VERSAILLES Cat. No.
42” CONSOLE PGVCL
W: 42”
D: 22 1/2”
H: 32”
Features:
►Fine Fire Clay for Durability
►Large Deck
►Should be mounted to wall using molly bolts or toggle
bolts (not inlcuded)
Compliance Certification
Colors:
WH White
Meets or exceeds the following
specifications: ASME 112.19.9M
(and 19.6M) for Fire Clay
fixtures.
42” console side deck: 9 1/2”
Back of basin to center of faucet: 2 1/2”
Back of basin to center of drain: 7 1/2”
Mount bolts height: 29 1/2”
Faucet and spout holes: 1 3/8”
Interior Dimensions:
Basin Interior: 18 1/4” x 13”
Basin Depth: 9 1/4”
Dimensions of fixture are nominal and may vary within the range of tolerances established by ANSI Standard A112.19.2. Dimensions and
specifications subject to change without notice.
5/15/09
Page: 1 of 3
P 847•244•1234 www.barclayproducts.com
VERSAILLES Cat. No.
42” CONSOLE PGVCL
Dimensions of fixture are nominal and may vary within the range of tolerances established by ANSI Standard A112.19.2. Dimensions and
specifications subject to change without notice.
5/15/09
Page: 2 of 3
P 847•244•1234 www.barclayproducts.com
VERSAILLES Cat. No.
42” CONSOLE PGVCL
Dimensions of fixture are nominal and may vary within the range of tolerances established by ANSI Standard A112.19.2. Dimensions and
specifications subject to change without notice.
5/15/09
Page: 3 of 3
P 847•244•1234 www.barclayproducts.com
