Page 1
FOR THE LOVE OF SEWING
LBSP-BLR2
www.babylock.com
Sewing & Embroidery machines
Sewing & Embroidery machines
ellure plus & ellure
FOR THE LOVE OF SEWING
800-422-2952
Sewing Features Ellure Plus (BLR2) Ellure (BLR)
Total Built-in stitches 205 187
Utility 71 67
Decorative 51 51
Satin 18 satin, 11 decorative satin 16
Cross 15 14
Combinable Utility stitches 39 39
Built-in alphabet styles 3 0
Buttonholes; type 10; 1-step 10; 1-step
Needle positions 15 15
Needle threader Built-in Built-in
Auto needle up/down Yes-programmable Yes-programmable
Side feeding Yes No
Bobbin loading Quick-Set, top-loading Quick-Set, top-loading
Bobbin winding Quick-Set, bobbin winder Quick-Set, bobbin winder
Knee lift Yes No
Extension table Optional Optional
Thread cutter Auto Auto
Maximum stitch length in mm 5 5
Maximum stitch width in mm 7 7
Tension Automatic Automatic
Retractable feed dogs Ye s Yes
Variable speed control Yes Yes
Free arm Ye s Yes
Number of feet included 11 8
Accessory storage Built-in Built-in
Warranty
• 25-year limited manufacturer’s warranty
• 10-year parts
• 5-year circuit board
• 5-year electrical
• 1-year labor
Optional Gold Standard
service and support program
Yes - see retailer for details No
Embroidery
Features
Ellure Plus (BLR2)
Ellure (BLR)
Built-in designs 106 including one
script and 40 exclusives
106 including one script
and 40 exclusives
Built-in
embroidery
alphabet styles
6 6
Frame patterns 120 120
Embroidery field 5” x 7” 5” x 7”
Rotation 1, 10, and 90 degree 1, 10, and 90 degree
Sizing 20% up, 10% down 20% up, 10% down
Data input USB (type B), Cards Cards
Embroidery
pattern memory
Yes Yes
Embroidery speed 650 SPM 650 SPM
Format PES, PEC PES, PEC
Number of hoops
included
2 1
Built-in needle
threader
Yes Yes
Mirror image Yes Yes
Low bobbin
indicator
Yes Yes
Ellure Plus & Ellure Sewing Features
Ellure Plus & Ellure Embroidery Features
Page 2
Introducing the new Ellure Plus & Ellure Sewing &
Embroidery Machines
The Baby Lock Ellure has the perfect amount of advanced features for
avid sewers and beginning embroiderers. With an LCD touch screen,
187 built-in stitches, and 106 built-in embroidery designs, you’ll have
the freedom to add a unique touch to all of your projects.
And now, Baby Lock’s NEW Ellure Plus gives you the ability to
take your creativity even further. The Ellure Plus includes all of the
advanced features of the Ellure and more. The USB (type B) port
lets you easily expand your embroidery design collections. Sewing
is also more convenient with the hands-free presser foot lift, which
allows you to lift your presser foot with the tap of your knee. And with
a variety of built-in designs, optional hoop and 205 built-in stitches,
you’ll have the versatility and resources that you’ve been looking for
in a sewing and embroidery machine.
For the love of sewing.
Embroidery Design Library
Built-In
With 120 frame patterns, 6 fonts
in upper and lower case, and 106
built-in embroidery designs which
include 40 Baby Lock exclusive
designs, you’ll have an endless
variety of options to make sure
your projects are unique.
Large Embroidery Field
M a^ . Q 0 ahhi ` bo^ l rh n f hk^
room to complete projects of
virtually any size. Optional hoops
in other sizes are also available.
Ellure Plus and Ellure Embroidery Features
LCD Touch Screen
(120 x 64 dot matrix)
The large, easy-to-read LCD
touch screen makes accessing
the Ellure’s settings, designs, and
editing tools fast and simple.
Embroidery Lettering
Choose from 6 character/
alphabet styles for monograms or
text to t projects of any style.
Built-in Stitches
Give all of your projects a
customized and intricate look
with built-in stitches, including
combinable utility stitches,
decorative, cross, utility and
satin stitches, as well as one-step
buttonholes.
Optional Extension Table
Great for quilting, the optional
table is also a helpful addition for
any bulky or large projects.
Quick-Set, Top-Loading
Bobbin
Now loading your bobbin is
fast and easy! In addition to the
convenient location, the bobbin
case has a clear cover so you see
your progress and avoid running
out of thread mid-stitch.
Ellure Plus and Ellure Key Sewing Features
Baby Lock Accessories
There are many great accessories
available for your Baby Lock
machines - ask your Baby Lock
Retailer about them today.
Features on the Ellure Plus and Ellure
• Built-in Embroidery Design Library
• 106 embroidery designs which include
an elegant script font and 40 Baby Lock
exclusive designs
• 120 Frame Patterns
• 6 Font styles in upper and lower case
• Embroiders up to 5” x 7” (130mm x
180mm) embroidery field
• Reads embroidery designs with a stitch
capacity of up to 50,000 stitches per design
• Up to 12 Memory Pockets for embroidery
equaling 512KB/150,000 stitches
• Pattern editing
• Enlargement (up to 20%)
• Reduction (up to 10%)
• Mirror imaging
• 1°, 10°, and 90° pattern rotation
• LCD touch screen (120 x 64 dot matrix) shows
• Estimated embroidery time display and
stitch count
• Needle position placement (1, 10, or 100
stitch increments)
• Measurements displayed in inches or
millimeters (mm)
• Thread color indicator
• On-screen hoop size indicator
• 8-point trial check points
• Embroidery speed up to 650 spm (stitches
per minute)
• 300 color names
Embroidery Capabilities
• Language conversion capabilities
(14 languages)
• Warranty (25 years limited, 10
years parts, 5 years computer
circuit, 5 years electrical, 1 year
labor)
• Optional extension table
• Optional embroidery hoops
• Medium 4” x 4”
• Small 1” x 2-1/2”
• Multi-position 5” x 12” (included
with Ellure Plus)
Additional Information
• Convenient One-Touch Buttons
• Start/Stop
• Reverse sewing
• Needle up/down
• Thread cutter
• Programmable needle up/down
• Needle plate with scale in inches
and centimeters
• Electronic foot control with separate
power cord
• Free arm with drop feed lever
• Accessory storage compartment
Convenient Sewing Features
• Hard cover for machine
• Bobbin center pin (for pre-wound
bobbin)
• Embroidery bobbin thread (White)
• Bobbins
• Seam ripper
• Twin needle
• Plus more
Included Accessories
• Built-in Operational Guide
Instructional and Help Resources
Technology Features
• LCD touch screen (120 x 64 dot matrix)
• Embroidery card slot
• Advanced needle threader
• Automatic thread cutter
• Quick-Set, top-loading bobbin
• Quick-Set, bobbin winder
• Upper and lower thread sensors to alert
when threads are broken
• 2 LED lights illuminate sewing surface
• Sewing speed up to 850 spm
Advanced Sewing Features
• Stitch length 0.0mm - 5.0mm on
sewing stitches
• Maximum Utility stitch width: 7mm
• Utility stitch editing capabilities
• Store personal stitch settings for
each Utility stitch on machine
• Decorative stitch editing capabilities
• Edit and combine Character/
Decorative stitches
• 10 Memory pockets for Character
or Decorative stitches; allows 70
entries per pocket
• Lock key for Utility and Decorative
stitches
• Variable needle positions
• Twin needle settings key
Ellure Plus Features
Advanced Sewing Features
• 205 Built-in stitches including:
• 71 Utility (with 10 styles of
one-step buttonholes)
• 51 Decorative
• 18 Satin
• 11 Decorative satin
• 15 Cross
• 39 Combinable Utility stitches
• 3 Alphabet Styles
• Side feeding
Included Accessories
• USB cable
• 12 Snap-on feet
• Buttonhole
• Embroidery
• Overcasting
• Monogramming
• Zipper
• Zigzag
• Blind stitch
• Button tting
• Non-stick
• Open toe
• Stitch guide
• Adjustable zipper/piping
• 2 Hoops included:
• 5” x 7” Embroidery hoop and grid
• 5” x 12” Embroidery hoop and grid
• Alternate bobbin case for use with
pre-wound bobbins
Advanced Sewing Features
• 187 Built-in stitches including:
• 67 Utility (with 10 styles of
one-step buttonholes)
• 51 Decorative
• 16 Satin
• 14 Cross
• 39 Combinable Utility stitches
Included Accessories
• 8 Snap-on feet
• Buttonhole
• Overcasting
• Monogramming
• Zipper
• Zigzag
• Blind stitch
• Button tting
• Embroidery
• 5” x 7” Embroidery hoop and grid
Ellure Features
205 Built-in Stitches
The Ellure Plus has all of your
favorites and more with 205
[ nbem& bg lmbm\ a^ l % bg\ en] bg` 0*
utility stitches, 51 decorative,
18 satin, 11 decorative satin,
15 cross stitches. There are
also 3 alphabet styles.
USB (type B)
Let your design collection
grow larger than you’ve ever
imagined with the easy-to-use
USB (type B) port.
Additional Information
• Optional Gold Standard service and
support program for your peace of
mind (available in U.S.)
Hands-Free Presser Foot Lift
You won’t have to sacrifice precision
for convenience with the Ellure Plus
– lift your presser foot while keeping
both of your hands free for sewing.
Multi-Position Hoop
Embroider extra large or connected
designs with this specialty hoop,
which includes multiple brackets that
allow you to move the hoop up and
down the fabric.
Upgraded Accessories
Ellure Plus Upgraded
Features
