zoom, focus, vertical and horizontal shift
Color correction Yes
CLO (constant light output) Yes
Light source Laser phosphor
Light source lifetime Up to 20,000hrs
Sealed DLPcore Yes
Orientation 360° rotation, no restrictions
3D Active stereoscopic 3D
Image processing Embedded warp & blend possible via Ptoolset
Keystone correction Yes
Inputs 2x HDMI 1.4 / DVI-D / HDBaseT / 3G-SDI / VGA (D-Sub 15 pin) / RJ 45
Ethernet / RS232 in
Input resolutions Up to 1,920 x 1,200 @ 60Hz
Software tools Projector Toolset
Control IR, RS232, RJ45, 3.5mm phone jack for wired remote
Network connection 10/100 Ethernet, RJ45
Power requirements 100-240V / 50-60Hz
Power consumption 635W nominal, 730W maximum
BTU per hour 2,170 BTU/h nominal; 2,500 BTU/h maximum
Standby power < 0.5W
Noise level (typical at 25°C/ 77°F)
36dB(A) - 40dB(A) depending on the used mode
R5910888 /00 G60 47
Page 48
Specifications
Operating temperature 5 - 40 °C (sea level)
Storage temperature -10 to 60 °C
Operating humidity 10 - 85% RH, non-condensing
Storage humidity 5 - 90% RH, non-condensing
Dimensions (WxLxH) without feet: 484 x 529 x 195 mm / 19.06 x 20.83 x 7.68 in
Weight without lens: 17.4 kg / 38.4 lbs
Standard accessories Power cord, wireless remote control
Certifications CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI
Warranty Limited 3 years parts and labor

A.3 Product specification of the G60-W10

Specifictions
Projector type Single chip DLP laser phosphor projector
Resolution 1,920 x 1,200 (WUXGA)
Brightness 10,000 center lumens
Contrast ratio 1,200:1 sequential; 6,000:1 dynamic; Extreme black: 100,000:1
Brightness uniformity 85%
Aspect ratio 16:10
Lens type G-lenses - 0.36:1 / 0.75-0.95:1 / 0.95-1.22:1 / 1.22-1.52:1 / 1.52-2.92:1 /
2.90-5.50:1
Optical lens shift Up to 100% vertical lens shift, up to 30% horizontal lens shift. Motorized
zoom, focus, vertical and horizontal shift
Color correction Yes
CLO (constant light output) Yes
Light source Laser phosphor
Light source lifetime Up to 20,000hrs
Sealed DLPcore Yes
Orientation 360° rotation, no restrictions
3D Active stereoscopic 3D
Image processing Embedded warp & blend possible via Ptoolset
Keystone correction Yes
Inputs 2x HDMI 1.4 / DVI-D / HDBaseT / 3G-SDI / VGA (D-Sub 15 pin) / RJ 45
Ethernet / RS232 in
Input resolutions Up to 1,920 x 1,200 @ 60Hz
Software tools Projector Toolset
Control IR, RS232, RJ45, 3.5mm phone jack for wired remote
Network connection 10/100 Ethernet, RJ45
R5910888 /00 G6048
Page 49
Power requirements 100-240V / 50-60Hz
Power consumption 935W nominal, 1080W maximum
BTU per hour 3,190 BTU/h nominal; 3,690 BTU/h maximum
Standby power < 0.5W
Specifications
Noise level (typical at 25°C/ 77°F)
Operating temperature 5 - 40 °C (sea level)
Storage temperature -10 to 60 °C
Operating humidity 10 - 85% RH, non-condensing
Storage humidity 5 - 90% RH, non-condensing
Dimensions (WxLxH) without feet: 484 x 529 x 195 mm / 19.06 x 20.83 x 7.68 in
Weight without lens: 22.7 kg / 50.1 lbs
Standard accessories Power cord, wireless remote control
Certifications CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI
Warranty Limited 3 years parts and labor
36dB(A) - 40dB(A) depending on the used mode

A.4 Compatibility modes

Timing table
Signal type
PC 640x350 85 V V V
Resolution
640x400 85 V V V V 640x480 59 V V V 640x480 60 V V V V 640x480 72 V V V V 640x480 75 V V V V 640x480 85 V V V V 720x400 60 V V V V 720x400 85 V 768x480 60 V V V 768x480 75 V V V 768x480 85 V V V 800x600 50 V V V 800x600 56 V V V V 800x600 60 V V V V 800x600 72 V V V V 800x600 75 V V V V 800x600 85 V V V V 848x480 50 V V V 848x480 60 V V V 848x480 75 V V V 848x480 85 V V V 960x600 50 V V V 960x600 60 V V V 960x600 75 V V V
Frame rate
(Hz)
VGA HDMI1/2
DVI
HDBa-
seT
3G-SDI
R5910888 /00 G60 49
Page 50
Specifications
Signal type
Resolution
Frame rate
(Hz)
VGA HDMI1/2 DVI
HDBa-
seT
960x600 85 V V V 1024x768 60 V V V V 1024x768 75 V V V V 1024x768 85 V V V V 1024x768 120 V V V V 1064x600 50 V V V 1064x600 60 V V V 1064x600 75 V V V 1064x600 85 V V V
1152x720 50 V V V 1152x720 60 V V V 1152x720 75 V V V 1152x720 85 V V V 1152x864 60 V V V V 1152x864 70 V V V V 1152x864 75 V V V V
1152x864 85 V V V V 1224x768 50 V V V 1224x768 60 V V V 1224x768 85 V V V 1280x720 50 V V V 1280x720 60 V V V V 1280x720 75 V V V V 1280x720 85 V V V V 1280x720 120 V V V 1280x768 60 V V V V 1280x768 75 V V V V 1280x768 85 V V V V 1280x800 50 V V V V 1280x800 60 V V V V 1280x800 75 V V V V 1280x800 85 V V V V 1280x960 50 V V V 1280x960 60 V V V V 1280x960 75 V V V V 1280x960 85 V V V V
1280x1024 50 V V V 1280x1024 60 V V V V 1280x1024 75 V V V V 1280x1024 85 V V V V
1360x768 50 V V V 1360x768 60 V V V 1360x768 75 V V V 1360x768 85 V V V 1366x768 60 V V V V 1400x900 60 V V
1400x1050 50 V V V 1400x1050 60 V V V V 1400x1050 75 V V V V
1440x900 60 V V V V 1440x900 75 V V V 1600x900 60 V V V
3G-SDI
R5910888 /00 G6050
Page 51
Specifications
Signal type
Resolution
Frame rate
(Hz)
VGA HDMI1/2 DVI
HDBa-
seT
1600x1200 50 V V V 1600x1200 60 V V V V 1680x1050 50 V V V 1680x1050 60 V V V V
1704x960 50 V V V 1704x960 60 V V V
1728x1080 50 V V V 1728x1080 60 V V V 1864x1050 50 V V V
1864x1050 60 V V V 1920X1080 50 V V V 1920X1080 60 V V V V
1920X1200RB 60 V V V V 1920X1200RB 50 V V V V
SDTV 480i 60 V V V V
576i 50 V V V V
EDTV 480p 60 V V V V
576p 50 V V V V
HDTV 1080i 25 V V V V
1080i 29 V V V V 1080i 30 V V V V
720p 50 V V V V
720p 59 V V V V
720p 60 V V V V
1080s 23 V 1080s 24 V 1080p 23 V V V V
1080p 24 V V V V
1080p 25 V V V V
1080p 29 V V V V
1080p 30 V V V V
1080p 50 V V V V
1080p 59 V V V V
1080p 60 V V V V
Mandatory3DFrame Packing 1080p 24 V V V
Frame Packing 720p 50 V V V
60 V V V
Side by Side 1080i 50 V V V
60 V V V
Top and Bottom 720p 50 V V V
60 V V V
Top and Bottom 1080p 24 V V V
Frame
Sequential
1024x768 120 V V V 1280x720 120 V V V
SD-SDI 480i YcbCr422 10bit 59.94 V
576i YcbCr422 10bit 50 V
HD-SDI 720p Ycb-Cr422 10bit 50 V
720p Ycb-Cr422 10bit 59.94 V
720p Ycb-Cr422 10bit 60 V
1080i Ycb-Cr422 10bit 50 V
3G-SDI
R5910888 /00 G60 51
Page 52
Specifications
Signal type
3GA-SDI 1080p Ycb-Cr422
3GB-SDI 1080p Ycb-Cr422
Resolution
1080i Ycb-Cr422 10bit 59.94 V 1080i Ycb-Cr422 10bit 60 V
1080p Ycb-Cr422
10bit
1080p Ycb-Cr422
10bit
1080p Ycb-Cr422
10bit
1080p Ycb-Cr422
10bit
1080p Ycb-Cr422
10bit
1080sF Ycb-Cr422
10bit
1080sF Ycb-Cr422
10bit
1080sF Ycb-Cr422
10bit
10bit
10bit
With 352M Payload ID
Frame rate
(Hz)
23.98 V
24 V
25 V
29.97 V
30 V
25 V
29.97 V
30 V
50 V
59.94 V 60 V 50 V
59.94 V 60 V
VGA HDMI1/2 DVI
HDBa-
seT
3G-SDI
PIP/PBP Compatibility
PIP/PBP
Matrix
VGA V V V V V
DVI-D V V V V V
HDMI-1 V V V V V
HDMI-2 V V V V V
3G-SDI V V V V V
HDBaseT V V V V V
PIP/PBP does not support 3D input.
VGA DVI-D HDMI-1 HDMI-2 3G-SDI HDBaseT

A.5 Dimensions of the G60

CAUTION: Avoid installing the projector near a heat source.
R5910888 /00 G6052
Page 53
Front view
242.0
111.3
73.6
195.0
184.3
206.3
484.0
529.0
509.0
Image A-1: Dimensions given in millimeters.
Rear view
Specifications
Image A-2: Dimensions given in millimeters.
Top view
Image A-3: Dimensions given in millimeters.
R5910888 /00 G60 53
Page 54
280.0
140.0
100.0
100.0
310.0
310.0
99.0
99.0
280.0
4 - M6 x1.0P L10
Specifications

A.6 Ceiling mount

About ceiling mount
CAUTION: Be sure to use the correct screw size. Screw Length will vary depending on the
thickness of the mounting plate.
CAUTION: Be sure to keep at least 30 mm gap between the ceiling and the bottom of the projector.
Projector mounting holes
Image A-4: Dimensions given in millimeters.
R5910888 /00 G6054
Page 55
Environmental information
Overview
China RoHS compliance
Taiwan RoHS compliance
Turkey RoHS compliance
Disposal information
Production address
Contact information
Download Product Manual
B
R5910888 /00 G60
55
Page 56
10
Environmental information

B.1 China RoHS compliance

中国大陆 RoHS (Information for China ROHS compliance)
根据中国大陆《电器电子产品有害物质限制使用管理办法》(也称为中国大陆RoHS), 以下部分列出了 Barco产品中可能包含的有毒和/或有害物质的名称和含量。中国大陆RoHS指令包含在中国信息产业部MCV标 准:“电子信息产品中有毒物质的限量要求”中。
According to the Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products(Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barcos product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section Limit Requirements of toxic substances in Electronic Information Products.
零件项目(名称) Component name
外壳
Shell
主板
Motherboard
引擎模块
Engine module
雷射光源模组
Laser light source module
风扇
Fan
铁件
Iron frame
线材
Wire
遥控器
Remote control
包装
Package
有毒有害物质或元素
Hazardous substances and elements
(Pb)
X O X O O O
X O O O O O
X O O O O O
X O O O O O
X O O O O O
X O O O O O
X O X O O O
X O O O O O
O O O O O O
(Hg)
(Cd)
六价铬
(Cr6+)
多溴联苯
(PBB)
多溴二苯 醚
(PBDE)
本表格依据SJ/T 11364的规定编制 This table is prepared in accordance with the provisions of SJ/T 11364. O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 GB/T 26572 标准规定的限量要求以下. O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this
part is below the limit requirement in GB/T 26572. X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 标准规定的限量要求. X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials
used for this part is above the limit requirement in GB/T 26572.
在中国大陆销售的相应电子信息产品(EIP)都必须遵照中国大陆《电子电气产品有害物质 限制使用标识要求》标准贴上环保使用期限(EFUP)标签。Barco产品所采用的EFUP标签 (请参阅实例,徽标内部的编号使用于指定产品)基于中国大陆的《电子信息产品环保使用 期限通则》标准。
R5910888 /00 G6056
Page 57
Environmental information
All Electronic Information Products (EIP) that are sold within Chinese Mainland must comply with the Marking for the restriction of the use of hazardous substances in electrical and electronic productof Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the General guidelines of environment-friendly use period of electronic information productsof Chinese Mainland.

B.2 Taiwan RoHS compliance

限用物質含有情況標示聲明書 (Declaration of the Presence Condition of the Restricted Substances Marking)
限用物質及其化學符號
Restricted substances and its chemical symbols
單元
Unit
塑膠外殼
Plastic shell
電源供應器
Power supply
印刷電路板
Printed circuit board
絕緣墊片
Insulating gasket
光學鏡片
Optical lenses
雷射模組
Laser module
風扇模組
Fan module
鐵件
Iron frame
線材
wire (interlock switch/power cord)
Lead
(Pb)
O O O O O
O O O O O
O O O O O
O O O O O O
O O O O O
O O O O O
O O O O O
O O O O
Mercu-
ry
(Hg)
O O O O O
Cadmi-
um
(Cd)
六價鉻
Hexava-
lent
chromi-
um
(Cr6+)
多溴聯苯
Polybromi-
nated
biphenyls
(PBB)
多溴二苯醚
Polybromi-
diphenyl
nated
ethers
(PBDE)
喇叭
Speaker
馬達
Motor
自復式保險絲
Resettable fuse (polyswitch)
O O O O O
O O O O O
O O O O O O
R5910888 /00 G60 57
Page 58
Environmental information
限用物質及其化學符號
Restricted substances and its chemical symbols
單元
Unit
配件(如:遙控器等) Accessories (remote control, etc.)
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值。 Note 1:“Exceeding 0.1 wt %and exceeding 0.01 wt %indicate that the percentage content of the
restricted substance exceeds the reference percentage value of presence condition. 備考2.〝〇〞係指該項限用物質之百分比含量未超出百分比含量基準值。 Note 2:“〇” indicates that the percentage content of the restricted substance does not exceed the
percentage of reference value of presence. 備考3.〝—〞係指該項限用物質為排除項目。 Note 3The “—” indicates that the restricted substance corresponds to the exemption.
備註: RoHS表格適用於以下產品型號: G60-W7, G60-W8, G60-W10
Hint: This RoHS table is suitable for following models: G60-W7, G60-W8, G60-W10
Lead
(Pb)
O O O O O
Mercu-
ry
(Hg)
Cadmi-
um
(Cd)
六價鉻
Hexava-
lent
chromi-
um
(Cr6+)
多溴聯苯
Polybromi-
nated
biphenyls
(PBB)
多溴二苯醚
Polybromi-

B.3 Turkey RoHS compliance

nated
diphenyl
ethers
(PBDE)
Turkey RoHS compliance
Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur.
[Republic of Turkey: In conformity with the WEEE Regulation]

B.4 Disposal information

Disposal Information
Waste Electrical and Electronic Equipment
This symbol on the product indicates that, under the European Directive 2012/19/EU governing waste from electrical and electronic equipment, this product must not be disposed of with other municipal waste. Please dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
For more information about recycling of this product, please contact your local city office or your municipal waste disposal service.
For details, please visit the Barco website at: http://www.barco.com/AboutBarco/weee
R5910888 /00 G6058
Page 59
Environmental information
Disposal of batteries in the product
This product contains batteries covered by the Directive 2006/66/EC which must be collected and
disposed of separately from municipal waste.
If the battery contains more than the specified values of lead (Pb), mercury (Hg) or cadmium (Cd), these chemical symbols will appear below the crossed-out wheeled bin symbol.
By participating in separate collection of batteries, you will help to ensure proper disposal and to prevent potential negative effects on the environment and human health.

B.5 Production address

Producer
Barco NV (BELGIUM) Entertainment Division
Beneluxpark 21, 8500 Kortrijk, Belgium
Made in information
The made in country is indicated on the product ID label on the product itself.
Production date
The month and year of production is indicated on the product ID label on the product itself.

B.6 Contact information

Barco contact information
Registered office address: President Kennedypark 35, 8500 Kortrijk, Belgium
Contact address: Beneluxpark 21, 8500 Kortrijk, Belgium
Importers contact information
To find your local importer, contact Barco directly or one of Barco's regional offices via the contact information given on Barco's web site, www.barco.com.

B.7 Download Product Manual

Download Product Manual
Product manuals and documentation are available online at www.barco.com/td.
Registration may be required; follow the instructions given on the website.
IMPORTANT! Read Installation Instructions before connecting equipment to the mains power supply.
R5910888 /00 G60 59
Page 60
Environmental information
R5910888 /00 G6060
Page 61
Index
Numbers/Symbols
3D Menu 38
A
Address 59
C
Ceiling mount
Holes 54 Communications Menu 39 Compatibility modes 49 Control panel 18
D
Dimensions 52 Download
Product manual 59
E
Electrical shock 10 Environmental information 55
Disposal information 58
RoHS compliance
China 56 Taiwan 57 Turkey 58
F
Fire hazard 11
G
General considerations
Safety 8
H
Hazardous Chemicals 13 HD for G60-W10
Safety 9
HD for G60-W8
Safety 9
I
Importer 59 Input/Output 17 Instructions
Safety 10
L
Labels
Safety 13 Safety G60-W10 14 Safety G60-W7 13 Safety G60-W8 14
Laser safety precautions G60-W10
Safety 9
Laser safety precautions G60-W7
Safety 8
Laser safety precautions G60-W8
Safety 8 LED Indication chart 42 Light Source Menu 35
M
Main unit 16
N
Notice on safety 8
O
On/Off 21 Options Menu 36 OSD 26
R5910888 /00 G60 1
Page 62
Index
P
Personal injury 11 Picture Menu 27 Power 21 Power Off 22 Power On 22 Product overview 15 Production 59 Projector damage 12 Projector Problems 43
R
RCU 19
S
Safety 7
Battery explosion 13 General considerations 8 Hazardous Chemicals 13 HD for G60-W10 9 HD for G60-W8 9 Instructions 10 Labels 13 Labels G60-W10 14 Labels G60-W7 13 Labels G60-W8 14 Laser safety precautions G60-W10 9 Laser safety precautions G60-W7 8 Laser safety precautions G60-W8 8 Prevent electrical shock 10 Prevent fire hazard 11 Prevent personal injury 11 Prevent projector damage 12 Safety Data Sheet (SDS) 13 Servicing 13
User definition 10 Safety Data Sheet (SDS) 13 Screen Menu 30 Settings Menu 34 Specifications 45
G60-W10 48
G60-W7 46
G60-W8 47
T
Troubleshooting 41
U
User controls 25 User definition
Safety 10
R5910888 /00 G602
Page 63
R5910888 /00 G60 3
Page 64
R5910888 /00 | 2019-01-31
Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered office: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium
www.barco.com
Loading...
