C22
1/4” COMPACT REARVIEW CAMERA
INSTRUCTION MANUAL
SPECIFICATIONS
GENERAL
- Image Sensor: 1/4” CMOS
- Lens Angle: 120°
- Effective Pixels: 720 x 480
- Resolution: 480 TV Lines
- TV System: PAL
- Night Vision: 4 IR LEDs
- Min Illumination: 0 Lux (with IR)
- Image: Mirror
- Protection: IP66 Dust and Moisture
- Current Consumption: 200mA Max
- Input Power: 12V DC
- Operating Temperature: -20° to 60°C
- Connection: RCA
- Dimensions: 20H x 20W x 22Dmm
INCLUDED
- Installation Manual
- Installation Hardware
- 6m RCA Video Cable with DVD/Monitor Trigger Wire
- 1m Power Cable
Page 2
CAR REARVIEW CAMERA
GENERAL:
After installation, the rear view system will automatically activate when reverse gear
is selected. This provides a clear image for the driver as a protection for children,
pedestrians and property from injury or damage. It also avoids costly repairs to
your vehicle.
CAMERA:
The stealth camera can be mounted on the number plate or other panel. The RCA
video cable simply connects with most aftermarket LCD monitors.
INSTALLATION:
• Carefully choose the installation position (usually rear-centre of vehicle).
• Carefully drill hole for mounting screws (avoid fuel tank or cables) or use
adhesive tape.
• Connect RED cable to 12V+ power cable of reversing light.
• Connect BLACK cable to ground.
• Connect YELLOW RCA cable (video) to LCD monitor.
Page 3
Determine the installation location
Connect negative wire to ground
Securely mount camera
Connect camera power cable
to the 12V power cable of
reversing circuit
,QVWDOODWLRQ¿QLVK
CAR REARVIEW CAMERA
CABLE CONNECTIONS:
See wiring diagram below:
Video (6m)
GDN (Black)
+12V (Red)
Camera
TFT LCD Monitor
DC 12V
DC 12V
Connect RCA video cable
between camera and monitor
Camera signal extension cable
Rear Lamp (most vehicles)
A
B
C
*most vehicles*
6m Video RCA
(Yellow)
Monitor Trigger Wire
(Red)
