Data Capture for Workforce
in Motion
BaracodaManager
User Guide
©Baracoda TM April 2011
Data Capture for Workforce
in Motion
SUMMARY
SUMMARY ................................................................... 2
REVISION HISTORY .......................................................... 5
INTRODUCTION .............................................................. 6
1. OVERVIEW ............................................................ 7
1.1. BARACODAMANAGER MAIN WINDOW FUNCTIONS .................................... 7
2. INSTALLATION ....................................................... 10
3. GETTING STARTED .................................................... 11
3.1. USING BLUETOOTH INQUIRY TO FIND READERS .................................. 11
3.2. USING CONNECT&SCAN TO CONNECT READERS ................................... 14
4. FUNCTIONS .......................................................... 17
4.1. ADDING/REMOVING A BARCODE READER ....................................... 17
4.2. DISCONNECTING A BARCODE READER ......................................... 17
4.3. SETTING PARAMETERS OF A BARCODE READER ................................... 17
5. BARACODA PENCIL SETTINGS ........................................... 18
5.1. PRODUCT SETTINGS .................................................... 19
5.2. BLUETOOTH SETTINGS ................................................... 19
5.3. SYMBOLOGY SETTINGS ................................................... 20
5.4. BATCH MODE SETTINGS .................................................. 20
6. BARACODAPENCIL2 SETTINGS ........................................... 21
6.1. BATCH MODE SETTINGS .................................................. 22
6.2. PRODUCT SETTINGS .................................................... 23
6.3. BLUETOOTH SETTINGS ................................................... 23
6.4. SYMBOLOGY SETTINGS ................................................... 24
7. BL1000 SETTINGS .................................................... 25
8. D-FLY SETTINGS ..................................................... 26
8.1. BATCH MODE SETTINGS .................................................. 27
8.2. PRODUCT SETTINGS .................................................... 28
8.3. BLUETOOTH SETTINGS ................................................... 28
8.4. SYMBOLOGY SETTINGS ................................................... 29
9. BARACODA ROADRUNNERS SETTINGS ...................................... 30
BaracodaManager for PC – User Guide v3.39 - 2 -
Data Capture for Workforce
in Motion
9.1. BATCH MODE SETTINGS .................................................. 31
9.2. PRODUCT SETTINGS .................................................... 32
9.3. BLUETOOTH SETTINGS ................................................... 32
9.4. SYMBOLOGY SETTINGS ................................................... 33
10. BARACODA ROADRUNNERS EVOLUTION SETTINGS ............................ 34
10.1. BATCH MODE SETTINGS .................................................. 36
10.2. PRODUCT SETTINGS .................................................... 37
10.3. BLUETOOTH SETTINGS ................................................... 37
10.4. SYMBOLOGY SETTINGS ................................................... 38
10.5. SIGNATURE/IMAGE CONFIGURATION SETTINGS ................................... 39
11. BARACODA TAGRUNNERS SETTINGS ....................................... 41
11.1. BATCH MODE SETTINGS .................................................. 42
11.2. PRODUCT SETTINGS .................................................... 43
11.3. BLUETOOTH SETTINGS ................................................... 43
11.4. RFID SETTINGS ...................................................... 44
12. BARACODA DUALRUNNERS SETTINGS ...................................... 46
12.1. BATCH MODE SETTINGS .................................................. 48
12.2. PRODUCT SETTINGS .................................................... 49
12.3. BLUETOOTH SETTINGS ................................................... 49
12.4. SYMBOLOGY SETTINGS ................................................... 50
12.5. RFID SETTINGS ...................................................... 51
12.6. SIGNATURE/IMAGE CONFIGURATION SETTINGS ................................... 53
13. 2604 SERIES SETTINGS (FOR BC2604, BL2604, BLR2604) ................. 55
13.1. BATCH MODE SETTINGS .................................................. 56
13.2. PRODUCT SETTINGS .................................................... 57
13.3. BLUETOOTH SETTINGS ................................................... 57
13.4. SYMBOLOGY SETTINGS ................................................... 58
13.5. ADVANCED SETTINGS .................................................... 58
14. BCM2604 SETTINGS ................................................... 59
14.1. PRODUCT SETTINGS .................................................... 60
14.2. BLUETOOTH SETTINGS ................................................... 60
15. BARACODA TOUGHRUNNERS AND SCANWEAR SETTINGS ........................ 61
15.1. PRODUCT SETTINGS .................................................... 62
15.2. BLUETOOTH SETTINGS ................................................... 63
15.3. SYMBOLOGY SETTINGS ................................................... 63
16. IDBLUE SETTINGS .................................................... 64
16.1. BATCH MODE SETTINGS .................................................. 65
16.2. BLUETOOTH SETTINGS ................................................... 66
BaracodaManager for PC – User Guide v3.39 - 3 -
Data Capture for Workforce
in Motion
17. UPLOADING DATA STORED IN BATCH MODE ................................ 67
18. FIRMWARE UPGRADE ................................................... 68
19. PLUGINS ............................................................ 70
19.1. TERMINAL PLUGIN ..................................................... 70
19.2. KEMUL PLUGIN ....................................................... 71
19.3. IDBLUE PLUGIN ....................................................... 72
19.4. BTR_BSW PLUGIN ..................................................... 73
19.5. RFID PLUGIN ........................................................ 74
19.6. PICTUREPLUGIN ....................................................... 75
BaracodaManager for PC – User Guide v3.39 - 4 -
Data Capture for Workforce
in Motion
Revision History
Changes to the original manual are listed below.
Document Date Description
3.34 13th June 08 Initial release
3.34.1 18th August 08 TagRunners added, new master mode added
3.35 16th October 08 TagRunners RFID options added
3.35.2 22nd December 08 GUI modifications, BRRT plugin added
3.36 2nd March 09 DualRunners added
3.36.3 17th September 09 Version updated
3.37 3rd February 10 Signature (BRR Evolution 2D, BDR 2D) added
3.38 23rd November 10 C&S and Manual autoscan added, signature/picture capture modified
3.39 11th April 11 New D-Fly options added
BaracodaManager for PC – User Guide v3.39 - 5 -
Data Capture for Workforce
in Motion
Introduction
The BaracodaManager for PC software allows the user to easily operate their barcode reader(s), including:
Connecting automatically to the barcode reader(s) that the user wants to use Inserting the scanned barcode to a selected field in the client application (KEmul plugin) or displaying it
(Terminal plugin)
Setting a barcode reader(s) parameters (PIN code and others) Uploading data saved in a reader(s) memory.
Requirements:
Hardware: Pentium II class PC, CPU 200MHz or above RAM: 128MB or above OS: Windows XP/ Windows 2003 / Windows Vista / Win7 A compatible Bluetooth driver
Compatible Bluetooth drivers:
Widcomm Bluetooth stack / driver - version 1.4.x.x or above Microsoft stack (Windows XP Service Pack 1 US version, Service Pack 2 worldwide, Windows Vista,
Win7)
Note: the BaracodaManager for PC does not work with Plug&Scan dongles.
The BaracodaManager for PC and a complete list of compatible devices (Compatibility table) can be downloaded from the Partners download section of Baracoda website (registration is required):
http://www.baracoda.com
BaracodaManager for PC – User Guide v3.39 - 6 -
Data Capture for Workforce
in Motion
1. Overview
To set up the BaracodaManager and to configure it with their barcode reader(s), the user should check the following sections:
- Installation
- Getting Started
This section shows the user how to use the BaracodaManager icon and window during regular operation. For help on how to configure the BaracodaManager or how to set up the automatic connection mode – See section Getting Started.
1.1. BaracodaManager main window functions
In order to launch the BaracodaManager, the user can either double-click the desktop shortcut:
or they can use the Start Menu:
BaracodaManager for PC – User Guide v3.39 - 7 -
Data Capture for Workforce
in Motion
When the BaracodaManager is running its icon appears on the task bar:
If no barcode reader(s) are connected to the BaracodaManager, the inside color of the icon is white (as in the picture above).
The BaracodaManager automatically attempts to connect the barcode reader(s) which you have already configured. Its icon turns green as soon as it connects to at least one barcode reader:
The main window of the BaracodaManager is shown on the screenshot below:
The “My Paired Devices” section of the window shows the configured barcode reader(s) and their connection status (Connected/Disconnected/Connecting).
BaracodaManager for PC – User Guide v3.39 - 8 -
Data Capture for Workforce
in Motion
Button
Corresponding action
Search all devices
Find all discoverable barcode readers (which are within the Bluetooth radio signal range).
Add Selected
Add the selected barcode reader to the list of configured (paired)
barcode readers (in the “My Paired Devices” list).
Automatic connection
Settings
Set the parameters of the selected barcode reader.
Disconnect/Connect
Disconnect the selected barcode reader or connect a disconnected barcode reader.
Upload
Upload barcodes previously stored in the selected barcode reader’s
non-volatile memory.
Hide
Hide the BaracodaManager window in the system tray. Double-click the icon in order to bring it back to the foreground.
Exit
Quit the BaracodaManager and save information on the configured barcode reader(s). The Bluetooth radio connections are closed. The barcode reader(s) switches to stand-by mode.
Check box, left of the
barcode reader's ID
Set the autoconnect mode for the barcode reader: the BaracodaManager automatically tries to connect to the barcode reader.
The table below shows the main functions available in the BaracodaManager main window (for details, see the Functions section):
BaracodaManager for PC – User Guide v3.39 - 9 -
Data Capture for Workforce
in Motion
2. Installation
To use Baracoda barcode reader(s), the client needs to complete the following tasks in sequence:
- Install the Bluetooth stack software (if not installed yet)
- Install the BaracodaManager
- Configure the BaracodaManager with barcode reader(s)
To complete the first two tasks (installing the Bluetooth stack software and the Baracoda Manager):
1. Contact your Baracoda reseller to obtain the BaracodaManager installation file or download it from
the download section of the website (www.baracoda.com/download).
2. Install the Bluetooth stack according to the instructions provided in the installation package or by the
installation wizard itself.
3. Restart the computer, if necessary.
4. A Bluetooth Configuration icon should appear in the system tray, indicating that Bluetooth wireless
communication is active.
5. Double click on the BaracodaManager installation file:
- for the PC version: BM_PC_3.xx.exe
6. Let the installation wizard guide you through the installation steps. Be sure the following boxes are
checked :
- Baracoda Manager
- Start Menu Shortcuts
At this moment, everything is ready to complete the third task, that is configuring the BaracodaManager with the user’s barcode reader(s). See the next section, Getting started.
BaracodaManager for PC – User Guide v3.39 - 10 -
Data Capture for Workforce
in Motion
3. Getting started
This section shows the user how to configure the BaracodaManager to connect and use their barcode reader(s).
Since the BaracodaManager version 3.38, two ways of connecting a reader are possible:
- using Bluetooth inquiry to find a reader and then connect it (available on all supported Bluetooth
stacks)
- using the Connect&Scan method (scanning a connect barcode) to connect a reader without launching
a Bluetooth inquiry (available only on the Microsoft Bluetooth stack)
3.1. Using Bluetooth inquiry to find readers
To configure the barcode reader(s):
1. Turn on the barcode reader(s) and the computer on which the BaracodaManager has been installed.
2. Double-click the BaracodaManager icon in the system tray (if you do not find the BaracodaManager
icon, start the BaracodaManager). The BaracodaManager window appears:
- the “Devices in Range” section of the window lists the barcode reader(s) the Baracoda
Manager finds within Bluetooth radio range
- the BaracodaManager displays a progress bar just below the above list while it searches for
discoverable barcode readers Note: if the user has already run the BaracodaManager and configured their barcode reader(s), they should go to step 9 below.
BaracodaManager for PC – User Guide v3.39 - 11 -
Data Capture for Workforce
in Motion
3. Select a barcode reader (in the “Devices in Range” list) by clicking on it, then click on the “Add
Selected” button. A Bluetooth message appears near the system tray:
4. Click on the Bluetooth icon in the system tray. A Bluetooth passkey window appears:
5. Enter the barcode reader PIN/Passkey code (by default: “0000” – see Functions section to change the
code).
BaracodaManager for PC – User Guide v3.39 - 12 -
Data Capture for Workforce
in Motion
6. The BaracodaManager is now configured with the user’s barcode reader. The “My Paired Devices”
section of the BaracodaManager window displays:
- the AutoConnect box is checked. The BaracodaManager will try to automatically connect to
the barcode reader at the beginning of the next session.
- the barcode reader's identifier, name and Bluetooth address.
- the connection status of the barcode reader. After a few seconds, the Status field switches
from Disconnected to Connecting, then to Connected showing you that the barcode reader is
ready to use.
- the plugin, set by default to KEmul (see the Plugins section for KEmul information).
7. To change the plugin to be used for the barcode reader:
- Click on the KEmul text in the Plugin column. A down-pointing arrow appears.
- Click on the arrow. A list of plugins appears.
- Select a plugin.
8. Repeat steps 3 to 7, to add any newly discovered barcode reader(s) to “My Paired Devices”.
9. When the user ends the first session of the BaracodaManager, they should click Exit to save the
barcode reader(s) Bluetooth Device Address(s) for future sessions. The BaracodaManager will reconnect to the barcode reader(s) when it is restarted, even if the user ends sessions of the BaracodaManager by switching off the computer instead of clicking the Exit button.
10. When the user starts the BaracodaManager again (either manually or automatically at system start-
up time):
- the BaracodaManager tries to reconnect the barcode reader(s) which were previously
configured (paired) and for which the AutoConnect mode is set (checkbox situated on the left
of the barcode reader's identity information in the “My Paired Devices” list is checked).
BaracodaManager for PC – User Guide v3.39 - 13 -
Data Capture for Workforce
in Motion
- the BaracodaManager searches for all discoverable barcode reader(s) not previously
configured (which are in the Bluetooth radio range and are in listening mode). This is true
when there are no configured readers in the “My Paired Devices” list.
3.2. Using Connect&Scan to connect readers
To configure the barcode reader(s):
1. Turn on the barcode reader(s) and the computer on which the BaracodaManager has been installed.
2. Make sure that the Bluetooth stack on the PC is from Microsoft
3. Double-click the BaracodaManager icon in the system tray (if you do not find the BaracodaManager
icon, start the BaracodaManager). The BaracodaManager window appears.
4. Make sure that there are no more than 6 readers in the My Paired Devices, otherwise it will not be
possible to show the connect barcode.
5. Click the Automatic connection button in order to show the connect barcode
6. Scan the connect barcode with the reader
BaracodaManager for PC – User Guide v3.39 - 14 -
Data Capture for Workforce
in Motion
7. The BaracodaManager is now configured with the user’s barcode reader. The “My Paired Devices”
section of the BaracodaManager window displays:
- the AutoConnect box is checked. The BaracodaManager will try to automatically connect to
the barcode reader at the beginning of the next session.
- the barcode reader's identifier, name (or CS reader if it is a new reader) and Bluetooth
address.
- the connection status of the barcode reader (Connected showing you that the barcode reader
is ready to use).
- the plugin, set by default to KEmul (see the Plugins section for KEmul information).
8. To change the plugin to be used for the barcode reader:
- Click on the KEmul text in the Plugin column. A down-pointing arrow appears.
- Click on the arrow. A list of plugins appears.
- Select a plugin.
9. Repeat steps 5 to 7, to add any new barcode reader(s) to “My Paired Devices”.
10. When the user ends the first session of the BaracodaManager, they should click Exit to save the
barcode reader(s) Bluetooth Device Address(s) for future sessions. The BaracodaManager will reconnect to the barcode reader(s) when it is restarted, even if the user ends sessions of the BaracodaManager by switching off the computer instead of clicking the Exit button.
11. When the user starts the BaracodaManager again (either manually or automatically at system start-
up time):
- the BaracodaManager tries to reconnect the barcode reader(s) which were previously
configured (paired) and for which the AutoConnect mode is set (checkbox situated on the left
of the barcode reader's identity information in the “My Paired Devices” list is checked).
- the BaracodaManager searches for all discoverable barcode reader(s) not previously
configured (which are in the Bluetooth radio range and are in listening mode). This is true
when there are no configured readers in the “My Paired Devices” list.
BaracodaManager for PC – User Guide v3.39 - 15 -
Data Capture for Workforce
in Motion
Notes: If the user switches off a barcode reader (with the reset switch or through time-out) and they switch it on again, the BaracodaManager reconnects to the barcode reader. In the situation where the “Real time” mode and “No data loss modeoptions are enabled (see Functions section: Setting parameters), if the user takes the barcode reader out of range (more than 15-70 meters from the computer, depending on the Bluetooth emission power) and the connection is lost, the barcode reader will store any scanned barcode(s). When the user brings the reader back within range, the BaracodaManager reconnects automatically and the stored barcodes are then uploaded.
BaracodaManager for PC – User Guide v3.39 - 16 -
Data Capture for Workforce
in Motion
4. Functions
4.1. Adding/removing a barcode reader
The first time the user runs the BaracodaManager, it searches for all Bluetooth barcode readers which are discoverable (in listening mode and within Bluetooth radio range). The “Devices in Range” section of the BaracodaManager window displays the readers found. To add a barcode reader to the “My Paired Devices” list, the user should select the reader (in the “Devices in Range” section of the window) and click on the “Add to Paired” button. The “My Paired Devices” list displays the barcode reader's:
- AutoConnect status (set by default)
- ID: number assigned by the BaracodaManager
- Name: device name
- Bluetooth device address (BdAddr)
- Connection status: Connected, Disconnected, Connecting
- Associated plugin (KEmul by default).
If the BaracodaManager does not find the user’s barcode reader, they should make sure that their Bluetooth device is in listening mode and click on the Search button to restart the search. To remove a barcode reader, select it in the “My Paired Devices” list and click on the Remove button. The BaracodaManager will remove the reader from the “My Paired Devices” list.
4.2. Disconnecting a barcode reader
To close the Bluetooth radio connection between the BaracodaManager and the selected barcode reader, select the barcode reader in the My Paired Devices list and click the Disconnect button. The barcode reader returns to discoverable (listening) mode. The AutoConnect mode is deactivated.
4.3. Setting parameters of a barcode reader
To set the parameters of a barcode reader, select it in the “My Paired Devices” list and click on the Settings
button. A Settings window related to your barcode reader appears.
BaracodaManager for PC – User Guide v3.39 - 17 -
Data Capture for Workforce
in Motion
Field
Functionality
Radio
Version of Bluetooth chipset
Decoder
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Auto connect
Default setting. No more a valid setting, so select another one at the first set up.
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
5. Baracoda Pencil settings
The Settings window displays eight buttons and four groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
BaracodaManager for PC – User Guide v3.39 - 18 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Upgrade the BaracodaPencil with the latest version of the firmware. See
Chapter 16 for more information about the upgrade procedure.
Check the box to activate Baracoda Header
Check the box to activate prefix and suffix
When Prefix/Suffix box is checked, select Data Format (ASCII or Hex) and type
values in active fields.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
5.1. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
5.2. Bluetooth settings
BaracodaManager for PC – User Guide v3.39 - 19 -
Data Capture for Workforce
in Motion
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
Check the box to enable/disable decoding of the selected type of barcodes
5.3. Symbology settings
5.4. Batch mode settings
The Batch mode configuration displays three buttons and give the choice between:
1. Upload barcodes to a file
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
2. Upload barcodes to an application window
(for more information see the paragraph “Uploading data stored in batch mode”)
BaracodaManager for PC – User Guide v3.39 - 20 -
Data Capture for Workforce
in Motion
Field
Functionality
Application
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection is not established the barcodes are lost, unless “Enable Buffering” is set (see below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Field
Functionality
Battery
Battery level (0-100%) and its current charging status.
6. BaracodaPencil2 settings
The Settings window displays eight buttons and five groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Battery
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Battery field:
BaracodaManager for PC – User Guide v3.39 - 21 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
6.1. Batch mode settings
The Batch mode configuration displays three buttons and give the choice between:
1. Upload barcodes to a file
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
2. Upload barcodes to an application window
(for more information see the paragraph “Uploading data stored in batch mode”)
BaracodaManager for PC – User Guide v3.39 - 22 -
Data Capture for Workforce
in Motion
Check the box to activate Baracoda Header
Check the boxes to activate prefix/suffix
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
Check the box to activate timestamp
Configure the number of barcodes (0 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected)
Check the box to activate beep when a barcode is decoded
Select beep volume (high or low)
Check the box to activate beep when a barcode is acknowledged by the host PC (when No data loss mode is active)
Select to allow duplicate scans
Select to disable duplicate scans (duplicates not decoded by the reader)
Select to disable duplicate scans (error beep when a duplicate barcode is read)
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
6.2. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
6.3. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 23 -
Data Capture for Workforce
in Motion
Check the box to enable AIM ID prefix specific to symbology
Select type of barcode to configure.
Select the max. length of decoded barcodes
Reset all
symbologies’
options to default values
Click to enable all symbologies
Click to disable all symbologies
6.4. Symbology settings
To find out more about the Symbology settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 24 -
Data Capture for Workforce
in Motion
Field
Functionality
Radio
Version of Bluetooth chipset
Decoder
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
PIN code
The pin code used to authenticate the barcode reader
Field
Functionality
When connected
Set the delay (in seconds) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When disconnected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Field
Functionality
Acknowledgement beep
If checked, configure the reader to beep once when the barcode sent to the host is acknowledged
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
7. BL1000 settings
The Settings window displays three buttons and two groups:
- General information
- Shutdown Timers
The following two tables show the General information fields:
The following table shows the Shutdown Timer fields that you can set:
The table below shows how to use the acknowledgement beep checkbox:
The table below shows the actions you can take with the buttons:
BaracodaManager for PC – User Guide v3.39 - 25 -
Data Capture for Workforce
in Motion
Field
Functionality
Application
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings). Batch mode is supported on D-Fly with P/N value “B401202xx” (firmware v1.54 and newer).
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Field
Functionality
Battery
Battery level (0-100%) and its current charging status.
8. D-Fly settings
The Settings window displays eight buttons and five groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Battery
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Battery field:
BaracodaManager for PC – User Guide v3.39 - 26 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
8.1. Batch mode settings
Please note that the batch mode is supported on D-Fly with P/N value “B401202xx” (firmware v1.54 and newer).
The Batch mode configuration displays three buttons and give the choice between:
1. Upload barcodes to a file
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
2. Upload barcodes to an application window
(for more information see the paragraph “Uploading data stored in batch mode”)
BaracodaManager for PC – User Guide v3.39 - 27 -
Data Capture for Workforce
in Motion
Check the box to activate Baracoda Header
Check the boxes to activate prefix/suffix
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
active fields.
Configure the number of barcodes (0 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected)
Check the box to activate beep when a barcode is decoded
Select beep volume (high or low)
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
Check the box to activate beep when a barcode is acknowledged by the host PC (when No data loss mode is active)
Select to activate aiming trigger mode of the scan engine
Select to activate trigger mode of the scan engine
Check the box to activate timestamp (supported on D-Fly with P/N
“B401202xx”
(firmware >=
v1.54))
Select to allow duplicate scans
Select to disable duplicate scans (duplicates not decoded by the reader)
Select to disable duplicate scans (error beep when a duplicate barcode is read)
Select to activate manual autoscan mode of the scan engine
8.2. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
8.3. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 28 -
Data Capture for Workforce
in Motion
Check the box to enable AIM ID prefix specific to symbology
Select the max. length of decoded barcodes
Reset all
symbologies’
options to default values
Click to enable all symbologies
Click to disable all symbologies
Select type of barcode to configure.
8.4. Symbology settings
To find out more about the Symbology settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 29 -
Data Capture for Workforce
in Motion
Field
Functionality
Decoder
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Field
Functionality
Battery
Battery level (0-100%) and its current charging status.
9. Baracoda RoadRunners settings
The Settings window displays eight buttons and five groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Battery
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Battery field:
BaracodaManager for PC – User Guide v3.39 - 30 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
9.1. Batch mode settings
The Batch mode configuration displays three buttons and give the choice between:
1. Upload barcodes to a file
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
2. Upload barcodes to an application window
(for more information see the paragraph “Uploading data stored in batch mode”)
BaracodaManager for PC – User Guide v3.39 - 31 -
Data Capture for Workforce
in Motion
Check the box to activate Baracoda Header
Check the boxes to activate prefix/suffix
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
Check the box to activate timestamp
Configure the number of barcodes (0 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected)
Check the box to activate beep when a barcode is decoded
Select beep volume (high or low)
Select to activate autoscan mode of the scan engine
Select max BT power allowed by law in your country.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
Check the box to invert the LED
(connection / operating mode indication)
Select to disable the scan engine
Select to activate smart autoscan mode of the scan engine
Check the box to activate beep when a barcode is acknowledged by the host PC (when No data loss mode is active)
Select to activate trigger mode of the scan engine (default)
9.2. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
9.3. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 32 -
Data Capture for Workforce
in Motion
Check the box to enable AIM ID prefix specific to symbology
Select the max. length of decoded barcodes
Reset all
symbologies’
options to default values
Click to enable all symbologies
Click to disable all symbologies
Select type of barcode to configure.
9.4. Symbology settings
To find out more about the Symbology settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 33 -
Data Capture for Workforce
in Motion
Field
Functionality
Application
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Field
Functionality
Battery
Battery level (0-100%) and its current charging status.
10. Baracoda RoadRunners Evolution settings
The Settings window displays eight buttons and five groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Battery
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Battery field:
BaracodaManager for PC – User Guide v3.39 - 34 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (not available for 2D readers, see below)
Signature/image configuration
Access the signature mode and picture mode configuration (only for 2D
readers with firmware version >= 1.47, see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
BaracodaManager for PC – User Guide v3.39 - 35 -
Data Capture for Workforce
in Motion
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
10.1. Batch mode settings
The Batch mode configuration displays three groups of controls:
- the “Upload barcodes/RFID tag IDs” group that lets the user specify whether the uploaded barcodes
will be saved in a file or sent to an application window using keyboard emulation
o If the user chooses to save the uploaded barcodes to a file, the filename can be specified in
the text field
- the “Upload file name generation” method group
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
- the “Image upload file name generation” method group that lets the user specify the file name to
which uploaded signature/image captures will be saved.
The format of the image filename will be the following:
AAA_Filename_BBB_CCC.jpg, where
AAA – reader’s Bluetooth address (if the “Add reader Bluetooth address to filename” checkbox has been
checked in Signature/image capture configuration settings)
Filename – filename specified in the “Image upload file name generation” group, BBB – PC timestamp (year, month, day, hour, minute, second, millisecond) CCC – reader timestamp (if the timestamp has been activated on the reader)
For more information see the paragraph “Uploading data stored in batch mode”.
BaracodaManager for PC – User Guide v3.39 - 36 -
Data Capture for Workforce
in Motion
Check the box to activate Baracoda Header
Check the box to activate prefix/suffix
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
active fields.
Check the box to activate timestamp
Configure the number of barcodes (0 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected)
Check the box to activate beep when a barcode is decoded
Select beep volume (high or low)
Check the box to activate beep when a barcode is acknowledged by the host PC (when No data loss mode is active)
Select to allow duplicate scans
Select to disable duplicate scans (duplicates not decoded by the reader)
Select to disable duplicate scans (error beep when a duplicate barcode is read)
Select max BT power allowed by law in your country.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
Select to activate aiming trigger mode of the scan engine
Select to activate trigger mode of the scan engine (default)
Select to activate autoscan or manual autoscan mode of the scan engine
10.2. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
10.3. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 37 -
Data Capture for Workforce
in Motion
Select type of barcode to configure.
Select the max. length of decoded barcodes
Reset all
symbologies’
options to default values
Click to enable all symbologies
Click to disable all symbologies
Check the box to enable AIM ID prefix specific to symbology
10.4. Symbology settings
To find out more about the Symbology settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 38 -
Data Capture for Workforce
in Motion
Enable signature mode
Reference barcode – a barcode with this text will launch signature capture
X offset between the middle of the reference barcode and the capture area
Y offset between the middle of the reference barcode and the capture area
Ratio of the
barcode height to the narrow element width
Width of the signature capture area
Height of the signature capture area
Number of pixels that the reader outputs per each minimum bar width
Number of bits per pixel in the signature image
Image format (JPEG recommended)
Image file options
10.5. Signature/image configuration settings
This configuration window allows the user to set up the signature and picture mode options.
Please note that the signature and image modes are only available for
RoadRunners Evolution 2D readers with firmware versions 1.47 and newer.
The format of the image filename will be the following: AAA_Filename_BBB_CCC.jpg, where
BaracodaManager for PC – User Guide v3.39 - 39 -
AAA reader Bluetooth address (if the “Add reader Bluetooth address to filename” option is selected). This setting also applies to batch mode.
Filename – specified in the “Filename” text field BBB – PC timestamp (if the “Add PC timestamp to filename” is selected). The timestamp format is
YYMMDDHHMMSS. CCC reader timestamp (if the timestamp has been activated on the reader).
Data Capture for Workforce
in Motion
Please note that the above filename settings apply to real time mode only (with the exception of the “Add reader Bluetooth address to filename” option which also applies to batch mode). To set the batch mode
options, please refer to the “Batch mode settings” chapter.
BaracodaManager for PC – User Guide v3.39 - 40 -
Data Capture for Workforce
in Motion
Field
Functionality
Name
Bluetooth name of the RFID reader
Application
Version of embedded Baracoda software
RFID
Version of the RFID engine
Field
Functionality
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Field
Functionality
Battery
Battery level (0-100%) and its current charging status.
11. Baracoda TagRunners settings
The Settings window displays eight buttons and five groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Battery
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Battery field:
The following table shows the Other Settings buttons that you can set:
BaracodaManager for PC – User Guide v3.39 - 41 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
RFID Settings
Access types of RFID tags settings (see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
The table below shows the actions you can take with the buttons:
11.1. Batch mode settings
The Batch mode configuration displays three buttons and give the choice between:
1. Upload barcodes to a file
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
2. Upload barcodes to an application window
(for more information see the paragraph “Uploading data stored in batch mode”)
BaracodaManager for PC – User Guide v3.39 - 42 -
Data Capture for Workforce
in Motion
Check the box to activate Baracoda Header
Check the box to activate prefix/suffix
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
active fields.
Check the box to activate timestamp
Configure the number of RFID tags (0 or MAX) that are buffered by the reader (real time mode, reading tags while disconnected)
Check the box to activate beep when an RFID tag is decoded
Select beep volume (high or low)
Check the box to activate beep when an RFID tag is acknowledged by the host PC (when No data loss mode is active)
Select to allow duplicate scans
Select to disable duplicate scans (duplicates not decoded by the reader)
Select to disable duplicate scans (error beep when a duplicate RFID tag is read)
Select max BT power allowed by law in your country.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
Select to activate trigger mode of the RFID engine (default)
Select to activate autoscan or manual autoscan mode of the RFID engine
Select to activate smart autoscan mode of the RFID engine
11.2. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
11.3. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 43 -
Data Capture for Workforce
in Motion
Enable/disable Protocol ID transmission
Protocol ID table
11.4. RFID settings
The RFID Settings window has three different tab controls. The first one, named “General”, allows the user to activate/deactivate the Protocol ID transmission. When this option is active, every Tag ID will be prefixed by a symbol corresponding to the protocol of the read RFID tag. The list of available protocols is shown on the window:
BaracodaManager for PC – User Guide v3.39 - 44 -
Data Capture for Workforce
in Motion
Checkboxes show which keys are currently loaded. The first four A and B keys are reserved.
This button can be used to load the default keys and remove any keys set by the user from the reader’s memory.
This button can be used to load the selected key to the value set in the textbox.
These combo boxes can be used to select the index of the key to be loaded.
This text box can be used to set the value of the key to be loaded (max. 4 characters).
These controls change the format of the textbox (key value) to ASCII or Hex.
The second tab window of the RFID settings manages the NXP Mifare keys that are stored in the TagRunners memory:
The other tab windows, named “RFID Protocols”, can be used to enable/disable the type of RFID tags that will be read by the TagRunners reader.
To find out more about the RFID settings, please refer to the RFID reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 45 -
Data Capture for Workforce
in Motion
Field
Functionality
Application
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
RFID
Version of the RFID engine
Field
Functionality
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
12. Baracoda DualRunners settings
The Settings window displays nine buttons and six groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Battery
- Data capture mode
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
BaracodaManager for PC – User Guide v3.39 - 46 -
Data Capture for Workforce
in Motion
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Field
Functionality
Battery
Battery level (0-100%) and its current charging status.
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (see below)
RFID options
Access RFID settings
Signature/image configuration
Access the signature mode and picture mode configuration (only for 2D
readers with firmware version >= 1.47, see below)
Button
Functionality
Both
Activates both the barcode scan engine and the RFID engine.
RFID
Activates the RFID engine and turns off the barcode scan engine.
Barcode
Activates the barcode scan engine and turns off the RFID engine.
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Battery field:
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the Data capture mode radio buttons:
The table below shows the actions you can take with the buttons:
BaracodaManager for PC – User Guide v3.39 - 47 -
Data Capture for Workforce
in Motion
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
12.1. Batch mode settings
The Batch mode configuration displays three groups of controls:
- the “Upload barcodes/RFID tag IDs” group that lets the user specify whether the uploaded data will be
saved in a file or sent to an application window using keyboard emulation
o If the user chooses to save the uploaded data to a file, the filename can be specified in the
text field
- the “Upload file name generation” method group
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
- the “Image upload file name generation” method group that lets the user specify the file name to
which uploaded signature/image captures will be saved.
The format of the image filename will be the following:
AAA_Filename_BBB_CCC.jpg, where
AAA – reader’s Bluetooth address (if the “Add reader Bluetooth address to filename” checkbox has been
checked in Signature/image capture configuration settings)
Filename – filename specified in the “Image upload file name generation” group, BBB – PC timestamp (year, month, day, hour, minute, second, millisecond) CCC – reader timestamp (if the timestamp has been activated on the reader)
For more information see the paragraph “Uploading data stored in batch mode”.
BaracodaManager for PC – User Guide v3.39 - 48 -
Data Capture for Workforce
in Motion
Check the box to activate Baracoda Header
Check the box to activate prefix/suffix
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
active fields.
Check the box to activate timestamp
Configure the number of barcodes (0 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected)
Check the box to activate beep when data is read
Select beep volume (high or low)
Check the box to activate beep when a barcode is acknowledged by the host PC (when No data loss mode is active)
Select to allow duplicate scans
Select to disable duplicate scans (duplicates not decoded by the reader)
Select to disable duplicate scans (error beep when a duplicate barcode is read)
Select max BT power allowed by law in your country.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
Select to activate aiming trigger mode of the scan engine
Select to activate trigger mode of the scan engine (default)
Select to activate autoscan or smart or manual autoscan mode of the reader
Check the box to activate the data
nature byte (0 for barcodes and 1 for RFID tag IDs)
12.2. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
12.3. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 49 -
Data Capture for Workforce
in Motion
Select type of barcode to configure.
Select the max. length of decoded barcodes
Reset all
symbologies’
options to default values
Click to enable all symbologies
Click to disable all symbologies
Check the box to enable AIM ID prefix specific to symbology
12.4. Symbology settings
To find out more about the Symbology settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 50 -
Data Capture for Workforce
in Motion
Enable/disable Protocol ID transmission
Protocol ID table
12.5. RFID settings
The RFID Settings window has three different tab controls. The first one, named “General”, allows the user to activate/deactivate the Protocol ID transmission. When this option is active, every Tag ID will be prefixed by a symbol corresponding to the protocol of the read RFID tag. The list of available protocols is shown on the window:
BaracodaManager for PC – User Guide v3.39 - 51 -
Data Capture for Workforce
in Motion
Checkboxes show which keys are currently loaded. The first four A and B keys are reserved.
This button can be used to load the default keys and remove any keys set by the user from the reader’s memory.
This button can be used to load the selected key to the value set in the textbox.
These combo boxes can be used to select the index of the key to be loaded.
This text box can be used to set the value of the key to be loaded (max. 4 characters).
These controls change the format of the textbox (key value) to ASCII or Hex.
The second tab window of the RFID settings manages the NXP Mifare keys that are stored in the DualRunners memory:
The other tab windows, named “RFID Protocols”, can be used to enable/disable the type of RFID tags that will be read by the DualRunners reader.
To find out more about the RFID settings, please refer to the RFID reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 52 -
Data Capture for Workforce
in Motion
Enable signature mode
Reference barcode – a barcode with this text will launch signature capture
X offset between the middle of the reference barcode and the capture area
Y offset between the middle of the reference barcode and the capture area
Ratio of the
barcode height to the narrow element width
Width of the signature capture area
Height of the signature capture area
Number of pixels that the reader outputs per each minimum bar width
Number of bits per pixel in the signature image
Image format (JPEG recommended)
Image file options
12.6. Signature/image configuration settings
This configuration window allows the user to set up the signature and picture mode options.
Please note that the signature and image modes are only available for
DualRunners 2D readers with firmware versions 1.46 and newer.
The format of the image filename will be the following: AAA_Filename_BBB_CCC.jpg, where
BaracodaManager for PC – User Guide v3.39 - 53 -
AAA reader Bluetooth address (if the “Add reader Bluetooth address to filename” option is selected). This setting also applies to batch mode.
Filename – specified in the “Filename” text field BBB – PC timestamp (if the “Add PC timestamp to filename” is selected). The timestamp format is
YYMMDDHHMMSS. CCC reader timestamp (if the timestamp has been activated on the reader).
Data Capture for Workforce
in Motion
Please note that the above filename settings apply to real time mode only (with the exception of the “Add reader Bluetooth address to filename” option which also applies to batch mode). To set the batch mode
options, please refer to the “Batch mode settings” chapter.
BaracodaManager for PC – User Guide v3.39 - 54 -
Data Capture for Workforce
in Motion
Field
Functionality
Radio
Version of Bluetooth chipset
Decoder
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Batch
Set the batch mode: scanned barcodes are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection is not established the barcodes are lost, unless “Enable Buffering” is set (see below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
13. 2604 series settings (for BC2604, BL2604,
BLR2604)
The Settings window displays eight buttons and four groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
BaracodaManager for PC – User Guide v3.39 - 55 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (see below)
Advanced
Access advanced settings (only for developers working with Baracoda’s API)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
13.1. Batch mode settings
The Batch mode configuration displays three buttons and give the choice between:
1. Upload barcodes to a file
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
2. Upload barcodes to an application window
(for more information see the paragraph “Uploading data stored in batch mode”)
BaracodaManager for PC – User Guide v3.39 - 56 -
Data Capture for Workforce
in Motion
Check the box to activate Baracoda Header
Check the box to activate prefix/suffix
Configure reader’s User Interface when a barcode is read
Select reading mode
Configure the number of barcodes (1 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected)
Configure reader’s User Interface when a barcode is acknowledged
Configure reader’s User Interface when a barcode is queued before being acknowledged
Display the entire data format sent to the host device
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
Select max BT power allowed by law in your country.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
13.2. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
13.3. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 57 -
Data Capture for Workforce
in Motion
Check the box to enable decoding, uncheck the box to disable decoding of selected type of barcode .
Select type of barcode to configure.
Configure reader’s User Interface when a barcode is queued before being acknowledged (negative ack)
13.4. Symbology settings
To find out more about the Symbology settings, please refer to the barcode reader User Manual.
13.5. Advanced settings
These settings are useful only to developers writing their own plugin (using the Baracoda API) who desire that their application send positive and negative acknowledgements to the barcode reader for every barcode received.
BaracodaManager for PC – User Guide v3.39 - 58 -
Data Capture for Workforce
in Motion
Field
Functionality
Radio
Version of Bluetooth chipset
Decoder
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
When connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is connected and without any activity.
When not connected
Set the delay (in minutes) after which the barcode reader switches off, when the barcode reader is not connected and without any activity.
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
14. BCM2604 settings
The Settings window displays five buttons and four groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Other Settings buttons that you can set:
BaracodaManager for PC – User Guide v3.39 - 59 -
Data Capture for Workforce
in Motion
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Check the box to activate Baracoda Header
Check the box to activate prefix/suffix
Display the entire data format sent to the host device
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
active fields.
Configure the number of barcodes (1 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected)
Select max BT power allowed by law in your country.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
The table below shows the actions you can take with the buttons:
14.1. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
14.2. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 60 -
Data Capture for Workforce
in Motion
Field
Functionality
Decoder
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Radio
Version of Bluetooth radio
Boot
Version of bootloader
Field
Functionality
Real time
Set the Real-time mode: scanned barcodes are transmitted to the application immediately when the Bluetooth radio connection is active. If the connection
is not established the barcodes are lost, unless “Enable Buffering” is set (see
below).
Master
Set the Master mode: The barcode reader automatically creates connection to the specified Host device when the user scans a barcode. Then the reader works as in real time mode.
Host addr.
For use in Master mode : Set, in the address field, the Bluetooth address of the host device the reader has to connect to.
Field
Functionality
Shutdown timer
Set the delay (in minutes) after which the barcode reader switches off without any activity.
Field
Functionality
Battery
Battery level (OK or low).
15. Baracoda ToughRunners and ScanWear settings
The Settings window displays eight buttons and five groups:
- General information
- Current Operating Mode information
- Shutdown Timer information
- Battery
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Operating Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the Battery field:
BaracodaManager for PC – User Guide v3.39 - 61 -
Data Capture for Workforce
in Motion
Button
Functionality
Product
Access product settings (see below)
Bluetooth
Access Bluetooth connection settings (see below)
Symbology
Access types of barcodes settings (see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Default Settings
Restore the factory settings. The barcode reader (flash) memory is erased and the factory default parameters are restored. Check the device manual for details.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
Check the box to activate Baracoda Header
Fill in text to activate prefix/suffix
Check the box to Activate no data loss
mode (acknowledgement)
When Prefix/Suffix box is checked, select Data format (ASCII or Hex) and type values in
Configure the number of barcodes (0 or MAX) that are buffered by the reader (real time mode, reading barcodes while disconnected). Not available yet.
Check the box to activate beep when a barcode is decoded
Select to activate reader vibration
Select to set the reading mode of the scan engine (default trigger)
Check the box to activate beep when a barcode is acknowledged by the host PC (when No data loss mode is active)
Select to set the trigger level of wrist motion necessary to launch an automatic scan
Select to set the no duplicate mode of the reader (by default duplicates are allowed)
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
15.1. Product settings
To find out more about the product settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 62 -
Data Capture for Workforce
in Motion
Select max BT power allowed by law in your country.
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
Check the box to enable AIM ID prefix specific to symbology
Select type of barcode to configure.
15.2. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
15.3. Symbology settings
To find out more about the Symbology settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 63 -
Data Capture for Workforce
in Motion
Field
Functionality
Decoder
Version of embedded Baracoda software
Name
Bluetooth name of the barcode reader
Field
Functionality
Batch
Set the batch mode: tags read when the reader is disconnected are stored in non-volatile memory and can be uploaded to the application later (click on “Batch config” for more advanced settings)
No batch
Set the no batch mode: tags read when the reader is disconnected are lost.
Field
Functionality
Device shutdown
Set the delay (in minutes) after which the barcode reader switches off without any activity.
RFID shutdown
Set the delay (in seconds) that the reader allocates for the user to read an RFID tag after the reader button has been pressed.
Field
Functionality
None
Disable the engine reading RFID tags.
ISO 156693
Only ISO tags will be read.
Tag-IT HF
Only IT HF tags will be read.
16. IdBlue settings
The Settings window displays eight buttons and five groups:
- General information
- Disconnected Mode information
- Shutdown Timer information
- RF Protocol
- Battery
- Other Settings
The following two tables show the General information fields:
The table below shows the user the Disconnected Mode options that they can set:
The following table shows the Shutdown Timer fields that you can set:
The following table shows the RF Protocol field:
BaracodaManager for PC – User Guide v3.39 - 64 -
Data Capture for Workforce
in Motion
Field
Functionality
Battery
Battery level (OK or recharge battery).
Button
Functionality
Bluetooth
Access Bluetooth connection settings (see below)
Button
Functionality
Cancel
Close window with no changes.
Save
Store and send the new parameters to the barcode reader.
Upgrade
Ugrade the reader’s firmware. Please check Chapter 16 for details.
Button
Functionality
Browse
Choose a file name and path to store the barcodes
OK
Close Batch configuration window without saving any modifications
Cancel
Save the modifications and close Batch configuration window
The following table shows the Battery field:
The following table shows the Other Settings buttons that you can set:
The table below shows the actions you can take with the buttons:
16.1. Batch mode settings
The Batch mode configuration displays three buttons and give the choice between:
1. Upload barcodes to a file
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
2. Upload barcodes to an application window
(for more information see the paragraph “Uploading data stored in batch mode”)
BaracodaManager for PC – User Guide v3.39 - 65 -
Data Capture for Workforce
in Motion
Check the box to activate PIN code authentication
Select the duration of Sniff period
Reader’s PIN code,
used when Security is enabled
16.2. Bluetooth settings
To find out more about the Bluetooth settings, please refer to the barcode reader User Manual.
BaracodaManager for PC – User Guide v3.39 - 66 -
Data Capture for Workforce
in Motion
17. Uploading data stored in batch mode
This feature is supported by all readers with the exception of the BL1000, BCM2604 and some D-Fly (with firmware v1.54 and newer) reader models. Select a connected reader in the “My Paired Devices” list and click the Upload button to upload the stored barcodes.
Users can set the batch settings to one of the following options:
- Upload data to file (default option)
o Always upload to the same file, overwriting the previous content (“Overwrite last upload file”) o Append data to last upload file (default) o Generate a different file name for every upload (“Add timestamp to file name”)
- Upload barcodes to application window
At the beginning of the upload operation a modal popup is shown:
This message will be displayed as long as the upload operation is in progress. When all barcodes have been uploaded, the user will be shown a confirmation popup:
Note: the reader will emit an acknowledgement beep when the upload has completed.
If the “Upload barcodes to application window” option has been chosen, after clicking Upload, the following message will be shown:
The user should make sure their application is active, then click on the pop up and immediately go back to the application where they want the barcodes to be uploaded.
Note: the upload operation can be launched by scanning the corresponding barcode from their programming guide. The reader should be connected to the BaracodaManager before this is done.
BaracodaManager for PC – User Guide v3.39 - 67 -
Data Capture for Workforce
in Motion
18. Firmware upgrade
This function is supported by all Baracoda readers with the exception of the the 2604 series and the BCM 2604. In order to upgrade their reader, the user should select a connected barcode reader in the “My Paired Devices” list and click the Settings button. Next, they should click on the Upgrade button.
As soon as the button has been clicked, an open-file dialog window is shown. The user should browse for the upgrade file:
Current upgrade files can be found in the partners section of the www.baracoda.com website (registration is necessary). Any additional notes/instructions can be found in those files.
BaracodaManager for PC – User Guide v3.39 - 68 -
Data Capture for Workforce
in Motion
When the upgrade file has been specified, the BaracodaManager activates a modeless topmost window showing the progress of the upgrade operation:
The user should not try to close this window or click any BaracodaManager buttons or other GUI controls as long as the above dialog is visible. When the upgrade operation has been completed, the user is shown the following popup:
Most readers (Pencil2, D-Fly, Roadrunners Evolution) turn themselves on automatically when they are ready to be used. The Roadrunners and Pencil need to be turned on (they turn themselves off when the upgrade operation is over).
Note: the upgrade process of the Baracoda Pencil reader is a little different from the schema presented above. The Pencil needs to have its firmware erased first and only afterwards can it be upgraded. The newest upgrade
file (BPU_1_5.bpu) for the Baracoda Pencil reader can be found in the “upgrade” subdirectory of the
BaracodaManager installation directory (by default “C:\Program Files\Baracoda Manager”). The BaracodaManager automatically detects if the reader’s firmware needs to be erased (first upgrade operation)
or if it can already be upgraded (second and final upgrade operation).
BaracodaManager for PC – User Guide v3.39 - 69 -
Data Capture for Workforce
in Motion
19. Plugins
19.1. Terminal plugin
The Terminal function allows the user to display scanned barcode(s) when the reader is connected in Real Time mode.
BaracodaManager for PC – User Guide v3.39 - 70 -
Data Capture for Workforce
in Motion
19.2. KEmul plugin
The KEmul function is to emulate keyboard strokes corresponding to scanned barcodes. With KEmul the user can send the barcode scanned by the barcode reader to the selected field of their application. For example, they can store the barcodes in an MS Excel or MS Word file.
By clicking on the KEmul icon in the system tray with the right mouse button and selecting Configuration, the user can configure a predefined prefix and/or suffix for data coming from the reader(s):
The KEmul plugin works also via Terminal Server sessions.
BaracodaManager for PC – User Guide v3.39 - 71 -
Data Capture for Workforce
in Motion
19.3. IdBlue plugin
This plugin can be used to read and write RFID tag data. The KEmul or Terminal plugins receive only the Tag ID from the IdBlue reader. The Read and Write buttons allow the user to read and write tag data and the other button (Help) shows a window with a description of the reading/writing procedure.
BaracodaManager for PC – User Guide v3.39 - 72 -
Data Capture for Workforce
in Motion
19.4. BTR_BSW plugin
This plugin shows that the Baracoda ToughRunners/ScanWear readers can scan barcodes when sent a special
command (described in their protocol guide). When the user clicks the “Scan a barcode” button, the reader will
turn on the scan engine. If a barcode can be decoded, it will be shown on the plugin window. This plugin can be used for demonstration purposes.
BaracodaManager for PC – User Guide v3.39 - 73 -
Data Capture for Workforce
in Motion
Select the tag protocol or use Any (plugin will detect the protocol)
Use this button to read the tag data
Use this button to write data to the tag
Use this button to import data from a file to the tag
Use this button to export data from the tag to a file
Status log
Use this button to clear the status log
Current tag protocol
Tag contents
Show only successful operations in the status log
Show operations in real time in the status log
19.5. RFID Plugin
This plugin can be used to read and write the contents of an RFID tag with a TagRunners or DualRunners reader. The user should select the tag type in the combo box at the top of the window or leave the option on Any if they are not sure what protocol the RFID tag supports. When the tag is read, its protocol will be shown just above the status text field.
In order to save the contents of the tag to a file, please use the “Export data” button. If the user wants to write to the tag the contents of a file, they should use the “Import data” option.
BaracodaManager for PC User Guide v3.39 - 74 -
Data Capture for Workforce
in Motion
19.6. PicturePlugin
The PicturePlugin can be used to capture signatures or take pictures with the RoadRunners Evolution 2D or DualRunners 2D readers having a firmware version 1.47 or newer.
Please note that before the reader can capture a signature, it should be configured (refer to section
Signature/image configuration settings for the RoadRunners Evolution 2D and Signature/image configuration settings for DualRunners 2D) and in real time mode (not in batch mode).
The following screenshot shows the main window of the PicturePlugin:
As soon as the user reads the signature reference barcode, the captured signature area will be shown in the middle of the window. The image can be saved with the Save data button (in jpeg format).
In order to start to take a picture, the user will need to either scan the Take Picture barcode (please refer to the user Guide of the reader to find this barcode) or click the Take picture button on the plugin’s main window. In response the reader will turn on the beam and the user will need to press the trigger button to take the picture. The resulting picture will also be shown in the middle of the screen.
BaracodaManager for PC – User Guide v3.39 - 75 -
Loading...
