Document overview
This programming guide has been restructured from previous revisions for clarity. This contains two
documents for interface and programmer separately. Interface document contains I2C interface, 3 wire SPI
interface and 4 wire SPI interface .Programmer document contains a complete programming guide for using
any interface.
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
4
RDA1846
Doc. A: Interface
RDA1846 each register write is 24-bit long, including a r/wbit,7-bit register address , and 16-bit data (MSB is
the first bit).
R/W A
Note
If register address is more than 7FH, first write 0x0001 to 7FH, and then write value to the address
subtracted by 80H. Finally write 0x0000 to 7FH
Example: writing 85H register address is 0x001F .
Move 7FH 0x0001;
Move 05H 0x001F; 05H=85H-80H
Move 7FH 0x0000;
[6:0] D[15:0]
1. I2C Interface
RDA1846 enable software programming through I2C interface. Software controls chip working states, such as
Txon or Rxon operation, and reads status register to get operation result through I2C interface.
It includes two pins: SCLK and SDIO.
A I2C interface transfer begins with START condition, a command byte and data bytes, each byte has a
followed ACK (or NACK) bit, and ends with STOP condition. The command byte includes a 7-bit chip
address and a r/
low.The ACK ( or NACK) is always sent out by receiver. When in write transfer, data bytes is written out
from MCU, and when in read transfer, data bytes is read out from RDA1846.
w bit. The 7-bit chip address is 7’b0101110 when SEN is high, or is 7’1110001 when SEN is
Figure 1. I2C Interface Write Timing Diagram
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
5
RDA1846
Figure 2. I2C Interface Read Timing Diagram
Figure 3 I2C Interface Write Combined Format
Figure 4 I2C Interface Read Combined Format
Table 2. I2C Timing Characteristics
PARAMETER SYMBOL TEST CONDITION MIN TYP MAX UNIT
SCLK Frequency
SCLK High Time
SCLK Low Time
Setup Time for START Condition
Hold Time for START Condition
Setup Time for STOP Condition
SDIO Input to SCLK↑ Setup t
SDIO Input to SCLK↓ Hold t
STOP to START Time
SDIO Output Fall Time
SDIO Input, SCLK Rise/Fall Time
Input Spike Suppression
SCLK, SDIO Capacitive Loading
Digital Input Pin Capacitance
f
scl
t
high
t
low
t
su:sta
t
hd:sta
t
su:sto
su:dat
hd:dat
t
buf
t
f:out
t
r:in / tf:in
tsp
Cb
0 - 400 KHz
0.6 - -
1.3 - -
0.6 - -
0.6 - -
0.6 - -
100 - - ns
0 - 900 ns
1.3 - -
20+0.1C
20+0.1C
- - 50 ns
- - 50 pF
5 pF
- 250 ns
b
- 300 ns
b
s
s
s
s
s
s
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
6
RDA1846
2 Three- wire SPI interface
RDA1846 enable software programming through three-wire(SPI) interface. Software controls chip working
states, such as Txon or Rxon operation, and reads status register to get operation result through three-wire
interface.
Three-wire i
nterface is slave interface. It includes three pins:
SEN, SCLK and SDIO. SEN and SCLK are
input pins , SDIO are bi-direction pins.
RDA1846 samples command byte and data at posedge of SCLK.The turn around cycle between command byte
from MCU and data from RDA1846 is a half cycle. RDA1846 samples command byte at posedge of SCLK,
and output data also at posedge of SCLK.
Figure5. Three-wire Interface Write Timing Diagram
Figure6. Three-wire Interface Read Timing Diagram
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
7
T able 2. Three-wire Timing Characteristics
PARAMETER SYMBOL TEST CONDITION MIN TYP MAX UNIT
SCLK Cycle Time
SCLK Rise Time
SCLK Fall Time
SCLK High Time
SCLK Low Time
SDIO Input, SEN to SCLK↑ Setup t
SDIO Input, to SCLK↑ Hold t
SCLK↑ to SDIO Output Valid t
SEN↑ to SDIO Output High Z t
Digital Input Pin Capacitance
t
tLO
CLK
tR
tF
tHI
s
h
cdv
sdz
RDA1846
35 ns
50 ns
50 ns
10 ns
10 ns
10 - - ns
10 - - ns
Read 2 - 10 ns
Read 2 - 10 ns
5 pF
3. Four- wire SPI interface
RDA1846 enable software programming through four-wire(SPI) interface. Software controls chip working
states, such as Txon or Rxon operation, and reads status register to get operation result through four-wire
interface.
Four-wire interface is slave interface. It includes four pins:
SDI are input pins , SDO are bi-direction pins.
SEN, SCLK , SDI and SDO. SEN ,SCLK and
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
8
RDA1846
Figure7. Four-wire Interface Write/Read Timing Diagram
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
9
RDA1846
Doc. B: Programming guide
1. Setting frequency
Bit Name Function
29H[13:0] freq<29:16> Freq high value (unit 1khz/8)
2aH[15:0] freq<15:0> Freq low value (unit 1khz/8)
Freq<29:0>= Binary (Freq(MHz)*1000*8)
Such as frequency is 409.75MHz, Freq<29:0>=409.75*1000*8=3278000= Binary (1100100000010010110000)
so write 29H [15:0] =000000000000110010 and 2aH [15:0] = 0000010 010110000.
2. Setting RF band
Bit Name Function
0fH[7:6] band_select<1:0> 00 = 400~520MHz
10 =200~260MHz
11 = 134~174MHz
3. Reference clock
RDA1846 takes 12MHz~14MHz or 24MHz~ 28 MHz crystals as its master reference clock. Setting 2bH[15:0],
2cH[15:0] and 04H[0] according different reference clock.
Bit Name Function
2bH[15:0] xtal_freq<15:0> Crystal clk freq (unit khz)
12~14MHz:crystal freq*1000
24~ 28MHz: (crystal freq/2)*1000
2cH[15:0] adclk_freq<15:0> Adc clk freq (unit khz)
12~14MHz:(crystal freq/2)*1000
24~ 28MHz: (crystal freq/4)*1000
04H[0] clk_mode 12~14MHz:1
24~ 28MHz:0
Such as 12.8M crystal (12MHz~14MHz)
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
9
2bH[15:0]= xtal_freq<15:0>=12.8*1000=12800
2cH[12:0] =adclk_freq<15:0>=(12.8/2)*1000=6400
04H[0]= clk_mode =1
26M crystal (24MHz~28MHz)
2bH[15:0]= xtal_freq<15:0>=(26/2)*1000=13000
2cH[15:0] =adclk_freq<15:0>=(26/4)*1000=6500
04H[0]= clk_mode =0
4. Setting Tx and Rx
Bit Name Function
30H[13:12] channel_mode 11 = 25khz channel mode
00 = 12.5khz channel mode
10,01=reserved
30H[6] tx_on 1 = on
0 = off
30H[5] rx_on 1 = on
0 = off
RDA1846
5. Deep sleep
Bit Name Function
30H[2] pdn_reg The same as pdn pin
1 = enable
0 = disable
While Normal mode, pdn_reg and PDN pin must be high at the same time. Only one of pdn_reg and PDN pin
is low ,which can turn into deep sleep.
6. TX voice channel
Bit Name Function
3cH[15:14] voice_sel<1:0> =00; Tx voice signal from MIC
=01; Tx inner sine tone setted by tone2
=10; Tx code from GPIO1 code_in (gpio1<1:0> must be
set to 01)
=11; not Tx any signal
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
10
7. TX Pa_bias output voltage
RDA1846 Pa_bias pin output voltage can be controlled by 0aH [5:0].
Bit Name Function
0aH [5:0] pabias_voltage<5:0> 000000: 1.01V
000001:1.05V
000010:1.09V
000100: 1.18V
001000: 1.34V
010000: 1.68V
100000: 2.45V
1111111:3.13V
8. Subaudio
RDA1846
Bit Name Function
45H[2:0] c_mode<2:0> Ctcss/cdcss mode sel
x00=disable,
001=inner ctcss en,
010= inner cdcss en
101= outter ctcss en,
110=outter cdcss en
others =disable
45H[3] ctcss_sel 1 = ctcss_cmp/cdcss_cmp out via gpio
0 = ctcss/cdcss sdo out vio gpio
45H[4] cdcss_sel 24/23 bit cdcss code sel for both txon and rxon
1 = 24 bit code
0 = 23 bit code
45H[7] neg_det_en If 1,cdcss inverse code will be detected at the same
time.
45H[11] Pos_det_en If 1, cdcss code will be detected.
45H[10] css_det_en If 1, sq detection will add ctcss/cdcss detect result,
then 1846 control 1846 voice output on or off.
4aH[15:0] ctcss_freq<15:0> Ctcss/cdcss frequency setting
Ctcss freq = ctcss_freq*2^16 khz
It must be set to 134.4Hz when use standard cdcss
mode
When use ctcss/cdcss, this register must be set both
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
11
RDA1846
in rx and tx state
4bH[7:0]
4cH[15:0]
4bH[7:0]=cdcss_code<23:16>
4cH[15:0]=cdcss_code<15::0>
Cdcss send/receive bit
Note that MSB will be transmitted first!!!
See ‘RDA1846 register table’ CDCSS MSB
When use cdcss, this register must be set both in rx
and tx state
23/24 bit CDCSS can controlled by 45H [4] (CDCSS_sel). CDCSS_sel=1 is 24 bit code ,=0 is 23bit code.
Such as TX 94.7Hz CTCSS :
4aH[15:0](ctcss_sentreg)=0.0974*(2^16) = 6383
Note: setting 45H [2:0]=000 when without subaudio
Add dcs_pos_det & dcs_neg_det register in 45H when use cdcss mode
9. SQ
Bit Name Function
30H[3] sq_on 1 = on, then chip auto sq
0 = off
45H[3] ctcss_sel 1 = ctcss_cmp/cdcss_cmp out via gpio
0 = ctcss/cdcss sdo out vio gpio
45H[10] css_det_en If 1, sq detection will add ctcss/cdcss detect result,
then 1846 control 1846 voice output on or off.
48H[9:0] th_h_sq<9:0>
Sq open threshlod
49H[9:0] th_l_sq<9:0>
Sq shut threshold
54H[7] sq_out_sel If 1, the output gpio6 is sq & css_cmp;
Auto SQ set 30H [3]=1(sq_on).
If auto SQ and subaudio detected at the same time,45H [10]=1 must be set.
48H[9:0] is Sq detect high th,49H[9:0] is Sq detect low th.
Such as Sq open threshold=-120dBm and Sq shut threshold=-122dBm
So 48H[9:3]= B inary (135+(-120))=0001111, 48H[9:0]= 0001111000
49H[9:3]= Binary (135+(-122))=0001101, 49H[9:0]= 0001101000
Sq detect high th, rssi_cmp will be 1 when
rssi>th_h_sq, unit 1/8dB
48H[9:3]＝Binary (135+ Sq open threshlod)
Sq detect low th, rssi_cmp will be 0 when
rssi<th_l_sq && time delay meet, unit 1/8 dB
49H[9:3]＝Binary (135+ Sq shut threshlod)
Else, the outputp gpio is sq only.
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
12
10. VOX
Bit Name Function
30H[4] vox_on 1 = on, then chip auto vox
0 = off
41H[15:0] th_h_vox<15:0>
Vox open threshold
42H[15:0] th_l_vox<15:0>
Vox Shut threshold
Such as vox open open threshold=2mV, vox shut threshold=2mV
So 42H[15:0]=225*1(mV)= Binary (225)= 0000000011100001
41H[15:0]=225*2(mV)= Binary (450)= 0000000111000010
th_h_vox<15:0>=225* (open threshold)
When vssi > th_h_vox, then vox will be 1
(unit mV )
th_l_vox<15:0>=225* (shut threshold)
When vssi < th_l_vox && time delay meet, then vox
will be 0
(unit mV )
RDA1846
11. Eliminating tail noise
While setting 30H [11]=1 eliminates tail noise when Tx and Rx, note turning on Tx and Rx CTCSS operation.
Tx CTCSS phase can be controlled by 45H[15:14].
Bit Name Function
30H[11] tail_elim_en 1 = tail elim enable
0 = disable
45H[15:14] shift_select<1:0> Select ctcss phase shift when use tail eliminating
function when TX
00 = 120 degree shift
01 = 180 degree shift
10 = 240 degree shift
11 = reserved
12. DTMF
Bit Name Function
63H[15:10] others<5:0> 000000
63H[9:8] Dtmf_mode<1:0> 11 =transmit or receive Dtmf single tone2
01 =transmit or receive
Dtmf dual tone1+tone2
others = disable
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
13
RDA1846
63H[7:4] dtmf_time1<3:0> Time interval for dual tone transmission
Time = dtmf_time1*5ms
63H[3:0] dtmf_time2<3:0> Time interval for dtmf idle state
Time = dtmf_time2*5ms
35H[15:0] tone1_freq<15:0> interval_v_reg=
(Tone1 freq(kHz)* 2^12)
36H[15:0] tone2_freq<15:0> interval_c_reg=
(Tone2 freq(kHz)* 2^12)
5cH[12] dtmf_idle Dtmf idle
66H[15:8] dtmf_c0 697Hz
66H[15:8]= 01100001 12.8MHz and 25.6MHz
66H[15:8]= 01100001 13MHz and 26MHz
66H[7:0] dtmf_c1 770Hz
66H[7:0]=01011011 12.8MHz and 25.6MHz
66H[7:0]=01011110 13MHz and 26MHz
67H[15:8] dtmf_c2 852 Hz
67H[15:8]=01010011 12.8MHz and 25.6MHz
67H[15:8]= 01010111 13MHz and 26MHz
67H[7:0] dtmf_c3 941 Hz
67H[7:0]=01001011 12.8MHz and 25.6MHz
67H[7:0]= 01001011 13MHz and 26MHz
68H[15:8] dtmf_c4 1209 Hz
68H[15:8]=00101100 12.8MHz and 25.6MHz
68H[15:8]=00110001 13MHz and 26MHz
68H[7:0] dtmf_c5 1336 Hz
68H[7:0]=00011110 12.8MHz and 25.6MHz
68H[7:0]=00011110 13MHz and 26MHz
69H[15:8] dtmf_c6 1477 Hz
69H[15:8]=00001010 12.8MHz and 25.6MHz
69H[15:8]=00 001111 13MHz and 26MHz
69H[7:0] dtmf_c7 1633 Hz
69H[7:0]=1111011 0 12.8MHz and 25.6MHz
69H[7:0]=11111011 13MHz and 26MHz
6cH[10:5] dtmf_index<5:0> <5:3> : tone1 detect index
<2:0> : tone2 detect index, will be used when
single tone mode
6cH [4] dtmf_flag Dtmf code not valid flag
1 = not valid
6cH [3:0] dtmf_code<3:0> Dtmf code out
Usually, F0~F7 is selected as 697, 770, 852, 941,
1209, 1336, 1477, 1633 Hz (default)
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
14
RDA1846
F4 F5 F6 F7
F0 1 2 3 A
F1 4 5 6 B
F2 7 8 9 C
F3 E(*) 0 F(#) D
TX and RX DTMF set 63H [8]=1(DTMF_en),close DTMF set 63H [8]=0.
Setting DTMF frequency 35H[15:0 ] (tone1_freq)（35H）and 36H[15:0 ] (tone2_freq) .Unite is 1/2^12KHz
Such as ：DTMF signal is 697Hz 和 1633Hz，
Tone1_freq<15:0> = round（0.697 *2^12）=2855
Tone2_freq<15:0> = round（1.633 *2^12）=6689
If tx single frequency signal, only setting tone2_freq and 63H [9:8]=11(single_tone), and
63H[7:4]=1111,63H[3:0]=0000.Or set ting tone2_freq and 3CH[15:14]=01.
Rx DTMF:
Step1:set 66H,67H,68H,69H DTMF frequency according to reference clock
Step2: set DTMF_en=1 (63H[8]) if use INT mode, should set gpio2<1:0> to 01,
and set int_grp_en<6> to 1
Step3 read dtmf_idle every 10ms until dtmf_idle=1 (5cH[12]) or wait INT when use INT mode
Step4: read dtmf_code<3:0> (6cH[3:0]
Step5: read dtmf_idle every 10ms until dtmf_idle=0 (5cH[12]) or write 00H=0x1846 (to clear INT) when use
INT mode
Step6: jump to Step3
End of Rx DTMF, setting DTMF_en=0 and software jump out the circle Steps.
Tx DTMF:
Step1: setting DTMF sequence and the first DTMF frequency (ton1_freq and ton2_freq)
Step2: set DTMF_en=1 when needed (63H[8]) if use INT mode, should set gpio2<1:0> to 01,
and set int_grp_en<6> to 1
Step3: read dtmf_idle every 10ms until dtmf_idle=1 (5cH[12]) or wait INT when use INT mode
Step4: setting the next DTMF frequency (ton1_freq and ton2_freq) according DTMF sequence
Step5: read dtmf_idle every 10ms until dtmf_idle=0 (5cH[12]) or write 00H, 0x1846 (to clear INT) when use
INT mode
Step6: jump to Step3
End of Tx DTMF, setting DTMF_en=0 and software jump out the circle Steps.
13. Tx FM deviation
Bit Name Function
[15:13] others 00
43H [12:6] xmitter_dev<6:0> Ctcss/cdcss + voice dev setting
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
15
RDA1846
43H [5:0] c_dev<5:0> Ctcss/cdcss dev setting
Adjusting 43H [12:6] ( xmitter_dev) can change Tx FM deviation of voice and subaudio.
Adjusting 43H [5:0] ( c_dev) can only change Tx FM deviation of CTCSS and CDCSS.
14. Rx voice range
Bit Name Function
44H[15:8] others 00000000
44H[7:4] volume1<3:0> (0000)-15dB~(1111)0dB, step 1dB
44H[3:0] volume2<3:0> (0000)-15dB~(1111)0dB, step 1dB
Adjusting 44H [3:0] and 44H [7:4] can change Rx voice range.
15. TX and RX code
Set code mode:
Step1: set 58H[1:0]=11 set voice hpf bypass
Step2: set 58H[5:3]=111 set voice lpf bypass and pre/de-emph bypass
Step3 set 3CH[15:14]=10 set code mode
Step4: set 1FH[3:2]=01 set GPIO code in or code out
TX code mode
Step1: 45H[2:0]＝010
：
RX code mode：
Step1: set 45H[2:0]=001
Step2: set 4dH[15:10]=000001
16. GPIO
Register 1fh.
Bit Name Function
15:14 gpio7<1:0> 00 =hi-z
01 = vox
10 = low
11 = high
13:12 gpio6<1:0> 00 =hi-z
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
16
01 = sq,
or =sq&ctcss/cdcss,when sq_out_sel=1
10 = low
11 = high
11:10 gpio5<1:0> 00 =hi-z
01 = txon_rf
10 = low
11 = high
9:8 gpio4<1:0> 00 =hi-z
01 = rxon_rf
10 = low
11 = high
7:6 gpio3<1:0> 00 =hi-z
01 = sdo
10 = low
11 = high
5:4 gpio2<1:0> 00 =hi-z
01 = int
10 = low
11 = high
3:2 gpio1<1:0> 00 =hi-z
01 = code_out/code_in
10 = low
11 = high
1:0 gpio0<1:0> 00 =hi-z
01 = css_out/css_in/css_cmp
10 = low
11 = high
RDA1846
17. INT
Register 2dh.
16’ b0000_0000_0000
Bit Name Function
15:10 others <5:0> 000000
9:0 int_grp_en<9:0> <9> :css_cmp_int enabl
<8> : rxon_rf int enable
<7> : txon_rf int enable
<6> : dtmf_idle int enable
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
17
<5> : ctcss phase shift detect int enable
<4> : idle state time out int enable
<3> : rxon_rf timerout int enable
<2> : sq int enable;
<1> : txon_rf time out int enable;
<0> : vox int enable；
18. St_mode
Bit Name Function
30H[9:8] st_mode<1:0> 11 = reserved
10 = txon_rf & rxon_rf auto
01 = rxon_rf auto, txon_rf manu
00 = txon_rf & rxon_rf manu
RDA1846
Tmier1&Timer5
ST_mode=10
ST_mode=00
TXON
Timer1
TXON
Timer1
VOX=0
TXON
RXON
SLEEP
VOX=0
VOX =0 can generate INT
Detect VOX
Detect VOX
VOX=1
TXON
VOX=1 VOX=1
Timer5Timer5Timer1
VOX=1
Timer1
VOX =1 can t generate INT
VOX=0
TXON
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
18
RDA1846
Tmier 3
ST_mode=10
Tmier 4
ST_mode=01
TXON
RXON
Timer3
RXON
Timer4
TXON
RXON
Timer5
Timer4 Timer4
RXON
Timer4
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
19
RDA1846
Tmier 7
Idle time > Timer7 can generate INT
Idle time < Timer7 can
TXON
Idle time
>Timer7
RXON
Timer7 Timer7
t generate INT
RXON
Idle time
<Timer7
Idle time
>Timer7
Idle time
<Timer7
TXON
Timer7
Idle time
<Timer7
Tmier 8
PPT OFF PPT OFF
TXOFF TXOFF
PPT PUSH
Eliminate tail noise
TXON
Timer8
Idle time
>Timer7
Idle time
>Timer7
RXON
Timer7
RXON
Idle time
<Timer7
Invert phase 120 or 180
19. Pre-emphasis/De-emphasis filter
Bit Name Function
58H[3] pre/de-emph 1=pre/de-emph bypass
0=normal
20. Only read register
Bit Name Function
5fH[9:0] Rssi<9:0> Received signal strength indication, unit 1/8dB
60H[14:0] Vssi<14:0> Voice signal strength indication, unit mV
6cH[10:5] dtmf_index<5:0> <5:3> : tone1 detect index
<2:0> : tone2 detect index
6cH[3:0] dtmf_code<3:0> Dtmf code out
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
20
1:f0+f4, 2:f0+f5, 3:f0+f6, A:f0+f7,
4:f1+f4, 5:f1+f5, 6:f1+f6, B:f1+f7,
7:f2+f4, 8:f2+f5, 9:f2+f6, C:f2+f7,
E(*):f3+f4, 0:f3+f5, F(#):f3+f6, D:f3+f7
Such as：
Read 5fH[9:0]= Binary (110100000)=Dec(416)
So Received signal strength =(416*0.125)-135=(416/8)-135= -83dBm
21. Flag
Bit Name Function
5cH[12] dtmf_idle Dtmf idle
5cH [10] rxon_rf If 1, rxon is enable
5cH[ 9] txon_rf If 1, txon is enable
5cH[ 7] invert_det Ctcss phase shift detected
5cH [2] css_cmp Ctcss/cdcss compared
5cH [1] SQ Sq final signal out from dsp
5cH [0] VOX Vox out from dsp
RDA1846
22. Initial process
Refer to the ‘RDA18456 _register_table’
23. Register introduction
Register 30h.
Bit Name Function Default
15:14 others 00 00
13:12 channel_mode 11 = 25khz channel mode
00 = 12.5khz channel mode
10,01=reserved
11 tail_elim_en 1 = tail elim enable
0 = disable
10 others 0 0
9:8 st_mode<1:0> 11 = reserved
10 = txon_rf & rxon_rf auto
0
0
00
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
21
RDA1846
01 = rxon_rf auto, txon_rf manu
00 = txon_rf & rxon_rf manu
7 mute 1 = mute when rxno
0
0 = no mute
6 tx_on 1 = on
0
0 = off
5 rx_on 1 = on
0
0 = off
4 vox_on 1 = on, then chip auto vox
0
0 = off
3 sq_on 1 = on, then chip auto sq
0
0 = off
2 pdn_reg The same as pdn pin
0
1 = enable
0 = disable
1 chip_cal_en 1 = cal enable
0
0 = cal disable
0 soft_reset 1 = reset, then all the registers are reset
0
to default value
0 = normal
Register 04h.
Bit Name Function Default
15:1 others 0000_1111_0001_000
0 clk_mode 12~14MHz:1
1
24~ 28MHz:0
Register 0ah.
Bit Name Function Default
15:6 others 0000_0100_00
5:0 pabias_voltage<5:0> See TX Pa_bias output voltage 10_0000
Register 0fh.
Bit Name Function Default
15:8 others 00000000
7:6 band_select See setting RF band 00
5:0 others 100100
Register 29h.
Bit Name Function Default
15:14 others 00
13:0 freq_reg See setting frequency 0000000110010
Register 2ah.
Bit Name Function Default
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
22
RDA1846
15:0 freq_reg See setting frequency 0000010010110000
Register 2bh.
Bit Name Function Default
15:0 xtal_freq See reference clock 0011001000000000
Register 3ch.
Bit Name Function Default
15:14 voice_sel<1:0> See tx voice channel 00
13:0 others 00_1001_0101_1000
Register 41h.
Bit Name Function Default
15 others 0
14:0 th_h_vox<14:0> See vox 00_0000_0100_0000
Register 42h.
Bit Name Function Default
15 others 0
14:0 th_h_vox<14:0> See vox 00_0000_0011_1100
Register 45h.
Bit Name Function Default
15:14 shift_select<1:0> See eliminating tail noise 00
13:12 others 00
11 Pos_det_en See subaudio 1
10 css_det_en See subaudio/sq 0
9:8 others 10
7 neg_det_en See subaudio 1
6:5 others 00
4 cdcss_sel See subaudio 0
3 others 0
2:0 c_mode<2:0> See subaudio 000
Register 48h.
Bit Name Function Default
15:10 others 000000
9:0 Sq open threshold See SQ 0001010000
Register 49h.
Bit Name Function Default
15:10 others 000000
9:0 Sq shut threshold See SQ 0000111100
Register 4ah.
Bit Name Function Default
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
23
RDA1846
15:0 ctcss_freq See Subaudio 0001100110011001
Register 4bh.
Bit Name Function Default
15:8 others Read as zeros 0000_0000
7:0 cdcss_code See subaudio 0110_0101
Register 4ch.
Bit Name Function Default
15:0 cdcss_code See subaudio 1101_1000_0001_0110
Register 54h.
Bit Name Function Default
15:13 others 0001_0001
7 sq_out_sel See sq 0
6:0 others 100_1000
Register 63h.
Bit Name Function Default
15:10 Reserved<5:0> 000000 0000
9 single_tone See dtmf 0
8 dtmf_en See dtmf 0
7:4 dtmf_time1<3:0> See dtmf 1000
3:0 dtmf_time2<3:0> See dtmf 1000
Register 66h
Bit Name Function Default
15:8 dtmf_c0 697Hz 0110_0001
7:0 dtmf_c1 770Hz 0101_1011
Register 67h.
Bit Name Function Default
15:8 dtmf_c2<7:0> 852Hz 0101_0011
7:0 dtmf_c3<7:0> 941Hz 0100_1011
Register 68h.
Bit Name Function Default
15:8 dtmf_c4<7:0> 1209Hz 0010_1100
7:0 dtmf_c5<7:0> 1336Hz 0001_1110
Register 69h.
Bit Name Function Default
15:8 dtmf_c6<7:0> 1477Hz 0000_1010
7:0 dtmf_c7<7:0> 1633Hz 1111_0110
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
24
Change List
Rev Date Author Change Description
RDA1846
0.1 2009-5-20 Liu Ge & Liu
Original draft
ya nan
1.1 2009-6-17 Liu Ge & Liu
ya nan
1.1 2009-10-13 Liu Ge Add register indroduction
1.2 2009-11-13 Liu Ge Modify DTMF and RSSI indroduction
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
25
RDA1846
Disclaimer
The information provided here is believed to be reliable; RDA Microelectronics assumes no liability for
inaccuracies and omissions. RDA Microelectronics assumes no liability for the use of this information and all
such information should entirely be at the user’s own risk. Specifications described and contained here are
subjected to change without notice for the purpose of improving the design and performance. All of the
information described herein shall only be used for sole purpose of development work of RDA1846, no right
or license is implied or granted except for the above mentioned purpose. RDA Microelectronics does not
authorize or warrant any RDA products for use in the life support devices or systems.
Copyright@2006 RDA Microelectronics Inc. All rights reserved
For technical questions and additional information about RDA Microelectronics Inc.:
Website: www.rdamicro.com
Mailbox: info@rdamicro.com
A Microelectronics (Shanghai), Inc. RDA Microelectronics (Beijing), Inc.
RD
Tel: +86-21-50271108 Tel: +86-10-63635360
Fax: +86-21-50271099 Fax: +86-10-82612663
The information contained herein is the exclusive property of RDA and shall not be distributed, reproduced, or disclosed in whole or in
part without prior written permission of RDA.
26
Loading...
