Avycon AVC-VHN51VLT Specsheet

AVC-VHN51VLT

CTP-TLV15VHN

5MP H.265 NETWORK IR OUTDOOR DOME CAMERA

CAMERA

DIMENSION

Unit : mm (Inch)

86.1mm (3.39”)

136.6mm (5.38”)

FEATURES

A fully featured control board include reset button, SD Storage, and DC IN / CVBS test port.

Includes secondary test port for DC12V Power and CVBS Analog Out that connects inside the camera for easy adjustment and servicing.

152.7mm (6.01”)

Included junction box makes easy to hide and store cable safely.

DC 12V Power

PoE Port

Alarm

CVBS Analog

Audio In

Audio Out

RS 485

Our IP cameras offer a complete set of input and output connectors for easy installation.

• Built-in PoE (Power over Ethernet) Port

• DC 12V Power

• CVBS Analog BNC Out

• Audio In

• Audio Out

• RS 485

• Alarm

BNC Out

(MIC)

FUNCTION

H.265 Main Proﬁle Video Compression Technology, High Compression Ratio,

Stable Stream Control 5MP (2592x1944) Full Real Time Coding

Max. Resolution: 2592x1944

ICR Auto Switch, True Day & Night

100ft.* IR Night View Distance

3D DNR, S-WDR

Support 8 ROI Coding

One Gigabit Ethernet Network Port, 10M / 100M / 1000M Self-Adaptive

Support SD Card Local Storage, up to 128GB

Support CVBS Local Video, Two-Way Audio and PoE Power Supply

Support Smartphone, iPad, Remote Monitoring

Support P2P

IP66 & IK10 Ingress Protection

Support Three Streams

5MP

PoE

ICR

i-DNR

NOISE

REDUCTION

DAY & NIGHT

3-AXIS S-WDR

SPECIFICATION

DESCRIPTION

IMAGE SENSOR

EFFECTIVE PIXELS

ELECTRONIC SHUTTER

MIN. ILLUMINATION

VIDEO COMPRESSION

AUDIO COMPRESSION

IMAGE QUALITY

CARD STRORAGE

REMOTE MONITORING

SUPPORTED BROWSERS

ONLINE CONNECTION

CONNECTION PROTOCOL

INTELLIGENT ANALYSIS

ANGLE ADJUSTMENT

POWER CONSUMPTION（IR OFF）

POWER CONSUMPTION（IR ON）

WORKING ENVIRONMENT

LENS

LENS ANGLE

LENS MOUNT

WDR

BLC

DNR

BIT-RATE

ENCODE MODE

RESOLUTION

MULTI-STREAM

IMAGE SETTING

NETWORK

VIDEO OUTPUT

AUDIO

RS485

ALARM INPUT

ALARM OUTPUT

PROTOCOL

STORAGE

SMART ALARM

DAY & NIGHT

IR DISTANCE

IR LED (COUNT)

WATERPROOF

POWER SUPPLY

DIMENSION

WEIGHT

COLOR: 0.0lux@F1.2, AGC ON, B/W: 0lux WITH IR

H.265 MP, H.264 BL / MP / HP, MJPEG

FIVE LEVELS UNDER VBR； FREELY ADJUSTABLE UNDER CBR

5MP (2592×1944), 2K (2560×1440), 1080P（1920×1080), 720P（1280×720), D1, CIF, 480x240

5MP（1~30fps） / 2K（1~30fps） / 1080P（1~30fps） / 720P（1~30fps）

720P（1~5fps） / D1（1~10fps） / CIF（1~30fps）

D1（1~30fps） / CIF（1~30fps） / 480x240（1~30fps）

ROI，SATURATION, BRIGHTNESS, HUE, CONTRAST, WDR, SHARPNESS, DNR, ETC

TWO-WAY AUDIO（MIC IN × 1, MIC OUT × 1）

TCP/IP, UDP, DHCP, NTP, RTSP, PPPOE, DDNS, SMTP, FTP

LOCAL STORAGE (TF CARD), NETWORK REMOTE STORAGE

HORIZONTAL: 0°~77°，VERTICAL: 0°~360°，ROTATION: 0°~360°

1/1.8" CMOS

2592x1944

1/25s~1/100000s

3.6-10mm VARIFOCAL LENS

HORIZONTAL: 72°，83.7°~36.7°(-FZ)

CS MOUNT，Φ14 MOUNT（-FZ）

S-WDR

YES

2D / 3D DNR

G.711A / G.711U 64Kbps~10Mbps

VBR / CBR

RJ45

CVBS (BNC × 1)

TF CARD, UP TO 64GB

× 1 × 1

× 1 BROWSER, CVMS, MOBILE CVMS IE / CHROME / FIREFOX / SAFARI

10 ONLINE USERS

ONVIF

MOTION ALARM, SENSOR ALARM

PEA / OSC / AVD

ICR

100ft.*

30（Φ5 12mil）

IP66

DC 12V/PoE

＜3W

＜5.5W

-22°F~122°F，10%~90% HUMIDITY

Φ150mm×114mm

1025g

IP66
