Avaya™ Interaction Center

Release 6.0 Agent Data Unit Server Programmer’s Guide

DXX-1015-01

Issue 1.0

June 2002

Notice

Every effort was made to ensure that the information in this book was complete and accurate at the time of printing. However, information is subject to change.

Preventing Toll Fraud

“Toll fraud” is the unauthorized use of your telecommunications system by an unauthorized party (for example, a person who is not a corporate employee, agent, subcontractor, or working on your company's behalf). Be aware that there may be a risk of toll fraud associated with your system and that, if toll fraud occurs, it can result in substantial additional charges for your telecommunications services.

Avaya Fraud Intervention

If you

suspect that you are being victimized

support or assistance, call Technical Service Center Toll Fraud Intervention Hotline at +1 800 643 2353.

by toll fraud and you need technical

Providing Telecommunications Security

Telecommunications security (of voice, data, and/or video communications) is the prevention of any type of intrusion to (that is, either unauthorized or malicious access to or use of your company's telecommunications equipment) by some party.

Your company's “telecommunications equipment” includes both this Avaya product and any other voice/data/video equipment that could be accessed via this Avaya product (that is, “networked equipment”).

An “outside party” is anyone who is not a corporate employee, agent, subcon- tractor, or working on your company's behalf. Whereas, a “malicious party” is anyone (including someone who may be otherwise authorized) who accesses your telecommunications equipment with either malicious or mischievous intent.

Such intrusions may be either to/through synchronous (time-multiplexed and/or circuit-based) or asynchronous (character-, message-, or packet-based) equipment or interfaces for reasons of:

• Utilization (of capabilities special to the accessed equipment)

• Theft (such as, of intellectual property, financial assets, or toll-facility

access)

• Eavesdropping (privacy invasions to humans)

• Mischief (troubling, but apparently innocuous, tampering)

• Harm (such as harmful tampering, data loss or alteration, regardless of

motive or intent)

Be aware that there may be a risk of unauthorized intrusions associated with your system and/or its networked equipment. Also realize that, if such an intrusion should occur, it could result in a variety of losses to your company (including but not limited to, human/data privacy, intellectual property, material assets, financial resources, labor costs, and/or legal costs).

Your Responsibility for Your Company's Telecommunications Security

The final responsibility for securing both this system and its networked equipment rests with you - an Avaya customer's system administrator, your telecommunications peers, and your managers. Base the fulfillment of your responsibility on acquired knowledge and resources from a variety of sources including but not limited to:

• Installation documents

• System administration documents

• Security documents

• Hardware-/software-based security tools

• Shared information between you and your peers

• Telecommunications security experts

To prevent intrusions to your telecommunications equipment, you and your peers should carefully program and configure your:

• Avaya-provided telecommunications systems and their interfaces

• Avaya-provided software applications, as well as their underlying

hardware/software platforms and interfaces

• Any other equipment networked to your Avaya products.

Avaya National Customer Care Center

Avaya provides a telephone number for you to use to report problems or to ask questions about your contact center. The support telephone number is 1-800-242-2121.

Ordering Information

Avaya Publications Center Voice: +1 800 457 1235 International Voice: 410 568 3680 Fax: +1 800 457 1764 International Fax: 410 891 0207 Email: totalware@gwsmail.com

Write: GlobalWare Solutions Attention: Avaya Account Manager 200 Ward Hill Avenue Haverhill, MA 01835 USA

Order : Document No. DXX-1015-01, Issue 1.0, June 2002

To order product documentation online, go to

http://www.avayadocs.com, click on Online Services, and select the appropri-

ate product group.

Warranty

Avaya Inc. provides a limited warranty on this product. Refer to the “Limited Use Software License Agreement” or other applicable documentation provided with your package to establish the terms of the limited warranty.

Avaya Web Page

http://www.avaya.com

Trademarks

Avaya, Conversant, CustomerQ, Definity, DefinityOne, Nabnasset, Quintus, and WebQ are registered trademarks or trademarks of Avaya Inc. in the United States or other countries or both.

Portions of Avaya Interaction Center include technology used under license as listed below, and are copyright of the respective companies and/or their licensors:

ActivePerl is a trademark of ActiveState Tool Corp. This product includes software developed by the Apache Software Foundation (http://www.apache.org/). Cognos, Impr omptu and Powerplay are registered trademarks of Cognos Incorporated. YACC++ is a registered trademark of Compiler Resources, Inc. APEX, ComponentOne, VideoSoft, True DBGrid, VSVIEW, SizerOne, VS -OCX, VSFlexGrid, VSFORUM, VSREP ORTS, VSDOCX, VSSPELL, and TrueDBList are either registered trademarks or trademarks of ComponentOne LLC. CT Connect, Dialogic, Intel, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Hummingbird is a registered trademark of Hummingbird, Ltd. SearchServer is a trademark of Hummingbird, Ltd. RISC System/6000 and DirectTalk/2 are trademarks of International Business Machines Corporation in the United States or other countries or both. IBM, OS/2, AS/400, CICS, WebSphere, CT, VisualAge, and DirectTalk are registered trademarks of International Business Machines Corporation in the United States or other countries or both. Lotus and Lotus Sametime are trademarks or registered trademarks of Lotus Development Corporation and/or IBM Cor por ation in th e United Sta tes, other coun tries , or both . Vi sual X i s a registered trademark of Intergroup Technologies, Inc. ActiveX, Visio, Internet Explorer, Windows, Windows NT, Windows 2000, Win32s, SQL Server, Visual Basic, Visual C++, Outlook, and FrontPage are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. TimesTen is a registered trademark of TimesTen Performance Software. Oracle is a registered trademark, and Oracle8i and Ora cle ® SQL/Services are trademarks or registered trademarks of Oracle Corporation. Rogue Wave and .h++ are registered trademarks of Rogue Wave Software Inc. SourcePro is a trademark of Rogue Wave Software, Inc. Siebel is a trademark of Siebel Systems, Inc. BasicScript is a registered trademark of Summit Software Company. Sun, iPlanet, Java, Solaris JRE, J2EE, JavaServer Pages, and all Java-based trademarks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States, other countries, or both. SPARC is a registered trademark of SPARC International, Inc. Products bearing SPARC trademarks are based on an architecture developed by Sun Microsystems, Inc. In3D is a trademark of Visual Insights, Inc. InstallShield® is a registered trademark and service mark of InstallShield Software Corporation in the United States and/or other countries. ORBacus is a trademark of IONA Technologies PLC. Formula One is a licensed trademark and Tidestone Technologies, Inc. Visual Components, First Impression, and VisualSpeller are registered trademarks of Tidestone Technologies, Inc. JRun is a trademark of Macromedia, Inc. in the United States and/or other countries. Intervoice is a registered trademark of Intervoice-Brite, Inc. UNIX is a registered trademark of The Open Group in the United States and other countries. Acrobat is a registered trademark of Adobe Systems.

Other product and brand names are trademarks of their respective owners.

Acknowledgment

This document was written by the CRM Information Development group of Avaya

CONTENTS

BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1THE ADU SERVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Start-up Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Cooperation of ADU Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2THE AGENT DATA UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Definition of an ADU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

The ADU Lifecycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

ADU Creation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

ADU Activity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

ADU Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Listing Active ADUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

The ADUID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

The ADU Data Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

ADU Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Core ADU Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Agent ADU Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Voice Data Containers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Queue ADU Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Containers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Container Names and Special Tokens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Limitations of Container Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Container Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3EVENT MONITORING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

ADU Event Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Starting and Stopping Event Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Contents

Setting Event Monitoring Criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Monitoring Criteria: Syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Relational Operators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Boolean Operators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Monitoring Criteria: Wildcards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Monitoring Criteria: Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4ALARMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

5 ADU SERVER CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

System Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

ADU Server Alias Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

6IDL SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

7 ADU SERVER METHODS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Method Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Exception Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Routing Requests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Method Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

4 Agent Data Unit Server Programmer’s Guide

BEFORE YOU BEGIN

Typographical Conventions

This guide uses the following font conventions:

Font Type Meaning

code This font signifies commands, information that you enter into the computer, or

information contained in a file on your computer.

italics

jump Blue text in online documents indicates a hypertext jump to related information. To view

This font is used to add emphasis to important words and for references to other chapter names and manual titles.

It also indicates variables in a command string.

the related material, click on the blue text.

Notes, Tips, and Cautions

Note: A note calls attention to important information.

Tip: A tip offers additional how-to advice.

Caution: A caution points out actions that may lead to data loss or other serious problems.

Contacting Technical Support

If you are having trouble using Avaya software, you should:

1 Retry the action. Carefully follow the instructions in written or online documentation.

2 Check the documentation that came with your hardware for maintenance or hardware-related

issues.

3 Note the sequence of events that led to the problem and the exact messages displayed. Have the

Avaya documentation available.

4 If you continue to have a problem, contact Avaya Technical Support by:



Logging in to the Avaya Technical Support Web site (http://www.avaya.com/support/qq).



Calling or faxing one of the following numbers from 8:30 a.m. to 8:30 p.m. (Eastern Standard Time), Monday through Friday (excluding holidays):



Toll free in the U.S. only: 1-888-TECH-SPT (1-888-832-4778)



Direct line for international and domestic calls: 512-425-2201



Direct line for faxes: 512-719-8225



Sending email with your question or problem to crmsupport@avaya.com. You may be asked to email one or more files to Technical Support for analysis of your application and its environment.

Note: If you have difficulty reaching Avaya Technical Support through the above URL or email address, please go to www.avaya.com for further information.

Product Documentation

Most Avaya product documentation is available in both printed and online form. However, some reference material is available only online, and certain information is available only in printed form. A PDF document with detailed information about all of the documentation for the Avaya Interaction Center is included in the also included on the separate documentation CD-ROM.

Readme File

The Readme file is an HTML file included on the Avaya Interaction Center software CD-ROM. This file contains important information that was collected too late for inclusion in the printed documentation. The Readme file can include installation instructions, system requirements, information on new product features and enhancements, suggested work-arounds to known problems, and other information critical to successfully installing and using your Avaya software. You may also receive a printed Addendum to the Readme, containing similar information uncovered after the manufacture of the product CD-ROM. You should review the Readme file and the Readme Addendum before you install your new Avaya software.

Electronic Documentation

The electronic documentation (in PDF or HTML format) for each Avaya Interaction Center product is installed automatically with the program. Electronic documentation for the entire Avaya product suite is included on the product CD-ROM and the documentation CD-ROM.

Doc directory on the product CD-ROM. This PDF document is

You can also view the documentation set online at http://www.avayadocs.com.

6 Agent Data Unit Server Programmer’s Guide

Printed Documentation

You can purchase printed copies of these manuals separately. For details, see on the back of this manual’s title page.

License to Print the Electronic Documentation

Online copies of documentation are included on the CD-ROM that accompanies every software release. An Avaya customer who has licensed software (a “Licensee”) is entitled to make this online documentation available on an internal network or “intranet” solely for the Licensee's use for internal business purposes. Licensees are granted the right to print the documentation corresponding to the software they have purchased solely for such purposes.

Right-To-Print License Terms

Documents must be printed “as-is” from the provided online versions. Making changes to documents is not permitted. Documents may be printed only by any employee or contractor of Licensee that has been given access to the online documentation versions solely for Licensee's internal business purposes and subject to all applicable license agreements with Avaya. Both online and printed versions of the documents may not be distributed outside of Licensee enterprise or used as part of commercial time-sharing, rental, outsourcing, or service bureau use, or to train persons other than Licensee's employees and contractors for Licensee's internal business purposes, unless previously agreed to in writing by Avaya. If Licensee reproduces copies of printed documents for Licensee's internal business purposes, then these copies should be marked “For internal use only within <Licensee> only.” on the first page or cover (where <Licensee> is the name of Licensee). Licensee must fully and faithfully reproduce any proprietary notices contained in the documentation. The copyrights to all documentation provided by Avaya are owned by Avaya and its licensors. By printing any copy of online documentation Licensee indicates its acceptance of these terms and conditions. This license only governs terms and conditions of printing online documentation. Please reference the appropriate license agreement for terms and conditions applicable to any other use, reproduction, modification, distribution or display of Avaya software and documentation.

Educational Services

Avaya University provides excellent training courses on a variety of topics. For the latest course descriptions, schedules, and online registration, you can get in touch with us:



Through the web at http://learning2.avaya.com



Over the telephone at 800-288-5327 (within the U.S.) +001 303-406-6089 (outside of the U.S.)



Through email at Avaya.U.Helpdesk@accenture.com

Issue 1.0 June 2002 7

8 Agent Data Unit Server Programmer’s Guide

CHAPTER 1

Overview

The Agent Data Unit (ADU) Server is responsible for tracking the state of agents at the contact center. Agents are also referred to as customer service representatives, or CSRs. The term “agent” is used throughout this book to signify a customer service representative.

When an agent logs in the Avaya Interaction Center (Avaya IC), the ADU Server creates a record of the agent's session on the system. This record is called an Agent Data Unit or ADU. The ADU contains information such as the agent’s login ID, equipment number, phone type, time of login, state (InCall, WrapUp, and so on), and the time the current agent state was entered. It also contains a unique identifier (ADUID) for each ADU. The information in an ADU is used by IC Manager to generate real-time Agent Status monitors.

The ADU Server manages the ADU throughout its lifecycle. It creates new ADUs, stores open ADUs, and provides services that enable clients to interact with an agent's record. When an agent ends a session on the system, the server terminates the agent’s ADU.

HE ADU SERVER

The ADU Server is also responsible for monitoring the contents of ADUs. When ADUs are modified, the ADU Server generates events to interested clients.

Note: The ADU server is vary similar in function to the EDU (Electronic Data Unit) Server. With minor exceptions, the ADU Server functions the same way as the EDU Server.

Start-up Procedures

When Avaya IC starts up, the Avaya Toolkit starts up the ADU Server. When an agent logs in to Avaya IC, the Toolkit invokes the ADU.FindOr() method, causing the ADU Server to find or create an ADU for the agent.

If for some reason the ADU Server is not running when an agent logs in, the ADU.Create() method invocation causes the ADU Server to be started.

Chapter 1 The ADU Server

Cooperation of ADU Servers

When a new ADU Server is added to Avaya IC, existing ADU Servers must be made aware of the new server through use of the IC Manager. Refer to IC Administration Volume 1: Servers &

Domains for information on updating servers.

When the ADU Servers have been made aware of each other, they can make requests of each other. This is most significant in the area of the Assign method. When a client Assigns to an ADU Server, the Assign is relayed to other ADU Servers, and they watch for ADUs that match the client’s Assign criteria as well. This makes Assign a relatively expensive operation, and clients should be designed so they only need to Assign once to specify the ADUs in which they are interested. Assigning to multiple ADU Servers is unnecessary and causes numerous problems.

Every ADUID identifies the server that created it and the time at which it was created. When a client requests access to an ADU, the ADU Server that the client is using acts as a proxy to the originating ADU Server of the ADU.

10 Agent Data Unit Serve r Programmer’s Guide

CHAPTER 2

HE AGENT DATA UNIT

Definition of an ADU

When an agent logs in to Avaya IC for the first time, a record called an Agent Data Unit (ADU) is created. The ADU contains information about the agent’s activities during the session. A typical ADU might contain the time the agent logged in, the various states the agent entered (InCall, WrapUp, and so on..), and the time when the agent last entered each state.

Note: When an agent logs back into Avaya IC, a new ADU is not created. Avaya IC uses the ADU that was created at the initial login.

The information in ADUs is used to create Agent Status monitors in IC Manager.

The ADU Lifecycle

The lifecycle of an ADU is comprised of three stages: creation, activity, and termination. Each of these stages is discussed in this section.

ADU Creation

Every agent session has a corresponding ADU. When an agent logs on to Avaya IC for the first time, the Avaya Toolkit invokes the ADU.Create() method, which passes the agent’s Avaya IC login ID. In response, the ADU Server creates an ADU, assigns it a unique identifier called an ADUID, and stores the creation time and the agent’s login ID in the ADU. This ADUID is used whenever the agent logs back into Avaya IC. In other words, when the same agent logs out and back in again, the ADU server will attempt to reuse the same ADUID.

This behavior differes slightly from the way ADUIDs were created in previous versions (prior to version 5.5). In older versions, a new ADUID was created each time an agent logged in.

ADU Activity

The ADU is a real-time storage record that collects strings of text from multiple sources. During its life, the dual job of the ADU is to log the agent’s state information, as well as to collect the information ({name, value} data couples) entered by other clients or servers.

Chapter 2 The Agent Data Unit

Any application that wants to interact with an ADU has to request it by its unique identifier, the ADUID. Upon request, the ADU Server passes the ADUID out to other processes, thus enabling applications to request access to individual ADUs.

The ADU Server also honors requests to watch for ADUs that contain certain values. If any ADU matches the monitoring criteria, the ADU Server issues event messages (which contain the ADUID) to “interested” clients. (Refer to “ADU Event Monitoring,” on page 27

Typically, clients want to receive event notifications about ADUs, examine ADU contents, and modify ADU values. These activities are supported through method invocations. For example, a client could invoke one of the Get methods (GetOneValue(), GetSomeValues(), and so on) to ask the ADU Server to return values in an ADU. Chapter 7 of this manual describes the methods supporting these activities.

ADU Termination

When an agent logs out of Avaya IC, the agent’s ADU should be closed.

Before an ADU can be closed, the ADU Server must first verify that all processes are done with it. For each ADU, the ADU Server maintains an internal list of processes that have read, transferred, or modified the ADU. Any process that invokes a method using the ADUID of the ADU is added to the list. When a client invokes the method ADU.Terminate(), the client's name is removed from the list. When the list is empty, the ADU can be terminated.

Note: In some configurations, it is possible for the agent to log out of the teleset without logging out of Avaya IC. The ADU is not closed in this case.

Safeguards are built into the ADU Server to terminate “suspicious” ADUs, in other words, those that appear to have been lost. Any ADU that has been idle for an extended period (thirty minutes, by default) is automatically terminated. (The idle time can be changed with the Idle Time configuration parameter, as described in “Configuration Parameters,” on page 37.)

If the ADU Server goes down, all ADUs are closed. For Agent Status monitors to be accurate, all users must log off and log back on again to create new ADUs.

Listing Active ADUs

You can view a list of active ADUs and the clients interested in them with the listadu utility.

To use this utility:

1 Copy

2 From the system prompt, type

listadu -iinterface -uusername -ppassword

-i interface to use (often ADU or VDU, or an alias or uuid of such a server)

listadu.exe from the Avaya IC5.x/bin directory to the directory in which the vesp.imp

and

vespidl.pk files are located, which is /etc by default.

12 Agent Data Unit Serve r Programmer’s Guide

-u user name to log in as (often Admin)

-p password of user

No space between -x and the text that follows.

Example:

listadu -iBostonADU -uAdmin -pDaphnie

There are defaults for all of these, but if a login error occurs, always specify -u and -p.

The ADUID

When an ADU is created, it is automatically given an identification number (ADUID) that uniquely defines the agent's Avaya IC session. The ADUID is a 32 byte hexadecimal string partially composed of the time and date of creation of the ADU, as well as its progenitor–the software process and machine that created it. A combination of the IP and port identifies which ADU Server is the progenitor of this ADU.

The following example illustrates the structure of an ADUID.

The ADUID

ADUID = 30f4216300000000780000261f430002

Bytes

0–7 30f42163 Timestamp. Hex representation of the number of seconds since

8–11 0000 Hex representation of a uniqueness value

12–15 0000 Reserved

16–23 78000026 Hex representation of the IP address

24–27 1f43 Hex representation of a port

28–31 0002 Reserved

Example Contents

The ADU Data Table

The data in an ADU consists of a series of sequenced {name, value} couples that represent information about an agent's session on Avaya IC. For example, the name/value pair {createtime,19970704 08:00:01} represents the time the ADU was created. The field name createtime is the name data element and 19970704 08:00:01 is the value assigned to the field. Applications gain access to data by references to field names.

Description

January 1, 1970.

Issue 1.0 June 2002 13

Chapter 2 The Agent Data Unit



Names are restricted to non-empty strings of less than 35 characters. (Container names may contain more than 35 characters. Refer to “Container Names and Special Tokens,” on page 22 for information on container names.) Names may contain letters (a..z, A..Z), digits (0..9), and the underscore character (_). Data element names are case sensitive: “foo”, “Foo”, and “FOO” refer to three different data elements.

The set of names that Avaya IC software reserves for its own system use are listed in the following section. Although they are not strictly reserved words in the technical sense, to use these field names for anything other than their pre-defined purposes could result in conflicts between applications.



Values, the pieces of data assigned to a field, are strings that may contain from 0 to 4096 characters. Although longer strings are technically permissible, they are strongly discouraged. Any character except the null character (′\0′) is legal. An average ADU is expected to contain approximately 100 values. It can hold many more values, but additional values require more memory, which can affect system performance, and each time the ADU Server must allocate additional memory the system slows briefly.

The ADU Server sets certain name/value data pairs, such as the ADUID. Other name/value data pairs are written into the ADU by other processes. Because the ADU can accept input from a variety of sources, data could come from other servers or the agent's application. Changes to all data values are recorded, including information on who made the change and when the change was made.

ADU Contents

This section describes the ADU fields for Avaya IC in three categories: Core, Agent, and Queue. The Core category contains the ADU fields that are used by agents and queues. The Agent and Queue categories provide the ADU fields used by agents and queues respectively.

The following information may be maintained in an ADU by various system processes. Not all of these items are maintained in all environments.

Caution: The field names listed below can be used in client applications. However, they should be treated just like reserved words with specific meanings. Do not use these names for other than

these explicit purposes! Doing otherwise could result in misinterpretation. Some are read-only values to clients.

14 Agent Data Unit Serve r Programmer’s Guide

Core ADU Fields

The following ADU fields are used by both agents and queues on Avaya IC.

Field Name Description Set By

adu_id A string that uniquely identifies the ADU. ADU Server

ADU Contents

createtime The date and time the ADU was created

ADU Server

in yyyy-mm-dd hh:mm:ss format.

createtimet The time_t of the ADU creation. ADU Server

duration Historical field. ADU Server

endtime The time of the last successful

ADU Server termination of the ADU or equivalent such as removal due to idleness in hh:mm:ss format.

persistence The date and time that the EDU was last

EDU Server stored in the DUStore Server.

suspend The reason that the ADU was last

ADU Server removed from server memory. This can be any one of the following:



normal–all involved parties have suspended use of the ADU.



expired–removed from memory due to idleness.



exit–server was shut down.



overflow–removed from memory for other ADUs.



forced–removed by ForceTerminate method.

termination A string representing the reason for the

N/A termination of the ADU: normal, overflow, expired, or exit.

time Reserved for internal use. This field is

N/A inserted into each event that is set to reporting packages and is reserved for that purpose.

type The type of resource, set to “per”. Tool Kit

Issue 1.0 June 2002 15

Chapter 2 The Agent Data Unit

Agent ADU Fields

The following ADU fields are used by agents on Avaya IC.

Field Name Description Set By

auxwork.<m>.detail A code that describes the reason that the

agent entered this state.

auxwork.<m>.endtime The time that the agent exited this

AuxWork state.

auxwork.<m>.starttime The time that the agent entered the

current AuxWork state. The <m> is the increment time that agent enters into a different AuxWork state.

ceiling The maximum task load limit for the

agent.

cobject A unique representation of the client’s

last_termination The identity of the last user of the

Terminate method, used as debugging information.

load The maximum number of contacts that

can be concurrently assigned to the agent across all of the media channels.

Avaya IC in hh:mm:ss format.

loginid

The agent's Avaya IC login id.

Blender Server

Workflow Server

Tool Kit

ADU Server

Workflow Server

Tool Kit

logout The time that the agent logged off from

Avaya IC in hh:mm:ss format..

<media>.abandoned The total number of contacts that have

been abandoned since the agent logged in to the media channel. (voice, email, web)

<media>.ceiling The maximum task load limit on the

media channel.

<media>.connector The UUID of the Media Connector

Server: voice, email, or web.

<media>.contactcount The number of contacts assigned to the

agent for this media channel.

16 Agent Data Unit Serve r Programmer’s Guide

Tool Kit

Media Connector Server

Workflow Server & IC Manager

Media Connector Server

(Sheet 1 of 4)

Field Name Description Set By

ADU Contents

<media>.contactsoffered The total number of contacts that arrived

since the agent logged into this media channel. IC Manager computes handled

contacts by taking the difference between <media>.contactsoffered and <media>.abandoned.

<media>.currentload The current task load assigned to the

agent for this media channel. This is used to throttle delivery of ADUs.

<media>.load The maximum number of contacts that

can be concurrently assigned to the agent through this media channel.

<media>.loginid The login id of the agent for this media

channel.

<media>.login The time that the agent signed into the

media channel in hh:mm:ss format.

<media>.logout The time that the agent signed out of the

media channel hh:mm:ss format.

<media>.privileges This field defines the agent’s capability to

manipulate agent attributes, such as task load, for this media channel.

<media>.state The media channel state of the agent.

Normalized channel states are:



Logged-In



Logged-Out



Active



Available



Busy



Wrap-up

Media Connector

Server

Workflow Server

Workflow Server &

Blender Server

Media Connector

Server

Media Connector

Server

Media Connector

Server

Media Connector

Server &

IC Manager

Workflow Server &

Blender Server

<media>.state.<state>.total The total duration time of the agent in the

media channel state.

<media>.updatetime The time that the media channel was last

updated in hh:mm:ss format.

<media>.<n>.eduid

The Electronic Data Unit (EDU) associated with this contact where

is the contact number for the agent on this media channel.

<media>.<n>.sourcequeue The queue from which the contact was

received where

is the contact number

for the agent on this media channel.

Media Connector Server

(Sheet 2 of 4)

Issue 1.0 June 2002 17

Chapter 2 The Agent Data Unit

Field Name Description Set By

<media>.<n>.state The current media contact state.

Normalized contact states are:



Alerting



Active



On-Hold



Wrap-up



Completed

<media>.<n>.state.<state>. starttime

The time that the media channel state started.

modifier This field identifies the login id or uuid of

the user who caused the event. It is inserted into each event that is sent to reporting packages.

owner The loginid or UUID of the application

that created the ADUID, or that last used the Transfer/SetTransfer methods. (historical).

privileges This field defines the agent’s capability to

manipulate agent attributes, such as task load, for Avaya IC.

state The current agent state of the agent.

Normalized agent states are:



Logged-In



Logged-Out



Available



InitAuxWork



AuxWork

Media Connector Server

ADU Server

Workflow Server & IC Manager

Workflow Server & Blender Server

statedetail This field provides optional information

about the agent’s current state.

transfercount The number of times the ADU was

transferred since it was created. (historical)

ts. Container names beginning with ts. are

reserved for use by the Avaya Definity Telephony Server.

ts.<n>.loginid The login id of the agent for the Avaya

Definity switch.

ts.<n>.phone Agent extension, where

number for the agent on the Avaya Definity switch.

ts.<n>.ptype The Phone type–eas, acd. Definity Telephony

18 Agent Data Unit Serve r Programmer’s Guide

is the contact

Blender Server

ADU Server

Definity Telephony Server

Server

(Sheet 3 of 4)

ADU Contents

Field Name Description Set By

ts.<n>.equip Equipment number. Definity Telephony

Server

ts.<n>.starttime Time (time_t) that the client assigned to

the TS.

voice.acdname The name of the ACD the TS is serving. Telephony Server

voice.connector

voice.connectorname

Definity Telephony Server

(Sheet 4 of 4)

Voice Data Containers

The following table lists the call containers in which end point events and attributes are stored. X represents the unique identification number for each end point. Y and Z represent sequence numbers within each end point’s activities.

Note: The 6.0 style call containers are presented in this table. Call containers in the 5.5 style are still supported, and is documented in Appendix B of the Telephony Services for the Avaya Definity G3, Release 5.5 manual.

Name Value Explanation

voice.X delta time For voice.1, this is base time (should be

zero). For other cases, it is elapsed time in seconds since creation of the EDU.

voice.X.abandon reason for abandoning the call: "in

queue," "while ringing," "while on hold."

voice.X.agent_key unique database record key The key that retrieves the agent record

voice.X.conferencedest.Z phone number The destination phone number (Z) of a

voice.X.connect delta time The elapsed time in seconds between

voice.X.destination phone number Phone number of client at end point X.

voice.X.direction inbound/outbound The direction of the call to or from the

voice.X.exit_reason reason for exit: "normal,” "transfer,”

"abandon,” "other."

voice.X.holdtime.Y time in seconds Time spent on hold during hold

If the exit reason of a call end point is "abandon," this item provides additional details.

from the database.

conference call, where Z = 1, 2, 3, ...

the creation of the EDU and the time the call was connected.

agent.

The switch supplies a reason for the termination of a call end point.

instance Y.

Issue 1.0 June 2002 19

Chapter 2 The Agent Data Unit

Name Value Explanation

voice.X.leg_id unique id (UUID) Unique leg_id of the current leg of the

call.

voice.X.loginid loginid Login id of client at end point X.

voice.X.origin phone number Phone number (ANI) at other end of end

point X.

voice.X.queue delta time The elapsed time in seconds between

the creation of an EDU and the time at which the switch reports the call as queued.

voice.X.queue_number queue number Queue number configured within the

CallCenter switch as an Application Group.

voice.X.queuetime time in seconds Time reported by the switch between a

call arriving on an inbound trunk of the switch and the call being sent to an agent queue. Note: Currently, this value is always zero (0). Subsequent releases of the telephony server will supply more meaningful values.

voice.X.ringtime time in seconds Time reported by the switch between

agent phone starting to ring and agent answering the phone.

voice.X.talktime time in seconds Time reported by the switch between

agent answering the phone and agent hanging up the phone.

voice.X.transfer phone number The phone number to which the call has

been transferred.

Queue ADU Fields

The following ADU fields are used by queues on Avaya IC.

Field Name Description Set By

abandoned The total number of contacts that have

been abandoned before reaching an agent from this queue.

connector The UUID of the media connector server

responsible for the queue.

contactcount The number of contacts currently in the

queue.

Media Connector Server

(Sheet 1 of 2)

20 Agent Data Unit Serve r Programmer’s Guide

Field Name Description Set By

Containers

contactsoffered The total number of contacts received by

the queue. The number of handled contacts is computed by IC Manager by

taking the difference between contactsoffered and abandoned.

id The media channel specific id of the

queue. The id must be unique for a media channel in a specific site.

media The type of media channel over which

the queue is receiving contacts: voice, email, or web.

minimumagents The fewest number of agents that should

be assigned to one queue.

oldest The arrival time of the contact that has

been in the queue for the longest period.

priority The priority level assigned to the queue.

It can be 1 for the highest priority down to 10 for the lowest.

servicelevel The interval within which a queued

contact should be assigned to an agent on the system. This time period value varies across media channels.

Media Connector Server

servicelevelmiss The number of contacts that were not

queue_key The unique identifier for a queue, for

ttlqueuetime The period of time that contacts have

updatetime The time of the last update to the queue. Media Connector

youngest The arrival time of the contact that has

Containers

A container is a grouping of values under a common name. Containers are trees of data within an ADU.

handled during the prescribed service level time.

reporting on queue activity. This is only set when a Queue is involved in the routing of the segment. This is not set when it is a direct transfer or route to an agent, or if it is routed through Advocate.

spent in the queue.

been in the queue for the shortest period.

Media Connector Server

Server

Media Connector Server

(Sheet 2 of 2)

Issue 1.0 June 2002 21

Chapter 2 The Agent Data Unit

For example, within each ADU, the Telephony Server creates a container called ts, and within the ts container it creates a subcontainer for each of the agent's logical phones (ts.1, ts.2, and so on). Each data item pertaining to that logical phone takes a private subtree of the container–ts.1.phone, ts.1.ptype, and so on. Values for a second logical phone are written in fields ts.2.phone, ts.2.ptype, and do not interfere with values written for the first logical phone.

Note: For the Northern Telecom Meridian Link, the position ID and the IDN are considered separate logical phones, even though they share the same physical device.

The ts containers are maintained by Telephony within Avaya IC. You can create additional containers to suit your specific application.

Methods exist to return an entire container or subcontainer. Using the above example, to see all the data about the agent's first logical phone, you would use the GetSubTree() method on the ADUID and ask for “ts.1”. With the exception of the GetSubTree() and DeleteSubTree() methods, there are no special container methods. Any method that involves getting or setting data can use containerbased names.

Container Names and Special Tokens

You can specify container names or you can allow the ADU Server to generate container names for you based on your instructions. A number of special tokens are available for use when constructing container names. These tokens expand into appropriate strings and automate many of the steps involved in using containers.

Container names have multiple parts (two or more) separated by dots. Each part, called a name token, is limited to 1–35 alphanumeric characters (underscore is also permitted), with entirely numeric name tokens reserved for use with the special tokens described below. Up to 31 dots (32 tokens total) are permitted in a container name. Note that processor usage for container names is low, but is proportional to the number of tokens in the name.

There are four special tokens available for use with container names:

+ The simplest special token is +. This expands into a numeric token that is greater than

the last numeric token created with a + in that position (for that container in that ADU). The first time it is used, it generates a 1. This means that if any client specifies a name of “code.+”, the ADU server turns it into “code.1”, but the next time any client uses “code.+” in that ADU, it expands into code.2. This makes it very easy to create subtrees within a container. The name generated in this way will never be the name of an existing subtree. (The gencount and padwidth configuration parameters, described in “Configuration

Parameters,” on page 37), can affect subtrees created with the + token.)

22 Agent Data Unit Serve r Programmer’s Guide

! The ! token expands into a numeric token that belongs to the client. Tokens that belong

to a given client are created via a special use of the + token. Essentially, a subcontainer created with + is assumed to belong to a caller (usually the one who created it), and the ! token will find it.

To create a subcontainer for another client, add the loginid of the client after the + token that creates it, as follows:

“agent.+jane”

Whatever number it creates, it will be matched by a request for “agent.!” by client jane.

If several subcontainers have been created for the same user, the ! token seeks out the highest numbered (most recently created) one. If no subcontainer has been created for the client, the use of ! generates an exception. To find another client’s subcontainer, add the loginid of the client after the ! token:

“

containername.!loginid

null The null token contains no characters. It matches the subcontainer most recently

created with the + token, regardless of who it was created for or who the caller is. This is most generally useful in creating and filling a subcontainer in one method call. For example, the following names given to SetValues:

“mydata.+” “mydata..age“ “mydata..height”

”

Containers

would create a new, numbered subcontainer in mydata, and within that same subcontainer create age and height. If mydata.+ generated mydata.3, this would generate mydata.3.age and mydata.3.height.

Use of the null token should occur within the same method invocation as the use of the + token it relates to. Otherwise, some other application might use the + token within the same container and ADU, and change the meaning of the null token unexpectedly. However, if the intent is to add data to the most recently created subcontainer no matter who created it, the null token is appropriate.

* The * is permitted only within Assign methods and is described in “Monitoring Criteria:

Wildcards,” on page 32.

Limitations of Container Syntax

The first token in a container name cannot be a special token.

When a * token has been used, special tokens other than * cannot be subsequently used.

Note that some methods do not permit some tokens. Most do not support * and some (GetValues and methods like it) do not (meaningfully) support +. For example, in the method invocation GetValues( “a.+.x”), the + token would be interpreted as “create the next number in the sequence,” which is not meaningful for the GetValues method, as the name being generated cannot exist yet and so cannot be read..

Issue 1.0 June 2002 23

Chapter 2 The Agent Data Unit

Container Configurations

The following TS configuration parameters were agreed upon with regards to containers:

Parameter Ty pe Default Description

aducon bool false Turns ADU Containers on/off

tscon bool false Turns EDU Containers on/off

containers_56_style bool false Determines if “state” statistics in the old style (5.6) are written.

containers_60_style bool true Determines if “state” statistics in the new style (6.0) are written.

Following are examples of the results for a call scenario where an agent receives a queue call, hold and retrieves it, blind transfer to a second agent who concludes the call.

Values ALWAYS written:

ADU.Create VDU.Create

loginid ani

ADU.Update VDU.Update

voice.contactcount phone

voice.acdname ani

voice.connector dnis

voice.connectorname dest

voice.device orig

voice.eduid ext

voice.contactsoffered loginid

voice.state.loggedin agent.+

voice.state.available

dnis

primary_ani

primary_dnis

loginid

agent_key

voice.state.active

voice.state.loggedout

24 Agent Data Unit Serve r Programmer’s Guide

EDU Values written if tscon is set to true:

voice.1.loginid

voice.1.leg_id

voice.1.agent_key

voice.1.destination

voice.1.origin

voice.1.direction

voice.1.connect

voice.1.holdtime

voice.2.loginid

voice.2.leg_id

voice.2.agent_key

voice.2.destination

Containers

voice.2.origin

voice.2.direction

voice.2.connect

voice.1.exit_reason

voice.2.transfer

voice.2.ringtime

voice.2.queuetime

voice.2.talktime

voice.2.exit_reason

Issue 1.0 June 2002 25

Chapter 2 The Agent Data Unit

ADU and EDU values written if containers_56_style is set to true:

voice.1.state (value="alerting")

voice.1.state.alerting.starttime

voice.1.state (value ="incall”)

voice.1.state.incall.starttime

voice.state.incall.total

voice.1.state (value="hold")

voice.1.state.hold.starttime

voice.state.hold.total

voice.2.state (value="incall")

voice.2.state.incall.starttime

voice.1.state (value="disconnected")

voice.1.state.disconnected.startti me

ADU and EDU Values written if containers_60_style is set to true:

voice.1.stdstate.1009981854 (value="alerting”)

voice.1.stdstate.1009981854.alerting.reason

voice.1.stdstate.1009981856 (value="active")

voice.1.stdstate.1009981856.active.reason

voice.1.stdstate.1009981858 (value="inactive")

voice.1.stdstate.1009981858.inactive.reason

voice.2.stdstate.1009981863 (value="active")

voice.2.stdstate.1009981863.active.reason

voice.1.stdstate.1009981863 (value="terminated")

voice.1.stdstate.1009981863.terminated.reason (value="101")

26 Agent Data Unit Serve r Programmer’s Guide

CHAPTER 3

VENT MONITORING

ADU Event Monitoring

This chapter describes the events that are sent by the ADU Server. This chapter also explains how to assign a request on behalf of a client and how to establish monitoring criteria. The ADU Server continuously monitors the contents of ADUs for changes, and reports those changes to interested clients through event messages.

Clients register their interest in ADUs by assigning to the ADU Server with a monitoring criteria, which is a specification describing the condition that should generate an event notice. For example, a client might request notification when an agent enters wrapup state, or when an ADU is terminated. The client receives event messages about ADUs that match the specification, and continues to receive all events generated for those ADUs for as long as they match the client's monitoring criteria.

The ADU Server generates seven types of events that describe changes to existing ADUs. The following table lists the events and the contents of the event messages written in the ADU and sent to monitoring clients.

Event Description Message

ADU.change A modification has occurred in a monitored

ADU.

ADU.delete Values have been deleted from the ADU. All deleted values.

ADU.drop The ADU has changed and no longer

matches the assign criteria. It will no longer be monitored. If the ADU later changes so that it again meets the assign criteria, the client gets an ADU.watch event.

All affected {name, value} couples and the ADUID.

The ADUID.

(Sheet 1 of 2)

Chapter 3 Event Monitoring

Event Description Message

ADU.end The ADU has been terminated. The server

passes an ADU.end message to all monitoring applications.

ADU.transfer The ADU has been transferred. The new client and the

ADU.watch The ADU matches the monitoring criteria. All of the data elements in the

All of the data elements in the ADU.

ADUID. (Note that ADUs are not generally transferred. This event is relatively rare.)

ADU.

(Sheet 2 of 2)

When a client first assigns monitoring criteria to the server:



All existing ADUs are checked to see if any match the specification. All subsequently created ADUs are checked for a match.



Any ADUs that do match the criteria are placed under watch and an ADU.Watch event message is sent to the monitoring application.



Changes to ADUs under watch are reported to the application by an ADU.Change event.

Note: When a client has assigned to the ADU Server, it should monitor the event data stream for the data it wants, rather than invoking ADU.Get…() methods repeatedly.

As values are set in the ADU, the ADU Server sends Change events to assigned clients. The timing, order, and content of the Change events depend on the components setting the values, are is therefore variable.

Starting and Stopping Event Monitoring

The ADU Server methods ADU.Assign() and ADU.Monitor() let you set up monitoring conditions. The method ADU.Deassign() lets you revoke them.

By default, a client does not receive change events for the ADU changes that it itself initiates. This cuts down on needless event traffic. It does receive other sorts of events, as well as event messages for changes caused by other clients. If the change causes a .Watch or .Drop event, it is reported to the client. To receive change events for the client's own changes, prefix the Assign or Monitor expression with a plus symbol (+):

For example:

[ADU.Assign("+*")]

(The asterisk (*) in the example indicates that all ADUs in the local ADU Server should be monitored

28 Agent Data Unit Serve r Programmer’s Guide

Setting Event Monitoring Criteria

Assigning to the ADU Server and monitoring an ADU do not add a client's name to the internal list of ADU-modifying clients. (The internal list of clients is described in “ADU Termination,” on

page 12.) Assigning allows the client to watch the activity of an ADU. The client does not have to

issue an ADU.Terminate() for each ADU being watched.

By default, a client's assign criteria is distributed to all ADU servers. If this is not desired, prefix the Assign or Monitor expression with a colon symbol (:):

For example:

[ADU.Assign(":loginid=wynn")]

If you specify both : and +, : must come first. So ":a=b" watches field a for value b, and reports only on those local vdus.

Note: In this sense, local means "this VDU server". If you fail over to a different VDU server, you may not get the result you were expecting.

iver=148

To test, try: [ADU.Assign(":state#Z")]

In a WAN, your ADU server should show events coming back for all logged in agents, but the other ADU servers should only get RemoteWatcher requests with empty strings, and should send no events back.

Setting Event Monitoring Criteria

ADUs are selected for monitoring by criteria matching. A criteria is an expression that selects some ADUs and rejects others according to a defined specification. If a criteria expression is provided as a parameter to the Assign() or Monitor() method, each name/value pair in the ADU is tested against it. If the criteria determine that a match exists, the ADU is watched. Subsequent changes are sent to the client as change events.

The following values cannot be successfully used in an Assign criteria:



createtime



createtimet



duration



endtime



suspend



termination



transfercount.

Monitoring Criteria: Syntax

The general syntax of a criteria statement is:

method (name relationalop value [booleanop] name relationalop value)

Issue 1.0 June 2002 29

Chapter 3 Event Monitoring

Example: ADU.Assign "loginid=Joe & ts.1.s=wrapup"

In the above example, the client has assigned to the ADU Server, asking it to watch for any ADU that contains the following two values:



“Joe” in the field loginid



“wrapup” in the ts.1.s field.

In other words, notify the client every time Joe is in the wrapup state.

An example of a selection criteria string when making an ADU monitor request:

//[ADU.Monitor("adu_id=387cdde0000100000a6403b81f450002 |( type=per & name=jonathan & connectrate=* ) | ( type=queue & name=phone_queue & idletime=* )")]

Note the spaces between the parentheses and the type designation.

You can construct complex statements that evaluate multiple conditions by grouping expressions together with parentheses to control the order of evaluation.

A single * character has a special meaning when used as a monitor criteria. It causes all local ADUs (those in the local ADU Server) to be watched. This is used by the IC Manager and should generally be avoided by other applications, as it generates a very large amount of event traffic.

Setting the monitor criteria to a null value (“”) stops monitoring.

The Assign method does not accept special tokens !, +, or the null token in container names. These tokens have specific meanings for a particular ADU and vary from ADU to ADU. The Assign method has no provision for names that do not have ADU-independent meaning.

The Assign and Monitor methods contain criteria strings that allow you to use additional syntax. At the end of the string is a list of fields, called a projection list, enclosed in curly brackets where you can specify filter criteria. The list is comma separated with no spaces between the fields.

For example,

{specification,specification...}

You can specify the type of field name in three ways:

1 A simple fieldname, such as a, b, or c.

2 A wildcard container name, such as a.* or a.*.d. The wildcard designation (*) can be used after

a dot (.), at either end of the specification, or followed by a dot (.) in the specification.

3 A request to retrieve all of the fields below a specified point in a container tree, as in “a.b?”.

This format collects all of the field names below the specified point in container tree. It does not collect field names at its own level or higher on the tree.

Example:

+vdu_id> "" {call?,data.*,loginid}

Note: Spaces are optional after the selection criteria and before the projection list. The projection list itself is optional, but no filtering is done without one. If a projection list is used, it cannot be empty.

30 Agent Data Unit Serve r Programmer’s Guide



This assign criteria watches all EDUs in the system because all EDU IDs are longer than empty strings.



Change events that do not reflect a change in the loginid, any matching data.*, or any subcontainer of the call container are also suppressed.



Change events that not suppressed are trimmed to list only the names that are provided on the projection list. The duid, time, and modifier fields are also provided.

Note: Watch and drop events are not modified and they are always sent with their full content. User events, which are very rare, would be modified as they are actually change events with a different name.

Relational Operators

Values can be compared to each other as described below. There are four permissible relational operators. In the description column, the term couple refers to a name/value pair.

Symbol Definition Description

= equal Find a couple that matches the specified name and value.

Setting Event Monitoring Criteria

Wildcards are accepted.

< less than For a given name, find all couples with values less than the

specified search value (string-based).

> greater than For a given name, find the set of couples with values

greater than the specified criteria (string-based).

: exactly equal to For a given name, find a couple that exactly matches the

specified value. Wildcards are not accepted.

# not Expressions are not equal to each other.

The ADU Server compares the name/value data within an ADU against the criteria string one character at a time, starting with the leftmost character, until either a mismatch occurs or one field runs out of characters. Comparisons are case-sensitive. “Foo” is not the same as “foo” or “FOO”. To avoid ambiguity, enclose the specified value within double quotes (“”). Within a quoted string, (\") means quote and (\\) means backslash.

If the strings match character for character, they are equal. Strings can also be relatively compared. If one field runs out of characters without a mismatch, the relatively longer field is greater (for example, abc < abcd). If a mismatch occurs, the field containing the greater character is greater, (for example, 111 < 119). Because the comparison is string-based, not numeric, the field with the greater initial character is greater, (for example, 2 > 119).

Wildcards are permitted only with the equal (=) operator.

Issue 1.0 June 2002 31

Chapter 3 Event Monitoring

Boolean Operators

Boolean comparisons that return evaluations of true or false can be performed between two values. The two boolean operators are described below.

Symbol Definition Description

& and Both expressions must be true.

| or True if one or both expressions are true.

For example:

ts.1.s=Available | ts.1.s=WrapUp

selects all ADUs in which the agent state is either Available or WrapUp. Terms may also be grouped with parentheses for more complex expressions.

Monitoring Criteria: Wildcards

Instead of specifying each individual instance of a set, you can use wildcard symbols to stand in for other values. The wildcard symbols can be used in setting criteria given the following restrictions:



Wildcard usage is restricted to the equal (=) relational operator. You cannot use wildcards with the less than (<), greater than (>), or exactly equal to (:) operators.



Single character wildcards must have a character to match.

Each (?) symbol can stand in for one character. The (*) symbol can either be placed at the end of a value (a so-called value trailing wildcard), or can be entered by itself to find ADUs with an instance of any value (selects all ADUs as matching).

Wildcard Definition Example

? Match one character ts.1.ptype = ???

Find all couples named “ts.1.ptype” which contain a three-character value.

* Match an unlimited number

of characters.

ts.1.s.logout = * Find all ADUs for agents that have logged out of the teleset.

Container names used in an Assign can use limited wildcarding. Within an Assign, an expression like

ts.*.s = Available

selects any ADU in any subcontainer in ts in which the state is Available. Note that the ! token is not available in an Assign, but this use of the wildcard token can be used instead.

32 Agent Data Unit Serve r Programmer’s Guide

Monitoring Criteria: Examples

The following examples demonstrate how to instruct the server to monitor ADUs that fulfill specific criteria. As you can see, there is flexibility in specifying monitoring criteria. Choose the method that best fits the current circumstances.

Criteria Example Description

ts.*.phone = "1234" or ts.*.phone : "1234" Monitor all calls for agent extension 1234.

ts.*.phone > "0999" & ts.*.phone < "2000" Monitor all calls for agent extensions 1000 through

ts.*.phone = "1???" Monitor all calls for agent extensions 1000 through

Setting Event Monitoring Criteria

1999.

Issue 1.0 June 2002 33

Chapter 3 Event Monitoring

34 Agent Data Unit Serve r Programmer’s Guide

CHAPTER 4

LARMS

IC Manager provides system administration tools for monitoring alarm events. Visual and sometimes auditory alarms (beeps) are triggered whenever the system detects problems that require human intervention, such as server failures. Alarms are categorized as Emergency, High, Low, or Informational. (For more information about monitoring alarms, refer to IC Administration

Volume 1: Servers & Domains.)

To minimize Alarm Server traffic, alarms that occur repeatedly are gathered by the ADU Server and raised periodically. The repeat count indicates how many times the condition has occurred since the alarm was last raised.

The following table describes the alarms that are associated with the ADU Server.

Alarm Name Priority Description

AssignFail Emergency Cannot Assign to

ADU%s, ignoring it

BadADUInDS Emergency Bad UUID %s in DS’s

list of ADU servers

DumpADU High ADU overflow, killing

eldest

Cause/Recommended Action

Another ADU Server across the WAN is unavailable. A site has been cut off. WAN features may not be available.

Corruption in the DS has made it impossible to identify other ADU Servers for WAN work. Contact Technical Support (1800-886-3244).

The ADU limit set by the adus parameter has been reached. The oldest ADUs are being removed to make room for newer ones.

Increase the value of the adus parameter. Determine if ADUs are being left in the server when they are no longer needed, and possibly adjust timer settings (nouserinterval, idletime).

(Sheet 1 of 2)

Chapter 4 Alarms

Alarm Name Priority Description

FailADUCon High Connection to

closed; n dropped watchers

LostADUEvents High

NoMeInDS Emergency This ADU Server is not

NoEventSink High A VESP_Request call

events lost due to network congestion or error

listed in the domain’s DS for this ADU Server.

failed to send a request to the server named by the EventSink configuration parameter.

<uuid>

[reason]

Cause/Recommended Action

A connection to a remote server has failed. The UUID of the remote server is reported, as is the number of clients that were assigned to the server. The reason is often ADU.ServerFailed.

Event handling requests are timing out. approximate number of events that have been lost.

The configuration of servers and domains is incorrect. Contact Technical Support (1800-886-3244).

The server could not be reached. History is being lost. If you are not using a server to archive terminated ADUs, set the database configuration parameter to 0 and restart the ADU Server.

represents the

Victims High Shutdown with

in existence; objects discarded

ADUs

Check the vesp.imp and vespidl.pk installation files. If they do not list the server and interface, re-install the files and restart the ADU Server.

This alarm should not be generated. Contact Technical Support (1-800-886-3244.)

(Sheet 2 of 2)

36 Agent Data Unit Serve r Programmer’s Guide

CHAPTER 5

ADU S

ERVER CONFIGURATION

System Considerations

The Max Active Adus configuration parameter, described below, should be set with consideration for system capability. The number of ADUs that can be effectively handled by the ADU Server is proportional to the system's available memory and processor speed. A typical ADU requires 40K in memory. Active agent sessions might require 60K or more. Memory can be conserved by using the same data names in many ADUs. The memory space for name storage is shared. The memory used for storage of values, however, is not affected.

Processor usage may be decreased by setting values in groups as opposed to one at a time. When possible, gather sets of name/value pairs and apply them all at the same time.

ADU Server Alias Name

When setting an alias name for the ADU Server, note that the name “localADU” is reserved. In a WAN environment, it is used to segregate an ADU Server that has been taken offline. Refer to IC

Administration Volume 1: Servers & Domains for information on setting alias names for servers.

Configuration Parameters

The ADU Server is configured through the IC Manager. Refer to IC Administration Volume 1:

Servers & Domains for configuration instructions. The following table lists the label used when

configuring with IC Manager, followed in parentheses by the parameter name as it is required internally by the server.

Label Description

Checkpoint frequency (checkpoint.interval)

Idle Time (idletime)

Minimum interval period in seconds between requests to checkpoint a specified ADU into the DUStore server. A value of –1 means do not checkpoint.

Number of minutes an ADU may remain inactive before being terminated. The default is 90 minutes. Minimum is 1 minute, maximum is 30 days.

(Sheet 1 of 4)

Chapter 5 ADU Server Configuration

Label Description

No User Interval (nouserinterval)

Random Kill Interval (randomkillinterval)

Scan Interval (scaninterval)

Max Active Adus (adus)

Minimum number of seconds an ADU may linger in memory when there are no users active for it. Default is 60 seconds. Minimum is 1 second, maximum is 90 minutes.

Maximum number of seconds an ADU stays in memory after the usual timers have expired. The default is 30, the range is 1 to 180 seconds.

Random intervals are useful when a large number of ADUs are simultaneously suspended or deleted, causing the DUStore to be flooded with requests. Handling the requests over a 2-minute period decreases server stress.

Where such a situation is unlikely, more predictable timing and better memory usage result from a setting of 1. While testing to see if ADUs are being retired when they should be, 1 is also an appropriate setting.

Number of seconds to wait between checking various ADU Server timers. Higher values may save some CPU time. Lower values make for more predictable behavior during prototyping and testing. Default is 30 seconds. Minimum is 1 second, maximum is 60 seconds. Assume that other timers in the ADU could be off by as much as (this interval + 1) to start.

The maximum number of ADUs that the ADU Server keeps active at the same time. If more than this are created, it sends an alarm and forcibly terminate the oldest one to make room for each new one.

This value should be somewhat greater than the number of agents using this server to handle calls. The default varies by release. Always set this value explicitly. The number of ADUs that can be effectively handled by the ADU Server is proportional to the system’s available memory and processor speed. A typical ADU requires 40K in memory. Active agent sessions might require 60K or more.

Watchers (watchers)

Database (database)

Pool Size (poolsize)

Pool Growth Increments (poolgrowsize)

Number of fields (initialdatalength)

Pool Re-Pack (%) (repackfree)

The number of clients who are interested in assigning to ADU Servers. To start, this should be equal to the number of agents in the contact center (across all contact centers in a WAN environment), plus a few extra. Default varies by release. Always set this value explicitly, as the default is very large and some memory is wasted in each ADU if the value is set too high. If set too low, Assigns are rejected.

Should be checked if you want to enable the use of HISTADD reporting, unchecked if not. The default is unchecked.

The initial amount of memory allocated for data belonging to each ADU. Increase the pool size if a large amount of data is stored and performance needs to be improved. The default is 2048.

The amount of memory to add to the string pool for each ADU if the pool runs out. Increase the pool size allocation when more memory is needed to store strings or events. The default is 1024.

The number of fields expected in an ADU. This does not limit the number of fields, but when this number is exceeded, the server must reallocate space. The default is 128. If using containers, this value should possibly be increased to 256 or 512.

When the specified percentage of the pool belonging to an ADU pool becomes free, the ADU Server repacks the pool to save memory. Sites at which performance is critical and memory is plentiful may consider using a value of 100. The default is 25.

(Sheet 2 of 4)

38 Agent Data Unit Serve r Programmer’s Guide

Label Description

Configuration Parameters

DUStore (dustore)

DUStore ADU Batch Size (maxkills)

Poll Wait (pollwait)

Maximum number of Revisions (maxkeptrevisions)

Number of Cached Adu events (keepevents)

Retry Interval (serverretryinterval)

Enables the use of the DUStore Server. Check the check box to enable or uncheck to disable.

The maximum number of ADUs that are sent to the DUStore Server in one set. The minimum is 1 and the default is 60.

Sets the interval for the Toolkit's Select() method, in hundredths of a second.

The default value is 5 (50 milliseconds). Low values increase CPU utilization. High values (over 100) may affect the accuracy of the scaninterval parameter.

Determines the number of revisions of a value that are kept for access with the GetValuesHistory() method. The default is 4, which is generally recommended.

Determines the maximum number of events to be kept in memory for each ADU. The default is 256. A setting of 64 is recommended as a reasonable number of events to be kept in memory. High values may increase Eventsink throughput. Low values may conserve memory.

Specifies the number of seconds to wait between automatic attempts to reassign to servers. The minimum is 6 seconds, maximum is 48 hours, default is 1 minute. Setting this value below 30 seconds in a production environment is not recommended, as it does a synchronous DS call for a list of ADU Servers and attempts an asynchronous Assign to any of them it isn't already assigned to. If the Assign fails (the request function itself fails), the offending ADU Server is removed from the list and not retried automatically. The retry is only attempted if the Assign callback reveals an error or a ServerFailed event arrives.

Reset Interval (serverresetinterval)

Data Element Names

Suspend Interval (suspendinterval)

Adu Data Percent (adudata.perecnt)

Find Create to Search (findcreatestoresearch)

DUindex Lookup1 (duindex.lookup1)

DUindex Lookup2 (duindex.lookup2)

DUindex Info1 (duindex.info1)

Specifies the number of seconds to wait between attempts to reassign to servers after receiving an ADU.FailADUCon alarm. The minimum is 0, maximum is 48 hours, default is 2 seconds.

Number of seconds before an ADU, which is suspended by use of the Suspend method by all users, is considered for Suspension. This parameter can be overridden by a higher value in the Suspend method. The minimum is 1, maximum is 20 minutes, default is 1 second.

The percentage of ADUs that are sent to the ADU data feed, used for random sampling. The minimum is 0, maximum is 100, default is 0.

Enables a WAN wide DUStore search on the FindOrCreate method. Check the check box to enable or uncheck to disable.

The name of one of the fields used to index the ADU in the DUStore Server. Used with the Find method.

The name of one of the fields used to identify the ADU in the DUStore Server. Used with the Find method.

(Sheet 3 of 4)

Issue 1.0 June 2002 39

Chapter 5 ADU Server Configuration

Label Description

DUindex Info2 (duindex.info2)

DUindex Info3 (duindex.info3)

Adudata Alarm Priority (adudata.alarm.priority)

Adudata Event Name (adudata.eventname)

Adudata Event Ifname (adudata.event.ifname)

Adudata Data Only Name (adudata.data.onlyname)

Server Group servergroup

Server Status serverstatus

The name of one of the fields used to identify the ADU in the DUStore Server. Used with the Find method. The default value is media.

The name of one of the fields used to identify the ADU in the DUStore Server. Used with the Find method. The default value is site.

An alarm priority used when raising an alarm related to the ADUDATA feed. Values are Low, High, Informational, and Emergency.

The names of events that may be sent to the ADUDATA feed. If there are no events identified, all events are sent. Use this parameter multiple times to specify multiple events.

Sends an event to the ADUDATA feed only if the event contains this field. This parameter can be specified multiple times to allow multiple valid names.

Filters events to the ADUDATA feed so they only contain this field. The parameter can be specified multiple times to allow multiple valid names.

Reserved

(Sheet 4 of 4)

40 Agent Data Unit Serve r Programmer’s Guide

The following configuration parameters are not presented on the ADU tab in IC Manager. You can set them on the Config tab of the ADU Server Editor dialog.

Name Description

Configuration Parameters

filter (filter)

Sets the filter for determining which ADU events are sent to the HISTMAP server (the Report Server). The event types are start, change, delete, transfer, user, and data. A plus sign (+) marks the event type for storage, a minus sign (–) excludes the event type from storage.

data

The

Each filter criterion must be entered on a separate line, with subsequent lines taking precedence.

Examples:

parameter encompasses all event types.

End

events cannot be filtered out.

-data

is the default.

–data

change

only

change

and

end

events are stored

+change

–

data

only

end

events are stored

Note that

+data

aduhskeepname (reportkeepname) Names of data elements in ADU events to be sent to the server specified with the Eventsink configuration parameter.

Each element must be entered on a separate line.

filter.

drop

and

watch

events are sent to clients but are not included with the

If this parameter is not used, all data elements are sent. (The ADUID field is always stored.) Use of wildcards is permitted. Use this parameter with care. Filtering elements from the End event may adversely affect reporting capability.

gencount Specifies the number of instances of a subcontainer created with the + token that can

exist at one time. If more than this number are created the earliest is deleted. For example, to limit the number of subcontainers of the ts container, you could set gencount to ts.3. When ts.+ creates ts.4, ts.1 is deleted. When ts.5 is created, ts.2 is deleted, and so on. The default is 0, which specifies no limit (all generations of a subcontainer are kept). The gencount value should be set to accommodate the maximum number of active contacts for each media channel.

padwidth Specifies the number of digit positions required in a container name token. Numbers

are padded with zeroes to this position. For example, to specify the number of digit positions for the second token of the ts container, you could set padwidth to ts.4. Subcontainers would then be named ts.0001, ts.0002, and so on. The default is 0, which specifies no padding.

autostart Specifies whether the server should start automatically at the same time as the ORB

Server. Values: true, false.

timetype Sets ADU server timestamp format. The only supported value for this version is gmt

(lower case).

Issue 1.0 June 2002 41

Chapter 5 ADU Server Configuration

The following settings are on the Debug tab of the ADU Server Editor.

Name Description

logfilesize The maximum size of the log file. The default log file size is 2,560,000 bytes. The

minimum is 1000 bytes and the maximum is 50,000,000 bytes.

Ping Interval pingtimer

trace The trace parameter can contain any number of the following settings, comma

The number of seconds between messages that are sent to a server to determine if it is running. The default is 60 seconds and the minimum is 1 second.

separated, no spaces permitted. This following list works for MTT servers. STT servers have some minor differences..

idl – Whether requests, responses and events are logged flush – Whether the logged information if forced to disk after each significant operation timing – Whether requests have timing information logged explain – Whether requests explain which server they were sent to, and why on – Whether logging happens at all thread – Whether each log entry contains the id of the thread that wrote it usr1 through usr8 – For use by third party implementers. dev1 – reserved appverbose – Used by individual applications. appwarn – Used by individual applications. debug – Used by individual applications. debug2 – Used by individual applications.

Note: Previous versions of Avaya IC included the ADU History Server. To support existing installations, send the events to an existing ADU History Server.

1 Use the default for the Eventsink parameter (HISTMAP.EventsIn) to send events to the

Reporting server.

2 Set the Reporting servers’s eventforward parameter to ADUHS.EventsIn. The Reporting server

forwards all ADU events to the ADUHS.

42 Agent Data Unit Serve r Programmer’s Guide

CHAPTER 6

IDL S

PECIFICATION

The Interface Definition Language (IDL) is defined within CORBA standards. It is used to create interfaces that are called by client objects and provided by object implementations.

The following is the IDL description of the ADU Server. The virtual interface is inherited by both the EDU Server and the ADU Server. Several of the methods listed are specific to the ADU Server, and are therefore omitted from the method descriptions in Chapter 7.

interface genericdu virtual { ORBStatus Create( in SeqCouple values, out stringvduid ); ORBStatus Terminate( in stringvduid ); void TerminateMine(); ONEWAY EventsIn(in string vdu_id, in SeqEvent events); ORBStatus FindByKey( in string name, in string value, out stringvduid ); ORBStatus Find( in string search_criteria, in unsigned long, scope, out SeqString matches ); ORBStatus FindExtended( in string search_criteria, in unsigned long scope, out SeqCouple matches ); ORBStatus GetOneValue( in string vduid, in string name, out string value ); ORBStatus GetValues( in string vduid, out SeqCouple c ); ORBStatus GetActive( out SeqString vduseq ); ORBStatus SetOneValue( on string vduid, in string name, in string value ); ORBStatus SetValues( instring vduid, in SeqCouple values ); ORBStatus DeleteValue( in string vduid, in string pattern ); ORBStatus IncrValue( in string vduid, in string name, in long incr, out string newvalue ); ORBStatus Assign( in stringmonitorcriteria ); ORBStatus Monitor( in stringmonitorcriteria ); ORBStatus Transfer( in string vduid, in string to ); ORBStatus SetAndTransfer(in string vduid, in string to, in SeqCouple values ); ORBStatus GetValuesHistory( in string vduid, in unsigned long flags, out SeqLong headers, out SeqString names, out SeqSeqSeqString values ); ORBStatus GetValueHistory( in string vduid, in string name, out SeqString values, out SeqString when, out SeqString who ); ORBStatus GetSubTree( in string vduid, in string name, out SeqCouple matches ); ORBStatus GetSomeValues( in string vdu_id, in string name, out SeqCouple matches );

Chapter 6 IDL Specification

ORBStatus SetValuesExtended( in string vdu_id, in SeqCouple data, out SeqString newnames ); ORBStatus DeleteValues( in string vdu_id, in SeqString names ); ORBStatus DeleteOneValue( in string vdu_id, in string name ); ORBStatus DeleteSubTree( in string vdu_id, in string name ); ORBStatus SetAndTerminate( in string vdu_id, in SeqCouple data ); void GetUserSessions( in string vdu_id, out SeqString users ); //Server ONLY ORBStatus RemoteWatcher( in unsigned long handles, in string cri ); ORBStatus ForwardEvent( in unsigned long handles, in Event Event );

void SetDefaultHistoryFilter( in unsigned long mask ); ORBStatus SetHistoryFilter( in unsigned long mask ); }

interface ADU : genericdu, General { const unsigned long NO_OS = 0x00; const unsigned long ASK_OS = 0x01; const unsigned long NET_NO_OS = 0x02; const unsigned long NET_ASK_OS = 0x03;

};

44 Agent Data Unit Serve r Programmer’s Guide

CHAPTER 7

ADU S

ERVER METHODS

Method Objectives

Clients request Avaya IC servers to perform various functions by issuing server-specific method invocations. These methods behave in a similar fashion across all servers. For example, when you invoke any of the various ADU Server Set methods, existing values are overwritten. Values that did not previously exist are created. With the exception of the Delete methods, all of the ADU Server methods generate change events to indicate changes or additions. If an error occurs, exceptions are raised.

This chapter defines the methods provided with the ADU Server.

Note: Some program examples were formatted to fit the page. Actual program lines cannot be arbitrarily split.

Exception Information

The ADU Server methods may return the following exception information:

Cannot use empty token Improper special token for this method Improper use of a special token No listing for home server for that ADU No such name: <name> No such ADU: <aduid> No WAN ADU services in this version Not an ADU id: <aduid> Server only attribute Too many characters in token Too many dot separators Too many names at the same time Unknown error ADU is read-only

Chapter 7 ADU Server Methods

You are not a server Cannot find subcontainer for that owner First token must be normal here No match (or illegal usage) Cannot access invalidated member

Routing Requests

In an environment with several ADU Servers, any method that accepts an ADUID routes the request to another ADU Server if the ADU named is not local to the first server. ADUIDs contain location data, so a server can identify which system owns each ADU.

Method Overview

The following is a brief description of the methods available for use with the ADU Server.

ADU.Assign Create a session with the ADU Server.

ADU.Create Create a new ADU.

ADU.Deassign Destroy a session with an ADU Server.

ADU.DeleteOneValue This is equivalent to DeleteValues with a single name.

ADU.DeleteSubTree DeleteOneValue on the given name and every name in the

subcontainer beneath it, cutting a branch from the tree a container represents.

ADU.DeleteValues Given a list of names, this method removes from the ADU

the name and its value history, in effect making the ADU smaller.

ADU.EventsIn Adds user-defined ADU events to an ADU.

ADU.Find Returns a list of ADUIDs that match a simple criterion.

ADU.FindByKey Finds one active local ADU based on a single search

criterion.

ADU.FindOrCreate Searches for a specified ADU and, if not found, creates the

ADU.

ADU.ForceTerminate Forces theADU object to be deleted from memory and

from the database both, so it can no longer be used.

ADU.ForwardEvent Reserved.

ADU.GetActive Finds all the active ADUs at the time the call is made.

ADU.GetOneValue Retrieves one value from an ADU.

ADU.GetSomeValues Returns all names and values matching a container name.

ADU.GetSubTree Returns all names and values in the subcontainer named

46 Agent Data Unit Serve r Programmer’s Guide

name

Method Overview

ADU.GetUserSessions Returns the sessions of all clients believed to have an

interest in the ADU.

ADU.GetValues Retrieves all of the values of an ADU.

ADU.GetValueHistory Returns everything that is known about the named field's

values in an ADU.

ADU.GetValuesHistory Returns everything that is known about all values in an

ADU.

ADU.IncrValue A useful alternative to using SetOneValue and

GetOneValue to modify a value when there is a risk that two applications might conflict, and the value being changed is numeric.

ADU.Monitor Changes Assign criteria.

ADU.RemoteWatcher Reserved.

ADU.SetAndTerminate Combines a SetValues and a Terminate.

ADU.SetAndTransfer Combines SetValues and Transfer into a single call, as

these operations often occur together.

ADU.SetDefaultHistoryFilter Reserved.

ADU.SetHistoryFilter Allows the caller to specify which types of events are saved

when an individual ADU is sent to the eventsink server, overriding the default history filter for one ADU.

ADU.SetOneValue Sets one ADU data element.

ADU.SetValues Sets one or more ADU data elements.

ADU.SetValuesExtended Performs a SetValues, but in addition returns a parallel list

of names that it created while resolving container names.

ADU.Terminate Removes the client's name from the list of interested

parties for one ADU.

ADU.TerminateMine Removes the client's name from the list of interested

parties for all ADUs.

ADU.Touch Accesses or “touches” an ADU onceper invocation, as a

default, to prevent it from being harvested from memory out of idleness.

ADU.Transfer Adds a new client to an ADU's list of interested parties.

Issue 1.0 June 2002 47

Chapter 7 ADU Server Methods

Methods

The following sections describe the ADU Server methods.

ADU.Assign

IDL Syntax ORBStatus Assign( in string monitorcriteria ) ;

Description Create a session with the ADU Server. When a session is created, events are sent to the assigned

Avaya IC client.

When multiple ADU Servers are in use, Assigns watch all calls in the domain of the ADU Servers and notify the client with events when they occur. This makes Assign a relatively expensive operation. Design clients so they only need to Assign once to specify the ADUs in which they are interested. Assigning to multiple ADU Servers is unnecessary and causes numerous problems. (Refer to “Cooperation of ADU Servers,” on page 10 for additional information.)

Input Parameters

monitorcriteria Information used to select ADUs for monitoring. If values contain

anything other than letters and numbers (for example, spaces), they should be enclosed in double quotes, and \ or " characters must be quoted by a \ character. (Refer to “Starting and Stopping Event

Monitoring,” on page 28 and “Setting Event Monitoring Criteria,” on page 29.)

Returns

VESP_SUCCESS Request was successful..

VESP_ERROR Request was unsuccessful.

C Program Example

status = Vesp_Assign_Request( "ADU.Assign", callback, user_data,

event_callback, session, "loginid=user" );

ADU.Create

IDL Syntax ORBStatus Create( in SeqCouple values, out ADU_ID aduid ) ;

Description This method creates a new ADU. This function is usually performed by the Toolkit and is hidden

from normal application development. The ADU Server sets the creation timestamp and ADUID.

Input Parameters

values Initial values of the ADU, not to exceed 1023 values.

48 Agent Data Unit Serve r Programmer’s Guide

Output Parameters

aduid Agent Data Unit Identifier.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR Internal error in ADU Server.

C Program Example

_IDL_SEQUENCE_Couple *seq_couple; ADU_ID aduid; /* receives the id of the created ADU */ /* Create space for values */ seq_couple = vesp_couple_seq_create(); /* fill in the field for the new ADU entry */ vesp_couple_seq_add_couple_values( seq_couple,

vesp_couple_seq_add_couple_values( seq_couple,

/* Create the new ADU */ status = Vesp_Request( "ADU.Create", callback, 0x2132, session,

vesp_couple_seq_delete( seq_couple );

ADU.Deassign

"name1", "value1" );

"name2", "value2" );

"name3", "value3" );

seq_couple, &aduid );

ADU.Deassign

IDL Syntax ORBStatus Deassign( ) ;

Description Destroy a session with an ADU Server. When a session is deassigned, the flow of events from the

ADU Server to the client ceases. Events may continue to arrive until the response for this method is received. It is not an error to deassign when no session exists.

Returns

VESP_SUCCESS Request was successful.

ADU.DeleteOneValue

IDL Syntax ORBStatus DeleteOneValue( in ADU_ID aduid, in string name) ;

Description This is equivalent to DeleteValues with a single name.

Issue 1.0 June 2002 49

Chapter 7 ADU Server Methods

If used with a container name (“a.b”), you only delete that one name, a.b. However, the ADU Server methods are not able to address names “below” that point. Although a.b.c may still exist, the ADU Server cannot find it, even though GetSubTree on “a” still sees them. Resolving a.b.c depends on resolving a.b, which does not exist anymore. Callers should generally not delete elements from non-leaf positions.

Input Parameters

aduid Agent Data Unit Identifier.

name Name whose values are to be deleted from the ADU.

ADU.DeleteSubTree

IDL Syntax ORBStatus DeleteSubTree( in ADU_ID aduid, in string name) ;

Description This method does a DeleteOneValue on the given name and every name in the subcontainer

beneath it, cutting a branch from the tree a container represents. If given a simple container name (“data”), it deletes the entire container.

Input Parameters

aduid Agent Data Unit Identifier.

name Name whose values are to be deleted from the ADU.

ADU.DeleteValues

IDL Syntax ORBStatus DeleteValues( in ADU_ID aduid, in SeqString names) ;

Description Given a list of names, this method removes from the ADU the names and their values, in effect

making the ADU smaller. Values are deleted from active memory only. This method does not interact with the database.

If used with a container name (“a.b”), this method only deletes that one name, a.b. However, the ADU Server is not able to address names “below” that point. Although a.b.c may still exist, the ADU Server cannot find it, even though GetSubTree on “a” still sees them. Resolving a.b.c depends on resolving a.b, which does not exist anymore. Callers should generally not delete elements from non-leaf positions.

Input Parameters

aduid Agent Data Unit Identifier.

names List of names whose values are to be deleted from the ADU.

50 Agent Data Unit Serve r Programmer’s Guide

ADU.EventsIn

IDL Syntax ONEWAY EventsIn(in string vdu_id, in SeqEvent events);

Description This function adds a user-defined ADU event to an ADU. Values in the ADU are updated to

reflect the names and values in the event.

Input Parameters

aduid Agent Data Unit Identifier.

event The event information. Each event must include an event name to

describe the event. Requests without an event name are rejected.

Returns No return value. One way requests do not have any returns.

C Program Example

Event *event;

/* Create space for record */ event = vesp_event_create( "Update" ); vesp_event_add_couple( event, "name1", "value1" );

/* Create the new ADU History event entry */ status = Vesp_Request( " ADU.EventsIn", callback, 0x2132,

session, aduid, event );

/* release memory we allocated */ vesp_event_delete( event );

ADU.Find

IDL Syntax ORBStatus Find( in string search_criteria, in unsigned long scope,

out SeqString matches ) ;

Description This method returns a list of ADUIDs that match a simple criterion. The ADUs found may be

active in the local ADU Server or in other WAN ADU Servers, depending on the setting in scope.

The criteria can be any expression an Assign method would accept.

The Find method, especially one distributed across the WAN, can take time, as it cannot reply until it receives a response from all the other servers it contacts and combines the lists it receives. A WAN-wide search proceeds in parallel across all involved ADU Servers, but the speed is still limited to the speed of the slowest single search. In the worst case, the request may start other servers that had not been started yet, which can entail a significant delay.

Issue 1.0 June 2002 51

Chapter 7 ADU Server Methods

Input Parameters

search_criteria Criteria to be used for the search, consisting of names and values. If

scope Can be one of the following. Note that the "no_os" designation is for

Output Parameters

matches List of ADUIDs meeting the search criteria. Note that an empty list is

Returns

VESP_SUCCESS Request was successful.

values contain spaces or anything other than letters and numbers, they must be enclosed in double quotes. If the value contains a \ or " character it must be quoted by a \ character.

consistency with the EDU Server. ADU_NO_OS Check the local ADU Server only. ADU_NET_NO_OS Check the WAN ADU Servers but

no Object Stores.

considered valid and returns VESP_SUCCESS.

ADU.FindByKey

IDL Syntax ORBStatus FindByKey( in string name, in string value, out ADU_ID aduid ) ;

Description This method finds one active local ADU based on a single search criterion, or key. Each ADU

contains at least one unique element, typically the login ID.

FindByKey() searches only the local ADU Server for active ADUs.

Input Parameters

name Search key to find ADU.

value Value to match if name is found.

Output Parameters

aduid Agent Data Unit Identifier.

Returns

VESP_SUCCESS Request was successful.

C Program Example

Locate an ADU having a key containing 1137.

52 Agent Data Unit Serve r Programmer’s Guide

ADU.FindOrCreate

status = Vesp_Request( "ADU.FindByKey", callback, 0x2132,

session, "key", "1137", &aduid );

ADU.FindOrCreate

IDL Syntax ORBStatus FindOrCreate( in SeqCouple match, in SeqCouple, oncreate, out string

vdu_id) ;

Description This method searches the local server for an ADU that exactly matches all names and values in the

match. It does not support wildcards. If a match is not found on the local server, it searches other ADU servers. If a match is found, it returns the id of the ADU. If multiple matches are found, the id of the most recently created ADU is returned.

If ADU.FindOrCreate does not find a match, the local server creates the ADU with the names and values from the combined list of match and oncreate. The id is then returned. This is the only case where the oncreate parameter is used.

Note: This method is intended to by used by the Avaya Toolkit. If you know the ADU needs to be created, it is recommended that you use the Create method because it is considerably faster and much more efficient.

Input Parameters

name Search key to find ADU.

value Value to match if name is found.

Output Parameters

aduid Agent Data Unit Identifier.

Returns

VESP_SUCCESS Request was successful..

VESP_ERROR Requires values to find ADU. The match parameter may be empty.

ADU.ForceTerminate

IDL Syntax ORBStatus ADU.ForceTerminate(in string duid)

Description Forces the ADU object to be deleted from memory and from the database both, so it can no longer

be used.

ADU.ForwardEvent

IDL Syntax ORBStatus ForwardEvent( in unsigned long handleis, in Event Event) ;

Issue 1.0 June 2002 53

Chapter 7 ADU Server Methods

Description This method is reserved. ADU Servers use this method to pass events to each other. Client

applications should not call this method.

ADU.GetActive

IDL Syntax ORBStatus GetActive( out SeqADU_ID aduseq ) ;

Description This method finds all the active ADUs at the time the call is made. Note that only ADUs currently

in memory are found.

Output Parameters

aduseq A list of active ADUs.

Returns

VESP_SUCCESS Request was successful.

C Program Example

SeqADU_ID ADU_ids;

/* Initialize a sequence of ADUs (0 specifies no limit) */ ADU_ids._maximum = 0; ADU_ids._length = 0; ADU_ids._buffer = NULL; status = Vesp_Request("ADU.GetActive", callback, user_data,

session, &ADU_ids );

ADU.GetOneValue

IDL Syntax ORBStatus GetOneValue( in ADU_ID aduid, in string name, out string value ) ;

Description This method retrieves one value from an ADU.

Input Parameters

aduid Agent Data Unit Identifier.

name ADU element to be returned.

Output Parameters

value One returned value from the ADU.

54 Agent Data Unit Serve r Programmer’s Guide

ADU.GetSomeValues

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADUID or name not found.

C Program Example

Get the value of “myfavoriteelement” from the ADU named by aduid.

char *value; status = Vesp_Request( "ADU.GetOneValue", callback, 0x2132, session,

aduid, "myfavoriteelement", &value );

ADU.GetSomeValues

IDL Syntax ORBStatus GetSomeValues( in ADU_ID aduid, in string name,

out SeqCouple matches) ;

Description This function returns all names and values matching a container name. It is one of the few that

accepts the * token. Thus, a name of data.*.emergency returns names such as data.1.emergency, data.brian.emergency, and so on.

Input Parameters

aduid An ADUID.

name A name. By intent, a container name.

Output Parameters

matches All names and values in that container.

ADU.GetSubTree

IDL Syntax ORBStatus GetSubTree( in ADU_ID aduid, in string name,

out SeqCouple matches) ;

Description This function returns all names and values in the subcontainer named by name. It can be given a

container name (ts) or a subcontainer name (ts.1) and returns all names and values from that point down.

Input Parameters

aduid An ADUID.

name A name. By intent, a container or subcontainer name.

Issue 1.0 June 2002 55

Chapter 7 ADU Server Methods

Output Parameters

matches All names and values in the container or subcontainer.

ADU.GetValues

IDL Syntax ORBStatus GetValues( in ADU_ID aduid, out SeqCouple values ) ;

Description This method retrieves all of the values of an ADU.

Input Parameters

aduid Agent Data Unit Identifier.

Output Parameters

values A sequence to contain ADU information.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADUID was not found.

C Program Example

Get all of the data elements active in a specific ADU.

_IDL_SEQUENCE_Couple *values;

/* init an empty, unlimited sequence of Couples */ seq_couple = vesp_couple_seq_create(); status = Vesp_Request( "ADU.GetValues", callback, 0x2132,

session, aduid, seq_couple);

ADU.GetValueHistory

IDL Syntax ORBStatus GetValueHistory( in string aduid, in string name,

out SeqString values, out SeqString when, out SeqString who) ;

Description GetValueHistory returns everything that is known about the named field's values in an ADU. It

reports on all the values the field has had (up to the limit specified with the maxkeptrevisions configuration parameter), who set them, and when.

The returned arrays are parallel, with the bottommost element being the most recent.

56 Agent Data Unit Serve r Programmer’s Guide

Input Parameters

aduid An ADUID of an existing ADU.

name The name of a field.

Output Parameters

values A list of values to which the named field has been set.

when When the field was set to each value, time_t string.

who The session ID of the client that set each value.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADUID was not found.

ADU.GetValuesHistory

IDL Syntax ORBStatus GetValuesHistory( in ADU_ID aduid, in unsigned long flags,

out SeqLong headers, out SeqString names, out SeqSeqSeqString values) ;

Description GetValuesHistory returns everything that is known about all values in an ADU. For each named

field in an ADU, it reports on all the values the field has had (up to the limit specified with the maxkeptrevisions configuration parameter), who set them, and when. By providing the various ADU_GSGET flags, you can control which of these values are returned.

The output in headers is a list of your specified flags, one per long integer. This indicates the order in which the bottommost sequence of strings in the values parameter are filled. Thus, if you specify (ADU_GSGETVALUE | ADU_GSGETTIME), headers would come back with two long integers, one containing ADU_GSGETVALUE and one containing ADU_GSGETTIME. The bottommost sequences in the values parameter would list values in the same order.

The output in names is a list of all the data names within the ADU. Container elements each get their own entry. The topmost sequences in values are in the name order, so if names[3] is “x”, values[3] is the sequence that describes the history for “x”.

Va lu es itself runs three levels down. The topmost level is parallel to the names sequence. The next level down represents one entry for each value that names has had over time. If a value has only been set once (a common case) this sequence only has one element. The lowest level runs parallel to the headers parameter, and has one element for each of the kinds of data requested (any combination of text, time, and who).

Issue 1.0 June 2002 57

Chapter 7 ADU Server Methods

For example, field quark was set twice, once at ADU creation (11:37:00am, by Scott, to “truth”) and again at ADU transfer (11:38:00, by Jane, to “charm”). Specifying flags = ADU_GSGETTIME | ADU_GSGETVALUE | ADU_GSGETWHO would yield:

header[0] = ADU_GSGETVALUE; //first subelement is the text

header[1] = ADU_GSGETTIME; //second is time

header[2] = ADU_GSGETWHO; //third is who

names[?] = “quark”; //one of the names returned will be quark

values[?][0][0] = “truth”; //values[13] is parallel to names[13], and the

values[?][0][1] = “8145264302”; //the time_t it was set (11:37:00am)

values[?][0][2] = “Scott”; //Scott set it

values[?][1][0] = “charm”; //next value set was “charm”

values[?][1][1] = “8145264362”; //set at this time

//first value that was set was “truth”

values[?][1][2] = “Jane”; //by this loginid

Input Parameters

aduid An ADUID of an existing ADU.

flags One or more of the ADU_GSGET flags, OR'd together.

Output Parameters

headers A list of ADU_GSGET values.

names A list of ADU data names.

values A list of data values (one per name), which are lists of value histories

Returns

VESP_SUCCESS Request was successful.

Flags are:

#define ADU_GSGETVALUE 0x01 #define ADU_GSGETTIME 0x02 #define ADU_GSGETWHO 0x04

(one per value), which are lists of fields (text, when, and who).

VESP_ERROR ADUID was not found.

58 Agent Data Unit Serve r Programmer’s Guide

ADU.IncrValue

IDL Syntax ORBStatus IncrValue( in ADU_ID aduid, in string name, in long incr,

out string newvalue ) ;

Description This method is a useful alternative to using SetOneValue and GetOneValue to modify a value

when there is a risk that two applications might conflict.

This method changes one ADU data element. If the element does not exist it is created. An element that exists is overwritten if permission allows. The value of the element is treated as a number and is converted to a long integer (by use of the C function atol). The specified increment is added, and the element’s value is set to the result. Elements that do not exist are treated as if they contained a zero (0). The increment may be a negative value.

The atol function is robust in that if it cannot recognize a number, it returns 0. The method stores the resulting, incremented value as a decimal digit string without extraneous spaces or leading zeros. Thus, incrementing “x2” by one results in “1” and incrementing “00034E6” by one results in “35”.

Input Parameters

aduid Agent Data Unit Identifier.

name The name of the ADU element to change or create.

incr Increment value.

Output Parameters

newvalue The new value of the element, after the increment.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADU not found, or the element cannot be changed.

C Program Example

char *result; status = Vesp_Request( "ADU.IncrValue", callback, 0x2132, session,

ADU.Monitor

aduid, "some_numeric_element", 1L, &result );

IDL Syntax ORBStatus Monitor( in string monitorcriteria ) ;

Description This method changes Assign criteria. It works like Assign in all respects. You must have

previously assigned (and have not since deassigned) to use this method.

Issue 1.0 June 2002 59

Chapter 7 ADU Server Methods

Input Parameters

monitorcriteria Monitor criteria string. If values contain anything other than letters and

numbers (for example, spaces), they should be enclosed in double quotes, and \ or " characters must be quoted by a \ character. Refer to

“ADU Event Monitoring,” on page 27 for additional information.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR Invalid monitor criteria.

ADU.RemoteWatcher

IDL Syntax ORBStatus RemoteWatcher( in unsigned long handleis, in string cri) ;

Description This method is reserved. Client applications should not call this method.

When multiple ADU Servers are listed in one directory, any Assign, Monitor, or Deassign method invocation is communicated by the local ADU Server to all other ADU Servers by a RemoteWatcher method invocation.

RemoteWatcher events are included in the ADU Server log file following Assign, Monitor, or Deassign events. They take the form:

uuid

where:

.RemoteWatcher(

uuid

is the UUID of the ADU Server

nnnn

is a number used internally.

abcde

is a string identifying the Assign or Monitor criteria. A blank

string indicates a Deassign method invocation.

nnnn

, "

abcde

" )

ADU.SetAndTerminate

IDL Syntax ORBStatus SetAndTerminate( in ADU_ID aduid, in SeqCouple data ) ;

Description This method combines a SetValues and a Terminate.

Input Parameters

aduid An ADUID.

data Values to be set, not to exceed 1023 values.

60 Agent Data Unit Serve r Programmer’s Guide

ADU.SetAndTransfer

IDL Syntax ORBStatus SetAndTransfer( in ADU_ID aduid, in string to,

in SeqCouple values ) ;

Description This method combines SetValues and Transfer into a single call, as these operations often occur

together. If the operation succeeds, it generates a Change event containing all changes made to the ADU. This operation is usually performed by Avaya IC components, not client software.

Input Parameters

aduid Agent Data Unit Identifier.

to A string representing the receiving client.

values A list of names and values to apply to the ADU, not to exceed 1023.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADU not found, set failed, or client not a valid string.

C Program Example

/*Transfer an ADU. */ char *to; _IDL_SEQUENCE_Couple *values;

/* init an empty, unlimited sequence of Couples */ seq_couple = vesp_couple_seq_create();

/* fill in the field for the new ADU entry */ vesp_couple_seq_add_couple_values( seq_couple,"loginid",

"meritha" );

to = ORB_object_to_string( VESP_ORB, &environment,

to_object);

status = Vesp_Request( "ADU.SetAndTransfer", callback, 0UL,

session, aduid, to, seq_couple );

vesp_couple_seq_delete( seq_couple );

ADU.SetDefaultHistoryFilter

IDL Syntax void SetDefaultHistoryFilter( in unsigned long mask ) ;

Description This method is reserved. Client applications should not call this method.

Issue 1.0 June 2002 61

Chapter 7 ADU Server Methods

This method allows the caller to specify which types of events are saved when ADUs are sent to the server named in the eventsink configuration parameter. The filter takes effect in subsequently created ADUs, not existing ones. All events generated for all subsequent ADUs are checked against the permissions in the bits set in the mask argument. Events already generated are not affected.

The SetHistoryFilter()method can be used to override the default filter for individual ADUs.

The bits are defined in the file generic.idl as:

HS_NOSTART (unsigned short)0x01 Do not record new events

HS_NOCHANGE (unsigned short)0x02 Do not record change events

HS_NOTRANSFER (unsigned short)0x04 Do not record transfer events

HS_NOUSER (unsigned short)0x08 Do not record user-defined events

HS_NODELETE (unsigned short)0x10 Do not record delete events

End events (ADU.End) cannot be filtered out. They must be included in the stored ADUs. Data elements in the End event can be filtered with the aduhskeepname configuration parameter.

ADU.SetHistoryFilter

IDL Syntax ORBStatus SetHistoryFilter( in ADU_ID aduid, in unsigned long mask ) ;

Description This method allows the caller to specify which types of events are saved when an individual ADU

is sent to the server set with the eventsink configuration parameter, overriding the default history filter for one ADU. The filter takes effect immediately. All subsequent events generated are checked against the permissions in the bits set in the mask argument. Events already generated are not affected.

The bits are defined in the file vespidl.idl as:

HS_NOSTART (unsigned short)0x01 Do not record new events

HS_NOCHANGE (unsigned short)0x02 Do not record change events

HS_NOTRANSFER (unsigned short)0x04 Do not record transfer events

HS_NOUSER (unsigned short)0x08 Do not record user-defined events

HS_NODELETE (unsigned short)0x10 Do not record delete events

The end event (ADU.End) cannot be filtered out. It must be included in the stored ADU. Data elements in the End event can be filtered with the aduhskeepname configuration parameter.

Input Parameters

aduid Agent Data Unit Identifier.

mask Permission bits to be set.

62 Agent Data Unit Serve r Programmer’s Guide

ADU.SetOneValue

Returns

VESP_SUCCESS Request was successful.

C Program Example

Vesp_Request_Sync( "ADU.SetHistoryFilter", /* method identification */ &ev, /* environment pointer */ session, /* session object */ &request, /* pntr to pntr to request structure */ aduid, /* an ADU id */ HS_NOUSER /* The permission bit to be set

for this ADU */ );

/* check ev for errors as needed */ Vesp_Request_Delete(session, request);

ADU.SetOneValue

IDL Syntax ORBStatus SetOneValue( in ADU_ID aduid, in string name, in string value ) ;

Description This method sets one ADU data element. An element that does not exist is created. An element

that exists is overwritten if permission allows.

The following fields are restricted and cannot be changed by applications:

aduid termination

transfercount duration

createtime update_time

endtime

Setting values can generate watch, change, and drop events.

Input Parameters

aduid Agent Data Unit Identifier.

name The name of the ADU element to change or

create.

value The value to be set.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADU not found, or the element cannot be changed.

Issue 1.0 June 2002 63

Chapter 7 ADU Server Methods

C Program Example

/*Set one value. */ status = Vesp_Request( "ADU.SetOneValue", callback, 0x2132, session,

aduid, "my_favorite_element", "new value" );

ADU.SetValues

IDL Syntax ORBStatus SetValues( in ADU_ID aduid, in SeqCouple values );

Description This method sets one or more ADU data elements. Data elements that do not exist are created.

Existing elements are updated if permission allows.

The following fields are restricted and cannot be changed by applications:

aduid termination

transfercount duration

createtime update_time

endtime

Setting values can generate watch, change, and drop events.

Input Parameters

aduid Agent Data Unit Identifier.

values A sequence containing ADU information, not to exceed 1023 values.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADU not found or values not able to be set.

C Program Example

/* Example of an initialized sequence with fixed values: */ status = Vesp_Request( "ADU.SetValues", callback, 0x2132,

session, aduid, &values );

ADU.SetValuesExtended

IDL Syntax ORBStatus SetValuesExtended( in ADU_ID aduid, in SeqCouple data,

out SeqString newnames) ;

Description This function performs a SetValues method, but in addition returns a parallel list of names that it

created while resolving container names. For example, if the data SeqCouple contained two names, agent.!.x and data.+, the newnames list might be returned containing agent.2.x and data.4.

64 Agent Data Unit Serve r Programmer’s Guide

This method is useful for applications that need to know how names were generated, especially for applications that make repeated use of the + token and need to be able to go back and fill in values in the various subcontainers they have created.

The following fields are restricted and cannot be changed by applications:

aduid termination

transfercount duration

createtime update_time

endtime

Setting values can generate watch, change, and drop events.

Input Parameters

aduid An ADUID.

data Values to be set, not to exceed 1023.

Output Parameters

ADU.Suspend

newnames List of names created to resolve container names.

ADU.Suspend

IDL Syntax ORBStatus Suspend( in string aduid ) ;

Description Like Terminate, this removes the caller's session from the ADU's session list, but it does not

remove the loginid from the owner's list. Use this when your application is done with the ADU for now, but intends to do more work on it later. This method gives permission for the ADU server to retire the ADU to the DUStore, on the grounds that it may not be accessed for some time.

ADU.Terminate

IDL Syntax ORBStatus Terminate( in ADU_ID aduid ) ;

Description When a client creates, reads, modifies, or transfers an ADU, the client's name and session is added

to internal lists. When the Terminate method is invoked, the client's name and session is removed from

the lists for that ADU. When the of names is empty, the ADU is purged from the system and is used for reporting. When the list of sessions is empty but the list of names is not (this can occur if Suspend is used), the ADU may be moved to the DUStore for temporary storage.

Issue 1.0 June 2002 65

Chapter 7 ADU Server Methods

Input Parameters

aduid Agent Data Unit Identifier.

Returns

VESP_SUCCESS Request was successful.

VESP_PARTIAL_ SUCCESS

VESP_ERROR Specified ADU does not exist.

The ADU was not found in memory.

C Program Example

status = Vesp_Request( "ADU.Terminate", callback, 0x2132, session,

aduid );

ADU.TerminateMine

IDL Syntax void TerminateMine( ) ;

Description When a client creates, reads, modifies, or transfers an ADU, the client's name is added to an

internal list of clients. When the TerminateMine method is invoked, the client's name is removed from the list for all ADUs.

The Terminate() method is marginally faster than TerminateMine(), and is therefore preferable when the ADUID is known.

It is important to realize that transferring a call does not automatically end a client’s responsibility toward the ADU. The client must use the ADU.Terminate() or the ADU.TerminateMine() method to signal that it has no further interest in the ADU.

Returns There is no return value.

C Program Example

status = Vesp_Request ( "ADU.TerminateMine" , callback, 0x2132, session );

ADU.Touch

IDL Syntax ORBStatus Touch( in string aduid ) ;

Description This method accesses an ADU, just as a GetOneValue might, but it modifies or fetches no values.

As a result, the caller's session and loginid are placed on the internal lists for the ADU, and if the ADU was in the DUStore, it is brought into ADU server memory.

Input Parameters

aduid Agent Data Unit Identifier.

66 Agent Data Unit Serve r Programmer’s Guide

ADU.Transfer

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADU not found in memory or in the ADU Server.

ADU.Transfer

IDL Syntax ORBStatus Transfer( in ADU_ID aduid, in string to ) ;

Description This method generates an ADU.Transfer event to any process monitoring the ADU, changes the

value of the transfercount element and adds the new client to the ADU's list of interested parties. Transfers do not “move” an ADU anywhere.

Transferring an ADU does not end the client’s responsibility to the ADU. The client must use ADU.Terminate() to signal that it has no further interest in modifying the ADU.

Input Parameters

aduid Agent Data Unit Identifier.

to A string representing a new client.

Returns

VESP_SUCCESS Request was successful.

VESP_ERROR ADU not found, or client not a valid string.

C Program Example

/* Transfer an ADU */ char *to; to = ORB_object_to_string(VESP_ORB, &environment, object); Vesp_Request( "ADU.Transfer", callback, 0UL, session, aduid, to);

Issue 1.0 June 2002 67

Chapter 7 ADU Server Methods

68 Agent Data Unit Serve r Programmer’s Guide

INDEX

Symbols

(adudata.alarm.priority) 40 (adudata.data.onlyname) 40 (adudata.event.ifname) 40 (adudata.eventname) 40 (adudata.perecnt) 39 (adus) 38 (checkpoint.interval) 37 (database) 38 (duindex.info1) 39 (duindex.info2) 40 (duindex.info3) 40 (duindex.lookup1) 39 (duindex.lookup2) 39 (dustore) 39 (filter) 41 (findcreatestoresearch) 39 (idletime) 37 (initialdatalength) 38 (keepevents) 39 (maxkeptrevisions) 39 (maxkills) 39 (nouserinterval) 38 (pollwait) 39 (poolgrowsize) 38 (poolsize) 38 (randomkillinterval) 38 (repackfree) 38 (reportkeepname) 41 (scaninterval) 38 (serverresetinterval) 39 (serverretryinterval) 39 (suspendinterval) 39 (watchers) 38 ..eduid 17 ..sourcequeue 17 ..state 18 ..state.. 18 .abandoned 16 .ceiling 16 .connector 16 .contactcount 16 .contactsoffered 17 .currentload 17 .load 17 .login 17 .loginid 17

.logout 17 .privileges 17 .state 17 .state..total 17 .updatetime 17

abandoned 20 Active 17 ADU 9

ADU Contents 14 Adu Data Percent 39 ADU methods

–18

activity 11 agent fields 16 creation 11 description 11 listing active 12 queue fields 20 structure 13 termination 12

abnormal 15

ADU.Assign 48 ADU.Create 48 ADU.Deassign 49 ADU.DeleteOneValue 49 ADU.DeleteSubTree 50 ADU.DeleteValues 50 ADU.Find 51 ADU.FindByKey 52 ADU.FindOrCreate 53 ADU.ForwardEvent 53 ADU.GetActive 54 ADU.GetOneValue 54 ADU.GetSomeValues 55 ADU.GetSubTree 55 ADU.GetValueHistory 56 ADU.GetValues 56 ADU.GetValuesHistory 57 ADU.IncrValue 59 ADU.Monitor 59 ADU.RemoteWatcher 60 ADU.SetAndTerminate 60 ADU.SetAndTransfer 61 ADU.SetDefaultHistoryFilter 61

, 65–66

Index

ADU.SetHistoryFilter 62 ADU.SetOneValue 63 ADU.SetValues 64 ADU.SetValuesExtended 64 ADU.Terminate 65 ADU.TerminateMine 66 ADU.Transfer 67

ADU Server, overview 9 ADU.Assign 48 ADU.change 27 ADU.Create 48 ADU.Deassign 49 ADU.delete 27 ADU.DeleteOneValue 49 ADU.DeleteSubTree 50 ADU.DeleteValues 50 ADU.drop 27 ADU.end 28 ADU.EventsIn 51 ADU.Find 51 ADU.FindByKey 52 ADU.FindOrCreate 53 ADU.ForceTerminate 53 ADU.ForwardEvent 53 ADU.GetActive 54 ADU.GetOneValue 54 ADU.GetSomeValues 55 ADU.GetSubTree 55 ADU.GetValueHistory 56 ADU.GetValues 56 ADU.GetValuesHistory 57 ADU.IncrValue 59 ADU.Monitor 59 ADU.RemoteWatcher 60 ADU.SetAndTerminate 60 ADU.SetAndTransfer 61 ADU.SetDefaultHistoryFilter 61 ADU.SetHistoryFilter 62 ADU.SetOneValue 63 ADU.SetValues 64 ADU.SetValuesExtended 64 ADU.Suspend 65 ADU.Terminate 65 ADU.TerminateMine 66 ADU.Touch 66 ADU.Transfer 67 ADU.transfer 28 ADU.watch 28 adu_id 15 aducon 24 Adudata Alarm Priority 40 Adudata Data Only Name 40 Adudata Event Ifname 40

Adudata Event Name 40 adudata.alarm.priority 40 adudata.data.onlyname 40 adudata.event.ifname 40 adudata.eventname 40 adudata.perecnt 39 ADUHS, support for 42 aduhskeepname 41 ADUID 9 ADUID, structure of 13 adus 38 agent fields 16 Alarm Name 35 Alarms 35 Alerting 18 Alias name, reserved 37 Assign method 48 Assign, request to monitor ADUs 27 AssignFail 35 autostart 41 AuxWork 18 auxwork..detail 16 auxwork..endtime 16 auxwork..starttime 16 Available 17

–18

BadADUInDS 35 Busy 17

call containers

contents (QeS 5.5) 19

ceiling 16 Checkpoint frequency 37 checkpoint.interval 37 cobject 16 Completed 18 connector 20 contactcount 20 contactsoffered 21 Containers

description of 21 limitations of tokens 23 names and tokens 22

containers_56_style 24 containers_60_style 24 Cooperation of ADU Servers 10 Create a new ADU 11 Create method 48 createtime 15 createtimet 15

, 29

, 48

, 29

70 Agent Data Unit Serve r Programmer’s Guide

Index

Data Element Names 39 Database 38 database 38 Deassign method 49 Deassign method, to stop monitoring 28 DeleteOneValue method 49 DeleteSubTree method 50 DeleteValues method 50 DUindex Info1 39 DUindex Info2 40 DUindex Info3 40 DUindex Lookup1 39 DUindex Lookup2 39 duindex.info1 39 duindex.info2 40 duindex.info3 40 duindex.lookup1 39 duindex.lookup2 39 DumpADU 35 duration 15 DUStore 39 dustore 39 DUStore ADU Batch Size 39

, 29

eDU methods

VDU.Transfer 66

educational services 7 endtime 15 Event Monitoring 27 Event monitoring

criteria

starting 27 stopping 28

Event types 27 Events

list of 27

Exception Information 45 Exception information 45

, 29

boolean operators 32 examples 33 relational operators 31 syntax 29 wildcards 32

–28

FailADUCon 36 filter 41 Find Create to Search 39 Find method 51

FindByKey method 52 findcreatestoresearch 39 ForwardEvent method 53

–53

gencount 41 GetActive method 54 GetOneValue method 54 GetSomeValues method 55 GetSubTree method 55 GetValueHistory method 56 GetValues method 56 GetValuesHistory method 57

History, maintaining duplicate 42

id 21 IDL specification 43 Idle Time 37 idletime 37 IncrValue method 59 InitAuxWork 18 initialdatalength 38 Interested parties list 12

keepevents 39

Label 37 last_termination 16 listadu utility 12 load 16 LocalADU, as alias name 37 logfilesize 42 Logged-In 17 Logged-Out 17 login 16 loginid 16 logout 16 LostADUEvents 36

–18

Max Active Adus 37–38 Maximum number of Revisions 39 maxkeptrevisions 39 maxkills 39 media 21

Issue 1.0 June 2002 71

Index

Memory, use of 37 Methods, overview list of 46 minimumagents 21 modifier 18 Monitor method 59 Multiple database servers, use of 42

Name/value pairs, defined 14 No User Interval 38 NoEventSink 36 NoMeInDS 36 nouserinterval 38 Number of Cached Adu events 39 Number of fields 38

oldest 21 On-Hold 18 Overview 9 owner 18 Ownership of an ADU 12

padwidth 41 persistence 15 Ping Interval 42 pingtimer 42 Poll Wait 39 pollwait 39 Pool Growth Increments 38 Pool Re-Pack (%) 38 Pool Size 38 poolgrowsize 38 poolsize 38 priority 21 privileges 18

queue fields 20 queue_key 21

Random Kill Interval 38 randomkillinterval 38 RemoteWatcher method 60 repackfree 38 reportkeepname 41 Reset Interval 39 Retry Interval 39

Routing requests 46

Scan Interval 38 scaninterval 38 serverresetinterval 39 serverretryinterval 39 servicelevel 21 servicelevelmiss 21 SetAndTerminate method 60 SetAndTransfer method 61 SetDefaultHistoryFilter method 61 SetHistoryFilter method 62 SetOneValue method 63 SetValues method 64 SetValuesExtended method 64 Special tokens 22 starttime 18 Start-up Procedures 9 Start-up procedures 9 state 18 statedetail 18 suspend 15 Suspend Interval 39 suspendinterval 39 System considerations 37

, 29

Terminate method 65 TerminateMine method 66 termination 15 time 15 timetype 41 Tokens 22

limitations of 23

trace 42 Transfer method 66 transfercount 18 transfercount. 29 ts. 18 ts..equip 19 ts..loginid 18 ts..phone 18 ts..ptype 18 ts..starttime 19 tscon 24 ttlqueuetime 21 type 15

, 29

–67

updatetime 21

72 Agent Data Unit Serve r Programmer’s Guide

Victims 36 voice.1.state 26 voice.1.state.alerting.starttime 26 voice.1.state.disconnected.starttime 26 voice.1.state.hold.starttime 26 voice.1.state.incall.starttime 26 voice.2.state 26 voice.2.state.incall.starttime 26 voice.acdname 19 voice.connector 19 voice.connectorname 19 voice.state.hold.total 26 voice.state.incall.total 26 voice.X 19 voice.X.abandon 19 voice.X.agent_key 19 voice.X.conferencedest.Z 19 voice.X.connect 19 voice.X.destination 19 voice.X.direction 19 voice.X.exit_reason 19

voice.X.holdtime.Y 19 voice.X.leg_id 20 voice.X.loginid 20 voice.X.origin 20 voice.X.queue 20 voice.X.queue_number 20 voice.X.queuetime 20 voice.X.ringtime 20 voice.X.talktime 20 voice.X.transfer 20

WAN environment 10 Watchers 38 watchers 38 Wildcard usage 28 Wildcards 32 Wrap-up 17

–18

youngest 21

Index

Issue 1.0 June 2002 73

Index

74 Agent Data Unit Serve r Programmer’s Guide

Avaya Release 6.0, Interaction Center 6.0 Programmer's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
