Data Capture

ToughRunners / ScanWear

for Workforce

in Motion

Communication Protocol

©Baracoda TM – May 2009

Data Capture

for Workforce

in Motion

SUMMARY

SUMMARY ................................................................... 2

REVISION HISTORY .......................................................... 3

INTRODUCTION: GENERIC PACKET FORMAT ................................. 4

COMMAND ID SUMMARY .................................................. 5

COMMAND DETAILS ..................................................... 8

3.1.

3.2.

3.3.

3.4.

3.5.

3.6.

3.7.

3.8.

3.9.

3.10. C

3.11. P

ETTING MODE

PERATIONAL STATISTICS

RIST MOTION DETECTION LEVEL (FOR

ESTORE DEFAULT SETTINGS

MMI

SETTINGS

LUETOOTH COMMANDS

EADING AND TRIGGERING COMMANDS

ECODER COMMANDS

ATA FORMAT COMMANDS OMMUNICATION COMMANDS OWER SAVING COMMANDS

......................................................... 8

................................................. 8

BSW

ONLY

) ............................... 9

.............................................. 10

....................................................... 10

................................................... 12

........................................ 13

.................................................... 17

................................................. 19

................................................ 24

................................................ 25

4.1.

4.2.

4.3.

4.4.

5.1.

5.2.

SPECIAL PACKETS .................................................... 27

EPRECATED PACKETS

CKNOWLEDGMENT PACKETS

PECIAL SCANNER TO HOST MESSAGES

PECIAL HOST TO SCANNER MESSAGES

APPENDIX A: BLUETOOTH PROTOCOL. .................................... 29

HE CONFIGURATION FRAMES ARE AS FOLLOWS

OMMANDS

APPENDIX B: DECODER PROTOCOL. ...................................... 38

: .......................................................... 29

................................................... 27

................................................ 27

........................................ 28

: ................................. 29

ToughRunners / ScanWear – Communication Protocol v1.2 - 2 -

Data Capture

Revision History

Changes to the original manual are listed below.

Document Date Description

1.0 25th Sep. 07 Initial release

1.1 16th Dec. 08 Graphic Presentation updated

1.2 15th May 09 Updated for firmware version 4.00.6

for Workforce

in Motion

ToughRunners / ScanWear – Communication Protocol v1.2 - 3 -

Data Capture

for Workforce

in Motion

Introduction: generic packet format

All the frames described in this document are formatted as shown (*):

STX Frame # Nbr of cmds Command 1 … Command x Checksum ETX

1 byte 1 byte 1 byte 3  n bytes … 3  n bytes 1 byte 1 byte

Command ID Data length data

1 byte 1 byte x bytes

Ba) 1 Byte : STX Bb) 1 Byte : Frame number Bc) 1 Byte : Number of commands (or number of commands responses) Bd) 3..n Bytes : Command 1 … Bx) 3..n Bytes : Command x …

By) 1 Byte : CheckSum = (

Bz) 1 Byte : ETX

Each command is formatted as follows: Ca) 1 Byte : Command ID Cb) 1 Byte : Data length Cc) 0..n Bytes : Data

(*): a limited number of frames do not follow this format. They are described in the section 2/.

∑

=xbi

) mod 256

ToughRunners / ScanWear – Communication Protocol v1.2 - 4 -

Data Capture

Command ID summary

The commands are sorted by category (4 MSB of Command ID):

0x0? Scanner control commands

0x01 Enter "Setting Mode"

0x02 Exit "Setting Mode"

0x03 Launch autotest // RESERVED

0x04 Endurance (AutoScan) test setting // RESERVED

0x05 Retrieve operational statistics

0x06 Reset operational statistics

for Workforce

in Motion

0x07 Get wrist motion detection level

0x08 Set wrist motion detection level

0x0E firmware presence flag // RESERVED

0x0F Restore default settings

0x1? RESERVED

0x2? Firmware upgrade commands // RESERVED

0x27 Start programming (application AT89C51ED2)

0x28 End programming

0x29 Clear firmware

0x2A Read 128Byte bloc

0x2B Write 128Byte bloc

0x2C Verify checksum

0x2D Read Boot cartouche

0x2E Read Application cartouche

0x2F Switch to download mode

ToughRunners / ScanWear – Communication Protocol v1.2 - 5 -

Data Capture

0x3? RESERVED

0x4? MMI commands

0x40 Get vibrator

0x41 Set vibrator

0x42 Get beeps (since version 3.01.00)

0x43 Set beeps (since version 3.01.00)

0x5? Bluetooth commands

0x5E Bluetooth module commands

for Workforce

in Motion

0x6? Reading and triggering commands

0x60 Get reading mode

0x61 Set reading mode

0x62 Get remote triggering settings

0x63 Set remote triggering settings

0x7? RESERVED

0x8? Decoder commands

0x80 Get symbology settings

0x81 Set symbology settings

0x82 Get voting value

0x83 Set voting value

0x84 Get scan beam timeout

0x85 Set scan beam timeout

0x9? RESERVED

ToughRunners / ScanWear – Communication Protocol v1.2 - 6 -

Data Capture

0xA? Data format commands

0xA2 Get symbology prefix

0xA3 Set symbology prefix

0xA4 Get data suffix

0xA5 Set data suffix

0xA6 Get data prefix

0xA7 Set data prefix

0xA8 Get AIM symbology ID transmission

0xA9 Set AIM symbology ID transmission

for Workforce

in Motion

0xAA Get symbology suffix

0xAB Set symbology suffix

0xB? RESERVED

0xC? RESERVED

0xD? Communication commands

0xD5 Get Radio behavior when in charge

0xD6 Set Radio behavior when in charge

0xE? RESERVED

0xF? Power saving commands

0xF0 Get shutdown timers

0xF1 Set shutdown timers

0xF2 Get battery status

ToughRunners / ScanWear – Communication Protocol v1.2 - 7 -

Data Capture

0x01

0x02

0x05

AAAABBBBCC

Command details

3.1. Setting mode

Command ID

Description Enter Setting mode

Length 0

payload none

Response 0 (1 = ERROR)

Command ID

Description Exit Setting mode

Length 0

for Workforce

in Motion

payload none

Response 0 (1 = ERROR)

A radio disconnection leads to an exit from this setting mode.

3.2. Operational statistics

Command ID

Description Retrieve operational statistics

Length 0

payload none

Response

10 bytes :

where :

AAAA = Number of scans done

BBBB = Operating time (minutes)

CC = Number of charge cycles done (MSB first)

ToughRunners / ScanWear – Communication Protocol v1.2 - 8 -

Data Capture

0x06

AAAABBBBCC

0x07

0x08

Command ID

Description Reset operational statistics

Length 10

payload

Response 0 (1 = ERROR)

10 bytes :

where :

AAAA = Number of scans done

BBBB = Operating time (minutes)

CC = Number of charge cycles done (MSB first)

for Workforce

in Motion

3.3. Wrist motion detection level

Command ID

Description Get wrist motion detection level

Length 0

payload none

Response 1 byte :

A = 0, 1 or 2

0 = medium, 1 = easy, 2 = hard

Default setting = 1 (easy)

Command ID

Description Set wrist motion detection level

Length 1

(for BSW only)

payload

Response 0 (1 = ERROR)

ToughRunners / ScanWear – Communication Protocol v1.2 - 9 -

= 0, 1 or 2

0 = medium, 1 = easy, 2 = hard

Data Capture

0x0F

0x40

ABC

0x41

ABC

for Workforce

3.4. Restore default settings

Command ID

Description Restore factory default settings (reboots scanner)

Length 1

payload

Response none

= 0

3.5. MMI settings

Command ID

Description Get vibrator

Length 0

in Motion

payload none

Response

where :

A = Vibration duration on BAD READ event

B = Vibration duration on BARCODE LOST event

C = Vibration duration on NACK event

Durations in 1/10 sec

Default settings:

0x0A 0x0A 0x0A

Command ID

Description Set vibrator

Length 3

payload

where :

A = Vibration duration on BAD READ event

ToughRunners / ScanWear – Communication Protocol v1.2 - 10 -

Data Capture

0x42

(Since version 3.01.00)

0x43

(Since version 3.01.00)

= Vibration duration on BARCODE LOST event

C = Vibration duration on NACK event

Durations in 1/10 sec

Response 0 (1 = ERROR)

Command ID

Description Get beeps

Length 0

payload none

Response 1 byte:

for Workforce

in Motion

Bit A.0 = 0  enable barcode decoded beep, 1  disable barcode decoded beep

Bit A.1 = 0  enable barcode acknowledgement beep,  disable barcode acknowledgement beep

Default settings:

0x00

Command ID

Description Set beeps

Length 1

payload 1 byte:

Bit A.0 = 0  enable barcode decoded beep, 1  disable barcode decoded beep

Response 0 (1 = ERROR)

ToughRunners / ScanWear – Communication Protocol v1.2 - 11 -

Bit A.1 = 0  enable barcode acknowledgement beep,  disable barcode acknowledgement beep

Data Capture

0x5E

{Code ID} {length}

for Workforce

in Motion

3.6. Bluetooth commands

Command ID

Description Bluetooth Commands

Length Variable (1-255)

payload {Code ID} {length} “Parameters”

Response If the device responds:

“Response”

Else: {0}

Bluetooth specific commands from the Bluetooth communication protocol are to be framed within the payload of this message. See Appendix A for more details.

The default Bluetooth settings are the BT module’s default settings, excepted the BT name which default value must be handled by the firmware:

ToughRunners : “ToughRunners xx xx” Scanwear : “ScanWear xx xx”

xx xx being the 4 last readable characters of the BDA written in hexadecimal (two last bytes of BDA).

Example : “Get PIN Code”

Command :

Ba) 0x02 : STX Bb) 0x00 : Frame number Bc) 0x01 : Number of commands (or number of commands responses) Bd) : Command

Bd1) 0x5E : Command ID Bd2) 0x03 : Data length Bd3) : Data

) 0x07 : Get PIN Code

d31

) 0x00 : Length MSB

d32

) 0x00 : Length LSB

d33

Be) 0x69 : CheckSum = (

Bf) 0x03 : ETX

Response:

Ba) 0x02 : STX Bb) 0x00 : Frame number Bc) 0x01 : Number of commands (or number of commands responses) Bd) : Command

ToughRunners / ScanWear – Communication Protocol v1.2 - 12 -

∑

=ebi

Bd1) 0x5E : Command ID Bd2) 0x07 : Data length

) : Data

) 0x07 : Get PIN Code

d31

) mod 256

Data Capture

0x60

ABCDEFGHI

) 0x00 : Length MSB

d32

) 0x04 : Length LSB

d33

) 0x30 : PIN Code 0

d34

) 0x30 : PIN Code 1

d35

) 0x30 : PIN Code 2

d36

) 0x30 : PIN Code 3

d37

Be) 0x31 : CheckSum

= (

= 0x01+0x5E+x007+0x07+0x04+0x00

= 0x131 mod 0x100 = 0x31

Bf) 0x03 : ETX

) mod 256

∑

=xbi

+0x30+0x30+0x30+0x30 mod 0x100

3.7. Reading and triggering commands

Command ID

for Workforce

in Motion

Description Get reading mode

Length 0

payload none

Response

where :

A = long press action (1 sec.):

------00 : Disabled

------01 : Hold laser beam

------10 : Shut down scanner

------11 : Start Multiscan Session

B = simple press action :

------00 : Disabled

------01 : Simple scan

------10 : Start Multiscan Session

---1---- : Stop Multiscan Session

C = wrist motion action :

------00 : Disabled

ToughRunners / ScanWear – Communication Protocol v1.2 - 13 -

Data Capture

for Workforce

in Motion

------01 : Simple scan

------10 : Start Multiscan Session

---1---- : Stop Multiscan Session

D = long press duration x 100ms

E = maximum scans in session:

-0000000 : unlimited

-XXXXXXX : number of scans in the session

1------- : Anti-doubloon in the session

F = Inter-scan interval x100ms

G = 0

H = 0

I = 0

Default settings :

ScanWear : 0x00 0x01 0x01 0x0A 0x00 0x0A 0x00 0x00 0x00 ToughRunners :0x01 0x01 0x01 0x0A 0x00 0x0A 0x00 0x00 0x00

ToughRunners / ScanWear – Communication Protocol v1.2 - 14 -

Data Capture

0x61

ABCDEFGHI

Command ID

Description Set reading mode

Length 9

payload

where :

A = long press action (1 sec.):

------00 : Disabled

------01 : Hold laser beam

------10 : Shut down scanner

------11 : Start Multiscan Session

for Workforce

in Motion

B = simple press action :

------00 : Disabled

------01 : Simple scan

------10 : Start Multiscan Session

---1---- : Stop Multiscan Session

C = wrist motion action :

------00 : Disabled

------01 : Simple scan

------10 : Start Multiscan Session

---1---- : Stop Multiscan Session

D = long press duration x 100ms

E = maximum scans in session:

-0000000 : unlimited

-XXXXXXX : number of scans in the session

1------- : Anti-doubloon in the session

F = Inter-scan interval x100ms

ToughRunners / ScanWear – Communication Protocol v1.2 - 15 -

Data Capture

0x62

ABCDEFG

= 0

H = 0

I = 0

Response 0 (1 = ERROR)

Command ID

Description Get remote triggering settings

Length 0

payload none

Response

for Workforce

in Motion

where :

A = character to trigger a Good Read signal

B = character to trigger a Good Read signal

C = character to trigger a Simple Scan

D = character to start an Multiscan Session

E = character to stop an Multiscan Session

F = character to lock the scan engine

G = character to unlock the scan engine

Default settings :

0xA1 0xA2 0xB1 0xB2 0xB3 0xC1 0xC2

ToughRunners / ScanWear – Communication Protocol v1.2 - 16 -

Data Capture

0x63

ABCDEFG

0x80

(cf. Appendix

If length = 0 then 17 bytes, if length = 1 then 20

Command ID

Description Set remote triggering settings

Length 7

payload

where :

A = character to trigger a Good Read signal

B = character to trigger a Good Read signal

C = character to trigger a Simple Scan

D = character to start an Multiscan Session

E = character to stop an Multiscan Session

for Workforce

in Motion

F = character to lock the scan engine

G = character to unlock the scan engine

Response 0 (1 = ERROR)

3.8. Decoder commands

Command ID

Description Get symbology settings

Length 0 or 1

payload none

Response 17 or 20 bytes (since version 3.02.03)

B for more details)

bytes

Default value:

0xB4 0x90 0xEF 0x20 0x36 0x00 0x00 0x00 0x77 0x00 0x00 0x00 0xE3 0x2F 0x08 0x00 0x1D

ToughRunners / ScanWear – Communication Protocol v1.2 - 17 -

Data Capture

0x81

0x82

0x83

0x84

0x85

Command ID

Description Set symbology settings

Length 20 (since version 3.02.03)

payload cf. Appendix B for details

Response 0 (1 = ERROR)

Command ID

Description Get voting value

Length 0

payload none

for Workforce

in Motion

Response

Command ID

Description Set voting value

Length 1

payload

Response 0 (1 = ERROR)

Command ID

Description Get scan beam timeout

Length 1

= number of decodes to validate a good scan

Default value = 1

= number of decodes to validate a good scan

payload

Response 0 (1 = ERROR)

Command ID

Description Set Scan beam timeout

ToughRunners / ScanWear – Communication Protocol v1.2 - 18 -

= timeout in seconds (255 = Autoscan mode)

Default value = 3

Data Capture

0xA2

(if length =

Length 1

payload

Response 0 (1 = ERROR)

= timeout in seconds (255 = Autoscan mode)

3.9. Data format commands

Command ID

Description Get symbology prefix

Length 0 or 1

payload None

Response 22 or 28 bytes (since version 3.02.03)

0 then 22 bytes, if length = 1 then 28 bytes):

for Workforce

in Motion

AABBCCDDEEFFGGHHIIJJKKLLMMNN

Where:

AA = Code39

BB = Interleaved 2 of 5

CC = Standard 2 of 5

DD = Codabar

EE = EAN/UPC

FF = Code128

GG = MSI

HH = PLESSEY

II = Code93

JJ = EAN128

ToughRunners / ScanWear – Communication Protocol v1.2 - 19 -

KK = Codablock F

LL = RSS 14 (GS1 Databar)

MM = RSS Ltd (GS1 Databar Ltd)

NN = RSS Expanded (GS1 Databar Expanded)

0x00 means disabled.

Data Capture

0xA3

AABBCCDDEEFFGGHHIIJJKK

LLMMNN

Default settings :

0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00

Command ID

Description Set symbology prefix

Length 28 (since version 3.02.03)

payload

Where:

AA = Code39

for Workforce

in Motion

BB = Interleaved 2 of 5

CC = Standard 2 of 5

DD = Codabar

EE = EAN/UPC

FF = Code128

GG = MSI

HH = PLESSEY

II = Code93

JJ = EAN128

KK = Codablock F

LL = RSS 14 (GS1 Databar)

MM = RSS Ltd (GS1 Databar Ltd)

Response 0 (1 = ERROR)

ToughRunners / ScanWear – Communication Protocol v1.2 - 20 -

NN = RSS Expanded (GS1 Databar Expanded)

0x00 means disabled.

Data Capture

0xA4

suffix

0xA5

suffix

0xA6

prefix

0xA7

prefix

Command ID

Description Get data suffix

Length 0

payload None

Response

Command ID

Description Set data suffix

Length 0-32

payload

0-32 bytes:

Default settings :

No suffix

for Workforce

in Motion

Response 0 (1 = ERROR)

Command ID

Description Get data prefix

Length 0

payload None

Response

Command ID

0-32 bytes:

Default settings :

No prefix

Description Set data prefix

Length 0-32

payload

Response 0 (1 = ERROR)

ToughRunners / ScanWear – Communication Protocol v1.2 - 21 -

Data Capture

0xA8

0xA9

0xAA

(if length =

Command ID

Description Get AIM symbology ID transmission

Length 0

payload None

Response

0 = disabled

1 = enabled

Default settings :

A = 0

for Workforce

in Motion

Command ID

Description Set AIM symbology ID transmission

Length 1

payload

Response 0 (1 = ERROR)

Command ID

Description Get symbology suffix

Length 0 or 1

payload None

Response 22 or 28 bytes (since version 3.02.03)

0 = disabled

1 = enabled

0 then 22 bytes, if length = 1 then 28 bytes):

ToughRunners / ScanWear – Communication Protocol v1.2 - 22 -

AABBCCDDEEFFGGHHIIJJKKLLMMNN

Where:

AA = Code39

BB = Interleaved 2 of 5

Data Capture

0xAB

AABBCCDDEEFFGGHHIIJJKK

LLMMNN

for Workforce

in Motion

= Standard 2 of 5

DD = Codabar

EE = EAN/UPC

FF = Code128

GG = MSI

HH = PLESSEY

II = Code93

JJ = EAN128

KK = Codablock F

LL = RSS 14 (GS1 Databar)

MM = RSS Ltd (GS1 Databar Ltd)

NN = RSS Expanded (GS1 Databar Expanded)

0x00 means disabled.

Default settings : 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00

0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00

Command ID

Description Set symbology suffix

Length 28 (since version 3.02.03)

payload

Where:

ToughRunners / ScanWear – Communication Protocol v1.2 - 23 -

AA = Code39

BB = Interleaved 2 of 5

CC = Standard 2 of 5

DD = Codabar

Data Capture

0xD5

0xD6

for Workforce

in Motion

= EAN/UPC

FF = Code128

GG = MSI

HH = PLESSEY

II = Code93

JJ = EAN128

KK = Codabloc F

LL = RSS 14 (GS1 Databar)

MM = RSS Ltd (GS1 Databar Ltd)

NN = RSS Expanded (GS1 Databar Ltd)

0x00 means disabled.

Response 0 (1 = ERROR)

3.10. Communication commands

Command ID

Description Get radio behavior when in charge

Length 0

payload None

Response 1 byte:

Bit A.0 = 1 if switch to slave when charging

Bit A.1 = 1 if switch radio off when charging

Default settings :

A = 0x01

Command ID

Description Set radio behavior when in charge

ToughRunners / ScanWear – Communication Protocol v1.2 - 24 -

Data Capture

A.0

0xF0

0xF1

AABBCCU

Length 1

payload

Response 0 (1 = ERROR)

Bit

Bit A.1 = 1 if switch radio off when charging

= 1 if switch to slave when charging

3.11. Power saving commands

Command ID

Description Get shutdown timers

Length 0

payload None

Response 7 bytes:

for Workforce

in Motion

AABBCCU

Where:

AA = scanner shutdown timer (sec.)

BB = radio shutdown timer when in Master mode (sec.)

CC = radio shutdown timer when in Slave mode (sec.)

U = 0 (unused)

Default settings : 0x04 0xB0 0x04 0xB0 0x04 0xB0 0x00

Command ID

Description Set shutdown timers

Length 7

payload

Where:

AA = scanner shutdown timer (sec.)

BB = radio shutdown timer when in Master mode (sec.)

ToughRunners / ScanWear – Communication Protocol v1.2 - 25 -

Data Capture

0xF2

= radio shutdown timer when in Slave mode (sec.)

U = 0 (unused)

Response 0 (1 = ERROR)

Command ID

Description Get battery status

Length 0

payload None

Response 1 byte:

Bits A.0-6 = battery level (RFU)

for Workforce

in Motion

Bit A.7 = 1  low battery

ToughRunners / ScanWear – Communication Protocol v1.2 - 26 -

Data Capture

Code ID

Description

frame

Code ID

Description

frame

Code ID

Description

Frame

for Workforce

in Motion

Special packets

These packets do not follow the above frame format.

4.1. Deprecated packets

0x01 Legacy 1 1 1 or 1 2 1

These 2 sequences will be recognized and purged for backward compatibility with older Baracoda products.

4.2. Acknowledgment packets

0x06 ACK 0x06 1 X

0x15 NAK 0x15 1 X

These messages acknowledge the reception of a valid message with the expected sequence number X, before processing it. For captured data from the scanner, ACK and NAK have the same meaning but will trigger a different event on the scanner.

0x16 SYN 0x16 1 X

This message acknowledges the reception of a message to acknowledge with an unexpected sequence number. X is the expected sequence number. The device will resynchronize its remote sequence number when receiving this message.

From this point, all the frames described in this section 2/ are formatted as shown:

Code ID length Payload

1 byte 2 bytes -

 1 byte for code ID

o Bits 7:5 is the logical device o Bits 4:1 is the command o Bit 0: when set, the message must be acknowledged

 2 bytes for the size of the payload (big-endian), including the sequence number byte which is

considered as part of the payload

 Payload (including 1 byte for sequence number when applicable).

The response will have the same code ID as the command.

ToughRunners / ScanWear – Communication Protocol v1.2 - 27 -

Data Capture

Code ID

Description

Payload

Code ID

Description

Payload

Response

Code ID

Description

Payload

Response

Code ID

Description

Payload

Response

4.3. Special scanner to host messages

0x32–0x33 Barcode data Barcode string

4.4. Special host to scanner messages

0x46-0x47

Get Capture Frame Format

None

1 byte

{0 = Baracoda, 1 = Baracoda + ACK, 2 = Raw}

for Workforce

in Motion

Default settings = 0

0x48-0x49

Set Capture Frame Format

1 byte

{0 = Baracoda, 1 = Baracoda + ACK, 2 = Raw}

1 byte:

{Bit 0: Success}

0x76-0x77

Get Product Version

None

x bytes :

«Baracoda ScanWear…» / «Baracoda ToughRunners…»

ToughRunners / ScanWear – Communication Protocol v1.2 - 28 -

Data Capture

Command

Header

Length

Payload

Answer

Set PinCode

0x01

xx xx

N digits PIN.

01 00 01 01 if done

Command

Header

Length

Payload

Answer

Get PinCode

0x07

00 00

N digits PIN. (D

efault

“0000”)

0x07 {PinCode size} {Pincode}

Command

Header

Length

Payload

Answer

Set Name

0x02

xx xx

New name

0x02 00 01 01 if done

Command

Header

Length

Payload

Answer

Get Name

0x08

00 00

0x08 {name size} {name}

Command

Header

Length

Payload

Answer

Set mode

0x03

00 01

0x0

1 if MASTER, 0x00 if SLAVE

0x03 00 01 01 if done

Appendix A: Bluetooth Protocol.

5.1. The configuration frames are as follows:

Header Length Payload

1 byte 2 bytes(MSB, LSB) 0 to 65535 bytes

5.2. Commands:

(new pin size)

Max Pin length=16

(Default “0000”)

for Workforce

in Motion

0x01 00 01 00 if not

(new name size)

(Names up to 20 Bytes)

(Name size: 2 Bytes MSB, LSB)

0x02 00 01 00 if not

When in Master, the Module connects to the address specified by Set REMOTE BDA or to the last paired device.

ToughRunners / ScanWear – Communication Protocol v1.2 - 29 -

(default SLAVE)

0x03 00 01 00 if not

Data Capture

Command

Header

Length

Payload

Answer

Set mode

0x03

00 02 [0x01 if MASTER, 0x00 if SLAVE],

0x03 00 01 01 if done

Command

Header

Length

Payload

Answer

Get mode

0x04

00 00

0x04 00 02 {Mode (1byte) | Switch role (1byte)}

Command

Header

Length

Payload

Answer

Set Remote BDA

0x05

00 06

BDA(ex:0x00,0x02,0xC3,0x21, 0xDE,0xFA)

0x05 00 01 01 if done

Command

Header

Length

Payload

Answer

Get Remote BDA

0x06

00 00

0x06 00 06 {6 bytes of BDA}

for Workforce

in Motion

[BT Clock Role switch] (default SLAVE)

You can set the size to 2. In this case, the second argument tells the module for an automatic BT clock role switch. This is an optional argument.

The real MASTER in a Bluetooth piconet is the device which manages the clock used for the frequency hopping. We used to speak about MASTER too for devices which create the connection( that's true if you do not switch the clock role)

A device with a slave BT clock role is unable to synchronize more than one master clock. If more than one SmartModule needs to connect to the same other device (PC, Access Point…) you will need to switch the clock role to allow the slave to be connected to more than one master. Note that most of the BT access point already generate the BT clock role switch when a master device creates a connection. In that case you don't need to specify this argument (if you do, it will cancel the Access Point clock switch and the result is as nothing was done).

0x03 00 01 00 if not

Mode: 0x01 if MASTER, 0x00 if SLAVE Switch role: 0x01 if want automatic switch role, 0x00 otherwise

(Used by Master Mode)

If The SM is set to Master (using Set MODE command), the SM use this Address to connect to. (No default value, depends of the last programmed)

0x05 00 01 00 if not

ToughRunners / ScanWear – Communication Protocol v1.2 - 30 -

Data Capture

Command

Header

Length

Payload

Answer

Get

0x76

00 00

0x76,

x, x, {version string

}

Command

frame

Answ

Restore Factory Settings

'R', 's', 't'

Command

Header

Length

Payload

Answer

Get inquiry scan timeout

0x27

00 00

0x27 00 04 [Inquiry Interval (MSB) | Inquiry

Command

Header

Length

Payload

Answer

Set inquiry

0x26

00 04

[Inquiry Interval (MSB) | Inquiry Interval (LS

B) |

0x26 00 01 01 if

Bluetooth Version

Restore default settings: Pin code “0000” Mode : Slave Link Timeout : 5s Security mode : ON Sniff Uart settings. Class of Device : 0x500 (peripheral) Encryption Mode Page And Inquiry Scan. Remote Channel (0) and Target Service (SPP) Bluetooth Name (Smart Module) Local Services (SPP only) All other settings are not changed.

for Workforce

in Motion

Interval (LSB) | Inquiry Window (MSB) | Inquiry Window (LSB)]

Inquiry Interval and Inquiry Window are in number of Bluetooth slots) (1 slot = 0.625 ms)

scan timeout

Inquiry Scan TimeOuts are used by the Module to answer to Inquiries. So, if you set both values to 0, the Module will not be discoverable.

ToughRunners / ScanWear – Communication Protocol v1.2 - 31 -

Inquiry Window (MSB) | Inquiry Window (LSB)]

(default 0xC80, 0x18)

done

0x26 00 01 00 if not

Data Capture

Command

Header

Length

Payload

Answer

Get page scan timeout

0x25

00 00

0x25 00 04 [Page Interval (MSB) | Page Interval

Command

Header

Length

Payload

Answer

Set page

0x24

00 04

[Page Interval (MSB) | Page Interval (LSB) |

0x24 00 01 01 if done

Page Scan and Inquiry Scan Interval

Page Scan

Inquiry Scan

for Workforce

(LSB) | Page Window (MSB) | Page Window (LSB)]

Page Scan Interval and Page Scan Window are in number of Bluetooth slots) (1 slot = 0.625 ms)

scan timeout

Page Window (MSB) | Page Window (LSB)]

0x24 00 01 00 if not

(default 0x320, 0xb0)

Page Scan TimeOuts are used by the Module to answer to Connect Inquiries. So, if you set both values to 0, the Module will not be Connectable.

in Motion

Typical values are:

Full power: Inquiry Interval = 0x400 Inquiry Window = 0x200 Page Scan Interval = 0x400 PageScan Window = 0x200

Low power: Inquiry Interval = 0x320 Inquiry Window = 0x80 Page Scan Interval = 0x320 PageScan Window = 0x80

Here is how these values change the consumption of the Module:

Window

ToughRunners / ScanWear – Communication Protocol v1.2 - 32 -

Data Capture

Command

Header

Length

Payload

Answer

Set sniff

0x09

00 04

[MSB of

MinSniff interval, LSB of MinSniff

0x09 00 01 01 if done

Command

Header

Length

Payload

Answer

Set sniff

0x09

00 08

[MSB of MinSniff interval, LSB of MinSniff

0x09 00 01 01 if done

Command

Header

Length

Payload

Answer

t sniff

0x10

00 00

0x10 00 08 [MSB of MinSniff interval, LSB of MinSniff interval,

(advanced)

(default 0xf0, 0x50, 0x08, 0x08)

interval, MSB of MaxSniff interval, LSB of MaxSnif interval]

interval, MSB of MaxSniff interval, LSB of MaxSnif interval,

Sniff Attempts MSB, Sniff attempts LSB,

Sniff timeout MSB, Sniff timeout LSB]

for Workforce

in Motion

0x09 00 01 00 if not

MSB of MaxSniff interval, LSB of MaxSnif interval, Sniff Attempts MSB, Sniff attempts LSB, Sniff timeout MSB, Sniff timeout LSB]

When setting only MinSniff and MaxSniff values, the default value 0x08 will be used for Sniff attempts and Sniff timeout.

Typical values are:

Full speed (full power) MinSniff = 0 MaxSniff = 0

Very Low Power (low speed): (sniff of 500ms Only are accepted. If the remote device does not support sniffs of 500ms, no sniff will be used) MinSniff = 0x0320 MaxSniff = 0x0320

Very Low Power (low speed): (sniff between 250ms to 500ms are accepted. No sniff will be used if the remote device does not support any sniff values in this specified range) MinSniff = 0x0160 MaxSniff = 0x0320

Low Power (medium speed):

ToughRunners / ScanWear – Communication Protocol v1.2 - 33 -

Data Capture

Command

Header

Length

Payload

Answer

Set link

timeout

0x19

00 02

[MSB of link Tmo, LSB of link Tmo]

0x19

00 01 01 if done

Command

Header

Length

Payload

Answer

Get link timeout

0x18

00 00

0x18 00 02 [MSB of link Tmo, LSB of link Tmo]

for Workforce

in Motion

MinSniff = 0x0050 MaxSniff = 0x00F0 Attempt = 0x0008 Timeout = 0x0030

MaxSniff and MinSniff are only used for sniff negociation between the Smartodule and the other BT device. If both sides allow sniff value MaxSniff, then MaxSniff will be used. If the other side does not accept Sniff values MinSniff to MaxSniff, no sniff will be used.

Values are in number of Bluetooth slots (1 slot = 625µs) Set MinSniff and MaxSniff to 0 to disable Sniff. MinSniff must be inferior to MaxSniff. Possible values for MinSniff and MaxSniff are 0x12 to 0xFFFF. Sniff attempts of 0 is not allowed. Warning: Setting MaxSniff to 0xFF means a sniff period of 40s! You will have very very low data rate. Note: This setting takes effect immediately.

Attempt Negociated Sniff

For further details on Sniff values, see the Bluetooth spec 1.1, chapter 10.8.2

0x19 00 01 00 if not

The link Time Out is a multiple of 625µsec (625µs = 1 Bluetooth slot) (default 0x7D00 (=20s))

This Timeout is used by the Link Manager to monitor the Bluetooth Link. If there is no answer from the other device after this timeout, the Link Manager assumes that we are disconnected. By default, this value is set to 20 seconds. You can go down to 1s, but then you can have disconnection even if it’s only a temporary perturbation.

This value will take effect at the next connection.

ToughRunners / ScanWear – Communication Protocol v1.2 - 34 -

Data Capture

Command

Header

Length

Payload

Answer

Set security

0x21

00 {size}

{00 non secured, 01 secured} {PIN CODE

0x21 0

0 01 01 if done,

Command

Header

Length

Payload

Answer

Get secur

ity

0x20

00 00

0x20 00 01 01 if secured

Command

Header

Length

Payload

Answer

Get Bluetooth class

0x30

00 00

0x30 00 04 [Class of Device]

Peripheral

0x00

0500

(default)

Undefined

0x00

1F00

Phone

0x502204

Computer

0x120104

PDA 0x100114

Access Point

0x120320

Command

Header

Length

Payload

Answer

Set BT class of device

0x31

00 04

[Class of Device (4 bytes, MSB

>LSB)]

0x31 00 01 01 if done

Command

Header

Length

Payload

Answer

Get BT class of device

0x30

00 00

- 0x30 00 04 [CoD (4 bytes, MSB

>LSB)]

mode

(default 01)

Size=PINCODE size + 1 For example : 0x21 00 05 00 30 30 30 30 to disable security

mode

0x20 00 01 00 if non secured

for Workforce

in Motion

0x21 00 01 00 if not

of device

See the Bluetooth spec. for more details.

Typical Bluetooth class of device:

ToughRunners / ScanWear – Communication Protocol v1.2 - 35 -

(default 0x500)

0x31 00 01 00 if not

Data Capture

Command

Header

Length

Payload

Answer

Get local BT address

0x43

00 00

0x43 00 06 {6 Bytes (BD_address MSB, ..., LSB)}

Command

Header

Length

Payload

Answer

Set Target

0x38

00 02

[UUID (2 Bytes)]

0x38 00 01 01 if done

Com

mand

Header

Length

Payload

Answer

Get Target

0x39

00 00

0x39 00 02 [UUID]

Command

Header

Length

Payload

Answer

Set

Encryption Mode

0x41

00 01

[Encryption (1

Byte)]

0x41 00 01 01 if done

Command

Header

Length

Payload

Answer

Get

Encryption mode

0x40

00 00

0x40

00 01 [

encryption

]

Service UUID

Try to connect to this remote service.

Here are some service UUID:

SPP 0x1101

DUN 0x1103

(default 0x1101)

for Workforce

in Motion

0x38 00 01 00 if not

FAX 0x1102

You can get more UUIDs by reading the Bluetooth spec.

Service UUID

Argument is: 0x01 to enable encryption, 0x00 to disable.

0x41 00 01 00 if not

ToughRunners / ScanWear – Communication Protocol v1.2 - 36 -

Data Capture

Command

Header

Length

Payload

Answer

Set Remote rfcomm

0x36

00 01

[channel (1

Byte)]

0x36 00 01 01 if done

Command

Header

Length

Payload

Answer

Get

Remote rfcomm

0x37

00 00

0x37

00 01 [

channel

]

for Workforce

in Motion

channel

0x36 00 01 00 if not

channel

If “channel” is not zero, the Module will directly try to connect (if in master mode) to the specified rfcomm channel. Setting the channel to zero will force the Module to connect (if in master mode) to the first specified Remote Service UUID (by default SPP). The services in the Module are all set to channel 1.

ToughRunners / ScanWear – Communication Protocol v1.2 - 37 -

Data Capture

Appendix B: Decoder Protocol.

for Workforce

This section describes in detail the 20 bytes of the response/payload of the 0x80/0x81.

Byte # Byte name Default value

1 COD1 0xB4 2 COD2 0x90 3 OPC39 0xEF 4 OPMUL 0x20 5 OP25I 0x36 6 LEI1 0x00 7 LEI2 0x00 8 LEI3 0x00

9 OP25S 0x77 10 LES1 0x00 11 LES2 0x00 12 LES3 0x00 13 OPMON 0xE3 14 OPEAN1 0x2F 15 OPEAN2 0x08 16 OPC93 0x00 17 FNC1 0x1D 18 RSS 14 (GSS Databar) 0x3B 19 RSS Ltd (GSS Databar Ltd) 0x3B 20 RSS Expanded (GSS Databar Expanded) 0x3B

The symbologies 18,19,20 are available since firmware version 3.02.03.

COD1 Description Default

b0 Reserved 0 b1 Enable MSI-PLESSEY 0 b2 Enable Code 128 1 b3 Enable standard 2/5 0 b4 Enable CODABAR / MONARCH 1 b5 Enable UPC/EAN 1 b6 Enable interleaved 2/5 0 b7 Enable CODE 39 1

COD2 Description Default

b0 unused 0 b1 unused 0 b2 unused 0 b3 unused 0 b4 Enable EAN 128 1 b5 Enable AIM ID for EAN128 0 b6 Disable EAN8 check digit transmission 0 b7 Enable code 93 1

in Motion

Remark:

The EAN128 is encoded with code128 symbology.

When code128 is enabled, EAN128 barcodes are decoded but the symbology ID is the code128’s one.

ToughRunners / ScanWear – Communication Protocol v1.2 - 38 -

Data Capture

for Workforce

in Motion

When both code128 and EAN128 are enabled, both are decoded but have a different symbology ID. When only EAN128 is enabled, only EAN128 codes are decoded.

Code39 parameters:

OPC39 Description Default

b0 Standard 43 characters (1) / FULL ASCII (0) 1 b1 Start/Stop characters not transmitted 1

b3 1

b4 Check digit not transmitted 0 b5 Reserved (do not modify) 1 b6 Reserved (do not modify) 1 b7 Reserved (do not modify) 1

OPMUL Description Default

b0 Reserved (do not modify) 0 b1 Reserved (do not modify) 0 b2 Reserved (do not modify) 0 b3 Reserved (do not modify) 0 b4 Reserved (do not modify) 0 b5 Reserved (do not modify) 1 b6 Reserved (do not modify) 0 b7 Reserved (do not modify) 0

Interleaved 2 of 5 parameters:

OP25I Description Default

b0 Reserved (do not modify) 0

b2 1

b3 Check digit not transmitted 0 b4 Check Digit not calculated 1 b5 Reserved (do not modify) 1 b6 Reserved (do not modify) 0 b7 Reserved (do not modify) 0

LEI1 / LEI2 / LEI3 Description Default

Nota : If one length allowed, specify it in LEI1. If two lengths allowed, fill LEI1 and LEI2 with positive values. If zero is specified and the (b1,b2) bits of OP25I are not (1,1) then the first interleaved 2/5 decoded barcode will fix the length.

(1,0) : 2 fixed allowed lengths (specified in LEI1 and LEI2) (0,1) : 3 fixed allowed lengths (specified in LEI1, LEI2 and

(0,0): mod43 checksum calculation enabled

(0,1): CIP checksum calculation enabled

(1,0): Italian checksum calculation enabled

(1,1): checksum calculation disabled

(0,0) : 1 fixed allowed length (specified in LEI1)

LEI3)

(1,1) : any length allowed (>4)

0: No length test

>0: Authorise n-character barcodes

ToughRunners / ScanWear – Communication Protocol v1.2 - 39 -

Data Capture

for Workforce

in Motion

Standard 2 of 5 and MSI parameters:

OP25S Description Default

b0 Reserved (do not modify) 1

b2 1

b3 Check digit not transmitted 0 b4 Check digit not calculated 1

b6 1

b7 Code MSI check digit not transmitted 0

LES1 / LES2 / LES3 Description Default

Nota : If one length allowed, specify it in LES1. If two lengths allowed, fill LES1and LES2 with positive values. If zero is specified and the (b1,b2) bits of OP25S are not (1,1) then the first standard 2/5 decoded barcode will fix the length.

CODABAR et PLESSEY parameters :

OPMON Description Default

b0 Reserved (do not modify) 1 b1 Reserved (do not modify) 1

b3 0

b4 Reserved (do not modify) 0 b5 Reserved (do not modify) 1 b6 Reserved (do not modify) 1 b7 Code PLESSEY check digit not transmitted 1

UPC/EAN parameters :

OPEAN1 Description Default

b0 Validation UPCA 1 b1 Validation UPCE 1 b2 Validation EAN8 1 b3 Validation EAN13 1 b4 ADD-ON required and transmitted (**) 0 b5 ADD-ON disabled 1 b6 UPCA number system not transmitted 0 b7 UPCA check digit not transmitted 0

(**) when decoded, the add-on is transmitted.

(0,0) : 1 fixed allowed length (specified in LES1) (1,0) : 2 fixed allowed lengths (specified in LES1 and LES2) (0,1) : 3 fixed allowed lengths (specified in LES1, LES2 and

LES3)

(1,1) : any length allowed (>4)

Code MSI Check Digit

(0,0): not calculated

(1,0): Modulo 11

(0,1): Double modulo 10

(1,1) : Modulo 10

0: No length test

>0: Authorise n-character barcodes

Start/Stop CODABAR

(0,0) : start/stop abcd/abcd

(1,0) : start/stop ABCD,ABCD

(0,1) : start/stop abcd,tn*e

(1,1) : standard

ToughRunners / ScanWear – Communication Protocol v1.2 - 40 -

Data Capture

for Workforce

in Motion

OPEAN2 Description Default

b0 UPCE check digit not transmitted 0 b1 UPCE conversion enabled 0

b4 Reserved (do not modify) 0 b5 UPCE number system not transmitted 0 b6 Reserved (do not modify) 0 b7 EAN13check digit not transmitted 0

Code93 parameters :

OPC93 Description Default

Reserved (do not modify) 0

EAN128 parameters :

FNC1 Description Default

b0-b6 ASCII (0 à 127) GS replacment character 0x1D

b7 FNC1 separator character transmitted 0

RSS 14 (GS1 Databar) parameters :

RSS14 Description Default

b0 RSS14 validation 1 b1 AIM Prefix « ]e0 » validation 1 b2 AIM Prefix « ]C1 » validation (prioritary over b1) 0 b3 Application indentifier AI=(01) validation 1 b4 Checksum modulo 10 validation 1 b5 Linear decoding of composite 2D barcodes allowed 1 b6 Not used 0 b7 Not used 0

0: transmit UPCE as UPCA

1: transmit UPCE as EAN13

0: transmit UPCA as EAN13

1: transmit UPCA as UPCA

RSS Ltd (GS1 Databar Ltd) parameters :

RSS Ltd Description Default

b0 RSS Ltd validation 1 b1 AIM Prefix « ]e0 » validation 1 b2 AIM Prefix « ]C1 » validation (prioritary over b1) 0 b3 Application indentifier AI=(01) validation 1 b4 Checksum modulo 10 validation 1 b5 Linear decoding of composite 2D barcodes allowed 1 b6 Not used 0 b7 Not used 0

ToughRunners / ScanWear – Communication Protocol v1.2 - 41 -

Data Capture

RSS Expanded (GS1 Databar Expanded) parameters :

RSS

Expanded

b0 RSS Expanded validation 1 b1 AIM Prefix « ]e0 » validation 1 b2 AIM Prefix « ]C1 » validation (prioritary over b1) 0 b3 Application indentifier AI=(01) or (019) validation 1 b4 Checksum modulo 10 validation 1 b5 Linear decoding of composite 2D barcodes allowed 1 b6 Not used 0 b7 Not used 0

Description Default

for Workforce

in Motion

ToughRunners / ScanWear – Communication Protocol v1.2 - 42 -

Baracoda All in One Printer User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
