Avaya Managing Routers Web Server User Manual

Managing Routers Using the Web Server

BayRS Version 13.20 Site Manager Software Version 7.20
BCC Version 4.20
Part No. 300019-C Rev 00 April 1999
Bay Networks, Inc.
4401 Great America Parkway
Santa Clara, CA 95054
Copyright © 1999 Bay Networks, Inc.
All rights reserved. Printed in the USA. April 1999. The information in this document is subject to change without notice. The statements, configurations, technical data,
and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty. Users must tak e full re spo nsibility fo r th eir a pplic atio ns o f a ny products specifi ed in th is d ocume nt . The information in this document is proprietary to Bay Networks, Inc.
The software described in this document is furnished under a license agreement and may only be used in accordance with the terms of that license. A summary of the Software License is included in this document.
Trademarks
AN, BCN, BLN, BN, and Bay Networks are registered trademarks and BayRS and BCC, are trademarks of Bay Networks, Inc.
Internet Explorer, Microsoft, MS, MS-DOS, Win32, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Netscape is a registered trademark of Netscape Communications Corporation in the united States and o ther countries. All other trademarks and registered trademarks are t he property of their respective owners.
Restricted Rights Legend
Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer So ftware clause at DFARS 252.227-7013.
Notwithstanding any other license agreement that may pertain to, or accompany the delivery of, this computer software, the rights of the United States Government regarding its use, reproduction, and disclosure are as set forth in the Commercial Computer Software-Restricted Rights cl ause at FAR 52.227-19.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, Bay Networks, Inc. reserves the right to make changes to the pr oducts described in this document without notice.
Bay Networks, Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
Portions of the code in this software product may be Copyright © 1988, Regents of the University of California. All rights reserved. Redistribution and use in source and binary forms of such portions are permitted, provided that the above copyright notice and this paragraph are duplicated in all such forms and that any documentation, advertising materials, and other materials related to such distribution and use acknowledge that su ch portions of the software were developed by the University of California, Berkeley. The name of the University may not be used to endorse or promote products derived from such portions of the software without specific prior written permission.
SUCH PORTIONS OF THE SOFTWARE ARE PROVIDED “AS IS” AND WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
In addition, the program and information contained herein are licensed only pursuant to a license agreement that contains restrictions on use and disclosure (that may incorporate by reference certain limitations and notices imposed by third parties).
ii
300019-C Rev 00
Bay Networks, Inc. Software License Agreement
NOTICE: Please carefully read this license agre ement before copying or using the accompanying software or installing the hardware unit with pre-enabled software (each of which is referred to as “Software” in this Agreement). BY COPYING OR USING THE SOFTWARE, YOU ACCEPT ALL OF THE TERMS AND CONDITIONS OF THIS LICENSE AGREEMENT. THE TERMS EXPRESSED IN THIS AGREEMENT ARE THE ONLY TERMS UNDER WHICH BAY NETWORKS WILL PERMIT YOU TO USE THE SOFTWARE. If you do not accept these terms and conditions, return the product, unused and in the original shipping container, within 30 days of purchase to obtain a credit for the full purchase price.
1. License Grant. Bay Networks, Inc. (“Bay Networks”) grants the end user of the Software (“Licensee”) a personal, nonexclusive, nontransferable license: a) to use the Software either on a single computer or, if applicable, on a single authorized device identified by host ID, for which it was originally acquired; b) to copy the Software solely for backup purposes in support of authorized use of the Software; and c) to use and copy the associated user manual solely i n support of authorized use of the Software by Licensee. This license applies to the Software only and does not extend to Bay Networks Agent software or other Bay Networks software products. Bay Networks Agent software or other Bay Networks software products are licensed for use under the terms of the applicable Bay Networks, Inc. Software License Agreement that accomp anies such software and upon payment by the end user of the applicable license fees for such software.
2. Restrictions on use; reservation of rights. The Software and user manuals are protected under copyright laws. Bay Networks and/or it s licensors retain all title and ownership in both the Software and user manuals, including any revisions made by Bay Networks or its licensors. The copyright notice must be reproduced and included with any copy of any portion of the Software or user manuals. Licensee may not modify, translate, decompile, disassemble, use for any competitiv e analysis, re v erse engineer , distrib ute, or create deriv ati ve works from the Softwa re or user manuals or any copy, in whole or in part. Except as expressly provided in this Agreement, Licensee may not copy or transfer the Software or user manuals, in whole or in part. The Soft ware and user manuals embody Bay Networks’ and its licensors’ confidential and proprietary intellectual property. Licensee shall not sublicense, assign, or otherwise disclose to any third party the Software, or any information about the operation, design, performance, or implementation of the Software and user manuals that is confidential to Bay Networks and its licensors; however, Licensee may grant permission to its consultants, subcontractors, a nd agents to use the Softw are at Licensee’s facility, provided they have agreed to use the Software only in accordance with the terms of this license.
3. Limited warranty. Bay Netw o r ks wa r ra nts ea c h item of So ft ware, as deliv e re d b y Ba y Net w o r k s an d pro pe r ly installed and operated on Bay Networks hardware or other equipment it is originally licensed for, to function substantially as described in its accompanying user m anual during its warranty period , which begins on the date Software is first shipped to Licensee. If an y item of S oftware f ails to so function d uring its w arranty period, as the sole remedy Bay Networks will at its discretion provide a suitable fix, patch, or workaround for the problem that may be included in a future Software release. Bay Network s fur ther w arra nts to Licen see that the medi a on which the Software is provided will be free from defec ts in materials and wo rkman ship under no rmal use for a peri od of 90 da ys from the date Software is first shipped to Licensee. Bay Networks will replace defective media at no charge if it is returned to Bay Netw orks during the warran ty perio d alon g with proof of the date of shipment . This war ranty do es not apply if the media has been dam aged as a resul t of acci dent, misuse , or ab use. The Licen see assumes all re sponsibilit y for selection of the Software to achieve Licensee’s intended results and for the installation, use, and results obtained from the Software. Bay Networks does not warrant a) that the functions contained in the software will meet the Licensee’ s requireme nts, b) that the Software will operate in the hardw are or soft wa re c ombi nations th a t the L icensee may select, c) that the operation of the Softw a re will be uninterru pte d or error free, or d) that all defec ts in the operation of the Software will be corrected. Bay Networks is not obligated to remedy any Software defect that cannot be reproduced with the latest Software release. These warranties do not apply to the So ftw are if i t has been (i) altered, except by Bay Networks or in accordance with its instructions; (ii) used in conjunction with another vendor’s product, resulting in the defect; or (iii) damaged by improper environment, abuse, misuse, accident, or negligence. THE FOREGOING WARRANTIES AND LIMITATIONS ARE EXCLUSIVE REMEDIES AND ARE IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING W ITHOUT LIMITATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Licensee is responsible for the security of
300019-C Rev 00 iii
its own data and information and for maintaining adequate procedures apart from the Software to reconstruct lost or altered files, data, or programs.
4. Limitation of liability. IN NO EVENT WILL BAY NETWORKS OR ITS LICENSORS BE LIABLE FOR ANY COST OF SUBSTITUTE PROCUREMENT; SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES; OR ANY DAMAGES RESULTING FROM INACCURATE OR LOST DATA OR LOSS OF USE OR PROFITS ARISING OUT OF OR IN CONNECTION WITH THE PERFORMANCE OF THE SOFTWARE, EVEN IF BAY NETWORKS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL THE LIABILITY OF BAY NETWORKS RELATING TO THE SOFTWARE OR THIS AGREEMENT EXCEED THE PRICE PAID TO BAY NETWORKS FOR THE SOFTWARE LICENSE.
5. Government Licensees. This provision applies to a ll Softwa re and docum entation acquired d irectly or i ndirectly by or on behalf of the United States Government. The Software and documentation are commercial products, licensed on the open market at market prices, and were developed entirely at private expense and without th e use of any U.S. Government funds. The license to the U.S. Government is granted only with restricted rights, and use, duplication, or disclosure by the U.S. Government is subject to the restrictions set forth in subparagraph (c)(1) of the Commercial Computer Software––Restricte d Rig hts cla u se o f FAR 52.227-19 and the limitatio ns set o ut in this license for civilian agencies, and subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause of DFARS
252.227-7013, for agencies of t he Department of Defense or their successors, whichever is applicable.
6. Use of Software in the European Community. This provision applies to all Software acquired for use within the European Community. If Licensee uses the Software within a country in the European Community, the Software Directive enacted by the Council of European Communities Directive dated 14 May, 1991, will apply to the examination of the Software to facilitate interoperability. Licensee agrees to notify Bay Networks of any such intended examination of the Software and may procure support and assistance from Bay Networks.
7. Term and termination. This license is effective until terminated; however, all of the restrictions with re spect to Bay Networks’ copyright in the Software and user manuals will cease being effective at the date of expiration of the Bay Networks copyright; those restrictions relating to use and disclosure of Bay Networks’ confidential information shall continue in effect. Licensee may terminate this license at any time. The license will automatically terminate if Licensee fails to comply with any of the terms and conditions of the license. Upon termination for any reason, Licensee will immediately destroy or return to Bay Networks the Software, user manuals, and all copies. Bay Networks is not liable to Licensee for damages in any form solely by reason of the termination of this license.
8. Export and Re-export. Licensee agrees not to export, directly or indirectly, the Software or related technical data or information without first obtaining any required export licenses or other governmental approvals. Without limiting the foregoing, Licensee, on behalf of itself and its subsidiaries and affiliates, agrees that it will not, without first obtaining all export licenses and approvals required by the U.S. Government: (i) export, re-export, transfer, or divert any such Software or technical data, or any direct product thereof, to any country to which such exports or re-exports are restricte d or em b argoed under United States expor t con t ro l la w s an d r egulations, or to an y national or resident of such restricted or embargoed countries; or (ii) provide the Software or related technical data or information to any military end user or for any military end use, including the design, development, or production of any chemical, nuclear, or biological weapons.
9. General. If any provision of this Agreement is held to be invalid or unenf orceable by a court of competent jurisdiction, the remainder of the provisions of this Agreement shall remain in full force and effect. This Agreement will be governed by the laws of the state of California.
Should you have any questions concerning this Agreement, contact Bay Networks, Inc., 4401 Great America Parkway, P.O. Box 58185, Santa Clara, California 95054- 8185.
LICENSEE ACKNOWLEDGES THAT LICENSEE HAS READ THIS AGREEMENT, UNDERSTANDS IT, AND AGREES TO BE BOUND BY ITS TERMS AND CONDITIONS. LICENSEE FURTHER AGREES THAT THIS AGREEMENT IS THE ENTIRE AND EXCLUSIVE AGREEMENT BETWEEN BAY NETWORKS AND LICENSEE, WHICH SUPERSEDES ALL PRIOR ORAL AND WRITTEN AGREEMENTS AND COMMUNICATIONS BETWEEN THE PARTIES PERTAINING TO THE SUBJECT MATTER OF THIS AGREEMENT. NO DIFFERENT OR ADDITIONAL TERMS WILL BE ENFORCEABLE AGAINST BAY NETWORKS UNLESS BAY NETWORKS GIVES ITS EXPRESS WRITTEN CONSENT, INCLUDING AN EXPRESS WAIVER OF THE TERMS OF THIS AGREEMENT.
iv 300019-C Rev 00

Contents

Preface
Before You Begin .............................................................................................................xiii
Text Conventions .............................................................................................................xiv
Acronyms ........................... .......................... .......................... ......................... ................. xv
Bay Networks Technical Publications ..............................................................................xvi
How to Get Help ..............................................................................................................xvi
Chapter 1 Starting and Configuring the HTTP Server
Browser Requirements ...................................................................................................1-1
Starting the HTTP Server Using install.bat .....................................................................1-2
Starting the HTTP Server Using the BCC or Site Manager ............................................1-3
Setting HTTP Server Security ........................................................................................1-4
User Name/Password Security Concepts ................................................................1-5
Basic Access Authentication ................. ...... ....... ...................................... ....... ...... ...1-8
Digest Authentication ...............................................................................................1-9
Filtering Network Address es .... ....... ...... ....................................... ...... ....... ...... ....... ...... ...1-9
Using a Domain Name Instead of an IP Address ...........................................................1-9
Relocating HTTP Server Help Information ...................................................................1-10
Customizing HTTP Parameters ....................................................................................1-10
Chapter 2 HTTP Server Concepts
What the HTTP Server Does ..........................................................................................2-1
Navigating the HTTP Server Interface ............................................................................2-3
Data Display Formats .....................................................................................................2-4
Enabling and Disabling Connections ..............................................................................2-4
What the Administration Functions Do ...........................................................................2-4
300019-C Rev 00
v
Chapter 3 Monitoring Routers Using the HTTP Server
Getting Help ....................................................................................................................3-1
Specifying a Router to Monitor .......................................................................................3-2
Viewing Overall System Status .......................................................................................3-2
Chapter 4 Troubleshooting Router Operation
Trouble Shooting Icon .....................................................................................................4-1
Displaying Circuit Alerts ..................................................................................................4-2
Viewing the Event Log .................... ...... ....... ...... ....... ...... ....................................... ...... ...4-2
Filtering What the Event Log Shows ........................................................................4-3
Interpreting Event Messages ...................................................................................4-3
Saving and Clearing the Event Log ..........................................................................4-4
Saving the Event Log ................................... ...... ....... ...... ...... ....... ......................4-4
Clearing the Event Log ......................................................................................4-5
Getting Help on the Event Log Window ...................................................................4-5
Pinging Devices ..............................................................................................................4-5
Ping IP ............................... ....... ...... ....... ...... ....... ...... ....... ...... ...... .............................4-6
Ping IPX ............................ ....... ...... ....... ...... ....... ...... ....................................... ...... ...4-6
Ping AppleTalk ............................... ....... ...... ....... ...... ....... ...... ...................................4-7
Chapter 5 Viewing Router Services Statistics
Router Services Statistics ..............................................................................................5-1
Using the HTTP Server to View HTTP Statistics ............................................................5-3
HTTP Configuration Statistics ..................................................................................5-3
HTTP Counters ........................................................................................................5-3
HTTP Request Statistics ..........................................................................................5-4
HTTP Response Statistics .......................................................................................5-4
Using the Statistics Manager to View HTTP Server Statistics ........................................5-5
Selecting the Windows to Display ............................................................................5-5
Starting the Statistics Launch Facility ......................................................................5-5
Viewing HTTP Statistics ........................ ...... ....... ...... ....... ...... ...... ....... ...... ................5-6
vi
300019-C Rev 00
Chapter 6 Viewing Router Port Statistics
Changing the Administrative Status of a Port ....................................................................2
Viewing Traffic Statistics for All Ports .................................................................................2
Viewing Ethernet Port Statistics ........................................................................................3
Viewing Serial Port Statistics .............................................................................................3
Viewing FDDI Port Statistics ..............................................................................................3
Viewing HSSI Port Statistics ..............................................................................................4
Viewing Token Ring Port Statistics ....................................................................................4
Chapter 7 Viewing Router Protocol Statistics
Changing the Administrative Status of an Interface ........................................................7-1
Viewing IP Statistics .................................... ...... ....... ...... ....... ...... ...... ....... ...... ....... ...... ...7-2
Viewing IPX Statistics ........ ...... ....... ...... ....................................... ...... ....... ...... ....... ...... ...7-3
Viewing AppleTalk Statistics .............................................................. ....... ......................7-3
Chapter 8 Support and Administration
What Administration Functions Do .................................................................................8-1
Using Date and Time Functions .....................................................................................8-2
Using the Reset and Boot Functions ..............................................................................8-3
Resetting a Slot ........................................................................................................8-3
Booting the Router ...................................................................................................8-3
File Manager Functions ..................................................................................................8-4
Files Function ...........................................................................................................8-4
Volumes Function .....................................................................................................8-5
Appendix A Site Manager Parameters
Accessing HTTP Site Manager Parameters .................................................................. A-2
Appendix B BCC show Commands
Sample show Command Output .................................................................................... B-2
Online Help for show Commands .................................................................................. B-3
Show Commands for the HTTP Server ......................................................................... B-3
show http summary ................................................................................................. B-3
300019-C Rev 00
vii
Index
show http requests .................................................................................................. B-4
show http responses ............................................................................................... B-4
viii
300019-C Rev 00

Figure

Figure 2-1. HTTP Server Interface Components ........................................................2-2
300019-C Rev 00
ix

Tables

Table 1-1. Access Privilege Levels and Associated Functions ................................1-6
Table 4-1. Event Message Severity Levels ...................... ...... ...... ....... ......................4-4
300019-C Rev 00 xi

Preface

This guide describes how to configure and use the Bay Networks® HTTP Server, an embedded Web-based router management tool include d with the Bay Networ ks
router operating system software (BayRS Web browser. Using HTTP Server software, you can monitor network devices, viewing summary, fault, and statistical information on a device-by-device basis.
You can use the Bay Command Console (BCC HTTP Server software on a router. In this guide, you will find configuration instructions for both the BCC and Site Manager.
) and accessible from any standard
) or Site Manager to configure the

Before You Begin

Before using this guide, you must complete the following procedures. For a new router:
Install the router (see the installation guide that came with your router).
Connect the router to the network and create a pilot configuration file (see Quick-Starting Routers).
Configure IP on the router (see Configuring IP Multicasting and Multimedia
Services; Configuring IP, ARP, RIP, and OSPF Services; and Configuring GRE, NAT, RIPSO and BFE Services).
Make sure that you are running the latest version of Bay Networks BayRS and Site Manager software. For information about upgrading BayRS and Site Manager, see the upgrading guide for your version of BayRS.
300019-C Rev 00
xiii
Managing Routers Using the Web Server

Text Conventions

This guide uses the following text conventions:
angle brackets (< >) Indicate that you choose the text to enter based on the
description inside the brackets. Do not type the brackets when entering the command.
Example: If the command syntax is:
<
ip_address
ping ping 192.32.10.12
>, you enter:
bold text
Indicates command names and options and text that you need to enter.
Example: Enter Example: Use the
show ip {alerts | routes}.
command.
dinfo
italic text Indicates file and directory names, new terms, book
titles, and variables in command syntax descriptions. Where a variable is two or more words, the words are connected by an underscore.
Example: If the command syntax is:
show at <
valid_rout e
valid_route
is one variable and you subst itute one value
>
for it.
screen text Indicates system output, for example, prompts and
system messages. Example:
Set Bay Networks Trap Monitor Filters
xiv
300019-C Rev 00
Preface
separator ( > ) Shows menu paths.
Example: Protocols > IP iden tifi es the IP optio n on the Protocols menu.

Acronyms

vertical line (
) Separates choices for command keywords and
|
arguments. Enter only one of the choices. Do not type the vertical line when entering the command.
Example: If the command syntax is:
show ip {alerts | routes} show ip alerts
or
show ip routes
, you enter either:
ARP Address Resolution Protocol BootP Bootstrap Protocol FDDI Fiber Distributed Data Interface FTP File Transfer Protocol HSSI High-Speed Serial Interface HTTP Hypertext Transfer Protocol ICMP Internet Control Message protocol IP Internet P rotocol IPX Internet Packet Exchange
, but not both.
300019-C Rev 00
MAC media access control RIP Routing Information Protocol SAP Service Advertising Protocol SMDS Switched Multimegabit Data Service SNMP Simple Network Management Protocol TCP Transaction Control Protocol URL uniform resource locator
xv
Managing Routers Using the Web Server

Bay Networks Technical Publ ications

You can now print Bay Networks technical manuals and release notes free, directly from t he Inte rnet. Go to support.bay networks.co m/library/t pubs/ . Find the Bay Networks product for which you need documentation. Then locate the specific category and model or version for your hardware or software product. Using Adobe Acrobat Reade r, you can open the manuals and rel ease n ote s, sea rch for the sections you need, and print them on most standard printers. You can download Acrobat Reader free from the Adobe Systems Web site, www.adobe.com.
You can purchase Bay Networks documentation sets, CDs, and selected technical publications through the Bay Networks Collateral Catalog. The catalog is located on the World Wide Web at support.baynetworks.com/catalog.html and is divided into sections arranged alphabetically:
The “CD ROMs” section lists available CDs.
The “Guides/Books” section lists books on technical topics.
The “Technical Manuals” section lists available printed documentation sets.
Make a note of the part numbers and prices of the items that you want to order. Use the “Marketing Collateral Catalog description” link to place an order and to print the order form.

How to Get Help

For product assista nce, support contracts, in for m at ion about educational servic es, and the telephone numbers of o ur glob al supp ort of f ices, g o to the foll owing URL :
http://www.baynetworks.com/corporate/contac ts/
In the United States and Canada, you can dial 800-2LANWAN for assistance.
xvi
300019-C Rev 00
Chapter 1
Starting and Configuring the HTTP Server
The Bay Networks HTTP Server is an embedded Web-based router management tool included with BayRS and accessible from any standard Web browser. Using the HTTP Server software, you can monitor network devices, viewing summary, fault, and statistical infor mati on on a device -by -de vic e basi s.
Before you can use the HTTP Server to monitor a router, you must configure and enable the HTTP Server software on the router using the Quick-Start installation script install.bat, the Bay Command Console (BCC
), or Site Mana ger.
The following sections describe how to get started.
B
rowser Requirements Starting the H TT P Server Usin g install.bat
Starting the HTTP Server Using the BCC Starting the HTTP Server Using Site Manager
Setting HTTP Server Security Using a Domain Name Instead of an IP Address Relocating HTTP Server Help Information Customizing HTTP Parameters

Browser Requirements

Your Web browser must support the following:
•Frames
JavaScript 1.2 or later
Java applets
Cascading style sheets
300019-C Rev 00 1-1
Managing Routers Using the Web Server
For example, the browsers Netscape® 4.0 and later and Microsoft® Internet
®
Explorer
4.0 and later offer these features.
If you have changed the default settings for these browsers, you must ensure that Java is enabled and that your browser is configured to accept cookies. To configure digest aut hent ic at io n, you must use a browser t hat supports this featu re .
Caution:
Internet Explorer lets you store your browser password. For security reasons, Bay Networks strongly recommends that you do not store your password.
If you are upgrading from an earlier version of the HTTP Server and want to access Web pages that require digest authentication, you must reenter or change your password when upgrading to the HTTP Server in BayRS Version 13.20.
Starting the HTTP Serve r Us ing
A new router comes wit h a flash mem ory card containing the software im age for the router, two configuration files (config and ti.cfg), and the Quick-Start script install.bat.
The Quick-Start installation scr ipt install.bat creates an initial IP network interface on the rout er so that your router ca n communicate wit h the con figurati on workstation from which you will manage t he route r . Th e i nstall.ba t script pr ompts you to enter the network information that dynamically configures the initial IP interface.
install.bat
As the following example shows, the script asks whether you want to enable HTTP. Answer yes to this question. (The default is no.)
Step 7. Enable HTTP
Enable the HTTP (Web) Server
----------------------------
Do you want to enable the HTTP (Web) server? (y/n)[n]:
HTTP server enabled.
1-2 300019-C Rev 00
y
Starting and Configuring the HTTP Server
Note:
For complete ins truct ion s on runn ing the ins tall. bat scr ipt an d verif ying
that the installation is successful, see Quick-Starting Routers.
When you enable the HTTP Ser ver duri ng the Qui ck-St art pr ocedur e, you ca n use the HTTP Server with its default configuration settings after completing the install.bat procedure. For information on modifying the default HTTP Server settings, see “C
ustomizing HTTP Parameters.”
After you run the install.bat script, you can install Site Manager software, as described in Quick-Starting Routers.

Starting the HTTP Serve r Us ing the BCC or Site Manager

If you did not use the Quick-Start procedure to start the HTTP Server, you can start it using the BCC or Site Manager. When you complete this procedure, the HTTP Server software is configured on the router. Before you start the HTTP Server, verify that you have configured IP on an interface.
You can start the HTTP Server using default values for all parameters. For information about modifying the default HTTP Server settings, se e “C
ustomizing
HTTP Parameters.”
Using the BCC
Adding the HTTP Server to a router automatically loads TCP on all slots. To add the HTTP Server to a router, navigate to the box prompt and enter:
http
For example, the following command adds HTTP Server to a router:
box#
http
http#
300019-C Rev 00 1-3
Managing Routers Using the Web Server
Using Site Manager
You can configure the HTTP Server software in any Configuration Manager mode. To start the HTTP Serve r software, complete the fo llowing tasks:
You do this System responds
Site Manager Procedure
1. In the Configuration Manager window,
Protocols
choose
2. Choose
3. Choose
4. Choose
5. Choose
6. Choose
7. Choose
8. Choose
Global Protocols TCP Create TCP
Protocols Global Protocols HTTP Create HTTP
.
. The Global Protocols menu opens.
. The TCP menu opens.
. You return to the Configuration Manager
. The Protocols menu opens.
. The Global Protocols menu opens.
. The HTTP menu opens.
. You return to the Configuration Manager

Setting HTTP Server S ecurity

The HTTP Server allows access to device information from anywhere in the network. To protect your network information, you can implement security controls. The HTTP Server offers access control through: user name/password security, basic access or digest authentication, and network address filtering, as described in the following sections.
User Name/Password Security Concept Basic Access Authentication Digest Authentication
The Protocols menu opens.
window.
window.
s
1-4 300019-C Rev 00

User Name/Password Security Concepts

The HTTP Server control s access to network device i nf ormation by grouping that information into col le ction s, call ed realms, that share the same security attr ibut es. The HTTP Server defines three security realms on the router: user, operator, and manager . A use r name/p assword author izati on mechan is m control s acce ss to ea ch realm.
The user access privileges let you view device information
The operator access privileges additionally let you make temporary changes
to the router configuration; for example, enabling and disabling an interface, setting and clearing the event log, se tting the date and time, re sett ing a slot on the router, and rebooting the router using a file that a person with manager access privilege has loaded on the router.
The manager access privileges add complete read-write access to the router,
letting you, for example, format and compact volumes and load files onto the router’s flas h memory . A per son with manager ac cess privileges can also view SNMP communities and SNMP manager information.
Starting and Configuring the HTTP Server
and
ping a router.
Note:
Setting the user access privileges, assigning passwords, and related activities are not part of the HTTP Server, but your level of privilege determines what you can do in the HTTP Server.
The nonvolatile RAM (NVRAM) standard Manager and User login accounts are similar to the Manager and User logins for the Technician Interface. BayRS also supports custom logins, such as chris, lee, and operations. The access privilege levels for custom logins are manager (same privileges as for the Manager login), user (same privileges as for the User login) and operator, as previously listed.
Note:
In this guide, the wo rd “Manage r” or “User” with an init ial capit al lette r (other than at the start of a sentence) refers to the the actual NVRAM login. The word “manager,” “user,” or “oper ator” (a ll l owercas e) re fe rs to a pri vilege level.
The system administrator can also create groups of user login accounts with the same access privilege levels. For example, users with the logins chris and lee can be members of the group support, which could have operator-level access privileges. For information about how to configure custom logins and associated access privileges, see Using the Bay Command Console (BCC).
300019-C Rev 00 1-5
Managing Routers Using the Web Server
Privileges are cumulative. An operator can do all that a user can, plus the functions listed for the operator privilege level. A manager can do everything an operator can, plus those functions that are exclusively available to the manager privilege level. Table 1-1 summarizes the privilege levels and the functions available to each.
Table 1-1. Access Privilege Levels and Associated Functions
A user with at least this privilege level Can perform this function
By clicking on this path in the navigation frame
User Display router summary
information. View circuit alerts and the event
log. Ping a router. Trouble Shooting > Ping - IP
Display router statistics for services, ports, and protocols (except SNMP communities and SNMP manager statistics).
Get help on the HTTP Server interface, view the release notes, link to online manuals, and contact the Bay Networks Technical Solutions Center.
Display file status. Administration > File Manager View the date and time. Administration > Date
Summary
Trouble Shooting > Circuit Alerts Trouble Shooting > Event Log
Trouble Shooting > Ping - IPX Trouble Shooting > Ping - AppleTalk
Statistics > Services Statistics > Ports Statistics > Protocols
Support > Help Support > Release notes Support > Manuals Support > Support
(continued)
1-6 300019-C Rev 00
Starting and Configuring the HTTP Server
Table 1-1. Access Privilege Levels and Associated Functions
(continued)
A user with at least this privilege level Can perform this function
Operator Enable or disable a conn ection to
a router.
Reset a slot. Boot a router.
Save or clear the event log. Troubleshooting > Event Log > Save Log
Set the date and time. Administration > Date
Manager Copy, delete, get, or put a file. Administration > File Manager > Files
Compact a volume. Format a volume. Create or delete a partition on a volume.
By clicking on this path in the navigation frame
Statistics > Ports > Ethernet > Summary Statistics > Ports > Serial > Summary Statistics > Ports > FDDI > Summary Statistics > Ports > HSSI > Summary Statistics > Ports > Token Ring > Summary
Administration > Reset & Boot
Troubleshooting > Event Log > Clear Log
Administration > File Manager > Volumes
The system administrator sets the privilege level and assigns a password for each user or group of users. The manag er password cannot be an empt y (null) string. To perform manager functions on a device, you must enter the appropriate login name and password.
A password is optional for a user or operator login account. If the system administrator does not set a user or operator password, the HTTP Server accepts an empty (null) string as the password. Generally, the system administrator sets passwords using Technician Interface or BCC commands, just as for console access.
300019-C Rev 00 1-7
Managing Routers Using the Web Server
If you have user or operator pr ivileges and att empt to access info rmation requir ing manager or operator privileges (or, if you attempt to use the manager login with a null password), the HTTP Server prompts you for the manager password. If you do not provide the appropriate password, an error message appears, and you cannot perform that operation.
Note:
The BCC and Technician Interface provide two default user login accounts, User and Ma nager. Information about these acce ss privil ege level s is stored in nonvolatile RAM (NVRAM) on the router.
A system administrator can define multiple-user groups, names, passwords, and access privileges for other users.
The operator privilege level can be assigned to any user login account other than one of the default login names. Information about these other configured users is stored in the device configuration file. Only one system administrator at a time can change the configuration file.
For specific informat ion about creating login names and pa sswo rds and as si gni ng access privileges, see Using the Bay Command Console (BCC) or Using Technician Interface Software. For information about securing a router as part of the Quick-Start procedure, see Quick-Starting Routers.

Basic Access Authentication

In basic access authentication, the user name and password are passed over the network as encoded but unencrypted text. While this serves to verify the identity of the user, the information is less secure than with digest authentication. Even in basic access authentication, the information is not visible to anyone with a sniffer or similar device. If yo ur browser does n ot support digest authenticatio n, you must leave authenti catio n set to the defaul t va lue of b asic; othe rwise, you cannot acce ss the device.
1-8 300019-C Rev 00

Digest Authentication

Digest authenticati on, based on RFC 2069, uses an encrypte d password to verif y a user’s identity. Like basic access authentication, digest authentication uses a challenge-respo nse mode l, but th e au thent icati on infor mation i s enc rypted . To use digest authenticatio n, your brows er mu st be capa ble of support in g diges t authentication, and you must explicitly set the HTTP server Authentication parameter to digest. If your browser supports digest authentication, but the server is set to basic authentication, the browser uses basic authentication. If your browser does not support digest authentication, you must set authentication to basic; otherwise, you cannot access the device.

Filtering Network Addresses

For additional security, you can implement IP access control filters when you configure IP on the router. These filters further restrict access to the router, limiting access to specific IP addresses or IP address ranges.
You must also ensure that IP is appropriately configured to support HTTP. To do this, you must ensure that the appropriate access policy filters are configured for HTTP.
Starting and Configuring the HTTP Server
To specify these requirements as part of the IP configuration process, use the BCC. For additional information about IP access policy filters and how to configure them, see Configuring IP Utilities. For general instructions about using the BCC, see Using the Bay Command Console (BCC).

Using a Domain Name Instead of an IP Address

By default, you access a server using its IP address. However, you can let the server be accessible by a domain name, rather than by IP address, by specifying the HTTP Server Domain Name parameter. The value of the HTTP Server Domain Name parameter must be a domain name that a DNS lo okup would re turn for the router. The name can consist of any valid string of characters.
300019-C Rev 00 1-9
Managing Routers Using the Web Server

Relocating HTTP Server Help Information

When you click on Help in an HTTP Server window, a secondary window displays Help informati on for that window. By default, these Help pages reside on the server. If the available space is limited, or if you want to place the Help files on a different server, you can locally relocate the Help files. If you do this, you must tell the HTTP Server wher e to find the help fi les by providin g a base unifor m resource locator (URL) to the start of those files. Thi s base URL, combined wi th a relative URL for each window, points to the detailed Help information for that window.
To see the current value of the Help Base URL parameter, choose the following path in the navigation frame: Statistics > Services > HTTP > Configuration. You can accept the default value for the Help Base URL parameter or specify a new help base URL.

Customizing HTTP Parameters

Adding the HTTP Server to a router automatically configures HTTP with all default values. You can change these settings using either the BCC or Site Manager.
Using the BCC
To change these parameter settings, first navigate to the http prompt. To disable http on the router, enter:
disable
For example:
http#
disable
To change the port number, enter:
<
port_number>
port
For example:
http#
port 81
To specify access authentication level, enter:
authentication digest
1-10 300019-C Rev 00
or
authenti ca ti o n b a s ic
For example, the following command configures digest authentication:
box# http http# authentication digest http#
To specify the use of a domain name for the router, enter:
domain-name
For example, the following command allows the use of the domain name “myrouter”:
http# domain-name myrouter
To specify the base uniform resource locator (URL) of the location at which the HTTP Server Help files are stored, enter:
help-base-url
For example, the following command sets the HTTP Server Help base U R L to
library.mycompany.com/helpfiles/:
http#
Using Site Manager
Starting and Configuring the HTTP Server
<
domain_name>
>
<
url
help-base-url library.mycompany.com/helpfiles/
To configure or change the HTTP Server parameters, first create HTTP on the router, then complete the following tasks:
Site Manager Procedure
You do this System responds
1. In the Configuration Manager window,
Protocols > Global Protocols >
choose
HTTP > Global
2. Set the
Enabled Disabled
Click on description on page A-2
3. Set the on which you enabled the HTTP Server. Click on description on page A-3.
300019-C Rev 00 1-11
Enable/Disable
Port
.
parameter to
to enable the HTTP Server or to
to disable the HTTP Server.
Help
or see the parameter
.
parameter to the port number
Help
or see the parameter
The Edit HTTP Global Parameters window opens.
(continued)
Managing Routers Using the Web Server
Site Manager Procedure
You do this System responds
4. Set the
Basic
parameter description on page A-3
5. Set the domain name to use for the router. To use the IP address instead of a domain name, leave this parameter value blank. Click on
Help
page A-3
6. Set the help files if you put the m in a differe nt location from the default. Click on see the parameter description on
page A-4
7. Click on OK. You return to the Configuration Manager
Authentication
or
Digest
Domain Name
or see the parameter description on
.
Help Base URL
.
parameter to
. Click on
parameter to the
or see the
Help
.
parameter for the
or
Help
(continued)
window.
1-12 300019-C Rev 00
Chapter 2
HTTP Server Concepts
HTTP Server software lets you access device information from anywhere in the network using any standard Web browser that conforms to HTTP and HTML specifications. The HTTP Server is part of the BayRS software. This chapter provides an overview of the HTTP Server.
What the HTTP Server Does Navigating the HTTP Server Interface Enabling and Disabling Connections What the Administration Functions Do
To obtain Web-accessible data, you must configure the HTTP Server software on the router. Chapter 1, “Starting and Configuring the HTTP Server the configuration procedure.
,” summarizes

What the HTTP Server Does

The HTTP Server is a graphical user interface (GUI) that lets you view real-time device summaries, events, alerts, and statistics. Users with appropriate privileges can also save or clear the event log, enable and disable connections, and perform administrative functions such as resetting a slot, rebooting the router, managing files and volumes, and setting the date and time. The HTTP Server graphically displays information similar to (and a superset of) the text-only information available through the BCC point-and-clic k interfa ce, you also have dir ect acces s to online document ation and Bay Networks technical support.
300019-C Rev 00 2-1
show, enable
, and
disable
commands. Through this
Managing Routers Using the Web Server
The information that you gather through the HTTP Server interface can help you monitor and manage your network’s performance on a device-by-device basis. You can see, for example, where conges tion is oc curri ng or whe re transmi ssion o r reception problems exist. For detailed information about interpreting this information, refer to Troubleshoot ing Routers and the description of the event log in Chapter 4, “Troubleshooting Router Operation
To start the HTTP server, specify a device in your browser’s location field and press Enter. You see a multiframe window, like that in Figure 2-1
.”
.
Banner frame
Display frame
Navigation frame
Figure 2-1. HTTP Server Interface Components
This window has the following components:
Banner -- The top frame shows the Nort el Net works lo go and the dev ice typ e. The banner specifies the device’s IP address or its domain name and, if defined, identifies the device by name and physical location, and lists the name of the contact pe rson respo nsibl e for that device. If Telnet server service is configured, you can click on the IP address or domain name to establish a Telnet connection to the device.
2-2 300019-C Rev 00
Navigat ional frame -- The frame on the left contains link s to each monitored function. Initially, these links are all folders. The folders (and the documents they contain) in the navigational frame are active links to device information.
Display frame -- The lar ge fr ame on the lower right side displa ys the retr ieved Web data.

Navigating the HTTP Server Interface

The navigational frame contains the following expandable folder icons:
Summary -- System information, hardware informaation, PROM information, software image information, system resource information, and system task information
Trouble Shooting -- Circuit alerts, the event log, and Ping functions
Statistics -- Services, ports, and protocols
Support -- Help, release notes, technical manuals, and customer support links
Administration -- Router date and t ime, s lot r eset and r outer boot, and f ile and volume management information
HTTP Server Concepts
Click on each folder in turn to display the information for t he device you are monitoring.
To show the types of data a folder contains, click on the folder icon. The folder opens, revealing document icons for the data within that folder.
To view a specific data type within a folder, click on its document icon.
To close (that is, collapse) a folder’s contents, click again on the folder icon.
Some windows contain fields in which you can enter data. The browser ensures that the type of data you enter is appropriate for the function requested; for example, it ensures that data you enter in a numeric field is, in fact, numeric. If you enter invalid data, a dialog box appears listing the fields containing the invalid data.
When you try to perform a function that would cause a permanent change to the router, a dialog box opens asking you to confirm this action.
300019-C Rev 00 2-3
Managing Routers Using the Web Server

Data Display Formats

The HTTP Server displays data either in tables, as for summary statistics, or in a cumulative list, as for the event log. If a table continues on a subsequent window, the HTTP Server provides a set of buttons that let you navigate to the next, previous, or top por tion of the tabl e. An end of table i ndicator s hows tha t you have reached the last entry in a table.

Enabling and Di sa bling Connections

If you have either operator or manager access privileges, you can disable or enable the connection to the router you are managing. Be particularly careful when disabling a connection. If you disable the connection that the HTTP Server is using to communicate with the router, then the HTTP Server can no longer monitor or manage that device.
To disable or enable a connection, do the following steps.
Choose Statistics > Ports.
1.
Select the type of port (Ethernet, serial, and so on).
2.
Select Summary and click on Enable or Disable in th e row corr esponding
3.
to the connection you want to disable or enable.
The HTTP Server requires a confirmation before allowing you to disable a connection.
Note:
If you disable the connection through which you are connecting, you must access the device and use eit her Sit e Manager or the BCC to reenable t he interface.

What the Administration Functions Do

The administration functions let any user view the system date, time, and time zone information, and information about the files on each volume.
A person with operat or acces s privil eges c an also ch ange the da te and time, res et a slot, and reboot the router using an image that is already loaded on a volume.
2-4 300019-C Rev 00
HTTP Server Concepts
A person with manager access privileges can load, copy, or delete files on the router and format and compact volume s.
See Chapter 8, “Support and Administration administration functions.
,” for a detailed description of the
300019-C Rev 00 2-5
Chapter 3
Monitoring Routers Using the HTTP Server
This chapter describes how to use the Web Server to monitor the operation of individual routers on your network. For specific descriptions of how to use the information from the HTTP (Web) Server to troubleshoot the devices in your network, refer to Troubleshooting Routers.
Getting Help Specifying a Router to Monitor Viewing Overall System Status
Info Hardware PROMs Software Resources Tasks

Getting Help

HTTP Server windows that offer interactive features also offer a Help button. When you click on Help, you see a secondary window containing detailed information about the elements in that window.
300019-C Rev 00 3-1
Managing Routers Using the Web Server
In addition, other types of online Help are available from the Support folder, as the followin g table shows.
For this information Click on Support, then on
HTTP Server interface help Help icon Release Notes Release Notes icon Bay Networks documentation Manuals icon Bay Networks technical support Support document icon
After opening one o f these l inks, choose Fil e > Close to ret urn to t he HTTP Ser ver page on the Web browser. Choosi ng File > Exi t shuts down the browser. The Back button may not be available on linked pages.

Specifying a Router to Monitor

To specify a router to monitor, complete the following steps:
Start your Web browser.
1.
In the Location field, enter:
2.
http://<
router_IP_address
router_IP_address> or
is an IP addre ss on t he device that y ou want t o monitor; f or
://<domain-name>
http
example:
http://192.168.12.54
domain-name
is the fully quali fied path t o the domain name of the de vice yo u
want to monitor; for example:
http://myrouter
The browser displays a summary window for the specified device.

Viewing Overall System Status

To get an overall picture of the operational state of the router, use the summary information. The summary provides hardware and software information including this router’s configuration and its internal resource usage. To see the types of summary information available, click on the Summary folder icon in the navigational frame.
3-2 300019-C Rev 00
Monitoring Routers Using the HTTP Server
The following table lists the icons within the Summary folder and the information that each displays when you click on it.
Shows
Icon
Info System Device name -- the mnemonic name that the
Hardware Specific device Model name and serial number
PROMs PROM modules
Software Software image
Resources System
Tasks System tasks on
information for Displayed summary information
system administrator assigns
Location -- the loca tion, as defined by the system administrator
Contact person responsible for that device, as defined by the system administ r ato r
Up time -- the time elapsed since the last device reset
MIB version -- the version numb er of the management information base (MIB) for the router software
Software version -- the versio n number and cre ation date and time of the router software image
Type, revision, and serial number of the processor and link module in each slot and, for platforms that support it, the link module number.
For the Boot PROM and for the Diagnostic PROM in
in the device
on the specified device
resources on the specified hardware device
the specified hardware device
each slot:
Revision number
Date and time of PROM information
For each router slot:
Name of the software image file and the volume number from which it loads
Source of that image
Date and time the image was created
Name of the configuration file
For each router slot, usage data for:
•CPU
Memory
•Buffers
For each active task:
Name of each task
Usage data for the CPU, memory, and buffers
Slots on which the task is running
For detailed information about interpreting the information obtained through the HTTP Server, refer to Troubleshooting Routers.
300019-C Rev 00 3-3
Chapter 4
Troubleshooting Router Operation
With the HTTP Server, you can view the events and alerts generated by the entities on the router. When you click on the Trouble Shooting icon, the folder opens and displays document icons that invoke the following functions:
View all circuit alerts on the router
View all, or a selection of, event log messages
Determine whether a device is operational (ping a device) You must first have configured and enabled the HTTP Server on your router, as
described in Chapter 1, “Starting and Configuring the HTTP Server detailed descri pt ion of how to isolate and correct problems wit h a specific device, refer to Troubleshooting Routers. The following sections describe the troubleshooting fea tu res.
Trouble Shooting Icon Displaying Circuit Alerts Viewing the Event Log

Trouble Shooting Icon

Clicking on the Trouble Shooting folder icon in the navigational frame reveals five additional choices:
Circuit Alerts
Event Log
Ping - IP
Ping - IPX
Ping - AppleTalk
.” For a
300019-C Rev 00 4-1
Managing Routers Using the Web Server

Displaying Circuit Alerts

A cir cui t aler t i ndicat es a con ditio n, su ch as a por t/in te rface that ha s been br ought down unexpectedly, that requires your immediate attention. To view any exceptional status conditions for any interface on the router, choose Trouble Shooting > Circuit Alert in the navigational frame.
For each index item, the circuit alerts display shows:
Index number
•Circuit name
Administrative state (usually up)
Operational state (usually down)
Type
MAC address
Maximum transmission unit (MTU)
Line speed

Viewing the Event Log

An event is something that happens to the operating status of a router. The router stores each event as a singl e entr y i n a memory- resi den t log f ile. The event l og for a router is t he composit e of al l eve nts that occur f or all the p rocessor s in the router.
An event message briefly describes an event an d reports th e event code ass ociat ed with that event. Use the entity identifier together with the event code to look up the meaning of the message in the events database.
To view the events for a router, choose Trouble Shooting > Event Log in the navigational frame.
iltering What the Event Log Show s
F Interpreting Event Messages
Note:
Event code numbers are not unique among entities.
4-2 300019-C Rev 00

Filtering What the Event Log Shows

By default, the event log display shows Fault, Warning, and Info event messages.
To show other event messages, click on the check boxes to select the appropriate Event Message Severity Levels
To restrict the display to one or more specific slots or entities and to show only events that happen after a specific date and time, fill in the fields in the Event Log window, separating individual entries with spaces.
Entity names are not case-sensitive. If the entity name contains a space character, you must enclose the name i n double quot es. For a li st of ent ity names, r efer to the events database. The default URL for the events database is:
http://support.baynetworks.com/library/tpubs/events/
If you specify a date filter, the event log displays events that occur on or after the specified date. You can specify the date as month, day, and year; for example, 01:22:99 or 01:22:1999. If you spe ci fy a t ime f il te r, use one of the formats shown on the Event Log window; for example, hh:mm:ss. The event log display shows only events logged after the given hour, minute, and second. The current date is assumed.
Troubleshooting Router Operation
.

Interpreting Event Messages

Each event in the event log has a hot link to the corresponding description in the events data base. To view the detailed informat ion for an event, click on the hot link. The description appears in a secondary window.
Most messages document routine occurrences that do not require you to do anything. Table 4-1
300019-C Rev 00 4-3
lists and briefly describes the severity levels.
Managing Routers Using the Web Server
Table 4-1. Event Message Severity Levels
Severity Description
Fault Major service disruption, usually caused by a configuration, network,
or hardware problem. The entities involved keep restarting until th e
problem is resolved either by the router itself or by you. Warning Service acted in an unexpected manner. Info Routine event. Usually, no action is required. Trace Detailed history of everything that happens on the router. Because of
the amount of information that the trace function records, Bay
Networks recommends viewing this type of message only when
diagnosing specific network problems. Debug Information that Bay Networks Customer Support uses. Because of
the amount of information that the Debug function records, Bay
Networks recommends viewing this type of message only at the
direction of Bay Networks Customer Support.

Saving and Clearing the Event Log

To save or clear the event log, you must have either operator or manager access privilege. If a person with user access pri vileges attempts one o f t h es e o p er ati ons , the HTTP Server opens a secondary window with an
Authorization failed
message. To log in at a higher privilege level, click on Retry, then enter an appropriate login name and password.
Saving the Event Log
To save the event log to a file, do the following steps.
Click on Save Log.
1.
A secondary window opens, listing the filters that you selected in the Event Log window (slot, date, and time information). The save log function saves event messages of all severity levels in the log file, regardless of the severity level filter s.
Select a volume where you want to save the file.
2.
Scroll through the list of files on that volume and select a file name to use,
3.
or specify a new file name in the File field.
4-4 300019-C Rev 00
Troubleshooting Router Operation
Click on Save to stor e the curr e nt conten ts of the event log a s a file on the
4.
indicated volume.
Click on Cancel to exit the Save Log window without saving the file.
Note:
Although the router does no t r equir e it , Bay Net works r ecommends that files saved in flash memory follow the 8.3 file naming co nvention; fo r example, savelog1.log.
Clearing the Event Log
To clear the event log, do the following steps.
Click on Clear Log. A secondary window opens, asking you to select the
1.
slot (or all slots) for which you want to clear the event log. Make your selection, the n cl ic k on Clear to clear the log or Cancel to end
2.
the operation without clearing the log.
If you click on Clear, another secondary window replaces the previous one, confirming your slot se lection and asking you to conf ir m tha t yo u re all y want to clear the log for the selected slot or slots.
Click on OK to confirm and complete the operation.
3.

Getting Help on the Event Log Window

Click on Help to open a secondary window that explains the fields and functions available in the Event Log window.

Pinging Devices

To determine whether a router or host on a network is operational, any user can send a PING packet using the Ping icon appropriate for that protocol and device.
PING
The response, and reports success or failure and statistics about its operation.
To ping a device, do the following steps.
1.
300019-C Rev 00 4-5
command se nds an echo packet to the specified device, wa its for a
Navigate to the Ping window for IP, IPX, or AppleTalk by selecting Trouble Shooting and clicking on the Ping icon for the appropriate protocol.
Managing Routers Using the Web Server
Fill in the fields in the Ping window.
2.
Click on Help in the Ping window for a complete description of these fields. Specify the device from which you are sending the PING, the device to receive the PING, the packet size, the number of ti mes to issue the PING, how long to wait for a response, and various options about the contents of the report. The exact set of fields depends on the protocol you select.

Ping IP

Ping IPX

Click on PING to issue the
3.
PING
command.
The following sections give specific information about pinging devices on IP, IPX, and AppleTalk networks.
Choosing Tro ubl e Shoot ing > Ping-IP opens the Ping IP window. For a device on an IP network, you can specify either the IP address or the domain name for the source and destination devices.
Clicking on PING after you fill in these fields executes an ICMP Echo Request/Reply handsha ke with the spec ifie d IP Address . The re sult app ears in the Ping IP window. PING statistics and any error information are logged.
Choosing Tr ouble Sh ooting > Ping-I PX opens th e Ping IP X window. For a device on an IPX network, the address of the device that you are pinging consists of the network address concatenated with the host address on that network; that is, an address of the format:
nnnnnnnn
.0x
hhhhhhhhhhhh
. Network or host addresses
0x
of 0 or broadcast are i nvalid. If an I PX inter face on th is router is pinged, no packet is sent on the w ire; however, the interface itself is pinged internally.
Clicking on PING after you fill in these fields executes an IPX Echo Request/ Reply handshake with the specified IPX address. The result appears in the Ping IPX window. PING statistics and any error information are logged.
4-6 300019-C Rev 00

Ping AppleTalk

Choosing T roubl e Shoot ing > Ping-App le Talk opens the Ping AppleTalk window. For a device on an AppleTalk network, specify the device address as
<network>.<nodeID>
ddddd
( in hexadecimal format. Broadcast addresses are invalid.
Clicking on PING after you fill in these fields executes an AppleTalk Echo Protocol Request/Respons e handshake with the specified Apple Talk address. The result appears in the Ping AppleTalk window. PING statistics and any error information are logged.
, where
) or hexadecimal (
<network>
0x
hhhh
Troubleshooting Router Operation
and
<nodeID>
can be in either decimal
) format; that is, both must be in decimal or both
300019-C Rev 00 4-7
Chapter 5
Viewing Router Services Statistics
Examining the router’ s stat istics along with the e vent log ca n give you a pi cture of how well a router is working. When you choose Statistics in the navigational frame, the folder opens to show the Services, Ports, and Protocols folders, each containing subordinate links. This chapter shows the Services statistics. For Port statistics, go to Chapter 6, “Viewing Router Port Statistics statistics, go to Chapter 7, “Viewing Router Protocol Statistics
Note:
This guide presents the details of the HTTP statistics. Detailed descriptions of statistics for the other services are in the guides for each service.
,” and for Protocol
.”
Router Services Stati stics Using the HTTP Server to View HTTP Statistics Using the Statistics Manager to View HTTP Server Statistics

Router Service s St atistics

You can display router services statistics either through the Web interface, by choosing Statistics > Services in the navigational frame, or by using the Site Manager Statistics Manager. For information about using the Statistics Manager,
Using the Statistics Manager to View HTTP Server Statistics.” You can also
see use BCC show commands to view router services statistics, as described in
Chapter B, “BCC show Commands
300019-C Rev 00 5-1
.”
Managing Routers Using the Web Server
Using the Web interface, choosing Statistics > Services displays links to the statistics for each service.
To see these statistics Use this path
TFTP Statistics > Services > TFTP TCP Statistics > Services > TCP FTP Statistics > Services > FTP Telnet Statistics > Services > Telnet BootP
Statistics > Services > Bootp This reveals several s ubordi nate li nks: Traffic, Interfaces, Clients, Preferred Srv (Servers), and Relay Agents.
•Traffic
•Interfaces
•Clients
Preferred servers
Relay agents SNMP
Counters
Communities
Trap Entity
Trap Events HTTP
Configuration
Counters
Requests
Responses
* You must have operator or manager access privileges to view the statistics for SNMP communities.
If you logged in with user privileges, HTTP prompts you to enter the operator or manager login name and password.
Statistics > Services > Bootp > Traffic Statistics > Services > Bootp > Interfaces Statistics > Services > Bootp > Clients Statistics > Services > Bootp > Preferred Srv Statistics > Services > Bootp > Relay Agents
Statistics > Services > SNMP This reveals the following subordinate links: Counters, Communities, Entity Traps, and Exceptions.
Statistics > Services > SNMP > Counters Statistics > Services > SNMP > Communities* Statistics > Services > SNMP > Trap Entity Statistics > Services > SNMP > Trap Events
Statistics > Services > HTTP This reveals the following subordinate links: Configuration, Counters, Requests, and Responses.
Statistics > Services > HTTP > Configuration Statistics > Services > HTTP > Counters Statistics > Services > HTTP > Requests Statistics > Services > HTTP > Responses
5-2 300019-C Rev 00
Viewing Router Services Statistics

Using the HTTP Server to View HTTP Sta tis tics

You can display HTTP Server statistics either through the Web interface, by choosing Statistics > Services > HTTP in the navigational frame, or by using the Site Manager Statistics Manager.
HTTP Configuration Statistics HTTP Counters HTTP Request Statistics HTTP Response Statistics Using the Statistics Manager to View HTTP Server Statistics

HTTP Configuration Statistics

HTTP configuration statistics provide the following information:
HTTP Statistic Meaning
State Whether the server is set to be enabled or disabled Status Whether the server is currently up, down, initializing, or not present Port The port number on which this server listens to requests Authentication The level of access authentication security in use Domain Name The domain name, if any, that can be used to access this router Help Base URL The base uniform resource locator (URL) for the HTTP Server Help
files if those files do not reside at the default location

HTTP Counters

HTTP counters provide the following information:
HTTP Statistic Meaning
Total Requests Received
Total Request Errors
Total Request Discards
300019-C Rev 00 5-3
The total number of requests that this entity received
The total number of request errors that this entity detected (as server)
The total number of requests that this entity discarded (as server)
(continued)
Managing Routers Using the Web Server
HTTP Statistic Meaning
Total Responses The total number of responses that this entity generated or received Total In
Unknowns Total Rx Octets The total number of bytes that this entity received Total Tx Octets The total number of bytes that this entity transmitted Total Time Outs The total number of timeouts for this entity Start Time The date and time that the HTTP services were enabled
The total number of unknown messages that this entity received

HTTP Request Statistics

HTTP request statistics provide the following information:
HTTP Statistic Meaning
Method The HTTP standard request method to which these statistics apply Total In The number of requests of this type that this entity received In Last Time The date and time the last request was received

HTTP Response Statistics

HTTP response statistics include
HTTP Statistic Meaning
Status An HTTP standard code and sta tus message des cription ind icating the
category of the response Total Out The number of times this response was generated Out Last Time The date and time the most recent response was sent
5-4 300019-C Rev 00
:
Viewing Router Services Statistics

Using the Statisti cs Manager to View HTTP Server Statistics

T o use the Site Manager Statistics Manager tool to view statistical information for the HTTP Server, select the router that you want to monitor. Choose Statistics on the tool bar or, from the Site Manager menu, choose Tools > Statistics Manager. The Statistics Manager window opens, showing the device IP address and, for each circuit on that device, showing the slot, connector, type, and protocols.
Selecting the Windows to Display Starting the Statistics Launch Facility Viewing HTTP Statistics

Selecting the Windows to Display

Use the Screen Manager tool to select the windows to display. In the Statistics Manager window , choose T o ols > Screen Manager. Add the HTTP windows to the list of those to display, then exit the Screen Manager.

Starting the Statistics Launch Facility

In the Statistics Manager window, choose Tools > Launch Facility to display the Statistics Launch Facility window, which lets you choose the type of statistical information that you want to view for this device.
Select the line that indicates the type of information you want to display, then click on Launch. To return to this window, choose File > Exit in the resulting window.
300019-C Rev 00 5-5
Managing Routers Using the Web Server

Viewing HTTP Statistics

Each statistical wi ndow shows the window name (in t he format name.dat), window description, SNMP agent IP address, and number of elements in the display.
To see these statistics Choose this option What the window shows for each element
HTTP requests
HTTP responses
HTTP server configuration
HTTP summary statistics
httpreq.dat
httpresp.dat
httpsrv.dat
httpsrv2.dat
httpsum.dat
HTTP request statistics:
Methods
Total requests (Total In) for each method HTTP response statistics:
Status (description)
Number of times the server responds for each status type (TotalOut)
HTTP server configuration statistics:
State (enabled or disabled)
Operational status
Port number
HTTP server configuration statistics:
Access authorization level
Domain name
HTTP summary statistics (overview of the router’s current state):
Total requests received
Total request errors
Total discarded requests
Total responses
Total unknown inputs
Total bytes received
Total bytes sent
T otal timeouts
Start time
5-6 300019-C Rev 00
Chapter 6
Viewing Router Port Statistics
Choosing Statistics > Ports displays th e following folders in the navigationa l frame:
•Summary
•Ethernet
•Serial
FDDI
HSSI
Token Ring Choosing Statistics > Ports > Summary opens a window that lists the port traffic
(number of packets transmitted and re ceived) for al l configured interfaces, regardless of media type. For each interface, the Summary window shows the interface description, administrative state, operational state, and type. It also shows the number of octets, errors, and discards received and transmitted.
To get statistical information about any port type, choose the appropriate link. Each port-type folder contains links to sum mary statistics, traffic statistics, receive error statistics, and transmit error statistics. All but Ethernet also display system error statistics. The following sections summarize these displays.
Changing the Administrative Status of a Port Viewing Traffic Statistics for All Ports Viewing Ethernet Port Statistics Viewing Serial Port Statistics Viewing FDDI Port Statistics Viewing HSSI Port Statistics Viewing Token Ring Port Statistics
300019-C Rev 00 6-1
Managing Routers Using the Web Server

Changing the Administrative Status of a Port

If you have operator or manag er a ccess privileges, you can e nab le or disable (that is, change the administrative setting of) a port. To do this, click on the radio buttons in the Enable/Disable column of the table in the summary statistics window for any port type. The HTTP Server requires a confirmation before allowing you to disable a connection.
If you attempt to access information requiring a higher level of access privileges than your current login allows (or, if you attempt to use the manager login with a null password), the HTTP Server prompts you for the appropriate login and password. If you do not provide the appropriate login and password, an error message appears, and you cannot perform that operation.
Caution:
communicating with a router, you will no longer be able to monitor that router’s operation with the HTTP Server.
The State column shows the operational state of the port (up or down). If the port is enabled, but the State column shows that the port is down, there is a problem with the port.
If you disable the IP interface through which your Web browser is

Viewing Traffic Statistics for All Ports

To view traffic statistics for all ports, regardless of media types, choose Statistics > Por ts > Summary. Y ou cannot change the ad ministrat ive stat e of a port from the Port Traffic summary statistics window.
6-2 300019-C Rev 00

Viewing Ethernet Port Statistics

The followi ng table lists t he Ethernet port statistics and the paths to them.
To see these statistics Use this path
Summary Statistics > Ports > Ethernet > Summary Traffic Statistics > Ports > Ethernet > Traffic Rx Errors Statistics > Ports > Ethernet > Rx Errors Tx Errors Statistics > Ports > Ethernet > Tx Errors

Viewing Serial Port Statistics

The following table lists the serial port statistics and the paths to them.
To see these statistics Use this path
Viewing Router Port Statistics
Summary Statistics > Ports > Serial > Summary Traffic Statistics > Ports > Serial > Traffic Rx Errors Statistics > Ports > Serial > Rx Errors Tx Errors Statistics > Ports > Serial > Tx Errors Sys Errors Statistics > Ports > Serial
Sys Errors
>

Viewing FDDI Port Statistics

The following table lists the FDDI port statistics and the paths to them.
To see these statistics Use this path
Summary Statistics > Ports > FDDI > Summary Traffic Statistics > Ports > FDDI > Traffic Rx Errors Statistics > Ports > FDDI > Rx Errors Tx Errors Statistics > Ports > FDDI > Tx Errors Sys Errors Statistics > Ports > FDDI
300019-C Rev 00 6-3
Sys Errors
>
Managing Routers Using the Web Server

Viewing HSSI Port Statistics

The following table lists the HSSI port statistics and the paths to them.
To see these statistics Use this path
Summary Statistics > Ports > HSSI > Summary Traffic Statistics > Ports > HSSI > Traffic Rx Errors Statistics > Ports > HSSI > Rx Errors Tx Errors Statistics > Ports > HSSI > Tx Errors Sys Errors Statistics > Ports > HSSI

Viewing Token Rin g Port Statistics

The following table lists the token ring port statistics and the paths to them.
To see these statistics Use this path
Sys Errors
>
Summary Statistics > Ports > Token Ring > Summary Traffic Statistics > Ports > Token Ring > Traffic Rx Errors Statistics > Ports > Token Ring > Rx Errors Tx Errors Statistics > Ports > Token Ring > Tx Errors Sys Errors Statistics > Ports > Token Ring
6-4 300019-C Rev 00
Sys Errors
>
Chapter 7
Viewing Router Protocol Statistics
Choosing Statistics > Protocols displays the following folders in the navigational frame:
•IP
•IPX
•AppleTalk T o get stat ist ical in format ion ab out any protoc ol t ype, choos e th e a ppropri ate link.
Each protocol folder cont ains links to summa ry statistics , traffic statistics (nu mber of packets transmitted and received), and interface statistics, as well as to other statistics specific to that protocol. The following sections show and briefly describe these displays.
Changing the Administrative Status of a Viewing IP Statistics Viewing IPX Statistics Viewing AppleTalk Statistics
n Interface

Changing the Administrative Status of an Interface

A person who has manager or operator access privileges can enable or disable (that is, change the administrative setting of) the interface.
Choose Statistics > Protocols and choose a specific protocol from the list.
1.
Open the folder for the chosen protocol by double-clicking its icon.
2.
Display the interface statistics by double-clicking the Interfaces icon.
3.
Click on the Enable or Disable radio button in the first column of the
4.
table in the interface statistics window.
300019-C Rev 00 7-1
Managing Routers Using the Web Server
Click on Submit to submi t the c hange or on Reset to cancel the o pera ti on.
5.
A secondary window opens asking you to confirm the submit operation.
Click on OK to confirm to complete the operation or on Cancel to
6.
terminate the operation.
Caution:
If you disable the IP interface through which your Web browser is communicating with a router, you will no longer be able to monitor that router’s operation with the HTTP Server.
The State column shows the operational state of the interface (up or down). If the interface is enabled, b ut the St ate c olumn sh ows that the inte rface i s down, th ere is a problem with the interface.

Viewing IP Statistics

The following table lists the available IP statistics and the paths to them.
To see these statistics Use this path
Global Statistics > Protocols > IP > Global Traffic Statistics > Protocols > IP > Traffic Interfaces Statistics > Protocols > IP > Interfaces Routes Statistics > Protocols > IP > Routes ARP Cache Statistics > Protocols > IP RIP Statistics > Protocols > IP ICMP
> ARP Cache > RIP
Statistics > Protocols > IP This reveals the following subordinate link s : Server an d Client, Received, and T r an sm itt ed.
> ICMP
Counters
Received
Transmitted
7-2 300019-C Rev 00
Statistics > Protocols > IP > ICMP > Server Statistics > Protocols > IP > ICMP > Client Statistics > Protocols > IP > ICMP > Received Statistics > Protocols > IP > ICMP > Transmitted

Viewing IPX Statistics

The following table lists the available IPX statistics and the paths to them.
To see these statistics Use this path
Global Statistics > Protocols > IPX > Global Traffic Statistics > Protocols > IPX > Traffic Interfaces Statistics > Protocols > IPX > Interfaces Forwarding Statistics > Protocols > IPX > Forwarding Hosts Statistics > Proto cols > IPX > Hosts Routes Statistics > Protocols > IPX > Routes Services Statistics > Protocols > IPX RIP Statistics > Protocols > IPX SAP Statistics > Protocols > IPX
Viewing Router Protocol Statistics
> Services > RIP > SAP

Viewing AppleTalk Statistics

The following table lists the avai lable AppleTalk statistics and the paths to them .
To see these statistics Use this path
Global Statistics > Protocols > AppleTalk > Global Traffic Statistics > Protocols > AppleTalk > Traffic Interfaces Statistics > Protocols > AppleTalk > Interfaces Routes Statistics > Protocols > AppleTalk > Routes ARP Cache Statistics > Protocols > AppleTalk Zones Statistics > Protocols > AppleTalk
300019-C Rev 00 7-3
> ARP Cache > Zones
Chapter 8
Support and Administration
In addition to the function-specific Help availabl e for windows that offer interactive features, you can get other types of online Help from the Support folder, as the foll owing table shows.
For this information Choose Support, then click on
HTTP Server window description Help icon Release notes Release Notes icon Bay Networks documentation Manuals icon Bay Networks technical support Support icon
After opening one o f these l inks, choose Fil e > Close to ret urn to t he HTTP Ser ver page on the Web browser. Choosi ng File > Exi t shuts down the browser. The Back button may not be available on linked pages.

What Administration Functions Do

The administration functions include:
Using Date and Time Functions
“Using the Reset and Boot Functions
“File Manager Functions
-- “Files Function
-- “Volumes Function
The administration functions let you monitor (and, with the appropriate access privileges, change) t he administrative sta tus of the router.
300019-C Rev 00 8-1
With user access privileges, you can view the system date, time, and time
zone information and information about the files on each volume.
With oper ator acc ess pri vileges , you can also change th e date and t ime, re set a
slot, and reboot the router, using an image that is already loaded on a volume.
With manag er access privileges , you can als o change the router c onfigurat ion,
including loading, copying, or deleting files on the router and formatting and compacting volumes.
If you attempt a privileged operation without having the appropriate access privileges, the HTTP Serv er d isplays a n “Author izat ion Failed” mes sag e and ask s whether you want to retry the operation. It then lets you enter a login name and password with the appropriate privilege level.

Using Date and Time Functions

Choosing Administration > Date opens the Date & Time window. With user privileges, you can view the router’s current date and time settings and get Help on the window’s contents. A user with operator or manager access privileges can set the date, time, and time zone . The t ime zo ne fi el d i s an offset from Greenwich Mean Time (GMT), also known as Universal Time (UT).
Note:
When setting the date, you must specify all four digits for the year; for
example, 1999.
To set the date, time, and time zone, enter the appropriate data in th e following fields:
Date -- The system date that you want to set, in the format
mm/dd/yyyy
; for
example, 03/31/1999. The default value is the current date.
Time -- The system time that you want to set, in the format
hh:mm:ss
; for example, 09:45:00. The default value is the current time of day for the specified time zone.
Time Zone -- The system time zone that you want to set, in the format,
hh:mm
<+->
300019-C Rev 00 8-2
.
The time zone is dis played as t he of f set i n hour s and minut es fr om Green wich Mean Time (GMT). For e xample, the Eastern Sta ndard Time Zone is 5 hours behind GMT and is represent ed as GMT-5. For Eastern St andard T i me (EST),
-5:00:00. No confirmation is req uired for thes e changes.
enter

Using the Reset and Boot Functions

Selecting Administration > Reset & Boot opens a window showing the slots on the router and the contents of the various volumes on the router. With user access privileges, you can v iew this i nformation a nd also vi ew the Help i nformati on. You must have operator or manager access privileges to perform reset and boot functions.

Resetting a Slot

The slot reset function reboots the image on the selected slot. This function occupies the upper part of the Reset & Boot window. To reset a slot:
Select a slot.
1.
Click on Reset Slot.
2.
A secondary window o pens di spla ying yo ur cho ice a nd ask ing yo u to c onfir m it.
Click on Reset to reset the specified slot. Click on Cancel to terminate the
3.
operation without resetting the slot.

Booting the Router

The boot function reboots the router with the selected image and configuration files. To reboot the router:
Select the volume number and file name for both the image and
1.
configurat ion files.
You can limit the display of file names by selecting a filter in the Filter field below the File field.
Click on Reboot.
2.
A secondary window opens displaying your choices and asking you to confirm them.
300019-C Rev 00 8-3
Click on Boot to reboot the router as specified. Click on Cancel to
3.
terminate the operation without rebooting.
The following table shows the fields that you can select for the Boot function.
Field Specifies Example
Volume The volume where the configuration and image
files reside
File The name of the file or files that match the filter
criteria on the specified volume
Filter The filter to apply in selecting files on the
specified volume to display in the file window

File Manager Functions

The File Manager functions let a person with user or operator access privileges view the contents of the volumes and files in the router’s flash memory. If you have manager access privileges, you can also manage the router file system by performing operat ions s uch as cop yin g, dele ting, trans ferri ng fi le s to a nd fro m the flash, and compacting files on a selected volume.

Files Function

Choosing Administra tion > Fi le Manager > Files op ens th e Files window. Use this window to get information a bout and pe rfor m some management funct ions on t he files on a specified volume. When you select a volume from the list in the upper part of the window, the HTTP Server displays information about the files on that volume in the lower part of the window, including:
4:
bn.exe
*.exe
Total size of the volu me
Available free space
Contiguous free space To increase the contiguous free space on the volume, click on Compact. This
collects all the space from files that have been deleted and forms a single contiguous block of usable free space for new files. If the contiguous free space equals the available free space, no compacting is necessary.
300019-C Rev 00 8-4
For each file on the specified volume, the display also lists the file name, size, creation date, and creation time. You can select each listed file.
To manipulate the file using the buttons on the right side of the frame, you must have manager access privileges. First select the file by choosing its underlined link or on the check box that precedes the file name.
The following table lists the file functions a person with manager access privileges can perf orm. In eac h instance, you can tra nsfer or del ete only one fi le at a time.
Button Function
Copy Copies the conten ts of the source fi le to the destinat ion fil e. Displa ys a Copy
dialog box in which you choose a destination volume and name the destination file. You must confirm this operation.
Delete Permanently removes a file from the volume. Once a file is removed, it
cannot be recovered. You must confirm this operation.
Put Transfers a file from the host to the router. Displays a File Put dialog box in
which you can:
Choose a destination volume.
Specify or locate (browse to) a file to load to that volume.
Rename that file on the volume. You must confirm this operation. A status monitor displays the progress of
the operation.
Get Transfers a selected file from the router to the host.
Caution:
Interrupting the file put process may corrupt the volume.

Volumes Function

Choosing Administration > File Manager > Volumes opens the Volumes window. Use this window to get information about and perform management functions on the volumes on a router.
300019-C Rev 00 8-5
The following information about the volumes on the router appears in the lower part of the display frame:
Volume number
Volume state
Total size of the volu me
Available free space
Contiguous free space You can select each listed volume. To choose a list item for use with the function
buttons on the right s ide of the frame, click on the under lined link or on the check box that precedes it.
The following table lists the volume functions that a person with manager access privileges can perform.
Button Function
Create Partition Creates a partition on the router's file system. Delete Partition Permanently removes a partition from the router's file system. Compact Increases the contiguous free space on the volume, if necessary, by
collecting all the space from files that have been deleted to form a single contiguous block of usable free space for new files.
Format Reinitializes t he specified volume, removing all data from th at volume.
300019-C Rev 00 8-6
Appendix A
Site Manager Parameters
This appendix contains the Site Manager parameter descriptions for the HTTP Server. You can display the same information using Site Manager or the BCC online Help.
For each para meter, this appendix p rovides the f ollowing in formation:
Parameter name
Configuration Manager menu path
Default setting
Valid parameter options
Parameter function
Instructions for settin g the parameter
Management information base (MIB) object ID The Technician Interface allows you to modify parameters by issuing
commit
modifying parameters using Site Manager. For more information about using the Technician Interface to access the MIB, see Using Technician Interface Software.
Caution:
parameter values. Entering an invalid value can corrupt your configuration.
commands with the MIB object ID. This process is equivalent to
The Technician Interface does not verify the validity of your
set
and
300019-C Rev 00 A-1
Managing Routers Using the Web Server

Accessing HTTP Site Manager Parameters

The Edit HTTP Global Parameters window contains the parameters that you can configure for the HTTP Server. To access the Edit HTTP Global Parameters window, complete the following tasks:
Site Manager Procedure
You do this System responds
1. In the Configuration Manager window, choose
2. Choose
3. Choose
4. Choose
Protocols
Global Protocols HTTP Global
.
. The Global Protocols menu opens.
. The HTTP menu opens.
. The Edit HTTP Global Parameters
The Protocols menu opens.
window opens.
The parameter descriptions follow.
Parameter: Enable/Disable
Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global
Default: When you enable the HTTP Server, this parameter is automatically set to
Enabled.
Options: Enabled
Disabled
|
Function: Enables or disables the HTTP Server.
Instructions: To prohibit the use of th e HTTP Serve r on this inter face, set this parameter
to Disabled.
MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.2
A-2 300019-C Rev 00
Site Manager Parameters
Parameter: Port
Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global
Default: 80
Options: 0 to 4096
Function: Specifies the port number on which this server listens to requests.
Instructions: Accept the default value, 80, or specify a value from 0 to 4096. This must be a
unique TCP port number.
MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.4
Parameter: Authentication
Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global
Default: Basic
Options: Basic
Digest
|
Function: Specifies the type of authentication to use on this interface: basic or digest.
Basic authentication verifies the user’s identity using the user name and password passed over the network as clear text. Digest authentication uses an encrypted password. If your bro wser does not support digest authentica tion, you must set authentication to basic; otherwise, you cannot access the device.
Instructions: Accept the default value Basic, or specify Digest.
MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.7
Parameter: Domain Name
Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global
Default: None
Options: Any valid string of characters constituting a domain name
Function: Lets the server be accessible by a domain name, rather than by IP address. The
Domain Name parameter must be set to the domain name that a DNS lookup would return for the route r.
Instructions: Accept the default value, no domain name, to indicate that the server is
accessible only by an IP address; or specify a domain name to use instead of an IP address.
MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.8
300019-C Rev 00 A-3
Managing Routers Using the Web Server
Parameter: Help Base URL
Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global
Default: http://support.baynetworks.com/library/tpubs/
Options: Any valid uniform resource locator (URL) or -1
Function: Lets you speci fy the base URL for the HTTP Server Help files. This ba se URL,
combined with a r elat ive URL, p oints to more deta iled i nform ati on too large for storage on the router.
A value of -1 disabl es the generation of Help li nks and prevents the displa y o f a “broken links” message.
Instructions: Accept the default value unless the Help files reside at a different location, in
which case you would specify that location as the base URL. To disable this feature, specify -1.
MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.9
A-4 300019-C Rev 00
Appendix B
BCC show Commands
Use the BCC Server on the router. See Using the Bay Comman d Console (BCC) for information
show
about This chapter contains the following information about
Sample show Command
Online Help for show Commands
Show Commands for the HTTP Server
show http summary
show http requests
show http responses
show
command to display statistical information about the HTTP
scripts command syntax.
Output
show
commands:
300019-C Rev 00
B-1
Managing Routers Using the Web Server

Sample show Command Output

The
show
command displays summary information about the HTTP Server on
the router. For example, if you enter the command:
bcc>
show http summary
you see this type of output:
show http summary Mar 24, 1999 17:34:53 [GMT-5]
State : enabled Status : up Port : 80 Authentication Type : basic Domain Name : Total Requests Received: 116 Total Request Errors : 4 Total Request Discards : 0 Total Responses : 238 Total In Unknowns : 0 Total In Bytes : 24988087 Total Out Bytes : 328595 Total Timeouts : 0 Start Time : Mar 22 1999 16:57:24
To display a specific type of statistics, enter the BCC command for that statistic; for example, if you enter the command:
B-2
bcc>
show http requests
you see this type of output:
show http requests Mar 21, 1999 11:48:04 [EDT]
Method Total In In Last Time
------ -------- ---------------------------­get 186 Mar 21 1999 14:20:57 [GMT-5] head 0 trace 0 post 0 options 0 put 0 delete 0
300019-C Rev 00

Online Help for show Commands

BCC show Commands
To display a list of available command options, enter without additional options or with a question mark as an option. For example, entering
show http
show
or
show http ?
keyword (subcommand) options.
at the BCC prompt displays the list of all

Show Commands for the HTTP Server

The
show http
subcommands) available with this command. These keywords are:
•summary
requests
responses The
show http
Server activity on the router. The HTTP Server
flags, or fi lter arguments. The router shows information for all applicable entries.

show http summary

or
show http ?
<keyword>
show http
command lists the keywords (also called
command displays information about the HTTP
commands have no command arguments, filter
show
or
show
<option>
show
or
300019-C Rev 00
The
show http summary
command displays summary statistics about HTTP
services on the router. The output contains the following information:
Total Requests Received
Total Request Errors The number of received requests that were in error Total Request
Discards Total Responses The number of router responses Total In Unknowns The number of unrecognizable requests received Total Rx Octets The number of received octets Total Tx Octets The number of transmitted octets Total Time Outs The number of time outs that occurred since the last reset Start Time The time of the last router reset
The total number of requests the router received
The number of received requests that were discarded
B-3
Managing Routers Using the Web Server

show http requests

show http requests
The router. The output contains the following information:
Method An HTTP keyword indicating a type of request Total In The number of requests received for each method In Last Time The time the most recent request was received for each method

show http responses

show http requests
The router. The output contains the following information:
Status A numeric status code and a brief interpretation for a response
category Total Out The number of responses sent for each response category Out Last Time The time the most recent response was sent for each response
category
command displays HTTP request statistics for the
command displays HTTP response statistics for the
B-4
300019-C Rev 00
A
access control filtering, 1-9 acronyms, xv
,
,
2-3
A-3
administration folder icon administration functions, 8-1 administrative status of a port, changing, 7-1
,
alert, circuit AppleTalk statistics, 7-3 authentication
basic configured digest
Authentication parameter
4-2
,
1-8
,
5-3
,
1-9
B
basic access authentication, 1-8 BCC show command, B-1
,
BCC, using to start the HTTP Server boot function, 8-3 BootP statistics, 5-2
,
browser requirements
1-1
1-3
C
cascading style sheets, 1-1
,
changing HTTP parameters circuit alert
,
displaying compact volume configuration files, initial, 1-2 configuration statistics, HTTP, 5-3 contiguous space
4-2
,
8-4
,
8-4
1-10
conventions, text counters, HTTP, 5-3 customizing HTTP parameters, 1-10
,
xiv
D
date and time, setting, 8-2 debug event, meaning, 4-4
,
device monitoring digest authentication, 1-9 DNS, 1-9 documentation domain name
configured domain name instead of IP address, 1-9 Domain Name parameter
3-1
,
8-1
,
5-3
,
1-9, A-3
E
Edit HTTP Global Parameters window, A-2
,
educational services Enable/Disable parameter, A-2 enabling HTTP Server, 1-1 Ethernet port statistics event
,
viewing event log
filtering
interpreting
severity levels Events icon, 4-2
4-2
,
4-3
xvi
,
3
,
4-3
,
4-4

Index

300019-C Rev 00
Index-1
F
fault event, meaning, 4-4 FDDI port statistics, 3
,
File Manager functions Files function, 8-4 filtering the event log, 4-3 flash memory card folder icon, 2-3 frames, 1-1
,
FTP statistics
5-2
8-4
,
1-2
G
getting help, 3-1
,
Greenwich Mean Time (GMT)
8-2, 8-3
H
hardware icon, 3-3
,
1-10
,
,
5-3
,
3-1
B-4
,
5-3
1-11
,
5-3
,
B-4
Help Base URL Help Base URL parameter, A-4 help for show commands, B-3 Help icon, 8-1 help, getting HSSI port statistics, 4 HTTP authentication, configured, 5-3 HTTP configuration statistics HTTP counters, 5-3 HTTP domain name, 5-3 HTTP parameters, customizing
,
BCC
Site Manager HTTP port HTTP request statistics, 5-4 HTTP requests, 5-6 http requests HTTP response statistics, 5-4 HTTP responses, 5-6 http responses, show command
HTTP Server
concepts, 2-1
,
,
1-1
,
5-6
,
5-3
5-6
,
, ,
5-2
A-3
,
,
A-3
A-2
A-4
,
1-1
,
5-6
starting starting and configuring
statistics HTTP server configuration statistics, 5-6 HTTP Site Manager parameter
Authentication
Domain Name
Enable/Disable
Help Base URL HTTP state, 5-3 HTTP statistics
viewing HTTP status, 5-3 HTTP summary statistics http summary, show command, B-3 httpreq.dat, 5-6 httpresp.dat httpsrv.dat, 5-6 httpsum.dat, 5-6
I
ICMP statistics, 7-2 icon
,
4-2
,
,
2-3
8-1
2-3
administration folder
Circuit Alert
Events
Hardware
help
,
Info
Manuals
Release Notes
Support
support folder
tasks in last time, HTTP statistic, 5-4 info event, mea nin g, 4-4 Info icon install.bat script, 1-2 IP access control filter, 1-9
,
,
4-2
,
3-3
,
8-1
3-3
,
8-1
,
8-1
,
3-3
,
3-3
Index-2
300019-C Rev 00
IP address
,
replacing with domain name
IP statistics, 7-2
,
IPX statistics
7-3
1-9
J
Java applets, 1-1
M
Manuals icon, 8-1 method, HTTP statistic, 5-4
,
modifying HTTP parameters monitoring device operation, 3-1
1-10
N
network address filterin g, 1-9
O
online help for show commands, B-3 out last time, HTTP statistic, 5-4
P
parameters
,
Site Manager Port parameter port statistics, 1
Ethernet
FDDI port
,
HSSI
,
serial
traffic (all) port status, changing, 7-1 port, HTTP, 5-3 port, troubleshooting product support, xvi protocol statistics, 7-1 publications, Bay Networks
A-1
,
A-3
,
3
,
3 4 3
,
2
, 2,
7-2
,
xvi
Q
Quick-Start procedure, 1-2
R
reboot router, 8-3 received (rx) octets, HTTP statistic, 5-4 Release Notes icon, 8-1
,
request discards, HTTP statistic request errors, HTTP statistic, 5-3 request statistics, 5-6 requests received, HTTP statistic requests, show, B-4 requirements, browser, 1-1
,
reset slot response (status) code, 5-4 response statistics, 5-6 responses
router
router monitoring, 3-1 router protocol statis ti cs, 7-1 router reboot router statistics, 5-1
8-3
HTTP statistic show command
specifying
,
3-2
,
8-3
,
5-4
,
B-4
5-3
,
5-3
S
security, setting, 1-4 serial port statistics, 3 server configuration statistics, 5-6
,
,
,
B-3
B-2
,
4-4
B-3
severity levels, events show command, BCC, B-1 show commands
command syntax
,
B-2
config
