Troubleshooting
An Avaya IR system interacts with other systems and relies on them for critical functions.
Consequently, troubleshooting may involve testing connections and checking other systems
where databases, speech functions, and host services reside. This section guides you in
resolving many Avaya IR system problems and includes information on basic LAN, server,
and host troubleshooting. Additionally, Avaya technical support provides troubleshooting
assistance that is specific to your Avaya IR system and the current problem.
This section includes the following topics:
Troubleshooting overview ................................................................. 6
Troubleshooting procedure ............................................................. 12
Troubleshooting based on observations ......................................... 15
Troubleshooting overview
This overview explains how the Avaya IR system works and and identifies potential problem
Requirements for successful operations
The public switched telephone network (PSTN)
areas.
Interactions between the IR system and other systems and applications are essential to voice
response operations. This section explains the requirements for successful operations to help
you to prevent problems and identify them more quickly when they occur.
Calls come into the IR system from the public switched telephone network (PSTN). Calls
from the PSTN can reach the IR system in one of three ways:
• A MultiVantage (DEFINITY) system receives the calls from the PSTN and passes them to
the IR system through direct digital connections between the two systems.
6 Avaya IR R2.0 Troubleshooting
Contents
• An IP-enabled DEFINITY or MultiVantage system receives calls from the PSTN, converts
them to packet-based signals, and sends them to the IR system over a Local Area
Network (LAN) connection.
• Calls come from the PSTN directly to the IR system through digital connections.
For successful voice response operations, all of the connections described above and the
telephony network that supports them–including central offices–must be working and free
from errors.
Switches
IR systems can be linked to DEFINITY or MultiVantage systems that route calls to and from
the IR system and perform call handling functions. For successful operations, switches must
be free of hardware problems and must be administered correctly. Additionally, connections
between the switch and the IR system must be operating properly and not be overloaded.
DEFINITY and MultiVantage systems come with a comprehensive set of self-tests that you
can use to troubleshoot problems with the switch and with connections, such as trunks.
Procedures are documented in detail in the various administration manuals. Switch
troubleshooting should be done with the aim of bringing connections into service. Once the
connections are in service, there is a good chance that the problem is not with the switch.
Voice response applications
Voice response applications manage the interactions between callers and play the
information that callers hear. For successful operations, voice response applications must
perform a variety of tasks, such as:
• Interpreting caller input and taking appropriate action
• Communicating with hosts, databases, and proxy speech servers
• Transferring values entered by callers to other applications
• Providing information to callers in the form of recorded speech or speech generated
through the Proxy Text-to-Speech feature
As you can see, voice response applications are central to the successful operation of an IR
system.
Connections and communications
Connections to other systems, and the communications that take place across them, are
critical to smooth voice operations. Major connections and communications are as follows:
Issue 1.0 April 2006 7
Contents
• Digital lines and LAN connections that bring calls in from and send calls out to the public
switched telephone network (PSTN)
• Connections between any MultiVantage systems and the IR system
• Connections from the back of the IR system to other devices, and to the LAN
• LAN connections between the IR system and servers that provide speech functions,
database information, or both
System and LAN capacity
A breakdown in any of these connections can affect voice response operations.
Like any computer, the IR system has a certain amount of memory, drive space, and CPU
capacity to support system operations. Additionally, the IR system requires LAN capacity to
communicate with servers that provide critical functions. For successful operation, both IR
system capacity and LAN capacity must be adequate.
Possible malfunctions and errors
Hardware malfunctions and failures
This section explains the types of problems that may affect voice response operations.
Hardware malfunctions and failures may stop or interfere with voice operations. These
include problems in:
• The IR system itself
• Servers providing speech functions, database information, or both
• Connected MultiVantage (DEFINITY) systems
Hardware malfunctions and failures are relatively easy to identify. However, they are rarely a
cause of problems.
Incorrect system administration
Errors in IR system administration can cause problems with voice operations. Examples are:
• A service cannot be assigned to a channel, resulting in the service not functioning when
calls come in.
8 Avaya IR R2.0 Troubleshooting
Contents
• TCIP/IP connections between the IR system and a server might be set up incorrectly, so
that required data is not available to callers.
Application errors
Applications manage voice response functions, so errors can be devastating to operations.
For instance, an application may call for the playing of recorded speech that does not exist,
or try to access the wrong server for speech. Applications that are not sufficiently tested, or
that are not tested under realistic conditions, can function poorly when used for business
operations. Voice response applications that are large and complex or that use system
resources inefficiently are the most common cause of performance problems.
Connection and communication problems
When any connection that supports voice response applications experiences a problem,
operations may be affected. Disruptions may occur in the public switched telephone network
(PSTN), MultiVantage (DEFINITY) system, servers that support operations, or in the LAN.
Circuit-based configurations
Circuit-based configurations allocate a physical cable (or part of a cable by using Time
Division Multiplexing) to each telephone call. Obviously, problems with these cables might
affect voice response applications.
Packet-based configurations
When the VoIP feature is used, the voice data is transmitted in small packets that contain a
fraction of the entire spoken transmission. Rather than a dedicated cable being used
between the end-points, packets traverse the network between the end-points via one or
more available routes. With this type of transmission, packets may get lost. An overloaded
network might delay or lose packets.
Overloading
Overloading may occur in these ways:
• An overloaded IR system exhibits performance problems. Causes of system overloaded
include:
― Voice response applications that use system resources inefficiently or are too complex
or lengthy
― Excessive system processes that are external to voice response operations
Issue 1.0 April 2006 9
Contents
Speech
• LAN overloading may result from competition with other processes for LAN capacity. The
result can be delays and breaks in the availability of required data and functions.
If the call load increases beyond the capacity of the IR system, call handling problems are
likely to occur. A new system, or re-routing of calls, is generally required.
The IR system provides information to callers through recorded or generated speech. For
successful operation:
• Recorded speech must exist, be of acceptable quality, and be accessible to voice
response applications.
• Generated speech must be constructed properly by the Proxy Text-to-Speech feature and
the voice response application.
• Recorded speech must be transferred from a server, so that the application can play it for
the caller.
Communication between the IR system and the server or host must be adequate to deliver
speech in a timely manner.
Identifying possible causes of problems
Generally, you will work with Avaya support representatives to identify the cause of the
problem and correct it. However, you may find that some problems are easy to identify and
resolve on your own.
The following table describes common problems and suggests actions you can take to
identify them:
Problems Effects Actions
Disconnection or poor
connection of cables to the
back of the IR system
Possible effects include:
• Monitor, keyboard, or
mouse are not operating.
• Speech functions and data
resident on servers are not
accessible.
Check the cable connections.
See Checking cable
connections on page 43 for
more information.
10 Avaya IR R2.0 Troubleshooting
Contents
Inadequate or expired
feature licensing
Note: Renaming the IR
system may cause loss of
feature licensing.
Calls not terminating on the
IR system.
Poor communication or no
communication with
required servers across the
LAN
Incorrect system
administration, such as
errors in channel
assignments, server
assignments, and other
configuration information
Affected features are not
functioning, or are not
functioning as expected.
Callers hear a fast busy signal.
Possible effects include:
• Response times for speech
functions and data retrieval
are slow, interrupted, or
both.
• Speech functions and data
resident on servers are not
accessible to voice
response applications.
Degraded or non-functional
voice response services
• From web administration, go
to the Feature Licensing
screen (Configuration
Management > Feature
Licensing) to identify the
features licensed for the
system.
• Contact your Avaya support
representative if you have
renamed the IR system or
to purchase more features, if
you require them.
• From web administration, go
to Configuration
Management > System
Control.
• Stop and start the voice
system.
• Test the LAN connection.
See Checking LAN
communications on page 36
for more information.
• Work with your LAN
administrator as needed to
resolve the problem.
• Add additional proxy speech
servers or speech server
resources
• From web administration, go
to the Display Equipment
screen (Configuration
Management > Voice
Equipment > Display
Equipment) and check the
system settings.
• Make corrections as
needed.
Inadequate system
resources (memory, CPU,
disk)
Voice response application
coding errors
Poor response times, speech
breaks, load-related messages
and alarms, increased hold
times and blocking of calls
• Degraded or non-functional
voice response services
• Dropped calls
Assess the load and reduce it, if
necessary. Manage better the
performance of your system in
the future.
Contact the vendor or internal
staff who develop your
applications.
Issue 1.0 April 2006 11
Contents
Troubleshooting procedure
If a problem develops with voice response operations, follow this general procedure to
resolve it:
1. Go to the Message Log Report screen (Reports > Message Log Report) and check for
messages about events related to the problem.
Events may generate alarms. The level of the alarm (critical, major, or minor) indicates the
severity of the problem.
2. Follow repair procedures for any events related to the problem.
On the Message Log Report screen, you may display repair procedures by using the
Explain function. Explanations of messages and related repair procedures are included in
this online help as well.
3. If you cannot resolve the problem based on events and related repair procedures, check
the indications of the problem against information in Troubleshooting based on
observations on page 15 and take action based on your findings there.
4. Before contacting others for assistance, gather data on the problem:
― Alarms received
― Application involved
― Type of channel protocol in use
― Type of card
― Type of switch
― System history related to the problem
5. Contact other resources for assistance as needed. Contact your:
― Avaya support representative for problems related to IR system operations
― Application developer for problems related to voice response applications
― LAN administrator for problems with remote access that are not related to
configuration of remote resources on the IR system
― Database administrator for problems with database functions
― Host support personnel for problems with host operations
12 Avaya IR R2.0 Troubleshooting
Contents
Using IR system events
The first step in the general troubleshooting procedure is to check for messages about events
related to the problem. This topic provides more information about troubleshooting based on
events.
Events on the Avaya IR system are logged, and alarms are generated when those events
cause or might cause a problem with voice response operations.
To troubleshoot using Avaya IR system alarms and errors:
1. When a problem arises, check the Message Log Report screen (Reports > Message Log
Reports) for messages about events related to the situation.
Events include a time stamp, event ID, and brief explanatory text. See the sample event
that follows:
Mon May 12 00:15:05 2003 CDH CDH007 -- -- --- (CDH_TRASUM) trasum
failed. Reason: Could not connect to the database
2. If you find events that are relevant to the problem, view additional information on the
event.
Additional information includes priority, description, and repair procedures. You may
display additional information by using the Explain option in the Message Log Report
screen, or by going to the online Help topic for the message.
3. Follow the repair procedure for the event.
The repair procedure may provide specific instructions, direct you to contact your Avaya
support representative, or link to other topics in the online Help or to other resources.
Gathering information on a problem
The next step of the general procedure for troubleshooting is to gather information on the
problem. The topics in this section explain how to gather the information. You may do this on
Reviewing the Display Equipment screen
your own or under the direction of an Avaya support representative.
Go to the Display Equipment screen (Configuration Management > Voice Equipment >
Display Equipment) to view configuration information, such as:
• Type of card
• Type of channels
Issue 1.0 April 2006 13
Contents
• Services (voice response applications) assigned to channels
• Service state
The following table shows state descriptions and their meanings.
State Meaning
INSERV In service
MANOOS Manually out of service
FOOS Facility out of service
BROKEN Not functioning, possibly
needing replacement
Monitoring live operations
Use the sysmon command to observe voice response operations as they occur. You can see
calls coming in, digits entered by callers, and line conditions, such as off-hook.
Note:
Monitoring live operations places a heavy demand on system resources. Using
the sysmon command at times of heavy system activity might result in overload
and interference with call processing.
Checking system history
Researching the history of your IR system helps you to identify the current problem. Talk to
others and check records external to the system to find out about:
• Previous problems and support calls
• Recent changes to the system, including upgrades and repairs
• Changes to the LAN configuration in your organization
Check the Message Log Report screen (Reports > Message Log Report) for previous
intermittent problems that may indicate a pattern.
Using Sun diagnostic tests
Three types of diagnostic tests are available through Sun applications. Use the following Sun
diagnostic tests:
14 Avaya IR R2.0 Troubleshooting
Contents
• Validation Test System (VTS) to test and validate major hardware components
• OpenBoot Diagnostics system to perform root cause failure analysis on various IR
devices
• PROM Diagnostics to check system processes, such as the error rate and type for
Ethernet packets
Sun Fire V210 and V240 Servers Administration Guide explains how to run these diagnostic
tests on the Sun Fire V240 platform. The Sun Fire 280R Server Service Manual explains how
to run these diagnostic tests on the Sun Fire 280R platform. The Sun Blade 150 Service
Manual explains how to run these diagnostic tests on the Sun Blade 150 platform.
These documents are available in Avaya IR System Help (under "Print documents") or from
the Sun Web site (http://www.sun.com).
Using commands
Execute IR system administrative commands to check components and processes.
Information available through administrative commands includes:
• The allocation of resources for all devices
• Resources and space available in the database
• Feature packages installed on your IR system
• A report of all active fax jobs
Since the Solaris operating system is Solaris-based, you also can run Solaris commands that
check devices, processes, and files.
Troubleshooting based on observations
Troubleshoot based on observations when:
• You have reviewed the Message Log Report screen and cannot identify any events
related to the problem.
• The suggested repair procedure for the event does not completely resolve the problem.
• Further investigation is required, such as when you are investigating an intermittent
problem.
Issue 1.0 April 2006 15
Contents
Investigating operations problems
Problems central to voice response functions can affect business operations and may result
in missed calls and caller frustration. Most of the problems described in this section require
prompt attention. To investigate these problems, you should have a good understanding of
the Requirements for successful operations
Call-handling problems
Call handling problems include issues related to responding to and transferring voice and fax
calls. This section provides information about how to resolve various call-handling problems.
Voice system not answering
The voice system will not take calls. The voice system rings but does not answer, or the voice
system is busy.
Note:
If you depend on a host system for caller services, refer to Host interaction
problems on page 22.
on page 6.
To check on possible causes of the problem:
1. Determine whether the voice response application required for the service is running.
― If the application is a permanent process, use the Solaris ps command to list the
running processes and look for the application process.
― If the application is started on demand, the AD (application dispatch) process starts it
when a call arrives for that application.
2. If the application is not running, take any required actions to correct the operation of the
voice response application.
The application may not be installed or there may be errors in coding. For instance, the
voice response application should contain an action to answer the phone. Check with the
person responsible for development of voice response applications for more information.
3. If the voice response application is running correctly and does not contain errors, ensure
that all cards are in the in service (INSERV) state by taking one of the following actions:
― Enter display card all and press Enter.
― Go to the Display Equipment screen (Configuration Management > Voice Equipment >
Display Equipment).
16 Avaya IR R2.0 Troubleshooting
Contents
4. If cards are not in service, either try to restore them or contact your Avaya support
representative.
See Restoring cards and channels
on page 48 for procedures that may bring cards back
into service.
5. If cards are in service, go to the Channel Services screen (Voice Equipment > Voice
Services > Channel Services) and verify that required voice response applications are
assigned to the appropriate channels.
6. If Speech Recognition or Text-to-Speech are in use, make sure that those applications are
working and that servers running the applications are accessible.
7. Go to the Message Log Report screen (Reports > Message Log Report) and check for
messages indicating that the Transaction State Machine process (TSM) is respawning
due to an excessive number of channels in the system.
The message MTC017 (MTC_RESPAWN) indicates respawning of a system maintenance
process.
8. If TSM is respawning due to an excessive number of channels, reassign channels to
another Avaya IR system or contact your Avaya support representative to order more
channels.
Calls dropped
The Avaya IR system can drop calls at the initial prompt or at any other time.
Calls dropped at initial prompt
The IR system may drop calls when the initial prompt is playing if the prompt was recorded
over background noise, such as a fan or ventilation system. The background noise may be
detected as a dial tone following connection by the caller. If this happens, the call is dropped
by the IR system. To fix the problem, re-record the prompt without the background noise.
Note:
For sound quality, you should record in an environment that is free of
background noise.
All calls dropped
Take these actions when all calls are dropped:
Note:
If you depend on a host system to provide information to callers, refer to Host
interaction on page 22 problems.
1. Go the Message Log Report screen (Reports > Message Log Report) and scan it for
messages related to the trouble.
Issue 1.0 April 2006 17
Contents
Look for messages that occurred just before and at the time when calls began dropping. If
calls are handled by VoIP, look for the messages VOIP_DISABLED_CALL_PROC or
VOIP_CALL_FORCE_CLEARED.
2. Type who -rpb and press Enter to display a log of system processes.
3. Search for different time stamps on the processes.
A recent date different from most of the others may indicate that the process respawned.
4. If you find different time stamps, record the situation that caused the problem and take
steps to correct it.
Calls not transferred properly
A transfer may fail simply because the number receiving the call is busy. However, if there
are repeated problems with transfer operations, the cause may be:
• Digits are being dialed incorrectly.
• The switch does does not support transfer operations.
• There are mismatches between the anticipated number of digits in an ANI or DID pass
and the actual number received. (This situation applies to the R2MFC protocol only.)
To resolve the problem:
1. Ensure that digits are being dialed correctly:
a) Type sysmon and press Enter to observe system operations.
b) Observe transfer operations to determine if the correct digits are being dialed.
c) If the wrong digits are being dialed, make the required correction in the voice response
application.
2. If the correct digits are being dialed, verify that the transfer number is valid and that the
switch supports transfer operations.
3. If the R2MFC protocol is in use, try to match the anticipated number of digits in an ANI or
DID pass and the actual number received:
a) Type sysmon and press Enter to observe system operations.
b) Observe transfer operations to determine the number of digits passed in ANI and DID
operations.
c) Use the nms command to specify the correct number of digits.
Note:
It might not be possible to specify the correct number of digits for each call
instance.
18 Avaya IR R2.0 Troubleshooting
Contents
No DTMF tones (WINK protocol)
If voice response applications are not responding correctly to caller input, you may suspect
that DTMF tones (the tones that identify the called number) are missing. For calls handled
with the WINK start protocol, run a trace to determine if the NMS card is receiving the tones.
To set up the trace:
1. Set the following values in the cta.cfg file:
― Tracemode=1
― Tracemask=allevt
― Tracefile=cta.log
2. Stop and start the voice system.
3. Review the ctdaemon file.
The system displays trace output.
4. Check the trace output to determine whether digits are being sent.
In the trace output, the digits in parentheses for the val field identify digits sent. In the
sample trace output that follows, val entries indicate that the digits 1, 2, and 3 were sent.
(The digit 3 is not significant, and the val entries are in bold here to help you find them.)
MESG: Tue May 13 17:08:48 2003
| pid=580 tid=578 ctahd=80000001 (CTATEST) uid=0 tag=4006 sev=0
| DISPEVT: ? NCCEVN_RECEIVED_DIGIT (1c201d) (val=31) objhd=1
src=1c dst=2000 time=235a9a97 uid=0 size=0 buf=0
MESG: Tue May 13 17:08:48 2003
| pid=580 tid=578 ctahd=80000001 (CTATEST) uid=0 tag=14001
sev=0
| ? Msg:854D Ch#01 Obj:0000 Np=16 Nb=0 0032 0000 0000 0000 0000
0000 ...
MESG: Tue May 13 17:08:48 2003
| pid=580 tid=578 ctahd=80000001 (CTATEST) uid=0 tag=4006 sev=0
| DISPEVT: ? NCCEVN_RECEIVED_DIGIT (1c201d) (val=32) objhd=1
src=1c dst=2000 time=235a9b32 uid=0 size=0 buf=0
Issue 1.0 April 2006 19
Loading...
