AXIS P37-PLE, P3717-PLE, P3719-PLE Instructions Manual

AXIS P37-PLE Network Cameras

AXIS P3717-PLE Network Camera

AXIS P3719-PLE Network Camera

Repainting Instructions

AXIS P37-PLE Network Cameras

Impact on warranty

Impact on warranty

This product is approved for repaint by Axis, provided that you follow the instructions in this document and at

www.axis.com/warranty-implication-when-repainting

Risks with repainting

There are several risks when disassembling or assembling an Axis product. There is always a certain yield loss during assembly. Training
of operators and the use of correct tools mediates some of the problems but they can never be fully avoided. Some of the risks include:

ESD Damage - Always handle the product in an ESD safe environment. Even if precautions are taken there is always a risk of ESD
damage. The damage can remain undetected and cause problems during the lifetime of the equipment.

Dust contamination - Opening a camera may expose the lens and sensor to dust or paint. Dust will affect the optical performance.
Lenses need to be disassembled in a dust-free environment, preferably a cleanroom.

Paint overspray - Masking the different components of the equipment is critical. Failure to mask sensitive areas can cause problems
with assembling the equipment. Any areas that are not painted at factory or have a different surface treatment than the rest of the
parts (threads, ground and electrical contact surfaces) must also be masked to ensure function.

2

AXIS P37-PLE Network Cameras

How to repaint the product

How to repaint the product

Preparations

• If applicable, disassemble the equipment according to the instructions in this document.

• Clean all parts to be repainted thoroughly to remove grease, dust, or oil.

• To ensure reassembly and functionality of the product, mask openings for screws, LED indicators, or microphones before
painting.

Pretreatment of parts

Depending on the part material and type of paint applied at factory, different pretreatment should be done for the new paint to
adhere as well as possible. Clean the parts properly to remove oil, grease and dust.

For more information on the materials used in the product, see its datasheet at www.axis.com

Powder coated parts - Use a primer. Alternatively, remove the original powder coating down to the base material, using ne
sandpaper, and clean the parts before painting.

Anodised and chromated parts - Use a primer.

Uncoated stainless steel - No special pretreatment is needed, but make sure that the surface is clean before painting.

Plastic - Use a primer.

Disassembly

3
