Avocent SwitchView SC User Manual
®
SWITCHVIEW SC
Installer/User Guide
Avocent Corporation
4991 Corporate Drive
Huntsville, Alabama 35805-6201 • USA
(Tel) 256-430-4000 (Fax) 256-430-4030
http://www.avocent.com
®
SwitchView SC
Installer/User Guide
Avocent Corporation
4991 Corporate Drive
Huntsville, Alabama 35805-6201 • USA
(Tel) 256-430-4000 (Fax) 256-430-4030
http://www.avocent.com
©2003 Avocent Corporation. All rights reserved.
Avocent is a trademark of Avocent Corporation. IBM, PC, PC/AT and PS/2 are registered trademarks of International
Business Machines Corporation. Cybex, the Cybex logo, AutoBoot and SwitchView are trademarks or registered trademarks
of Cybex Computer Products Corporation. IntelliMouse is a trademark of Microsoft Corporation. All other marks are the
property of their respective owners.
SwitchView SC Installer/User Guide
FCC Notifi cation
War ning: Changes or modifi cations to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful inter ference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Canadian Notifi cation
NSA Notifi cation
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques les limites
applicables aux appareils numériques de la class B prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le Ministère des Communications du Canada.
This appliance complies with NSA certifi cation requirements to EAL 4.
Table of Contents
Chapter 1 - Product Overview
Feature Overview....................................................................................................................................... 1
Compatibility.............................................................................................................................................. 3
Chapter 2 - Installation
Basic Install................................................................................................................................................. 5
Chapter 3 - Operations
Overview....................................................................................................................................................... 9
Chapter 4 - Appendices
A: Specifi cations ......................................................................................................................................11
B: Troubleshooting.................................................................................................................................. 12
SwitchView SC Installer/User Guide
INSTRUCTIONS: This symbol is intended to alert the user to the presence
of important op er at ing and maintenance instructions in the literature
ac com pa ny ing the appliance.
DANGEROUS VOLTAGE: This symbol is intended to alert the user to t he presence
of uninsulated “dangerous voltage” within the product's enclosure that may be
of suffi cient magnitude to constitute a risk of electric shock to persons.
PROTECTIVE GROUNDING TERMINAL: This symbol indicates a terminal
which must be connected to earth ground prior to making any other connections
to the equipment.
POWER ON: This symbol indicates the principal on/off switch is in the
on position.
POWER OFF: This symbol indicates the principal on/off switch is in the
off position.
