ILLUS. NO.
Planetary Bearing Retainer
1
Bearing Retainer A
1
Bearing Retainer B
1
Gear Housing Cover
1
Transmission Case
1
Support of Top Cover
1
Top Cover
1
Planetary Shaft
1
PARTS CATALOG OF AX-M80
26
11092-05-001
Motor Rack
1
Hub Attachment
1
Plug
1
Thumb Screw
1
Shift Fork
1
Shifter Shaft
1
Bracket
1
Shifter Hub
1
Bracket
1
PARTS NO. PARTS NAME QT'S
1 11091S-01-002B
2 11091S-01-003B
3 11100B-01-003B
4 11100B-01-004
5 11100B-01-005
6 11100-01-OIL PUMP Oil Pump (Gear Box) 1
7 11092-01-010
9 11091-01-001
10 11100B-02-001
11 11100B-02-003 Gear 50T 1
12 11100B-02-004 Chimney 1
13 11193-02-006 Bevel Gear 1
14 11100B-03-001
Transmission Shaft 1
15 11100B-03-002 Spiral Gear 16T 1
16 11100B-03-003 Spacer 1
17 11100B-03-004 Copper Washer 1
18 11100B-03-005
Gear 19T
19 1191-03-002 Clutch Gear 1
11100B-03-007
20
11100B-03-008
21
11092-03-001 Pulley (Motor) 1
23
Copper Washer 1
Gear 32T 1
24 11100B-04-001 Transmission Shaft 1
25 11100B-04-004 Gear 26T 1
1
27 11092-05-003
Pulley (Transmission Case)
28 11100-05-005/208/60/3 Motor(220V/60Hz/3Ph)4/8P 1
29 11093-06-001 Bevel Gear 1
30 11093-06-002
31 11091-06-004
32 11031-06-005
34 1109S-07-001 Control Panel 1
35 11100B-07-001 Handle 1
36 1109S-07-003B shiftin shaft 1
37 1109S-07-004B
38 11100B-07-005B
40 11092-07-007
41 1109S-07-008B Shifting Cam 1
42 1109S-07-009B Plug 1
43 11091-07-010 Compressing Spring 1
44 11091-07-011 Set Screw 2
45 11091-07-012 Ball(Handle) 1
46 1109S-07-013B
47 11091-07-006
48 11091-07-018 Compressing Spring 2
49 11091-08-001 Internal Gear 1
51 11091-08-003 Gear 18T 1
52 11091-08-004 Seat of Oil Seal 1
1
53 11092-08-004 Planetary Head 1
Bowl Retainer
1
Bowl Locating Pin
2
Apron
1
Lifting Screw Gear
1
Lifting Nut
1
86
11100-13-001
Head Ring
1
Wire Guard
1
Fix Ring
1
Rear Cover
1
Control Shaft Screw
1
Control Shaft
1
Control Shaft Seat
1
54 11100-08-OIL PUMP Oil Pump (Planetary Head) 1
55 11092-08-008A Planetary Shaft 1
56 11091-08-009 Taper Pin 1
57 11091-09-001 Fix Bar of Top Cover 1
58 11092-09-002 Column 1
59 11091-09-003 Slide Way 2
60 11100-09-004 Base 1
61 11091-09-005 Rear Cover(Column) 1
62 11091-10-001A
63 11091-10-001B
Bowl Clamp(left)
Bowl Clamp(right)
65 11100-10-003 Bowl Support 1
66 11100-10-004
67 11147-10-002
68 11091-10-006
69 SH-11/220-380/3PH Reducer Motor(Bowl Lift) 1
70 11091-11-016 Chain Gear 1
74 11091-11-007
75 11091-11-008
76 11091-11-009 Fix Plate 1
77 11100-12-001 80qt Bowl 1
81 11100-12-002 Beater 1
82 11100-12-011 Bowl Truck 1
83 11100-12-004 Wire Whip 1
85 11100-12-003 Dough Arm 1
2
2
87 GM60-13-002A
88 11091-13-003A
89 11100-13-004
91 1109P-13-008
92 11091-13-007
93 11091-13-012 Compressing Spring 1
94 1109P-13-006
113 NUT-1/2*12NC Nut 8
114 NUT1"*12NF Nut 1
115 NUT-5/16*18NC Nut 2
116 NUT-5/8*11NC Nut 4
117 W-3/8 Nut 4
118 WB-3/8 Washer 1
119 11100B-03-011 Spacer 1
120 11100B-03-012 Spacer 1
121 OS-TC38*50*07 Oil Seal 1
122 OS-TC43*58*08 Oil Seal 1
123 OS-TC40*72*08 Oil Seal 1
124 OS-TC19*27*07 Oil Seal 1
125 S-S1/4*5/16 Set Screw 2
126 S-S5/16*3/8 Set Screw 3
127
STW-S25 C type Snap Ring
128 S+BR-3/16*1/4 Mach. Screw 4
2
129 S+F1/4"*3/8 Cap Screw 1
154
S-C-5/16*1-1/4
Set Screw
4
130 SW-1/2 Spring Washer 10
131 SW3/8" Spring Washer 3
132 SW-5/8 Spring Washer 4
133 KR-7*7*40 Key 1
134 BELT-M7*1320 Belt 5
135 BR-2907 Bearing 1
136 SB-6 Ball 2
137 TP-4*32 Taper Pin 2
138 11091-11-018 Oil Cup 1
139 WB-3/4 Flat Washer 1
140 WHEEL-001 Wheel 3
141 S-7/16"*3/4 Bolt 5
142 S-3/8"*3/4 Bolt 9
143 S-1/4*3/8 Bolt 8
144 S-5/8*2-1/2 Bolt 4
145 S-3/16*1/2 Bolt 6
146 S-1/2"*1/4 Bolt 9
147 S-5/16*3/4 Bolt 4
148 S-3/8"*1/2 Bolt 1
149 S-1/2*4 Bolt 1
150 S-C1/2*2-1/4 Set Screw 4
151 S-C-3/8*1-1/4 Set Screw 4
152 S-C1/2*1-1/4 Set Screw 2
153 S-C5/16"*5/8 Set Screw 8
155 S-C-3/8*1 Set Screw 3
156 S-C-1/4*5/8 Set Screw 4
157 S-C-3/8*1-1/2 Set Screw 12
158 S-C5/16*1 Set Screw 4
159 M40 Lock Washer 1
160 MN40 Lock Nut 1
161 M55 Lock Washer 1
162 MN55 Lock Nut 1
163 M17 Lock Washer 1
164 MN17 Luck Nut 1
165 SPP-10*50 Spring Pin 2
166 SPP-8*28 Spring Pin 4
167 SPP-4*28 Spring Pin 1
168 SPP-8*50 Spring Pin 4
169 SPP-4*16 Spring Pin 1
170 BR-6306Z Ball Bearing 1
171 BR-6207Z Ball Bearing 1
172 BR-2903 Ball Bearing 1
173 BR-6203 Ball Bearing 1
174 BR-6205 Ball Bearing 2
175 BR-6207 Ball Bearing 1
176 BR-6010 Ball Bearing 1
177 BR-6206 Ball Bearing 1
178 KR-5*5*15 Key 1
Emergency Stop
1
Button Switch
2
Plastic Box of Control Board
1
Control Board
1
5
11100-07-001E
Control Panel
1
3A1B(60,50HZ)
Terminal Block
1
4A) B220V
179 KR-1/4*1/4*50 Key 1
180 KR-1/4*1/4*100 Key 1
181 KR-09 * 14 * 52 Key 1
182 KR-6*6*35 Key 1
183 KRR-10*08*28 Key 1
184 KRR-5*5*10 Key 1
185 KRR-5*5*13 Key 1
186 KRR-08*08*43 Key 1
187 S+R3/16*3/8 Mach. Screw 8
188 S+R3/16*1/4 Mach. Screw 6
189 KR-7*7*40 Key 1
191 KRR-08*08*43 Key 1
192 BL-04-008 Chain 1
ELECTRICAL PARTS
ILLUS. NO.
PARTS NO. PARTS NAME QT'S
1 ABESMT44
ABMS800M
ABAU8F01
Ring of Switch
Terminal of Switch
2 ABPBFMF3
ABMS800M
ABAU8F10
Ring of Switch
Terminal of Switch
3 GM07-07-003B
XL-GM07
4
1
1
2
2
6 ABSSMM32 Speed Shifting Switch 1
ABMS800M
ABAU8F01
MC HUO-16AK 5HP/16K B
7
220V
MC CU-11 AC220V
8
Ring of Switch
Terminal of Switch
Contactor 16AK 5HP 220V 2
Contactor 11 3A1B 220V 2
9 SL 14P20A
10 11100-E-BOX Electrical Box 1
11 HQ-BIMZD-M25 Cable Tie 1
12 WF-UL#12*4C Power Cable 1
13 11100-07-001E-1 Sticker of Control Panel 1
14 ME 8108
Limit Switch (Bowl Lift) 1
15 MJ-7106 Limit Switch (Bowl Down) 1
17 Z15GQWB Limit Switch (Safety Guard) 1
MC HUO-11AK/1HP(2.9-
18
Contactor 11AK 1HP 220V
1
1
2
