Product Information Packet
VBM3116
1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Part Detail
Revision: P Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 34WGW990 CD Diagram: CD0005 Mfg Plant:
Mech. Spec: 34-3093 Layout: 34LY3093 Poles: 04 Created Date:
Base: N Eff. Date: 07-24-2018 Leads: 9#18
Specs
Catalog Number: VBM3116
Enclosure: OPEN
Frame: 56C
Frame Material: Steel
Output @ Frequency: 1.000 HP @ 60 HZ
Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ
Voltage @ Frequency: 208.0 V @ 60 HZ
230.0 V @ 60 HZ
460.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: UR
CSA
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: No Mounting
Bearing Grease Type: Polyrex EM (-20F +300F)
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: K
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3424M
Mounting Arrangement: F1
Power Factor: 70
Product Family: General Purpose
Product Type: BRAKE MOTOR
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Standard
Rodent Screen: None
Blower: None
RoHS Status: ROHS COMPLIANT
Page 2 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Current @ Voltage: 1.700 A @ 460.0 V
3.400 A @ 230.0 V
3.700 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Brake Mounting
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Extension Location: Pulley End
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: None
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: None
Winding Thermal 2: None
Page 3 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Nameplate NP1256L
CAT.NO. VBM3116
SPEC. 34-3093W990-C
HP 1
VOLTS 208-230/460
AMP 3.7-3.4/1.7
RPM 1725
FRAME 56C HZ 60 PH 3
SER.F. 1.15 CODE K DES B CLASS B
NEMA-NOM-EFF 78.5 PF 70
RATING 40C AMB-CONT
CC USABLE AT 208V 3.7
DE 6203 ODE 6203
ENCL OPEN SN
Page 4 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Parts List
Part Number Description Quantity
SA040540 SA 34-3093W990-C 1.000 EA
RA036424 RA 34-3093W990-C 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
34CB3002A CB CAST W/.88 DIA HOLE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
34EP3900A07 FR ENDPLATE, MACH 1.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
34EP3400A05 PU ENDPLATE, MACH 1.000 EA
34AD2000 BAFFLE PLATE, STAMPED 1.000 EA
60XW0632A06 6-32 X 3/8 TORX HEAD SCREW TAPTITE II 4.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
HW2500A13 KEY, USA #605, WOODRUFF 1.000 EA
18XN2520A08 1/4-20X1/2 FLAT HD SLTD X 2.000 EA
34CB4517 CB LID 4 MTG HOLES .22 DIA STAMPED, FOR 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA
HA7000A04 KEY RETAINER 0.625 DIA SHAFTS 1.000 EA
MG1000G27 MED CHARCOAL METALLIC GREY 400-0096 0.014 GA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA
LB1185 LABEL,BRAKE CONNECTION (ON ROLLS) 1.000 EA
HA3100A15 THRUBOLT 10-32 X 8.375 4.000 EA
48BK7101BP- 1-048-171-01-BP- BRAKE 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 5 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Parts List (continued)
Part Number Description Quantity
LC0005E01 CONN.DIA./WARNING LABEL (LC0005/LB1119N) 1.000 EA
NP1256L ALUM UL CSA CC INDUSTRIAL MOTOR A60 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
PK3083 STYROFOAM PACKING CRADLE 1.000 EA
PK3088 MICROFOAM, 8"X"8 PERF. SHEETS 5,400/RL 1.000 EA
Page 6 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
AC Induction Motor Performance Data
Record # 50818 - Typical performance - not guaranteed values
Winding: 34WGW990-R002 Type: 3424M Enclosure: OPEN
Nameplate Data
460 V, 60 Hz:
High Voltage Connection
Rated Output (HP) 1 Full Load Torque 3.1 LB-FT
Volts 208-230/460 Start Configuration direct on line
Full Load Amps 3.7-3.4/1.7 Breakdown Torque 11.8 LB-FT
R.P.M. 1725 Pull-up Torque 8 LB-FT
Hz 60 Phase 3 Locked-rotor Torque 10.5 LB-FT
NEMA Design Code B KVA Code K Starting Current 11.4 A
Service Factor (S.F.) 1.15 No-load Current 1.1 A
NEMA Nom. Eff. 78.5 Power Factor 70 LinelineRes.@25ºC 13.4Ω
Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load
Load Characteristics 460 V, 60 Hz, 1 HP
% of Rated Load 25 50 75 100 125 150 S.F.
Power Factor 34 51 63 72 77 81 75
Efficiency 59.6 72.6 77.3 79.1 79.3 78.6 79.2
Speed 1778 1760 1741 1721 1698 1673 1707
Line amperes 1.2 1.3 1.4 1.7 1.9 2.2 1.8
Page 7 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Performance Graph at 460V, 60Hz, 1.0HP Typical performance - Not guaranteed values
Page 8 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Page 9 of 10
Product Information Packet: VBM3116 - 1HP,1725RPM,3PH,60HZ,56C,BRAKE,3424M
Page 10 of 10
