Avanti W752PC User Manual
Specifications and Main Features
- Model Numbers: W751SC / W752PC
- Hot Water Supply Hose
- Cold Water Supply Hose
- Drain Hose Pump
- Absorbing Panel & Screw
- Male and Female Hose Thread Adapters
- Support Legs
- Power supply: Standard 115/120 volt, 60 Hertz.
- Grounding: Three prong plugs for grounded outlets.
- Washing courses: Fuzzy, heavy, speedy, wool.
- Functions: Wash + rinse + spin, soak + wash + rinse + spin, wash + rinse, spin, rinse + spin, delay start.
- Water levels: Medium, high, extra low, low.
- Control panel: Power button, Start/Hold button, Course select button, Function select button, Water Level select button, Water Supply select button, Delay start button, Remaining time indicator light, Function indicator light.
- Water connection: Dual water inlets (hot & cold)
- Maximum Water Temperature: 60C, 140F
- Cleaning Features: Boomerang pulsator, Magic filter for lint collection
- Dimensions: Adjustment of legs for leveling.
- Weight: Tba upon actual inspection of the product.
Frequently Asked Questions
Q: What is the maximum water temperature the washer can handle?
A: The washer can handle a maximum water temperature of 60C, 140F.
Q: How can I choose a washing course?
A: Upon a press of Course Select Button, available options include Fuzzy, Heavy, Speedy and Wool with the respective setting: From left to right.
Q: Is it possible to set a time for a delay start of the wash time?
A: You are allowed to set a time for the delay to start wash time by making use of Delay Start Button.
Q: Is it right to say that the machine guesses the water level?
A: Indeed, Fuzzy and Heavy courses are programmed to automatically set the water level corresponding to the selected washload.
Q: How do I proceed when the water is not pumped out?
A: Make sure the drain hose has no kinks in it and it is not twisted or frozen in position.
Q: Is this machine suitable for woolen clothes?
A: There is also a course for wool to wash with cold water at a high or medium level – this is appropriate to those delicate garments.
