Barco Data 808s User Manual
PLEASE READ
We are in no way responsible for the
contents of the manual. We do not guarantee
its accuracy and we do not make any claim
of copyright. The copyright remains the
property of their respective owners.
Visit the site to read the latest projector
news and reviews, read and comment on
projector specifications, download user
manuals and much more.
DATA
808s
R9002031
R9002038
OWNER'S MANUAL
BARCO PROJECTION SYSTEMS
DATA
808s
R9002031
R9002038
OWNER'S MANUAL
Date :
170397
Art. No. :
R5975597
Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, March 1997.
All rights reserved.
Trademarks are the rights of their respective owners.
Printed in Belgium
BARCO nv/Projection Systems
Noordlaan 5
B-8520 Kuurne
Belgium
Printed in Belgium
Table of Contents
Table of contents ...........................................................................................................................................................................i
Safety instructions ..................................................................................................................................................................... 1-1
On safety.............................................................................................................................................................................1-1
On installation ..................................................................................................................................................................... 1-2
On servicing ........................................................................................................................................................................1-2
On cleaning .................................................................................................................... ..................................................... 1-2
On repacking ....................................................................................................................................................................... 1-2
On illumination.....................................................................................................................................................................1-2
Location and Functions of Control ...........................................................................................................................................2-1
Rear panel terminology........................................................................................................................................................2-1
Front panel terminology ........................................................................................................ ............................................... 2-1
Control panel terminology .................................................................................................................................................... 2-2
a. The Local Keypad............................................................................................................................................................2-2
b. RCU control panel terminology ........................................................................................................................................2-2
Connections ...............................................................................................................................................................................3-1
AC Power (mains) Cord Connection ....................................................................................................................................3-1
Power Check ....................................................................................................................................................................... 3-1
Switching On/Off .................................................................................................................................................................3-1
Signal Input Connection to the Projector : ............................................................................................................................ 3-2
Connecting a Composite Video source to port 1. .................................................................................................................3-3
Connecting a S-Video or Video source to port 2. ................................................................................................................. 3-3
Connecting a RGB Analog source to port 3. ........................................................................................................................ 3-4
Connecting a RGB Analog source to port 4/5.......................................................................................................................3-4
Connecting a RGB Analog source with Tri-level sync to port 4/5.(option) ............................................................................. 3-5
Connecting a Component Video source to port 4/5. ............................................................................................................. 3-5
Connecting a Component Video source with Tri-level sync to port 4/5.(Opion)......... . . . . .. . . . . . .. . . . . . .. . . . . . .. . . . . . .. . . . . . .. . ..................3-5
Peripheral equipment...........................................................................................................................................................3-6
Connecting a RCVDS 05 switcher to the BARCODATA 808S.............................................................................................. 3-6
Connecting a VS05 switcher to the BARCODATA 808S. .............................................................................. ....................... 3-6
Connecting an IR Remote Receiver to the BARCODATA 808S ...........................................................................................3-6
Controlling..................................................................................................................................................................................4-1
Battery installation in the RCU. ............................................................................................................................................4-1
How to use your RCU .......................................................................................................................................................... 4-2
Projector Address ................................................................................................................................................................ 4-2
How to display a projector address? .................................................................................................................................... 4-3
How to program an address into the RCU? .......................................................................................................................... 4-3
Input selection .....................................................................................................................................................................4-3
Analog Picture Controls ........................................................................................................ ............................................... 4-4
Controlling chained projectors. ............................................................................................................................................ 4-4
Start up of the Adjustment Mode ..............................................................................................................................................5-1
Adjustment Mode ................................................................................................................................................................5-1
Random Access Adjustment Mode ........................................................................................................................................... 6-1
Starting-Up the Random Access Adjustment mode..............................................................................................................6-1
Overview 'Random Access Adjustment' mode ..................................................................................................................... 6-1
Selecting Setup Pattern ....................................................................................................................................................... 6-3
Internal Cross Hatch Pattern................................................................................................................................................6-3
Random access adjustment mode selection menu. ............................................................................................................. 6-4
Picture Tuning ..................................................................................................................................................................... 6-4
Color Balance......................................................................................................................................................................6-4
Sync Fast/Slow Adjustment ...................................................................................................... ........................................... 6-5
Peaking ............................................................................................................................................................................... 6-5
Clamp Tuning ...................................................................................................................................................................... 6-5
Port 2 : Video or S-Video .....................................................................................................................................................6-6
Line Doubler ........................................................................................................................................................................ 6-6
Color Select.........................................................................................................................................................................6-6
Focusing .............................................................................................................................................................................6-7
Focusing color select...........................................................................................................................................................6-7
Blue on source ....................................................................................................................................................................6-7
Geometry Adjustments ........................................................................................................................................................6-8
Horizontal Phase Adjustment............................................................................................................................................... 6-8
Raster Shift Adjustment ....................................................................................................................................................... 6-9
Left-Right (east-west) Adjustments .................................................................................................................................... 6-10
Seagull correction.............................................................................................................................................................. 6-11
Left Side Correction........................................................................................................................................................... 6-11
Top-Bottom (north-south) Adjustments ........................................................................................... ................................... 6-12
Seagull Correction ............................................................................................................. ................................................ 6-13
Horizontal Size Adjustment..................................................................................................... ........................................... 6-13
Vertical Linearity Adjustment .................................................................................................. ........................................... 6-14
Vertical Size Adjustment....................................................................................................... ............................................. 6-14
5975597 BARCODATA 808S 110397
i-1
Table of Contents
Blanking Adjustments........................................................................................................................................................ 6-15
Convergence Adjustment .................................................................................................................................................. 6-16
Service mode ............................................................................................................................................................................. 7-1
Starting up the Service mode. ............................................................................................................................................. 7-1
Overview flowchart 'Service' mode. ..................................................................................................................................... 7-1
Identification........................................................................................................................................................................ 7-2
Copy a block ....................................................................................................................................................................... 7-2
Deletion of blocks............................................................................................................. ................................................... 7-3
Deleting block by block ....................................................................................................................................................... 7-3
Deletion of all blocks ........................................................................................................................................................... 7-3
Change password ............................................................................................................................................................... 7-4
Change Language............................................................................................................................................................... 7-4
Run time ............................................................................................................................................................................. 7-4
Set to midposition ............................................................................................................................................................... 7-5
Undo Midposition ................................................................................................................................................................ 7-5
Convergence Mid ................................................................................................................................................................ 7-5
Undo Convergence Mid(position) ........................................................................................................................................ 7-5
Dynamic Astigmatism (spot shape adjustment) .................................................................................... ............................... 7-6
G2 Adjust ............................................................................................................................................................................ 7-7
Gamma corrections ............................................................................................................................................................. 7-7
CRT run in cycle ................................................................................................................................................................. 7-7
Projector Warm Up.............................................................................................................................................................. 7-8
CRT Drive Mode ................................................................................................................................................................. 7-8
Messages, warnings and failures ............................................................................................................................................. 8-1
Options....................................................................................................................................................................................... 9-1
Appendix A : Orbiting ................................................................................................................................................................... A-1
Appendix B : Adjsutment Blocks and Source Numbers 90-99 ........................................................................ .............................. B-1
i-2 5975597 BARCODATA 808S 110397
Safety Instructions
1
SAFETY INSTRUCTIONS
Notice on Safety
This equipment is built in accordance with the requirements of the
international safety standards EN60950, UL 1950 and CSA C22.2
No.950, which are the safety standards of information technology
equipment including electrical business equipment.
These safety standards impose important requirements on the use of
safety critical components, materials and isolation, in order to protect
the user or operator against risk of electric shock and energy hazard,
and having access to live parts.
Safety standards also impose limits to the internal and external
temperature rises, radiation levels, mechanical stability and strength,
enclosure construction and protection against the risk of fire.
Simulated single fault condition testing ensures the safety of the
equipment to the user even when the equipment's normal operation
fails.
INSTALLATION INSTRUCTIONS
Before operating this equipment please read this manual
thoroughly, and retain it for future reference.
Installation and preliminary adjustments should be performed
by qualified BARCO personnel or by authorized BARCO
service dealers.
WARNING
TO PREVENT FIRE OR ELECTRICAL SHOCK
HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE
FEDERAL COMMUNICATION COMMISSION (FCC STATEMENT)
This equipment has been tested and found to comply with the limits
of a class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Note :
The use of shielded cables is required to comply within the limits of
Part 15 of FCC rules and EN55022.
* All the safety and operating instructions should be read before using
this unit.
* The safety and operating instructions manual should be retained for
future reference.
OWNER’S RECORD
The part number and serial number are located at the back side of the
projector. Record these numbers in the spaces provided below.
Refer to them whenever you call upon your BARCO dealer regarding
this product.
PART NUMBER :
SER. NUMBER :
DEALER :
The lightning flash with an arrowhead within a
triangle is intended to tell the user that parts
inside this product may cause a risk of electrical
shock to persons.
The exclamation point within a triangle is intended to tell the user that important operating
and/or servicing instructions are included in the
technical documentation for this equipment.
5975597 BARCODATA 808S 170397
* All warnings on the equipment and in the documentation manuals
should be adhered to.
* All instructions for operating and use of this equipment must be
followed precisely.
On safety
1. This product should be operated from an AC power source.
This projector may be connected to an IT-power system.
Operating AC power voltage of the projector:
BARCODATA 808S
Art.No. R9002031 (230V AC)
Art. No R9002038 (120V AC)
Consult your dealer to switch over from 230Vac to 120 Vac or from
120Vac to 230 Vac.
If you are not sure of the type of AC power available, consult your
dealer or local power company.
2. This product is equipped with a 3-wire grounding plug, a plug
having a third (grounding) pin. This plug will only fit into a groundingtype power outlet. This is a safety feature. If you are unable to insert
the plug into the outlet, contact your electrician to replace your
obsolete outlet. Do not defeat the purpose of the grounding-type
plug.
WARNING FOR THE CUSTOMERS: THIS APPARATUS MUST BE
GROUNDED (EARTHED) via the supplied 3 conductor AC power
cable.
(If the supplied power cable is not the correct one, consult your
dealer.)
1-1
Safety Instructions
A. Mains lead (Power cord) with CEE 7 plug:
The wires of the mains lead are colored in
accordance with the following code.
Green and yellow: earth (safety earth)
Blue: neutral
Brown: line (live)
B. Power cord with ANSI 73.11 plug:
The wires of the power cord are colored in
accordance with the following code.
Green/yellow: ground
White: neutral
Black: line (live)
3. Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
To disconnect the cord, pull it out by the plug. Never pull the cord
itself.
4. If an extension cord is used with this product, make sure that the
total of the ampere ratings on the products plugged into the extension
cord does not exceed the extension cord ampere rating. Also make
sure that the total of all products plugged into the wall outlet does not
exceed 15 amperes.
5. Never push objects of any kind into this product through cabinet
slots as they may touch dangerous voltage points or short out parts
that could result in a risk of fire or electrical shock.
Never spill liquid of any kind on the product. Should any liquid or solid
object fall into the cabinet, unplug the set and have it checked by
qualified service personnel before resuming operations.
6. Lightning - For added protection for this video product during a
lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will prevent
damage to the projector due to lightning and AC power-line surges.
On installation
1. Do not place this equipment on an unstable cart, stand, or table.
The product may fall, causing serious damage to it.
qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the equipment.
c.If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating
instructions are followed.
Note : Adjust only those controls that are covered by the operating
instructions since improper adjustment of the other controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating
a need for service.
Replacement parts - When replacement parts are required, be sure
the service technician has used original BARCO replacement parts or
authorized replacement parts which have the same characteristics as
the BARCO original part. Unauthorized substitutions may result in
degraded performance and reliability, fire, electric shock or other
hazards. Unauthorized substitutions may void warranty.
Safety check - Upon completion of any service or repairs to this
projector, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
On cleaning
Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
- To keep the cabinet looking brand-new, periodically clean it with a
soft cloth. Stubborn stains may be removed with a cloth lightly
dampened with mild detergent solution. Never use strong solvents,
such as thinner or benzine, or abrasive cleaners, since these will
damage the cabinet.
- To ensure the highest optical performance and resolution, the
projection lenses are specially treated with an anti-reflective coating, therefore, avoid touching the lens. To remove dust on the lens,
use a soft dry cloth. Do not use a damp cloth, detergent solution, or
thinner.
2. Do not use this equipment near water.
3. Slots and openings in the cabinet and the back or bottom are
provided for ventilation; to ensure reliable operation of the product
and to protect it from overheating, these openings must not be
blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. This
product should never be placed near or over a radiator or heat
register.
The projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided.
4. Do not block the projector cooling fans or free air movement under
and around the projector. Loose papers or other objects may not be
nearer to the projector than 4" on any side.
On servicing
Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltage potentials
and risk of electric shock!
Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing to
1-2 5975597 BARCODATA 808S 170397
On repacking
Save the original shipping carton and packing material; they will
come in handy if you ever have to ship your equipment. For maximum
protection, repack your set as it was originally packed at the factory.
On illumination
In order to obtain the best quality for the projected image, it is essential
that the ambient light which is allowed to fall on the screen be kept to
an absolute minimum.
When installing the projector and screen, care must be taken to avoid
exposure to ambient light directly on the screen. Avoid adverse
illumination on the screen from direct sunlight or fluorescent lighting
fixtures.
The use of controlled ambient lighting, such as incandescent spot
light or a dimmer, is recommended for proper room illumination.
Where possible, care should also be taken to ensure that the floors
and walls of the room in which the projector is to be installed are nonreflecting, dark surfaces. Brighter surfaces will tend to reflect and
diffuse the ambient light and hence reduce the contrast of the
projected image on the screen.
Location and Functions of Control
2
LOCATION AND FUNCTION OF CONTROLS
REAR PANEL TERMINOLOGY
See installation instructions before connecting to the supply.
Voir la notice d'installation avant de raccorder au réseau.
120/230 V
7/5 Am p
50/60 Hz
1 2 3 4 5 76 8 9
Power Switch : Press the switch to turn the projector ON.
1
Depending on the hardware set-up of the projector during
installation, the projector switches to ‘Standby’ or to ‘Op-
erational' mode. If in standby, the standby LED lights up.
AC Power Input
2
Communication Port (800 peripherals)
* Allows communication between the RCVDS switcher and
3
the projector.
* Allows connection of a remote IR receiver unit to the
projector.
Port 3
RGB Analog Input (9 pin female sub D connector). Allows
4
a character generator, microcomputer, etc. having analog
RGB outputs to be connected to the projector.
Port 4/5 : RGB-S Input (5x BNC connector):
RGB-S input : allows a character generator, microcomputer,
5
video camera, etc. having analog RGB output to be connected to the projector.
Line inputs: - signals RED-GREEN-BLUE
- COMPOSITE sync. signal
- Tri level sync signal (option)
PORT 4/5
This device complies wit h part 15 o f
the FCC rules. Operat ion is subject to
following two conditions (1). This
device may no t cause harmf ul interference, and (2) this device must
accept an y interf erence receiv ed
includin g interfer ence that may cause
10
undesired operation"
S-VIDEO Input: Separated Y/C (luma-chroma) signal in-
puts and outputs for higher quality playback of Super VHS
6
signals (4-pin S-VIDEO connector loop-through).
75 ohm Termination Switch for S-Video signals
7
VIDEO Input (Composite video, 2x loop-through BNC
8
connector): Allows a video tape recorder, video camera,
color receiver/monitor, etc. having video line output to be
connected to the projector.
75 ohm Termination Switch for Video signals
9
Projector Pilot Lamp : Indicates the status of the projector.
75 Ohm
PORT 2
75 Ohm
10
- Unlit : mains (power) switch is not pressed.
- Lit : mains (power) switch is pressed and the indicated color
shows the projector mode:
Green color : Operational mode of the projector.
Red color : Standby mode of the projector.
Important : Projector ("Operational" or "Standby") mode is
defined during the installation of the projector. (Refer to a
qualified technician for change).
FRONT PANEL TERMINOLOGY
RS232 IN
RS232 OUT IR
RS232 INRS232 OUTIR
11
11
12
5975597 BARCODATA 808S 110397
RS 232 Input Port
Connection between the BARCODATA 808 and an IBM PC
(or compatible) or MAC (RS422) for remote computer
control and data communication.
RS 232 Output Port
RS 232 Output Port allows a communication link for PC or
MAC to the next projector in a series of projector.
12 13
REMOTE
14
REMOTE
13
14
IR Sensor
Receiver for control signals transmitted from the RCU.
IR Remote
Connector for remote input for hard wired remote control
2-1
Location and Functions of Control
GRAPHICS
Control panel terminology
12
a. The Local Keypad
Gaining Access
The local keypad is located underneath the top cover door with the
BARCO logo.
To open this door, push as indicated on drawing and turn it to the front
side of the projector.
This local keyboard has the same functions as the Remote Control
Unit (RCU).
b. RCU control panel terminology
This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely.
This remote control is used for source selection, control, adaptation
and set-up. It includes automatic storing of :
- Picture controls (Brightness, Sharpness,....)
- Picture geometry adjustments
- Convergence adjustments
Other functions of the remote control are:
- Switching between standby and operational modes
- Switching to "pause" (blanked picture, full power for immediate
restarting)
- Direct access to all connected sources
- Variable adjustment speed : when pushing continuously on the
control stick or the picture keys, the adjustment will be executed in
an accelerated fashion.
Back light key : When activated, all keys will be lit up and
1
visible in the dark.
9
7
stand-by
pause/park
sharpness
tint
color
brightness
contrast
ADJ. : Adjust key, to enter or exit the adjustment mode.
2
Address key (recessed key), to enter the address of the
3
projector (between 0 and 9). Press the address key, followed
by pressing one digit button between 0 and 9.
STBY : Stand-by button :
4
5
6
7
8
- to initiate remote power up operation
- to stop projection without main power off.
Pause : To blank the image, press PAUSE. The image
disappears but full power is retained for immediate restarting.
Digit buttons : Direct input selection.
Picture controls : Use these buttons to obtain the desired
level (see also 'Controlling') for each picture function.
TEXT : When adjusting one of the image controls during a
meeting, the displayed bar scale can be removed by pressing 'TEXT' key first. To re-display the bar scale on the
screen, press 'TEXT' key again. 'TEXT' key is only active in
operational mode. When 'TEXT' is off, no warning message
will be displayed.
1
2
3
4
ADJ
STBY
PAUSE8TEXT
EXIT
ENTER
11
10
5
+
-
0
9
6
7
5
3
SHARPNESS
+
-
8
TINT
+
-
6
COLOR
-
BRIGHTNESS
-
CONTRAST
+
+
32c
4
21
9
ENTER : To start up the adjustment mode or to confirm an
adjustment or selection in the adjustment mode.
10
EXIT : To leave the adjustment mode or to scroll upwards
when in the adjustment mode.
11
12
2-2 5975597 BARCODATA 808S 110397
Control disk : To make menu selections when in the
adjustment mode. Also allows to increment or decrement an
adjustment in the adjustment mode.
Control disk up = up arrow in the menus
Control disk down = down arrow in the menus
Control disk to the right = arrow to the right on the menus
Control disk to the left = arrow to the left on the menus
RC operating indication : lights up when a button on the
remote control is pressed. (This is a visual indicator to check
the operation of the remote control)
Connections
3
CONNECTIONS
AC Power (mains) Cord Connection
Use the supplied power cord to connect your projector to
the wall outlet. Plug the female power connector into the
male connector at the backside of the projector.
Power Check
The power voltage is determined by the art. no., listed on sticker on
the back side of the projector.
See installation instructions before connecting to the supply.
Voir la notice d'installation avant de raccorder au réseau.
120/230 V
7/5 Amp
50/60 Hz
This device comp li es with part 15 of
the FC C ru l es. Operat i o n is su bjec t t o
following two conditions (1). This
device may not cause harmful interference, and (2) this device must
accept any interference received
including interference that may cause
PORT 4/5
75 Ohm
PORT 2
120/230 V
7/5 Amp
50/60 Hz
undesired operation"
75 Ohm
Warning !
Verify the power voltage corresponds to that of the wall outlet.
Art. No. R9002031 must be connected to a 230 VAC power source.
Art. No. R9002038 must be connected to a 120 VAC power source.
If the wall outlet voltage is different, call a qualified technician for
power adaptation of the projector.
Switching On/Off
The projector is switched ON and OFF using the power (mains) switch
ON/OFF.
Pressed : ON
Not pressed : OFF
The projector can start in the 'operational mode' (image displayed) or
in the 'stand by mode', depending on the position of the 'power up' dip
switch on the controller unit. This DIP switch must be set during
installation by a qualified technician. If you want to change this start
up mode, call a qualified technician.
Stand by indication lamp :
RS232 IN
RS232 OUT IR
RS232 INRS232 OUTIR
VIDEO
PORT 1
REMOTE
REMOTE
OFF - ON
75 Ohm
green : operati on
red : standby
PROJECTOR MODE
This device complies with part 15 of
the FCC rules. Operation is subject to
following two conditions (1). This
device may not cause harmful interference, and (2) this device must
accept any interference received
including interference that may cause
undesired operati on"
No light up : projector switched off
Green color : projector in Operational mode
Red color : projector is in Standby mode.
5975597 BARCODATA 808S 110397
3-1
Connections
When starting up the projector, with the power switch or via the stand-by key, the
projector can start up in two ways if the "CRT run in" cycle option is switched OFF.
- full white image (projector warm up) or
- immediate image display.
The way of starting up can be set in the service mode.
Start up with full white image.
The next menu will be displayed for 30 seconds.
a. Start up with warm up period.
If no action is taken, a white image will be displayed for 20 minutes.
This white image will be shifted on the faceplate of the CRT to avoid a CRT burn in.
During this warm up period, it is possible to interrupt this white image projection by
pressing the EXIT key. The previous menu will be repeated for another 30 seconds but
the remaining time will be indicated.
If EXIT is pressed, the remaining warm up period will be skipped.
PROJECTOR WARM UP
A FULL WHITE PATTERN
WILL BE GENERATED FOR
20 MINUTES.
FOR IMMEDIATE USE OF
THE PROJECTOR, PRESS
<EXIT>.
WARNING : SKIPP I NG THIS
PROCEDURE CAN REDUCE
THE INITIAL PICTURE
QUALITY OF THE PROJECTED
IMAGE.
THIS OPTION CAN BE
DISABLED IN THE SERVICE
MENU
During the warm up period, every 30 seconds a text box with the remaining time will
be displayed on the screen for 2 seconds. This text box will be displayed each time in
a different place.
If another key, different from EXIT, is pressed, a text box with following text will be
displayed :
Please use
EXIT to leave this procedure.
b. Start up without warm up period.
If the
EXIT key is pressed, the warm up period will be skipped and the projector is
immediately ready for use.
Warning : skipping this warm up procedure can reduce the initial picture quality
of the projected image.
Signal Input Connection to the Projector :
See installation instructions before connecting to the supply.
- Composite Video
- S-Video
- RGBS or RGsB
- RGB3S or RG3sB (option)
Voir la notice d'installation avant de raccorder au réseau.
120/230 V
7/5 Amp
50/60 Hz
REMAINING
PROJECTOR
WARM UP
TIME
18.5MIN
PLEASE USE
<EXIT> TO
LEAVE THIS
PROCEDURE
This device compli es with part 15 of
the FCC rul es. Operation is subject t o
following two conditions (1). This
device may not cause har mful interference, and (2) this device must
accept any interf erence received
including int erference that may cause
PORT 4/5
75 Ohm
PORT 2
75 Ohm
123 4 5
undesired opera ti on"
Port No Projector input Press Digit Button
1 Comp. Video 1
1
2 S-Video
1
/Comp. Video* 2
Input signal Y/C (luma/chroma)
2
Input signal : R, G and B with automatic sync
detection between seperate sync (separate com-
3 RGB
4/5 RGB
4/5 Component video
4/5 RGB with Tri level sync
2
2
3
4
3
4 or 5
6
7
4/5 Component video
with Tri-level sync
5
Only available when the optional Tri-level sync module is installed.
8
posite sync or with separate Hor and Vert. sync)
or sync on green (composite sync). Automatic
sync polarity detection betweenpositive or negative sync.
3
Input signal : R-Y, Y and B-Y with separate
composite sync or with separate Hor and Vert.
sync or with composite sync on Y. Automatic
sync polarity detection betweenpositive or negative sync.
4
Input signal : R, G and B with separate Tri level
sync or with Tri-level sync on green.
5
Input signal : R-Y, Y and B-Y with separate Tri
level sync or with composite Tri-level sync.
* Video or S-Video : switchable in the Picture
Tuning menu.
3-2 5975597 BARCODATA 808S 110397
Connecting a Composite Video source to port 1.
Composite video signals from a VCR, OFF air signal decoder, etc..
Video input selection :
Press digit button 1 on the RCU or the local keypad.
See installation instructions b efore connecting to the supply.
Voir la notice d'installation avant de raccorder au réseau.
120/230 V
7/5 Amp
50/60 Hz
TV tuner, e.g. TVDM40 stereo
Composite
video
Connections
This device complies with part 15 of
the FCC rules. Operat ion is subject to
following two conditions (1). This
device may not cause harmful interference, and (2) this device must
accept any interferen ce received
including interfer ence that may cause
PORT 4/5
75 Ohm
PORT 2
75 Ohm
undesired operation"
to next projector or
to a monitor
* Note : If using the loop-through Video output, then set the
Termination Switch to the "OFF" position.
VCR
Connecting a S-Video or Video source to port 2.
Separate Y-luma/C-chroma signals for higher quality playback of Super VHS signals.
See installation instruc tions before connecting to the supply .
Voir la notice d'installation avant de raccorder au réseau.
120/230 V
7/5 Am p
50/60 Hz
4 pin connector configurations:
For S-video:
Pin 1: earth(ground) luminance
Pin 2: earth(ground) chrominance
Pin 3: luminance signal(Y)
1Vpp ±3dB
Pin 4: chrominance signal(C)
300mVpp ±3dB
3
4
Input selection
Press digit button 2 on the RCU or the local keypad.
Depending on the priority setting in the Picture Tuning
menu, Video or S-Video can be displayed.
If the setting is not correct, start up the adjustment mode by
pushing on th
ADJUST key.
Select 'Random Access' and press
Select 'Selected source' and press
Highlight 'Picture Tuning' and press ENTER.
Highlight Port 2 : Video and press ENTER to toggle between VIDEO
or S-VIDEO.
Press EXIT to return.
Press ADJUST to return to operational mode.
For video:
Pin 1: earth(ground) video
Pin 2: not connected
1
Pin 3: video signal
Pin 4: not connected
2
ENTER.
.
ENTER
Luma/Chroma
VCR S-VHS
PORT 4/5
ADJUSTMENT MODE
Select a path from below :
GUIDED
RANDOM ACCESS
INSTALLATION
SERVICE
IRIS
Source 02
Choose a setup pattern
Select with or
from below :
then <ENTER>
<EXIT> to return.
SELECTED SOURCE
GENLOCKED PATTERN
INTERNAL # PATTERN
Select with or
then <ENTER>
<EXIT> to return.
Audio amplifier
75 Ohm
PORT 2
Audio amplifier
Source 02
RANDOM ACCESS
ADJUSTMENT MODE
PICTURE TUNING
GEOMETRY
CONVERGENCE
FOCUSING
COLOR SELECT
ORBITING
CONTR. MODULATION
SOFT EDGE
Select with or
then <ENTER>
<EXIT> to return.
LINE DOUBLER : ON
75 Ohm
to next projector or
to a monitor
PICTURE TUNING
COLOR BALANCE
SYNC : FAST
PORT2 : S-VIDEO
358
This device complies with part 15 of
the FCC rules. Operation is subject to
following two conditions (1). This
device may not cause harmful interference, and (2) t his device must
accept any interferen ce received
including interfer ence that may cause
undesired operation"
359
* Note: When using the Port 2 loop-through output, set the Termination Switch in the "OFF" position.
5975597 BARCODATA 808S 110397
Select with or
<ENTER> to accept
<EXIT> to return.
3-3
Connections
Connecting a RGB Analog source to port 3.
Connect your RGB source via an interface to Port 3.
Always use an interface when a computer and local monitor have to
be connected to the projector.
Available Barco interfaces :
Universal analog interface R9826100
RGB 120 MHz analog interface R9826570
VGA interface 120V R9828079
230V R9828070
MAC interface 120V R9828059
230V R9828050
MAGIK interface 120V R9828129 & R9828128
230V R9828120 & R9828121
RGB analog input with automatic sync detection. (Separate H and
V sync inputs, with composite sync input or with sync signals on
green)
Pin configuration D9 connector of the Analog input.
1 Not connected
2 Ground RGBS
3 RED
4 GREEN
5 BLUE
6 Ground RGBS
7 Ground RGBS
8 Hor/comp. sync
9 Vert. sync
See installation instructions b efore connecting to the supply.
Voir la notice d'installation avant de raccorder au réseau.
120/230 V
7/5 Amp
50/60 Hz
ANALOG INTERF . 120MHz
ON
OFF
This device complies with part 15 of
the FCC rules. Operat ion is subject to
following two conditions (1). This
device may not cause harmful interference, and (2) this device must
accept any interferen ce received
including interfer ence that may cause
PORT 4/5
INPUT
BH
G
R
INP INP
75 ohm term.
75 Ohm
PORT 2
V
inver.
75 Ohm
undesired operation"
361
Analog Input Selection :
Press digit button 3 on the RCU or the local keypad.
Connecting a RGB Analog source to port 4/5.
RGB analog input terminals with separate H and V sync inputs,
composite sync input or sync signals on green (automatic sync
detection).
Always use an interface when a computer and local monitor have to
be connected to the projector. See 'Connecting a RGB Analog
source to port 3' for a list of BARCO interfaces which can be applied.
RGB input selection :
(RGB : R, G, B signals with automatic sync detection)
Press digit button 4 or 5 on the RCU or the local keypad.
See installa tion instructions be fore connec ting to the supply.
Voir la no ti ce d 'i n st al lat i o n ava n t de ra cco r de r au réseau.
120/230 V
7/5 Amp
50/60 Hz
ON
OFF
ANALOG INTERF. 120MHz
G
R
INPUT
This device compli es with part 15 of
the FCC rul es. Operation is subject t o
following two conditions (1). This
device may not cause har mful interference, and (2) this device must
accept any interf erence received
including int erference that may cause
PORT 4/5
B
75 Ohm
PORT 2
H
V
INP
INP
inver.
75 ohm term.
75 Ohm
undesired opera ti on"
363
3-4 5975597 BARCODATA 808S 110397
Connecting a RGB Analog source with Tri-level
sync to port 4/5.
(option)
RGB analog input terminals with Tri level sync input or Trilevel sync on green. The projector detects automatically
where the sync signal is located.
RGB input selection :
(RG3sB : R, G, B signals with automatic Tri-level sync detection)
See installa tion instructions be fore connec ting to the supply.
Voir la no ti ce d 'i n st al lat i o n ava n t de ra cco r de r au réseau.
120/230 V
7/5 Amp
50/60 Hz
Connections
This device comp lies with part 15 of
the FCC rul es. Operation is subj ect to
following two conditions (1). This
device may not cau se harmful interference, and (2) this device must
accept any int erference received
including int erference that m ay cause
PORT 4/5
75 Ohm
PORT 2
75 Ohm
undesired operation"
Press digit button 7 on the RCU or the local keypad.
Connecting a Component Video source to
port 4/5.
A component video (R-Y, Y, B-Y) with sync signals can be connected
to the projector via the Port 4/5. The projector automatically detects
where the sync signal is located.
To select the component video input :
Press digit button 6 on the RCU or the local keypath.
VCR HDTV player
See installa tion instructions be fore connec ting to the supply.
Voir la no ti ce d 'i n st al lat i o n ava n t de ra cco r de r au réseau.
120/230 V
7/5 Amp
50/60 Hz
VCR HDTV player
Audio amplifier
798
This device comp lies with part 15 of
the FCC rul es. Operation is subj ect to
following two conditions (1). This
device may not cau se harmful interference, and (2) this device must
accept any int erference received
including int erference that m ay cause
PORT 4/5
PORT 2
75 Ohm
Audio amplifier
75 Ohm
undesired operation"
798
Connecting a Component Video source with Trilevel sync to port 4/5.
(Opion)
A component video (R-Y, Y, B-Y) with Tri-level sync signals can be
connected to the projector via the Port 4/5. The projector automatically detects where the sync signal is located.
See installa tion instructions be fore connec ting to the supply.
Voir la no ti ce d 'i n st al lat i o n ava n t de ra cco r de r au réseau.
120/230 V
7/5 Amp
50/60 Hz
PORT 4/5
75 Ohm
PORT 2
75 Ohm
This device comp lies with part 15 of
the FCC rul es. Operation is subj ect to
following two conditions (1). This
device may not cau se harmful interference, and (2) this device must
accept any int erference received
including int erference that m ay cause
undesired operation"
To select the component video input :
Press digit button 8 on the RCU or the local keypad.
VCR HDTV player
5975597 BARCODATA 808S 110397
Audio amplifier
798
3-5
Connections
PERIPHERAL EQUIPMENT
Connecting a RCVDS 05 switcher to the
BARCODATA 808S
- Up to 20 inputs with the RCVDS 05 switcher and up to 90 inputs
when 10 RCVDS switchers are linked via the expansion modules.
- Serial communication with the projector.
- Remote control buttons on the RCVDS to control the
BARCODATA 808S (source selection and analog settings)
- The selected source number will be displayed on a 2 digit display
and the selected input modules will be indicated with a LED on the
rear.
For more information about the use of the RCVDS 05, consult the
Owner's Manual of the RCVDS 05.
Order number : RCVDS05 : R5975765
Connecting a VS05 switcher to the BARCODATA
808S.
The VS05 can switch up to 5 Composite Video sources, 3 S-Video
Sources and 1 RGB analog or component Video source to the
BARCODATA 808S. In addition, an audio signal associated with the
source, can be switched to an audio amplifier.
Order number : R9827890.
For more information about the use of the VS05, consult the VS05
Owner's Manual, order number : R5975245.
Connecting an IR Remote Receiver to the
BARCODATA 808S
This infra-red receiver unit makes it possible to control the
BARCODATA 808S from another room. There is a communication
line cable between the IR receiver and the projector or the RCVDS
800. The infrared control information from the Remote Control Unit
is sent to the IR Remote Receiver. The IR Remote Receiver 800
displays the selected source on a 7-segment display.
Order number : R9827515.
3-6 5975597 BARCODATA 808S 110397
Controlling
4
CONTROLLING
Caution : Do not display a stationary image with full brightness
and contrast for longer than 20 min., otherwise you risk damage
to the CRT's.
Battery installation in the RCU.
A new battery (not yet installed to save the battery life) is delivered inside the plastic bag with the power
cord. Before using the RCU, follow the battery installation procedure.
Remove the battery cover on the backside of the RCU by pushing the indicated handle a little to the
bottom of the RCU. Lift up the top side of the cover at the same time (fig. 1).
Insert the new 9 V battery (type 6F22S or equivalent) in the lower compartment and connect the battery
to the contact plate.
Insert the battery into the lower compartment and put the cover back.
Contact
plate
Battery
fig.2
310a.DRW
Behind the
plastic cover,
insert the 'card
for RCU'. You
can cut out the
correct insert
card on one of
the last pages of
this manual.
fig.1
5975597 BARCODATA 808S 110397
4-1
Loading...
