Avanti WC34N2P User Manual

INSTRUCTION MANUAL

MANUAL DE INSTRUCCIONES

MANUEL D’INSTRUCTION

Model Number / No. de Modelo / No de Modèle:

WINE CHILLER / VINERA / CELLIER

WC34N2P

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.

Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice.

Avanti Products LLC,

P.O. Box 520604 - Miami, Florida 33152

www.avantiproducts.com

TABLE OF CONTENTS

Help Us Help You

Parts and Features

Important Safety Instructions

5 – 7

Installation Instructions

Before Using Your Wine Chiller

Installation of Your Wine Chiller

Electrical Connection

Extension Cord / Surge Protector

Operating Your Wine Chiller

Control Panel

Setting the Temperature

Storage Capacity

Interior Light

Care and Maintenance

Cleaning Your Wine Chiller

Power Failure

Vacation Time

Moving Your Wine Chiller

Energy Saving Tips

Troubleshooting Guide

Service for Your Appliance

Wiring Diagram

Your Avanti Products War rant y

Instrucciones en Español

15 – 17

Instructions en Français

18 – 29

Registration Information and Registration Card

Last

Page

CAUTION:

HELP US HELP YOU...

Read this guide carefully.

It is intended to help you operate and maintain your new Wine Chiller properly.

Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call:

Avanti Customer Service 800-220-5570

Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period.

THIS WINE CHILLER IS NOT DESIGNED FOR THE STORAGE OF MEDICINE OR OTHER MEDICAL PRODUCTS.

IF YOU NEED SERVICE

We're proud of our ser vice and want you to be pleased. If for som e reason you are not happ y with the service you receive, here are some steps to follow for further assistance. FIRST, contact the people who serviced your Wine Chiller. Ex pla in wh y you are not ple ased. In most cases, this will solve the problem.

Write down the model and serial numbers.

You'll find them on a plate located on the rear outside wall of the Wine Chiller.

Please write these numbers here:

____________________________________ Date of Purchase

____________________________________ Model Number

____________________________________ Serial Number

Use these numbers in any correspondence or service calls concerning your Wine Chiller.

If you received a damaged Wine Chiller, immediately contact t he de aler (or bu ilder) that sold you the Wine Chiller.

Save time and money. Before you call for service, check the Troubleshooting Guide. It lists causes of minor operating problems that you can correct yourself.

NEXT, if you are still not pleased, write all the details, including your telephone number, and send it to:

Customer Servic e

Avanti Products 10880 NW 30 Street Miami, FL 33172 USA

1. Wine Shelves (Total 6)

PARTS & FEATURES

2. Lower Storage Bar (Total 1)

3. Leveling Leg

4. Top Hinge with Cover

5. Control panel (Front of Door)

6. Glass Door with Integrated Handle

APPLIANCE SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

Warning means that failure to heed this

or death.

All safety messages will alert you to what the potential hazard is, tell you how to reduce the chance of injury, and let you know what can happen if the instructions are not followed.

This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the Safety Alert Symbol and either the wards” DANGER”, “WARNING” or “CAUTION”.

Danger means that failure to heed this safety statement may result in severe personal injury or death.

safety statement may result in extensive product damage, serious personal injury,

Caution means that failure to heed this safety statement may result in minor or moderate personal injury, or property or equipment damage.

REFRIGERANT GAS WARNINGS / AVERTISSEMENTS GAZ REFRIGERANT

DANGER - Risk of fire or explosion. Flammable refrigerant used.

DO NOT use mechanical devices to defrost wine chiller. DO NOT puncture refrigerant tubing.

DANGER - Risque d’incendie ou d’explosion. Réfrigérant inflammable utilisé. Ne pas utiliser de dispositifs mécaniques pour cellier à dégivrage. Ne pas percer la tuyauterie du réfrigérant

DANGER - Risk of fire or explosion. Flammable refrigerant used. To be repaired only by trained service personnel. DO NOT puncture refrigerant tubing.

DANGER - Risque d’incendie ou d’explsion. Réfrigérant inflammable utilisé. Pour être réparé que par du peronnel qualifié.Ne pas percer la tuyauterie du réfrigérant.

CAUTION - Risk of fire or explosion. Flammable refrigerant u sed. Consult repair manual / owner’s guide before attempting to service this product. All safety precautions must be followed.

AVERTISSEMENT - Risque d’incendie ou d’explosion. Réfrigérant inflammable utilisé. Consultez réparation manuelle / propriétaire, guide avant d’ essayer de réparer ce produit. Toutes les précautions doivent être suivies.

CAUTION - Risk of fire or explosion. Dispose of property in acc ordance with federal or local regulations. Flammable refrigerant used.

AVERTISSEMENT - Risque d’incendie ou d’explosion. Aliéner des biens conformément à la réglementation fedérale ou loca le. Réfrigérant inflammable utilisé.

CAUTION - Risk of fire or explosion due to puncture of refrigerant tubing; Follow handling instructions carefully. Flammable refrigerant used.

AVERTISSEMENT - Risque d’incendie ou d’explosion dus à la perforation des tuyaux de fluide réfrigérant, suivez attentivement les instructions remise. Réfrigérant inflammable utilisé

CAUTION-To Prevent A Child From Being Entrapped, Keep Out Of Reach Of Children And Not In The Vicinity Of Freezer (Or Refrigerator).

CAUTION-Risk of Fire

IMPOR TANT SAFEGU ARDS

Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and

recommended in this material. All other servicing should be referred to a qualified technician.

• Use two or more people to move and install the appliance. Failure to do so can result in back or

• Do not use this apparatus for other than its intended purpose.

Before the appliance is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the appliance, follow basic precautions,

do not use an extension cord

• Replace all panels before operating

• It is recommended that a separate circuit, serving only your appliance, be provided. Use receptacles that cannot be turned off by a switch or pull chain

• Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.

• Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is disconnected.

• Do not connect or disconnect the electric plug when your hands are wet

• Unplug the appliance or disconnect the power before cleaning or servicing. Failure to do so can result in electrical shock or death.

• Do not attempt to repair or replace any part of your appliance unless it is specifically

including the following:

other injury.

• To ensure proper ventilation for your appliance, the unit must be completely unobstructed. Choose a well-ventilated area with temperatures above 55 This unit must be installed in an area protected from the elements, such as wind, rain, water spray or sunlight.

• The appliance should not be located next to ovens, grills or other sources of high heat.

• The appliance must be installed with all electrical, water and drain connections in accordance with state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in accordance with the National Electrical Code and local codes and ordinances is required.

• Do not kink or pinch the power supply cord of the appliance.

• The fuse (or circuit breaker) size should be 15 amperes.

• It is important for the appliance to be leveled in order to work properly. You may need to make several adjustments to level it.

• All installation must be in accordance with local plumbing code requirements.

• Make certain that the pipes are not pinched or kinked or damaged during installation.

• Check for leaks after connection.

• Never allow children to operate, play with or crawl inside the appliance

• Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may

damage or discolor the interior.

F (130C) and below 900F (32 0C).

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of fire, electrical shock, these basic precautions:

-Save these instructions-

WARNING~

or injury when using your appliance, follow

• Read all instructions before using the Wine Chiller.

• DANGER or WARNING: Risk of child entrapment.

Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are still dangerous . . . even if they will “just sit in the garage a few days”.

• Before you throw away your old Wine Chiller: Take off the door. Leave the

shelves in place so that children may not easily climb inside.

• Never allow children to operate, play with, or crawl inside the appliance.

• Never clean appliance parts with flammable fluids. The fumes can create a fire

hazard or explosion.

• Do not store or use gasoline or any other flammable vapors and liquids in the vicinity

of this or any other appliance. The fumes can create a fire hazard or explosion.

• Do not repair or replace any part of the refrigerator or attempt a ny servicing unless

specifically recommended in the user-maintenance instructions or in published userrepair instructions. Replace the fuse with the same type.

INSTALLATION INSTRUCTIONS

Ø Before Using Your Wine Chiller

• Remove the exterior and interior packing.

• Check to be sure you have all of the following parts:

• 6 Shelves

• 1 Instruction Manual

• Clean the interior surface with lukewarm water using a soft cloth.

Ø Installation of Your Wine Chiller Ø This Wine Chiller is designed for free standing installation only and should not be recessed nor

built-in (fully recessed).

Ø Allow 5 inches of space between the top and sides of the unit which allows the proper

air circulation to cool the compressor.

• Locate the Wine Chiller away from direct sunlight and sources of heat (stove, heater, radiator,

etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform properly.

• Avoid locating the unit in moist areas.

• Plug the Wine Chiller into an exclusive, properly installed-grounded wall outlet. Do not under

any circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized Avanti Products s ervice cen ter .

• After plugging the Wine Chiller into a wall outlet, allow the unit to cool down for 2-3 hours

before placing any items in the compartment.

~Warning~

Ø ELECTRICAL CONNECTION

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized Avanti Products serv ice cent er .

This appliance should be p roperly grounded for your saf ety. The power cord of this appliance is equipped with a three-prong plug which mates with standar d three prong wall ou tlets to minimize the possibility of electrical shock.

Do not under any circumstances cut or remove the third ground prong from the power cord supplied. For personal safety, this appliance must be properly grounded.

This appliance requires a standard 115/120 Volt AC ~/60Hz electrical ground outlet with threeprong. H ave the wall outlet and circuit check ed by a qualified elect rician to mak e sure the outlet is properly grounded. W hen a standard 2-prong wall outlet is encountered, it is your responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

The cord should be secured behind the appliance and not left exposed or dangling to prevent accidental injury.

The appliance should always be plugged int o its o wn indi vidua l electrical outlet which has a voltage rating that matches the rati ng label on t he appli ance. This provi des the bes t perf orm ance and also prevent overloading house wiring circuits that could c ause a fire hazard from overheated. Never unplug the appliance b y pulling the power cord. Always grip the plug firm ly and pull straight out from the receptacle. Repair or replace imm ediately all power cords that have become fra yed or otherwise damaged. Do no t use a cord that shows crac ks or abrasion damage alo ng its length or at either end. When moving the appliance, be careful not to damage the power cord.

Ø EXTENSION CORD Because of potential safety hazards under certain conditions, it is strongly recommended that you do not use an extension cord with this appliance. However, if you must use an extension cord it is absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes.

Ø SURGE PROTECTOR Most electrical appliances use a series of electric control boards to operate. These boards are very susceptible to power surges and could be damaged or destroyed.

If the appliance is going to be used in an area or if your city / country is prone to power surges / outages; it is suggested that you use a power surge protector for all electrical devices / appliances you use. The surge protector that you select must have a surge block high enough to protect the appliance it is connected to. If you have any questions regarding the type and size of surge protector needed contact a licensed electrician in your area.

Damages due to power surges are not considered a manufacturer covered defect and will void your product warranty.

OPERATING YOUR WINE CHILLER

Red Wines

15º - 18º C

58 – 65º F

Dry/White Wines

9º - 14º C

48 – 57º F

Rose Wines

10º - 11º C

49 – 51º F

Sparkling Wines

5º - 9º C

40 – 47º F

Temperature Range

5 - 18º C

40 – 65º F

You can select temperature display setting from Fahrenheit to Celsius degree by pushing

It is recommended you install the Wine Chiller in a place where the ambient temperature is between 23º-26ºC/ 72º-78ºF. If the ambient temperature is above or below recommended temperatures, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. The range of 5º18ºC/40º-65ºF may not be reached.

Recommended Temperatures for Chilling Wine.

Temperature Ranges For Your Wine Chiller

CONTROL PANEL

and holding the button until the display changes

Ø CONTROL PANEL LOCK

Your cooler is equipped with a control panel lock feature which will lock itself automatically 20 seconds after the last time a button is pressed.

Press the the control is now active.

SETTING THE TEMPERATURE CONTROL

Ø You can manually adjust the temperature inside Cooler by pressing the buttons on the display

panel. The two buttons on the panel 1ºC or 1ºF .

Ø When you store mostly red wines, the temperature which you control by pushing the above two

buttons need to be set at between 15º - 18ºC (58º - 64ºF).

Ø When you store mostly white wines, the temperature needs to be set at between 8º - 14ºC (46º

- 57ºF).

Ø When you store mostly sparkling wines, the temperature needs to be set at between 8º - 9ºC

(46º - 47ºF).

button to unlock the c ontrol panel. You will hear a “BEEP” soun d to alert you tha t

and adjust the temperature in increments of
