DEFINITY

4606 IP Telephone

Release 1 User’s Guide

555-233-775 Issue 1 Comcode 700206444 July 2001

Page 2

Page 3

Copyright and Legal Notices

Notice

Every effort was made to ensure that the information in this book was comple te and accurate at the ti me of printing. Howev er, information is subject to change.

Avaya Web Page

The World Wide Web home page for Avaya is: http://www.avaya.com

Preventing Toll Fraud

“Toll fraud” is the unauthorized use of your telecommunications system by an unauthorized party (for example, a person who is not a corporate employee, agent, subcontractor, or working on your company’s behalf). Be aw are th at th ere ma y b e a ris k of tol l f raud associated with your system and that, if toll fraud occurs, it can result in substantial additional charges for your telecommunications services.

Avaya Fraud Intervention

If you suspect you are being victimized by toll fraud and you need technical support or assist ance, call the appropriate Avaya National Customer Car e Center telephone number. Users of the MERLIN®, PARTNER®, and System 25 produ ct s shoul d ca ll 1 800 628-2888. Users of the System 75, Syste m 85 , DEFINIT Y ® Generic 1, 2 and 3, and DEFINITY ® EC S products should call 1 800 643-2353.

Providing T elecommunications Security

Telecommunications security of voic e, da ta, and/or video communications is the prevention of any type of i n trusion to, that is, either unauthoriz ed or malicious access to or use of, your com pany’s telecommunications equipment) by some party.

Your company’s “telec o mmunications equipment” include s bot h this Avaya product and any other voice/data/video equipment that could be accessed via thi s Avaya product (i.e., “networked equipment”).

An “outside party” is anyone who is not a corporate employee, agent, subcontrac tor, or working on your company’s behalf. Whereas, a “malicious party” is anyone, including someone who may be otherwise authorized, who a ccesse s your telecom munications equipm ent with either malici ous or mischievous intent .

Such intrusions may be either to/through synchronous (time-multiplexed and/or circuit-based) or asynchronous (characte r-, m essage-, or packet-based) equipment or interfaces for reasons of:

• Utilization of capabilities special to the accessed equipment

• Theft (such as, of intellectual property, financial assets, or toll-facil ity access)

• Eavesdropping (privacy invasions to humans)

• Mischief (troubling, but appare nt ly i nnocuous, tampering)

• Harm (such as harmful ta m pering, data loss or alteration, regardless of motive or intent)

Be aware that there may be a risk of unauthorized intrusions associated with your system and/or its networked equipme nt . Also realize that, if such an intrusion sho uld occur, it could result in a

variety of losses to your com pa ny including, but not limited to, human/data privacy, intellectual prope rty, material assets, financial resources, labor costs, and/or l egal costs.

Y o ur Responsibility for Your Company’s Telecommunications Security

The final responsibility for securing both this system and its networked equipment rest s wit h you – an Avaya customer ’s system administrator, your telecommunications peers, and your managers. Base the fulfillment of your responsibility on acquired knowledge and resources from a variety of sources including, but not li m it ed to:

• Installatio n doc uments

• System administration documents

• Security docume nt s

• Hardware-/software-ba sed se curity tools

• Shared information between you and your peers

• Telecommunications security experts To prevent intrusions to your telecommunications equipment, you and your peers should ca refully program and configure your:

• Avaya-provided telecommunications systems and their

interfaces

• Avaya-provided software applica tions, as well as their

underlying hardware /software platforms and interfaces

• Any other equipment networked to yo ur Avaya products Avaya does not warrant that this product or any of its networked equipment is eithe r im mune from or will prevent either unauthorized or malicious intrusions. Avaya will not be responsible for any charges, losses, or damages that result from such int rusi ons.

Federal Communications Commission Statement Part 15: Class A Statement. This equipment has been tested and

found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable pro tection against harmful in te rference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not install ed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential are a is likely to cause harm ful interference , in which case the user w il l be required to correct the interference at his own expense.

Part 15: Class B Statement. This eq uipment has been tes ted and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Thes e li m it s are desi gne d to provide reasonable pr ote ction against harmful interference in a residential installation. This equipment genera tes, uses, and can radiate radio-frequency energy and, if not insta ll ed and used in accordance with the instructions, may cause harmful interference to radio comm uni cations. However, ther e is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmf ul interference to radio or televisi on re ception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measure s:

• Reorient the receivi ng t el evision or radio antenna where

this may be done safely.

• To the extent possible, relocate the receiver with respect to

the telephone equipment.

• Where the telephone equipment requires ac power, plug the

telephone into a different ac outlet so tha t t he telephone equipment and receiver are on different branch circuits.

Page 4

Part 15: Personal Compute r Sta tement. This equipment has been certified to comply with the limits for a Class B computing device, pursua nt to Subpart J of Part 15 of FCC Rules. Only peripherals (com puting input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to this computer. Operation with noncertified peripherals is likely to result in interference to radio and television reception.

Part 68: Network Registration Number. This e qui pm ent is registered with the FCC in accordance with Part 68 of the FCC Rules.

Part 68: Answer-Supervision Signaling. Allowing this equipment to be operated in a manner that does not provide proper answer-supervision signaling is in violation of Part 68 Rules. This equipment returns answer-supervision signals to the public switched network when:

• Answered by the called station

• Answered by the attendant

• Routed to a recorded a nnouncement that can be administered by the CPE user

This equipment returns answer-supervision signals on all DID calls forwarded back to the public switched telephone network. Permissible exceptions are:

• A call is unanswered

• A busy tone is received

• A reorder tone is received

Industry Canada (IC) Interference Information

This digital apparatus does not exceed the Class A limits for radio noise emissions set out in th e radio interference regulations of Industry Canada.

Document” entitled “Related Resources.”

You can be placed on a standing order list for this and other documents you may need. For more information on standing orders, or to be put on a list to receive future issues of this document, contact the Avaya Publications Ce nte r.

Obtaining Products

To learn more about Avaya products and to order products, contact Avaya Direct, the direct-market organization of Avaya Business Communications Systems. Access their web site at www.avayadirect.com. Or call the following numbers: customers 1 800 451 2100, account executives 1 888 778 1880 (voice) or 1 888 778 1881 (fa x).

Warranty

Avaya provides a limited warranty on this product. Refer to the “Limited Use Software License Agreement” card provided with your package.

European Union Declaration of Conformity

The “CE” mark affixed to the equipment mean s that it conforms to the above dire ct ives. Avaya Business Communications Systems declares that equipmen t s pecified in this document conform s to th e referenced European Union (E U) Directives and Harmoni ze d Standards listed below: EMC Directive 89/336/EEC Low-Voltage Directive73/23/EEC

Acknowledgment

This docume nt w as prepared by Avaya Universi ty, Avaya, Denver, CO.

Le Présent Appareil Nomérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A préscrites dans le reglement sur le brouillage radi oélectrique édicté par le Industrie Canada.

Trademarks

All trademarks identified by

®, ™ and

are registered trademarks, trade marks, or service marks, respective ly, of Avaya Inc. All other trademarks are the properties of their respective owne r s .

Ordering Information Call: Avaya Publications Center

Voice 1 800 457-1235 Internationa l Voice +1

317 322-6791

Fax 1 800 457-1764 International Fa x +1 317

322-6699 Write: Avaya Publications Center

2855 N. Franklin Road

Indianapolis, IN 46219 USA Documents may also be ordered from the Customer Information Centre in Malmesbury, England. Call: 44 1666 83-2900 Fax 44 1666 83-2213 For additional documents, refer to the section in “About This

Page 5

Contents

About This Document

■

Purpose vii

■

Intended Audience vii

■

Issue Date vii

■

How to Use This Document vii

■

Document Organization viii

■

Conventions Used ix

Symbolic Conventions ix Typographic Conventions ix

■

About This Document

Purpose

The DEFINITY® 4606 IP Telephone User’s Guide describes the 4606 IP Telephone’s operation and functionality.

Intended Audience

This document is intended for telephone users who have a 4606 IP Telephone at their desks. It is not intended to be a technical reference guide for System Administrators or phone technicians.

Issue Date

This document was issued for the first time in July, 2001. IP Telephone user documentation has been available online at the Av aya support site, http://support.avaya.com since October, 2000.

How to Use This Document

This Guide is organized to help you find topics in a logical manner. Read it from start to finish to get a thorough understanding of how to use your 4606 IP Telephone, or review the Table of Contents to locate information specific to a task or function you want to perform.

Issue 1 July 2001

vii

Page 12

About This Document

Document Organization

This guide contains the following chapters:

Chapter 1, 4606 IP Telephone Description

Chapter 2, Using Programmable Buttons

Chapter 3, Using the Display Screen Describes the display screen area at

Chapter 4, Call Handling Features Describes dedicated Feature

Chapter 5, IP Telephone Features Explains the telephone features

Chapter 6, Message Retrieval Covers how to access messages left

Chapter 7, IP Telephone Management Features

Chapter 8, Using a Headset or Specialized Handset

Describes each element on the face of the telephone.

Explains how to program certain Line/Feature buttons for additional functionality.

the top of the phone.

buttons, such as Conference, Hold, Redial and Transfer.

accessed using Line/Feature buttons or Feature Access Codes.

on your phone. Explains how to test your phone and

personalize its ringing pattern. Interpreting ringer tones and indicator lights are also covered in this chapter.

Describes the headsets and handsets that are compatible with your IP Telephone.

Chapter 9, Troubleshooting Provides basic Troubleshooting

viii

Issue 1 July 2001

actions if you encounter errors or experience problems.

Page 13

Conventions Used

This guide uses the following textual, symbolic, and typographic conventions to help you interpret information.

Symbolic Conventions

NOTE:

This symbol precedes additional information about a topic.

Typographic Conventions

This guide uses the following typographic conventions:

“italics”

italics

Enter

Italic type enclosed within quotation marks indicates a document or section in this document containing additional information about a topic.

Italic type indicates the result of an action you take or a system response in step by step procedures.

In step by step procedures, words shown in bold represent a single telephone button that should be pressed. These include

Menu, Exit

and #.

4606 IP Telephone Description

Introduction

This chapter introduces you to the layout of the 4606 IP Telephone. It provides a description for each functional button and other phone characteristics.

The 4606 IP Phone

The 4606 IP telephone is a multi-line phone with 6 Line/Feature buttons, 6 dedicated feature buttons, a 2-line by 16 character display area, and a full-duplex, two-way speakerphone.

3 4

Issue 1 July 2001

1-1

Page 15

Match the numbered callouts on the 4606 illustration to the descriptions below.

Display

1. phone usage, the top line shows the name/phone number you are calling or the name/phone number of the person calling you; while idle, it displays the current date and time. The second line also displays volume control (when a volume arrow is pressed) and elapsed time (when the Timer feature is active).

- The display screen has two lines of 16 characters each. During

(Conference)

person. With the phone on-hook, also used to select a personal ringing pattern.

(Transfer)

on-hook, also used to test lights and the display screen.

(Redial)

Line/Feature buttons

dedicated to incoming and outgoing calls; those line buttons are labeled with an extension number. The Line/Feature buttons not dedicated to incoming or outgoing calls provide access to system features like sending all calls to another phone or speed-dialing. For your specific configuration, see your System Administrator. One red and one green light appear next to each button. Steady red indicates the line is available. Steady green indicates the line or feature is in use; other green light indications (winking, fluttering and flashing) are feature-specific.

Mute/Speaker Light

Flashes when the handset, headset or Speakerphone microphone is muted.

(Speaker)

feature. The LED above this button lights when the speakerphone is active.

Voice Message Light

- Set up conference calls with more than one other

- Transfer a call to another phone. With the phone

- Redial the last number dialed from the phone.

- Several of the six buttons are Line buttons

- Lights steadily when the Speakerphone is active.

- Access the built in two-way, full-duplex Speakerphone

- When lit, indicates you have a message waiting.

1-2

Issue 1 July 2001

10.

11.

12.

(Mute)

prevent the other person from hearing you. The LED above the Spkr button flashes when the microphone is muted.

(Volume Control)

depending on which item is in use.

Numeric (Dialing) Pad

numbers.

(Hold)

- Turn off the active microphone (handset or speaker), to

- Adjust the speaker, handset or ringer volume,

- Standard 12 button pad for dialing phone

- Red button used to place a call on hold.

Page 16

Using Programmable Buttons

Introduction

Your 4606 IP Telephone has six Line/Feature buttons, some of which are dedicated to incoming and outgoing calls. The remaining Line/Feature buttons can be programmed by your Telephone System Administrator to provide additional phone functionality.

Programmable Line/Feature Buttons

Line buttons available for incoming/outgoing calls are usually the first few buttons on the left-most button column.

The Line/Feature buttons following your incoming/outgoing lines may be reserved for features not available using dedicated buttons like

(Mute) and search, Inspect phone features and Program may also be assigned to this group of buttons. These features may alternately be available through Feature Access Codes.

Two suggested features for 4606 IP Telephone users to add are allows a party to be dropped from a conference call) and the display when using certain features like the Directory).

For information regarding how the Line/Feature buttons have been set up for your phone system, contact your System Administrator. Be sure that the Line/Feature button labels are filled in before starting to use your telephone, and that you update them promptly for new, customized features.

(Speaker). Features such as Voice Mail retrieval, Directory

(Conference),

Drop

Normal

(which clears

(which

Issue 1 July 2001

2-1

Page 17

IP Telephone Features Available on Programmable Line/Feature Buttons

Regardless of whether a specific feature is available on a Line/Feature button, or via an Access Code, you can find procedures for all 4606 IP Telephone features in Chapter 5, “

IP Telephone Features

.”

2-2

Issue 1 July 2001

Page 18

Using the Display Screen

Introduction

The DEFINITY® 4606 IP Telephone has a 2-line by 16 character display (screen) area located at the top third of the phone. What you see on the display is controlled by the current status of the phone or by selections you make using Line/Feature buttons, Access Codes, or dedicated feature buttons like Redial or Transfer.

The 4606 IP Telephone's display:

■

Indicates the date and time of day on the top line when the phone is idle

■

Displays call information on both lines, such as the extension being dialed or the name and extension of someone calling you

■

Shows feature-related instructions or messages when using certain phone features

About the Display Screen

The two display lines provide (general) information (time of day), feature information/instructions, and/or call information.

Upper Display Line

The Time and Date appear on the upper display line when the phone is idle. Time and date are set at the switch, so if there is an error, contact your Telephone System Administrator.

When plugging in your 4606 IP Telephone for the first time, or after a power outage, it may take several minutes for the time and date to appear on the display screen.

Issue 1 July 2001

3-1

Page 19

Lower Display Line

Line/Feature Button Information

Line/Feature button information identifies the line being used. Each of the six Line/Feature buttons is given an alphabetic designation of a through c (left column) and d through f (right column). When the display shows a=, it represents call information for the first Line/Feature button; the next button down would show as b=, and so on. Line/Feature buttons are also called "call appearance" buttons.

Call Information

Call information, such as the extension being dialed or the name and extension of the person you are calling, displays. When someone on another extension calls you, the display shows the caller's name. Outside calls show either the telephone number, the words OUTSIDE CALL, or a trunk identifier.

3-2

Issue 1 July 2001

Page 20

Call Handling Features

Introduction

Call-handling features are those you would use while a call is in progress or while making a call. They are those features which have a dedicated phone button, such as:

■

Conference

■

Hold

■

Redial

■

Speaker

■

Transfer

■

Mute

Each of the above features is described in detail in this section.

Conference

The Conference feature allows you to conference up to the maximum number of parties set by your System Administrator.

Adding another party to a call

1. Dial the first party, then press .

The current call is placed on hold and you hear a dial tone.

2. Dial the number of the next party and wait for an answer.

3. Press again to add the new party to the call.

4. Repeat Steps 1- 3 for each party you want to conference in to the call.

Issue 1 July 2001

4-1

Page 21

Adding a held call to the current call

1. Press .

The current line and the held line lights flutter.

2. Press the line button of the held call.

Press again.

All parties are now connected.

Dropping the last person added to the confer ence call

Press the as the "Drop" button.

The last party connected to the conference call is dropped from the call.

Line/Feature button your System Administrator has designated

Hold

The Hold feature puts a call on hold until you return to it.

Placing a call on hold

Press .

The green light next to the held line blinks.

Returning to the held call

4-2

Issue 1 July 2001

Press the line button of the held call.

The call is restored.

Page 22

Mute

During an active call, the Mute feature prevents the party with whom you are speaking from hearing you. This feature is most commonly used in conjunction with the Speakerphone, but can be used to hold an off-line conversation at any time during a call.

Preventing the other person on the line from hearing you

Press .

The other party cannot hear you. The indicator light above blinks when Mute is active.

2. To reinstate two-way conversation, press again.

Redial

The Redial (or, Last Number Dialed) feature automatically initiates dialing of the most recent extension or outside number dialed.

Redialing the last number called

Press .

The last number dialed is automatically redialed.

Speakerphone

A two-way, built-in Speakerphone lets you place and answer calls without lifting the handset.

Your telephone may be set for the two-way Speakerphone or for the one-way, listen-only Speaker. Check with your System Administrator to see for which feature your telephone is set.

NOTE:

It is also possible to disable the Speakerphone feature. If your Speakerphone does not operate as indicated, contact your System Administrator to be sure your telephone's Speakerphone is enabled.

Issue 1 July 2001

4-3

Page 23

Placing a call without l ift in g the handset or using the Speakerphone with any feature

1. Press .

The Speaker/Mute indicator above lights and voice control is handled by the speaker.

2. Place or answer the call, or access the selected feature.

3. Adjust the speaker volume if needed by pressing until you reach the desired volume lev el.

As you press , the display screen shows the volume leve

Changing from the speakerphone to the handset

Pick up the handset and talk.

The Speaker/Mute indicator above goes off.

Turning the speaker on during a call

Press .

The Speaker/Mute indicator above lights. Both the speaker and handset are now operational.

Turning the speaker off during a call

Lift the handset at any time.

The speaker and the corresponding indicator light turn off; voice control reverts to the handset.

Ending a call while the speaker is active

4-4

Issue 1 July 2001

Press .

The speaker and the corresponding indicator light turn off and the call terminates.

Page 24

Transfer

The Transfer feature lets you transfer a call from your telephone to another extension or outside number.

Sending a call to another telephone

1. With the call active (or with only one held call and no active calls), press .

The call is placed on hold and its associated indicator light blinks; you hear a dial tone and the next available line activates.

2. Dial the number to which you want to transfer the call.

3. Remain on the line and announce the call; if the line is busy or if no one

answers, return to the held call by pressing the line button on which it is being held.

4. Press again.

The call is sent to the extension or number you dialed. A two-second display message indicates the transfer is complete.

5. Hang up your handset.

Issue 1 July 2001

4-5

Page 25

4-6

Issue 1 July 2001

Page 26

IP Telephone Features

Introduction

This chapter contains procedures for using DEFINITY® phone features. Depending on how your 4606 IP Telephone was set up by your System Administrator, you can access some or all of the features discussed in this chapter using Line/Feature buttons or Feature Access Codes.

We cover feature access methods in the next section. Following that section, a “Feature List” provides a reference to the procedures for activating and using features, which are then listed in alphabetical order.

Check with your System Administrator for the configuration of your phone system.

Accessing IP Telephone Features

Your 4606 IP Telephone provides two ways to access IP T elephone features:

1. Your System Administrator may have programmed some of your

telephone's Line/Feature buttons to automatically access a feature when pressed. "steady green" indicator light to signify active status. When the feature is deactivated (turned off), the indicator light goes off.

2. If you don't have a button administered on your phone for a specific feature,

you may be able to access a feature by entering a two or three digit Feature Access code using the number pad. Note that the procedures in this chapter often provide information about using access codes for applicable features. Your System Administrator assigns access codes.

In some cases, features activated via Line/Feature buttons have a

NOTE:

Note that because the DEFINITY 4606 IP Telephone has just six line/feature buttons, button-activated features may be limited.

Issue 1 July 2001

5-1

Page 27

Whether your DEFINITY® IP telephone system uses access codes and/or feature buttons, be sure to check with your System Administrator to find out your phone system’s specific configuration.

Feature List

The following DEFINITY® Features are described in alphabetic order in this chapter:

Table 5-1. DEFINITY® Features

■

Abbreviated Dialing

■

Account Code Entry

■

Automatic Callback

■

Automatic Intercom

■

Button View

■

Call Display

■

Call Forwarding (all calls)

■

Call Park

■

Call Pickup/Directed Call Pickup

■

Consult

■

Abbreviated Dialing (AD)

The Abbreviated Dialing (AD) feature lets you access stored numbers for quick and easy dialing. The numbers stored can be a complete or partial telephone number, a trunk code (to access an outside line), an extension or a feature Access Code. You can also set up a Personal Abbreviated Dialing list, to allow you to access frequently-dialed numbers using short access codes.

To be programmable for abbreviated dialing, a Line/Feature button must be administered for the Abbreviated Dialing feature; check with your System Administrator to see if AD is available on your phone, then see the

Abbreviated Dialing”

has been disabled, lift the handset or use the headset to go off-hook before using AD.

Placing an Abbreviated Dialing call

Press the Line/Feature button programmed to dial the number or extension you want to call.

feature later in this chapter. Also, if your telephone's speaker

“Program

Your call is dialed automatically.

Account

The Account feature allows users to enter Call Detail Recording (CDR) account codes. CDR account codes allow your phone system to associate and track calls according to a particular project or account number.

Issue 1 July 2001

5-3

Page 29

Automatic Callback

The Automatic Callback feature sends your phone a priority ring, indicating the previously busy or unanswered extension you dialed is now available. Note that if you initiate call forwarding after activating Automatic Callback, returned calls (callbacks) are not forwarded, and ring at your phone.

Automatically placing another call to an extension that was busy or did not answer, or in response to a returned call waiting ringback tone

1. During a call attempt, press the button your System Administrator has designated for Automatic Callback.

Three tones indicate Automatic Callback is active.

2. Hang up.

You hear a priority ring when both your phone and the number you called are available. The display shows the message "Callback."

3. When you hear the priority ring, lift the handset.

Your call proceeds as originally dialed.

NOTE:

Automatic Callback cancels (automatically) after 30 minutes.

Canceling Automatic Callback

With the handset on-hook, press the button your System Administrator has designated for Automatic Callback again.

ne tone indicates automatic callback is canceled; this feature

automatically cancels after 30 minutes.

Automatic Intercom

The Automatic Intercom feature places a call to a specific phone associated with this button. The recipient of the call receives a unique alerting ring, and the indicator light associated with the intercom button flashes.

5-4

Issue 1 July 2001

Page 30

Button View

The Button View feature lets you display the name of the feature that has been programmed on any of your telephone's Line/Feature (call appearance) buttons.

Viewing the feature programmed on a Line/Feature button

1. Press the button your System Administrator has programmed to represent

2. Press the Line/Feature button for which you want to see its assigned

Button View.

function.

The Line/Feature button assignment or telephone number displays.

3. To see another feature/number, repeat this procedure from Step 2.

Call Display

The Call Display feature initiates a call to the phone extension or number shown on the display screen. The number displayed could be from a Leave Word Calling (LWC) message, or a number you retrieved using the directory feature.

Call Forwarding

The Call Forwarding feature lets you redirect all calls to your phone to another extension or an outside number. Because this feature may operate differently among customers, check your office procedures for call forwarding before performing the procedures below. Call forwarding must be disabled to resume call pickup at your phone.

Temporarily sending your calls to another phone

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Call Forwarding, press that button to initiate call forwarding,

or Dial the Call Forward Access Code with the phone off-hook.

2. Dial the extension or number to which calls should be sent.

3. Hang up.

When Call Forwarding has been activated, the Line indicator light is on and you may hear a brief ring-ping tone as each call is forwarded.

Issue 1 July 2001

5-5

Page 31

Canceling Call Forwarding

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Call Forwarding Cancel, press that button,

or Dial the Call Forward Cancel Access Code with the phone off-hook.

The Line indicator light goes off and you hear a confirmation tone; your calls will now ring at your phone.

Call Park

The Call Park feature lets you place a call on hold at your telephone for retrieval at any extension.

Parking a call at your extension

If your System Administrator has programmed one of the Line/Feature buttons to represent Call Park, press that button to initiate Call Park.

The call is parked at your extension.

Retrieving a parked call from another extension

1. With the handset off-hook, dial the Answer Back Access Code.

2. Dial the extension where you parked the call (usually your own extension).

If an intercept tone sounds, the parked call has been disconnected or retrieved by someone else.

5-6

Issue 1 July 2001

Page 32

Call Pickup and Directed Call Pickup

The Call Pickup feature lets you answer a call at your telephone for another extension in your call pickup group. Directed call pickup, if available, lets you pick up a call for a specific extension even if that extension is not part of your pickup group. Because these features may operate differently among customers, check your office procedures on picking up calls before performing the procedures below.

Answering a call placed to someone in your pickup group (when your phone is idle)

If your System Administrator has programmed one of the Line/Feature buttons to represent Call Pickup, press the Call Pickup Feature button,

or Dial the Call Pickup Access Code.

The extension called stops ringing and you are connected to the call for pickup

Picking up a call for someone in your office using Directed Call Pickup

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Directed Call Pickup, press that button,

or Dial the Directed Call Pickup Access Code.

2. Dial the extension for which you want to pick up a call.

The extension called stops ringing and you are connected to the call for pickup.

Consult

The Consult feature allows a covering user, after answering a coverage call, to call the principal (the party called) for private consultation. Activating the Consult feature places the caller on hold and establishes a private connection between the principal and the covering user. The covering user may then add the caller to the conversation, transfer the call to the principal, or return to the caller.

Issue 1 July 2001

5-7

Page 33

Drop (a Person from a Conference Call)

See

5-8

Issue 1 July 2001

“Conference”

in Chapter 4, “

Call Handling Features

.”

Page 34

Exclusion

The Exclusion feature allows multi-appearance users to prevent other multi-appearance users having the same extension from bridging on to an existing call.

Group Paging

The Group Page feature allows users make announcements to groups of phone stations by automatically turning on their speakerphones.

Hands Free Answer on Intercom

“Internal Auto Answer”

See

in this chapter.

Headset On/Off

The Headset On/Off feature allows headset usage to be activated or deactivated using a Line/Feature button. When this feature is active, the green indicator light corresponding to the button administered signifies the headset is off-hook; when the indicator is not lit, it signifies on-hook headset status.

Inspect

The Inspect feature provides call-related information for an incoming or held call when you are active on another call.

Using the Inspect feature:

1. Press the Line/Feature button your System Administrator has programmed to represent this feature.

2. Press the Line/Feature button of the incoming or held call.

The display shows the name and/or number of the person calling/on hold, and you remain connected to the active call.

3. To answer the incoming or held call, put the current call on hold (or hang up).

4. Press the Line/Feature button of the incoming or held call.

Issue 1 July 2001

5-9

Page 35

Internal Auto Answer (Hands Free Answer)

The Internal Auto Answer (or Hands-Free Answer on Intercom) feature lets your Speakerphone-equipped telephone automatically go off-hook to answer internal calls.

Answering internal calls automatically

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Internal Auto Ans wer, press that button to initiate this feature,

or Dial the Internal Auto Answer Access Code.

A three-tone warble sounds when your phone goes off-hook on each internal call. The Speaker indicator lights.

2. Use the Speakerphone to proceed with the call.

Canceling Internal Auto Answer

If your System Administrator has programmed one of the Line/Feature buttons to represent Internal Auto Answer (Hands Free Ans wer), press that button to cancel internal auto answer.

or Dial the Internal Auto Answer Access Code again.

Control reverts to the handset.

Leave Word Calling

The Leave Word Calling (LWC) feature lets you leave a standard message for a person at another extension. LWC allows the called party to retrieve a short, standard message (your name, extension, date and time called and number of times you called) from your message service (AUDIX, other voice mail system or a covering user).

5-10

Issue 1 July 2001

Page 36

Pause (During Abbreviated Dialing)

Leaving a message after dialing an extension (in response to a busy or coverage tone, no answer or Hold status)

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Leave Word Calling, press that button to initiate leave word calling,

The Speaker indicator light activates.

2. Hang up.

The Message Indicator light at the extension called goes on.

Leaving a message without ringing an extension

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Leave Word Calling, press that button to initiate leave word calling,

The Speaker indicator light activates.

2. Dial the extension.

The Message Indicator light at the extension called goes on.

3. Hang up.

Canceling a Leave Word Calling message

You cannot cancel a LWC message left for an AUDIX subscriber.

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Cancel Leave Word Calling, press that button. The phone can be either on- or off-hook.

2. Dial the extension at which you left the message.

You hear a confirmation tone.

3. Hang up.

Pause (During Abbreviated Dialing)

The Pause feature allows a pause to be programmed into an Abbreviated Dialing entry when setting up an abbreviated dialing number or list.

Issue 1 July 2001

5-11

Page 37

Priority Calling

The Priority Calling feature lets you place an internal call with a distinctive ring (usually a 3-burst ring) to indicate your call needs immediate attention.

Placing a priority call

1. If your System Administrator has programmed one of the Line/Feature buttons to represent Priority Calling, press that button,

or Dial the Priority Calling Access Code.

2. Dial the extension and wait for the person to answer.

The extension called receives three ring tones and the message "Priority" displays.

If your call is not answered, you can redirect it to a person on coverage. While the phone is ringing, pressing the Line/Feature button your System Administrator has designated as the Go to Cover button.

Changing a regular call into a priority call (when you hear a call waiting ringback tone)

If you use an access code for priority calling, you cannot use an access code after dialing an extension to change a regular call into a priority call.

If you have a Line/Feature button programmed for priority calling, stay on the line when you hear the ringback tone indicating the phone is in use and follow the steps above for placing a priority call. If you still receive a call waiting ringback tone, hang up and place the priority call again in a few minutes.

5-12

Issue 1 July 2001

Page 38

Program Abbreviated Dialing

To be programmable for abbreviated dialing, a Line/Feature button must be administered for the Abbreviated Dialing feature. Note that two separate procedures follow for programming Abbreviated Dialing numbers — one for programming Line/Feature buttons for abbreviated dialing using the Program feature, and one for programming Line/Feature buttons for abbreviated dialing using an AD Access Code.

Programming or re-programming a single Abbreviated Dialing button on a Line/Feature button using the Program feature

Use this procedure only if your System Administrator has programmed a Line/Feature button for the

NOTE:

If you make a mistake while programming, you CANNO T mov e back a space to erase it. Instead, press the # key or go on-hook to erase the entry and start over.

Prog

(Program) feature.

1. Write down the outside numbers, extensions and/or Feature Access codes you want to program. (Each AD button holds one complete phone number, an inside extension or a Feature Access code.)

2. To enter programming mode, press the Line/Feature button to which your System Administrator has assigned the Program Abbreviated Dialing feature.

The phone goes off-hook, the Speaker indicator lights and the message "Press button to program" displays.

3. Press the pre-administered Line/Feature button you want to program for Abbreviated Dialing.

The message "Enter number" displays.

4. Enter the outside number, extension or Feature Access Code you want to store. An automatic dialing number or code can be from 1 - 16 digits. (24 digits are allowed if the number is associated with an AD list; see your System Administrator for information.) When programming an outside number, be sure to include the trunk code, for example, a "9" if applicable.

5. Press the # button to save the number or code.

A three-beep confirmation tone indicates the AD number has been stored and the message "Number saved" displays for one second.

6. Record the number, code or other identification on the label next to the AD button.

7. Repeat Steps 1 through 6 to program additional AD numbers on Line/Feature buttons.

Issue 1 July 2001

5-13

Page 39

8. To end programming, hang up by pressing or lifting and replacing the handset.

Programming or re-programming a single Abbreviated Dialing button on a Line/Feature button using an AD Access Code

Use this procedure only if your System Administrator has programmed an Abbreviated Dialing Access Code.

Write down the outside numbers, extensions and/or feature access codes you want to program. (Each AD button holds one complete phone number or feature access code.)

1. Pick up the handset.

Dial the Abbreviated Dialing Access Code, if your System Administrator has programmed one.

The phone goes off-hook and the Speaker indicator lights.

3. Press the Line/Feature button you want to program for Abbreviated Dialing.

NOTE:

There is a 10-second time limit between your going off-hook and entering the first digit of an AD button, and then a 10-second time limit between each digit. If you hear an intercept tone while you are programming the button, you have exceeded the time limit and must begin again.

4. Dial the outside number, extension or feature Access Code you want to store. An automatic dialing number or code can be from 1 - 16 digits (24 digits are allowed if the number is associated with an AD list; see your System Administrator for information). When programming an outside number, be sure to include the trunk code, for example, a "9" if applicable.

5. Press th e # key to save the number.

A confirmation tone indicates the AD number has been stored.

6. Record the number, code or other identification on the label next to the AD button.

7. Repeat Steps 4 through 6 to program additional AD buttons.

8. To end programming, hang up by pressing or lifting the handset.

5-14

Issue 1 July 2001

Page 40

Release

The Release feature allows an agent on an ACD (Automated Call Dialing) call to be released from that call. This feature is used in conjunction with other ACD features.

Ringer Off

The Ringer Off feature stops your phone from ringing. Use this feature when you don't want to be disturbed. When your ringer is set to off, the Line indicator lights and the display alerts you to incoming calls. Your phone also gives one short ring burst to indicate an incoming call.

Turning the ringer off

If your System Administrator has programmed one of the Line/Feature buttons to represent ringer off, press that button,

or Dial the Ringer Off Access Code.

Turning the ringer back on

If your System Administrator has programmed one of the Line/Feature buttons to represent Ringer Off, press that button again to turn the ringer back on.

or Dial the Ringer Off Access Code again.

Issue 1 July 2001

5-15

Page 41

Send All Calls

The Send All Calls feature lets you temporarily send your calls to the extension of a person designated by the System Administrator to answer them when you cannot.

Sending all calls (except priority calls) immediately to a coverage extension

Your Telephone System Administrator must provide a coverage path before you can use this feature.

If your System Administrator has programmed one of the Line/Feature buttons to represent Send All Calls, with the phone on-hook, press that button to initiate coverage,

or With the phone on-hook, dial the Send All Calls Access Code.

You may hear a ring-ping (half-ring) tone as each call is forwarded.

Canceling send all calls

If your System Administrator has programmed one of the Line/Feature buttons to represent Send All Calls, with the phone on-hook, press that button again to cancel coverage,

or With the phone off-hook, dial the Send All Calls Cancel Access Code.

A confirmation tone indicates coverage cancellation.

5-16

Issue 1 July 2001

Page 42

Stored Number (View)

The Stored Number feature lets you display:

■

The numbers stored in Abbreviated Dialing (AD) locations

■

The number you last dialed

Viewing either the last number dialed or a number stored on an AD button

1. If one has been programmed by your System Administrator , press the Line/Feature button.

2. To view the last number dialed, press , or To view the number stored on an Abbreviated Dialing button, press the

applicable AD Line/Feature button.

The associated telephone number displays.

3. To return to call handling mode, press feature/number, repeat this procedure from Step 2.

Timer

The Timer (display) feature lets you measure elapsed time.

Exit

or, to see another

View

Viewing elapsed time (hours, minutes, seconds)

1. Press the Line/Feature button your System Administrator has programmed for the Timer feature.

The elapsed time displays.

2. To stop the Timer and clear the display, press the button your System Administrator has programmed for the Timer feature again.

The time elapsed since initiating the Timer displays for about three seconds, then disappears.

Issue 1 July 2001

5-17

Page 43

Whisper Page (Activate)

The Whisper Page feature lets you make an announcement to a person at another extension who is currently on a call; only the person being paged hears the announcement.

NOTE:

If you have a headset other than those recommended (see Chapter 8) or a base unit/adaptor other than the M12LU Modular Base Unit plugged into your 4624 telephone, the Whisper Page announcement may be overheard by the other person on the call.

Making an important announcement (such as an incoming call) to an extension with a call in progress

If your System Administrator has programmed one of the Line/Feature buttons to represent Whisper Page Activate, press that button,

or Dial the Whisper Page Activate Access Code.

You hear a dial tone.

2. Dial the number of the person you want to page.

Both parties on the other call hear a beep.

You can now speak to the party you paged without the other person on the call hearing you. The paged party cannot speak to you unless the "Answering a Whisper Page call" procedure is followed.

5-18

Issue 1 July 2001

Page 44

Whisper Page Answer

The Whisper Page Answer feature lets you speak with a person who pages you while you are on a call.

NOTE:

Answering a Whisper Page call

1. When you hear the Whisper Page beep while on a call, press the button your System Administrator has designated for Whisper Page Answer.

Your current call is placed on hold to allow you to speak with the person who paged you. The party on hold cannot hear your conversation.

2. When you finish speaking with the person who paged you, remove the original call from Hold and resume your conversation.

Whisper Page Off

The Whisper Page Off feature prevents callers from using Whisper Page Activate to page your telephone.

Blocking Whisper Page on your phone (your phone must be programmed for Whisper Page off)

Press the button your System Administrator has designated as the Whisper Page Off button.

Other parties can no longer page your phone using the Whisper Page Activate procedure.

Issue 1 July 2001

5-19

Page 45

5-20

Issue 1 July 2001

Page 46

Retrieving Voice Messages

Message Retrieval

Your message indicator lights when a caller has left you a message. Because voice mail systems are administered differently among customers, check your office procedures for message retrieval. For example, some telephone users may be authorized to retrieve messages for other telephones not equipped with a display.

To retrieve a message by dialing the voice mail system

Dial your voice mail system directly using the dial pad or, if one was programmed by your System Administrator, press the Line/Feature button for voice mail. Some systems also use softkeys for message retrieval.

Follow your standard voice mail retrieval procedures. Contact your System Administrator if you have questions.

Issue 1 July 2001

6-1

Page 47

6-2

Issue 1 July 2001

Page 48

IP Telephone Management Features

Introduction

This chapter explains how to interpret both the different ringer tones you hear and the telephone’s indicator lights. Also covered are testing your telephone to be sure it is operating properly, and personalizing your phone’s ringing pattern.

Interpreting Ringer Tones

As you become more familiar with your IP Telephone, you will recognize the various tones you hear in response to an incoming call or while using the handset. The chart below provides an overview of the tones you hear; check with your System Administrator to verify if the descriptions are accurate for your system.

Ringing Tones accompany an incoming call. Feedback Tones (as shown on the next page) are those which you hear through the handset (receiver) or the speaker.

Ringing (Incoming) Tones Meaning

1 Ring -------- Call from anot her extension. 2 Rings ------- ------- Call from outside or the System Administrator. 3 Rings ------ ------ ------ Priority call from another extension, or from an Automatic

Callback call you placed.

Half Ring (ring-ping) --- A call is being redirected from your phone to another

because Send All Calls or Call Forwarding All Calls is active.

Issue 1 July 2001

7-1

Page 49

Feedback (Handset) Tones Meaning

Busy --- --- --- Low-pitched, rapid tone (repeated 60 times per minute) ,

signifying the number dialed is in use.

Call Waiting Ringback Tone ---_

Confirmation -- -- -- Three short tone bursts; indicates a feature activation or

Coverage - One short tone burst; indicates your call will be sent to

Dial --------- Continuous tone indicating dialing can begin. Intercept/Time-out

-_-_-_-

Recall Dial - - - ----------- Three shorts tone bursts followed by a stea dy dial ton e to

Reorder -- -- -- -- -- -- Fast busy tone repeated every half-second to indicate all

Ringback ---- ---- ---- ---- Low-pitched tone repeated 15 times a minute to indicate

A ringback tone with lower-pitched signal at the end; indicates the extension called is busy and the called party has been given a call waiting tone. If you hear this tone, you may want to activate Automatic Callback.

cancellation has been accepted.

another extension to be answered by a covering user.

Alternating high and low tone indicating either a dialing error, denial of a requested service or failure to dial within a preset i nterval (usually 10 seconds) after lifting the handset or dialing the previous digit

indicate a feature request has been accepted and dialing can start.

phone trunk lines are busy.

the number dialed is ringing.

7-2

Issue 1 July 2001

Page 50

Personalizing Your Telephone's Ringing Pattern

The Select Ring feature lets you choose your own personalized ringing pattern from among eight different patterns.

Selecting a personalized ringing pattern

With the phone on-hook, press .

The current ringing pattern sounds and repeats every three seconds.

Continue to press (and then release) to cycle through each of the eight ring patterns.

To save a ringing pattern as it plays, do not continue to press . You hear the selected ringing pattern two more times, after which it is automatically saved.

A confirmation tone (two rising tones) sounds and your new ringing pattern is set.

NOTE:

Going off-hook, receiving a call or losing power during ring pattern selection interrupts the process, and you must start over from Step 1.

Interpreting Indicator Lights

As you become more familiar with your IP T elephone, you will recognize the lights associated with a Line/Feature button. The chart below provides an overview of the indicator lights you see; check with your System Administrator to verify if the descriptions are accurate for your system.

Light Meaning

Steady Red The line is available. Steady Green Indicates the line is in use or the

feature programmed for that button is

on (active). Blinking Green Indicates a call is on hold on this line. Flashing Green An incoming call is arriving on this

line. Fluttering Green This line's call was put on hold

pending a conference or a transfer.

Issue 1 July 2001

7-3

Page 51

Testing Your Phone

The Test feature lets you verify that your telephone's lights and display are operating properly.

Testing the telephone's lights and display

With the phone idle, press and hold .

The Line/Feature indicators light and the display lines each show 16 shaded blocks, representing the 16 characters available on each line.

To end the test, release .

The lights and display return to normal operation.

If any indicator light or the display does not respond during the test, contact your Telephone System Administrator.

7-4

Issue 1 July 2001

Page 52

Using a Headset or Specialized Handset

Introduction

This chapter describes the headsets and specialized handsets that are compatible with your IP telephone. How to operate a headset is also covered.

IP Telephone-Compatible Headsets

Use any of the following headsets with the 4600-Series IP Telephones:

■

Earset Starter Earset Starter Noise Canceling Encore Ultra VT Encore Ultra Noise Canceling Encore Ultra II Encore Ultra II Noise Canceling Mirage Ultra Mirage Ultra Noise Canceling Starset Supra Starter Starter Special VT Starter Special Noise Canceling Supra Starter Noise Canceling Supra Ultra Supra Ultra Noise Canceling Supra Ultra II Twin Top Supra Ultra II Noise Canceling Tristar Ultra

■

Tristar Ultra Noise Canceling

Issue 1 July 2001

8-1

Page 53

Operating a Headset

Headset operation must be administered by your System Administrator and requires either an M12LU Modular Base Unit (PEC 3124-022) or a 3124-HIC: Attenuation (headset adapter) Cord (PEC 3124-HIC). For the latest list of compatible headsets and adapters, or for ordering information, access "Products and Services" at www.avayadirect.com

IP Telephone-Compatible Specialized Handsets

The IP Phone's handset interface (labeled HAC on the underside of the phone) is compatible with the following handsets:

■

AB1C (the handset provided with your phone)

■

AB5C

■

AB6C

■

AB8C

Specialized handsets are available for noisy environments, hearing-impair ed users and other special purposes. These handsets are labeled either as "K-type" or "AJ-type" handsets.

For the latest list of special purpose handsets and ordering information, access "Products and Services" at www.avayadirect.com

8-2

Issue 1 July 2001

Page 54

Troubleshooting

Introduction

The DEFINITY 4600-Series IP Telephones are relatively trouble-free. The Basic Troubleshooting chart provides the most common problems an end user might encounter. The remaining pages in this chapter provide procedures for resetting or power-cycling your phone, when Basic Troubleshooting does not resolve the problem. For all other IP Telephone questions or problems, contact your Telephone System Administrator.

Basic Troubleshooting

Problem/Symptom Suggested Solution

Phone does not activate after connecting it the first time

Phone does not activate after a power interruption

Unless your System Administrator has already initialized your telephone, you may experience a delay of several minutes before it becomes operational. Upon plug-in, your telephone immediately begins downloading its operational software, its IP address and any special features programmed by your System Administrator from the server to which it is connected. Report any delay of more than 8-10 minutes to your System Administrator.

Allow a few minutes for re-initialization after unplugging, powering down the phone, server problems or other power interruption causes .

Issue 1 July 2001

9-1

Page 55

Characters do not appear on the Display screen

See "Phone does not activate after connecting it the first time" above.

Check the power source to be sure your telephone is receiving power.

Check all lines into the phone to be sure it is properly connected.

Perform the Test procedure: with the telephone idle, press and hold ; the line/feature indicators should light and the display should show all shaded blocks. Release to end the test.

If the above suggested solutions do not resolve the problem, reset or power cycle the phone.

Display shows an error/informational message

No dial tone Make sure both the handset and line cords

Most messages involve server/phone interaction. If you cannot resolve the problem based on the message received, contact your Telephone System Administrator for resolution.

into the phone are securely connected. Note that there may be a slight operational delay if you unplug and reconnect the phone.

If you have a 4612 or 4624 IP Telephone, check to be sure the phone is powered (press appears on the display, check your power source.

If you have a 4612 or 4624 IP Telephone, check to be sure your phone is communicating with the switch; press

(e.g., Timer). If the selected feature activates, the switch/IP phone connection is working.

, then any of the softkey features

, then

Exit

); if nothing

9-2

Issue 1 July 2001

Reset or power cycle the phone. See your Telephone System Administrator

if the above steps do not produce the desired result.

Page 56

Basic Troubleshoo ting

Echo, noise or static when using a headset; handset operation works properly

Phone does not ring If you have a 4612 or 4624 IP Telephone,

Check the headset connection. If the connection is secure, verify that you

are using an approved headset, base unit and/or adapter, as described in the list of approved Avaya Communication compatible Headsets in Chapter 8 of this guide.

use the Menu to access the (Ringer Off) feature; if a carat (downward triangle) appears above that feature, your phone is set to the softkey below does not display, your ringer is active.

If "Ringer Off" is programmed on a Line/Feature button, that button's indicator light will appear as steady green; reactivate the ringer by pressing that Line/Feature button again.

Set your ringer volume to a higher level using the Up/Down Volume keys.

From another phone, place a call to your extension to test the above suggested solutions.

not

ring. To correct, press

RngOf

; when the carat

Speakerphone does not operate

A feature does not work as indicated in the User Guide

All other IP Phone problems Contact your Telephone System

Ask your System Administrator if your Speakerphone has been disabled.

Verify the procedure and retry. For certain features, you must lift the handset first or place the phone off-hook.

See your Telephone System Administrator if the above action does not produce the desired result; your telephone system may have been specially programmed for certain features applicable only to your installation.

Administrator.

Issue 1 July 2001

9-3

Page 57

Resetting and Power Cycling the IP Telephone

Reset your IP Telephone when other Troubleshooting suggestions do not correct the problem. Use a Power Cycle with the approval of your System Administrator

only

when a reset does not resolve the problem.

Resetting your phone

This basic reset procedure should resolve most problems.

1. Press .

2. Using the dial pad, press the following keys in sequence:

The display shows the message "Reset values? * = no # = yes."

3. Choose one of the following:

If you want to Then

Reset the phone without resetting any assigned values

Reset the phone and any previously assigned (programmed) values

(Use this option only if your phone has programmed, static values)

Press * (asterisk).

A confirmation tone sounds and the display prompts "Restart phone? * = no # = yes."

Press # (the pound key).

The display shows the message "Resetting values" while your IP Telephone resets its programmed values, such as the IP address, to its default values, and re-establishes the connection to the server. The display then prompts "Restart phone? * = no # = yes."

73738#

9-4

Issue 1 July 2001

4. Press # to restart the phone or * to terminate the restart and restore the phone to its previous state.

NOTE:

Any reset/restar t of your phone may take a few minutes.

Page 58

Resetting and Power Cycling the IP Telephone

Power cycling the phone

Use the power cycle with your System Administrator’s approval only if the basic or programmed reset procedure cannot be performed or does not correct the problem:

1. Unplug the phone and plug it back in.

The phone connection is re-established.

2. If power-cycling does not correct the problem, your System Administrator can perform a more severe power cycle routine by unplugging both the phone and the Ethernet cables.

WARNING:

Because the type of power cycle mentioned in Step 2 involves reprogramming certain values, it should only be performed by your Telephone System Administrator.

Issue 1 July 2001

9-5

Page 59

9-6

Issue 1 July 2001

Avaya DEFINITY 4606 IP Telephone User's Guide

Copyright and Legal Notices

About This Document

Purpose

Intended Audience

Issue Date

How to Use This Document

Document Organization

Conventions Used

Symbolic Conventions

Typographic Conventions

Related Documentation/Training

4606 IP Telephone Description

Introduction

The 4606 IP Phone

Using Programmable Buttons

Introduction

Programmable Line/Feature Buttons

IP Telephone Features Available on Programmable Line/Feature Buttons

Using the Display Screen

Introduction

About the Display Screen

Upper Display Line

Lower Display Line

Line/Feature Button Information

Call Information

Call Handling Features

Introduction

Conference

Adding another party to a call

Adding a held call to the current call

Dropping the last person added to the confer ence call

Hold

Placing a call on hold

Returning to the held call

Mute

Preventing the other person on the line from hearing you

Redial

Redialing the last number called

Speakerphone

Placing a call without l ift in g the handset or using the Speakerphone with any feature

Changing from the speakerphone to the handset

Turning the speaker on during a call

Turning the speaker off during a call

Ending a call while the speaker is active

Transfer

Sending a call to another telephone

IP Telephone Features

Introduction

Accessing IP Telephone Features

Feature List

Abbreviated Dialing (AD)

Placing an Abbreviated Dialing call

Account

Automatic Callback

Canceling Automatic Callback

Automatic Intercom

Button View

Viewing the feature programmed on a Line/Feature button

Call Display

Call Forwarding

Temporarily sending your calls to another phone

Canceling Call Forwarding

Call Park

Parking a call at your extension

Retrieving a parked call from another extension

Call Pickup and Directed Call Pickup

Answering a call placed to someone in your pickup group (when your phone is idle)

Picking up a call for someone in your office using Directed Call Pickup

Consult

Directory

Using the Directory feature

Calling the person whose name is displayed

Drop (a Person from a Conference Call)

Exclusion

Group Paging

Hands Free Answer on Intercom

Headset On/Off

Inspect

Using the Inspect feature:
