Product Information Packet

CDRX14244T-5

2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Part Detail

Revision: - Status: PRD/A Change #: Proprietary: No Type: AC Elec. Spec: 35WGN956 CD Diagram: CD0006 Mfg Plant: Mech. Spec: Layout: 35LYX732 Poles: 04 Created Date: 07-22-2019 Base: Eff. Date: 07-23-2019 Leads: 3#18

Specs

Catalog Number: CDRX14244T-5 Enclosure: XPFC Frame: 145TC Frame Material: Steel Output @ Frequency: 2.000 HP @ 60 HZ Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ Voltage @ Frequency: 575.0 V @ 60 HZ XP Class and Group: CLI GP C,D XP Division: Division I Agency Approvals: CSA

CSA EEV

UR Auxillary Box: No Auxillary Box Auxillary Box Lead Termination: None Base Indicator: Rigid Bearing Grease Type: Polyrex EM (-20F +300F) Blower: None

Heater Indicator: No Heater Insulation Class: F Inverter Code: Inverter Duty IP Rating: NONE KVA Code: L Lifting Lugs: No Lifting Lugs Locked Bearing Indicator: Locked Bearing Motor Lead Termination: Flying Leads Motor Type: 3528M Mounting Arrangement: F1 Power Factor: 75 Product Family: General Purpose Pulley Face Code: C-Face Rodent Screen: None Shaft Ground Indicator: No Shaft Grounding Shaft Rotation: Reversible Speed Code: Single Speed

Constant Torque Speed Range: 6

Motor Standards: NEMA

Page 2 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Current @ Voltage: 2.300 A @ 575.0 V Design Code: B Drip Cover: No Drip Cover Duty Rating: CONT Electrically Isolated Bearing: Not Electrically Isolated Feedback Device: NO FEEDBACK

Starting Method: Direct on line Thermal Device - Bearing: None Thermal Device - Winding: Normally Closed Thermostat Vibration Sensor Indicator: No Vibration Sensor Winding Thermal 1: None Winding Thermal 2: None XP Temp Code: T3C

Page 3 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Nameplate NP1401XPSLEV

NO. CC 010A

S/N TEMP CODE T3C

SPEC. 35-0000-0269 INV.TYPE PWM

CAT.NO. CDRX14244T-5 C HP FR 60 C HP TO 90

HP 2 CT HZ FROM 6 CT HZ TO 60

VOLTS 575 VT HZ FROM 6 VT HZ TO 60

AMPS 2.3 MAG CUR 1.5

RPM 1755 MX RPM 2700

HZ 60 PH 3 CL F NOM.EFF. 86.5

SER.F. 1.00 DES B SL HZ 1.5 WK2 0.17

FRAME 145TC RATING 40C AMB-CONT

55C AMB @ 1.0 SF

1.15 SF SINEWAVE NEMA MG-1 PT 5,IP55

Page 4 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Parts List

Part Number Description Quantity SA372064 SA 35-0000-0269 1.000 EA RA361788 RA 35-0000-0269 1.000 EA LB1119N WARNING LABEL 1.000 EA LC0006 CONNECTION LABEL 1.000 EA NP1401XPSLEV SS XP INV UL CSA-EEV CC CL-I GP-C&D 1.000 EA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 2.000 EA 85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 4.000 EA MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA LB1359F ALUM XP CAUTION LABEL 1.000 EA 35FH4005A01SP IEC FH NO GREASER W/PRIMED 1.000 EA 51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA 35FN3002A05SP EXFN, PLASTIC, 6.376 OD, .638 ID 1.000 EA 51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB HA3104A08 THRUBOLT-5/16-18X9.375 X X 4.000 EA XY3118A12 5/16-18 HEX NUT DIRECTIONAL SERRATION 4.000 EA 35EP3700B07 FR ENDPLATE, XPFC - GROUP C, W/ DRAIN 1.000 EA HW5100A03 WAVY WASHER (W1543-017) 1.000 EA HW4506A02 BREATHER/DRAIN-EXP PROOF-.125-27 NPTF AI 1.000 EA HW3022E05 .125 DIA X .500 ROLLED SPRING PIN 1.000 EA HA2009A89 SPACER FOR XP MTRS - 205 BRG. 1.000 EA 35EP1704A40 PUEP 205 BRG XP,GP C,ALUM SLINGER,DRAIN 1.000 EA HA2071A02 SLINGER ALUM (AUTO) 1.000 EA 80XN1032A04 10-32 X 1/4 SET SCREW 1.000 EA

Page 5 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Parts List (continued)

Part Number Description Quantity 84XN1032J20 SCREW, SOC 10-32 X 1 1/4"BMH4602 2.000 EA HW4001A01 1/4 HX SOC PIPE PLG (F/S) ALLOY STEEL W/ 2.000 EA 60XN1032A07 10-32 X .4375 TRUSS HEAD, TORX SERRATED 2.000 EA HW4506A02 BREATHER/DRAIN-EXP PROOF-.125-27 NPTF AI 1.000 EA HW3022E05 .125 DIA X .500 ROLLED SPRING PIN 1.000 EA 35CB1005A01 CONDUIT BOX,MACH - GROUP "C" MTRS 1.000 EA RM1020A41 O-RING, -150 BUNA-N, .103 CS X 2.862 ID 1.000 EA 11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA HW3001B01 BRASS CUP WASHER, FOR #10 SCREW 1.000 EA 35CB1501A01 CONDUIT BOX LID, MACH. - GROUP "C"MTRS 1.000 EA MG1500Y02 WILKOPON (use 004824003CAH) 0.022 GA MG1025G29 WILKOFAST, 789.229, DARK CHARCOAL GRAY 0.022 GA 36PA1001 PKG GRP, PRINT PK1017A06 1.000 EA HW2501D13 KEY, 3/16 SQ X 1.375 1.000 EA HA7000A01 KEY RETAINER 7/8" DIA SHAFT 1.000 EA

Page 6 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

AC Induction Motor Performance Data

Record # 77529 - Typical performance - not guaranteed values

Winding: 35WGN956-R014 Type: 3528M Enclosure: XPFC

Nameplate Data

575 V, 60 Hz:

Single Voltage Motor Rated Output (HP) 2 Full Load Torque 5.98 LB-FT Volts 575 Start Configuration direct on line Full Load Amps 2.3 Breakdown Torque 26 LB-FT R.P.M. 1755 Pull-up Torque 16.6 LB-FT Hz 60 Phase 3 Locked-rotor Torque 18 LB-FT NEMA Design Code B KVA Code L Starting Current 19.6 A Service Factor (S.F.) 1 No-load Current 1.48 A NEMA Nom. Eff. 86.5 Power Factor 75 LinelineRes.@25ºC 11.2Ω Rating - Duty 40C AMB-CONT Temp. Rise @ Rated Load 62°C

Locked-rotor Power Factor 50.3

Rotor inertia 0.165 LB-FT2

Load Characteristics 575 V, 60 Hz, 2 HP

% of Rated Load 25 50 75 100 125 150 Power Factor 32 52 65 74 79 82 Efficiency 76 84.3 86.8 86.9 86.5 85.2 Speed 1790 1780 1769 1757 1744 1729 Line amperes 1.54 1.71 1.99 2.34 2.73 3.2

Page 7 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Performance Graph at 575V, 60Hz, 2.0HP Typical performance - Not guaranteed values

Page 8 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

5.94

.8750 .8745

4.00

5.00 .50

2.75

510-520 = 14.34 521-528 = 15.21 529-535 = 16.09 536-546 = 17.46

4.73

7.19

6.49

4.500

4.497

2.12

.13

6 HOLES

.38 DIA.

.19 KEY

1.38 LONG

DRAIN FITTINGS (EACH END)

SLINGER

6.50

6.67

7.08

45°

7.18

3.50

3.44

2.75

3.25 4.83

LEAD HOLE

.75 N.P.T.

4 HOLES

.38-16 TAP

.56 DEEP ON

5.88 DIA. B.C.

.38

.13 MIN.

1.00 MIN.

.006 .004

.0015 MAX CLEARANCE

D

C

B

A

B

C

D

1

2

3

4

5

6

7

8

7

6

5

4

3

2

1

35LYX732

B

HOR 143-5TC XPFC M,CLI GP C&D,DRILL RIG,ALUM. SLINGER,DRAINS

REV. DESC:

REV:

BY:

REVISED:

MODEL NO.

VERSION:

TDR:

REF:

35LYX732

LOAD TO SOLIDWORKS

USBUFRA

B

10:56:07 08/30/2019

-

000001117187

02

35LYX732

CUSTOMER IS RESPONSIBLE FOR DETERMINING THAT THE PRODUCT WILL PERFORM SUITABLY IN THE INTENDED APPLICATION

BALDOR - RELIANCE

®

Page 9 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Page 10 of 11

Product Information Packet: CDRX14244T-5 - 2HP,1755RPM,3PH,60HZ,145TC,XPFC,F1

Marketing maintained PDF of MN416:

http://www.baldor.com/support/Literature/Load.ashx/MN416?ManNumber=MN416
