Avaya Managing Routers HTTP Server User Manual

Managing Routers Using the HTTP Server

BayRS Version 13.10 Site Manager Software Version 7.10

Part No. 300019-B Rev. 00 November 1998

4401 Great America Pa rkw ay 8 Federal S treet Santa Clara, CA 95054 Billerica, MA 01821

and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty. Users must tak e full re spo nsibility fo r th eir a pplic atio ns o f a ny products specifi ed in th is d ocume nt . The information in this document is proprietary to Bay Networks, Inc.

The software described in this document is furnished under a license agreement and may only be used in accordance with the terms of that license. A summary of the Software License is included in this document.

Trademarks

AN, BCN, BLN, BN, and Bay Networks are registered trademarks and BayRS, BCC, and the Bay Networks logo are trademarks of Bay Networks, Inc.

Internet Explorer, Microsoft, MS, MS-DOS, Win32, Windows, and Windows NT are registered trademarks of Microsoft Corporation.

All other trademarks and registered trademarks are t he property of their respective owners.

Restricted Rights Legend

Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer So ftware clause at DFARS 252.227-7013.

Notwithstanding any other license agreement that may pertain to, or accompany the delivery of, this computer software, the rights of the United States Government regarding its use, reproduction, and disclosure are as set forth in the Commercial Computer Software-Restricted Rights cl ause at FAR 52.227-19.

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, Bay Networks, Inc. reserves the right to make changes to the pr oducts described in this document without notice.

Bay Networks, Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.

Portions of the code in this software product may be Copyright © 1988, Regents of the University of California. All rights reserved. Redistribution and use in source and binary forms of such portions are permitted, provided that the above copyright notice and this paragraph are duplicated in all such forms and that any documentation, advertising materials, and other materials related to such distribution and use acknowledge that su ch portions of the software were developed by the University of California, Berkeley. The name of the University may not be used to endorse or promote products derived from such portions of the software without specific prior written permission.

SUCH PORTIONS OF THE SOFTWARE ARE PROVIDED “AS IS” AND WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

In addition, the program and information contained herein are licensed only pursuant to a license agreement that contains restricti ons on use and disclosure (that may incorporate by reference certai n limitations and no tices imposed by third parties).

Bay Networks, Inc. Software License Agreement

NOTICE: Please carefully read this license agre ement before copying or using the accompanying software or installing the hardware unit with pre-enabled software (each of which is referred to as “Software” in this Agreement).

300019-B Rev. 00

BY COPYING OR USING THE SOFTWARE, YOU ACCEPT ALL OF THE TERMS AND CONDITIONS OF THIS LICENSE AGREEMENT. THE TERMS EXPRESSED IN THIS AGREEMENT ARE THE ONLY TERMS UNDER WHICH BAY NETWORKS WILL PERMIT YOU TO USE THE SOFTWARE. If you do not accept these terms and conditions, return the product, unused and in the original shipping container, within 30 days of purchase to obtain a credit for the full purchase price.

1. License Grant. Bay Networks, Inc. (“Bay Networks”) grants the end user of the Software (“Licensee”) a personal, nonexclusive, nontransferable license: a) to use the Software either on a single computer or, if applicable, on a single authorized device identified by host ID, for which it was originally acquired; b) to copy the Software solely for backup purposes in support of authorized use of the Software; and c) to use and copy the associated user manual solely i n support of authorized use of the Software by Licensee. This license applies to the Software only and does not extend to Bay Networks Agent software or other Bay Networks software products. Bay Networks Agent software or other Bay Networks software products are licensed for use under the terms of the applicable Bay Networks, Inc. Software License Agreement that accomp anies such software and upon payment by the end user of the applicable license fees for such software.

2. Restrictions on use; reservation of rights. The Software and user manuals are protected under copyright laws. Bay Networks and/or it s licensors retain all title and ownership in both the Software and user manuals, including any revisions made by Bay Networks or i ts licensors. The copyr ight notice must be reproduced and included with any copy of any portion of the Software or user manuals. Licensee may not modify, translate, decompile, disassemble, use for any competitiv e analysis, re v erse engineer , distrib ute, or create deriv ati ve works from the Softwa re or user manuals or any copy, in whole or in part. Except as expressly provided in this Agreement, Licensee may not copy or transfer the Software or user manuals, in whole or in part. The Soft ware and user manuals embody Bay Networks’ and its licensors’ confidential and proprietary intellectual property. Licensee shall not sublicense, assign, or otherwise disclose to any third party the Software, or any information about the operation, design, performance, or implementation of the Software and user manuals that is confidential to Bay Networks and its licensors; however, Licensee may grant permission to its consultants, subcontractors, a nd agents to use the Softw are at Licensee’s facility, provided they have agreed to use the Software only in accordance with the terms of this license.

3. Limited warranty. Bay Networks warrants each item of Software, as delivered by Bay Networks and properly installed and operated on Bay Networks hardware or other equipment it is originally licensed for, to function substantially as described in its accompanying user m anual during its warranty period , which begins on the date Software is first shipped to Licensee. If an y item of S oftware f ails to so function d uring its w arranty period, as the sole remedy Bay Networks will at its discretion provide a suitable fix, patch, or workaround for the problem that may be included in a future Software release. Bay Network s fur ther w arra nts to Licen see that the medi a on which the Software is provided will be free from defec ts in materials and wo rkman ship under no rmal use for a peri od of 90 da ys from the date Software is first shipped to Licensee. Bay Networks will replace defective media at no charge if it is returned to Bay Netw orks during the warran ty perio d alon g with proof of the date of shipment . This war ranty do es not apply if the media has been dam aged as a resul t of acci dent, misuse , or ab use. The Licen see assumes all re sponsibilit y for selection of the Software to achieve Licensee’s intended results and for the installation, use, and results obtained from the Software. Bay Networks does not warrant a) that the functions contained in the software will meet the Licensee’ s requireme nts, b) that the Software will operate in the hardw are or soft wa re c ombi nations th a t the L icensee may select, c) that the operation of the Softw a re will be uninterru pte d or error free, or d) that all defec ts in the operation of the Software will be corrected. Bay Networks is not obligated to remedy any Software defect that cannot be reproduced with the latest Software release. These warranties do not apply to the So ftw are if i t has been (i) altered, except by Bay Netwo rks or in a ccordance with its instru ction s; (ii) used in con junc tion with another v en dor’s product, resulting in the defect; or (iii) damaged by improper environment, abuse, misuse, accident, or negligence. THE FOREGOING WARRANTIES AND LIMITATIONS ARE EXCLUSIVE REMEDIES AND ARE IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING W ITHOUT LIMITATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Licensee is responsible for the security of its own data and information and for maintaining adequate procedures apart from the Software to reconstruct lost or altered files, data, or programs.

4. Limitation of liability. IN NO EVENT WILL BAY NETWORKS OR ITS LICENSORS BE LIABLE FOR ANY COST OF SUBSTITUTE PROCUREMENT; SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES; OR ANY DAMAGES RESULTING FROM INACCURATE OR LOST DATA OR LOSS OF USE OR

300019-B Rev. 00

iii

PROFITS ARISING OUT OF OR IN CONNECTION WITH THE PERFORMANCE OF THE SOFTWARE, EVEN IF BAY NETWORKS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL THE LIABILITY OF BAY NETWORKS RELATING TO THE SOFTWARE OR THIS AGREEMENT EXCEED THE PRICE PAID TO BAY NETWORKS FOR THE SOFTWARE LICENSE.

5. Government Licensees. This provision applies to all Software and documentation acquired directly or indirectly by or on behalf of the United States Government. The Software and documentation are commercial products, licensed on the open market at market prices, and were developed entirely at private expense and without the use of any U.S. Government funds. The license to the U.S. Government is granted only with restricted rights, and use, duplication, or disclosure by the U.S. Government is subject to the restrictions set forth in subparagraph (c)(1) of the Commercial Computer Software––Restricte d Rig hts cla u se o f FAR 52.227-19 and the limitatio ns set o ut in this license for civilian agencies, and subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause of DFARS

252.227-7013, for agencies of t he Department of Defense or their successors, whichever is applicable.

6. Use of Software in the European Community. This provision applies to all Software acquired for use within the European Community. If Licensee uses the Software within a country in the European Community, the Software Directive enacted by the Council of European Commun ities Directive dated 14 May, 1991, will apply to the examination of the Software to facilitate interoperability. Licensee agrees to notify Bay Networks of any such intended examination of the Software and may procure support and assistance from Bay Networks.

7. Term and termination. This license is effective until terminated; however, all of the restrictions with respe ct to Bay Networks’ copyright in the Software and user manuals will cease being effective at the date of expiration of the Bay Networks copyright; those restrictions relating to use and disclosure of Bay Networks’ confidential information shall continue in effect. Licensee may terminate this license at any time. The license will automatically terminate if Licensee fails to comply with any of the terms and conditions of the license. Upon termination for any reason, Licensee will immediately destroy or return to Bay Networks the Software, user manuals, and all copies. Bay Networks is not liable to Licensee for damages in any form solely by reason of the termination of this license.

8. Export and Re-export. Licensee agrees not to export, directly or indirectly, the Software or related technical data or information without first obtaining any required export licenses or other governmental approvals. Without limiting the foregoing, Licensee, on behalf of itself and its subsidiaries and affiliates, agrees that it will not, without first obtaining all export licenses and approvals required by the U.S. Government: (i) export, re-export, transfer, or divert any such Software or technical data, or any direct product thereof, to any country to which such exports or re-exports are restricte d or em b argoed under United States expor t con t ro l la w s an d r egulations, or to an y national or resident of such restricted or embargoed countries; or (ii) provide the Software or related technical data or information to any military end user or for any military end use, including the design, development, or production of any chemical, nuclear, or biological weapons.

9. General. If any provision of this Agreement is held to be invalid or unenf orceable by a court of competent jurisdiction, the remainder of the provisions of this Agreement shall remain in full force and effect. This Agreement will be governed by the laws of the state of California.

Should you have any questions concerning this Agreement, contact Bay Networks, Inc., 4401 Great America Parkway, P.O. Box 58185, Santa Clara, California 95054- 8185.

LICENSEE ACKNOWLEDGES THAT LICENSEE HAS READ THIS AGREEMENT, UNDERSTANDS IT, AND AGREES TO BE BOUND BY ITS TERMS AND CONDITIONS. LICENSEE FURTHER AGREES THAT THIS AGREEMENT IS THE ENTIRE AND EXCLUSIVE AGREEMENT BETWEEN BAY NETWORKS AND LICENSEE, WHICH SUPERSEDES ALL PRIOR ORAL AND WRITTEN AGREEMENTS AND COMMUNICATIONS BETWEEN THE PARTIES PERTAINING TO THE SUBJECT MATTER OF THIS AGREEMENT. NO DIFFERENT OR ADDITIONAL TERMS WILL BE ENFORCEABLE AGAINST BAY NETWORKS UNLESS BAY NETWORKS GIVES ITS EXPRESS WRITTEN CONSENT, INCLUDING AN EXPRESS WAIVER OF THE TERMS OF THIS AGREEMENT.

iv 300019-B Rev. 00

Preface

Before You Begin .............................................................................................................. ix

Text Conventions ...............................................................................................................x

Acronyms ........................... .......................... .......................... ......................... .................. xi

Bay Networks Technical Publications ............................................................................... xi

How to Get Help ...............................................................................................................xii

Chapter 1 Starting and Configuring the HTTP Server

Browser Requirements ...................................................................................................1-1

Starting the HTTP Server Using install.bat .....................................................................1-2

Starting the HTTP Server Using the BCC or Site Manager ............................................1-3

Setting HTTP Server Security ........................................................................................1-4

User Name/Password Security Concepts ................................................................1-5

Basic Access Authentication ................. ...... ....... ...................................... ....... ...... ...1-5

Digest Authentication ...............................................................................................1-6

Network Address Filtering ..............................................................................................1-6

Using a Domain Name Instead of an IP Address ...........................................................1-6

Customizing HTTP Parameters ......................................................................................1-7

Chapter 2 HTTP Server Concepts

What the HTTP Server Does ..........................................................................................2-1

Navigating the HTTP Server Interface ............................................................................2-2

Chapter 3 Monitoring Routers Using the HTTP Server

Getting Help ....................................................................................................................3-1

Specifying a Router to Monitor .......................................................................................3-2

Viewing Overall System Status .......................................................................................3-2

300019-B Rev. 00

Chapter 4 Monitoring Circuit Alerts and Events

Fault Icon ........................................................................................................................4-1

Displaying Circuit Alerts ..................................................................................................4-2

Viewing the Event Log .................... ...... ....... ...... ....... ...... ....................................... ...... ...4-2

Filtering What the Event Log Shows ........................................................................4-3

Interpreting Event Messages ...................................................................................4-3

Chapter 5 Viewing Router Services Statistics

Router Services Statistics ..............................................................................................5-1

Using the HTTP Server to View HTTP Statistics ............................................................5-3

HTTP Configuration Statistics ..................................................................................5-3

HTTP Counters ........................................................................................................5-3

HTTP Request Statistics ..........................................................................................5-4

HTTP Response Statistics .......................................................................................5-4

Using the Statistics Manager to View HTTP Server Statistics ........................................5-4

Selecting the Windows to Display ............................................................................5-5

Starting the Statistics Launch Facility ......................................................................5-5

Viewing HTTP Statistics ........................ ...... ....... ...... ....... ...... ...... ....... ...... ................5-5

Chapter 6 Viewing Router Port Statistics

Changing the Administrative Status of a Port .................................................................6-2

Viewing Traffic Statistics for All Ports ..............................................................................6-2

Viewing Ethernet Port Statistics .....................................................................................6-2

Viewing Serial Port Statistics ..........................................................................................6-3

Viewing FDDI Port Statistics ...........................................................................................6-3

Viewing HSSI Port Statistics ...........................................................................................6-4

Viewing Token Ring Port Statistics .................................................................................6-4

Chapter 7 Viewing Router Protocol Statistics

Changing the Administrative Status of a Port .................................................................7-1

Viewing IP Statistics .................................... ...... ....... ...... ....... ...... ...... ....... ...... ....... ...... ...7-2

Viewing IPX Statistics ........ ...... ....... ...... ....................................... ...... ....... ...... ....... ...... ...7-2

Viewing AppleTalk Statistics .............................. ....... ...... ....... ...... ...................................7-3

300019-B Rev. 00

Appendix A Site Manager Parameters

Site Manager Parameters .............................................................................................. A-2

Appendix B Show Commands for the HTTP Server

Sample show Command Output ................................................................................... B-2

Online Help for show Commands .................................................................................. B-2

Show Commands for the HTTP Server ......................................................................... B-3

show http summary ................................................................................................. B-3

show http requests .................................................................................................. B-4

show http responses ............................................................................................... B-4

Index

300019-B Rev. 00

vii

Preface

This guide describes how to configure and use the Bay Networks® HTTP Server, an embedded Web-based router management tool include d with the Bay Networ ks router operating system software and accessible from any standard Web browser. Using HTTP Server software, you can monitor network devices, viewing summary, fault, and statistical information on a

device-by-device basis.

You can use the Bay Command Conso le (BCC HTTP Server software on a router. In this guide, you will find configuration instructions using both the BCC and Site Manager.

Before You Begi n

Before using this guide, you must complete the following procedures. For a new router:

• Install the router (see the installation guide that came with your router).

• Connect the router to the network and create a pilot configuration file (see

Quick-Starting Routers

• Configure IP on the router (see Make sure that you are running the latest version of Bay Networks BayRS

Site Manager software. For information about upgrading BayRS and Site Manager, see the upgrading guide for your version of BayRS.

™

) or Site Manager t o conf i gure the

Configuring IP Services

™

and

300019-B Rev. 00

Managing Routers Using the HTTP Server

Text Con ventions

This guide uses the following text conventions:

angle brackets (< >) Indicate that you choose the text to enter based on the

description inside the brackets. Do not type the brackets when entering the command.

Example: If the command syntax is:

ping <

ip_address

ping 192.32.10.12

, you enter:

bold text

Indicates command names and options and text that you need to enter.

Example: Enter

show ip {alerts | routes

Example: Use the

dinfo

command.

braces ({}) Indicate required elements in syntax descriptions

where there is more than one option. You must choose only one of the options. Do not type the braces when entering the command.

Example: If the command syntax is:

show ip {alerts | routes show ip alerts or show ip routes

}

, you must enter either:

, but not both.

brackets ([ ]) Indicate optional elements in syntax descriptions. Do

not type the brackets when entering the command. Example: If the command syntax is:

show ip interfaces [-alerts show ip interfaces

]

, you can enter either:

show ip interfaces -alerts

ellipsis points (. . . ) Indicate that you repeat the last element of the

command as needed. Example: If the command syntax is:

ethernet/2/1 [< ethernet/2/1

and as many parameter-value pairs as

parameter> <value

>] . . .

, you enter

needed.

300019-B Rev. 00

Preface

italic text Indicates file and directory names, new terms, book

titles, and variables in command syntax descriptions. Where a variable is two or more words, the words are connected by an underscore.

Example: If the command syntax is:

show at <

valid_route

is one variable and you substitute one value

for it.

screen text Indicates system output, for example, prompts and

system messages. Example:

Set Bay Networks Trap Monitor Filters

separator ( > ) Shows menu paths.

Example: Protocols > I P ide nti fies the IP option on the Protocols menu.

vertical line (

) Separates choices for command keywords and

arguments. Enter only one of the choices. Do not type the vertical line when entering the command.

Example: If the command syntax is:

show ip {alerts | routes}, you enter either: show ip alerts or show ip routes, but not both.

300019-B Rev. 00

Managing Routers Using the HTTP Server

Acronyms

ARP Address Resolution Protocol BootP Bootstrap Protocol FDDI Fiber Distributed Data Interface FTP File Transfer Protocol HSSI High-Speed Sserial Interface HTTP Hypertext Transfer Protocol ICMP Internet Control Message protocol IP Internet P rotocol IPX Internet Packet Exchange MAC media access control RIP Routing Information Protocol SAP Service Advertising Protocol SMDS Switched Multimegabit Data S ervice SNMP Simple Network Management Protocol TCP Transaction Control Protocol

Bay Networks Technical Publications

You can now print Bay Networks technical manuals and release notes free, directly from the Internet. Go to support.baynetwork s.com/libr ary/ tpubs/ . Fi nd the Bay Networks product for which you need documentation. Then locate the specific category and model or ve rsion for your hardware or software product. Using Adobe Acrobat Re ader, you can open the manuals and rel ease n otes, searc h for the sections you need, and print them on most standard printers. You can download Acrobat Reader free from the Adobe Systems Web site, www.adobe.com.

You can purchase Bay Networks documentation sets, CDs, and selected technical publications through the Bay Networks Collateral Catalog. The catalog is located on the World Wide Web at support.baynetworks.com/catalog.html and is divided into sections arranged alphabetically:

xii

300019-B Rev. 00

• The “CD ROMs” section lists available CDs.

• The “Guides/Books” section lists books on technical topics.

• The “Technical Manuals” section lists available printed documentation sets. Make a note of the part numbers and prices of the items that you want to order.

Use the “Marketing Collateral Catalog description” link to place an order and to print the order form.

How to Get Help

For product assistance, support contracts, or information about educational services, go to the following URL:

http://www.baynetworks.com/corporate/contacts/

Or telephone the Bay Networks Technical Solutions Center at: 800-2LANWAN

Preface

300019-B Rev. 00

xiii

Managing Routers Using the HTTP Server

xiv

300019-B Rev. 00

Chapter 1

Starting and Configuring the HTTP Server

The Bay Networks HTTP Server is an embedded Web-based router management tool included with the Bay Networks router operating system software and accessible from any sta ndard Web browser . Using HTTP Ser ver soft ware, you can monitor network de vices, viewi ng summary, fault, and statisti cal i nforma tion o n a device-by-device basis.

Before you can use the HTTP Server to monitor a router, you must configure and enable the HTTP Server software on the router using the Quick-Start installation script install.bat, the Bay Command Console (BCC™), or Site Manager.

Browser Requirements Starting the HTTP Server Using install.bat

Starting the HTTP Server Using the BCC Starting the HTTP Server Using Site Manager

Setting HTTP Server Security

Go to “Starting and Configuring the HTTP Server.”

Browser Requirements

Your Web browser must support frames, Java applets, and cascading style sheets; for example, Netscape 4.0 or higher and Microsoft higher. If you have changed the default settings for these browsers, you must ensure that Java is enabled. If you configure digest authentication, your browser must be enabled for this capability; oth erwise, authentication reverts to basic.

Caution:

security reasons, it is wise not to store your password.

300019-B Rev. 00 1-1

Internet Explorer lets you store your browser password. For

Internet E xplorer® 4.0 or

Managing Routers Using the HTTP Server

Go to “Starting and Configuring the HTTP Server.”

Starting the HTTP Serve r Us ing

A new router comes wit h a flash mem ory card containing the software im age for the router, two configuration files (config and ti.cfg), and the Quick-Start script install.bat.

The Quick-Start installation scr ipt creates an initial IP network interface on the router, so that your router can communicate with the configuration workstation from which you will manage the rout er. The install.bat script prompts you t o enter the network information that dynamically configures the initia l IP interface .

As the following example shows, the script asks whether you want to enable HTTP. Answer yes to this question. (The default is no.)

Step 7. Enable HTTP

Enable the HTTP (Web) Server

----------------------------

Do you want to enable the HTTP (Web) server? (y/n)[n]:

HTTP server enabled.

Note:

For complete ins truct ion s on runn ing the ins tall. bat scr ipt an d verif ying

that the installation is successful, see Quick-Starting Routers.

install.bat

When you enable the HTTP Ser ver duri ng the Qui ck-St art pr ocedur e, you ca n use the HTTP Server with its default configuration settings after completing the install.bat procedure. For information on modifying the default HTTP Server settings, see Customizing HTTP Parameters

After you run the install.bat script, you can install Site Manager software, as described in Quick-Starting Routers.

Go to “Starting and Configuring the HTTP Server

1-2 300019-B Rev. 00

.”

Starting and Configuring the HTTP Server

Starting the HTTP Serve r Us ing the BCC or Site Manager

If you did not use the Quick-Start procedure to start the HTTP Server, you can start it using the BCC or Site Manager. When you complete this procedure, the HTTP Server software is configured on the router. Before you start the HTTP Server, verify that you have configured IP on an interface.

You can start the HTTP Server using default values for all parameters. For information on modifying the default HTTP Server settings, see Customizing

HTTP Parameters.

Using the BCC

Adding the HTTP Server to a router automatically loads TCP on all slots. To add the HTTP Server to a router, navigate to the box prompt and enter:

http

For example, the following command adds HTTP Server to a router:

box#

http

http#

Go to “Starting and Configuring the HTTP Server.”

300019-B Rev. 00 1-3

Managing Routers Using the HTTP Server

Using Site Manager

You can configure HTTP Server software in any Configuration Manager mode. To start HTTP Server software, complete the following tasks:

You do this System responds

Site Manager Procedure

1. In the Configuration Manager window,

Protocols

choose

2. Choose

3. Choose

4. Choose

5. Choose

6. Choose

7. Choose

8. Choose

Global Protocols TCP Create TCP

Protocols Global Protocols HTTP Create HTTP

. The Global Protocols menu opens.

. The TCP menu opens.

. You return to the Configuration Manager

. The Protocols menu opens.

. The Global Protocols menu opens.

. The HTTP menu opens.

. You return to the Configuration Manager

Go to “Starting and Configuring the HTTP Server

Setting HTTP Server S ecurity

The HTTP Server allows access to device information from anywhere in the network. To protect your network information, you can implement security controls. The HTTP Server offers access control through: user name/password security, basic access or digest authentication, and network address filtering.

The Protocols menu opens.

window.

.”

User Name/Password Security Concepts Basic Access Authentication Digest Authentication Network Address Filtering

1-4 300019-B Rev. 00

User Name/Password Security Concepts

The HTTP Server control s access to network device i nf ormation by grouping that information into col le ction s, call ed realms, that share the same secu rity at tri butes. The HTTP Server defines two security realms on the router: User and Manager. These are the same as the login names for the Technician Interface. Similarly, a user name/password authorization mechanism controls access to each realm.

• User access privileges let you view information.

• Manager access pri vil eges g rant c omple te ac cess t o the r out er, letting you, for example, enable and disable an interface.

Before allowing any Manager-level operations, however, the HTTP Server requires that the system administrator set a nonnull Manager password. If the system administrator does not set a User password, the HTTP Server accepts an empty (null) string as the password. Generally, the system administrator sets passwords using Technician Interface commands, just as for console access through the Technician Interface.

If you have User privileges and attempt to access information requiring Manager privileges (or, if you attempt to use the Manager login with a null password), the HTTP Server prompts you for the Manager password. If you do not provide the appropriate password, an error message appears, and you cannot perform that operation. You control the level of access authentication protection when you configure the Authentication parameter.

Starting and Configuring the HTTP Server

For specific information about how to set user names and passwords, see Using Technician Interface Software. For information about securing a router as part of the Quick-Start procedure, see Quick-Starting Routers.

Basic Access Authentication

In basic access authentication, the user name and password are passed over the network as c lear text. While this serves to verify the identity of the user, the information is vulnerable to anyone with a sniffer or similar device.

300019-B Rev. 00 1-5

Managing Routers Using the HTTP Server

Digest Authentication

Digest authenticati on, based on RFC 2069, uses an encrypte d password to verif y a user’s identity. Like basic access authentication, digest uses a challenge-response model. To use digest authentication, you must configure the HTTP Server Authentication parameter as digest and your browser must be capable of supporting digest authentication. If your browser lacks this capability, the HTTP Server reverts to basic authentication.

Network Address Filtering

For additional security, you can implement IP access control filters when you configure IP on the router. These filters further restrict access to the router, limiting access to specific IP addresses or IP address ranges.

You must also ensure that IP is appropriately configured to support HTTP. To do this, you must ensure that:

• The configuration for the IP service also has HTTP configured.

• The appropriate access policy filters are configured for HTTP.

Specify these req uirements as part of the I P configur ation process, us ing the BCC. For additional information about IP access control filters and how to configure them, see Configuring IP Utilities. For general instructions about using the BCC, see Using the Bay Command Console (BCC).

Using a Domain Name Instead of an IP Address

By specifying the Domain Name parameter, you let the server be accessible by a domain name, rather than by IP address. The Domain Name parameter must be set to the domain name that a DNS lookup would return for the router. The name can consist of any valid string of characters that constitute a domain name.

Accept the default value, no doma in name, to ind icate that the serv er is acc essib le only by the IP address; or specify a domain name to use instead of the IP address.

Go to “Starting and Configuring the HTTP Server

1-6 300019-B Rev. 00

.”

Customizing HTTP Parameters

Adding the HTTP Server to a router automatically enables HTTP on the router using port 80, sets acce ss authen ticati on to basic, an d uses the IP addr ess to access the router. You can change these settings using either the BCC or Site Manager.

Using the BCC

To change these parameter settings, first navigate to the http prompt. To disable http on the router, enter:

disable

For example:

http#

To change the port number, enter:

port

For example:

http#

disable

port_number>

port 81

Starting and Configuring the HTTP Server

To specify access authentication level, enter:

digest

basic

For example, the following command configures digest authentication:

http

box# http# http#

digest

To specify the use of a domain name for the router, enter:

domain-name

domain_name>

For example, the following command allows the use of the domain name, “myrouter”:

http#

domain-name myrouter

Go to “Starting and Configuring the HTTP Server.”

300019-B Rev. 00 1-7

Managing Routers Using the HTTP Server

Using Site Manager

To configure or change the HTTP Server parameters, first create HTTP on the router, then complete the following tasks:

You do this System responds

Site Manager Procedure

1. In the Configuration Manager window, choose

Protocols > Global Protocols >

HTTP > Global

2. Set the

Enabled Disabled

3. Specify t he enabled the HTTP Server.

4. Set the

Basic

5. Specify t he router. To use the IP address instead of a domain name, leave this parameter value blank.

6. Click on OK. You return to the Configuration Manager

Enable/Disable

Authentication

parameter to

to enable the HTTP Server or to

to disable the HTTP Server.

number on which you

Port

parameter to

Digest

Domain Name

to use for the

Go to “Starting and Configuring the HTTP Server

The Edit HTTP Global Parameters window opens.

window.

.”

1-8 300019-B Rev. 00

Chapter 2

HTTP Server Concepts

HTTP Server software lets you access device information from anywhere in the network using any standard Web browser that conforms to HTTP and HTML specifications. The HT TP Ser ver is par t o f t he r outer operating system for al l Bay Networks non-VME-based GAME routers. This chapter provides an overview of the HTTP Server.

What the HTTP Server Does Navigating the HTTP Server Interface

To obtain Web-accessible data, you must configure the HTTP Server software on the router. Chapter 1, “Starting and Configuring the HTTP Server the configuration procedure.

What the HTTP Server Does

The HTTP Server is a graphical user interface (GUI) that lets you view real-time device summaries, events, alerts, and statistics. The HTTP Server graphically displays information similar to (and a superset of) the text-only information available through the BCC point-and-clic k interfa ce, you also have dir ect acces s to online document ation and Bay Networks Technical Support.

The information that you gather through the HTTP Server interface can help you monitor your network’s performance on a device-by-de vice basis. You can see, for example, where congestion is occurring or where transmission or reception problems exist. For detailed information about interpreting this information, refer to Troubleshooting Routers and Event Messages for Routers.

show, enable

, and

disable

,” summarizes

commands. Through this

300019-B Rev. 00 2-1

Managing Routers Using the HTTP Server

You see a multiframe window when you specify a device in your browser’s location field or when you cli ck on the Su mmary folder icon, the n on the In fo icon in the navigational frame.

• Banner -- The top frame shows the Bay Networks logo and the device type. The banner also identifies the device by name, specifies its physical location and IP address, and lists the name of the contact person responsible for that device. The IP address is a link that you can click on to establish a Telnet connection to the device.

• Navigational frame -- The frame on the left contains links to each m onitored function. Initially, these links are all folders. The folders (and the documents they contain) in the navigational frame are active links to device information.

• Display frame -- The lar ge fr ame on the lower right side displa ys the retr ieved web data.

Navigating the HTTP Server Interface

The navigational frame contains the following expandable folders:

• Summary -- System informa tion, hardware status, PR OM information, software image information, system resource information, and system task information

• Fault -- Circuit alerts and the event log

• Statistics -- Services, ports, and protocols

• Support -- Help, release notes, technical manuals, and customer support links

Click on each folder in turn to display the information for t he device you are monitoring.

• To show the types of data a folder contains, click on the folder icon. The folder opens, revealing document icons representing the types of data within that folder.

• To view a specific data type within a folder, click on its document icon.

• To close (that is, collapse) a folder’s contents, click again on the folder icon.

2-2 300019-B Rev. 00

Chapter 3

Monitoring Routers Using the HTTP Server

This chapter describes how to use the HTTP Server to monitor the operation of individual routers on your network. For specific descriptions of how to use the information from the HTTP (Web) Server to troubleshoot the devices in your network, refer to Troubleshooting Routers.

Getting Help Specifying a Router to Monitor Viewing Overall Syst em Status

Info Hardware PROMs Software Resources Tasks

Getting Help

For this information Click on Support, then on

HTTP Server interface help Help icon Release Notes Release Notes icon Bay Networks documentation Documentation icon Bay Networks technical support Bay Networks Technical Solutions Center icon

After opening one o f these l inks, choose Fil e > Close to ret urn to t he HTTP Ser ver page on the Web browser. Clicking on File > Exit shuts down the browser. The Back button may not be available on linked pages.

300019-B Rev. 00 3-1

Managing Routers Using the HTTP Server

Go to “Monitoring R outers Using the HTTP Server.”

Specifying a Router to Monitor

Start your Web browser.

In the Location field, enter:

http://<

router_IP_address

router_IP_address>

is an IP address on the device that you want to monitor, for

example:

http://192.168.12.54

The browser displays a summary window for the specified device. Go to “Monitoring R outers Using the HTTP Server

Viewing Overall System Status

Use the summary information to get an overall picture of the operational state of the router. The summary provides hardware and software information including this router’s configuration and its internal resource usage. To see the types of summary information available, click on the Summary folder icon in the navigational frame.

.”

3-2 300019-B Rev. 00

Monitoring Routers Using the HTTP Server

The following table lists the icons within the Summary folder and the information that each displays when you click on it.

Shows

Icon

Info System • Device name -- the mnemonic name that the

Hardware Specific device • Model name and serial number

PROMs PROM modules

Software Software image

Resources System

Tasks System tasks on

information for Displayed summary information

system administrator assigns

• Location -- the location, as defined by the system administrator

• Contact person responsible for that device, as defined by the system administrator

• Up time -- the time elapsed since the last device reset

• MIB version -- the version number of the management information base (MIB) for the router software

• Software version -- the version number and creation date and time of the router software image

• Type, revision, and serial number of the processor and link module in each slot.

For the Boot PROM and for the Diagnostic PROM

in the device

on the specified device

resources on the specified hardware device

the specified hardware device

in that slot:

• Revision number

• Date and time of installation

For each router slot:

• Name of the software image file

• Source of that imag e

• Date and time the image was created

• Name of the configuration file

For each router slot, usage data for:

•CPU

• Memory

•Buffers

For each active task:

• Name of each task

• Usage data for the CPU, memory, and buffers

• Slots on which the task is running

For detailed information about interpreting the information obtained through this interface, refer to Troubleshooting Routers .

300019-B Rev. 00 3-3

Chapter 4

Monitoring Circuit Alerts and Events

With the HTTP Server, you can view the events and alerts generated by the entities on the router. When you click on the Fault icon, the folder opens and displays two document icons. Click on these document icons to view:

• All circu it alerts on the router

• All, or a selection of, event log messages You must first have configured and enabled the HTTP Server on your router, as

described in “Starting and Configuring the HTTP Server description of how to isolate and correct problems with a specific device, refer to Troubleshooting Routers.

.” For a detailed

Fault Icon Displaying Circuit Alerts Viewing the Event Log

Fault Icon

Clicking on Fault in the navigational frame reveals two additional choices. You can view:

• All circu it alerts on the router

• All, or a selection of, event log messages Go to “Monitoring C ircuit Alerts and Events

300019-B Rev. 00 4-1

.”

Managing Routers Using the HTTP Server

Displaying Circuit Alerts

A cir cui t aler t i ndicat es a con ditio n, su ch as a por t/in te rface that ha s been br ought down unexpectedly, that requires your immediate attention. To view any exceptional status conditions for any interface on the router, click on Fault > Circuit Alert in the navigational frame.

For each index item, the circuit alerts display shows:

• Index number

•Circuit name

• Administrative state

• Operational state

• Type

• MAC address

• Maximum transmission unit (MTU)

• Line speed Go to “Monitoring C ircuit Alerts and Events

.”

Viewing the Event Log

An event is something that happens to the operating status of a router. The router stores each event as a singl e entr y i n a memory- resi den t log f ile. The event l og for a router is the composite of all the events that occur for all the processors in the router.

An event message provides a brief description of an event, along with the event code associated with that event. Use the even t code to look up the meani ng of the message and what you must do about it in the events database.

To view the events for a router, click on Fault > Events in the navigational frame.

Filtering What the Event Log Shows Interpreting Event Messages

Go to Monitoring Circuit Alerts and Events.

4-2 300019-B Rev. 00

Filtering What the Event Log Shows

By default, the event log display shows Fault, Warning, and Info event messages.

• To show other event messages, click on the check boxes to select the appropriate Event Message Severity Levels

• To restrict the display to one or more specific slots or entities and to show only events that happen after a specific date and time, fill in the fields in this frame, separating individual entries with spaces.

Note:

All entity names are case-sensitive. For a list of entity names, refer to

the events database.

Monitoring Circuit Alerts and Events

Go to “Monitoring C ircuit Alerts and Events

Interpreting Event Messages

Event Messages for Routers provides detailed information about interpreting event messages and taking appropriate action. Most messages document routine occurrences that do not require you to do anything. The following table lists and briefly describes the severity levels.

Event Message Severity Levels

Severity Description

Fault Major service disruption, usually caused by a configuration, network,

or hardware problem. The entities involved keep restarting until th e

problem is resolved either by the router itself or by you. Warning Service acted in an unexpected manner. Info Routine event. Usually, no action is required. Trace Detailed history of everything that happens on the router. Because of

the amount of information that the Trace function records, Bay

Networks recommends viewing this type of message only when

diagnosing specific network problems. Debug Information that Bay Networks Customer Support uses. With few

exceptions, these messages do not appear in

Routers.

.”

Event Messages for

Return to Monitoring Circuit Alerts and Events

300019-B Rev. 00 4-3

Chapter 5

Viewing Router Services Statistics

Examining the router’s statistics along with t he e vent log can give you a pic ture of how well your router is working. When you click on Statistics in the navigational frame, the folder opens to show the Services, Ports, and Protocols folders, each containing subordinate links. This chapter shows the Services statistics. For Port statistics, go to Chapter 6, “Viewing Router Port Statistics statistics, go to Chapter 7, “Viewing Router Protocol Statistics

This guide presents the details of the HTTP statistics. Detailed

Note:

descriptions of statistics for the other services are in the guides for each service.

,” and for Protocol

.”

Router Services Stati stics Using the HTTP Server to View HTTP Statistics Using the Statistics Manager to View HTTP Server Statistics

Router Services Statistics

You can display router services statistics either through the Web interface, by clicking on Statistics > Services in the navigational frame, or by using the Site Manager Statistics Manager. For information on using the Statistics Manager, see

Using the Statistics Manager to View HTTP Server Statistics

300019-B Rev. 00 5-1

Managing Routers Using the HTTP Server

Using the Web interface, clicking on Statistics > Services displays links to the statistics for each service.

To see these statistics Use this path

TFTP Statistics > Services > TFTP TCP Statistics > Services > TCP FTP Statistics > Services > FTP Telnet Statistics > Services > Telnet BootP

Statistics > Services > Bootp This reveals several subordinate links: Traffic, Interfaces, Clients, Preferred Srv (Servers), and Relay Agents.

•Traffic

•Interfaces

•Clients

• Preferred servers

• Relay agents SNMP

• Counters

• Communities

• Entity traps

• Exceptions HTTP

• Configuration

• Counters

• Requests

• Responses

* You must have Manager-level access privileges to view the statistics for SNMP communities. If you

logged in with user-level privileges, HTTP prompts you to enter the manager login name and password.

Statistics > Services > Bootp > Traffic Statistics > Services > Bootp > Interfaces Statistics > Services > Bootp > Clients Statistics > Services > Bootp > Prefe rred Srv Statistics > Services > Bootp > Relay Agents

Statistics > Services > SNMP This reveals the following subordinate links: Co unters, Communities, Entity Traps, and Exceptions.

Statistics > Services > SNMP > Counters Statistics > Services > SNMP > Communities* Statistics > Services > SNMP > Entity Traps Statistics > Services > SNMP > Exceptions

Statistics > Services > HTTP This reveals the following subordinate links: Co nfiguration, Counters, Requests, and Responses.

Statistics > Services > HTTP > Configuration Statistics > Services > HTTP > Counters Statistics > Services > HTTP > Requests Statistics > Services > HTTP > Responses

Go to “Viewing Router Services Statistics

5-2 300019-B Rev. 00

”.

Viewing Router Services Statistics

Using the HTTP Server to View HTTP St atistics

You can display HTTP Server statistics either through the Web interface, by clicking on Stati stics > Se rvices > HTTP in t he na vigat ional f rame, or b y using t he Site Manager Statistics Manager.

HTTP Configuration Statistics HTTP Counters HTTP Request Statistics HTTP Response Statistics Using the Statistics Manager to View HTTP Server Statistics

HTTP Configuration Statistics

HTTP configuration statistics provide the following information:

HTTP Statistic Meaning

State Whether the server is enabled or disabled Status Whether the server is currently up, down, initializing, or not present Port The port number on which this server listens to requests Authentication The level of access authentication security in use Domain Name The domain name, if any, that can be used to access this router

HTTP Counters

HTTP counters provide the following information:

HTTP Statistic Meaning

Total Requests Received

Total Request Errors

Total Request Discards

Total Responses The total number of response s that this en tity generated or received Total In

Unknowns

300019-B Rev. 00 5-3

The total number of requests that this entity received

The total number of request errors that this entity detected (as server)

The total number of requests that this entity discarded (as server)

The total number of unknown messages that this ent ity received

Managing Routers Using the HTTP Server

Total Rx Octets The total number of bytes that this entity received Total Tx Octets The total number of bytes that this entity transmitted Total Time Outs The total number of timeouts for this entity Start Time The date and time that the HTTP services were enabled

HTTP Request Statistics

HTTP request statistics provide the following information:

HTTP Statistic Meaning

Method The HTTP standard request method to which these statistics apply Total In The number of requests of this type that this entity received In Last Time The date and time the last request was received

HTTP Response Statistics

HTTP response statistics include

HTTP Statistic Meaning

Status An HTTP standa rd code and m essage descriptio n indicat ing the status

of the response Total Out The number of times this response was generated Out Last Time The date and time the most recent response was sent

Go to “Viewing Router Services Statistics”.

Using the Statisti cs Manager to View HTTP Server Statistics

T o use Site Manager Statistics Manager tool to view statistical information for the HTTP Server, click on Statistics on the toolbar or, from the Site Manager menu, choose T o ols > Statistics Manager. Se lect the router that y ou want to monit or. The Statistics Manager window appears, showing the device IP address and, for each circuit on that device, showing the slot, connector, type, and protocols.

5-4 300019-B Rev. 00

Selecting the Windows to Display Starting th e Statistics Launch Facility Viewing HTTP Statistics

Selecting the Windows to Display

Use the Screen Manager tool to select the windows to display. In the Statistics Manager window, click on Tools > Screen Manager. Add the HTTP windows to the list of those to display, then exit the Screen Manager.

Starting the Statistics Launch Facility

In the Statistics Manager window, click on Tools > Laun ch Facility to display the Statistics Launch Facility window, which lets you choose the type of statistical information that you want to view for this device.

Click on the line that indicates the type of information you want to display, then click on Launch. To return to this window, click on File > Exit in the resulting window.

Viewing Router Services Statistics

Viewing HTTP Statistics

Each statis tical window shows the window name (name.dat), window description, SNMP agent IP address, and number of elements in the display.

To see these statistics Choose this option What the window shows for each element

HTTP requests

HTTP responses

300019-B Rev. 00 5-5

httpreq.dat

httpresp.dat

HTTP request statistics:

• Methods

• Total requests (Total In) for each method HTTP response statistics:

• Status

• Number of times the server responds for each status type (TotalOut)

Managing Routers Using the HTTP Server

To see these statistics Choose this option What the window shows for each element

HTTP server configuration

HTTP summary statistics

httpsrv.dat

httpsum.dat

HTTP server configuration statistics:

• State (enabled or disabled)

• Operational status

• Port number

• Access authorization level

• Domain name

HTTP summary statistics (overview of the router’s current state):

• Total requests received

• Total request errors

• Total discarded requests

• Total responses

• Total unknown inputs

• Total bytes received

• Total bytes sent

• T otal timeouts

• Start time

5-6 300019-B Rev. 00

Chapter 6

Viewing Router Port Statistics

Clicking o n Statistic s > Ports displays the following fold ers in the na vigational frame:

•Summary

•Ethernet

•Serial

• FDDI

• HSSI

• Token Ring To get statistical information about any port type, click on the appropriate link.

Each port- t ype folder contains li nks to summary statisti cs, traffic (number of packets transmitted and received) statistics, receive error statistics, and transmit error statisti cs. All but Eth ernet also displ ay sys tem erro r stati stic s. The fol lowing sections summarize these displays.

Changing the Administrative Status of a Port Viewing Traffic Statistics for All Ports Viewing Ethernet Port Statistics Viewing Serial Port Statistics Viewing FDDI Port Statistics Viewing HSSI Port Statistics Viewing Token Ring Port Statistics

300019-B Rev. 00 6-1

Managing Routers Using the HTTP Server

Changing the Administrative Status of a Port

A user who has Manager-level access privileges can click on the first column of the table in the summary statistics window for any port type to enable or disable (that is, change the administrative setting of) the port.

Caution:

If you disable the interface through which your Web browser is communicating with a router, you will no longer be able to monitor that router’s operation with the HTTP Server.

The Enabled column displays the administrative setting, but it is not a clickable link. The State column sh ows t he operational state of the port (up or down). If th e Enabled column shows that the port is enabled, but the State column shows that the port is down, there is a problem with the port.

Viewing Traffic Statistics for All Ports

To view traffic statistic s for all port s, click on Statistics > Ports > Summary.

Viewing Ethernet Port Statistics

Clicking on Statistics > Ports > Ethernet in the navigational frame reveals the following subordinate links: Summary, Traffic, Rx Errors, and Tx Errors.

To see these statistics Use this path

Summary Statistics > Ports > Ethernet > Summary Traffic Statistics > Ports > Ethernet > Traffic Rx Errors Statistics > Ports > Ethernet > Rx Errors Tx Errors Statistics > Ports > Ethernet > Tx Errors

6-2 300019-B Rev. 00

Viewing Serial Port Statistics

Clicking on Statistics > Ports > Serial in the navigational frame reveals the following subordinate links: Summary, Traffic, Rx Errors, Tx Errors, and Sys Errors.

To see these statistics Use this path

Summary Statistics > Ports > Serial > Summary Traffic Statistics > Ports > Serial > Traffic Rx Errors Statistics > Ports > Serial > Rx Errors Tx Errors Statistics > Ports > Serial > Tx Errors Sys Errors Statistics > Ports > Serial

Viewing FDDI Port Statistics

Clicking on Statistics > Ports > FDDI in the navigational frame reveals the following subordinate links: Summary, Traffic, Rx Errors, Tx Errors, and Sys Errors.

Sys Errors

Viewing Router Port Statistics

To see these statistics Use this path

Summary Statistics > Ports > FDDI > Summary Traffic Statistics > Ports > FDDI > Traffic Rx Errors Statistics > Ports > FDDI > Rx Errors Tx Errors Statistics > Ports > FDDI > Tx Errors Sys Errors Statistics > Ports > FDDI

300019-B Rev. 00 6-3

Sys Errors

Managing Routers Using the HTTP Server

Viewing HSSI Port Statistics

Clicking on Statistics > Ports > HSSI in the navigational frame reveals the following subordinate links: Summary, Traffic, Rx Errors, Tx Errors, and Sys Errors.

To see these statistics Use this path

Summary Statistics > Ports > HSSI > Summary Traffic Statistics > Ports > HSSI > Traffic Rx Errors Statistics > Ports > HSSI > Rx Errors Tx Errors Statistics > Ports > HSSI > Tx Errors Sys Errors Statistics > Ports > HSSI

Viewing Token Rin g Port Statistics

Clicking on Statistics > Ports > Token Ring in the navigational frame reveals the following subordinate links: Summary, Traffic, Rx Errors, Tx Errors, and Sys Errors.

Sys Errors

To see these statistics Use this path

Summary Statistics > Ports > Token Ring > Summary Traffic Statistics > Ports > Token Ring > Traffic Rx Errors Statistics > Ports > Token Ring > Rx Errors Tx Errors Statistics > Ports > Token Ring > Tx Errors Sys Errors Statistics > Ports > Token Ring

6-4 300019-B Rev. 00

Sys Errors

Chapter 7

Viewing Router Protocol Statistics

Clicking on Statistics > Protocols displays the following folders in the navigational frame:

•IP

•IPX

•AppleTalk To get statistical information about any protocol type, click on the appropriate

link. Each protocol folde r contains lin ks to summary statistics, traffic statistics (number of packets transmitted and received), and interface statistics, as well as to other statistics specific to that protocol. The following sections show and briefly describe these displays.

Changing the Administrative Status of a Port Viewing IP Statistics Viewing IPX Statistics Viewing AppleTalk Statistics

Changing the Administrative Status of a Port

A user who has Manager- le vel access privileges can click on a radio butt on i n t he first column of th e t able in the interf ac e s tatistics window for any protocol type to enable or disable (that is, change the administrative setting of) the port

Caution:

communicating with a router, you will no longer be able to monitor that router’s operation with the HTTP Server.

300019-B Rev. 00 7-1

If you disable the interface through which your Web browser is

Managing Routers Using the HTTP Server

The Enabled column displays the administrative setting, but it is not a clickable link. The State c olumn shows the op erationa l stat e of t he inte rface ( up or d own). If the Enabled column shows that the interface is enabled, but the State column shows that th e interface is down, there is a problem wi th the interfa ce.

Viewing IP Statistics

Clicking on Statistics > Protocols > IP in the navigational frame reveals the following subordinate links: Global, Traffic, Interfaces, Routes, ARP Cache, RIP, and ICMP.

To see these statistics Use this path

Global Statistics > Protocols > IP > Global Traffic Statistics > Protocols > IP > Traffic Interfaces Statistics > Protocols > IP > Interfaces Routes Statistics > Protocols > IP > Routes ARP Cache Statistics > Protocols > IP RIP Statistics > Protocols > IP ICMP

Statistics > Protocols > IP This reveals the following subordinate link s : Counters , Received, and Transmitted.

> ARP Cache > RIP > ICMP

• Counters

• Received

• Transmitted

Statistics > Protocols > IP > ICMP > Counters Statistics > Protocols > IP > ICMP > Received Statistics > Protocols > IP > ICMP > Transmitted

Viewing IPX Statistics

Clicking on Statistics > Protocols > IPX in the navigational frame reveals the following subordinate links: Global, Traffic, Interfaces, Forwarding, Hosts, Routes, Services, RIP, and SAP.

7-2 300019-B Rev. 00

To see these statistics Use this path

Global Statistics > Protocols > IPX > Global Traffic Statistics > Protocols > IPX > Traffic Interfaces Statistics > Protocols > IPX > Interfaces Forwarding Statistics > Protocols > IPX > Forwarding Hosts Statistics > Protocols > I PX > Hosts Routes Statistics > Protocols > IPX > Routes Services Statistics > Protocols > IPX RIP Statistics > Protocols > IPX SAP Statistics > Protocols > IPX

Viewing AppleTalk Statistics

Viewing Router Protocol Statistics

> Services > RIP > SAP

Clicking on Statistics > Protocols > AppleTalk in the navigational frame reveals the following subordinate links: Global, Traffic, Interfaces, Routes, ARP Cache, and Zones.

To see these statistics Use this path

Global Statistics > Protocols > AppleTalk > Global Traffic Statistics > Protocols > AppleTalk > Traffic Interfaces Statistics > Protocols > AppleTalk > Interfaces Routes Statistics > Protocols > AppleTalk > Routes ARP Cache Statistics > Protocols > AppleTalk RIP Statistics > Prot ocols > AppleTalk Zones Statistics > Protocols > AppleTalk

> ARP Cache > RIP > Zones

300019-B Rev. 00 7-3

Appendix A

Site Manager Parameters

This appendix contains the Site Manager parameter descriptions for the HTTP Server. You can display the same information using Site Manager or the BCC online Help.

For each para meter, this appendix p rovides the f ollowing in formation:

• Parameter name

• Configuration Manager menu path

• Default setting

• Valid parameter options

• Parameter function

• Instructions for settin g the paramete r

• Management information base (MIB) object ID

set

The Technician Interface allows you to modify parameters by issuing

commit

modifying parameters using Site Manager. For more information about using the Technician Interface to access the MIB, see Using Technician Interface Software.

Caution:

parameter values. Entering an invalid value can corrupt your configuration.

commands with the MIB object ID. This process is equivalent to

The Technician Interface does not verify the validity of your

and

300019-B Rev. 00 A-1

Managing Routers Using the HTTP Server

Site Manager Parameters

The Edit HTTP Global Parameters window contains the parameters that you can configure for the HTTP Server. To access the Edit HTTP Global Parameters window, complete the following tasks:

You do this System responds

Site Manager Procedure

1. In the Configuration Manager window, choose

2. Choose

3. Choose

4. Choose

Protocols

Global Protocols HTTP Global

. The Global Protocols menu opens.

. The HTTP menu opens.

. The Edit HTTP Global Parameters

The Protocols menu opens.

window opens.

The parameter descriptions follow.

Parameter: Enable/Disable

Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global

Default: When you enable the HTTP Server, this parameter is automatically set to

Enabled.

Options: Enabled

Disabled

Function: Enables or disables the HTTP Server on this interface.

Instructions: To prohibit the use of the HTTP Se rver on this interface, set this parameter

to Disabled.

MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.2

Parameter: Port

Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global

Default: 80

Options: 0 to 4096

Function: Specifies the port number on which you enable the HTTP Server.

Instructions: Accept the default value, 80, or specify a value from 0 to 4096.

MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.4

A-2 300019-B Rev. 00

Site Manager Parameters

Parameter: Authentication

Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global

Default: Basic

Options: Basic | Digest

Function: Specifies the type of authentication to use on this interface: basic or digest.

Basic authentication verifies the user's identity using the user name and password passed over the network as clear text. Digest authentication uses an encrypted password. If yo u spec ify digest aut hentic ation, b ut your browser does not support this, authentication reverts to basic.

Instructions: Accept the default value Basic, or specify Digest.

MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.7

Parameter: Domain Name

Path: Configuration Manager > Protocols > Global Protocols > HTTP > Global

Default: None

Options: Any valid string of characters constituting a domain name

Function: Lets the server be accessible by a domain name, rather than by IP address. The

Domain Name parameter must be set to the domain name that a DNS lookup would return for the route r.

Accept the default value, no domain name, to indicate that the server is accessible only b y the I P address ; or sp ecify a domain name to use instead of the IP address.

Instructions: Accept the default value, no domain name, to indicate that the server is

accessible only b y the I P address ; or sp ecify a domain name to use instead of the IP address.

MIB Object ID: 1.3.6.1.4.1.18.3.5.3.22.1.1.8

300019-B Rev. 00 A-3

Appendix B

Show Commands for the HTTP Server

Use the Bay Command Console (BCC) information about the HTTP Server on the router. The statistics available through the BCC are a subset of the information available through the HTTP Server interface itse lf. See Usi ng the Bay Comman d Console for i nformat ion abou t scripts command syntax.

This chapter contains the following information about show commands:

• Sample show Command Output

• Online Help for show Commands

• Show Commands for the HTTP Server

• show http summary

• show http requests

• show http responses

show

command to d isplay statistical

show

300019-B Rev. 00

B-1

Managing Routers Using the HTTP Server

Sample show Command Output

show

The

command displays summary information about the HTTP Server on

the router. For example, if you enter the command:

show http requests

bcc> You see this type of output:

show http requests Sep 21, 1998 11:48:04 [EDT]

Method Total In In Last Time

------ -------- ---------------------------get 186 Sep 21 1998 14:20:57 [GMT-5] head 0 trace 0 post 0 options 0 put 0 delete 0

Online Help for show Commands

B-2

You can display a list of available command options by entering

example, entering

show

without additional options or with a question mark as an option. For

show http

show

keyword (subcommand) options.

show http ?

at the BCC prompt displays the list of all

show

300019-B Rev. 00

show

Show Commands for the HTTP Server

show http

The subcommands) available with this command. These keywords are:

•summary

• requests

• responses

show htt p

The activity on the router.

The HTTP Server flags, or filter arguments. The router shows in formation for all applicable entr ies.

show http summary

The services on the router.

The output contains the following information:

Total Requests Received

Total Request Errors The number of received requests that were in error. Total Request

Discards Total Responses The number of router responses. Total In Unknowns The number of unrecognizable requests received. Total Rx Octets The number of received octets. Total Tx Octets The number of transmitted octets. Total Time Outs The number of time outs that occurred since the last reset. Start Time The time of the last router reset.

show http ?

show http

command lists the keywords (also called

command displays informat ion about the HTTP Serv er

commands have no command arguments, filter

command displays summary statistics about HTTP

The total number of requests the router received.

The number of received requests that were discarded.

300019-B Rev. 00

B-3

Managing Routers Using the HTTP Server

show http requests

The router.

The output contains the following information:

Method An HTTP keyword indicating a type of request. Total In The number of requests received. In Last Time The time the most recent request was received.

show http responses

show http requests

The router.

The output contains the following information:

Status A numeric status code and a brief interpretation for a response

category. Total Out The number of responses sent. Out Last Time The time the most recent response was sent.

command displays HTTP request statistics for the

command displays HTTP response statistics for the

B-4

300019-B Rev. 00

Index

access control filtering, 1-6 acronyms, xi administrative status of a port, changing, 7-1 alert, circuit, 4-2 AppleTalk statistics, 7-3 authentication

basic, 1-5 configured, 5-3 digest, 1-6

Authentication parameter, A-3

basic access authentication, 1-5 BCC show command, B-1 BCC, using to start the HTTP Server, 1-3 BootP statistics, 5-2 browser requirements, 1-1

cascading style sheets, 1-1 changing HTTP parameters, 1-7 circuit Alert, 4-1 circuit alert

displaying, 4-2 configuration files, initial, 1-2 configuration statistics, HTTP, 5-3 conventions, text, x counters, HTTP, 5-3 customizing HTTP parameters, 1-7

debug event, meaning, 4-3 device monitoring, 3-1 digest authentication, 1-6 DNS, 1-6 Domain, A-3 domain name

configured, 5-3 domain name instead of IP address, 1-6 Domain Name parameter, 1-6, A-3

Edit HTTP Global Parameters window, A-2 educational services, xii Enable/Disable parameter, A-2 enabling HTTP Server, 1-1 Ethernet port statistics, 6-2 event, 4-1

viewing, 4-2 event log

filtering, 4-3

interpreting, 4-3

severity levels, 4-3 Events icon, 4-2

fault event, meaning, 4-3 FDDI port statistics, 6-3 filtering the event log, 4-3 flash memory card, 1-2

300019-B Rev. 00

Index-1

folder icon, 2-2 frames, 1-1 FTP statistics, 5-2

GAME, 2-1 getting help, 3-1

HTTP statistics, 5-2

viewing, 5-5 HTTP status, 5-3 HTTP summary statistics, 5-6 http summary, show command, B-3 httpreq.dat, 5-5 httpresp.dat, 5-5 httpsrv.dat, 5- 6 httpsum.dat, 5-6

hardware icon, 3-3 help for show commands, B-2 help, getting, 3-1 HSSI port statistics, 6-4 HTTP authentication, configured, 5-3 HTTP configuration statistics, 5-3 HTTP counters, 5-3 HTTP domain name, 5-3 HTTP parameters, customizing

BCC, 1-7

Site Manager, 1-8 HTTP port, 5-3 HTTP request statistics, 5-4 HTTP requests, 5-5 http requests, B-4 HTTP response statistics, 5-4 HTTP responses, 5-5 http responses, show command, B-4 HTTP Server

concepts, 2-1

starting, 1-1

starting and configuri ng, 1-1

statistics, 5-3 HTTP server configuration statistics, 5-6 HTTP Site Manaager parameter

Enable/Disable, A-2 HTTP Site Manager parameter

Authentication, A-3

Domain Name, A-3 HTTP state, 5-3

ICMP statistics, 7-2 icon

Circuit Alert, 4-2 Events, 4-2 Hardware, 3-3 Info, 3-3 support folder, 2-2

tasks, 3-3 in last time, HTTP statistic, 5-4 info event, mea nin g, 4-3 Info icon, 3-3 install.bat script, 1-2 IP access control filter, 1-6 IP address

replacing with domain name, 1-6 IP statistics, 7-2 IPX statistics, 7-2

Java applets, 1-1

Max Cache Age (secon ds) parameter, A-3 Max Cache Count parameter, A-3 method, HTTP statistic, 5-4 modifying HTTP parameters, 1-7 monitoring, 4-1 monitoring devi ce opera tio n, 3-1

Index-2

300019-B Rev. 00

network address filterin g, 1-6

online help for show commands, B-2 out last time, HTTP statistic, 5-4

responses

HTTP statistic, 5-3

show command, B-4 router

specifying, 3-2 router monitoring, 3-1 router protocol statis ti cs , 7-1 router statistics, 5-1

parameters

Site Manager, A-1 Port parameter, A-2 port statistics, 6-1

Ethernet, 6-2

FDDI port, 6-3

HSSI, 6-4

serial, 6-3

traffic (all), 6-2 port status, changing, 7-1 port, HTTP, 5-3 port, troubleshooting, 6-2, 7-2 product support, xii protocol statistics, 7-1 publications

Bay Networks, xi

Quick-Start procedure, 1-2

received (rx) octets, HTTP statistic, 5-4 request discards, HT TP statistic, 5-3 request errors, HTTP statistic, 5-3 request statistics, 5-5 requests received, HTTP statistic, 5-3 requests, show, B-4 requirements, browser, 1-1 response (status) code, 5-4 response statistics, 5-5

security, setting, 1-4 serial port statistics, 6-3 server configuration statistics, 5-6 severity levels, events, 4-3 show command, BCC, B-1 show commands

command syntax, B-2 config, B-2

online Help for, B-3 show commands, help, B-2 show http requests, B-4 show http responses command, B-4 show http summary command, B-3 Site Manager

parameter descript ions, A-1

Statistics Manager, 5-4

using to start the HTTP Server, 1-4, 1-8 SNMP statistics, 5-2 specifying a router to monitor, 3-2 start time, HTTP statistic, 5-4 starting HTTP Server, 1-1

BCC, 1-3

Site Manager, 1-4 state

HTTP, 5-3 statistics

AppleTalk, 7-3

Ethernet port, 6-2

FDDI port, 6-3

HSSI port, 6-4

HTTP, 5-3

300019-B Rev. 00

Index-3

HTTP configuration, 5-3 HTTP request, 5-4 HTTP requests, 5-5 HTTP response, 5-4 HTTP responses, 5-5 HTTP server configuration, 5-6 HTTP summary, 5-6 ICMP, 7-2 IP, 7-2 IPX, 7-2 port, 6-1 router protocol, 7-1 serial port, 6-3 token ring portport statisti cs

token ring, 6-4 traffic, all ports, 6-2 viewing, 5-1

Statistics Launch Facility, 5-5 Statistics Manager, 5-1, 5-3, 5-4 statistics, ava ilable , 5-1 status of a port, changing, 7-1 status, HTTP, 5-3 status, HTTP statistic, 5-4 summary

http show command, B-3 system status, 3-2

summary statistics, 5-6 support folder icon, 2-2 support, Bay Networks, xii system status, summary, 3-2

total in unknowns, HTTP statistic, 5-3 total in, HTTP statistic, 5-4 total out, HTTP statistic, 5-4 total request discards, HTTP statistic, 5-3 total request errors, HTTP statistic, 5-3 total requests received, HTTP statistic, 5- 3 total responses, HTTP statistic, 5-3 total rx octets, HTTP statistic, 5-4 total time outs, HTTP statistic, 5-4 total tx octets, HTTP statistic, 5-4 trace event, meaning, 4-3 traffic statistics for all ports, 6-2 transmitted (tx) octets, HTTP statistic, 5-4 troubleshootin g a port, 6-2, 7-2

unknowns, HTTP statistic, 5-3

warning event, meaning, 4-3

Tasks icon, 3-3 TCP statistics, 5-2 technical publications, xi technical support, xii Telnet statistics, 5-2 text conventions, x TFTP statistics, 5-2 time outs, HTTP statistic, 5-4 token ring port statis tics, 6-4

Index-4

300019-B Rev. 00

Avaya Managing Routers HTTP Server User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Managing Routers Using the HTTP Server

Contents

Preface

Before You Begi n

Text Con ventions

Acronyms

Bay Networks Technical Publications

How to Get Help

Browser Requirements

Starting the HTTP Serve r Us ing the BCC or Site Manager

Setting HTTP Server S ecurity

User Name/Password Security Concepts

Basic Access Authentication

Digest Authentication

Network Address Filtering

Using a Domain Name Instead of an IP Address

Customizing HTTP Parameters

What the HTTP Server Does

Navigating the HTTP Server Interface

Getting Help

Specifying a Router to Monitor

Viewing Overall System Status

Fault Icon

Displaying Circuit Alerts

Viewing the Event Log

Filtering What the Event Log Shows

Interpreting Event Messages

Router Services Statistics

Using the HTTP Server to View HTTP St atistics

HTTP Configuration Statistics

HTTP Counters

HTTP Request Statistics

HTTP Response Statistics

Using the Statisti cs Manager to View HTTP Server Statistics

Selecting the Windows to Display

Starting the Statistics Launch Facility

Viewing HTTP Statistics

Changing the Administrative Status of a Port

Viewing Traffic Statistics for All Ports

Viewing Ethernet Port Statistics

Viewing Serial Port Statistics

Viewing FDDI Port Statistics

Viewing HSSI Port Statistics

Viewing Token Rin g Port Statistics

Changing the Administrative Status of a Port

Viewing IP Statistics

Viewing IPX Statistics

Viewing AppleTalk Statistics

Site Manager Parameters

Sample show Command Output

Online Help for show Commands

Show Commands for the HTTP Server

show http summary

show http requests

show http responses

Index
