AVM FRITZ!Box Fon WLAN 7270 User guide

Installation, Configuration and Operation
FRITZ!Box
Fon WLAN 7270
Legal Notice
FRITZ!Box Fon WLAN 7270
This documentation and the software it describes are protected by copyright. AVM grants the non­exclusive right to use the software, which is supplied exclusively in what is known as object code format. The licensee may create only one copy of the software, which may be used exclusively for backup use.
AVM reserves all rights that are not expressly granted to the licensee. Without previous approval in writing, and except for in cases permitted by law, it is particularly prohibited to
copy, propagate or in any other manner make this documentation or this software publicly ac-
cessible, or
process, disassemble, reverse engineer, translate, decompile or in any other manner open
the software and subsequently copy, propagate or make the software publicly accessible in any other manner.
Please consult the “License.txt” file on the product CD included in the package for specifics about the licensing conditions.
This documentation and software have been produced with all due care and checked for correct­ness in accordance with the best available technology. AVM GmbH disclaims all liability and war­ranties, whether express or implied, relating to the AVM product’s quality, performance or suitabi­lity for any given purpose which deviates from the performance specifications contained in the product description. The licensee bears all risk in regard to hazards and impairments of quality which may arise in connection with the use of this product.
AVM will not be liable for damages arising directly or indirectly from the use of the manual or the software, nor for incidental or consequential damages, except in case of intent or gross negli­gence. AVM expressly disclaims all liability for the loss of or damage to hardware or software or data as a result of direct or indirect errors or destruction and for any costs (including connection charges) related to the documentation and the software and due to incorrect installations not per­formed by AVM itself.
The information in this manual and the software are subject to change without notice for the pur­pose of technical improvement.
We offer a manufacturer’s warranty for this original product. The conditions of this warranty are contained in the “Warranty.pdf” file in the “Info” folder on the product CD included with delivery.
© AVM GmbH 2006 – 2009. All rights reserved. Documentation release 08/2009
AVM Audiovisuelles Marketing und Computersysteme GmbH Alt-Moabit 95 D 10559 Berlin
AVM in the Internet: www.avm.de/en Unless otherwise indicated, all trademarks mentioned are legally protected trademarks owned by
AVM. This includes product names and logos in particular. Microsoft, Windows and the Windows logo are trademarks owned by Microsoft Corporation in the USA and/or other countries. Bluetooth is a trademark of Bluetooth SIG, Inc. licensed to AVM GmbH. All other product and company na­mes are trademarks of their respective owners.
AVM Computersysteme Vertriebs GmbH Alt-Moabit 95 D 10559 Berlin
FRITZ!Box Fon WLAN 7270 2

Table of Contents

Symbols and Highlighting . . . . . . . . . . . . . . . . . . . . . . . . . 7
I CONNECTING AND OPERATION . . . . . . . . . . . . . . . . . . . . . . 8
1 Security and Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 FRITZ!Box Fon WLAN 7270 . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Operation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 Launching Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 Connecting to Electrical Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3 Connecting to the Computer(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.4 Connecting Computers to the LAN Port . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5 Connecting Computer(s) Wirelessly via WLAN . . . . . . . . . . . . . . . . . . 19
3.6 Connecting to the DSL Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.7 Connecting to the ISDN Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.8 Connecting with the Analog Telephone Line. . . . . . . . . . . . . . . . . . . . 26
3.9 Connecting Telephone, Fax, or Answering Machine. . . . . . . . . . . . . . 27
3.10 Connecting ISDN Telephones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.11 Connecting ISDN PBXs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.12 Connecting IP Telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4 Opening the User Interface. . . . . . . . . . . . . . . . . . . . . . . . 31
4.1 Password Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2 Saving Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5 Internet Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.1 Configuring the Internet Connection Using the Wizard . . . . . . . . . . . 33
5.2 Configuring the Internet Connection Manually. . . . . . . . . . . . . . . . . . 33
5.3 Internet Connection via the Mobile Telephone Network . . . . . . . . . . 34
FRITZ!Box Fon WLAN 7270 3
6 Telephone Connections . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.1 Entering Your Phone Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.2 Configuring Telephony Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.3 Telephony Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.4 The Answering Machine Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7 DECT Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.1 Registering Cordless Telephones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.2 Making an Internal Call to a Cordless Telephone . . . . . . . . . . . . . . . . 46
7.3 Logging a Cordless Telephone off of the FRITZ!Box . . . . . . . . . . . . . . 47
7.4 Enabling and Disabling DECT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8 USB Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.1 Connecting USB Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.2 Accessing USB Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.3 USB Mass Storage Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.4 USB Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.5 FRITZ!Box USB Remote Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8.6 FRITZ!WLAN USB Stick N and FRITZ!WLAN USB Stick . . . . . . . . . . . . . 61
8.7 USB Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
8.8 Tips for Using USB Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
9 FRITZ!DSL: The Software Suite . . . . . . . . . . . . . . . . . . . . . 64
9.1 Installing FRITZ!DSL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.2 FRITZ!DSL Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.3 FRITZ!DSL Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
9.4 FRITZ!Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
9.5 Update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
9.6 FRITZ!DSL Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
9.7 WebWatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
FRITZ!Box Fon WLAN 7270 4
10 Configuration and Operation on the Telephone . . . . . . . 68
10.1 The Telephone Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
10.2 Instructions for Operation at the Telephone. . . . . . . . . . . . . . . . . . . . 69
10.3 Audio Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
10.4 Configuring on the Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
10.5 Operation at the Telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
11.1 Errors Opening the User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
11.2 The WLAN Adapter Cannot Find FRITZ!Box . . . . . . . . . . . . . . . . . . . . 108
11.3 WLAN Connection Is Not Established . . . . . . . . . . . . . . . . . . . . . . . . 110
11.4 Obtaining an IP Address Automatically. . . . . . . . . . . . . . . . . . . . . . . 113
12 Uninstalling the FRITZ!Box . . . . . . . . . . . . . . . . . . . . . . . 118
12.1 Disconnecting the FRITZ!Box from the Computer . . . . . . . . . . . . . . . 118
12.2 Removing the FRITZ!DSL Software . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
12.3 Removing the Printer Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
12.4 Removing the Program Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
II PRODUCT DETAILS AND USEFUL INFORMATION . . . . . . . 122
1 Product Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
1.1 Cables and Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
1.2 LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
1.3 WLAN Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
1.4 DECT Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
1.5 Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
1.6 Declaration of CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
1.7 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
FRITZ!Box Fon WLAN 7270 5
2 More about WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
2.1 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
2.2 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
2.3 Frequency Ranges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
2.4 Increasing the WLAN Range Using WDS . . . . . . . . . . . . . . . . . . . . . . 138
2.5 WPS (Wi-Fi Protected Setup) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
3 More about Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
3.1 Network Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
3.2 IP Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
3.3 UPnP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
3.4 IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
3.5 DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
3.6 Subnetwork. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
3.7 Changing the Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
4 More about Internet Telephony . . . . . . . . . . . . . . . . . . . 154
4.1 Telephony Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
5 More about Virtual Private Network (VPN). . . . . . . . . . . 155
5.1 What Is VPN?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
5.2 Security through a VPN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
5.3 The Tunnel Technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
5.4 Supplementary Software for VPN . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
6 More about Bandwidth Management and Prioritization159
6.1 Bandwidth Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
6.2 The Prioritization of Network Applications and Network Devices . . 159
7 More Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
7.1 Child Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
7.2 Energy Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
7.3 Push Service E-mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
7.4 Night Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
FRITZ!Box Fon WLAN 7270 6
8 Customer Service Guide . . . . . . . . . . . . . . . . . . . . . . . . . 167
8.1 Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
8.2 Information in the Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
8.3 Updates and Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
8.4 Support from the Service Team . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
FRITZ!Box Fon WLAN 7270 7

Symbols and Highlighting

Symbols and Highlighting
The following sections present explanations about the symbols and highlighting used in this manual.
This symbol indicates useful hints to assist you in work­ing with the FRITZ!Box.
This symbol indicates important instructions that must be observed to avoid malfunctions.
The table below explains the highlighting used in this manual.
Highlighting Function Examples
Quotation marks Keys
Buttons
Settings pages
Menus
Commands
File paths
File names
Underlined text Text input fritz.box
Pointed brackets Joker <MSN>
Bold Emphasis Do not click the but-
“F1” key
“Help”
“Advanced”
“Edit/Paste”
“Copy”
“C:/My Documents”
“Documentation”
ton...
For detailed information about the numerals and function keys used in the manual, see the section “Instructions for Operation at the Telephone” on page 70.
FRITZ!Box Fon WLAN 7270 8
Security and Handling

I CONNECTING AND OPERATION

1 Security and Handling

What to Watch Out For
Safety Instructions When working with the FRITZ!Box Fon WLAN 7270, ob-
serve the following security instructions in order to protect yourself and the FRITZ!Box from harm.
Do not install the FRITZ!Box during an electrical
storm.
Disconnect FRITZ!Box from the power supply during
electrical storms.
Never let liquids get inside the FRITZ!Box. Otherwise,
electric shocks or short circuits may result.
The FRITZ!Box is intended for indoor use only.
Do not open the FRITZ!Box housing. The device con-
tains hazardous components and should only be opened by authorized repair technicians.
Handling the
FRITZ!Box
You can either place FRITZ!Box on a horizontal surface or mount it on a wall. Please note the following:
Place or hang the FRITZ!Box in a dry location that is
free of dust and protected from direct sunlight.
Do not place FRITZ!Box on excessively heat-sensitive
surfaces, as the base of the device can heat up dur­ing normal operation.
Make sure that the ventilation slits are unobstructed.
For this reason the FRITZ!Box should not be placed on a carpet or on upholstered furniture. The ventilation slits provide for air cooling of the FRITZ!Box.
When connecting FRITZ!Box to your computer using
the network, remember to take the length of the ca­ble into account.
FRITZ!Box Fon WLAN 7270 9
Security and Handling
If you would like to establish wireless connections
between FRITZ!Box and the computer, position the device at a central location.
Make sure to keep sufficient distance from potential
sources of interference like microwave devices or electric devices with large metal housings.
FRITZ!Box Fon WLAN 7270 10
FRITZ!Box Fon WLAN 7270

2 FRITZ!Box Fon WLAN 7270

An Overview
The FRITZ!Box is a DSL modem that connects your computers directly with your DSL line. Each connected computer can establish an Internet connection over the FRITZ!Box. As a WLAN access point, FRITZ!Box of­fers you the possibility of connecting your computer to the DSL line wirelessly.
The FRITZ!Box is a Private Branch Exchange (PBX) for making telephone calls via the Internet and the fixed-line network (ISDN and analog).
Possibilities for connecting FRITZ!Box
PBX Two analog telephones, fax machines and answering ma-
chines can be connected to FRITZ!Box to take advantage of the features of ISDN. Up to eight ISDN telephony terminal devices can be connected to the integrated ISDN S
Using Cordless
Phones
Thanks to the DECT function, the FRITZ!Box can be used as a basis station for cordless phones. Every cordless phone that supports the DECT-GAP standard can be registered at the FRITZ!Box.
FRITZ!Box Fon WLAN 7270 11
port.
0
FRITZ!Box Fon WLAN 7270
Connecting
Computers
Four computers can be connected directly to the FRITZ!Box using the four LAN ports.
You can also connect a network hub or switch to the LAN ports so that even more computers can be connected to your FRITZ!Box.
WLAN Access Point The FRITZ!Box is a WLAN access point. All computers
equipped with a WLAN adapter can be wirelessly connect­ed to the FRITZ!Box.
Local Network All of the computers connected with the FRITZ!Box consti-
tute a network and can share access to any files released for file sharing.
Internet All of the computers connected to the FRITZ!Box can ac-
cess the Internet.
The FRITZ!Box works as a DSL router, making the Internet connection available to all connected computers. All con­nected computers can then use the Internet connection at the same time.
Firewall The FRITZ!Box is equipped with an integrated firewall. The
integrated firewall protects your network from attacks from the Internet as long as the FRITZ!Box is operated as a router.
USB Port The FRITZ!Box is equipped with a USB host controller to
which you can connect a USB storage device (hard drive, stick), a printer, an AVM FRITZ!WLAN USB Stick N, an AVM FRITZ!WLAN USB Stick or a USB hub.
The USB port supports the USB 1.1 and USB 2.0 stan­dards.
If you use AVM’s FRITZ!WLAN USB Stick N or the FRITZ!WLAN USB Stick, AVM Stick & Surf technology is at your disposal. Use Stick & Surf to adopt the WLAN security settings from the FRITZ!Box quickly and conveniently.
For connecting a printer, FRITZ!Box has a printer server.
Media Server An integrated media server makes music files available in
the local network. Music files from a USB stick can be made available even when the computer is switched off.
FRITZ!Box Fon WLAN 7270 12
Package Contents
Network Devices Other network devices can also be connected to the net-
work ports of the FRITZ!Box, for instance game consoles.
Operating Systems
Supported
The FRITZ!Box can be connected to computers with Win­dows operating systems, the Linux operating system or Apple computers with the Mac OS X operating system.

2.1 Package Contents

The following is included in the FRITZ!Box Fon WLAN 7270 package:
FRITZ!Box Fon WLAN 7270
one power supply unit with a cable for connection to
one DSL/telephone cable for connecting the
one network cable for connection to a computer or a
one RJ45/RJ11 adapter (gray) for the DSL line (re-
one RJ45/RJ11 adapter (black) for connecting
one FRITZ!Box CD with
the power mains
FRITZ!Box to your DSL line
network
quired in some countries)
FRITZ!Box Fon WLAN 7270 to the analog telephone network
installation Help
FRITZ!DSL software package
software for the printer port
documentation for all enclosed AVM products
one quick guide
FRITZ!Box Fon WLAN 7270 13
Operation Requirements

2.2 Operation Requirements

In order to operate the FRITZ!Box, you must have the fol­lowing:
a Web browser that supports Java script (for instance,
Internet Explorer version 6.0 or higher, or Firefox version 1.5 or higher)
DSL line, ITU G.992.1 standard, ITU G.992.3 stan-
dard, ITU G.992.5 standard
for connection via WLAN:
computer with a WLAN adapter compliant with IEEE 802.11n draft 2.0, IEEE 802.11g,a or IEEE 802.11b, for example a FRITZ!WLAN USB Stick N
for connection via network cable:
computer with a network port (network adapter stan­dard Ethernet 10/100 Base-T)
for fixed-line telephony:
an ISDN point-to-multipoint line in accordance with the Euro ISDN protocol DSS1, or an analog telephone line
to install the DSL software ComWareDSL, the mini-
mum computer requirements are:
Pentium III processor (or comparable) with
Windows Vista (32-bit) or Windows XP (32-bit) and CD drive
128 MB RAM
40 MB free memory on the hard drive
FRITZ!Box Fon WLAN 7270 14
Connection

3Connection

Connecting FRITZ!Box
This chapter contains instructions on the following topics:
launching FRITZ!Box operation
connecting FRITZ!Box to electrical power
connecting one or several computers to the FRITZ!Box
connecting FRITZ!Box to DSL
connecting FRITZ!Box to ISDN or the analog telephone line
connecting analog terminal devices to the FRITZ!Box
connecting ISDN terminal devices to the FRITZ!Box
connecting an IP telephone
Please see the instructions about setting up the FRITZ!Box in section “Security and Handling” on page 9.

3.1 Launching Operation

We recommend using the Installation Help on the FRITZ!Box CD when launching operation of the FRITZ!Box for the first time.
Using the Installation Help on the CD
On computers with Windows operating systems you can use the Installation Help on the FRITZ!Box CD. The Installa­tion Help presents instructions on the screen, guiding you through the steps required to launch operation of the FRITZ!Box.
1. Insert the FRITZ!Box CD in the CD-ROM drive of your
computer.
The Installation Help starts automatically.
2. Follow the instructions in the Installation Help to pre-
pare the FRITZ!Box for operation.
FRITZ!Box Fon WLAN 7270 15
Launching Operation without the Installation Help CD
At the conclusion of the Installation Help, you will be rout­ed directly to the FRITZ!Box user interface.
Launching Operation without the Installation Help CD
If you do not want to use the Installation Help on the FRITZ!Box CD, then work through the instructions below in the recommended order:
1. Mounting FRITZ!Box; see the section “Security and
Handling” from page 9.
2. Connecting FRITZ!Box to the power supply; see the
section “Connecting to Electrical Power” on page 17.
3. Connecting FRITZ!Box to the computer(s); see the
section “Connecting to the Computer(s)” on page 17.
4. Connecting FRITZ!Box to DSL; see section “Connect-
ing to the DSL Line” from page 24.
5. If you want to make telephone calls with the fixed-
line network using FRITZ!Box:
If you have an ISDN line, please read section
“Connecting to the ISDN Line” on page 26.
If you have an analog line, please read section
“Connecting with the Analog Telephone Line” on page 27.
6. If you want to make telephone calls and fax using the
FRITZ!Box over the Internet and/or the fixed-line net­work, connect your analog equipment to the FRITZ!Box: See the section “Connecting Telephone, Fax, or Answering Machine” on page 28.
7. If you want to connect an ISDN telephone or an ISDN
PBX to the FRITZ!Box, please read the sections “Con­necting ISDN Telephones” on page 28 and “Connect­ing ISDN PBXs” on page 29.
8. If you would like to connect an IP telephone to the
FRITZ!Box, please read the section “Connecting IP Telephones” on page 30.
FRITZ!Box Fon WLAN 7270 16
Connecting to Electrical Power

3.2 Connecting to Electrical Power

Connecting to the power supply
Connecting Set aside the power supply unit out of the FRITZ!Box pack-
age.
1. Connect the power supply unit to the socket on the
FRITZ!Box labeled “Power”.
2. Plug the other end into an AC power outlet.
The green “Power/DSL” LED will light up after a few sec­onds.

3.3 Connecting to the Computer(s)

If you would like to surf the web using the FRITZ!Box or to open the FRITZ!Box user interface, then you must connect a computer with the FRITZ!Box.
A computer can be connected with the FRITZ!Box in two different ways:
via a LAN port
wirelessly via WLAN
FRITZ!Box Fon WLAN 7270 17
Connecting Computers to the LAN Port
Connection Szenarios Note the following when connecting computers to the
FRITZ!Box:
One computer can be connected to the FRITZ!Box by
only one of these means.
At each of the network ports of the FRITZ!Box, a com-
puter can be connected directly or via a hub/switch.
Using WLAN you can connect multiple computers wi-
th the FRITZ!Box at the same time.
The way a computer is connected to the FRITZ!Box is
the same regardless of the operating system on the computer.
All of the computers connected with the FRITZ!Box
constitute a network.

3.4 Connecting Computers to the LAN Port

If you would like to connect a computer to the LAN port of the FRITZ!Box, make sure the computer is equipped with a LAN port (network adapter). A LAN port is usually desig­nated by the icon at left or labeled “LAN”.
Connecting a computer to a LAN port on the FRITZ!Box
FRITZ!Box Fon WLAN 7270 18
Connecting More Computers to the LAN Ports
Connecting Set aside the network cable (yellow) from the FRITZ!Box
package.
1. Switch on your computer.
2. If you work with a Linux operating system, use YaST
to configure your network card with the setting “DHCP”, if this setting is not already configured.
Insert one end of the LAN cable to the computer’s network adapter.
3. Connect the other end of the LAN cable to a socket on
the FRITZ!Box labeled “LAN 1”, “LAN 2”, “LAN 3” or “LAN 4”.
Now the FRITZ!Box and computer are connected to each other.
Connecting More Computers to the LAN Ports
Additional cables are required to connect further comput­ers. In purchasing a LAN cable, note the instructions in the section “Cables and Buttons” on page 123.
You can connect a computer to any of the four LAN ports of the FRITZ!Box at any time.
Connecting a Network Hub or Switch
You can connect a network hub or switch to one of the LAN ports on the FRITZ!Box if you would like to connect multi­ple computers via LAN.
FRITZ!Box Fon WLAN 7270 19
Connecting Computer(s) Wirelessly via WLAN
Connecting FRITZ!Box to a network hub
Connecting Set aside the network cable (yellow) from the FRITZ!Box
package.
1. Connect one end of the LAN cable to the uplink port
of the network hub or switch.
2. Connect the other end of the cable to one of the LAN
sockets on the FRITZ!Box.
The FRITZ!Box and network hub are now connected with each other.

3.5 Connecting Computer(s) Wirelessly via WLAN

Using WLAN you can connect one or multiple computers with the FRITZ!Box wirelessly.
The wireless WLAN connection is independent of the oper­ating system used. Each computer to be connected to the FRITZ!Box via WLAN must support WLAN, by means of a compatible WLAN adapter, for instance the FRITZ!WLAN USB Stick N.
FRITZ!Box Fon WLAN 7270 20
Connecting the FRITZ!WLAN USB Stick
For more information on WLAN, see the section “More about WLAN” from page 131.
Connecting the FRITZ!WLAN USB Stick
Connecting If you are using a FRITZ!WLAN USB Stick N or a
FRITZ!WLAN USB Stick by AVM as a WLAN adapter, you can transmit the security settings of the FRITZ!Box to your FRITZ!WLAN USB Stick quickly and conveniently using AVM Stick & Surf. Proceed as follows to do so (described here using the example of the FRITZ!WLAN USB Stick N):
1. Switch on your computer.
2. Insert the FRITZ!WLAN USB Stick N the USB port on
the FRITZ!Box. The “INFO” LED on the FRITZ!Box be­gins flashing rapidly.
The WLAN security settings are being transferred to the FRITZ!WLAN USB Stick N. As soon as the “INFO” LED stops flashing, transmission of the settings has been concluded.
3. Remove the FRITZ!WLAN USB Stick N.
4. Now insert the FRITZ!WLAN USB Stick N in the USB
port of the computer.
The security settings saved on the FRITZ!WLAN USB Stick N are applied to the computer. Now the FRITZ!Box and FRITZ!WLAN USB Stick N are connected with each other wirelessly.
For more information, see the manual on the AVM FRITZ!WLAN USB Stick N or the manual for the AVM FRITZ!WLAN USB Stick.
Using WLAN Adapters from Other Manufacturers
Installing Proceed as follows to install a WLAN adapter from another
manufacturer:
1. Switch on your computer.
FRITZ!Box Fon WLAN 7270 21
Using WLAN Adapters from Other Manufacturers
2. Install the WLAN adapter in your computer along with
the appropriate software. Please take note of the in­structions in the documentation of the adapter.
3. In order to establish a WLAN connection to the
FRITZ!Box, you must either use the WLAN software supplied with the operating system, or the manufac­turer’s WLAN software included in the WLAN adapter package.
Establishing a
Connecti on
The FRITZ!Box is delivered with preset values for WLAN se­curity. You must enter these values during the configura­tion of the WLAN adapter.
If you would like to establish a WLAN connection using these preset values, then your WLAN adapter must sup­port the WPA encryption procedure.
1. Start the WLAN software.
2. Enter the following values for the connection be-
tween the FRITZ!Box and the WLAN adapter:
SSID (name of the WLAN radio network)
Encryption methods WPA (TKIP) or WPA2 (AESCCMP)
Encryption WPA-PSK or WPA2-PSK (AES)
Key The key is printed on the sticker on
Network mode Infrastructure
FRITZ!Box Fon WLAN 7270
the base of the device and on the cover of the FRITZ!Box CD.
3. Confirm your entries using the relevant button in the
user interface (for instance, “OK” or “Connect”).
Now your WLAN adapter and the FRITZ!Box are connected with each other wirelessly.
Please see the instructions in the section “Opening the User Interface” on page 32. See also the information on WLAN security in the section “Security” from page 134.
FRITZ!Box Fon WLAN 7270 22
Using WLAN Adapters from Other Manufacturers
WPA Not Supported If your WLAN adapter does not support WPA, you must
convert the encryption in the FRITZ!Box to WEP. For this you must change the WLAN settings in the FRITZ!Box. To do so, proceed as follows:
1. Connect the FRITZ!Box and the computer using the
network cable (yellow) (see the section “Connecting Computers to the LAN Port” from page 18).
2. Start a web browser on your computer.
3. Enter fritz.box
in the address line of the browser.
4. Select the “Advanced Settings / WLAN / Security”
menu in the “Settings” area.
5. Then select WEP encryption and enter a network key.
6. Click the “Apply” button.
A window is displayed with the WLAN security set­tings.
7. Make a note of the settings or print out the page by
clicking the printer icon in the toolbar.
8. Close the user interface and clear the connection be-
tween the FRITZ!Box and the computer. Remove the network cable (yellow).
9. Configure your WLAN adapter with the security set-
tings entered in the FRITZ!Box.
The WLAN connection between your WLAN adapter and the FRITZ!Box will be established.
FRITZ!Box Fon WLAN 7270 23
Connecting to the DSL Line

3.6 Connecting to the DSL Line

Depending on whether you have a DSL line and a tele­phone line, or a DSL line without a telephone line, the FRITZ!Box is connected to DSL with two different cables.
Connecting to the Telephone Line
FRITZ!Box on the DSL line: Connecting to the telephone socket
Connecting If you have a DSL line without a telephone line, connect
the FRITZ!Box to DSL using the DSL cable (gray).
1. Insert one end of the DSL cable into the socket on the
FRITZ!Box labeled “DSL/TEL”.
2. Insert the other end into the appropriate socket on
your telephone socket.
The green “Power” LED stops flashing after a short time and remains lit to signalize that FRITZ!Box is ready for In­ternet connections over DSL.
For instructions on how to connect your telephony termi­nal devices, read from page 28.
FRITZ!Box Fon WLAN 7270 24
DSL and Telephone Line
DSL and Telephone Line
Connecting to the DSL splitter
Connecting If you have a DSL line and a telephone line, then connect
the FRITZ!Box using the DSL/telephone cable (gray-black).
1. Connect the longer of the two gray ends of the cable
to the port labeled “DSL/TEL”.
2. Then connect the other end of the cable to the socket
on the DSL splitter labeled “DSL”. If the end of the ca­ble does not fit into the socket on the splitter, insert the end of the cable into the gray RJ45/RJ11 adapter included in the package and then insert the adapter into the socket on the DSL splitter.
The black branch of the Y-shaped cable is for con­nection to the telephone line (see the page 26 and page 27).
FRITZ!Box Fon WLAN 7270 25
Connecting to the ISDN Line
The green “Power” LED stops flashing after a short time and remains lit to signalize that FRITZ!Box is ready for In­ternet connections over DSL.

3.7 Connecting to the ISDN Line

Your telephone line is either an analog line or an ISDN line.
If you have an ISDN line, read here how to connect the FRITZ!Box with the ISDN line.
Connecting to the ISDN NT
Connecting Set aside the Y-shaped cable (gray-black) delivered in the
package. This cable is a combined DSL/telephone cable.
1. Connect the longer gray end of the cable to the sock-
et on the FRITZ!Box labeled “DSL/TEL”.
2. Insert the black end of the Y-branch of the cable into
the socket of your ISDN NT. If the end of the cable does not fit into the socket on the splitter, insert the
FRITZ!Box Fon WLAN 7270 26
Connecting with the Analog Telephone Line
end of the cable into the gray RJ45/RJ11 adapter in­cluded in the package and then insert the adapter in­to the socket of the ISDN NT.
Now the FRITZ!Box and the ISDN line are connected.

3.8 Connecting with the Analog Telephone Line

Your telephone line is either an analog line or an ISDN line.
If you have an analog telephone line, read here about how to connect the FRITZ!Box with the analog telephone line.
Connecting to the analog telephone line via the DSL splitter
Connecting Set aside the Y-shaped cable (gray-black) delivered in the
package. This cable is a combined DSL/telephone cable.
1. Connect the longer gray end of the cable to the sock-
et on the FRITZ!Box labeled “DSL/TEL”.
FRITZ!Box Fon WLAN 7270 27
Connecting Telephone, Fax, or Answering Machine
2. Then insert the black plug into the appropriate sock-
et of your DSL splitter. If the plug does not fit into the splitter, connect the end of the cable to the black RJ45/RJ11 adapter included in the package and then insert the adapter into the socket on the DSL splitter.
Now the FRITZ!Box and the analog telephone line are con­nected.

3.9 Connecting Telephone, Fax, or Answering Machine

The FRITZ!Box provides Internet and/or fixed-line telepho­ny for analog terminal devices.
You can connect two analog terminal devices like tele­phones, fax machine or answering machine to the FRITZ!Box.
Analog devices with an RJ11 plug are connected to the RJ11 sockets “FON 1” and “FON 2”. These two sockets are located on the back panel of the FRITZ!Box.
Connecting an analog telephone to an RJ11 socket

3.10 Connecting ISDN Telephones

ISDN telephones can be connected to the FRITZ!Box. With appropriate cabling, up to eight ISDN telephones can be connected.
FRITZ!Box Fon WLAN 7270 28
Connecting ISDN PBXs
Connecting an ISDN telephone to the FRITZ!Box
Connecting Use an ISDN cable to connect an ISDN telephone.
1. Connect one end of the ISDN cable with the ISDN
telephone.
2. Connect the other end of the ISDN cable with the
“FON S

3.11 Connecting ISDN PBXs

If you have an ISDN PBX, you can connect this PBX to the FRITZ!Box. With the telephones connected to the PBX you can make calls in the usual fashion.
port of the FRITZ!Box.
0”
The ISDN PBX must support a point-to-multipoint line.
Connecting an ISDN PBX to the FRITZ!Box
Connecting Use an ISDN cable to connect an ISDN PBX.
FRITZ!Box Fon WLAN 7270 29
Connecting IP Telephones
1. Connect one end of the ISDN cable with the ISDN
PBX.
2. Connect the other end of the ISDN cable with the
“FON S
0”
If you have no more than two analog devices con­nected to the PBX, you can connect them directly to the FRITZ!Box and do without the PBX.

3.12 Connecting IP Telephones

IP telephones can be connected to the FRITZ!Box Fon WLAN 7270 at the LAN ports or via WLAN.
port of the FRITZ!Box.
Connecting to a LAN
At the LAN ports of the FRITZ!Box you can connect IP tele-
Port
phones using a LAN cable.
Connecting an IP telephone to the FRITZ!Box
1. Connect one end of the LAN cable with the IP tele-
phone.
2. Connect the other end of the LAN cable to one of the
LAN ports on the FRITZ!Box.
Now the IP telephone is connected to the FRITZ!Box. This phone must be configured before you can use it for tele­phone calls. Follow the instructions in the documentation of the device and in the section “Setting Up an IP Tele­phone in the FRITZ!Box” on page 41.
Connecting via WLAN IP telephones that support WLAN, known as “smart
phones”, can be connected wirelessly to the FRITZ!Box via WLAN.
FRITZ!Box Fon WLAN 7270 30
Connecting IP Telephones
Connecting a smart phone to the FRITZ!Box
1. Use your smart phone to search for WLAN devices at
2. Select the FRITZ!Box Fon WLAN 7270 from the list of
To establish a connection, enter the WLAN key of the FRITZ!Box.
your location.
WLAN devices found.
The smart phone is now connected to the FRITZ!Box. Be­fore you can make telephone calls that take advantage of the features of an IP telephone, this phone must be con­figured once. Follow the instructions in the documentation of the device and in the section “Setting Up an IP Tele­phone in the FRITZ!Box” on page 41.
FRITZ!Box Fon WLAN 7270 31
Opening the User Interface

4 Opening the User Interface

fritz.box
The FRITZ!Box has a user interface that can be used in a web browser.
The user interface presents information about the FRITZ!Box product, terminals and connections. This is where you configure all of the settings for operating the FRITZ!Box.
The user interface can be opened from any computer con­nected with the FRITZ!Box. The settings you configure are saved in the FRITZ!Box.
Starting 1. Start a web browser on your computer.
2. Enter “fritz.box
The “fritz.box” address entry in the address field of an Internet browser
The FRITZ!Box user interface opens.
If the user interface does not open, please see the in­structions in the section “Errors Opening the User Inter­face” from page 103.

4.1 Password Protection

Use the password protection set up for the user interface to protect your settings and all information in the FRITZ!Box from unauthorized access.
Here is how to set up the password protection in the FRITZ!Box:
1. Open the FRITZ!Box user interface.
2. Select “Advanced Settings / System / FRITZ!Box
Password” in the “Settings” area.
” in the address line of the browser.
FRITZ!Box Fon WLAN 7270 32
Saving Settings
3. Enable password protection and enter a password.
4. Save your settings by clicking “Apply”.
Be sure to use a password you can remember easily. If you forget the password, the only way to access the FRITZ!Box is to restore the factory settings. All settings made during operation will be overwritten. Then you can open the user interface again in order to reconfigure your settings or re­store the settings you saved during previous operation.

4.2 Saving Settings

The settings you made in the FRITZ!Box can be saved as a file on your computer. This file contains all user-defined settings, including the account information for the Inter­net and telephony connections. This settings file can be loaded back into your FRITZ!Box at any time.
The FRITZ!Box features a Wizard to accompany you step by step through the process of saving and restoring your set­tings.
FRITZ!Box Fon WLAN 7270 33
Internet Connections

5 Internet Connections

Setting Up the Internet Connection
In order to allow Internet access with the FRITZ!Box, you must first con­figure the Internet connection in the FRITZ!Box user interface.
The FRITZ!Box can be operated directly at the DSL line. Alternatively, it can be connected to a cable modem, a DSL modem, or a DSL router, or integrated into an existing network.
If no DSL line is available, the Internet connection can be established over the mobile telephone network using a USB modem.

5.1 Configuring the Internet Connection Using the Wizard

If the FRITZ!Box is connected directly to the DSL line, the account information from your Internet Service Provider is required to configure the Internet connection in the FRITZ!Box.
Use the Wizard to configure the Internet connection:
1. Open the FRITZ!Box user interface.
2. In the “Settings” area, please select the “Wizards”
menu command.
3. Click the “Configure Internet Connection” Wizard and
follow the instructions.
Once configuration has been completed, all of the com­puters connected with the FRITZ!Box can be used to surf the Internet without any further settings required.

5.2 Configuring the Internet Connection Manually

Changes to the Internet connection settings can be made in the FRITZ!Box user interface.
Proceed as follows:
1. Open the FRITZ!Box user interface.
2. Select the “Advanced Settings” menu in the “Set-
tings” area.
3. Select “Internet / Account Information”.
FRITZ!Box Fon WLAN 7270 34
Internet Connection via the Mobile Telephone Network
4. Configure the desired settings. Take advantage of the
Help available in the FRITZ!Box user interface for more information and instructions.
5. As a final step, click “Apply”.
If the FRITZ!Box is connected to a cable modem, a DSL mo­dem or a router, or integrated into an existing network, you must also configure your Internet connection as de­scribed above. To do so, enable the expert view in the “System / Expert Mode” menu.

5.3 Internet Connection via the Mobile Telephone Network

In situations where DSL is not available, you can use your FRITZ!Box Fon WLAN 7270 to connect to the Internet via the mobile telephone network. A USB modem for broad­band Internet access (UMTS/HSDPA) is required for this.
The USB modem is simply inserted into the USB port of the FRITZ!Box. The FRITZ!Box supports UMTS/HSDPA mo­dems from various manufacturers.
When the mobile telephone network function is used, the FRITZ!Box user interface presents information about net­work availability, connection status and throughput rate.
1. Insert the USB modem into the USB port on the
FRITZ!Box.
2. Open the FRITZ!Box user interface.
The user interface opens with the “Start Menu / Over­view” displayed.
3. The “Connection Information / USB Devices” area
displays the USB modem as a “Mobile Telephone Network Modem”.
4. Click “Mobile Telephone Network Modem”.
The “Mobile Telephone Network” menu opens to let you set up the USB modem.
FRITZ!Box Fon WLAN 7270 35
Internet Connection via the Mobile Telephone Network
The “Mobile Telephone Network” menu is not availa­ble until the USB modem has been connected to the FRITZ!Box. From this point on the menu is always available, even when the USB modem has been dis­connected.
5. Configure the settings for your Internet connection
over the mobile telephone network. For more infor­mation, see the Online Help of the FRITZ!Box.
Due to technical limitations on the part of the mobile tele­phone network carriers, some limitations may arise for In­ternet telephone calls and for applications requiring an incoming connections. The same is true for using port for­warding, sharing USB storage memory, remote mainte­nance via HTTPS, dynamic DNS and VPN.
FRITZ!Box Fon WLAN 7270 36
Telephone Connections

6 Telephone Connections

Configuring FRITZ!Box for Telephony
Using the FRITZ!Box you can make telephone calls via the Internet and the fixed-line network.
Once you have connected the FRITZ!Box as described in the chapter “Connection” from page 15, you can configure the FRITZ!Box for making telephone calls.
The configuration is performed in two consecutive steps:
entering your phone numbers
configuring the connected telephony devices
In the “Settings” area of the FRITZ!Box user interface there are various Wizards for the configuration of your FRITZ!Box. We recommend using these step-by-step in­structions.

6.1 Entering Your Phone Numbers

The “Enter Your Phone Numbers” Wizard supports you in performing the following tasks:
entering Internet telephone numbers
entering fixed-line telephone numbers
changing numbers already entered
deleting entered numbers
If you used the Basic Configuration Wizard after connect­ing your FRITZ!Box and entered numbers then, these num­bers are already entered in your FRITZ!Box. In this case you can start right away with the configuration of the con­nected telephony devices.
Entering New Internet Telephone Numbers
In order to be able to make calls via the Internet with the FRITZ!Box, you will need an Internet telephone number from an Internet telephony provider. Enter the Internet telephone number in the FRITZ!Box.
FRITZ!Box Fon WLAN 7270 37
Entering Fixed-line Numbers
You can enter multiple Internet numbers in the FRITZ!Box. The Internet numbers can be from one or from multiple dif­ferent Internet telephony providers.
Entering Fixed-line Numbers
With the FRITZ!Box you can make calls both via the analog fixed-line network and via the ISDN fixed-line network:
In order to make calls via the analog fixed-line net-
work with the FRITZ!Box, enter your telephone num­bers in the FRITZ!Box.
In order to make calls via the ISDN fixed-line network
with the FRITZ!Box, enter your ISDN numbers in the FRITZ!Box.

6.2 Configuring Telephony Devices

For the configuration of telephony equipment, the “Con­figure Telephony Devices” Wizard is available in the FRITZ!Box.
Telephony Devices Supported
The following telephony devices are supported by the FRITZ!Box:
telephones
analog telephones
ISDN telephones
telephones with an integrated answering machine
cordless (DECT) telephones
IP telephones
FRITZ!Box Fon WLAN 7270 38
Settings for Telephony Devices
answering machine
If you have connected an analog answering machine (to the “FON 1” or “FON 2” socket, for instance), con­figure it as an answering machine.
The FRITZ!Box is also equipped with integrated an­swering machines, which can be enabled and config­ured in the “Settings / Advanced Settings” area in the “Telephony / Telephony Devices” menu.
ISDN telephone systems (PBXs)
ISDN PBXs for analog telephones
ISDN PBXs for ISDN telephones
fax machines
The FRITZ!Box is equipped with an integrated fax ma­chine for receiving faxes. This device can be enabled and configured in the “Settings / Advanced Settings” area in the “Telephony / Telephony Devices” menu.
The FRITZ!Box also supports:
analog fax machines
ISDN fax machines
fax-telephone combinations
Settings for Telephony Devices
Telephony devices like telephones, faxes and answering machines can be connected to the FRITZ!Box. The FRITZ!Box is also equipped with an integrated answering machine and a fax machine for fax reception. The “Config­ure Telephony Devices” Wizard can assist you in configur­ing the necessary settings for all telephony devices.
Devices Connected to
the FRITZ!Box
telephone
kind of connection used to connect the telephone
with the FRITZ!Box
internal name for the telephone
FRITZ!Box Fon WLAN 7270 39
Settings for Telephony Devices
Number used to conduct outgoing calls: With this
Call acceptance: Specify here whether the tele-
fax machine
kind of connection used to connect the fax machi-
internal name for the fax machine
Number used to send faxes: This entry defines
Call acceptance: Here you define the numbers to
answering machine
kind of connection used to connect the answering
entry you specify whether outgoing calls should be conducted via the Internet or the fixed-line net­work.
phone should react to all calls or only to calls for certain telephone numbers.
ne with the FRITZ!Box
whether outgoing faxes are sent via the Internet or the fixed-line network.
which the fax machine should react.
machine with the FRITZ!Box
internal name for the answering machine
Call acceptance: Enter here whether the answer-
ing machine should react to all calls or only to calls for certain numbers.
ISDN PBX
The Wizard explains step by step how to prepare the ISDN telephone system for operation at the FRITZ!Box.
Device Integrated in
the FRITZ!Box
fax reception
Fax ID to be transmitted to the sender of the fax.
E-mail address to which the incoming faxes are
forwarded
FRITZ!Box Fon WLAN 7270 40
Setting Up an IP Telephone in the FRITZ!Box
USB memory on which the incoming faxes are
stored. For this option a USB memory device must be connected to the USB port of the FRITZ!Box.
Automatic fax detection for an analog fixed line,
which detects wether an incoming call is a fax.
answering machine
Specifications about how calls should be accept-
ed, and whether the message should also be sent by e-mail.
internal name for the answering machine
Call acceptance: Enter here whether the answer-
ing machine should react to all calls or only to calls for certain numbers.
Remote inquiry, which can be used to pick up
messages from the answering machine from an­other telephone line.
Setting Up an IP Telephone in the FRITZ!Box
Before you can use an IP telephone with the FRITZ!Box, it must be set up. Follow the instructions below:
See also the manufacturer’s documentation for informa­tion about how to set up your IP telephone.
1. Open the FRITZ!Box user interface (see the section
“Opening the User Interface” on page 32).
2. Enable the Expert Mode in the “Settings / Advanced
Settings / System” menu.
3. Click “Wizards / Telephony Devices” and then click
“Next”.
4. Select the option “Telephone” and then click “Next”.
5. Select “LAN/WLAN (IP Telephone)”, assign a name
and then click “Next”.
6. Assign a password.
FRITZ!Box Fon WLAN 7270 41
Telephony Functions
7. Enter the password, the user name and the registrar
in your IP telephone. Be sure to consult the documen­tation for your telephone on how to do this.
8. Confirm the Telephony Wizard of the FRITZ!Box by
clicking “Next” and follow the instructions.
The IP telephone will be set up in the FRITZ!Box so that it can be used to make telephone calls.

6.3 Telephony Functions

More functions and settings options for telephony are available in the “Settings / Advanced Settings” area, in the “Telephony” menu.
Call List
The Call List displays outgoing calls and sent faxes, in­coming calls and faxes, as well as incoming calls in ab­sence.
If the number of a caller or someone called is entered in the Telephone Book, the Call List will display the name from the Telephone Book.
The Call List can be saved as a file.
Menu The Call List is found in the “Settings / Advanced Set-
tings” area, in the “Telephony / Calls” section.
Telephone Book
A telephone book is at your disposal in the FRITZ!Box.
If an AVM handset is registered at the FRITZ!Box, the tele­phone book can be transferred to the handset.
Menu The “Telephone Book” is found in the “Settings / Advan-
ced Settings” area, in the “Telephony” menu.
FRITZ!Box Fon WLAN 7270 42
Call Diversion
Call Diversion
With this function you can divert incoming calls to another number. The following kinds of call diversion are availa­ble:
diversion of all incoming calls to a certain telephone
number
diversion of calls for certain numbers
diversion of calls to other telephones connected with
the FRITZ!Box
diversion of calls that come from a certain telephone
number
Menu The “Call Diversion” menu is located in the “Settings / Ad-
vanced Settings” area, in the “Telephony” menu.
Blocking Calls
The telephone number block of the FRITZ!Box offers you the following options:
numbers and number ranges can be blocked for out-
going calls
From the FRITZ!Box no outgoing calls to a blocked number range are possible. In this manner you can block connections to certain mobile networks, for in­stance.
blocking telephone numbers for incoming calls
For incoming calls you can block certain numbers to avoid receiving calls from unwanted callers.
Menu The command for blocking calls is located in the “Settings
/ Advanced Settings” area, in the “Telephony / Calls” menu.
FRITZ!Box Fon WLAN 7270 43
Alarm
Alarm
With the alarm function you can use the telephones con­nected to the FRITZ!Box as alarm clocks.
You can specify several different times for the alarm
to go off.
An individual telephone can be selected for the alarm
function.
Menu The “Alarm” function is located in the “Settings / Advan-
ced Settings” area, in the “Telephony” menu.
Dialing Rules
Dialing rules specify when calls are conducted on the fixed-line network, and when they take place over the In­ternet.
All connections to number ranges for which a dialing rule has been defined are established using the specified con­nection type.
Menu The “Dialing Rules” are located in the “Settings / Advan-
ced Settings / Telephony” area.
Integrated Fax
The FRITZ!Box is equipped with an integrated fax function so that you can receive faxes without having to connect a fax machine. The integrated fax machine forwards incom­ing faxes to an e-mail address, or stores them on a USB mass storage device connected to the FRITZ!Box.
For operation, the integrated fax machine must be set up using the Wizard for Telephony Devices in the FRITZ!Box user interface. Enter an e-mail address to which incoming faxes should be forwarded.
If the FRITZ!Box is connected to an analog fixed line with only one number, remember to enable automatic fax de­tection as well. The fax detection works passively, mean­ing that it does not detect an incoming fax until a call has been accepted. For this reason we recommend also using
FRITZ!Box Fon WLAN 7270 44
Integrated Answering Machines
the Wizard for Telephony Devices to set up an answering machine, so that fax detection can also function when you do not accept a call.
The integrated fax machine of the FRITZ!Box supports only fax reception. To send faxes you can install the “FRITZ!fax for FRITZ!Box” software. This program can be downloaded from the AVM web site for the operating systems Windows Vista, Windows XP and Windows 2000.
Integrated Answering Machines
The FRITZ!Box is equipped with several integrated answer­ing machines, each of which can be enabled and config­ured individually.
By enabling the setting “Send messages by e-mail” you can have recorded messages sent to you by e-mail. The messages are sent as audio files.
To check an answering machine internally, enter the fol­lowing keypad sequences:
Answering machine 1 ss600 Answering machine 2 ss601 Answering machine 3 ss602 Answering machine 4 ss603
etc. etc.
An overview of the answering machine menu is presented in the section “The Answering Machine Menu” on page 46.
Menu The “Answering Machine” menu is located in the “Set-
tings / Advanced Settings” area, in the “Telephony” menu.
FRITZ!Box Fon WLAN 7270 45
The Answering Machine Menu

6.4 The Answering Machine Menu

Main menu 1 Play back messages
If no messages have been recorded, you hear two short audio signals and re­turn to the main menu.
1 Pause / Play 3 Call back the caller of the message 5 Delete message 7 To previous message 9 To next message 0 Listen to “Play back messages” menu again r Back to Main menu
2 Delete all messages
3 Switch the answering machine on / off
4 Record greetings
1 Record greeting message 2 Record announcemenmt 3 Record closing message
Record and Select 1 Hear all recordings with the selected typ > Selection of the de-
sired type with 2
5 Delete recording 8 Record greeting > End with 1 0 Listen to “Record and Select” menu again
r Back to Main menu 0 Listen to “Record greetings” menu again r Back to Main menu
5 Switch the greeting and announcement mode on / of
0 Listen to Main menu again
FRITZ!Box Fon WLAN 7270 46
DECT Function

7DECT Function

Cordless Telephony with FRITZ!Box
Thanks to the integrated DECT function, the FRITZ!Box Fon WLAN 7270 can be used as a basis station for cordless telephones that support the DECT-GAP or CAT-iq standard. A total of up to five cordless phones can be registered on the FRITZ!Box.

7.1 Registering Cordless Telephones

With FRITZ!Box Fon WLAN 7270 you can use all cordless telephones that support the DECT-CAP and CAT-iq radio standards. See the documentation of your cordless tele­phone to find out whether it supports either of these stan­dards.
To register a cordless telephone from any manufacturer on the FRITZ!Box, please follow the corresponding instruc­tions in your telephone manual.
Press and hold down the search key on the FRITZ!Box la­beled “DECT” during the entire registration process. This facilitates telephone registration.

7.2 Making an Internal Call to a Cordless Telephone

All telephones connected to the FRITZ!Box can establish connections to each other free of charge.
Telephones can establish internal connections using in­ternal numbers, which are assigned to each telephone automatically upon registration.
The internal numbers of the telephones you have connect­ed are listed in the FRITZ!Box user interface. Perform the following steps:
1. Start a web browser.
2. Open the FRITZ!Box user interface by entering
fritz.box
3. In the “Start Menu” area, select the “Telephone
Book” menu.
4. Click on the “Internal Numbers” tab.
FRITZ!Box Fon WLAN 7270 47
.
Logging a Cordless Telephone off of the FRITZ!Box
The internal numbers of the telephones connected to the FRITZ!Box are displayed.

7.3 Logging a Cordless Telephone off of the FRITZ!Box

1. Start a web browser.
2. Open the FRITZ!Box user interface by entering
fritz.box
.
3. In the “Start Menu” area, select the “Telephony De-
vices” menu.
4. In the “Cordless Telephones (DECT)” area, select the
cordless phone you want to log off and click the “De­lete” button.
Now the cordless telephone will be logged off.

7.4 Enabling and Disabling DECT

The DECT function is disabled upon delivery of the FRITZ!Box.
Enabling the DECT function
The DECT function is enabled when the first cordless telephone is registered.
Disabling the DECT function
When the last cordless telephone is logged off in the FRITZ!Box user interface, the DECT function is dis­abled automatically.
FRITZ!Box Fon WLAN 7270 48
USB Devices

8USB Devices

USB Devices at the FRITZ!Box
The FRITZ!Box is equipped with a USB port (also known as a USB host controller).
The USB port of the FRITZ!Box supports the USB 1.1 and USB 2.0 stan­dards.
Various USB devices can be connected to the host controller:
one FRITZ!WLAN USB Stick N or one FRITZ!WLAN USB Stick by AVM
a USB mass storage device (hard drive, memory stick)
one USB printer
one USB modem (UMTS/HSDPA)
a USB hub
A maximum of three USB devices can be connected to the USB hub.

8.1 Connecting USB Devices

Connecting a USB cable to the USB port
Connecting Some USB devices, such as memory sticks or the
FRITZ!WLAN USB Stick N, are inserted directly into the USB port of the FRITZ!Box. Other devices like USB printers are connected to the USB port by means of a USB cable.
FRITZ!Box Fon WLAN 7270 49
Accessing USB Devices

8.2 Accessing USB Devices

Network Access As soon as a USB device is connected to the FRITZ!Box, all
of its functions are available in the entire network:
The files in the USB mass storage can be accessed
from the network via FTP (File Transfer Protocol), or you can make the USB mass storage device available as a network storage device. The two kinds of access are explained in greater detail in the section “Access­ing the Data in the USB Mass Storage” on page 51.
USB printers are available as network printers.
USB Remote
Connecti on
With the USB remote connection, a computer in the net­work can use USB devices just as if they were connected directly to the computer via the USB cable.
The USB remote connection is enabled for each USB de­vice class individually (USB printer, USB storage and other USB devices).
While a computer accesses a USB device via the USB re­mote connection, the USB device is not available for other computers in the network.

8.3 USB Mass Storage Devices

USB mass storage devices include hard drives and memo­ry sticks.
File Systems For access via FTP (File Transfer Protocol), or via the USB
remote connection, USB mass storage devices using the file systems FAT, FAT32, and NTFS are supported.
Connecting A USB storage device can be connected either directly to
the USB port or via the USB hub (see the “USB Hub” from page 63).
Please see also the “Tips for Using USB Devices” from page 64.
FRITZ!Box Fon WLAN 7270 50
Access Rights and Passport Protection
Access Rights and Passport Protection
The access rights and password are valid for all USB mass storage devices. It is not possible to assign a different password for each individual mass storage device. The access rights and password are are not enabled if the USB remote connection is enabled for all USB mass stor­age devices.
Access Rights and
Passport Protection
FTP (File Transfer
Protocol)
On the FRITZ!Box user interface you can configure access rights and password protection for USB mass storage de­vices.
1. Start a web browser.
2. Enter fritz.box
in the address field.
3. Select the “Advanced Settings” menu in the “Set-
tings” area.
4. Select the “USB Devices / Mass Storage Device”
menu.
5. Configure the access rights and password protection
for the USB mass storage devices.
Accessing the Data in the USB Mass Storage
USB storage devices connected to the FRITZ!Box directly or via a USB hub are displayed with their device name in the “USB Devices / Device Overview” menu on the user in­terface.
All of the computers in the network can access the data in the USB mass storage simultaneously via FTP.
Access via FTP is possible only if the USB remote connec­tion is not enabled for USB storage devices.
Click the name of the USB storage device in the “USB De­vices / Device Overview” menu or open a web browser and enter FTP://fritz.box ture of the USB storage device is displayed in the web browser.
FRITZ!Box Fon WLAN 7270 51
in the address field. The folder struc-
Accessing the Data in the USB Mass Storage
The data in the USB storage device can be accessed via FTP using any FTP client.
Files from the USB storage device cannot be executed or opened in a suitable program until they have been copied to your computer or your local network.
USB Network
Memory
The FRITZ!Box offers you the possibility of making USB mass storage devices available in the Windows network as network drives (Samba). Files in the USB memory then can be opened and processed directly on the USB mass storage device.
Files are supported up to a size of 2 GB.
Access to USB network memory is only possible if the USB remote connection is not enabled for USB storage devic­es.
Musikbox With this command music files on the USB mass storage
device can be played back by compatible devices (stream­ing). The hard drive with the music collection is simply connected to the USB port of the FRITZ!Box and a suitable playback device is integrated into the local network.
The devices automatically communicate via Universal Plug & Play (UPnP). This technology allows the devices con­nected to each other by cable or radio network to perform automatic detection, recognize events, and exchange data with each other accordingly. With UPnP-AV this technology has been expanded to audio and video contents.
With the Musikbox, music files of all kinds of formats can be made available from the connected USB memory via UPnP.
FRITZ!Box Fon WLAN 7270 52
USB Printer

8.4 USB Printer

To connect a USB printer to the USB port of the FRITZ!Box, you can either enable the USB remote connection, or use it as a network printer.
USB Printer at the USB Remote Connection
If you enable the USB remote connection for USB printers, then you can use the printer on another computer just as if it were connected directly to your computer.
If you want to use the printer with the USB remote
connection enabled, then the program for the USB re­mote connection (see page 60) and the suitable printer drivers must be installed on any computer that is supposed to use the printer.
When the USB remote connection is enabled, all-in-
one printers (printers with supplementary fax or scanner functions) can also be used for faxing and scanning.
If your printer is equipped with a status monitor, you
can use this feature when the USB remote connection is enabled.
Host-based printers that work according to the GDI
system, for instance, and require bidirectional com­munication for status messages, can only be used via the USB remote connection. These printers usually can be used only with an operating system for which the printer manufacturer has provided driver soft­ware. Such printers connected to the FRITZ!Box are not supported as network printers.
FRITZ!Box Fon WLAN 7270 53
USB Printer as a Network Printer
USB Printer as a Network Printer
When configured as a network printer, the USB printer can be used simultaneously by all of the computers connected to the FRITZ!Box.
If you want to use the printer as a network printer, the
printer port must be configured, and the suitable printer drivers installed, on every computer. Print jobs are forwarded to the IP address of the printer server in the local network via the printer port.
Only printers that can be addressed with the device
class “Printer” are supported as network printers. This is generally not the case for some multi-function devices, for instance combined fax-scanner-printers.
If your printer is equipped with a status monitor, it
may not be possible to use the status monitor if the printer is operated as a network printer.
For multi-function devices (printers with additional
functions like fax or scanning), only the printing func­tion is supported for network printers.
Configuring the Windows Printer Port for a Network Printer
If the “FRITZ!Box” entry is already listed in the “Programs” group of the start menu of the computer, this means that the printer port is already configured on this computer.
Otherwise, work through the following steps to configure the printer port:
1. Insert the FRITZ!Box CD in your CD-ROM drive.
The installation Help is started.
2. Click the “View CD Contents” button.
3. Click the “Start Menu Entry” button.
The printer port designated “AVM: (FRITZ!Box USB Printer Port)” will be configured.
Now you can install the printer drivers of the printer con­nected to FRITZ!Box for this printer port.
FRITZ!Box Fon WLAN 7270 54
USB Printer as a Network Printer
Installing Print Drivers in Windows Vista
1. Click the “Start” button in the task bar and select the
“Control Panel”.
2. Select “Printers”.
3. Click “Add Printer”.
4. Select “Add a local printer”.
You must make this selection because the printer port on the computer functions as a local port.
5. Select the setting “Use an existing port” and then
choose the entry “AVM: (FRITZ!Box USB Printer Port)” from the list. Click “Next”.
6. Select the manufacturer for the USB printer connect-
ed to the FRITZ!Box from the “Manufacturers” list and then select the exact model from the “Printers” list.
If the manufacturer or the model is not included in the lists, use an installation disk or CD with the re­quired files and click “Have Disk...”.
7. You can enter a name for the printer in the “Printer
Name” field. The operating system will use this name to administer the printer.
8. Conclude the installation by clicking “Finish”.
Installing Print Drivers in Windows XP/2000
1. Open the start menu of the computer and click the
“Printers and Faxes” entry (Windows XP) or click “Start / Settings / Printer” (Windows 2000).
2. In the “Printers and Faxes” window, click “Add a
printer” in the “Printer Tasks” area on the left hand side.
The “Add Printer Wizard” will be started.
3. Click “Next”.
FRITZ!Box Fon WLAN 7270 55
USB Printer as a Network Printer
4. Select the option “Local printer attached to this com-
puter” (Windows XP) or click “Local Printer” (Windows 2000) and make sure that the setting “Au­tomatically detect and install my Plug and Play print­er” is disabled.
You must make this selection because the printer port on the computer functions as a local port.
5. Click “Next”.
6. In the “Select a Printer Port” window, select the op-
tion “Use the following port” and select “AVM: (FRITZ!Box USB Printer Port)” from the list field. Click “Next”.
7. Select the manufacturer for the USB printer connect-
ed to the FRITZ!Box from the “Manufacturers” list and then select the exact model from the “Printers” list.
If the manufacturer or the model is not included in the lists, use an installation disk or CD with the re­quired files and click “Have Disk...”.
8. In the “Name Your Printer” window, answer the ques-
tion “Do you want to use this printer as the default printer?” (Windows XP) or “Do you want your Win­dows-based programs to use this printer as the de­fault printer?” (Windows 2000) with “No”.
Setting Up Printers in SUSE Linux Systems
A USB printer can be connected to the USB port of the FRITZ!Box for use as a network printer. The printer is then available to all computers connected with the FRITZ!Box.
You install the printer as “root” or “superuser”.
1. Open a console and enter the following command:
lpadmin -p <printer_name> -E -v socket://<IP_ address_of_the_FRITZ!Box>:<port_number> -m <printer_description_file.ppd>
FRITZ!Box Fon WLAN 7270 56
USB Printer as a Network Printer
2. For more information and instructions, go to the fol-
lowing web site:
http://www.cups.org/man/lpadmin.html
The printer must be supported by CUPS (Common UNIX Printing System) software and be detected correctly at the USB port of the FRITZ!Box.
Example For a laser jet printer with the example name of Laserjet4
and the PPD file laserjet.ppd at a FRITZ!Box with the de­fault address 192.168.178.1, on the console you must en­ter:
lpadmin -p LaserJet4 -E -v socket://192.168.178.1:9100 ­m laserjet.ppd
You can view the PPD files installed in the system with the following command:
lpinfo -m
For More Information Please direct any questions about PPD files to the manu-
facturer of the printer or system used. More detailed infor­mation on the CUPS printing software is included in the following documentation:
http://www.cups.org/documentation.php
More detailed questions on the setup should also be di­rected to the manufacturer of the distribution or to an In­ternet-based or usenet forum that deals with CUPS or the distribution used.
Setting Up USB Printers on Apple Computers
A USB printer can be connected to the USB port of the FRITZ!Box for use as a network printer. The printer is then available to all computers connected with the FRITZ!Box.
The only printers that can be used are the ones whose drivers can be selected in the printer utility or for which a compatible driver is available there.
FRITZ!Box Fon WLAN 7270 57
USB Printer as a Network Printer
1. Open “Programs / System Preferences / Print & Fax”.
2. Click the “+” at the left of the bottom half of the
screen.
FRITZ!Box Fon WLAN 7270 58
USB Printer as a Network Printer
3. Click “IP”.
4. In the “Protocol:” field, select the entry “HP JetDirect
– Socket”.
5. Enter in the “Address:” field the IP address of the
FRITZ!Box:
192.168.178.1
6. Leave the “Queue:” field empty.
7. Enter the desired values in the “Name:” and “Loca-
tion:” fields.
8. Enter a driver compatible with your printer in the
“Print Using:” field.
FRITZ!Box Fon WLAN 7270 59
FRITZ!Box USB Remote Connection
If the printer cannot be selected, it may be possible to select a compatible printer or printer driver.
9. Click the “Add” button to save your settings.
The printer is then available to all computers connected with the FRITZ!Box.
Information about compatible printers or printer drivers is available in the Internet, for instance on the following page:
http://gutenprint.sourceforge.net/p_Supported_Print­ers.php

8.5 FRITZ!Box USB Remote Connection

The USB remote connection can be utilized in Windows Vista (32-bit) and Windows XP (32-bit) with Ser­vice Pack 2 or higher.
With the FRITZ!Box USB remote connection you can control connections between your computer and USB devices. The computer and the USB devices are all connected with the FRITZ!Box.
A USB device connected to the FRITZ!Box is handed over to a computer via the USB remote connection function. The USB device is detected as new hardware by the oper­ating system on this computer, so that device software can be installed as if it were connected directly to the computer.
Isochronal USB devices with time-critical transmission (isochronous USB devices like sound cards, web cams, video converters or TV adapters) are not supported. The FTP and USB network memory functions are not available as long as the USB remote connection is active for USB storage devices.
FRITZ!Box Fon WLAN 7270 60
Enabling the USB Remote Connection
Enabling the USB Remote Connection
Work through the following steps in order to enable the USB remote connection on your computer:
1. Start a web browser on your computer.
2. Enter fritz.box
in the address line of the browser.
3. Select the “Advanced Settings” menu in the “Set-
tings” area.
4. Enable the expert view of the FRITZ!Box in the “Sys-
tem / Expert Mode” menu. Confirm by clicking “Ap­ply”.
5. Open the “USB Devices / Device Overview” menu.
6. Select the setting “Enable USB remote connection”
and click “Apply”.
7. Open the “USB Remote Connection” menu and in-
stall the program for the USB remote connection on the computer from which you want to use the USB de­vices. Follow the instructions on the “USB Remote Connection” page.
The program can be implemented in Windows Vista (32-bit) and Windows XP (32-bit) with Service Pack 2 or higher.
8. The next step is to specify for which kind of USB de-
vices the USB remote connection should be enabled. Enable the desired options.
9. As a final step, click “Apply”. All USB devices con-
nected to the FRITZ!Box will be detected again.
The result of the changed USB settings can be viewed in the “Device Overview”.
FRITZ!Box Fon WLAN 7270 61
Disabling the USB Remote Connection
Disabling the USB Remote Connection
Perform the following steps to disable the USB remote connection:
1. Open a web browser on the computer for which the
USB remote connection is to be disabled.
2. Enter fritz.box
in the address line of the browser.
3. Select the “Advanced Settings” menu in the “Set-
tings” area.
4. Enable the expert view of the FRITZ!Box in the “Sys-
tem / Expert Mode” menu. Confirm by clicking “Ap­ply”.
5. Open the “USB Devices / USB Remote Connection”
menu.
6. Disable all types of USB devices.
7. As a final step, click “Apply”.
The result of the changed USB settings can be viewed in the “Device Overview”.

8.6 FRITZ!WLAN USB Stick N and FRITZ!WLAN USB Stick

The FRITZ!WLAN USB Stick N and the FRITZ!WLAN USB Stick are WLAN adapters manufactured by AVM for con­nection to a computer. Using a WLAN adapter you can con­nect the computer wirelessly with the FRITZ!Box.
FRITZ!WLAN USB
Stick N
The FRITZ!WLAN USB Stick N supports all WLAN features of your FRITZ!Box.
the WLAN standards IEEE 802.11 n+g+b in the 2.4-
GHz frequency band, and alternatively
the WLAN standards IEEE 802.11 n+a in the 5-GHz
frequency band.
For more information, see the chapter “More about WLAN” from page 131 and the manual for the FRITZ!WLAN USB Stick N.
FRITZ!Box Fon WLAN 7270 62
USB Hub
FRITZ!WLAN USB
Stick
If you are using the FRITZ!WLAN USB Stick with your FRITZ!Box, the WLAN standards IEEE 802.11 g+b are sup­ported in the 2.4-GHz frequency band.
For more information, see the “More About WLAN” chapter from page 142 and the manual for the FRITZ!WLAN USB Stick.
AVM Stick & Surf With the AVM Stick & Surf technology it is easy to estab-
lish a secure WLAN connection. Stick & Surf is possible wi­th the FRITZ!WLAN USB Stick N and also with the FRITZ!WLAN USB Stick.
1. Insert the your stick into the USB port on the
FRITZ!Box.
The WLAN security settings are transmitted automati­cally to the FRITZ!WLAN USB Stick. The “INFO” LED on the FRITZ!Box begins flashing rapidly.
As soon as the “INFO” LED stops flashing, transmis­sion of the settings has been concluded.
2. Remove the FRITZ!WLAN USB Stick from the device.
3. After the security settings have been transmitted au-
tomatically, you can insert the FRITZ!WLAN USB Stick in a computer.
Now the FRITZ!WLAN USB Stick is ready to establish a con­nection to the FRITZ!Box. No further settings are neces­sary.

8.7 USB Hub

A USB hub can be connected to the USB host controller. A USB hub is a device to extend existing USB ports.
You can connect two USB mass storage devices and one USB printer, or three USB mass storage devices (like a hard drive or memory stick) to the USB hub.
AVM storngly advises to use a USB hub with its own pow­er supply.
FRITZ!Box Fon WLAN 7270 63
Tips for Using USB Devices

8.8 Tips for Using USB Devices

When using USB devices at the USB port of the FRITZ!Box, please keep in mind the following;
If more than one USB device without its own power
supply is connected to the FRITZ!Box, please note that, in accordance with the USB specification, the total current consumption may not exceed a value of 500 mA. Otherwise unspecified malfunctions with the USB devices or even damage to the FRITZ!Box may occur.
AVM expressly advises against performing firmware
updates for USB devices connected to the computer via the USB remote connection on the FRITZ!Box.
Before removing a USB storage device, select the
“Remove safely” option in the FRITZ!Box user inter­face to prevent losses of data.
To avoid damage to the FRITZ!Box, only operate USB
storage devices that require more than one USB port for operation (for instance hard drives with a Y cable) if they have their own power supply or a USB hub wi­th its own power supply.
AVM has no influence over external interference to
the USB memory devices on the FRITZ!Box. Thus such phenomena as voltage spikes during storms may oc­cur, and writing to older USB memory devices may corrupt the data structure due to a high number of defective structures. In such cases a complete loss of data may occur.
Therefore AVM recommends always making a securi­ty copy of the USB memory content so that your data are not irretrievably lost just because losses may oc­cur on the USB storage device.
FRITZ!Box Fon WLAN 7270 64
FRITZ!DSL: The Software Suite

9FRITZ!DSL: The Software Suite

Using DSL with the FRITZ!Box
The FRITZ!DSL software includes a number of programs designed for use with DSL, all of which are introduced briefly in this chapter.
Once you have installed FRITZ!DSL, the “Start Center” icon appears on your desktop. All of the programs in the soft­ware package are integrated in the StartCenter, from where they can be started directly.
The StartCenter contains the following buttons:
The “Internet” button starts the FRITZ!DSL Internet pro­gram. FRITZ!DSL Internet is the Internet monitoring soft­ware for your FRITZ!Box, with which you receive more de­tailed information about your current Internet connection.
The “Protect” button starts the FRITZ!DSL Protect program, which checks the Internet connections and supplements the firewall functions of your FRITZ!Box.
Click the “FRITZ!Box” button to open the user interface of FRITZ!Box in your web browser.
Click the “Update” button to check whether a firmware up­date for your FRITZ!Box is available on the AVM web site.
The “Diagnosis” button starts the FRITZ!DSL Diagnosis. This programs displays all relevant data about your DSL connection and checks the connection to your FRITZ!Box.
A click on the “Web Test” button starts the WebWatch pro­gram, which can measure the quality of your Internet con­nection to any remote site.
For comprehensive information about the FRITZ!DSL pro­grams, see the relevant Online Help files.
FRITZ!Box Fon WLAN 7270 65
Installing FRITZ!DSL

9.1 Installing FRITZ!DSL

1. Insert the FRITZ!Box CD and start “Setup.exe”.
2. Select “View CD Contents / Install FRITZ!DSL”.
3. The “File Download” window opens. Select the
“Open” button.
4. The welcome screen of FRITZ!DSL appears. Confirm
with “Continue”.
5. Specify the folder in which you want to install
FRITZ!DSL on your computer. Confirm with “Contin­ue”.
6. Next, specify the program group for FFRITZ!DSL in the
Start menu. Confirm with “Continue”.
7. Confirm with “Finish”.
Installation has been concluded.

9.2 FRITZ!DSL Internet

FRITZ!DSL Internet is the Internet monitoring software for your FRITZ!Box. For instructions on how to configure the program, see the corresponding Online Help.
As soon as an Internet connection has been established, FRITZ!DSL Internet presents you with information about the current Internet connection. The program displays the connection status, provides information about the course of data transmissions, and allows the Internet connection of FRITZ!Box to be established or cleared from the comput­er.
FRITZ!Box takes care of dialing into the Internet, firewall protection from unauthorized incoming connections, and keeps track of data volume and online time.
FRITZ!Box Fon WLAN 7270 66
FRITZ!DSL Protect

9.3 FRITZ!DSL Protect

FRITZ!DSL Protect protects your computer from unwanted Internet connections, supplementing the firewall func­tions of your FRITZ!Box. With FRITZ!DSL Protect you can check all Internet connections that are established or accepted by local programs on your computer. You can permit or prohibit individual programs from accepting connections: If an unknown program attempts to establish an Internet connection, you will be asked whether you wish to allow such a connection.
An overview shows the programs already set up in FRITZ!DSL Protect along with their access rights. A Journal grants you an overview of all successful and rejected at­tempts to access the Internet.
One of the most convenient functions offered by FRITZ!DSL Protect works in combination with the UPnP capability of the FRITZ!Box. If you have enabled the option “Allow changes to security settings over UPnP” in the FRITZ!Box, FRITZ!DSL Protect can release ports for incoming connec­tions on the FRITZ!Box whenever they are needed by pro­grams. For this capability you must activate the “Use Port Forwarding” option in the “Settings” of FRITZ!DSL Protect. In this manner you can participate in online activities like gaming without having to reconfigure the FRITZ!Box fire­wall functions manually.

9.4 FRITZ!Box

Click the “FRITZ!Box” button to open the user interface of FRITZ!Box in your web browser.
FRITZ!Box Fon WLAN 7270 67
Update

9.5 Update

New firmware updates for the FRITZ!Box are provided by AVM at regular intervals, free of charge. The updates can add new functions to your FRITZ!Box.
Click the “Update” button to check whether there is a new update available for the FRITZ!Box firmware.
When the FRITZ!DSL Start Center is started, the AVM web site is automatically checked for new updates at regular intervals. You will be informed when a new update is available.

9.6 FRITZ!DSL Diagnosis

FRITZ!DSL Diagnosis reports comprehensively about all of the details of the DSL connection, including data trans­mission and the activated fast-path mode. The compre­hensive DSL diagnostics function makes it possible to monitor the FRITZ!Box connection and installation.

9.7 WebWatch

Click the “Web Test” button in the FRITZ!DSL Start Center to start the FRITZ!DSL Web test program. FRITZ!DSL WebWatch determines the quality of your Internet connec­tion, and displays the results of these test graphically.
Once any URL is entered, FRITZ!DSL WebWatch sends a signal to the destination address.
The measured response times and the path of the data packets through the Internet are displayed in a diagram.
FRITZ!Box Fon WLAN 7270 68
Configuration and Operation on the Telephone

10 Configuration and Operation on the Telephone

FRITZ!Box Keypad Sequences
Many of the FRITZ!Box functions and features can be con­figured and used over a telephone connected to a FRITZ!Box extension. Only tone-dialing (dual-tone multi­frequency = DTMF) telephones can be used in configura­tion and operation. Pulse dialing telephones are not suit­able.
The telephone network features can be used only if they are supported by your telephone network carrier and en­abled on your telephone line.
Acknowledgment
Ton e
Entries input on the telephone are confirmed with ac­knowledgement tones (see also “Audio Signals” on page 71):
Entries made correctly are confirmed with a positive
acknowledgement tone (a single tone of one second in length).
If the entry was not successful, because of an incor-
rect key sequence, for instance, you hear a negative acknowledgment tone (an intermittent tone broken into intervals of about 0.25 seconds).
FRITZ!Box Fon WLAN 7270 69
The Telephone Keypad

10.1 The Telephone Keypad

0 through 9 Numeric keys s Asterisk key R Hold or flash key r Pound key

10.2 Instructions for Operation at the Telephone

M Dial a number. N Pick up the handset. O Hang up the handset. P Tal k. D Three-party conference call Q Wait for the acknowledgement tone. K You hear the ring tone.
<Ext.> Enter an extension number (Ext.).
In the place of the abbreviation <Ext.> used here, enter the number 1, 2 or a higher number, corresponding to the extension you would like to configure.
<MSN> Enter an ISDN number (MSN).
In place of the abbreviation <MSN> used here, enter the complete MSN desired, wit­hout any dialing prefix.
<DNo> Enter an external telephone number (desti-
nation number).
In the place of the abbreviation <DNo>, en­ter the complete number of the external line.
<DNo./Ext.> Enter the external telephone number (des-
tination number) or extension number (Ext.) to which your calls are to be diverted.
FRITZ!Box Fon WLAN 7270 70
Audio Signals
Audible Signals
Time in seconds
Ring
Busy signal
Internal dial tone
External dial tone
Positive confirmation
Neg. acknowledgment
Call waiting
Calls
External call
Internal call
Call back
012
3
4
56
Internet telephony
Registration error
Fixed-line subs titute

10.3 Audio Signals

The following diagram illustrates the duration and inter­vals of the various audio signals and ring tones of the tele­phones connected to the FRITZ!Box Fon WLAN 7270.
FRITZ!Box Fon WLAN 7270 71
Audio signals and ring tones of the connected telephones
Configuring on the Telephone

10.4 Configuring on the Telephone

Saving New Settings
In this section, saving refers to all current settings made in the FRITZ!Box. It is not necessary to save the configuration immediately after every change. You may first configure all of your settings as desired, and then save them perma­nently.
Permanent saving cannot be reversed. However, you can change the settings by using new commands or restore the FRITZ!Box to its factory settings.
Saving Permanently
N Pick up the handset. r91ss Save all settings permanently by dialing the
sequence shown at left.
O Hang up the handset.
Restoring Factory Settings
The FRITZ!Box can be reset to its condition upon delivery by restoring the factory settings.
All settings you made in the FRITZ!Box—including the con­figured Internet connection—are deleted when the factory settings are restored.
Restoring Factory Settings
r991s159 01590s
After restoring the factory settings, the FRITZ!Box is re­started.
FRITZ!Box Fon WLAN 7270 72
resets the FRITZ!Box to its condition upon delivery
Enabling/Disabling WLAN
Enabling/Disabling WLAN
The WLAN function can be switched on and off using the telephone keypad. This is especially convenient when the WLAN function has been switched off. Simply use your telephone to turn it back on. This means that the WLAN function can be enabled without having to use a wired connection to open the user interface.
Enabling and Disabling WLAN
r96s1s enables the WLAN function r96s0s disables the WLAN function
Do Not Disturb
You can enable a Do Not Disturb function for any tele­phone connected to FRITZ!Box in the user interface. When Do Not Disturb is enabled, the telephone will not ring. In configuring this function you can choose between en­abling the function immediately and selecting a specific time period.
Immediately When Do Not Disturb is enabled immediately, no incoming
calls will be signaled at the specified extension. The Do Not Disturb setting will remain enabled until it is disabled.
Period Alternatively, you can enter a Do Not Disturb period during
which the telephone will not ring. At the extension for which a Do Not Disturb period is to be configured, define the period during which the phone should not ring and save your entries. Then enable Do Not Disturb. Do Not Dis­turb then automatically will be switched on daily at the time entered in the “Start” field and switched off again at the time defined in the “End” field.
Example: Do Not Disturb should be configured from 20:00 p.m. until 07:00 a.m. daily. Enter the value “2000” for <Start> and “0700” for <End>.
Disabling the
Function
FRITZ!Box Fon WLAN 7270 73
Both kinds of Do Not Disturb settings can be disabled by means of a keypad sequence.
Alarm
Enabling Do Not Disturb Effective Immediately
r81<Ext.>s0s immediately enables Do Not Disturb for
the extension entered as <Ext>
Enabling Do Not Disturb for a Prescribed Period
r80<Ext.>s <Start>s<End>s
r91ss saves the settings r81<Ext.>s6s enables Do Not Disturb for the defined
Disabling Do Not Disturb
r81<Ext.>s6s disables Do Not Disturb for extension
defines the period for Do Not Disturb at extension <Ext.>
period
<Ext.>
Alarm
The FRITZ!Box includes an alarm function. The alarm can be configured individually for each connected telephone.
First enter on the telephone the time at which you would like to be awakened and save this entry. Then enable the alarm function.
Example: The telephone should ring to wake you at 07:00 a.m. Enter the value “0700” as the <Time> and save this setting.
Configuring the Alarm for a Telephone
r881s<Time>s <Ext.>s
r91ss saves the settings
FRITZ!Box Fon WLAN 7270 74
defines for the extension <Ext.> the time at which the telephone should ring
Call Diversion on the ISDN Line
Enabling/Disabling the Alarm Function
r881ss enables the alarm function for all ex-
r881r disables the alarm function for all ex-
Call Diversion on the ISDN Line
Call forwarding is performed by the ISDN operator’s switching station. To use call forwarding, FRITZ!Box must be connected to an ISDN line. Then this feature can be used to forward calls to an external line. Call forwarding is subject to charges by the network provider and cannot be used to forward calls to Internet numbers.
In addition to call forwarding, there is also call diversion via FRITZ!Box. Use this kind of call diversion to divert calls to internal and external lines. See the section “Call Diver­sion” on page 80 for more information.
Do not activate both call forwarding and call diversion at the same time.
tensions on which a time was set
tensions
For call forwarding you may specify whether you want in­coming calls to be forwarded unconditionally, after the fifth ring, or when busy. Different settings may be config­ured separately for each number.
Call Forwarding
Immediately
Incoming calls for the given MSN are always diverted im­mediately to the specified number. Call forwarding is sub­ject to charges by the network provider and cannot be used for forwarding calls to Internet numbers.
Call Forwarding Immediately for your Outgoing Caller ID
N Pick up the handset. s21s<DNo>r Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
FRITZ!Box Fon WLAN 7270 75
Call Diversion on the ISDN Line
Call Forwarding Immediately for Any MSN
N Pick up the handset. s21s<DNo> s<MSN>r Q Wait for the acknowledgement tone. O Hang up the handset.
Call Forwarding Immediately for All MSNs
N Pick up the handset. s21s<DNo>sr Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
Disabling Call Forwarding Immediately for Aour Outgoing Caller ID
N Pick up the handset. s21sr Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
Dial the sequence shown at left.
Disabling Call Forwarding Immediately for Any MSN
N Pick up the handset. s21ss<MSN>r Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
Disabling Call Forwarding Immediately for All MSNs
N Pick up the handset. s21ssr Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
FRITZ!Box Fon WLAN 7270 76
Call Diversion on the ISDN Line
Call Forwarding When
Busy
Incoming calls are forwarded to the specified number only if a call is already being conducted using the number dialed. You can define call diversion for the local outgoing call number. The local outgoing call number is the first number you assigned to an extension. You can also define call diversion for any other number, e.g. a telephone at an­other extension, or for all numbers. All settings can be dis­abled at any time.
Call Forwarding When Busy for Your Outgoing Caller ID
N Pick up the handset. s67s<DNo>r Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
Call Forwarding When Busy for Any MSN
N Pick up the handset. s67s<DNo> s<MSN>r Q Wait for the acknowledgement tone. O Hang up the handset.
Dial the sequence shown at left.
Call Forwarding When Busy for All MSNs
N Pick up the handset. s67s<DNo>sr Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
Disabling Call Forwarding When Busy for Your Outgoing Caller ID
N Pick up the handset. s67sr Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
FRITZ!Box Fon WLAN 7270 77
Call Diversion on the ISDN Line
Disabling Call Forwarding When Busy for Any MSN
N Pick up the handset. s67ss<MSN>r Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
Disabling Call Forwarding When Busy for All MSNs
N Pick up the handset. s67ssr Dial the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset.
Call Forwarding
Delayed
Incoming calls are forwarded to the specified number if not answered at the number originally dialed within 20 seconds (about five rings). Call forwarding can be con­figured for your extension’s outgoing caller ID (the first number assigned to an extension), for any number (for in­stance, a telephone at the other FRITZ!Box extension), or for all numbers. All settings can be disabled at any time.
Call Forwarding Delayed for Your Outgoing Caller ID
N Pick up the handset. s61s<DNo>r Dial the sequence shown at
left.
Q Wait for the acknowledgement
tone.
O Hang up the handset.
Call Forwarding Delayed for Any MSN
N Pick up the handset. s61s<DNo> s<MSN>r Q Wait for the acknowledgement
O Hang up the handset.
Dial the sequence shown at left.
tone.
FRITZ!Box Fon WLAN 7270 78
Call Diversion on the ISDN Line
Call Forwarding Delayed for All MSNs
N Pick up the handset. s61s<DNo>sr Dial the sequence shown at
Q Wait for the acknowledgement
O Hang up the handset.
Disabling Call Forwarding Delayed for Your Outgoing Caller ID
N Pick up the handset. s61sr Dial the sequence shown at
Q Wait for the acknowledgement
O Hang up the handset.
Disabling Call Forwarding Delayed for Any MSN
N Pick up the handset. s61ss<MSN>r Dial the sequence shown at
Q Wait for the acknowledgement
O Hang up the handset.
left.
tone.
left.
tone.
left.
tone.
Disable Call Forwarding Delayed for All MSNs
N Pick up the handset. s61ssr Dial the sequence shown at
Q Wait for the acknowledgement
O Hang up the handset.
FRITZ!Box Fon WLAN 7270 79
left.
tone.
Call Diversion
Call Diversion
Incoming calls to the FRITZ!Box telephones can be divert­ed to a different extension or to an external number. In contrast to call diversion over FRITZ!Box, there is also call forwarding (call diversion via the central exchange). How to use call forwarding by telephone is described in the section “Call Diversion on the ISDN Line” on page 75.
Do not activate both call forwarding and call diversion at the same time.
Call diversion allows you to forward calls to an external line or to another extension. This kind of diversion is orga­nized inside FRITZ!Box so that diversions to another exten­sion are free of charge. Calls are diverted to an external number over your ISDN line’s second B channel and are subject to normal transmission charges. If the FRITZ!Box is operated on an analog telephone line, incoming calls can only be diverted to a different extension or to Internet numbers.
Note that only numerical Internet telephone numbers can be entered for diversion to an Internet telephone number.
You can specify the conditions under which an incoming call will be diverted. You can select one of five different options. Different settings may be saved for each exten­sion.
Call Diversion Immediately (Without Ringing)
N Pick up the handset. r41<Ext.>s
<DNo>/<Ext.>s r91ss Save your settings if desired by di-
O Hang up the handset.
FRITZ!Box Fon WLAN 7270 80
Dial the sequence shown at left.
aling the sequence shown at left.
Call Diversion
Call Diversion After the Third Ring
N Pick up the handset. r42<Ext.>s <DNo>/<Ext.>s r91ss Save your settings if desired by
O Hang up the handset.
Call Diversion When Busy
N Pick up the handset. r43<Ext.>s <DNo>/<Ext.>s r91ss Save your settings if desired by
O Hang up the handset.
Dial the sequence shown at left.
dialing the sequence shown at left.
Dial the sequence shown at left.
dialing the sequence shown at left.
Call Diversion After the Third Ring or When Busy
N Pick up the handset. r44<Ext.>s
<DNo>/<Ext.>s r91ss Save your settings if desired by
O Hang up the handset.
FRITZ!Box Fon WLAN 7270 81
Dial the sequence shown at left.
dialing the sequence shown at left.
Call Waiting
Call Diversion Immediately With Ringing
N Pick up the handset. r45<Ext.>s <DNo>/<Ext.>s r91ss Save your settings if desired by
O Hang up the handset.
Disabling Call Diversion
N Pick up the handset. r40<Ext.>ss Dial the sequence shown at left. r91ss Save your settings if desired by
O Hang up the handset.
Dial the sequence shown at left.
dialing the sequence shown at left.
dialing the sequence shown at left.
Call Waiting
Call waiting can be switched on or off for each extension. Some older terminal devices connected to extensions may misinterpret the call waiting signal. This is especially true of fax machines and modems. If communication errors oc­cur, you should disable call waiting for fax and modem ex­tensions.
See section “Waiting Calls” on page 91 for information about how to accept a call while another connection is ac­tive.
When call waiting is enabled, modem and fax connec­tions may be interrupted.
FRITZ!Box Fon WLAN 7270 82
Suppressing the Caller ID for Outgoing Calls (CLIR)
Enabling Call Waiting
N Pick up the handset. r2 <Ext.> s0s Dial the sequence shown at left. r91ss Save your settings if desired by dialing the
sequence shown at left.
O Hang up the handset.
Disabling Call Waiting
N Pick up the handset. r2 <Ext.> s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing the
sequence shown at left.
O Hang up the handset.
Suppressing the Caller ID for Outgoing Calls (CLIR)
The CLIR (Calling Line Identification Restriction) function prevents your telephone number being displayed on the other party’s phone during outgoing calls.
The CLIR function is disabled in the factory settings. You have the option of enabling this function permanently and then disabling it again. CLIR can also be used for individu­al connections. When CLIR is permanently enabled, this setting is saved for the extension and always enabled for outgoing connections.
If you would like to conduct only certain calls with the Call­er ID suppressed, prefix the number dialed with a keypad sequence. This enables CLIR only for the current connec­tion.
Enabling CLIR Permanently
N Pick up the handset. r51<Ext.>s1s Dial the sequence shown at left. r91ss Save your settings if desired by dial-
O Hang up the handset.
FRITZ!Box Fon WLAN 7270 83
ing the sequence shown at left.
Displaying the Caller ID for Incoming Calls (CLIP)
Disabling CLIR Permanently
N Pick up the handset. r51<Ext.>s0s Dial the sequence shown at left. r91ss Save your settings if desired by dial-
O Hang up the handset.
CLIR on a Case-by-Case Basis
N Pick up the handset. s31r Dial the sequence shown at left. Now
M Dial the number you want to call.
Displaying the Caller ID for Incoming Calls (CLIP)
The CLIP (Calling Line Identification Presentation) function makes the number of callers—external and internal—visi­ble on your telephone display.
This feature is only effective if your telephone supports CLIP.
ing the sequence shown at left.
you hear the external dial tone.
The CLIP function is enabled in the factory settings. This function can be permanently disabled and enabled again.
Enabling Display of Incoming Caller ID (CLIP)
N Pick up the handset. r50<Ext.>s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
O Hang up the handset.
FRITZ!Box Fon WLAN 7270 84
the sequence shown at left.
Connected ISDN Line Identification Restriction and Presentation (COLR/COLP)
Disabling Display of Incoming Caller ID (CLIP)
N Pick up the handset. r50<Ext.>s0s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
the sequence shown at left.
O Hang up the handset.
Connected ISDN Line Identification Restriction and Presentation (COLR/COLP)
By default, a caller’s display always shows the Multiple Subscriber Number (MSN) of the extension she or he dialed. Yet if you take the call at another extension, the MSN of this extension will be displayed (see page 90). If you want this number to remain concealed so that the call­er does not know that the call has been picked up at another extension, you have the option of suppressing transmission of the connected line’s number. The caller’s display will continue to show the number dialed.
Transmission of the connected line’s number can be switched on and off for each extension individually. Trans­mission of the connected line’s number is permanently enabled in the factory settings.
Enabling Connected Line Identification Restriction (COLR) Permanently
N Pick up the handset. r53<Ext.>s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
O Hang up the handset.
FRITZ!Box Fon WLAN 7270 85
the sequence shown at left.
Disabling Automatic Outside Dialing
Enabling Connected Line Identification Presentation (COLP) Permanently
N Pick up the handset. r53<Ext.>s0s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
O Hang up the handset.
Disabling Automatic Outside Dialing
The FRITZ!Box offers the possibility of disabling automatic outside dialing. This means that you will hear an internal dialing tone when you lift the handset at the correspon­ding extension. This makes sense at any extension which is used to make many internal calls, for instance, between the extensions of the FRITZ!Box. When automatic outside dialing is disabled, for an external call the 0 must be dialed before the telephone number.
Disabling Automatic Outside Dialing
N Pick up the handset. r1<Ext.>s0s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
O Hang up the handset.
the sequence shown at left.
the sequence shown at left.
Enabling Automatic Outside Dialing
N Pick up the handset. r1<Ext.>s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
O Hang up the handset.
FRITZ!Box Fon WLAN 7270 86
the sequence shown at left.
Call Rejection on Busy (Busy on Busy)
Call Rejection on Busy (Busy on Busy)
Calls for an extension can be rejected using the “Busy on Busy” feature. This means that the user hears a busy sig­nal whenever the extension is busy.
Enabling Busy on Busy
N Pick up the handset. r52<Ext.>s1s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
O Hang up the handset.
Disabling Busy on Busy
N Pick up the handset. r52<Ext.>s0s Dial the sequence shown at left. r91ss Save your settings if desired by dialing
O Hang up the handset.
the sequence shown at left.
the sequence shown at left.
FRITZ!Box Fon WLAN 7270 87
Operation at the Telephone

10.5 Operation at the Telephone

This section describes how you can use the FRITZ!Box fea­tures via your telephone keypad.
Shortening the Dialing Procedure
The FRITZ!Box automatically recognizes when a number has been entered, but not until a few seconds after the fi­nal digits are entered.
You have the possibility of shortening the dialing proce­dure by closing your entry with the r key.
Shortening the Dialing Procedure
<Number> r indicates that a number has been dialed
Selecting the Outgoing Number and the Type of Connection
For outgoing connections you can specify the kind of con­nection to be used for the next dialing procedure. For this entry you can use settings already made, or circumvent the settings currently configured. In this case the dialing rules are suspended for the given dialing procedure.
to shorten the dialing procedure
By entering precisely which Internet telephony account should be used it is possible to have the dialing proce­dure conducted via a certain Internet telephone number, even though this number was never previously configured for the extension used.
FRITZ!Box Fon WLAN 7270 88
Making Internal Calls
Selecting the Outgoing Number and the Type of Connection
s111r
<Phone number>
s12r
<Phone number> s12<P>r establishes an Internet telephony connec-
dials up this connection using the fixed line
dials up this connection using the first Inter­net telephone number
tion via the specified Internet telephone number. For <P> enter the position of the In­ternet telephone number in the “List of Inter­net Telephone Numbers”.
Making Internal Calls
All calls conducted between telephones connected to the FRITZ!Box, be they analog or ISDN/DECT telephones, are internal telephone calls. These calls are free of charge.
Dialing Internal Calls with Automatic Outside Dialing
N Pick up the handset. You can hear the exter-
nal dial tone immediately, since the exten­sion is set for automatic outside dialing.
ss<Ext.> If you would like to make an internal call to
one of the extensions, dial ss, followed by the number of the extension, for instance 1 or 2.
ss50 If you would like to call all ISDN terminal de-
vices for which no telephone number has be­en configured, then dial ss50.
ss<ISDN ID> If you would like to call an ISDN terminal de-
vice for which you have defined an internal telephone number, dial ss followed by the internal number of the device (for instance,
51).
ss5<MSN> If you would like to call an ISDN device that
does not have an internal number, dial ss5, followed by the MSN that was saved in the ISDN terminal device.
FRITZ!Box Fon WLAN 7270 89
Group Call
Dialing Internal Calls without Automatic Outside Dialing
N Pick up the handset. You hear the internal
dial tone.
<Ext.> Dial the desired extension number, for in-
stance 1 or 2.
50 If you would like to call all ISDN terminal de-
vices for which no telephone number has be­en configured, dial 50.
<ISDN ID> If you would like to call an ISDN terminal de-
vice for which you defined an internal num­ber, dial the internal number of the device (for instance, 51).
5<MSN> If you would like to call an ISDN terminal de-
vice that does not have an internal number, dial 5, followed by the MSN that was saved in the ISDN terminal device.
Group Call
Place a group call to call all other extensions at the same time. Your call is connected with whichever extension an­swers first.
Group Call
N Pick up the handset. ss9 Dial the keypad sequences listed here to call all
free extensions.
Picking up a Call from the Answering Machine
Use this function to pick up incoming calls on your tele­phone that already have been taken by the answering ma­chine.
Picking up a Call
N Pick up the handset. s09 Dial the sequence shown at left. P The call is now connected to your extension and
you can talk with the caller.
FRITZ!Box Fon WLAN 7270 90
Waiting Calls
Waiting Calls
When the “Call Waiting” feature is enabled and you are conducting a call, you will be notified as soon as an exter­nal call arrives on your your line. This call will be signaled by an acoustic signal in the handset. You can accept the connection with the new caller within 30 seconds. If you ignore the signal, the waiting call is rejected after 30 seconds.
For instructions on how to turn the Call Waiting function on and off, see the section “Call Waiting” on page 82.
Accepting or Rejecting Waiting Calls
R2 To accept a waiting call, dial the sequence
shown at left. Your original call is now on hold.
R1 To return to your original connection, dial the se-
quence shown at left. You can also accept the waiting call by hanging up your existing connection, i.e., by hanging up the handset. In this case the phone rings as soon as you have hung up. Pick up the handset again to accept the waiting call.
R0 To reject a waiting call, dial the sequence shown
at left.
Call Back on Busy (CCBS) on the ISDN Line
When you dial a number and it is busy, you can enable the “Call Back on Busy” feature. As soon as the line is free, your telephone rings for 20 seconds, as it would for an ex­ternal call. When you pick up your handset, the number of desired party will be dialed automatically.
“Call Back on Busy” can be used for both external and in­ternal connections.
A maximum of five call-back requests can be enabled for each extension at any given time.
FRITZ!Box Fon WLAN 7270 91
Call Back on No Response (CCNR) on the ISDN Line
Call Back on Busy (CCBS)
M You have just dialed a number and now you hear
the busy signal.
5 If the call is not answered, within twenty sec-
onds, dial either the number 5
or
Rs37r the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset. K As soon as the subscriber you dialed hangs up,
your telephone will ring.
N Pick up the handset. The subscriber’s number is
dialed again automatically.
Call Back on No Response (CCNR) on the ISDN Line
The “Call Back on No Response” function can be used when you dial a number and the party does not respond. Once the party can be reached again and conducts a call from her or his phone, this function recognizes when this conversation is ended. Your phone then rings. When you pick up your handset, the number of the desired party is automatically dialed again.
“Call Back on No Response” can be used both for external and internal connections.
FRITZ!Box Fon WLAN 7270 92
Call Back on No Response (CCNR) on the ISDN Line
This command can be activated five times for each line.
Enabling Call Back on No Response (CCNR)
M You have just dialed a number and hear a ring
tone.
5 If the call is not answered, within twenty sec-
onds, dial either the number 5
or
Rs37r the sequence shown at left. Q Wait for the acknowledgement tone. O Hang up the handset. As soon as the party you
dialed completes the conversation being con­ducted from her or his phone, your phone rings.
N Pick up the handset. The number is dialed again
automatically.
Callback requests can also be deleted manually, with the oldest callback request being deleted first.
Deleting Callback Requests Manually
N Pick up the handset. r37r Dial the sequence shown at left. O Hang up the handset.
FRITZ!Box Fon WLAN 7270 93
Alternating Between Calls
Alternating Between Calls
Whenever you have one active connection and one caller on hold, you can switch from one call to the other as often as you want using the Hold button.
Alternating Between Calls
Call 1
P R Press the Hold button. Caller 1 is now on hold. M To establish a second call, simply dial ss plus
Call 2
P R2 To switch back from Caller 2 to Caller 1, dial the
Call 1
P R2 To switch back again from Caller 2 to Caller 1,
You are talking to Caller 1.
the desired extension number for an internal call, or the desired external number.
If the call is answered, you can consult on this line. The original caller is still on hold.
sequence shown at left.
Caller 1 is now active again and Caller 2 is on hold.
dial the same sequence. In this way you can al­ternate between the two connections.
Ending Hold
O The caller on hold hangs up. You can continue
talking on the active connection.
R1 You end the active connection by dialing the se-
quence shown at left. The call that was on hold is now active again, and there is no call left on hold.
O K
Call
P
FRITZ!Box Fon WLAN 7270 94
You can also return to the call on hold by hang­ing up the handset: this ends the currently ac­tive connection. In this case the phone rings as soon as you hang up. Pick up the handset again to return to the last call that was on hold.
Three-Party Conference Call
Three-Party Conference Call
FRITZ!Box allows you to hold telephone conferences with two other people at once. Two external and one internal party, or two internal and one external party can conduct a conference call with each other.
Conducting a Three-Party Conference Call
N Pick up the handset. M Dial the external number of the first party. Talk. R Press the Hold button. M To establish a second call, simply dial ss plus
R3 Dial the sequence shown at left to begin a three-
D Now all three participants can confer together. If
O You can end the three-party call by hanging up
R2 You can also switch from the three-party call
the desired extension number for an internal call, or the desired external number.
You can now conduct a second conversation while your first call is on hold.
party conference call.
either of the other two parties hangs up, your connection with the remaining participant re­mains active.
the handset.
back to the original two-party connection. Dial the sequence shown at left. This ends the three­party conference. The connection that was active last before you initiated the three-party confer­ence is now active again. The other call is on hold. You can alternate between the two connec­tions by dialing the same sequence again.
FRITZ!Box Fon WLAN 7270 95
Consultation / Hold
Consultation / Hold
The Consultation/Hold feature allows you to place an ex­isting call on hold. You then may consult with someone else at your workplace or dial a second call. The party on hold does not hear the second conversation. Once you have finished the consultation, you can return to the origi­nal connection.
Consultation / Hold
Call 1
P R Press the Hold button. Caller 1 is now on
M To establish a second call, simply dial
Call 2
P R If the number you dialed is busy or the call
R1 To switch back to Caller 1 after talking on
You are talking to Caller 1.
hold and you can consult someone else.
ss plus the desired extension number for an internal call, or the desired external number.
If the call is answered, you can consult on this line. The original caller is still on hold.
is not answered, press the Hold button again to return to Caller 1.
the second connection, dial the sequence shown at left. Caller 1 is now active again.
If you return to Caller 1 by pressing the Hold button, the connection to Caller 2 is not cleared down until Caller 2 hangs up.
Ending Consultation
Call 1
P
O Hang up the handset to end the connection.
FRITZ!Box Fon WLAN 7270 96
You can also return to Caller 1 by hanging up the handset: this ends the connection to Caller 2. In this case, your phone rings as soon as you hang up. Pick up the handset to return to Caller 1 again.
Transferring Calls
Transferring Calls
The “Call Transfer” function allows you to transfer a con­nection from one of FRITZ!Box’s extension to another.
Transferring Calls
Call 1
P R Press the Hold button. Caller 1 is now on
ss<Ext.> To establish a connection to Caller 2, dial the
Call 2
P O To transfer the Caller 1 to Caller 2, simply
You are talking to Caller 1.
hold.
star key twice and then her or his extension number.
You can now talk with Caller 2.
hang up the handset.
Explicit Call Transfer (ECT)
Use the “Explicit Call Transfer” function to connect two
external parties with each other while one connection is active and the other is on hold. Then you can end your own connection while the other two parties continue their conversation.
Explicit Transfer of One Active and One Held Connection
N Pick up the handset. M Dial the external number of the first party. Talk. R Press the Hold button. M Dial the number for your second external call. You
can now conduct a second conversation while your first call is on hold.
FRITZ!Box Fon WLAN 7270 97
Explicit Call Transfer (ECT)
Explicit Transfer of One Active and One Held Connection
R4 Dial the sequence shown at left. The connection on
O Hang up the handset.
Explicit Call Transfer from a Three-party Conference Call
N Pick up the handset. M Dial the external number of the first party. Talk. R Press the Hold button. M Dial the number for your second external call. You
R3 Dial the sequence shown at left to begin a three-par-
D Now all three participants can confer together. If eit-
R2 You can also switch from the three-party call back to
R4 Dial the sequence shown at left. The connection on
O Hang up the handset.
To clear your connection while allowing the external parties to continue the call, connect the parties with each other.
hold and the active connection are connected with each other. The external parties continue the call while you clear the connection.
can now conduct a second conversation while your first call is on hold.
ty conference call.
her of the other two parties hangs up, your connec­tion with the remaining participant remains active.
To clear your connections while allowing the exter­nal parties to continue the call, connect the parties with each other.
the original two-party connection. Dial the sequence shown at left. This ends the three-party conference. The connection that was active last before you initi­ated the three-party conference is now active again. The second external call is on hold. You can alter­nate between the two connections by dialing the same sequence again.
hold and the active connection are connected with each other. The external parties continue the call while you clear the connection.
FRITZ!Box Fon WLAN 7270 98
One-time Explicit Transfer on the ISDN Line
One-time Explicit Transfer on the ISDN Line
Explicit Call Transfer (ECT) is an ISDN feature that must be enabled by your ISDN carrier and thus usually is subject to extra charges. If ECT has not been enabled on your line, you can program the telephone system to initiate a one­time explicit call transfer before connecting to two parties. When you end the connection, the other two parties will be connected to each other.
One-time Explicit Transfer
N Pick up the handset. s32r Dial the sequence shown at left. You hear the ex-
ternal dial tone.
M Dial the external number of the first party. Talk. R Press the Hold button. M Dial the number for your second external call.
You can now conduct a second conversation while your first call is on hold.
To clear your connections while allowing the ex­ternal parties to continue the call, connect the parties with each other.
R4 Dial the sequence shown at left. The connection
on hold and the active connection are connected with each other. The external parties continue the call while you clear the connection.
O Hang up the handset.
With this type of external transfer, both parties are con­nected to each other over your PBX. This means that both B channels on your ISDN line remain busy with this con­nection as long as the parties are connected to each other.
FRITZ!Box Fon WLAN 7270 99
Suspending/Resuming a Call on the ISDN Line
Suspending/Resuming a Call on the ISDN Line
The “Suspend/Resume” feature, also technically know as terminal portability, allows you to suspend an existing connection and resume it at another point on the S The connection can be resumed at a different ISDN termi­nal device (such as an ISDN telephone) that is connected to your BRI line along with the FRITZ!Box.
You will hear an acknowledgement tone to indicate that the call has been successfully suspended. If you hear the failure tone, this may indicate that you made a mistake, or that the “Suspend/Resume” feature is not enabled on your line. It is also possible that the parked-call ID you chose is already in use.
You can resume the suspended call using another ISDN device on the S
Suspending/Resuming a Call
P You are talking to a caller. R Press the Hold button. Caller 1 is now suspend-
s1<PC>s Dial the sequence shown at left. Type in a code
Q O
bus.
0
ed.
for the suspended call as <PC> (parked-call ID). The code can be any number between 0 and
99. You will need to enter this code again when you resume the call.
After the acknowledgement tone, the connection is suspended. You can hang up the handset. The call remains suspended at the ISDN provider’s local switch for two minutes.
bus.
0
Call Tracing on the ISDN Line
You can use this function during a call or after the caller hangs up. For more information about this feature, contact your ISDN carrier.
Call Tracing (MCID)
Rs39r Dial the sequence shown at left.
FRITZ!Box Fon WLAN 7270 100
