AXIS M5525-E User Manual

AXISM5525-EPTZNetworkCamera

UserManual

AXISM5525-EPTZNetworkCamera

TableofContents

Productoverview...........................................3

Howtoconnectamicrophonetothecamera....................4

Howtoaccesstheproduct....................................5

Howtoaccesstheproductfromabrowser...........................5

Aboutsecurepasswords..........................................5

Setup.....................................................7

Abouttheproduct'sbuilt-inhelp...................................7

Imagequality...................................................7

Privacymasks..................................................9

Overlays.......................................................9

PTZ(PanTiltZoom)..............................................10

Streamingandstorage...........................................10

Events........................................................11

Applications....................................................15

Troubleshooting............................................16

Howtoresettofactorydefaultsettings.............................16

Checkthecurrentrmware.......................................16

Upgradethermware............................................16

Technicalissues,cluesandsolutions................................17

Performanceconsiderations.......................................

Specications..............................................19

LEDindicators..................................................

SDcardslot....................................................

Buttons.......................................................

Connectors....................................................

18

19
19
19
19

2

AXISM5525-EPTZNetworkCamera

Productoverview

Productoverview

1

SDcardslot(microSD)

2

Controlbutton

3

StatusLED

4

RJ45connector

5

Audioin

6

Audioout

7

I/Oconnector

8

Powerconnector

3

AXISM5525-EPTZNetworkCamera

Howtoconnectamicrophonetothecamera

Howtoconnectamicrophonetothecamera

Thisexampleexplainshowtoconnectamicrophonetothecamerausinganaudioextensioncable.

Requiredhardware

•AXIST8351Microphone3.5mm

•AXISAudioExtensionCableA,5m(16ft)

Note

•Toavoidnoise,don'trunthecableclosetoorinparallelwithothercables.

•Toavoidnoise,cutthecableasshortaspossible.

•TomaintainIP66rating,makesureyoukeepthejackinsidethehousing.

Connectthecables

1.Keepthe3.5mmjackandcuttheaudioextensioncable.

2.Striptheoutercableinsulation.

3.Striptheinnerwireinsulation.

4.Twisttheaudiowires(withinsulation)together.

5.Twistthegroundingwires(withoutinsulation)together.

6.ConnecttheaudiowirestotheAUDIOINpinonthecamera.SeeProductoverviewonpage3.

7.ConnectthegroundingwirestotheGNDAUDIOINpinonthecamera.

8.Connectthemicrophonetothejackoftheaudioextensioncable.

9.Turnonaudioandadjustotheraudiosettingsinthecamera'swebpage.

4

AXISM5525-EPTZNetworkCamera

Howtoaccesstheproduct

Howtoaccesstheproduct

AXISIPUtilityandAXISCameraManagementarerecommendedmethodsforndingAxisproductsonthenetworkandassigning
themIPaddressesinWindows®.Bothapplicationsarefreeandcanbedownloadedfromaxis.com/support

Theproductcanbeusedwiththefollowingbrowsers:

•Chrome

•Chrome

•Chrome

Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoaxis.com/browser-support

TM

(recommended),Firefox

TM

(recommended)orSafari

TM

orFirefox

®

withotheroperatingsystems.

Howtoaccesstheproductfromabrowser

1.Startawebbrowser.

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’saddresseld.

®

,Edge

®

®

,orOpera

withOSX

®

withWindows

®

®

ToaccesstheproductfromaMaccomputer(OSX),gotoSafari,clickonBonjourandselecttheproductfromthe
drop-downlist.ToaddBonjourasabrowserbookmark,gotoSafari>Preferences.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabout
howtodiscoverandassignanIPaddress,seethedocumentAssignanIPAddressandAccesstheVideoStreamonAxis
Supportwebataxis.com/support

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe
congured.

4.Theproduct’sliveviewpageopensinyourbrowser.

Aboutsecurepasswords

Important

Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set
upasecureandencryptedHTTPSconnectionandthenchangethepassword.

Thedevicepasswordistheprimaryprotectionforthedataandservices.Axisdevicesdonotimposeapasswordpolicyastheymaybe
usedinvarioustypesofinstallations.Toprotectyourdatawerecommendthatyou:

•Changethedefaultpasswordthatcomeswiththedevices.

•Useapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.

•Don’texposethepassword.

•Changepasswordatarecurringinterval,atleastonceayear.

Setasecurepasswordfortherootaccount

Important

Thedefaultadministratorusernamerootcannotbedeleted.Ifthepasswordforrootislost,thedevicemustberesetto
thefactorydefaultsettings.

1.Makesuretofollowtheinstructionsaboutsecurepasswords.SeeAboutsecurepasswordsonpage5.

2.Typeapasswordandthenretypeittoconrmthespelling.

5

AXISM5525-EPTZNetworkCamera

Howtoaccesstheproduct

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

6

AXISM5525-EPTZNetworkCamera

Setup

Setup

Abouttheproduct'sbuilt-inhelp

Youcanaccessthebuilt-inhelpthroughyourproduct’swebpage.Thehelpprovidesmoredetailedinformationontheproduct’s
featuresandtheirsettings.

Imagequality

Howtoselectexposuremode

Therearedifferentexposuremodeoptionsinthecamerathatadjustsaperture,shutterspeed,andgaintoimproveimagequalityfor
specicsurveillancescenes.GotoSettings>Image>Exposureandselectbetweenthefollowingexposuremodes:

•Formostusecases,selectAutomaticexposure.

•Forenvironmentswithcertainarticiallighting,forexampleuorescentlighting,selectFlicker-free.

Selectthesamefrequencyasthepowerlinefrequency.

•Forenvironmentswithcertainarticiallightandbrightlight,forexampleoutdoorswithuorescentlightingatnightand
sunduringdaytime,selectFlicker-reduced.

Selectthesamefrequencyasthepowerlinefrequency.

•Tolockthecurrentexposuresettings,selectHoldcurrent.

HowtobenetfromIRlightinlow-lightconditionsusingnightmode

Yourcamerausesvisiblelighttodelivercolorimagesduringtheday.Aslightdiminishes,youcansetthecameratoautomatically
shifttonightmode.Innightmodethecamerausesbothvisiblelightandnear-infraredlighttodeliverblack-and-whiteimages.
Sincethecamerausesmoreoftheavailablelightitcandeliverbrighter,moredetailed,images.

1.GotoSettings>Image>Dayandnight,andmakesurethattheIRcutlterissettoAuto.

Howtohandlesceneswithstrongbacklight

Tomakebothdarkandbrightareasoftheimagevisible,turnonWDR.

1.GotoSettings>Image.

2.TurnonWDRunderWidedynamicrange.

7

AXISM5525-EPTZNetworkCamera

Setup

ImagewithoutWDR.

ImagewithWDR.

Note

IfyouuseWDR,youmayexperiencesomeWDRartifactsintheimage.

FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr

Howtoenhancefacialrecognition

Tobetterrecognizethefaceofapersonpassingbythecamera,youcansettheoptimalpixelresolutionwiththecamera’spixel
counter.

1.GotoSettings>System>Orientationandclick.

8

AXISM5525-EPTZNetworkCamera

Setup

2.Adjustthesizeandplacementoftherectangleinthecamera’sliveviewaroundtheareaofinterest,forexamplewhere
thefacesofpassingpersonsareexpectedtoappear.Youcanthenseethenumberofpixelsrepresentedbythesidesof
therectangle.

Note

Youcanuseanobjectofaknownsizeintheviewasareferencetodecidehowmuchresolutionisneededforrecognition.

Privacymasks

Howtohidepartsoftheimagewithprivacymasks

Whatisaprivacymask?

Aprivacymaskisauser-denedareathatpreventsusersfromviewingapartofthemonitoredarea.Inthevideostream,privacy
masksappearasblocksofsolidcolor.

Theprivacymaskisrelativetothepan,tilt,andzoomcoordinates,soregardlessofwhereyoupointthecamera,theprivacy
maskcoversthesameplaceorobject.

You’llseetheprivacymaskonallsnapshots,recordedvideo,andlivestreams.

YoucanusetheVAPIX®applicationprogramminginterface(API)toturnofftheprivacymasks.

Important

Usingmultipleprivacymasksmayaffecttheproduct’sperformance.

Howtocreateaprivacymask

Tocreateaprivacymask,gotoSettings>Privacymask.

Overlays

Aboutoverlays

Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,
orduringproductinstallationandconguration.

Howtoshowatextoverlaywhenthecameradetectsmotion

Thisexampleexplainshowtodisplaythetext“Motiondetected”whenthecameradetectsmotion:

MakesuretheAXISVideoMotionDetectionapplicationisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Addtheoverlaytext:

4.GotoSettings>Overlay.

5.Enter#Dinthetexteld.

6.Choosealignment,textsizeandappearance.

7.Includethetextoverlay.

Createanactionrule:

9

AXISM5525-EPTZNetworkCamera

Setup

8.GotoSystem>Events>Actionrules.

9.CreateanactionrulewithAXISVideoMotionDetectionastrigger.

10.Fromthelistofactions,selectOverlaytext.

11.Type“Motiondetected”.

12.Settheduration.

Note

Ifyouupdatetheoverlaytextitwillbeautomaticallyupdatedonallvideostreamsdynamically.

PTZ(PanTiltZoom)

Howtolimitpan,tilt,andzoommovements

Inthisexample,thecameraissurveillingaparkinglotwithnearbyapartmentbuildings.Setpan,tiltandzoomlimitstoensure
privacyforresidents.

Tolimitpan,tiltandzoommovements,gotoSettings>PTZ>Limits.

Streamingandstorage

Howtochoosevideocompressionformat

Decidewhichcompressionmethodtousebasedonyourviewingrequirements,andonthepropertiesofyournetwork.The
availableoptionsare:

MotionJPEG

MotionJPEGorMJPEGisadigitalvideosequencethatismadeupofaseriesofindividualJPEGimages.Theseimagesarethen
displayedandupdatedataratesufcienttocreateastreamthatshowsconstantlyupdatedmotion.Fortheviewertoperceivemotion
videotheratemustbeatleast16imageframespersecond.Fullmotionvideoisperceivedat30(NTSC)or25(PAL)framespersecond.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage
containedinthestream.

H.264orMPEG-4Part10/AVC

Note

H.264isalicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed
copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedtotheMotion
JPEGformatandbyasmuchas50%comparedtotheMPEG-4standard.Thismeansthatlessnetworkbandwidthandstoragespace
arerequiredforavideole.Orseenanotherway,highervideoqualitycanbeachievedforagivenbitrate.

Howtoreducebandwidthandstorage

Important

Ifyoureducethebandwidthitcanresultinlossofdetailsinthepicture.

1.GotoliveviewandselectH.264.

2.GotoSettings>Stream.

3.Dooneormoreofthefollowing:

10

AXISM5525-EPTZNetworkCamera

Setup

-TurnontheZipstreamfunctionalityandselectthedesiredlevel.

-TurnondynamicGOPandsetahighGOPlengthvalue.

-Increasethecompression.

-TurnondynamicFPS.

Howtosetupnetworkstorage

Tostorerecordingsonthenetwork,youneedtosetupnetworkstorage:

1.GotoSettings>System>Storage.

2.ClickSetupunderNetworkstorage.

3.EntertheIPaddressofthehostserver.

4.Enterthenameofthesharedlocationonthehostserver.

5.Movetheswitchifthesharerequiresalogin,andenterusernameandpassword.

6.ClickConnect.

Howtoaddaudiotoyourrecording

Editthestreamprolewhichisusedfortherecording:

1.GotoSettings>System>Streamproles.

2.SelectthestreamproleandclickModify.

3.IntheAudiotab,selecttheAudiostreamcheckboxandselectOnfromthedrop-downlist.

4.ClickOk.

Events

Aboutevents

Theeventpagesallowyoutocongureyourproducttoperformactionswhendifferenteventsoccur.Forexample,theproduct
canstartarecordingorsendanemailnoticationwhenmotionisdetected.Thesetofconditionsthatdeneshowandwhen
theactionistriggerediscalledanactionrule.

Howtodirectthecameratoapresetpositionwhenthecameradetectsmotion

Thisexampleexplainshowtosetupthecameratogotoapresetpositionwhenitdetectsmotionintheimage.

MakesuretheAXISVideoMotionDetectionapplicationisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Addapresetposition:

4.GotoSettings>PTZandsetwhereyouwantthecameratobedirectedbycreatingapresetposition.

Createanactionrule:

5.GotoSettings>System>Events>Actionrulesandaddanactionrule.

11

AXISM5525-EPTZNetworkCamera

Setup

6.Typeanamefortheactionrule.

7.Fromthelistoftriggers,selectApplicationsandthenselectAXISVideoMotionDetection(VMD).

8.Fromthelistofactions,selectPTZControlandthenselectPresetPosition.

9.Selectthepresetpositionyouwantthecameratogoto.

10.ClickOk.

HowtorecordvideowhenaPIRdetectorsensesmotion

ThisexampleexplainshowtoconnectanAxisPIRdetectortothecamera,andsetupthecameratostartrecordingwhenthe
detectorsensesmotion.

Requiredhardware

•3–wirecable(ground,power,I/O)

•AxisPIRdetector

NO

TICE

NO NO

TICE TICE

Disconnectthecamerafrompowerbeforeconnectingthewires.Reconnecttopowerafterallconnectionsaredone.

Connectthewirestothecamera’sI/Oconnector

Note

ForinformationontheI/Oconnector,seeConnectorsonpage19

1.Connectthegroundwiretopin1(GND/-).

2.Connectthepowerwiretopin2(12VDCoutput).

3.ConnecttheI/Owiretopin3(I/Oinput).

ConnectthewirestothePIRdetector’sI/Oconnector

1.Connecttheotherendofthegroundwiretopin1(GND/-).

2.Connecttheotherendofthepowerwiretopin2(DCinput/+).

3.ConnecttheotherendoftheI/Owiretopin3(I/Ooutput).

ConguretheI/Oportinthecamera’swebpage

1.GotoSettings>System>I/Oports.

2.SelectInputinthePort1drop-downlist.

3.Givetheinputmoduleadescriptivename.

4.TomakethePIRdetectorsendasignaltothecamerawhenitsensesmotion,selectClosedcircuitinthedrop-downlist.

12

AXISM5525-EPTZNetworkCamera

Setup

TotriggerthecameratostartrecordingwhenitreceivesasignalfromthePIRdetector ,youneedtocreateanactionruleinthe
camera’swebpage.

Useaudiotodeterintruders

Thisexampleexplainshowtoconnectaspeakertothecameraandsetituptoplayawarningmessagewhenthecameradetects
motioninarestrictedarea.

Requiredhardware

•Activespeakerwithbuilt-inamplierandconnectingwires

NO

TICE

NO NO

TICE TICE

Makesurethecameraisdisconnectedfrompowerbeforemakingtheconnections.Reconnecttopowerafterconnectingthe
wires.

Physicalconnection

1.ConnecttheaudiowirefromthespeakertotheAUDIOOUTpinonthecamera.SeeProductoverviewonpage3.

2.ConnectthegroundingwirefromthespeakertotheGNDAUDIOOUTpinonthecamera.SeeProductoverviewonpage3.

Addaudiocliptothecamera

1.GotoSettings>Audio>Outputandclick

2.ClickAdd.

3.SelectUploadunderAddAudioClipOptions.

4.BrowsetolocatetheaudioclipandclickUpload.

Totriggerthecameratoplaytheaudioclipwhenitdetectsmotion,createanactionruleinthecamera’swebpage.

toaddyouraudioclip.

Howtodirectthecameraandopenthelocktoagatewhensomeoneisnearby

Thisexampleexplainshowtodirectthecameraandopenagatewhensomeonewantstoenterduringdaytime.Thisisdoneby
connectingaPIRdetectortotheproduct’sinputportandaswitchrelaytotheproduct’soutputport.

Requiredhardware

•MountedPIRdetector

•Switchrelayconnectedtothegatelock,inthiscasetheswitchisnormallyclosed(NC)

•Connectingwires

Physicalconnection

1.ConnectthewiresfromthePIRdetectortotheinputpin,seeI/Oconnectoronpage20.

2.Connectthewiresfromtheswitchtotheoutputpin,seeI/Oconnectoronpage20

CongureI/Oports

Youneedtoconnecttheswitchrelaytothecamerainthecamera’swebpage.First,conguretheI/Oports:

SetthePIRdetectortoaninputport

1.GotoSystem>I/Oports.

13

AXISM5525-EPTZNetworkCamera

Setup

2.SelectInputinthePort1drop-downlist.

3.Givetheinputmoduleadescriptivename,forexample“PIRdetector”.

4.TotriggeraneventwheneverthePIRdetectorsensesmotion,selectOpencircuitinthedrop-down

list.

Settheswitchrelaytoanoutputport

1.GotoSystem>I/Oports.

2.SelectOutputinthePort2drop-downlist.

3.Givetheoutputmoduleadescriptivename,forexample“Gateswitch”.

4.Toopenthegatewheneveraneventistriggered,selectClosedcircuitinthedrop-downlist.

Createactionrules

ForthecameratoopenthegatewhenthePIRdetectorsensessomeonenearby,youneedtocreateanactionruleinthecamera:

1.GotoSystem>Events>Actionrules.

2.ClickAdd.

3.Givetheactionruleaname,forexample“Opengate”.

4.FromtheTriggerdrop-downlist,selectInputsignal.

5.SelectDigitalinputsignal.

6.Select”PIRdetector”,inthisexampleconnectedtoport1.

7.UnderActions,selectOutputportfromtheTypedrop-downlist.

8.FromthePortdrop-downlist,select“Gateswitch”.

9.ClickOk.

10.Createanotheractionrulewiththename“Directthecameratothegate"

11.Selectthesameinputsignalasbefore,butasactionselectthepreviouslycreated“Gateentrance”presetposition.

14

AXISM5525-EPTZNetworkCamera

Setup

12.ClickOk.

Applications

Aboutapplications

AXISCameraApplicationPlatform(ACAP)isanopenplatformthatenablesthirdpartiestodevelopanalyticsandotherapplications
forAxisproducts.Tondoutmoreaboutavailableapplications,downloads,trialsandlicenses,gotoaxis.com/applications

TondtheusermanualsforAxisapplications,gotoaxis.com

Note

•Severalapplicationscanrunatthesametimebutsomeapplicationsmightnotbecompatiblewitheachother.Certain

combinationsofapplicationsmightrequiretoomuchprocessingpowerormemoryresourceswhenruninparallel.Verify
thattheapplicationsworktogetherbeforedeployment.

15

AXISM5525-EPTZNetworkCamera

Troubleshooting

Troubleshooting

Howtoresettofactorydefaultsettings

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultresetsallsettings,includingtheIPaddress,to
thefactorydefaultvalues.

Toresettheproducttothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.Pressandholdthecontrolbuttonwhilereconnectingpower.SeeProductoverviewonpage3.

3.Keepthecontrolbuttonpressedfor15–30secondsuntilthestatusLEDindicatorashesamber.

4.Releasethecontrolbutton.TheprocessiscompletewhenthestatusLEDindicatorturnsgreen.Theproducthasbeenreset
tothefactorydefaultsettings.IfnoDHCPserverisavailableonthenetwork,thedefaultIPaddressis192.168.0.90

5.UsetheinstallationandmanagementsoftwaretoolstoassignanIPaddress,setthepassword,andaccessthevideostream.

Theinstallationandmanagementsoftwaretoolsareavailablefromthesupportpagesonaxis.com/support

Itisalsopossibletoresetparameterstofactorydefaultviathewebinterface.GotoSettings>System>Maintenanceand
clickDefault.

Checkthecurrentrmware

Firmwareisthesoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootinga
problemshouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticular
problem.

Tocheckthecurrentrmware:

1.Gototheproduct’swebpage.

2.Clickonthehelpmenu

3.ClickAbout.

.

Upgradethermware

Important

Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providedthatthefeaturesareavailablein
thenewrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

Important

Makesuretheproductremainsconnectedtothepowersourcethroughouttheupgradeprocess.

Note

Whenyouupgradetheproductwiththelatestrmwareintheactivetrack,theproductreceivesthelatestfunctionality
available.Alwaysreadtheupgradeinstructionsandreleasenotesavailablewitheachnewreleasebeforeupgradingthe
rmware.Tondthelatestrmwareandthereleasenotes,gotoaxis.com/support/rmware.

1.Downloadthermwareletoyourcomputer,availablefreeofchargeataxis.com/support/rmware.

16

AXISM5525-EPTZNetworkCamera

Troubleshooting

2.Logintotheproductasanadministrator.

3.GotoSettings>System>Maintenance.Followtheinstructionsonthepage.Whentheupgradehasnished,the
productrestartsautomatically.

AXISDeviceManagercanbeusedformultipleupgrades.Findoutmoreataxis.com/products/axis-device-manager.

Technicalissues,cluesandsolutions

Ifyoucan’tndwhatyou’relookingforhere,trythetroubleshootingsectionataxis.com/support

Problemsupgradingthermware

FirmwareupgradefailureIfthermwareupgradefails,theproductreloadsthepreviousrmware.Themostcommonreason

ProblemssettingtheIPaddress

Theproductislocatedona
differentsubnet

TheIPaddressisbeingused
byanotherdevice

isthatthewrongrmwarelehasbeenuploaded.Checkthatthenameofthermwarele
correspondstoyourproductandtryagain.

IftheIPaddressintendedfortheproductandtheIPaddressofthecomputerusedtoaccessthe
productarelocatedondifferentsubnets,youcannotsettheIPaddress.Contactyournetwork
administratortoobtainanIPaddress.

DisconnecttheAxisproductfromthenetwork.Runthepingcommand(inaCommand/DOS
window,typepingandtheIPaddressoftheproduct):

PossibleIPaddressconict
withanotherdeviceonthe
samesubnet

Theproductcannotbeaccessedfromabrowser

Cannotlogin

TheIPaddresshasbeen
changedbyDHCP

Certicateerrorwhenusing
IEEE802.1X

Theproductisaccessiblelocallybutnotexternally

Routerconguration

Firewallprotection

ThestaticIPaddressintheAxisproductisusedbeforetheDHCPserversetsadynamicaddress.
ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay
beproblemsaccessingtheproduct.

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting
tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,theproductmustberesettothefactorydefaultsettings.
SeeHowtoresettofactorydefaultsettingsonpage16.

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshas
beenchanged,useAXISIPUtilityorAXISCameraManagementtolocatetheproductonthe
network.Identifytheproductusingitsmodelorserialnumber,orbytheDNSname(ifthename
hasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,gotoaxis.com/support

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductmustbe
synchronizedwithanNTPserver.GotoSettings>System>Dateandtime

CheckthatyourrouterallowsincomingdatatrafctotheAxisproduct.Theroutermustsupport
UPnP

ChecktheInternetrewallwithyournetworkadministrator.

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...
thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.
ObtainanewIPaddressfromthenetworkadministratorandreinstalltheproduct.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable
forusewiththeAxisproduct.Checkallcablingandreinstalltheproduct.

®

.

17

AXISM5525-EPTZNetworkCamera

Troubleshooting

Problemswithstreaming

MulticastH.264only
accessiblebylocalclients

NomulticastH.264
displayedintheclient

PoorrenderingofH.264
images

Colorsaturationisdifferent
inH.264andMotionJPEG

Lowerframeratethan
expected

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe
productneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisproduct
arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

Ensurethatyourgraphicscardisusingthelatestdriver .Thelatestdriverscanusuallybe
downloadedfromthemanufacturer’swebsite.

Modifythesettingsforyourgraphicsadapter.Gototheadapter’sdocumentationformore
information.

•SeePerformanceconsiderationsonpage18.

•Reducethenumberofapplicationsrunningontheclientcomputer.

•Limitthenumberofsimultaneousviewers.

•Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

•Lowertheimageresolution.

•Intheproduct’swebpage,setacapturemodethatprioritizesframerate.Changingthe
capturemodetoprioritizeframeratemightlowerthemaximumresolutiondepending
ontheproductusedandcapturemodesavailable.

Performanceconsiderations

Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationsaffecttheperformance.Somefactors
affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe
CPUreachesitsmaximum,thisalsoaffectstheframerate.

Thefollowingfactorsarethemostimportanttoconsider:

•Highimageresolutionorlowercompressionlevelsresultinimagescontainingmoredatawhichinturnaffectsthe
bandwidth.

•AccessbylargenumbersofMotionJPEGorunicastH.264clientsaffectsthebandwidth.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclientsaffectsbothframerateand
bandwidth.

Useidenticalstreamswhereverpossibletomaintainahighframerate.Streamprolescanbeusedtoensurethat
streamsareidentical.

•AccessingMotionJPEGandH.264videostreamssimultaneouslyaffectsbothframerateandbandwidth.

•Heavyusageofeventsettingsaffectstheproduct’sCPUloadwhichinturnaffectstheframerate.

•UsingHTTPSmayreduceframerate,inparticularifstreamingMotionJPEG.

•Heavynetworkutilizationduetopoorinfrastructureaffectsthebandwidth.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformanceandaffectsframerate.

•RunningmultipleAXISCameraApplicationPlatform(ACAP)applicationssimultaneouslymayaffecttheframerateand
thegeneralperformance.

18

AXISM5525-EPTZNetworkCamera

Specifications

Specifications

Tondthelatestversionoftheproduct’sdatasheet,gototheproductpageonaxis.comandlocateSupport&Documentation.

LEDindicators

StatusLED

Unlit

GreenShowssteadygreenfor10secondsfornormaloperationafterstartupcompleted.

Amber

Amber/RedFlashesamber/redifnetworkconnectionisunavailableorlost.

Indication

Connectionandnormaloperation.

Steadyduringstartup.Flashesduringrmwareupgradeorresettofactorydefault.

SDcardslot

NO

TICE

NO NO

TICE TICE

•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe

SDcard.Useyourngerstoinsertandremovethecard.

•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.UnmounttheSDcard

fromtheproduct’swebpagebeforeremoval.

ThisproductsupportsmicroSD/microSDHC/microSDXCcards.

ForSDcardrecommendations,seeaxis.com

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.SeeHowtoresettofactorydefaultsettingsonpage16.

•ConnectingtoanAXISVideoHostingSystemservice.Toconnect,pressandholdthebuttonforabout3secondsuntilthe
statusLEDashesgreen.

Connectors

Networkconnector

RJ45EthernetconnectorwithPoweroverEthernet(PoE).

Audioconnector

4-pinterminalblockforaudioinputandoutput.SeeProductoverviewonpage3.

Foraudioin,theleftchannelisusedfromastereosignal.

PinNotes

AUDIOIN

Microphoneorlinein(mono)

19

AXISM5525-EPTZNetworkCamera

Specifications

GNDAUDIOINGroundaudioin

AUDIOOUT

GNDAUDIOOUTGroundaudioout

I/Oconnector

UsetheI/Oconnectorwithexternaldevicesincombinationwith,forexample,motiondetection,eventtriggering,andalarm
notications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:

Digitalinput-Forconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexamplePIRsensors,door/window
contacts,andglassbreakdetectors.

Digitaloutput-ForconnectingexternaldevicessuchasrelaysandLEDs.ConnecteddevicescanbeactivatedbytheVAPIX®
ApplicationProgrammingInterfaceorintheproduct’swebpage.

6–pinterminalblock.SeeProductoverviewonpage3.

Lineaudioout

FunctionPinNotes

0VDC(-)

DCoutput

(InputorOutput)

GNDDCground0VDC

12V

I/O
1–4

Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.

Digitalinput–ConnecttopinGNDtoactivate,orleaveoating
(unconnected)todeactivate.

Digitaloutput–Internallyconnectedtopin1(DCground)when
active,andoating(unconnected)wheninactive.Ifusedwithan
inductiveload,e.g.arelay,adiodemustbeconnectedinparallel
withtheload,forprotectionagainstvoltagetransients.

Powerconnector

2-pinterminalblockforDCpowerinput.UseaSafetyExtraLowVoltage(SELV)compliant
limitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Woraratedoutput
currentlimitedto≤5A.

Specications

12VDC
Maxload=50mA

0tomax30VDC Congurable

0tomax30VDC,opendrain,
100mA

20

UserManualVer.M4.2
AXISM5525-EPTZNetworkCamera
©AxisCommunicationsAB,2017-2020

Date:March2020

PartNo.T101 11798
