EasyLoader

End User Manual

Downloaded from: http://www.guardianalarms.net

Table of Contents

Table of Contents...................................................................................................................... 1

System Configuration............................................................................................................... 3

Introduction.............................................................................................................................. 4

AFETY AND MAINTENANCE INSTRUCTIONS

.................................................................... 4

LOSSARY

......................................................................................................................... 4

Basic Operations....................................................................................................................... 8

RMING YOUR SYSTEM

.................................................................................................... 8

ISARMING

....................................................................................................................... 8

MBUSH DISARMING

........................................................................................................ 8

ONE BYPASSING

.............................................................................................................. 9

OW TO BYPASS ZONES

................................................................................................... 9

RMING CHOICES

............................................................................................................. 9

AV-701T Keypad..................................................................................................................... 11

LED I

NDICATORS

............................................................................................................ 12

EYPAD DISPLAY

............................................................................................................ 12

ETTING NEW CODE FOR THE

AV-701 ........................................................................... 13

ELETE A USER CODE

.................................................................................................... 14

ETTING THE FOLLOW-ME TELEPHONE NUMBER

.......................................................... 14

OUNDER

........................................................................................................................ 14

AV-707 Keypad....................................................................................................................... 15

NTRODUCTION

............................................................................................................... 15

LCD

DISPLAY

.................................................................................................................. 16

EY ENTRIES

.................................................................................................................. 16

ETTING NEW CODE FOR THE

AV-707 ........................................................................... 16

ETTING FOLLOW-ME TELEPHONE AT

AV-707 ............................................................. 17

Displaying System Information.............................................................................................. 18

LARM MEMORY DISPLAY

............................................................................................. 18

VENTS DISPLAY

............................................................................................................ 18

ROUBLE CONDITIONS

.................................................................................................... 18

Setting System Features .........................................................................................................19

HANGING CODES

.......................................................................................................... 19

ELAYS DELETE

............................................................................................................. 19

Testing Your System............................................................................................................... 20

IREN AND BATTERY TEST

............................................................................................. 20

ETECTION DEVICES TEST

............................................................................................. 20

ESTING YOUR CENTRAL STATION

(CS) ........................................................................ 20

Troubleshooting...................................................................................................................... 21

Av-Gad Limited Warranty...................................................................................................... 23

System Configuration

Zone Index

Zone Description Type Zone Description Type

Installation Data

Installer CS Information Programmed Telephones

Phone: Phone:

Mobile: Account No.:

Installation date: Contact Person:

Zone at Home Mode Siren Times Silent Zones

Notes

--------------------------------------------------------------------------------------------------------

EASYLOADER

SERIES

ALARM CONTROL PANELS

End User Operating Manual

(for version 2.17)

Congratulations for purchasing this state-of-art computerized security panel. You

have made a wise investment in the future safety of your home or business premises

with this high-technology security system, however still EASY as 1,2,3. All of Av-Gad products conform to year 2000.

Introduction

Review this manual carefully before operating your security system. Your installer should instruct users how to operate the system, and about its various features. Complete the System Configuration page and store this manual in a safe place for future references.

Safety and Maintenance Instructions

Your security system cannot prevent burglaries, emergency case or damage to your

property. It is only intended to alert emergencies.

To keep your system efficient as intended it’s recommended to test the system daily;

upon arming and weekly testing the siren and detection devices. Read the ‘Testing

your System’ section. If your system does not function properly, contact your installer.

Keep the keypad dry; clean the keypad with dry cloth. Never disconnect the main AC

to your system.

Glossary

Your security system has been designed to offer the latest security features with simple and easy operation. Described here are some terms that are used throughout this manual to explain the common terms in this manual.

Group Bypass - (HOME mode)

‘Group Bypass’ allows bypass of zones determined by the installer to be bypassed at

once by entering a short keys combination prior to Arming.

24-hour Zone

A zone programmed for 24-hour protection. Zone is active in both Armed and Disarmed modes. When a 24-hours zone is troubled, alarm will sound in both Armed and Disarmed mode.

Battery

Standby battery located in the control box provides emergency backup power in event of power loss.

Bypass (Shunt) a zone

Allows manual removal of one or more protected zones from the system.

Day and Tamper Zone

A zone programmed as a Day or Tamper Zone enables alarm from keypad's buzzer during daytime, when system is usually disarmed. The Day or Tamper zone will trigger the keypad buzzer and the zone number will flash on keypad display. To reset Day Zone alarm, hold-down key 9 (reset key). During Armed mode, this zone will act as burglary zone and will emit an alarm when troubled.

Dialer and Communicator

Alarm reports directly to predetermined stations via telephone lines. The dialer reports an alarm to your telephone, a siren or a recorded message. To report a message, a SVM40 unit is required.

Digital Display

Keypad display. Provides alphanumerical readout of zone status and messages.

Entry Delay

The Entry Delay is the period allowed for someone to enter the premises and disarm the system.

Entry-Exit Zone

The entry-exit door or zones are designated by your installer to be used for entering and leaving the premises when the system is armed.

Exit Delay

The Exit Delay is the period allowed for users to leave the premises after arming the system.

Fire Zone

A zone programmed for connection of fire or smoke detector. Alarm heard in both Armed and Disarmed modes, and Fire LED is activated. The siren sound is different from the 24H zone or burglary alarm (it depends on the

siren type used). To reset Fire alarm, hold-down ‘9’ key and your code.

‘Follow-Me’ Programmable Telephone Number

Dialer feature. The desired Follow Me Telephone number is programmed by the user prior to arming – as necessary (to follow the user destination).

Follower Zone (also called conditioned Zone)

Follower Zone reacts instantly upon detection without previous triggering of Delayed zone. Exit delay applies to Follower zones.

Hold-down Functions Holding down keys for about 2 seconds provides additional easy-to-access functions.

Instant Arming

Instant Arming of system. Short press on key 5 instantly arms system.

Instant Zone

Zone feature. System reacts instantly upon detection at a zone, which has been

programmed as ‘Instant.’

Key-switch (optional)

Located on control panel door or remote panel. Used for arming/disarming the system.

Keypad

Your system contains one or more keypads. The keypad is used to operate the system, and to view operating information about the system. Information about the system is displayed. Commands are entered on the keypad by pressing one key at a time.

LCD

Shortening for ‘Liquid Crystal Display’. This type displays full texts, zone locations, messages, etc.

LED

Shortening for ‘Light Emitting Diode’. LED is a modern bulb. LED visually displays the

system status and confirms the functions.

Master Code

The Master Code is a 4 to 6 digit code used to arm and disarm the system, to program your codes and to bypass zones (in certain models). Normally, only one person should know the Master Code. Your default master code is 1,2,3,4.

Panic Button

Two keys (* and #) on the digital keypad, for alerting the central station in case of emergency.

Programmable Features

Computerized control panel allows system tailoring to suit individual requirements.

Smoke Detectors

Triggers alarm upon detection of smoke. Smoke detector requires reset after alarm.

Sounder

The sounder (in Keypad) simplifies alarm recognition by producing different amounts and patterns of sounds to identify various events. The sounder also functions as key-

press confirmation.

User Codes

One master and seven codes are available to allow users to arm and disarm the system and to bypass zones. Keep the code confidential to ensure maximum system security.

Zone (also called area)

An area protected by a security device. For example, a room protected by a motion detector as Zone number 1, while a door protected by a magnetic contact as Zone number 3. Your installer will inform you which zones have been set up on your system. The AV-701 contains a zone index list. The AV-707 displays the zone description.

Basic Operations

Arming Your System

Before arming your system, close all protected doors and windows, and stop movement in areas protected by motion detectors. When all protective zones are closed, the Green Status LED stops blinking.

To arm the system, enter your code. At each digit entry, the keypad sounder will beep. When the code has been entered, the Armed LED will light. If an incorrect user code is entered, the keypad will sound a single long tone. To correct the mistake, press ‘9’ and enter the code again.

When the Armed light is on, leave the premises through the designated entry-exit door before the exit delay expires. At the end of the exit delay, all lights on the keypad will be shut off, except for the Red Armed light - your system is now armed.

The factory setting for the exit delay is 30 seconds; your installer may change this time to suit your needs. Refer to the Arming Options section of this manual for information on other arming functions.

Disarming

Enter the premises through the designated entry-exit door. The keypad will sound a constant tone to indicate that the system must be disarmed. Enter your code at keypad, if an error made while entering the code, press ‘9’ and enter the code again. After six wrong entries, the keypad locks itself for 30 seconds, keys do not respond during this period. When a correct code is entered, the Armed light shuts OFF, and the sounder is silent your system is now disarmed. Enter your code before the entry delay expires (to prevent alarm). The factory setting for the entry delay is 12 seconds; your installer may change the time to suit your needs. If an alarm occurs while the system is armed, the Armed LED blinks. Refer to ‘Display Alarm Memory’ for instructions on displaying the zones in alarm.

Ambush Disarming

If you are forced by an intruder to disarm your system, the Ambush alarm can be activated. Disarming the system with the Ambush code will cause the system to disarm and simultaneously send a silent ambush alarm signal to central Station. This is an optional feature. For details ask your installer.

IMPORTANT: If you return to the premises and find that an alarm is in progress or that there are alarms in memory, do not enter the premises, as an intruder may be present. Contact the local authorities from your mobile or public phone.

Zone Bypassing

A ‘Bypassed’ zone will not cause an alarm. Zones may be bypassed to allow access to part of the protected area while other zones are armed. For example, you could bypass the zone protecting your living room. This would allow you to remain in the room, while the other zones on your system are armed.

With the system disarmed, hold-down ‘2’ key to display bypassed zones. The zone number displayed represents bypassed zones. Ensure that any zone displayed as bypassed is intentionally bypassed. Zone bypasses are automatically cancelled when the panel is disarmed.

How to Bypass Zones

To bypass a zone press ‘0’ key and the zone number (1 to 8, or 1 to 16 in AV-2016), the Shunt (Bypass) Yellow light is on in confirmation, enter your arming code, Armed Red LED goes on.

To remove a bypassed zone, arm then disarm the system, re-enter the bypassed zones.

When you arm your system, the zones you have indicated will now be bypassed. When arming the system with bypassed zones, it is always recommended to review the list of bypassed zones before entering your code to arm the system. After bypassing the desired zones, enter your code to arm the system.

Arming Choices

Home Mode

Arming with Home mode, automatically bypasses the zones programmed as Group Bypass. This feature allows you to arm the system and remain on the premises. For new systems, version 2.17 and later: To bypass 1

group press “0” and hold-down “1”, to bypass 2nd group press ”0” and hold-down “2”, to bypass both groups press “0” and hold-down “0”. At Home mode, another member would still be able to enter the premises through the entry-exit door without causing an alarm (requires special programming). When the entry-exit door is opened, to disarm the system, enter your user code.

Away Arming

Close all protected doors and windows, you can move in front of the delayed detector, enter your code, and check if the Armed LED is on. In case of arming with an open zone, a ≡ (three lines) sign will be displayed, indicating that the system is disarmed warning about a open (troubled) zone.

Instant Arming

The Instant Arming feature allows you to press ‘5’ key to arm the system. This command is designed to allow user to arm the system without needing a full user code.

Note: The instant arming is not recommended. This will allow the easy arming by someone who is not a regular user.

Auto Arming

Auto Arming provides setting of the desired system arming time when the regular user is away. This feature is useful for shop and sites requiring long exit delay. Enter to user programming mode; hold-down ‘8’ key then enter your master code, three LEDs are blinking. Hold down '8' ('A' is displayed); type hour and minutes in 24 hours format. To display, hold down '8' and wait. To disable Automatic Arming program 0000. After Automatic Arming is programmed, the system time can be set only via User Programming Mode: Enter User Programming Mode (hold-down ‘8’ and 1234), hold down '1' ('t' is displayed) and type hour and minutes. Hold down '1' and wait for the time to be displayed. Holding down '0'+'1' keys to program the time is possible only if the Automatic Arming is disabled (otherwise an 'Error’ warning is displayed). Automatic Arming will not operate if the system time has not been set (blinking 'h'). Automatic Arming will not operate if the control panel is already armed. Automatic Arming will operate even if the control panel is currently in ALARM. When the Automatic Arming programmed time arrives, the system starts at a 30-second countdown. An 'A' is intermittently displayed and beeps are sounded at the keypad. During the countdown period, the Automatic Arming can be aborted by entering a valid user code (not code No. 7, if used to ‘open’ a door).

Remote Arming

The Remote Arming allows you to use a remote key switch, or wireless tiny

transmitter to arm the system. This command is designed to arm the system without a

code, or for convenient arming from your car.

AV-701, AV-702 Keypads (LED type)

AV-702 keypad contains identical keys and LED structure.

The Status LED is on when all the zones are close.

The Red Armed LED is on when the system is armed.

The Shunt LED indicates that a zone is bypassed.

Blinking ‘h’ means that the system time is not set; hold-down ’1’ key then ’0’, three LEDs are blinking, enter time in 24 hours format.

Hold-down functions

To hold-down function accesses, hold down the key for approximately 2 seconds. Hold down function is confirmed by a prolonged beep. Refer to hold-down list:

1 - Siren Test 2 - Display Bypassed

Zones 3 - Display Troubled Zones

4 - Delay Delete 5 - Activate Chime 6 - Tel. Programming 7 - Zone Test 8 - Code Programming

9 - Delete Last key Press 0 – Display Alarm History * and # - Panic

Shunt

and

Siren

Display and Setting of System Time: Hold down ‘0’ key

and then hold-down ‘1’, three LEDs are blinking, wait for the time to be displayed in 4-digit format. To set new time, hold down key ‘0’ and then hold down ‘1’. Do not wait for time display; enter the new time in 24-hour format. The local clock time is not stored in the system memory; clock must be adjusted after power-up. After powering-up the system, time is reset to 00:00, ‘h’ will be displayed to remind user to set time; ‘h’ will disappear after the new time is set.

Shunt

and

Shunt Display

Display and Setting of System Date: Hold down ‘0’ key

and then hold-down ‘2’; 3 LEDs will blink. Enter date: ‘dd mm yy.’ The up and download PC software displays time and date, along with history event.

Siren

Shunt Display

Status

Delay Delete

Chime

Test

Program

Reset

Shunt

Telephone

ARMED STATUS SHUNT FIRE

ZONE DISPLAY

EASYLOADER AV-701

AV-GAD

Panic Button

Years 1978 through 99 as 78 to 99 Years 2000 through 2077 00 to 77

The local date is stored in system memory; adjust date after long power-failure.

LED Indicators

Four LEDs provide visual indication of System status, as well as confirmation of

various modes.

! Red ARMED/ALARM Indicator - Lights up when system is armed, and blinks

after an alarm is triggered at any zone. Blinking indicates alarm history in memory.

! Green STATUS Indicator - Blinks when zone/s is/are troubled, remains lit as

long as zones are not troubled, rapid blinking indicates Tamper alarm.

! Yellow SHUNT (Bypass) Indicator - Lights up upon zone bypass.

(Note: May light automatically upon arming if Auto Bypass was programmed).

The indicator also lights and blinks upon Group Bypass entry (by pressing ‘0’ twice).

! Red FIRE (Trouble) Indicator - Rapid blinking when a Fire Zone is troubled. !! Two LEDs Flashing (Left Most LEDs) - In user code programming mode,

rapid blinking indicates code or code index to be entered.

In Disarmed mode, the two left-most LEDs are blinking to indicate 24H-alarm mode.

Zone number will also be displayed.

!!! Three LEDs Flashing - In Disarmed mode, rapid blinking indicates AC

power failure. AC power failure event is displayed in Events History as three lines ≡.

In Armed mode, rapid blinking indicates system restored after AC Power Failure

mode.

During programming the Follow-Me Telephone Number, three flashing LEDs

indicate that system is expecting a new telephone number.

!!!! Four LEDs Flashing - Upon holding-down key ‘8,’ the system is ready for

code to be entered.

System with bypass via code: Same LED indication when code is expected for Bypass

via code.)

Keypad display

The 7-segment display provides visual readout of system status. The display indicates

zones in alarm, troubled zones, bypassed zones and also displays the following

confirmation letters:

Display Description Function

A Up & Download Modem ‘Answer Now’ function selected. Confirms hold-

down ‘6’ key then hold-down ‘1’ key.

‘A’ also displayed upon Auto-Arming programming

C Communication Displayed at dialer tests, and upon holding-down ‘6’ key C Communication C flashing in display indicates telephone line trouble

c Chime Confirms Chime mode via ‘5’ key c Closing When events log is displayed Indicates Arming followed by

user number

d Delay Delete Confirms Delay Delete Upon holding-down ‘4’ key

P Dial Delay When programming telephone number that requires an inter-

digit delay (‘Pause‘) during dialing. (Delay duration is 2

seconds.)

E Error Indicates programming and operation error

h Home Indicates entering of Home Mode (Group Bypass) h Hour Displayed after power-up to remind user to set the system

time: ‘h’ will be removed after time setting (using keys 0

and 1).

H Hold-Up Upon Panic triggering from Keypad

o Opening Indicates system opening (Disarming). Followed by user

number when events log is displayed

L Low Battery Indicates Low Battery – Call your installer

P Program System is in programming mode

t Tamper Indicates zone's Tamper alarm

U Update Confirms programming updating

u User ‘u’ (user) followed by user number when events log is

displayed and system is in user code programming mode

≡

(Three lines)

Arming Denied or AC Failure event

≡ Displayed upon Arming attempt with non-delayed

(instant) zones in trouble.

≡ Displayed after AC failure, in history display at the AV-

701 keypad, indicating the power-fail event

Setting New Code for the AV-701

1. Hold down key

Program

2. While four LEDs are blinking, enter the master code (default 1234)

3. If code is valid, four LEDs will stop blinking, and ‘u’ will be displayed

4. The two Left-Most LEDs blink to indicate that the system is waiting for a new user

code index (user 1 to 8) to be entered

5. Enter the code index (1 for code No. 1; 2 for code No. 2, etc.). User index will be

displayed for 2 seconds, until further digits are entered (eliminate confusing of

index number and code)

6. The two right-most LEDs blink to indicate that the system is waiting for a new

code (1 to 6 digits) to be entered. If user code is not entered, the code is voided

7. Enter the new code; ‘U’ is displayed for confirmation

8. To quit code setting, hold-down ‘9’

Delete a User Code

1. Hold down key

Program

2. While four LEDs are blinking, enter code No. 1 (default 1234)

3. If code is valid, four LEDs will stop blinking, and ‘u’ will be displayed

4. The two left-most LEDs blink to indicate that the system is waiting for a new user

code-index (user 1 to 8) to be entered

5. Enter the code index you want to delete (1 for code No. 1; 2 for code No. 2, etc.)

6. The two right-most LEDs blink to indicate that the system is waiting for a new

code

7. Hold-down ‘9’ key to quit code setting

If user code is not entered, the code is voided. A short beep confirms that the code has been deleted.

Setting the Follow-Me Telephone Number

The ‘Follow-Me’ feature is applicable only with the dialer; in alarm, Follow-Me

number is dialed first if the communicator (communicator dials to central station) is

not selected.

1. Hold down ‘6’ key twice; wait for the blinking of the three LEDs

2. Enter Telephone Number (maximum 16 digits and 4 pauses), and wait until all

LEDs stop blinking. The ‘Follow-Me’ number is now programmed

3. To delete ‘Follow-Me’ number, access ‘Follow-Me’ programming mode as

described in paragraph 1, just do not enter any number

Sounder

The Keypad sounder enhances the use of system operation and serves as a local alarm

device (requires programming).

In AV-707 (LCD keypad) the user is able to switch the buzzer on and off at each

keypad.

The sounder emits sounds in the following instances:

OPERATION SOUNDER RESPONSE

"Pressing of any key Short confirmation beep

"Hold-down functions Long confirmation beep

"Faulty programming input Long beep (+ ‘E’ display)

"Delayed Zone triggering 3 long beeps

"Exit delay starting (if programmed) Warning beeps until the delay is over

"Completion of Arm/Disarm programming

code

One long confirmation beep

"Programming Telephone numbers Two confirmation beeps

"Completion of address programming Two confirmation beeps

"Pressing ‘Code 7’ for driving door opening Seven confirmation beeps

" System Arming with Instant or 24H

troubled zone

Five warning beeps + troubled zone

" Feature programming Two confirmation beeps

" Follow-Me number programming Two confirmation beeps

"During alarm (requires programming) Intermittent beep until alarm reset

AV-707, AV-706, AV-705 Keypads

(LCD type for PRO panels)

Introduction

The AV-707 EasyKey™ is the future-generation keypad, with the New Look shape,

fully-customized microprocessor based remote station, multitasking functions with 32

Keypad ID’s, comply with year 2000 requirements. AV-706 provides similar

functions. For more details, refer to the AV-707/706 manual. The AV-705 is an

economical keypad, its shape similar to the AV-707 and supplied without the LCD

display.

The AV-707, 706 and 705 fits only PRO type control panels.

After power failure, ‘Set Panel Time’ is displayed. To set time hold-down ‘0’ key

then Hold-down ‘1’, enter time in 24H format and press #. To set the date, hold-down

‘0’ key then hold-down ‘2’, enter date in dd-mm-yy format and #.

The AV-707 keys and Hold-Down functions are identical to the AV-701 functions,

you can speed up the function by pressing ‘#’ key – the ENTER key.

The sounder and LEDs functions and indications are the same as described for the

AV-701.

The

is mostly used as an ENTER key, typed at the end of a command

LCD display

The LCD display helps understanding the system status and zone locations by reading

in plain text the system messages, zone description, time and other indications.

The first row displays system announcements, like: System Disarmed, Alarm, Low

Battery, etc., second row displays the zones

status.

Each ‘’ sign represents a zone. If a zone is

open, the zone’s number like 123567 will

replace the .

If a zone is bypassed a '*' appears instead. The

control panel time is displayed in the five

rightmost positions.

The LCD displays often the installer LOGO (the

logo is editable). For displaying zone description

hold-down ‘3’ key twice.

To save power, the LCD and keys backlight turns

OFF after 60 seconds of no typing activity (it

turns ON again when an alarm occurs).

Most of the accessible functions with the LCD Keypad are similar to those of the

AV-701 (seven segments keypad).

Key Entries

Keys typed at the keypad are concealed (as they are part of the User Code). '* * * *'

are displayed.

In Armed and Disarmed mode, after six attempts to enter fault code, the keys will not

respond for 30 seconds, in order to prevent code break exigency.

During all kinds of programming, keys are displayed as they are typed (some

combinations are exceptional).

Setting New Code for the AV-707

To enter User Programming mode ‘Hold Down’ the '8' (program) key.

armed

status shunt

fire

A V-7 0 7

Open Zone

Close Zone

Bypassed Zone

1 2 : 0 0

Time

System Message

The three Rightmost LEDs start blinking; enter the Master User Code (factory default

1 2 3 4) followed by # (Enter). The upper line displays 'User Programming', the lower

line is cleared and a blinking cursor appears.

The Leftmost two LEDs will start blinking indicating that a ‘location’ is expected. In

this case, location means ‘User Code’ index to be modified, erased or programmed.

User Index means User Number 1-8, as system contain eight different user codes.

Enter a two digits number from 01 to 08 (2 digits required). After the index had been

entered (the ‘location’), the upper line is

cleared, the blinking cursor moves to the

beginning of the line, three Rightmost LEDs

start blinking indicating that data is expected

(in this case the new User Code).

Enter a one to six digits code. Key '*'

corrects the input press, as backspace or

Hold Down key '9' (reset) to cancel the

input.

Press '#' key for confirm.

The control panel will verify that the new

code is not in use by other user (if that

happens you'll be notified) and respond by

displaying the code. At any time after the

control panel response, you can start typing a

new index (there is no need to wait for the

announcement to disappear).

To erase an existing code: Enter user index

number (01, 02, 03....), hold down

simultaneously keys '*' and ' #', followed by

#, E (erased) will be displayed.

The Master (code number 01) cannot be erased. Type ‘99’ followed by # to exit.

Setting Follow-Me Telephone at AV-707

To display the Follow-Me telephone number; hold down '6' (type '#' for faster display)

and the control panel will display the number (or the 'empty' announcement if there is

no telephone number currently programmed).

To program the Follow Me telephone number Hold Down twice the '6' key. The three

Rightmost LEDs blink, indicating that the keypad waits for input.

On the upper display line, a blinking cursor will appear, type the number (digits from

0 to 9), hold down * for '*' digit, hold down '0' key for Pause (a ‘P’ will be displayed)

or press simultaneously '*' & '#' to erase the phone number (a 'E' will be displayed).

To correct the input you can use the '*' as a backspace erasing key.

Siren

Shunt Display Status

Delay Delete

Chime

Test Program Reset

Shunt

Telephne

ARMED STATUS

SHUNT FIRE

SYSTEM DISARMED 1 2 3 4 5 6 6 7 *

12:00

Displaying System Information

Alarm Memory Display

Alarms generated when the system is armed are recorded in the system's memory. Hold-down twice ‘0’ to display the zones in alarm.

Shunt

Concise Alarm History (Events Log): Hold-down ‘0’ to display the last

alarm sequence. New alarm will erase the old events.

Shunt

and

Shunt

Detailed Events History (requires programming): Hold

down ‘0’ and again hold-down ‘0’ to display up to 99 events, like: System opening

and closing by user number, opening or closing time, zone-caused alarm and AC

failure. Your PRO panel stores up to 250 events displayed by the EasyLoad program,

the keypad display 99 events only.

By holding-down key

Shunt

twice, three LEDs start blinking, indicating a special

operation mode. The events are displayed from the most recent events to the oldest

ones.

Shunt

and

Chime

Display Last 2 Users: Hold down ‘0’ and then hold down

‘5’ to display user number and System opening or closing time.

‘o’ is displayed for Opening (Disarming); ‘c’ is displayed for Closing (Arming).

Events Display

Events are displayed as following:

XX - Event number (from 01 to 99), then HH_MM (Hour and Minutes) Event Time,

Event (alarm or opening/closing).

Translate the display as following:

‘u’ (user number 1 to 8),

‘o’ or ‘c’ - opening or closing

Zone causing alarm will blink twice

tX - Tamper alarm from zone causing the alarm (X)

H - Panic Alarm

Note: three lines (≡) indicate power failure. An AC failure event will be displayed

during history events. For detailed log events ask your installer to download the log events via EasyLoad software.

Trouble Conditions

The system constantly monitors itself to ensure proper operation. When a trouble condition occurs, the system condition will be displayed.

Indication

Cause

To do

‘L’ or Low Battery on Battery is low Call for service Four LEDs are blinking AC power failure Check the premises fuse

box. Call for service ‘C’ or ‘Tel. Line Fail’ Telephone line test failed Call for service Arming fail and ≡ is displayed

Zone is troubled Bypass the zone and call

for service

Setting System Features

Changing Codes

The system features eight programmable codes. The first code is the Master Code, and the remaining seven codes are normal arming and disarming codes. Do not use ‘0’ as the first digit in a code.

Do not use ‘5’ as first digit in a code number if Instant Arming via key 5 was

programmed. User code shall not start with the same numbers as the installer programming code (1994). Do not use same codes or same first digit for different codes. For example if code No. one is 1234, programming code No. 2 cannot be 1256.

Key Visual Feedback - Visual ‘feedback’ from the keypad display upon entering of

code. This feature indicates the code entry progress and is most practical when the

keypad buzzer is disabled at Home (Group Bypass) mode, or if selected by

programming. Entry of code by user or installer is confirmed at keypad display.

Display segments will light up clockwise, indicating the sequence of the entered

digits.

Note: After six unsuccessful attempts to enter an invalid code the keypad is locked.

Delays Delete

Delay Delete

Key 4 # DELAY DELETE (INSTANT PROTECTION)

Cancels the Entry Delay in zones selected as ‘Delayed’ zones. All zones become

Instant. This feature is optional when Home Mode set and all users are in. Hold-down

‘4’ key, ‘d’ is displayed in confirmation. Instant Protection becomes effective only if

System is armed within 20 seconds following hold-down of ‘4’ key.

Chime

Key 5 # DOOR CHIME

The Door Chime causes the keypad to beep whenever a zone is activated. Door

Chime operates on Chime-programmed zones.

Hold-down key 5 enables and disables the function.

Chime mode is confirmed by ‘c’ displayed on keypad.

Shunt

and

# LOCAL BUZZER ON and OFF

Holding down keys "0" and "#" simultaneously turn on and off the buzzer in each

LCD keypad. This function works in disarmed mode.

Testing Your System

It is recommended to test your system weekly. Perform system tests in the offpeak hours, such as early morning or late evening. Call to inform your monitoring station that you are testing your system.

Siren and Battery Test

Hold-down ‘1’ key, this command will generate a siren sound for few seconds. Turn off your main AC, verify that LEDs are blinking to indicate power failure; test siren again to make sure your battery can drive the siren during power failure. Arm and Disarm the system (main AC is still off) few times, if ‘L’ is displayed, your battery is faulty, call your installer.

Detection Devices Test

Test

Key 7 # FAULT FIND

•

Fault Find enables testing of all detection devices.

•

Fault Find mode can be entered only during the 15 seconds following system

Disarming.

•

Fire, 24H, or Panic alarm will stop Fault Find mode.

•

Hold down ‘7’ key, confirmed by ‘F’ on Keypad display.

•

Activate each sensor. Detection of zone opening is confirmed by a one-second beep.

Three beeps indicate zone closing.

•

Arm the system to quit Fault Find mode.

Testing your Central Station (CS)

Inform your CS that you perform testing, ask them to report you if an alarm is received. Arm the system, move in front of a detector or open a protected door, verify that the siren is activated; to quit testing, disarm the system.

Call your installer if any test fails to operate

Troubleshooting

PROBLEM INDICATION REMEDY

System fails to Arm

when code is entered

at Keypad

Keypad entries are

confirmed by beeps,

but system does not

react

1. Hold down ‘9’ key until you hear a beep,

then enter arming code

2. Program new arming code

3. If you forgot your Arming code, call your

installer

System cannot be

disarmed

Arming/Disarming

code is entered but

Red indicator

remains lit

1. Hold down ‘9’ key until you hear the

confirmation beep. Enter arming code

carefully. Do not be confused by Siren

noise.

2. System was armed using the Instant

Arming key (key 5), but code was changed.

(You can ask your installer to cancel this

feature.)

Yellow indicator is

on (indication that

zones have been

bypassed)

Yellow (shunt)

indicator constantly

Arm and disarm the system; the indicator

light should turn off

Green indicator

blinks continuously

when you attempt to

arm the system

≡ Sign is displayed,

and arming denied

(system can not be

Armed with an open

instant or 24H zone)

Hold down ‘3’ key; the zone/s in trouble

will be displayed. Check the cause: an open

window; movement detected by detector or

else.

1. Press ‘0’ key (Bypass), and then the zone

number where alarm was triggered.

The yellow indicator should light in

confirmation.

2. A delayed zone may be troubled. An open

delayed zone will cause the green indicator

to blink upon exit/entry

Three LEDs

indicators are

blinking, indicating

Power Failure

The system is not

responding; keys do

not respond

You may have a general power failure.

Check your premises fuse box

WARNING! If Green indicator is still OFF,

your system is operating on temporary

power supplied by the Battery

PROBLEM INDICATION REMEDY

Buzzer is activated

for no apparent

reason

Door at delayed zone

(entrance) is open or

there has been detec-

tion of movement at

an exit/entry zone.

Day or Tamper zone

was activated

Keys ‘5’ or ‘7’ have been pressed, activating

the door Chime or the Fault Find function.

Arm and disarm the system.

Hold-down ‘9’ key to reset Day Zone or

Tamper alarm

Entry at protected

zone activates mini-

sounder at keypad

A warning signal is

heard before the

siren is triggered

Disarm system immediately upon entry at

zone. If delay time is too short, call your

installer to reprogram delay time

‘L’ is displayed Battery is low,

faulty, or dead

Call your installer immediately

‘C’ is displayed

(blinking)

Telephone line

disconnected or dead

or the systems failed

to contact central

station

Call your installer immediately. Check your

telephone line

Siren was triggered,

but programmed

phone numbers were

not dialed

1. Faulty dialer

2. Faulty phone line

or phone off the

hook

3. Mistaken report of

alarm

1. Hold down ‘6’ key (dialer test);

automatically dialed numbers will be

displayed (test takes several minutes).

2. If the telephone line to the alarm control

has been disconnected, reconnect it.

3. Malfunction of the alarm system - call

your installer

‘H’ is displayed.

‘h’ is blinking.

A panic alarm was

activated. Take

emergency

measures. Blinking

‘h’; set the time

Arm and disarm system to abort alarm and

H display.

Set system time by holding-down ‘0’ key

then ‘1’ key

Yellow indicator

lights upon arming

of system, without

bypassing (pressing

0 and any key)

‘Automatic Bypass’

has been

programmed. Can

also occur if ‘0’ key

is pressed twice

before arming,

which activates zone

bypass

Before arming, make sure all entry/exit

doors protected by system are closed and all

detectors are off. Arm the system, and call

your installer

AV-GAD LIMITED WARRANTY

v-Gad Systems Ltd. (Av-Gad) warrants it’s products to be free from

production defects in components, materials used and labor, for the period of twelve months following the date of production. Av-Gad will within the mentioned period, as its option, repair or replace any product failing to proper operation without charge the purchaser.

This warranty shall not apply to any equipment, or any part thereof, which

has been repaired by others, installed not properly, used improperly, abused, altered damaged, subjected to acts of God or on which the serial and data code altered or removed.

Av-Gad will not be responsible for any dismantling or reinstallation expenses. In order to exercise the warranty, the product must be returned by the purchaser, delivery and transportation costs prepaid and insured to Av-Gad.

After repair or replacement, Av-Gad assumes the cost of returning products under warranty.

There are no warranties, express or implied, which extend beyond the description of the face hereof.

There is no express or implied warranty of merchantability or a warranty of fitness for particular purpose. Additionally, this warranty is in lieu of all other obligations or liabilities on the part of Av-Gad.

Any action for breach of warranty, including but not limited to any implied warranty of merchantability, must be brought within three months following the end of the warranty period. In no case shall Av-Gad be liable to anyone for any consequential or incidental damages for breach of this or any other warranty, express or implied, even if the loss or damage is caused by the seller’s own negligence or fault.

Av-Gad is not an insurer of either the property or safety of the user’s employees, family, or 3rd part and limits its liability for any loss or damage including incidental or consequential damages to Av-Gad original selling price of the

product regardless of the cause of such loss or damage.

Av-Gad recommends testing the entire system weekly. Refer to Testing Your System section for further details.

AV-GAD EasyLoader AV-701, EasyLoader AV-702, EasyLoader AV-707, EasyLoader AV-706, EasyLoader AV-705 End User Operating Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
