Badger Meter EPM-2 User Manual

Automotive Flow Measurement and Control Products
Control. Manage. Optimize.
Automotive Flow Measurement and Control Products
When every drop counts, choose automotive ow measurement and control products from Badger Meter. Precisely control and monitor dispensing and inventory of motor oil, gear oil, automatic transmission uid, antifreeze, brake uid, windshield wiper uid, and engine coolant. Badger Meter oers positive displacement meters in a wide variety of construction materials with accessories to meet the most demanding applications.
Applications
• Fleet Maintenance
• Quick Lube
• Dealerships
• Construction
• Mining
• General Automotive Service
• Specialty Service
Fluids
• Motor Oil
• Engine Coolant
• Automatic Transmission Fluid
• Brake Fluid
• Windshield Wiper Fluid
• Gear Oil
• Hydraulic Fluid
• Waste Oil
2
Fluid Management System
The Fluid Management System (FMS) controls and monitors automotive fluid product consumption and inventory balances with minimal installation and programming costs. FMS incorporates 2.4 GHZ radio frequency for effective communications and the rugged EPM-3 RF flow meter.
FMS Distributed System:
• PC-Based Work Order Queue Software
• Transaction database Stores up to:
• 250 Meters
• 250 Users
• 16 Fluid/Tanks
• 36 Dispense Keypads
FMS Stand-Alone System:
The wall-mounted keypad module controls up to 30 meters and eight dierent uid containers and denes up to 50 operators with unique PIN numbers.
• 2.4 GHZ Radio Frequency Communications
• 8 Fluids and Tanks
See FMS Distributed System Diagram on Page 5
Features
• Low installation cost
• Controls portable fluid tanks
• Integral ticket printer
• Remote antenna (optional)
Model EPM-3 RF Flow Meters:
• 2.4 GHZ Radio Frequency Communications
• Standard Petroleum Product & Special Fluids
• Compatible with both Distributed and Stand-Alone FMS Systems
Features
• Patented lock-out helps prevent unauthorized dispenses
• Oval gear metering technology
• Measures pints, quarts, gallons, or liters
See FMS Stand-Alone System Diagram on Page 6
• Field replaceable AA batteries
3
Distributed Fluid Management System
Host (ERP or DMS)
Dispense Keypad
FMS Software
Printer
Master Keypad
Dispense Keypad
Product 1 Product 2
Product 3
4
Stand-Alone Fluid Management System
Keypad
Up to 30 RF Meters per Keypad
Hose
1:1 with Meter
10-W-30 10-W-40
Up to 8 Fluid Types and 8 Tanks per Keypad
1:1 with Meter
Gear Oil
Hose
Trans Fluid
5
Electronic Preset Series - 2
The versatile, second generation Badger Meter Electronic Preset Meter (EPM-2) displays dispense totals in quarts, liters, pints, and gallons and can be eld selected. A ve-digit LCD is accurate to the second decimal place. A “stop” function stops uid ow immediately, while pulling on the handle continues dispensing. Maximum preset volume is 99.9 units and can be totalized and dispensed up to 99,999 units. EPM-2 SF dispenses non­petroleum based products.
Model EPM-2 STD: Standard Register Model EPM-2 STD-SF: Standard Register, Special Fluid
Features
• Measures motor oils, gear oils, automatic transmission fluids, engine coolant, and hydraulic fluids
• Total and resettable total
• Minimum 20,000 battery life cycles
• Low battery safety lock out
• Automatic pre-set shut-off
Model EPM-2 ADV: Advanced Register
Model EPM-2 ADV-SF: Advanced Register, Special Fluid
Features
• Six programmable presets
• History (previous five batches)
• Viewable flow rate
• Calibration factor for different fluids
• Total and resettable total
• Minimum 20,000 battery life cycles
• Low battery safety lock out
• Automatic pre-set shut-off
6
Oval Gear Series
When combined with electronic registers, oval gear technology delivers a simple and accurate way to measure dispensed bulk uid. Standard Badger Meter oval gear products are used for petroleum applications and transmission uid. A special uid model oers an excellent solution for dispensing antifreeze, brake uid, windshield wiper uid, and engine coolant. The Oval Gear Enhanced (OGE) meter can handle ow rates up to 20 GPM (3/4 in. and 1 inch versions) and up to 8 GPM (1/2 inch version). These meters are the optimum choice for higher ow dispensing applications.
• 1,500 PSI pressure rating
• Large, precise six digit LCD
• Measures pints, quarts, gallons, liters
• Operating temperature range -4° F to 140° F
• The Oval Gear Enhanced PVC (OGE-PVC) model is designed for dispensing diesel exhaust fluid, commonly used in emission
systems emission systems
• Oval Gear Transmitters (OGT) have a pulse output for interfacing with fluid control systems
• Fully customizable with genuine Badger Meter accessories
Model OGE; Model OGE-SF; Model OGE-HF; Model OGE-HF-SF:
• 1/2, 3/4 and 1 in.
• Electronic Programmable Registration
• Scalable for Different Fluids
Model OGT; Model OGT-HF; Model OGT-HF-SF:
• 1/2, 3/4 and 1 in.
• Pulse Output, Unscaled Transmitter
Model OGE-PVC; Model OGT-PVC:
• 1/2 in.
• Pulse Output, Unscaled Transmitter
• Electronic Programmable Registration
• Scalable for Different Fluids
7
Pistol Grip Series
The Pistol Grip Series (PG) works with a variety of petroleum products that service automobiles, trucks, buses, construction equipment, and similar indoor or outdoor applications. Its balanced, lightweight, rugged construction and comfort grip make it the best choice for overhead hose reels and other fluid applications. The Pistol Grip Electronic Meter has advanced microprocessing technology for electronic field recalibration.
Made in America
Model PG
Model PGB,
Model AF
Model PGE,
Model PGE-BF
Product Dial Capacities Lifetime Totalizer Register
Product Dial Capacities Lifetime Totalizer Register
Product
Dispense Totalization Lifetime Totalizer
Pistol Grip Standard Pints, Quarts, Gallons, Liters Pints, Quarts, Gallons, Liters
Pistol Grip Batch (Presettable) Quarts, Gallons, Liters Quarts, Gallons, Liters
Pistol Grip Electronic (PGE) and Pittol Grip Electronic- Brake Fluid (PGE-BF) Pints, Quarts, Liters, Gallons Gallons, Liters
Model PG
Model PGB
Model AF
Model PGE
Model PGE-BF
8
Universal Series
For reliable inventory control for lubricant dispensing systems, rely on the robust Universal Series designed for in-line applications. Equipped with a pulsing device, the Universal Series features an outlet port that can be rotated in 90 degree increments and is available with or without a totalizing register.
Made in America
Model UL
Model UH
Model UP
Product Dial Capacities
Product Dial Capacities Lifetime Totalizer Register
Product Pulses per Revolution Units of Measure
Universal Law 8 Pints
Model UL
Universal High Ounces, Pints, Quarts, Gallons, Liters Pints, Quarts, gallons, Liters
Universal Pulse 10 Pulses Pints, Quarts, Gallons, Liters
Model UH
Model UP
9
Industrial Oval Gear
The industrial oval gear ow meter, Model IOG, is compatible with very viscous or highly corrosive uids. It is available in two dierent construction materials: aluminum with liquid crystal polymer gears and stainless steel with stainless steel gears. Designed to withstand extreme conditions, the Model IOG provides high accuracy at ±0.5 percent, even in low ow environments. The meter operates up to 800 PSI and can be installed in tight spaces either vertically or horizontally and does not require a straight run of pipe or ow conditioning. Initial product oering includes 1/2, 3/4 and 1 inch sizes with inline National Pipe Thread and British Straight Pipe Thread or anged in 150, 300 and DIN 16.
Industrial oval gear meter registers are protected with a strong, shock­resistant housing and powered by a ve-year lithium battery. Four register options are available for use with the Model IOG including the ILR 700 Standard Register, ILR 710 Single Pulse Output, ILR 720 Dual Pulse Output, ILR 730 Analog Output, and ILR 740 Transmitter.
Aluminum with Liquid Crystal:
• Petroleum
• Non-aids
• Oil
• Paint
• Ink
Stainless Steel with Stainless Steel Gears:
• Cosmetic
• Acid
• Water mix
• Fertilizer
Registers:
• ILR 700 Standard Register
• ILR 710 Single Pulse Output
• ILR 720 Dual Pulse Output
• ILR 730 Dual Pulse Output
• ILR 740 Transmitter
10
Why Choose Badger Meter for Automotive Flow Measurement and Control Products?
Experience
With more than 100 years of experience as a trusted leader in ow measurement, Badger Meter has supplied more than 1 million automotive ow measurement and control products to commercial, retail and industrial companies worldwide.
Selection
Our comprehensive product line and versatile accessories assure a solution engineered both for petroleum and special uids.
Durable Functionality
Rugged construction, light weight modular design and reliable, easy-to-use simplicity are built into every one of our meters, including our precision electronic models.
Quality and Technology
State-of-the-art manufacturing and inspection processes assure product quality and long lasting measuring accuracy. Every meter is subjected to rigorous testing to ensure quality.
11
Control. Manage. Optimize.
Trademarks appearing in this document are the property of their respective entities. Due to continuous research, product improvements and enhancements, Badger Meter reserves the right to change product or system specifications without notice, except to the extent an outstanding contractual obligation exists. © 2015 Badger Meter, I nc. All rights reserved.
www.badgermeter.com
