Product Information Packet
35W191Q080G1
1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
Copyright © All product information within this document is subject to ABB Motors and Mechanical Inc. copyright © protection, unless otherwise noted.
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
Part Detail
Revision: AK Status: PRD/A Change #: Proprietary: No
Type: AC Elec. Spec: 35WGQ080 CD Diagram: CD0320 Mfg Plant:
Mech. Spec: 35W191 Layout: 35LYW191 Poles: 02 Created Date: 06-22-2007
Base: N Eff. Date: 07-09-2020 Leads: 4#14 A PH,2#18 B PH,1#12 #4TH
Specs
Enclosure: TEFC
Frame: 56CZ
Frame Material: Steel
Output @ Frequency: 1.500 HP @ 60 HZ
Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ
Voltage @ Frequency: 115.0 V @ 60 HZ
230.0 V @ 60 HZ
208.0 V @ 60 HZ
XP Class and Group: None
XP Division: Not Applicable
Agency Approvals: CE
CSA
UR
WEEE
Auxillary Box: No Auxillary Box
Auxillary Box Lead Termination: None
Base Indicator: No Mounting
Insulation Class: F
Inverter Code: Not Inverter
KVA Code: L
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 4 @ 14 AWG, A PH
Motor Lead Exit: Ko Box
Motor Lead Termination: Flying Leads
Motor Type: 3535LC
Mounting Arrangement: F1
Power Factor: 95
Product Family: General Purpose
Pulley End Bearing Type: Ball
Pulley Face Code: C-Face
Pulley Shaft Indicator: Ext Thread
Rodent Screen: None
RoHS Status: ROHS COMPLIANT
Bearing Grease Type: Polyrex EM (-20F +300F)
Shaft Extension Location: Pulley End
Page 2 of 11
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
Blower: None
Current @ Voltage: 7.800 A @ 208.0 V
7.300 A @ 230.0 V
14.600 A @ 115.0 V
Design Code: L
Drip Cover: No Drip Cover
Duty Rating: CONT
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Fixed Opposite Standard
Shaft Slinger Indicator: No Slinger
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
Thermal Device - Bearing: None
Thermal Device - Winding: Do Not Use Eve-Not Valiid
Vibration Sensor Indicator: No Vibration Sensor
Winding Thermal 1: Automatic Thermal Overload
Winding Thermal 1 Location: KO
Winding Thermal 2: None
Page 3 of 11
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
Nameplate NP1257L
CAT.NO. IP44
SPEC. 35W191Q080G1
HP 1.5
VOLTS 115/208-230
AMP 14.6/7.8-7.3
RPM 3500
FRAME 56CZ HZ 60 PH 1
SER.F. 1.30 CODE L DES L CL F
NEMA-NOM-EFF 72 PF 95
RATING 40C AMB-CONT
CC USABLE AT 208V
DE 6205 ODE 6203
ENCL TEFC SN
SFA 18.8/10.2-9.4
Page 4 of 11
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
Nameplate NP3266L
CAT.NO. IP44
SPEC. 35W191Q080G1
HP 1.5/1.1KW
VOLTS 110/220 24KG
AMP 16.8/8.4
RPM 2900
FRAME 56CZ HZ 50 PH 1
SER.F. 1.00 CODE L DES L CL F
NEMA-NOM-EFF 70 PF 88
RATING 40C AMB-CONT
CC USABLE AT 208V
DE 6205 ODE 6203
ENCL TEFC SN
SFA 18.8/10.2-9.4
Page 5 of 11
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
Parts List
Part Number Description Quantity
SA152620 SA 35W191Q080G1 1.000 EA
RA141387 RA 35W191Q080G1 1.000 EA
OC3050C09 CYL OIL CAP 50MFD/240V 1.000 EA
TPCRJ36CV THERMAL 1PH 1.00 AUT 105C 1.000 EA
EC1645A06SP ELEC CAP, 645-774 MFD, 125V, 2.06D X 4. 1.000 EA
NS2512A01 INSULATOR, CONDUIT BOX X 1.000 EA
35CB3007A14 35 CB .88 DIA @ 6:00, 1.00 ATO @ 3:00 1.000 EA
36GS1000SP GASKET-CONDUIT BOX, .06 THICK #SV-330 LE 1.000 EA
51XB1016A07 10-16 X 7/16 HXWSSLD SERTYB 2.000 EA
11XW1032G06 10-32 X .38, TAPTITE II, HEX WSHR SLTD U 1.000 EA
HA6015A02 THERMAL RETAINER (PLATED) 1.000 EA
NS2500A06 INSULATOR,AUTO THER PROT,W/PSA ON 1 SIDE 1.000 EA
51XB1214A10 12-14 X 5/8HX WS SL SR TYBX 2.000 EA
35EP3122K00 MASTER ODE,203 BRG,.683SH,#26 DRN,FH MTG 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 2.000 EA
85XU0407S04 4X1/4 U DRIVE PIN STAINLESS 4.000 EA
35CB3801 CAPACITOR COVER, CAST 1.000 EA
34GS3002 GASKET, CAPACITOR BOX 1.000 EA
HA7010 CAPACITOR RETENTION CLAMP 1.000 EA
NS2501A02 INSULATOR, CAPACITOR BOX 1.000 EA
51XB1016A08 10-16X 1/2HXWSSLD SERTYB 2.000 EA
HW5100A03 WAVY WASHER (W1543-017) 1.000 EA
35EP3307G00 MASTER DE,205 BRG,1.232SH,#26 DRN 1.000 EA
51XN1032A20 10-32 X 1 1/4 HX WS SL SR 2.000 EA
Page 6 of 11
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
Parts List (continued)
Part Number Description Quantity
51XB1214A16 12-14X1.00 HXWSSLD SERTYB 1.000 EA
35FH4005A55 IEC FH NO GRSR,3 MTG HOLE NO DIMPLES, 1.000 EA
51XW1032A06 10-32 X .38, TAPTITE II, HEX WSHR SLTD S 3.000 EA
WD4100A10 465 NIAGARA PLUG (SO ELEC),FOR 1.093 DIA 1.000 EA
35CB4521GX CONDUIT BOX LID KIT **ORDER INDIV PARTS 1.000 EA
51XW0832A07 8-32 X .44, TAPTITE II, HEX WSHR SLTD SE 4.000 EA
MJ1000A02 GREASE, MOBIL POLYREX EM - 124047 0.050 LB
35FN3002A05SP EXFN, PLASTIC, 6.376 OD, .638 ID 1.000 EA
MG1000B24 PAINT, 400-0125, WARNING BLUE 0.017 GA
HA3100A18 THRUBOLT 10-32 X 9.250 4.000 EA
SP5181A01 MODEL 35 LC TORQ STAT SWITCH LEAD ASSY 1.000 EA
WD1000A16 2-520128-2 AMP FLAG TERM (4M/RL) 22-18 4.000 EA
LB1118 LABEL,WARNING (ROLL LABEL) 1.000 EA
LB1451 WARNING LABEL, CE WARNING SYMBOLS ONLY 1.000 EA
LC0269 1PH,DV,REV,THERMAL,7 LD,L.AMP THRU HTR H 1.000 EA
LB1009N LABEL,ROTATION DIRECTION (ON ROLLS) 1.000 EA
NP1257L ALUM UL CSA CC THERMAL REV MTG 1.000 EA
NP3266L ALUM UL CSA CE CC THERMAL REV MTG 1.000 EA
36PA1000 PKG GRP, PRINT PK1016A06 1.000 EA
PK3083 STYROFOAM PACKING CRADLE 1.000 EA
LB1417 LABEL CARTON 6X4 PERFORATED BLANK ROLLS 1.000 EA
PK3088 MICROFOAM, 8"X"8 PERF. SHEETS 5,400/RL 1.000 EA
FE-0000001 ZRTG FE ASSEMBLY 1.000 EA
MN416A01 TAG-INSTAL-MAINT no wire (1200/bx) 3/19 1.000 EA
Page 7 of 11
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
PE-0000001 ZRTG PE ASSEMBLY 1.000 EA
Page 8 of 11
Product Information Packet: 35W191Q080G1 - 1.5HP,3500RPM,1PH,60HZ,56CZ,3535LC,TEFC
No performance data has been
assigned to this product.
